Samsung DA68-02787A User manual

English
Refrigerator
user manual
imagine the possibilities
Thank you for purchasing a Samsung product.
Free Standing Appliance
DA68-02787A (EN)-05.indd 1 2017. 8. 9. �� 10:51

02_ safety information
SAFETY INFORMATION
• Before using your new Samsung
Refrigerator, please read this
manual thoroughly to ensure
that you know how to operate
the features and functions that
your new appliance offers safely
and efficiently.
• This appliance is not intended
for use by persons (including
children) with reduced physical,
sensory, or mental capabilities,
or those who lack experience
and knowledge, unless they
have been given supervision or
instruction concerning the use
of the appliance by a person
responsible for their safety.
• This appliance can be used
by children aged from 8 years
and above and persons with
reduced physical, sensory or
mental capabilities or lack of
experience and knowledge
if they have been given
supervision or instruction
concerning use of the appliance
in a safe way and understand
the hazards involved. Children
shall not play with the
appliance. Cleaning and user
maintenance shall not be made
by children without supervision.
• Warnings and Important Safety
Instructions in this manual do
not cover all possible conditions
and situations that may occur.
It is your responsibility to use
common sense, caution,
and care when installing,
maintaining, and operating your
appliance.
• Because these following
operating instructions
cover various models, the
characteristics of your
refrigerator may differ slightly
from those described in this
manual and not all warning
signs may be applicable.
If you have any questions or
concerns, contact your nearest
service center or find help and
information online at www.
samsung.com.
• R-600a or R-134a is used
as a refrigerant. Check the
compressor label on the rear
of the appliance or the rating
label inside the fridge to see
which refrigerant is used for
your refrigerator. When this
product contains flammable gas
(Refrigerant R-600a), contact
your local authority in regard to
safe disposal of this product.
• In order to avoid the creation of
a flammable gas-air mixture if
safety information
DA68-02787A (EN)-05.indd 2 2017. 8. 9. �� 10:51

safety information _03
a leak in the refrigerating circuit
occurs, the size of the room in
which the appliance may be
sited depends on the amount
of refrigerant used.
• Never start up an appliance
showing any signs of damage.
If in doubt, consult your dealer.
The room must be 1 m³ in
size for every 8 g of R-600a
refrigerant inside the appliance.
The amount of refrigerant in
your particular appliance is
shown on the identification
plate inside the appliance.
• Refrigerant squirting out of the
pipes could ignite or cause an
eye injury. When refrigerant
leaks from the pipe, avoid
any naked flames and move
anything flammable away from
the product and ventilate the
room immediately.
- Failing to do so may result in
fire or explosion.
• It is hazardous for anyone
other than an Authorized
Service Person to service this
appliance. In Queensland –
the authorized Service Person
MUST hold a Gas Work
Authorization or Licence for
hydrocarbon refrigerants, to
carry out Servicing or repairs
which involve the removal of
covers. (For Australia only)
Important safety symbols and
precautions:
WARNING
Hazards or unsafe
practices that may result
in severe personal injury or
death.
CAUTION
Hazards or unsafe
practices that may result
in minor personal injury or
property damage.
Do NOT attempt.
Do NOT disassemble.
Do NOT touch.
Follow directions carefully.
Unplug the power plug
from the wall socket.
Make sure the refrigerator
is grounded to prevent
electric shock.
Call the contact center for
help.
Note.
These warning signs are here to
prevent injury to you and others.
Please follow them carefully.
After reading this section, keep
it in a safe place for future
reference.
DA68-02787A (EN)-05.indd 3 2017. 8. 9. �� 10:51

04_ safety information
SEVERE WARNING SIGNS
FOR INSTALLATION
• Do not install the
refrigerator in a damp place
or place where it may come
in contact with water.
- Deteriorated insulation of
electrical parts may cause an
electric shock or fire.
• Do not place this refrigerator in
direct sunlight or expose to the
heat from stoves, room heaters
or other appliance.
• Do not plug several appliances
into the same multiple power
strip. The refrigerator should
always be plugged into its
own individual electrical outlet
which has a voltage rating that
matches the voltage listed on
the refrigerator’s rating plate.
- This provides the best
performance and also prevents
overloading house wiring
circuits, which could cause a
fire hazard from overheated
wires.
• If the wall socket is loose, do
not insert the power plug.
- There is a risk of electric shock
of fire.
• Do not use a cord that shows
cracks or abrasion damage
along its length or at either end.
• Do not bend the power cord
excessively or place heavy
articles on it.
WARNING
• Never unplug your refrigerator
by pulling on the power cord.
Always grip plug firmly and pull
straight out from the outlet.
- Damage to the cord may cause
a short-circuit, fire and/or
electric shock.
• Do not use aerosols near the
refrigerator.
- Aerosols used near the
refrigerator may cause an
explosion or fire.
• Do not install this appliance
near a heater, inflammable
material.
• Do not install this appliance in
a humid, oily or dusty location,
in a location exposed to direct
sunlight and water (rain drops).
• Do not install this appliance in a
location where gas may leak.
- This may result in an electric
shock or fire.
• This appliance must be properly
grounded. Do not ground the
appliance to a gas pipe, plastic
water pipe, or telephone line.
- You must ground the refrigerator
to prevent any power leakages
or electric shocks caused
by current leakage from the
refrigerator.
- This may result in an electric
shock, fire, explosion, or
problems with the product.
• This appliance should be
DA68-02787A (EN)-05.indd 4 2017. 8. 9. �� 10:51

safety information _05
positioned in such a way that it
is accessible to the power plug.
- Failing to do so may result in
an electric shock or fire due to
electric leakage.
• Do not stand on top of the
appliance or place objects (such
as laundry, lighted candles,
lighted cigarettes, dishes,
chemicals, metal objects, etc.)
on the appliance.
- This may result in an electric
shock, fire, problems with the
product, or injury.
• Do not store explosive
substances such as aerosol
cans with a flammable
propellant in this appliance.
• This refrigerator must be
properly installed and
located in accordance
with the manual before it is
used.
• Connect the power plug in the
proper position with the cord
hanging down.
- If you connect the power plug
upside down, the wire can
get cut off and cause a fire or
electric shock.
• When moving the refrigerator,
be careful not to roll over or
damage the power cord.
- This constitutes a fire hazard.
• Make sure that the power plug
is not squashed or damaged by
the back of the refrigerator.
• Keep the packing materials out
of reach of children.
- There is a risk of death from
suffocation if children put them
on their head.
• The appliance must be
positioned so that the plug is
accessible after installation.
• You need to remove all the
protective plastic film before
you initially plug the product in.
• When disposing of this or
other refrigerator/s, remove
the door/door seals, door latch
so that children or animals
cannot become trapped inside.
Children should be supervised
to ensure that they do not enter
and play with the appliance.
- If trapped inside, the child may
become injury and suffocate to
death.
• If the power cord is
damaged, have it replaced
immediately by the
manufacturer or its service
agent.
DA68-02787A (EN)-05.indd 5 2017. 8. 9. �� 10:51

06_ safety information
INSTALLATION CAUTIONS
• Allow sufficient space to
install the refrigerator on a
flat surface.
- If your refrigerator is not level,
the internal cooling system may
not work correctly.
• Keep the ventilation space in
the appliance enclosure or
mounting structure clear of
obstruction.
• We recommend you have
installed this refrigerator by a
qualified technician or service
company.
- Failing to do so may result in an
electric shock, fire, explosion,
problems with the product, or
injury.
• Plug the power plug into the
wall socket firmly. Do not
use a damaged power plug,
damaged power cord or loose
wall socket.
- This may result in an electric
shock or fire.
• Do not plug several appliances
into the same multiple power
board. The refrigerator should
always be plugged into its
own individual electrical outlet
which has a voltage rating that
matched the rating plate.
- This provides the best
performance and also prevents
overloading house wiring
CAUTION circuits, which could cause a
fire hazard from overheated
wires.
• Do not pull or excessively bend
the power cord.
• Do not twist or tie the power
cord.
• Do not hook the power cord
over a metal object, place a
heavy object on the power
cord, insert the power cord
between objects, or push the
power cord into the space
behind the appliance.
- When moving the refrigerator,
be careful not to roll over or
damage the power cord
- This may result in an electric
shock or fire.
• The installation or any service of
this appliance is recommended
by a qualified technician or
service company.
- Failing to do so may result in an
electric shock, fire, explosion,
problems with the product or
injury.
DA68-02787A (EN)-05.indd 6 2017. 8. 9. �� 10:51

safety information _07
CRITICAL USAGE
WARNINGS
• Do not insert the power
plug with wet hands.
• Do not store articles on the top
of the appliance.
- When you open or close the
door, the articles may fall and
cause personal injury and/or
material damage.
• Do not put a container filled
with water on the refrigerator.
- If spilled, there is a risk of fire or
electric shock.
• Children should be supervised
to ensure that they do not play
with the appliance.
• Keep fingers out of “pinch
point” areas; clearances
between the doors and cabinet
are necessarily small. Be careful
when you open the doors when
children are in the area.
• Do not let children hang on the
door. If not, a serious injury may
occur.
• There is a Risk of children
entrapment. Do not let children
enter inside the refrigerator.
• Never put fingers or other
objects into the dispenser hole,
ice chute and ice maker bucket.
- It may cause a personal injury
or material damage.
• Do not use or place any
substances sensitive
WARNING
to temperature such
as inflammable sprays,
inflammable objects, dry ice,
medicine, or chemicals near or
inside of the refrigerator.
• Do not keep volatile or
inflammable objects or
substances (benzene, thinner,
propane gas, alcohol, ether, LP
gas and other such products
etc.) in the refrigerator.
- This refrigerator is for storing
food only.
- This may result in fire or
explosion.
• If you smell pharmaceutical or
smoke, pull out power plug
immediately and contact your
Samsung Electronics service
center
• Do not insert your hands into
the bottom area under the
appliance.
- Any sharp edges may cause
personal injury.
• Do not let children step on a
drawer’s cover.
- The drawer may break and
cause them to slip.
• Do not touch the inside walls of
the freezer or products stored
in the freezer with wet hands.
- This may cause frostbite.
• Never put fingers or other
objects into the water dispenser
hole, ice chute, or ice maker
DA68-02787A (EN)-05.indd 7 2017. 8. 9. �� 10:51

08_ safety information
bucket.
- It may cause personal injury or
material damage.
• Do not store pharmaceuticals
products, scientific materials, or
temperature sensitive products
in the refrigerator.
- Products that require strict
temperature controls must not
be stored in the refrigerator.
• Do not place or use an
electrical appliance inside the
refrigerator, unless it is of a
type recommended by the
manufacturer.
• Do not use mechanical
devices or any other means
to accelerate the defrosting
process, other than those
recommended by the
manufacturer.
• Do not damage the refrigerant
circuit.
• Do not spray volatile material
such as insecticide onto the
surface of the appliance.
- As well as being harmful to
humans, it may also result in an
electric shock, fire or problems
with the product.
• Never stare directly at the UV
LED lamp for long periods of
time.
- This may result in eye strain due
to the ultraviolet rays.
• Keep ventilation opening in
the appliance enclosure or
mounting structure clear of
obstruction.
• Do not touch the power plug
with wet hands.
- This may result in an electric
shock.
• Do not insert hands, feet
or metal objects (such as
chopsticks, etc.) into the
bottom or the back of the
refrigerator.
- This may result in an electric
shock or injury.
- Any sharp edges may cause a
personal injury.
• Do not attempt to repair,
disassemble, or modify the
appliance yourself.
- Do not use any fuse(such as
cooper, steel wire, etc.) other
than the standard fuse.
- When repairing or reinstalling
the appliance is required,
contact your nearest service
center.
- Failing to do so may result in an
electric shock, fire, problems
with the product, or injury.
• If any dust or water is in
refrigerator, pull out the power
plug and contact your Samsung
Electronics service center.
- Otherwise there is a risk of fire.
• Do not use a hair dryer to dry
the inside of the refrigerator. Do
DA68-02787A (EN)-05.indd 8 2017. 8. 9. �� 10:51

safety information _09
not place a lighted candle in
the refrigerator to remove bad
odors.
- This may result in an electric
shock or fire.
• Fill the water tank, ice tray, and
water cubes only with potable
water.
• Do not disassemble or
repair the refrigerator by
yourself.
- You run risk of causing a fire,
malfunction and/or personal
injury.
- When the interior or exterior
LED lamp has gone out, please
contact your service agents.
• Bottles should be stored
tightly together so that they
do not fall out.
• This product is intended only
for the storage of food in a
domestic environment.
• If a gas leak is detected, avoid
any naked flames or potential
sources of ignition and air the
room in which the appliance is
standing for several minutes.
• If there are burning smells
or smoke, pull out power
plug immediately and
contact your Samsung
Electronics service center.
• If the product is equipped
with LED Lamps, do not
disassemble the Lamp Cover
and LED Lamp by yourself.
- Please contact your service
agents.
• Use only the LED Lamps
provided by manufacturer or
service agents.
a) Allow the appliance to stand for
2hours after installation.
b) To get Best performance from
the product,
1) Do not place foods too
closely in front of the vents
at the rear of the appliance
as it can obstruct free air
circulation in the freezer
compartment.
2) Wrap the food up properly or
place it in airtight containers
before putting it into the fridge
or freezer.
3) Do not put any newly
introduced food for freezing
near to already existing food.
c) Do not place glass or bottles or
carbonated beverages into the
freezer.
- The container may freeze
and break, and this may
result in injury.
d) Please observe maximum
storage times and expiry dates
of frozen goods.
e) There is no need to disconnect
the refrigerator from the power
DA68-02787A (EN)-05.indd 9 2017. 8. 9. �� 10:51

10_ safety information
supply if you will be away for
less than three weeks. But,
Remove all the food if you are
going away for the three weeks
or more. Unplug the refrigerator
and clean it, rinse and dry.
USAGE CAUTIONS
• Do not re-freeze frozen
foods that have thawed
completely. Do not place
carbonated or fizzy drinks
in the freezer compartment.
Do not put bottles or glass
containers in the freezer.
- When the contents freeze, the
glass may break and cause
personal injury.
• Use only the ice maker provided
with the refrigerator. The water
supply to this refrigerator must
only be installed/connected by
a suitably qualified person and
connected to a potable water
supply only.
• In order to operate the ice maker
properly, water pressure of 138
kPa ~ 860 kPa is required. If
you have a long vacation or
business trip and won’t use
water or ice dispensers, close
the water valve.
- Otherwise, water leakage may
occur.
• Wipe excess moisture from
the inside and leave the doors
CAUTION
open.
- Otherwise, odor and mold may
develop.
• When the refrigerator got wet
by water, pull out the power
plug and contact your Samsung
Electronics service center.
• Take out the right box in the
refrigerator after removing the
guard(LMF-RL22*)
• Service warranty and
Modification.
- Any changes or modifications
performed by a 3rd party on
this finished appliance are
not covered under Samsung
warranty service, nor can
Samsung be responsible for
safety issues that result from
3rd party modifications.
• Do not block air holes.
- If the air holes are blocked,
especially with a plastic bag, the
refrigerator can be over cooled.
If this cooling period lasts too
long, the water filter may break
and cause water leakage.
• If the refrigerator is
disconnected from the power
supply, you should wait for
at least five minutes before
plugging it back in.
• If you have a long vacation
planned or the refrigerator is
not to be used for a long period
DA68-02787A (EN)-05.indd 10 2017. 8. 9. �� 10:51

safety information _11
of time, you must empty the
refrigerator and pull out the
power plug.
- Letting the refrigerator run
for a long time without using
it can cause the insulation to
deteriorate and may cause a
fire.
- Wipe excess moisture from
the inside and leave the doors
open. Otherwise, odor and
mold may develop.
• To get the best performance
from the product:
- Do not place foods too close
to the vents at the rear of the
appliance as it can obstruct free
air circulation in the refrigerator
compartment.
- Wrap food up properly or place
it in airtight containers before
putting it into the refrigerator.
• If the product is flooded,
make sure to contact your
nearest service center.
- There is a risk of electric shock
or fire.
• Do not keep vegetable oil in
your refrigerator’s door bins.
The oil can solidify, making it
foul-tasting and difficult to use.
In addition, the open container
can leak and the leaked oil can
cause the door bin to crack.
After opening an oil container, it
is best to keep the container in
a cool and shaded place such
as a cupboard or pantry.
- Examples of vegetable oil: olive
oil, corn oil, grape-seed oil, etc.
CLEANING CAUTIONS
• Do not directly spray water
on the inside or outside the
refrigerator.
- There is a risk of fire or electric
shock.
• Remove any foreign matter
or dust from the power
plug pins. Do not use a
wet or damp cloth when
cleaning the plug.
- Otherwise, there is a risk of fire
or electric shock.
• Unplug the refrigerator
before cleaning or making
repairs.
• Remove all foreign substances
such as dust or water from
the power plug terminals and
contact points using a dry cloth
on a regular basis.
- Unplug the power plug and
clean it with a dry cloth.
- Failing to do so may result in an
electric shock or fire.
• Before cleaning or performing
maintenance, unplug the
appliance from the wall socket.
CAUTION
DA68-02787A (EN)-05.indd 11 2017. 8. 9. �� 10:51

12_ safety information
- Failing to do so may result in an
electric shock or fire.
• Do not clean the appliance by
spraying water directly onto it.
• Do not use benzene, thinner, or
Clorox, Chloride for cleaning.
- They may damage the surface
of the appliance and may cause
a fire.
• Do not spray inflammable gas
near the refrigerator.
- There is a risk of explosion or
fire.
• Install the appliance in a
cool, dry room with adequate
ventilation.
• Ensure that it is not exposed
to direct sunlight and never put
it near a direct source of heat
(radiator, for example).
• Never block any vents or grilles
on the appliance. Allow warm
food to cool down before
placing it in the appliance.
• Put frozen food in the
refrigerator to thaw. You can
then use the low temperatures
of the frozen products to cool
food in the refrigerator.
• Do not keep the door of the
appliance open for too long
when putting food in or taking
food out.
• The shorter time for which the
door is open, the less ice will
form in the freezer.
• Allow clearance to the right, left,
back and top when installing.
• This will help reduce power
consumption and keep your
energy bills lower.
• In the event of a power failure,
call the local office of your
Electricity Company and ask
how long it is going to last.
- Most power failures that are
corrected in an hour or two
will not affect your refrigerator
temperatures. However, you
should minimize the number of
door openings while the power
is off.
- But Should the power failure
last more than 24hours, remove
all frozen food.
• If the key is provided with
refrigerator, the keys should be
kept out of the reach of children
and not be in the vicinity of the
appliance.
• The appliance might not
operate consistently (possibility
of defrosting of co tents or
temperature becoming too
warm in the frozen food
compartment) when sited for
an extended period of time
below the cold end of the range
of temperatures for which
the refrigerating appliance is
designed.
• Do not store food which goes
DA68-02787A (EN)-05.indd 12 2017. 8. 9. �� 10:51

safety information _13
bad easily at low temperature,
such as bananas, melons.
• Your appliance is frost free,
which means there is no
need to manually defrost your
appliance, as this will be carried
out automatically.
• Temperature rise during
defrosting can comply with ISO
requirements. But If you want
to prevent an undue rise in the
temperature of the frozen food
while defrosting the appliance,
please wrap the frozen food up
in several layers of newspaper.
• Any increase in temperature of
frozen food during defrosting
can shorten its storage life.
• Do not re-freeze frozen foods
that have thawed completely.
• To prevent children entrapment,
you must reinstall the divider
using provided screw after
cleaning or other actions if you
removed the divider from the
drawer.
• Use a clean sponge or soft
cloth and a mild detergent
in warm water to clean the
refrigerator.
• Do not use abrasive or harsh
cleansers such as window
sprays, scouring cleansers,
flammable fluids, muriatic acid,
cleaning waxes, concentrated
detergents, bleaches, or
cleansers containing petroleum
products on exterior surfaces
(doors and cabinet), plastic
parts, door and interior liners,
and gaskets.
- These can scratch or damage
the material.
• Do not clean glass shelves or
covers with warm water when
they are cold. Glass shelves and
covers may break if exposed to
sudden temperature changes
or impacts such as bumping or
dropping.
DA68-02787A (EN)-05.indd 13 2017. 8. 9. �� 10:51

14_ safety information
CRITICAL DISPOSAL
WARNINGS
• Please dispose of the
packaging material for this
product in an environmentally
friendly manner.
• Leave the shelves in place so
that children may not easily
climb inside.
• Ensure that none of the pipes
on the back of the appliance
are damaged prior to disposal.
• R600a or R134a is used
as a refrigerant. Check the
compressor label on the rear
of the appliance or the rating
label inside the fridge to see
which refrigerant is used for
your refrigerator. When this
product contains flammable
gas(Refrigerant R600a) contact
your local authority in regard to
safe disposal of this product.
• Cyclopentane used as an
insulation blowing gas.
The gases in insulation material
require special disposal
procedure. Please contact your
local authorities in regard to the
environmentally safe disposal of
this product. Ensure that none
of the pipes on the back of the
appliances are damaged prior
to disposal. The pipes shall be
broken in the open space.
• Keep all packaging materials
well out of the reach of children,
WARNING
as packaging materials can be
dangerous to children.
- If a child places a bag over
its head, it may result in
suffocation.
Be careful that your fingers
ars not caught in.
CAUTION
DA68-02787A (EN)-05.indd 14 2017. 8. 9. �� 10:51

safety information _15
contents
SETTING UP YOUR FRENCH DOOR REFRIGERATOR ……………… 16
OPERATING YOUR FRENCH DOOR REFRIGERATOR ……………… 25
TROUBLESHOOTING……………………………………………………… 32
This appliance is intended to be
used in household and similar
applications such as:
- Sta kitchen areas in shops,
oces and other working
environments;
- Farm houses and by clients
in hotels, motels and other
residential type environments;
- Bed and breakfast type
environments;
- Catering and similar non-retail
applications.
DA68-02787A (EN)-05.indd 15 2017. 8. 9. �� 10:51

16_ setting up
GETTING READY TO INSTALL THE
REFRIGERATOR
Congratulations on your purchase of this Samsung
French Door Refrigerator.
We hope you enjoy the state-of-art features and
efficiencies that this new appliance offers.
Selecting the best location for the
refrigerator
• A location with easy access to a water supply.
• A location without direct exposure to sunlight.
• A location with a leveled floor.
• A location with enough space for the refrigerator
doors to open easily.
• A location that allows sufficient space to the
right, left, back and top for air circulation.
• A location that allows you to move the
refrigerator easily if it needs maintenance or
service.
If the refrigerator does not have enough space, the
internal cooling system may not work properly.
If your refrigerator has an ice maker, allow extra
space at the back for the water line connections.
When you install the refrigerator next to a fixed wall,
you need a minimum clearance of 95mm between
the refrigerator and wall to allow the door to swing
open.
First thing! Make sure that you can easily move
your refrigerator to its final location by measuring
doorways (both width and height), thresholds,
ceilings, stairways, etc.
The following chart details the exact height and
depth of this Samsung French Door Refrigerator.
• Allow clearance to the right, left, back and top
when installing. This will help reduce power
consumption and keep your energy bills lower.
• Do not install the refrigerator where the
temperature will go below 10ºC.
• Do not locate the refrigerator where it may
become wet.
When moving your refrigerator
To prevent floor damage, be sure the front
adjusting legs are in the up position (above
the floor). Refer to ‘Adjusting the Level’ in
the manual (on page 15).
CAUTION
Setting up your French Door
Refrigerator
Flat-blade
screwdriver(-)
Control Lever
758mm
1234mm
1194mm
950mm
889mm
36mm
34mm
752mm
1410mm
1171mm
387mm
104mm
543mm
1697mm
1535mm
770mm
1007mm625mm 16mm
76mm
50mm
50mm 80mm
DA68-02787A (EN)-05.indd 16 2017. 8. 9. �� 10:51

setting up _17
01 SETTING UP
FLOORING
For proper installation, you must place this
refrigerator on a level, hard surface that is the
same height as the rest of the floor. This surface
should be strong enough to support a fully loaded
refrigerator, or approximately 150kg.
To protect the finish of the flooring, cut a large
section of the cardboard carton and place it under
the refrigerator where you are working. When
moving the refrigerator, you need to pull and push
it straight forwards or back. Do not wiggle it from
side to side.
ACCESSORIES AND REQUIRED
TOOLS
The following accessories are included with your
refrigerator:
Compression Fitting Compression Nut
Required Tools (Not provided)
You need the following tools to complete the
installation of your refrigerator:
Philips
screwdriver(+)
Flat-blade screw
driver(-)
Socket wrench
(10mm)
Allen wrench (5mm)
REMOVING THE REFRIGERATOR
DOORS
For some installations you need to remove the
fridge and freezer drawers so you can move the
refrigerator to its final location. Do not remove
the doors/drawer if you don’t need to. If you do
not need to remove the refrigerator doors, go to
Adjusting the Level on page 15. If you need to
remove the doors. continue below.
Before removing the door/drawer, make sure you
read the following items:
Disconnect power to the refrigerator before
removing the door or drawer.
• Be careful not to drop, damage or
scratch the door/drawer while removing
them.
• Be careful not to get injured while removing the
door/drawer.
• Reattach the door/drawer properly to avoid:
- Moisture from air leakage.
- Uneven door alignment.
- Wasting energy due to improper door seal.
Disassembling the fridge door
Be careful not to drop and scratch the
doors while removing the doors.
1. Remove the 3 screws holding down the top
table and remove it.
2. Disconnect electric wire on the top of the
refrigerator.
WARNING
WARNING
Top Table
DA68-02787A (EN)-05.indd 17 2017. 8. 9. �� 10:51

18_ setting up
3. Remove the 3 hex bolts that hold the hinge on
the top of the refrigerator with the 10mm socket
wrench.
4. Remove the screw that holds the ground wire
with a philips screwdriver(+).
5. Separate the hinge from the electric wire and
ground wire as shown above.
6. Lift the door straight up to remove.
Be careful not to drop and scratch the doors
while removing them.
Socket wrench
ground wire
Disassembling the freezer door
1. After opening the Freezer door, lift the drawer
box.
2. Remove 4 hex head bolts from both sides with
a socket wrench(10mm)
3. Remove 4 hex head bolts from both sides with
a socket wrench(10mm).
Reassembling the fridge door
1. Insert and tighten the screw into the left and
right middle hinges with a philips screwdriver(+).
DA68-02787A (EN)-05.indd 18 2017. 8. 9. �� 10:51

setting up _19
01 SETTING UP
2. Insert and tighten the 2 hex head bolts into the
left and right middle hinges with an allen
wrench.
3. Replace the middle hinge cap.
4. Place the hole in the bottom of the left d oor
over the middle hinge.
5. Position the top table in place. Insert and
tighten the 3 screws into the top table with a
philips screwdriver(+).
6. Insert the left upper hinge shaft into the hole on
Top Table
the corner of the fridge door.
7. Insert the upper hinges into the holes at the top
of the door.
Insert and tighten the 3 hex head bolts into the
left and right upper hinges with a socket
wrench.
8. Insert and tighten the ground screw into the left
and right upper hinges with a philips
screwdriver(+).
9. Connect the electronic wire on the top of the
refrigerator.
ground wire
DA68-02787A (EN)-05.indd 19 2017. 8. 9. �� 10:51

20_ setting up
Reassembling the freezer door
1. Pull out the rails to the full length on each sidle
of the cabinet evenly.
2. Hang the freezer door front onto open slot on
the sides.
3. With the 10mm wrench, reattach 4 bolts to
connect the rail with the door.
4. With the drawer pulled out fully, insert the
drawer box into the rail system.
Slot
Slot
Slot
DA68-02787A (EN)-05.indd 20 2017. 8. 9. �� 10:51
