Samsung SR-606EVSS User manual

ENGLISH
REFRIGERATOR
Before operating the unit, please read this manual throughly,
and retain for future reference.
If you took out of the
power supply outlet, you
should plug in again after
five minutes.
DA68-60306A (0.2)
OWNER’S
INSTRUCTIONS
SR-608EV/648EV/688EV
606EV/646EV/686EV
(dispenser Applied)
Register your product at www.samsung.com/global/register
DA68-60306A REV(0.1) 4/21/05 6:37 PM Page 1

1
What is H.M.CYCLE(High-efficiency Multi-
evaporator CYCLE)?
• A high efficiency cooling method adopting an
independent cooler and an independent cool-
ing fan in freezing room and refrigerating room,
respectively.
• A new cooling method providing an economic
energy, power cooling function and supply of
high humidity cool air by independent cooler
and cooling fan.
What is sensitivity technology?
• A theory for meeting the sensuous demands
from consumers by supplying the cool air that
suits their tastes for preserving foods. Neuro-
fuzzy genic algorithm theory was applied so
that the optimum uniform refrigeration can be
maintained by automatically activating the
rotating fan for distribution of cool air at the
locations where foods are stored and supply-
ing the cool air quickly to places where it is
mostly needed.
What is genic algorithm
(GA-FUZZY)
• A theory that senses the inside temperature of
refrigerator with temperature sensor and
controls it to be in an optimum state of uniform
refrigeration by applying the genetic principle
of natural ecosystem, i.e the law of the fittest
Øs survival and training to Micom.
CONTENTS
Ready to use
Contents...............................................................................1
Warnings for safety..............................................................2
Cautions for safety...............................................................4
Features...............................................................................6
Ready to use........................................................................8
Front operating panel.........................................................10
How to use
How to use freezing room..................................................12
How to use refrigerating room...........................................14
How to preserve the refrigerated foods.............................17
Functions of water dispenser.............................................19
Installation and cares
How to clean ......................................................................21
How to disassemble and assemble the
water supply device......................................................23
How to disassemble the accessories................................26
How to install......................................................................27
Before asking for service
Before asking for service...................................................31
Questions...........................................................................33
T
p
a
C
FEATURE
DA68-60306A REV(0.1) 4/21/05 6:37 PM Page 2

3
WARNING
Do not put a tank filled with water
on the product.
•If water poured, it cause bad insu-
lation of the electric parts which
may lead to fire or electric shock.
Do not disassemble, repair or
alter.
• It may cause fire or abnormal
operation which leads to injury.
If and when gas leaks, immediately ventilate
without touching the refrigerator and the plug.
• Explosion of gas may cause fire and a burn.
Dispose refrigerator after door or door’s packing
is removed, if disposition is required.
• It is dangerous for child to enter the refrigerator for
play-in with door closed.
Pull the power plug out for
exchanging the interior lamp of
the refrigerator.
• It may cause electric shock.
Be sure to earth.
• If earthing is not done, it will cause
breakdown and electric shock.
(Please refer to page 29.)
Do not install the refrigera-tor in
the wet place or the place which
water splashes.
• Deterioration of insulation of elec-
tric parts may cause electric shock
or fire.
Do not insert the power plug with
the wet hand.
• May cause electric shock.
DA68-60306A REV(0.1) 4/21/05 6:37 PM Page 4

5
CAUTION
Do not touch the tank and the food stuffs of the
frezzing room with the wet hand.
• It may cause frostbite.
Please wipe out foreign materials of the metal
option of the power plug cleanly.
• Use of it as it is may cause fire.
Move it by catching the upper handle of rear side
and the lower handle of front side.
• Slippery is caused to hurt, when other part is
grasped.
Use handle when opening and closing the
refrigerator door.
• In case of using other parts than handle, it may hurt
you with your finger jammed.
If the refrigerator is not to be used for a long time,
pull out the power play.
• Due to deterioration of insulation, mau cause fire.
When abnormal sound, small or smoke is noticed,
pull a power plug off immediately, then call service
center.
If you want to insert the power plug again, please
insert it five minutes after pulling out of the plug
socket.
• Abnormal operation of freezing device may cause
breakdown of it.
Do not enter the hand into the bottom surface of
the product.
• Sharp edge may inflict a wound.
Afterfive
minutes
R
•
A
•
•
W
6
•
P
•
R
•
DA68-60306A REV(0.1) 4/21/05 6:37 PM Page 6

7
SEPARATE AND INDEPENDENT COOLING OF REFRIGERATING
AND FREEZING ROOMS!
Refrigerator of energy-saving type
• It adopts the high-efficiency Multi-evaporator CYCLE that makes it possible to cool the refrigerating room and
freezing room separately and to reduce the power consumption and energy.
Super-power cooling technique for quick refrigeration.
• Selection of power freezing and power refrigerating by independent cooler and cooling fan allows the quick
cooling and preserving the freshness of foods.(pages 13, 15)
Natural humidity vegetable room lasting 3 times longer even without vinyl wraps.
• The independent cooling method is supplying the cool air with 4°~5 times of more humidity than conventional
refrigerator through the indirect cooling technique by which the cool air can not touch the vegetables and fruits
directly and therefore the freshness with the same natural humidity as that of producing areas can be
maintained for a long time
NATURALISM FOR REFRIGERATORS, TOO!
Refrigerator that does not destroy the ozone layer!
• It uses the new insulating materials, the new refrigerant (R-134A) whose ODP(Azone Depletion Potential) is zero
DA68-60306A REV(0.1) 4/21/05 6:37 PM Page 8

9
THE CORRECT WAY OF PRESERVING FOODS.
Please keep them after washing. Please store foods after dividing into small
pieces.
Please do not store foods which are apt to go bad
in low temperature.
(Examples : Bananas, Pineapples, Tomatoes etc.)
Please place watery foods(particularly bean
curds) on the front area of shelf in refrigerating
room.
• It may be possible that foods placed on areas where
cool air is coming out are frozen.
Please arrange foods with proper distance each
other.
• If the exit of cool air is blocked, the storing efficiency
gets low due to the bad cool air circulation.
Please cool off the hot foods before putting them
in the refrigerator.
• It reduces power consumption and also makes a
better cooling.
P
It
a
T
It
s
DA68-60306A REV(0.1) 4/21/05 6:37 PM Page 10

11
DISPLAY PANEL
High moisture refrigerating
function
A high moisture refrigerating display lamp is
always on when the refrigerator is in opera-
tion.
• The refrigerator adopted separate coolers in
freezing and refrigerating rooms, respectively,
that can supply a high moist cool air and there-
fore it can preserve the foods in fresh state.
Door-alarm function
(Door opening)
A warning sound(Dingdong-Dingdong) indi-
cates that door is open.
• In case the door is open wider than 15°, after 2
minutes the warning sounds for about 10
seconds with about 1 minute interval.
Deodorizing display lamp
This lamp is always on when the refrig-erator
is in operation.
Without any specific operation, the refrigera-
tor remains in deodorizing mode while air is
circulating.
Display of super X-flow function
If temperature in refrigerating room is getting
high with a lot of foods in it or the door is
open, the half-circle red lamps in the center
turn on in automatic sequence.
• You do not have to worry about any leakage of
cool air even though the door is open because
the rotating cool air is moving around foods in
center.
• The display lamp is on when the temperature in
refrigerating room gets uniform since the cooling
is made quickly by the rotation cooling tech-
nique.
Power savings of indoor lamp
• When the door is open for over 10 minutes,
the indoor lamps automatically go off.
DA68-60306A REV(0.1) 4/21/05 6:37 PM Page 12

13
POWER FREEZING/TEMPERATURE CONTROL OF FREEZING ROOM
The artificial intelligent function keeps the adjusted temperature of freezing room in the optimum state conforming
with conditions of use.
Power freezing(Quick freezing)
When you want to freeze foods at a fast speed or to get ice quickly,
●The red lamp is on when selecting Power freezing by pressing “QUICK FRE” Button
●Please press the button one more time if you want to cancel “QUICK FRE”
LOW
When the amount of foods to be stored is small,
●Please select “LOW” by pressing FRE. control button.
●Whenever pressing the button at “LOW”, temperature is set in sequence of
“LOW MID → MID”.
MID
When using it normally,
●Please select an appropriate position between “LOW” and “MID” or “MID” and “HIGH”, depending on the amount
of foods to be stored and frequency of use.
●”MID” is the normal position.
●The temperature is changed in sequence of “MID HIGH → HIGH” whenever pressing the button at “MID”.
HIGH
When making ice or there are a lot of foods to be stored.
●Please select “HIGH” by pressing the temperature control button.
●When pressing one more time at “HIGH”, “LOW” is selected.
●Whenever pressing the temperature control, the temperature setting is changed in sequence of
“LOW” → MID LOW → MID → MID HIGH → HIGH” and it goes to “LOW” when pressing the button one
more time at “HIGH”.
●Since power freezing function is automatically completed, it is automatically transferred, after power
freezing, to the previous temperature setting before the power freezing function is operated.
(Example : If it had been used in “LOW” mode, it automatically goes back to “LOW” after completing
“POWER FREEZING”.
●“MID” of freezing room is automatically set after initial power supply or power failure.
DA68-60306A REV(0.1) 4/21/05 6:37 PM Page 14

15
POWER REFRIGERATION/TEMPERATURE CONTROL OF REFRIGERATING ROOM
The artificial intelligent function keeps the adjusted temperature of refrigerating room in an optimum state conform-
ing with conditions of use.
Power refrigeration
When you want to cool the foods quickly.
●The red lamp is on when selecting POWER REFRIGERATING by pressing “QUICK ref” button
●Please press the button one more time for cancelling power refrigeration.
LOW
When foods are frozen or the quantity of foods is small,
●Please select “LOW” by pressing the temperature control button
●Whenever pressing the button at “LOW”, the temperature setting is changed in sequence of
“LOW MID → MID”.
MID
When in normal use or storing Kimchi,
●Please select an appropriate position between “LOW” and “MID” or “MID” and “HIGH”, depending on the quantity
of foods to be stored and frequency of use.
●“MID” is the normal position.
●Whenever pressing the button from “MID”, the temperature setting is changed in sequence of
“MID HIGH → HIGH”.
HIGH
When refrigeration is bad or there are a lot of foods to be stored,
●Please select “HIGH” by pressing the temperature control button.
●When pressing one more time from “HIGH”, the temperature is set to “LOW”.
DA68-60306A REV(0.1) 4/21/05 6:37 PM Page 16

HOW TO PRESERVE THE REFRIGERATED FOODS
17
High humidity special fresh room
(chilled Room )
• Please use this room for foods to be stored in
colder environments than refrigerating room.
❊Please keep meat or fish in freezing room for its
long storage.
Re-enforced glass shelf
• Please keep the side dish foods in storage bowl
or other refrigerated foods with a proper distance
apart.
❊ The shelf in refrigerating room is a re-enforced
glass one unliable to destruction even when
falling down, making sure of its safe use.
Eggs carrier
• Please keep eggs in the eggs carrier.
❊ The products with water dispensers (Models
applied: SR-608EV/648EV/668EV) contains two
eggs carriers.(Refer to figure of page 14)
Space for multi-use
• Please use this space for storing butter, milk ,
yogurt in small package or drinks.
DA68-60306A REV(0.1) 4/21/05 6:37 PM Page 18

FUCTIONS OF WATER DISPENSER
19
Water tank
Models applied : SR-608EV/648EV/688EV
What is the water dispenser? If a water tank full of water and equipped with water supply device is inserted into the
location where the water supply lever in the refrigerating room is connected to, the cold water can be available at the
outside of door even without opening the door by pressing the water supply lever.
When in no use of water
dispenser function,
After removing water tank,
tightly insert the cap for
sealing into the connector of
water dispenser
so that no cool
air is leaked.
•Please drain the water completely from water tank by pressing the water supply lever
after emptying it when in no frequent use of water dispenser.
•Please do not use juice or soda drinks because water tank or water supply system can be
polluted by their sugar contents. When it was used with those drinks, please make sure to
wash it with clean water.
•Acold water will be available right after the cold water stored in refrigerating room in
advance is put into water tank.
•Please clean the water tank frequently after it was filled with tea etc. for a long time since
the water tank is subject to change of color or smell and also the residues of tea may
cause an abnormal operation of water dispenser.
DA68-60306A REV(0.1) 4/21/05 6:37 PM Page 20

HOW TO CLEAN
21
How to use water-spout
• Please frequently throw away water collected on the
water-spout and wipe it out with dry cloth after separat-
ing it from cup platform by slightly pressing “PUSH”.
Please clean the water supply
device with a soft brush.
Water supply device
• Please disassemble and clean once in a while.
cup platform
Water-spout
Please separate the large lid from water
tank after pulling it out.
• It can be separated from water tank
when pulling up both hand-grips of large
lid.
Please separate the water tank from
water supply device.
Hand-grip Large lid
Water tank
• Please hold the upper part of water supply device and turn it to
arrow direction.
After washing water tank and
large lid with neutral
detergents, please rinse them
with water.
• Please do not boil the water supply device in hot water of over 60°
• Please be careful not to damage or lose the water supply device.
• Please do not let children mishandle the water supply lever. It may cause the water
overflow or any trouble.
(MODELS APPLIED : SR-608EV/648EV/688EV)
DA68-60306A REV(0.1) 4/21/05 6:37 PM Page 22

HOW TO DISASSEMBLE AND ASSEMBLE THE WATER SUPPLY DEVICE
23
When you want to further clean every corners of the water supply device, disassemble and assemble it after clean-
ing as follows.
HOW TO DISASSEMBLE (MODELS APPLIED : SR-608EV/648EV/688EV)
① Part (small rubber packing)
➁ Part
(2-1) Part (Medium rubber packing)
➂ Part (Large rubber packing)
➃Part
➄Part (Spring)
⑥Part
DA68-60306A REV(0.1) 4/21/05 6:37 PM Page 24

25
HOW TO ASSEMBLE
Fit the ➂part, while pressing it,
into ➃part. Fit the locking part of ➁part into the hole of ➃part.
Insert ➄part and ⑥part into
➃part.
Insert ®Á part while pressing the
lower end of ® A part.
Insert the long portion of ⑥part into
the hole of ➁part.
• At this time, the popping portion of ⑥part has to
be fitted into the grooves of ➁part.
➂part
➃part
➁part
➃part
➄part
➃part
⑥part
Hole
➁part
Popping porting
⑥part
• Be careful not to recklessly pull out spring
or not to make the spring stretched.
• Water leakage may be caused by filling
water tank with water or by pressing water
supply lever if rubber packing or rubber
ring were missing while assembling.
Assemble all parts in steps without missing
any one of them.
DA68-60306A REV(0.1) 4/21/05 6:37 PM Page 26

27
HOW TO INSTALL
HOW TO ADJUST LEVELING
Adjust the leveling of refrigerator.
• If the refrigerator is so installed to make its front a little high, the door can be easily opened and closed.
Refrigerator leaning to the left.
Make leveling by filling driver into
the groove of adjustible leg on the
left side and turning it to arrow
direction.
Refrigerator leaning to the right
Make leveling by fitting driver into
the groove of adjustible leg on the
right side and turning it to arrow direc-
tion.
––
DA68-60306A REV(0.1) 4/21/05 6:37 PM Page 28

29
HOW TO GROUND
The refrigerator should be grounded.
The purpose of grounding is to prevent any power leakage or electric shock caused by the current leakage from the
refrigerator.
❊Never ground to gas pipes, telephone line and lightning rod as it is very dangerous at the time of lightning strikes.
In case of outlets without ground terminals.
• Bury the ground cable connected to a copper plate into
the ground with plenty of moistures at the depth of over
25CM, or use a power source which is equipped with
circuit breakers. Ground
Ground screw
DA68-60306A REV(0.1) 4/21/05 6:37 PM Page 30

BEFORE ASKING FOR SERVICE
31
SYMPTIOMS CHECK
Non-operation or bad refrigeration
Foods in refrigerating room are frozen
Noises and strange sound
Too hot at the front corner and side wall areas of
refrigerator. Dew are forming
• Check the connection of power plug.
• Isn’t the temperature control lamp of front operating
panel in “LOW” mode?
• Isn’t there sunshine or heat directly applied to
refrigerator.
• Isn’t the rear plate of refrigerator too close to the wall?
• Isn’t the temperature control lamp of front operating
panel in “HIGH” mode?
• Isn’t the environmental temperature around the
installing place too high?
• Isn’t the watery foods put into the inside of refrigerator
when the cool air is coming out?
• Check if the floor is not flat or not hard.
• Isn’t the rear plate of refrigerator too close to walls?
• Is there any stuffs fallen down at rear or beneath of
refrigerator?
• Isn’t it the sound of compressor within the product?
• The sound of “TICK TICK” from inside of refrigerator
is the one to be heard when various parts are con-
tracted or expanded by cooling operation, therefore it
does not mean any trouble with it.
• This is because heat pipe is installed at the front cor-
ner to prevent dew-forming. It is likely to feel that the
temperature on these area is very high in the envi-
ronmental conditions of high exteior temperature.
However, it does not mean any trouble with it.
• It happens that dews form on the outer wall of refrig-
erator under the high humidity environment. This is
because the moisture in the air touches the cold sur-
face of refrigerator.
DA68-60306A REV(0.1) 4/21/05 6:37 PM Page 32

QUESTIONS
33
WHAT IS THE LOW TEMPERATURE CATALYZING DEODORIZER?
Low temperature catalyzing deodorizer
Low temperature catalyzing deodoriz-
er is installed at cool air suction hole
where the air of refrigerating room is
sucked, therefore, even without any
additional operation, smells are
removed while air is in a natural
circulation.
It is so designed as to suck and
completely remove smells. Also it
has an excellent capability of deodor-
izing the bad smell of the favorate
foods particularly at home.
bad smell
• Low temperature catalyzing deodorizer has a semi-permanent lifetime.
• The function of low temperature catalyzing deodrizer has no harmful effect on human bodies and is
applied only to remove smells from the stored foods within the refrigerator.
• Use wraps or sealed tank when preserving foods with much smells.
Deodorizing effect may be reduced as the smells are adhered to inner wall of refrigerator or to other
foods.
DA68-60306A REV(0.1) 4/21/05 6:37 PM Page 34

English
Correct Disposal of This Product (Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries with separate
collection systems)
This marking shown on the product or its literature, indicates that it should not be disposed with
other household wastes at the end of its working life. To prevent possible harm to the environ-
ment or human health from uncontrolled waste disposal, please separate this from other types
of wastes and recycle it responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their
local government office, for details of where and how they can take this item for environmentally
safe recycling.
Business users should contact their supplier and check the terms and conditions of the pur-
chase contract. This product should not be mixed with other commercial wastes for disposal.
DA68-60306A REV(0.1) 4/21/05 6:37 PM Page 36
