Samsung RB30J3 Series User manual

English
Refrigerator
user manual
imagine the possibilities
Thank you for purchasing a Samsung product.
Free Standing Appliance
SEAG
RB28F*
RB29F*
RB29H*
RB30F*
RB31F*
RB31H*
RB32F*
RB33F*
RB34F*
RB39F*
RB30J3*
RB33J3*
RB37J5*
RB33N*
RL33N*
RB34N*
DA68-02833Q-18.indb 1 2018. 2. 2. �� 9:15

02_ safety information
SAFETY INFORMATION
• Before operating the appliance,
please read this manual
thoroughly and retain it for your
reference.
• Use this appliance only for
its intended purpose as
described in this instruction
manual. This appliance is not
intended for use by persons
(including children) with
reduced physical, sensory
or mental capabilities, or
lack of experience and
knowledge, unless they have
been given supervision or
instruction concerning use
of the appliance by a person
responsible for their safety.
• This appliance can be used
by children aged from 8 years
and above and persons with
reduced physical, sensory
or mental capabilities or
lack of experience and
knowledge if they have
been given supervision or
instruction concerning use of
the appliance in a safe way
and understand the hazards
involved.
Children shall not play with
the appliance. Cleaning and
user maintenance shall not
be made by children without
supervision.
• Warnings and Important Safety
Instructions in this manual
do not cover all possible
conditions and situations that
may occur.
It is your responsibility to use
common sense, caution,
and care when installing,
maintaining, and operating
your appliance.
• Because these following
operating instructions
cover various models, the
characteristics of your
refrigerator may differ slightly
from those described in this
manual. R-600a or R-134a is
used as a refrigerant. Check
the compressor label on the
rear of the appliance or the
rating label inside the fridge to
see which refrigerant is used
for your refrigerator. When this
product contains flammable
gas (Refrigerant R-600a),
contact your local authority in
safety information
DA68-02833Q-18.indb 2 2018. 2. 2. �� 9:15

safety information _03
regard to safe disposal of this
product.
• In order to avoid the creation
of a flammable gas-air mixture
if a leak in the refrigerating
circuit occurs, the size of the
room in which the appliance
may be sited depends on the
amount of refrigerant used.
• Never start up an appliance
showing any signs of damage.
If in doubt, consult your dealer.
The room must be 1m³ in
size for every 8g of R-600a
refrigerant inside the appliance.
The amount of refrigerant in
your particular appliance is
shown on the identification
plate inside the appliance.
• Refrigerant squirting out of the
pipes could ignite or cause an
eye injury. When refrigerant
leaks from the pipe, avoid
any naked flames and move
anything flammable away from
the product and ventilate the
room immediately.
- Failing to do so may result in
fire or explosion.
• Do not store explosive
substances such as aerosol
cans with a flammable
propellant in this appliance.
Warning; Risk of
fire / flammable
materials
Important safety symbols
and precautions:
WARNING
Hazards or unsafe
practices that may result
in severe personal
injury or death.
CAUTION
Hazards or unsafe
practices that may result
in minor personal injury
or property damage.
Do NOT attempt.
Do NOT disassemble.
Do NOT touch.
Follow directions carefully.
Unplug the power plug
from the wall socket.
Make sure the machine
is grounded to prevent
electric shock.
Call the contact center for
help.
Note.
DA68-02833Q-18.indb 3 2018. 2. 2. �� 9:15

04_ safety information
These warning signs are here
to prevent injury to you and
others. Please follow them
carefully. After reading this
section, keep it in a safe
place for future reference.
SEVERE WARNING
SIGNS FOR
TRANSPORTATION
AND SITE
• When transporting
and installing the
appliance,care should be
taken to ensure that no
parts of the refrigerating
circuit are damaged.
- Refrigerant leaking from the
pipe work could ignite or
cause an eye injury. If a leak
is detected, avoid any naked
flames or potential sources
of ignition and air the room in
which the appliance is standing
for several minutes.
- This appliance contains a
small amount of isobutane
refrigerant(R-600a), a natural
gas with high environmental
compatibility that is, however,
also combustible. When
transporting and installing the
appliance, care should be
WARNING
taken to ensure that no parts
of the refrigerating circuit are
damaged.
SEVERE WARNING
SIGNS FOR
INSTALLATION
• Deteriorated insulation
of electrical parts may
cause an electric shock
or fire.
• Do not place this refrigerator
in direct sunlight or expose to
the heat from stoves, room
heaters or other appliance.
• Do not plug several appliances
into the same multiple power
board.
The refrigerator should always
be plugged into its own
individual electrical outlet
which has a voltage rating that
matched the rating plate.
- This provides the best
performance and also prevents
overloading house wiring
circuits, which could cause a
fire hazard from overheated
wires.
• If the wall socket is loose, do
not insert the power plug.
- There is a risk of electric shock
or fire.
WARNING
DA68-02833Q-18.indb 4 2018. 2. 2. �� 9:15

safety information _05
• Do not use a cord that shows
cracks or abrasion damage
along its length or at either
end.
• Do not pull or excessively bend
the power cord.
• Do not twist or tie the power
cord.
• Do not hook the power cord
over a metal object, place a
heavy object on the power
cord, insert the power cord
between objects, or push the
power cord into the space
behind the appliance.
- When moving the refrigerator,
be careful not to roll over or
damage the power cord.
- This may result in an electric
shock or fire.
• Do not use aerosols near the
refrigerator.
- Aerosols used near the
refrigerator may cause an
explosion or fire.
- Do not bend the power cord
excessively or place heavy
articles on it.
• This refrigerator must be
properly installed and
located in accordance
with the manual before it
is used.
• Do not install the refrigerator in
a damp place or place where
it may come in contact with
water.
- Deteriorated insulation of
electrical parts may cause an
electric shock or fire.
• Connect the power plug in
proper position with the cord
hanging down.
- If you connect the power plug
upside down, wire can get
cut off and cause a fire or an
electric shock.
• Make sure that the power plug
is not squashed or damaged
by the back of the refrigerator.
• When moving the refrigerator,
be careful not to roll over or
damage the power cord.
- This constitutes a fire hazard.
• Keep the packing materials out
of reach of children.
- There is a risk of death from
suffocation if children put them
on their head.
• This appliance should be
positioned in such a way that
it is accessible to the power
plug.
- Failing to do so may result in
an electric shock or fire due to
electric leakage.
DA68-02833Q-18.indb 5 2018. 2. 2. �� 9:15

06_ safety information
• Do not install this appliance
near a heater, inflammable
material.
• Do not install this appliance in
a humid, oily or dusty location,
in a location exposed to direct
sunlight and water (rain drops).
• Do not install this appliance in
a location where gas may leak.
- This may result in an electric
shock or fire.
• If any dust or water is in the
refrigerator, pull out power plug
and contact your Samsung
Electronics service center.
- Otherwise there is a risk of fire.
• Do not stand on top of the
appliance or place objects
(such as laundry, lighted
candles, lighted cigarettes,
dishes, chemicals, metal
objects, etc.) on the appliance.
- This may result in an electric
shock, fire, problems with the
product, or injury.
• This appliance must be
properly grounded.
• Do not ground the appliance
to a gas pipe, plastic water
pipe, or telephone line.
- You must ground the
refrigerator to prevent any
power leakages or electric
shocks caused by current
leakage from the refrigerator.
- This may result in an electric
shock, fire, explosion, or
problems with the product.
- Never plug the power cord into
a socket that is not grounded
correctly and make sure that it
is in accordance with local and
national codes.
• If the supply cord is
damaged, it must
be replaced by the
manufacturer, its service
agent or similarly qualified
persons in order to avoid
a hazard.
• The fuse on the refrigerator
must be changed by a qualified
technician or service company.
- Failing to do so may result in
an electric shock or personal
injury.
• When positioning the appliance,
ensure the supply cord is not
trapped or damaged.
• Do not locate multiple portable
socket-outlets or portable
power supplies at the rear of
the appliance.
CAUTION SIGNS FOR
CAUTION
DA68-02833Q-18.indb 6 2018. 2. 2. �� 9:15

safety information _07
INSTALLATION
• Keep ventilation opening
in the appliance enclosure
or mounting structure
clear of obstruction.
• Allow the appliance to stand
for 2 hours after installation.
• The installation or any
service of this appliance is
recommended by a qualified
technician or service company.
- Failing to do so may result
in an electric shock, fire,
explosion, problems with the
product, or injury.
SEVERE WARNING
SIGNS FOR USING
• Do not touch the power
plug with wet hands.
- This may result in an electric
shock.
• Do not store articles on the top
of the appliance.
- When you open or close the
door, the articles may fall and
cause a personal injury and/or
material damage.
• Do not put items filled with
water on the refrigerator.
- If spilled, there is a risk of fire
or electric shock.
WARNING
• Do not touch the inside walls
of the freezer or products
stored in the freezer with wet
hands.
- This may cause frostbite.
• Do not use or place any
substances sensitive
to temperature such
as inflammable sprays,
inflammable objects, dry ice,
medicine, or chemicals near
the refrigerator.
Do not keep volatile or
inflammable objects or
substances (benzene, thinner,
propane gas, alcohol, ether, LP
gas and other such products
etc.) in the refrigerator.
- This refrigerator is for storing
food only.
- This may result in a fire or an
explosion.
• Do not store pharmaceuticals
products, scientific materials or
temperature-sensitive products
in the refrigerator.
- Products that require strict
temperature controls must not
be stored in the refrigerator.
• Do not place or use electrical
appliance inside the
refrigerator/freezer, unless they
are of a type recommended by
the manufacturer.
DA68-02833Q-18.indb 7 2018. 2. 2. �� 9:15

08_ safety information
• If you smell pharmaceutical or
smoke, pull out power plug
immediately and contact your
Samsung Electronics service
center.
• If any dust or water is in
Refrigerator, pull out power
plug and contact your Samsung
Electronics service center.
- Otherwise there is a risk of fire.
• If gas leak is detected, avoid
any naked flames or potential
sources of ignition and air the
room in which the appliance is
standing for several minutes.
• Do not use mechanical
devices or any other means
to accelerate the defrosting
process, other than those
recommended by the
manufacturer.
• Do not damage the refrigerant
circuit.
• Do not spray volatile material
such as insecticide onto the
surface of the appliance.
- As well as being harmful to
humans, it may also result
in an electric shock, fire or
problems with the product.
• Do not use a hair dryer to dry
the inside of the refrigerator.
Do not place a lighted candle
in the refrigerator for removing
bad odours.
- This may result in an electric
shock or fire.
• Fill the water tank, ice tray and
water cubes only with potable
water (mineral water or purified
water).
- Do not fill the tank with tea,
juice or sports drink, this may
damage the refrigerator.
• Do not let children hang on
the door. If not, a serious injury
may occur.
- Risk of children entrapment.
Do not let children enter inside
the refrigerator.
• Do not leave the doors of the
refrigerator open while the
refrigerator is unattended and
do not let children enter inside
the refrigerator.
• Do not allow babies or children
go inside the drawer.
- It can cause death from
suffocation by entrapment or
personal injury.
• Do not sit on the Freezer door.
- The door may be broken and
cause a personal injury.
• Do not use mechanical
devices or any other means
to accelerate the defrosting
DA68-02833Q-18.indb 8 2018. 2. 2. �� 9:15

safety information _09
process, other than those
recommended by the
manufacturer.
• Do not damage the refrigerant
circuit.
• Do not put fridge shelf in
upside down.
Shelf stopper could not work.
- It may cause a personal injury
because of glass shelf drop.
• In the event of a gas leak
(such as propane gas,
LP gas, etc.), ventilate
immediately without
touching the power
plug. Do not touch the
appliance or power cord.
- Do not use a ventilating fan.
- A spark may result in an
explosion or fire.
• Use only the LED Lamps
provided by manufacturer or
service agent.
• Children should be supervised
to ensure that they do not play
with the appliance.
• Keep fingers out of “pinch
point” areas; clearances
between the doors and cabinet
are necessarily small.
• Do not let children hang on
the door. If not, a serious injury
may occur.
• There is a Risk of children
entrapment.
Do not let children enter inside
the refrigerator.
• Bottles should be stored tightly
together so that they do not
fall out.
• This product is intended only
for the storage of food in a
domestic environment.
• Never put fingers or other
objects into the dispenser
hole, ice chute and ice maker
bucket.
- It may cause a personal injury
or material damage.
• Do not insert hands, feet
or metal objects (such as
chopsticks, etc.) into the
bottom or the back of the
refrigerator.
- This may result in an electric
shock or injury.
- Any sharp edges may cause a
personal injury.
• Do not attempt to repair,
disassemble, or modify
the appliance yourself.
- Do not use any fuse(such as
cooper, steel wire, etc.) other
than the standard fuse.
- When repairing or reinstalling
the appliance is required,
DA68-02833Q-18.indb 9 2018. 2. 2. �� 9:15

10_ safety information
contact your nearest service
center.
- Failing to do so may result
in an electric shock, fire,
problems with the product, or
injury.
• If the appliance generates
a strange noise, a
burning or smell or
smoke, unplug the power
plug immediately and
contact your nearest
service center.
- Failing to do so may result in
an electric or fire hazards.
• Pull the power plug out of the
socket before changing the
interior lamps of the refrigerator
- Otherwise, there is a risk of
electric shock.
• If you experience difficulty
when changing the light,
contact service agent.
• If the products is equipped
with the LED Lamp, do not
disassemble the Lamp Cover
and LED Lamp by yourself.
- Please contact your service
agent.
• Plug the power plug into the
wall socket firmly.
Do not use a damaged power
plug, damaged power cord or
loose wall socket.
- This may result in an electric
shock or fire.
• Do not put a container filled
with water on the appliance.
- If spilled, there is a risk of fire
or electric shock.
• Never stare directly at the UV
LED lamp for long periods of
time.
- This may result in eye strain
due to the ultraviolet rays.
CAUTION SIGNS FOR
USING
• To get best performance
from the product,
- Do not place foods too closely
in front of the vents at the
rear of the appliance as it can
obstruct free air circulation in
the refrigerator compartment.
- Wrap the food up properly or
place it in airtight containers
before putting it into the
refrigerator.
- Do not put any newly
introduced food for freezing
near to already existing food.
• Do not place glass or bottles
or carbonated beverages into
the freezer.
CAUTION
DA68-02833Q-18.indb 10 2018. 2. 2. �� 9:15

safety information _11
- The container may freeze and
break, and this may result in
injury.
• Please observe maximum
storage times and expiry dates
of frozen goods.
• There is no need to disconnect
the refrigerator from the power
supply if you will be away for
less than three weeks.
But, remove all the food if you
are going away for the three
weeks or more.
Unplug the refrigerator and
clean it, rinse and dry.
• Do not place carbonated
or fizzy drinks in the freezer
compartment.
Do not put bottles or glass
containers in the freezer.
- When the contents freeze, the
glass may break and cause
personal injury and property
damage.
• Do not change or modify the
functionality of the refrigerator.
- Changes or modifications may
result in a personal injury and/
or property damage.
Any changes or modifications
performed by a 3rd party on
this completed appliance
are neither covered under
Samsung warranty service,
nor is Samsung responsible
for safety issues and damages
that result from 3rd party
modifications.
• Do not block air holes.
- If the air holes are blocked,
especially with a plastic bag,
the refrigerator can be over
cooled.
• Use only the ice-maker
provided with the refrigerator.
• Wipe excess moisture from
the inside and leave the doors
open.
- Otherwise, odor and mold may
develop.
• When the refrigerator got
wet by water, pull out the
power plug and contact your
Samsung Electronics service
center.
• Do not keep vegetable oil in
your refrigerator’s door bins.
The oil can solidify, making it
foul-tasting and difficult to use.
In addition, the open container
can leak and the leaked oil can
cause the door bin to crack.
After opening an oil container,
it is best to keep the container
in a cool and shaded place
such as a cupboard or pantry.
- Examples of vegetable oil: olive
DA68-02833Q-18.indb 11 2018. 2. 2. �� 9:15

12_ safety information
oil, corn oil, grape-seed oil, etc.
CAUTION SIGNS
FOR CLEANING AND
MAINTENANCE
• Do not spray cleaning
products directly on the
display.
- Printed letters on the display
may come off.
• If any foreign substance such
as water has entered the
appliance, unplug the power
plug and contact your nearest
service center.
- Failing to do so may result in
an electric shock or fire.
• Remove all foreign substances
such as dust or water from
the power plug terminals and
contact points using a dry
cloth on a regular basis.
- Unplug the power plug and
clean it with a dry cloth.
- Failing to do so may result in
an electric shock or fire.
• Do not clean the appliance by
spraying water directly onto it.
• Do not use benzene, thinner, or
Clorox, Chloride for cleaning.
- They may damage the surface
of the appliance and may
CAUTION
cause a fire.
• Never put fingers or other
objects into the dispenser hole.
- It may cause a personal injury
or material damage.
• Before cleaning or
performing maintenance,
unplug the appliance
from the wall socket.
- Failing to do so may result in
an electric shock or fire.
• Use a clean sponge or soft
cloth and a mild detergent
in warm water to clean the
refrigerator.
• Do not use abrasive or harsh
cleansers such as window
sprays, scouring cleansers,
flammable fluids, muriatic acid,
cleaning waxes, concentrated
detergents, bleaches, or
cleansers containing petroleum
products on exterior surfaces
(doors and cabinet), plastic
parts, door and interior liners,
and gaskets.
- These can scratch or damage
the material.
• Do not clean glass shelves or
covers with warm water when
they are cold.
Glass shelves and covers may
break if exposed to sudden
DA68-02833Q-18.indb 12 2018. 2. 2. �� 9:15

safety information _13
temperature changes or
impacts such as bumping or
dropping.
SEVERE WARNING
SIGNS FOR
DISPOSAL
• Leave the shelves in
place so that children
may not easily climb
inside.
• Ensure that none of the pipes
on the back of the appliance
are damaged prior to disposal.
• R-600a or R-134a is used as a
refrigerant.
Check the compressor label
on the rear of the appliance
or the rating label inside the
refrigerator to see which
refrigerant is used for your
refrigerator.
When this product contains
flammable gas (Refrigerant
R-600a), contact your local
authority in regard to safe
disposal of this product.
Cyclopentane is used as an
insulation blowing gas.
The gases in insulation material
require special disposal
procedure.
Please contact your local
authorities in regard to the
WARNING
environmentally safe disposal
of this product.
Ensure that none of the pipes
on the back of the appliances
are damaged prior to disposal.
The pipes shall be broken in
the open space.
• When disposing of this or
other refrigerator/s, remove the
door/door seals, door latch so
that children or animals cannot
become trapped inside.
Children should be supervised
to ensure that they do not
enter and play with the
appliance.
- If trapped inside, the child may
become injury and suffocate to
death.
• Please dispose of the
packaging material for this
product in an environmentally
friendly manner.
• Keep all packaging materials
well out of the reach of
children, as packaging
materials can be dangerous to
children.
- If a child places a bag over
its head, it may result in
suffocation.
DA68-02833Q-18.indb 13 2018. 2. 2. �� 9:15

14_ safety information
ADDITIONAL TIPS
FOR PROPER USAGE
• In the event of a power failure,
call the local office of your
Electricity Company and ask
how long it is going to last.
- Most power failures that are
corrected within an hour or two
will not affect your refrigerator
temperatures.
However, you should minimize
the number of door openings
while the power is off.
- But should the power failure
last more than 24 hours,
remove all frozen food.
• If keys are provided with the
refrigerator, the keys should
be kept out of the reach of
children and not be in the
vicinity of the appliance.
• The appliance might not
operate consistently (possibility
of defrosting of contents
or temperature becoming
too warm in the frozen food
compartment) when sited for
an extended period of time
below the cold end of the
range of temperature for which
the refrigerating appliance is
designed.
• Do not store food which goes
bad easily at low temperature,
such as bananas, melons.
• Your appliance is frost free,
which means there is no
need to manually defrost
your appliance, as this will be
carried out automatically.
• Temperature rise during
defrosting can comply with
ISO requirements.
But if you want to prevent an
undue rise in the temperature
of the frozen food while
defrosting the appliance,
please wrap the frozen food up
in several layers of newspaper.
• Any increase in temperature of
frozen food during defrosting
can shorten its storage life.
• Do not re-freeze frozen foods
that have thawed completely.
• The temperature of two
star section (sections) or
compartment (compartments)
which have two star symbol
( ) is slightly higher than
other freezer compartment
(compartments).
The two star section
(sections) or compartment
(compartments) is (are) based
on the instruction and/or the
condition as delivered.
DA68-02833Q-18.indb 14 2018. 2. 2. �� 9:15

safety information _15
Saving Energy Tips
- Install the appliance in a
cool, dry room with adequate
ventilation.
Ensure that it is not exposed
to direct sunlight and never put
it near a direct source of heat
(radiator, for example).
- Never block any vents or grilles
on the appliance.
- Allow warm food to cool
down before placing it in the
appliance.
- Put frozen food in the
refrigerator to thaw.
You can then use the low
temperatures of the frozen
products to cool food in the
refrigerator.
- Do not keep the door of the
appliance open for too long
when putting food in or taking
food out.
The shorter time for which the
door is open, the less ice will
form in the freezer.
- Allow clearance to the right,
left, back and top when
installing.
This will help reduce power
consumption and keep your
energy bills lower.
- We recommend the value of
clearance to be :
- Right, left, and back side:
more than 50mm
- Top side: more than 100mm
- For the most efficient use
of energy, please keep the
all inner fittings such as
baskets, drawers, shelves
on the position supplied by
manufacturer.
This appliance is intended
to be used in household and
similar applications such as
- staff kitchen areas in shops,
offices and other working
environments;
- farm houses and by clients
in hotels, motels and other
residential type environments;
- bed and breakfast type
environments;
- catering and similar non-retail
applications.
DA68-02833Q-18.indb 15 2018. 2. 2. �� 9:15

16_ setting up
contents
SETTING UP YOUR REFRIGERATOR………………………………………………………… 16
OPERATING YOUR REFRIGERATOR ………………………………………………………… 20
REVERSING THE DOOR (OPTIONAL)………………………………………………………… 26
TROUBLESHOOTING…………………………………………………………………………… 32
GETTING READY TO INSTALL THE
REFRIGERATOR
Congratulations on the purchase of your Samsung
Refrigerator.
We hope you will enjoy the many state-of-the-art
features and efficiencies that this new appliance
has to offer.
• This refrigerator must be properly installed and
located in accordance with the manual before it
is used.
• Use this appliance only for its intended purpose
as described in this instruction manual.
• We strongly recommend that any servicing be
performed by a qualified individual.
• Please dispose of the packaging material for
this product in an environmentally friendly
manner.
• Pull the power plug out of the socket
before changing the interior light of the
refrigerator.
- Otherwise, there is a risk of electric shock.
Selecting the best location for the
refrigerator
• Select a location without direct exposure to
sunlight.
• Select a location with level (or nearly level)
flooring.
• Select a location with enough space for the
refrigerator doors to open easily.
WARNING
• Allow sufficient space to install the refrigerator
on a flat surface.
- If your refrigerator is not level, the internal
cooling system may not work correctly.
- Overall space required in use.
Refer to drawing and dimension as below.
1850 mm
1780 mm
1920 mm
or
2010 mm
994mm
1062.4mm or 1060mm
595mm
602.2mm
1214.7 mm or 1212mm
135º
setting up your refrigerator
DA68-02833Q-18.indb 16 2018. 2. 2. �� 9:15

setting up _17
01 SETTING UP
Spacer
Spacer
• Remove paper on spacer and then
attach a spacer (Gray block) on the
back side of refrigerator for better
performance. Make sure a spacer
fix like above image when you install
the refrigerator. It is improving the
refrigerator performance.
(Only for RB31F***B, RB29F***B,
RB37J***9**, RB33J3**9, RB33N*,
RL33N* model)
• Allow sufficient space to the right, left,
back and top for air circulation.
This will help reduce power
consumption and keep your energy
bills lower.
• Do not install the refrigerator where the
temperature will go below 10°C.
• Please ensure that appliance can be moved
freely in the event of maintenance & service.
When installing, servicing, or cleaning
behind the refrigerator, be sure to pull the
unit straight out and push back in straight
after finishing.
Also, make sure your floor supports the
full-load refrigerator.
Otherwise, it may cause floor damage.
Please tie up the extra length of the power
cord at the back of the refrigerator so as
not to be touched on the floor preventing
the power cord from being crushed by the
rollers upon relocation.
CAUTION
CAUTION
FLOORING
For proper installation, this refrigerator must be
placed on a level surface of hard material that has
the same height as the rest of the flooring.
This surface should be strong enough to support
a fully loaded refrigerator (or approximately 65kg).
To protect the floor finish, cut a large section of the
cardboard carton and place it under the refrigerator
where you are working.
• Pulling or pushing the refrigerator may
damage the floor.
Moving the refrigerator after installation
may damage the floor.
• When you move the refrigerator, the
Power Cord should be fixed with the
fixer of the back side.
(Some model’s fixer on the cabinet
bottom or wire holder)
[Fixer on the cabinet bottom]
[Fixer on the wire holder]
DA68-02833Q-18.indb 17 2018. 2. 2. �� 9:15

18_ setting up
LEVELLING THE REFRIGERATOR
If the front of the appliance is slightly higher than
the rear, the door can be opened and closed more
easily.
Case 1) The appliance tilts down to the left.
Turn the left adjusting leg in the direction of the
arrow until the appliance is level.
Case 2) The appliance tilts down to the right.
Turn the right adjusting leg in the direction of the
arrow until the appliance is level.
< Case2 >
< Case1 >
INSTALLING THE HANDLES
(APPLICABLE MODELS ONLY)
The handles are included in the product
package.
1. Align each screw hole of the handle to the
corresponding screw hole of the door.
Then, insert the provided screws (x2) and use a
Phillips screwdriver to tighten them.
2. Insert the Cap-Handle Screws (x2) into each
handle hole on both sides.
Cap-Handle
screw
3. Repeat the steps above to install the handle on
the other freezer or fridge door.
4. Insert the Cap Screws (x2) into the door holes
of the opposite side of the door where no
handle is installed.
Cap screw
Use caution when installing the handle.
The door may be scratched.
CAUTION
DA68-02833Q-18.indb 18 2018. 2. 2. �� 9:15

setting up _19
01 SETTING UP
SETTING UP THE REFRIGERATOR
Now that you have your new refrigerator installed
and in place, you are ready to set up and enjoy the
full features and functions of the appliance.
By completing the following steps, your refrigerator
should be fully operational.
If not, first check the power supply and electricity
source or try the troubleshooting section at the
back of this user guide.
If you have any further questions, contact your
Samsung Electronics service center.
1. Place the refrigerator in an appropriate location
with reasonable clearance between the wall
and the refrigerator.
Refer to installation instructions in this manual.
2. Before using the refrigerator please remove the
shelf corner covers shown on below figure.
(The covers are used to secure your refrigerator
during transportation).
3. Once the refrigerator is plugged in, make sure
the interior light comes on when you open the
doors.
4. Set the temperature control to the coldest
temperature and wait for an hour.
The freezer should get slightly chilled and the
motor should run smoothly.
5. After powering the refrigerator, it will take a few
hours to reach the appropriate temperature.
Once the refrigerator temperature is sufficiently
cool, you can store food and drink in the
refrigerator.
After powering the refrigerator, the alarm
will sound. Press Freezer or Fridge button.
(Only for Coolselect zone funtion model )
Refer to on page 20 “Using the control
Panel”.
DA68-02833Q-18.indb 19 2018. 2. 2. �� 9:15

20_ operating
operating your refrigerator
USING THE CONTROL PANEL
TYPE A TYPE B
231 21
TYPE C
21
TYPE D
21
Each time you press a button on the
control panel, you will hear a short beep.
When you do not press any button, the
LEDs of Freezer, Fridge and CoolSelect
Zonebecome turned off for the minimum
energy consumption. But LEDs of Power
Freeze and Vacation are turned on at the
corresponding functions.
(Only for RB29****B, RB31****B,
RB32****B model)
Depending on the model, the LED
indicators of the freezer may not turn on
when you open the freezer door.
1Freezer
Press the Freezer button to set the freezer to
desired temperature from range between -15°C
and -23°C. Default set temperature is set on
-19°C and each time you press the Freeze button,
temperature will be changed in the following order
and temperature indicator will display the desired
temperature.
-21°C
-19°C -23°C -15°C -17°C
Press this button for 3 seconds to activate the
Power Freeze function.
Power Freeze indicator ( ) will light up and the
refrigerator will speed up the time to needed to
freeze products in the freezer.
This function will be activated for 50 hours and
freezer indicator will not change display.
This function switches off automatically.
When the Power Freeze process is completed, the
Power freeze indicator switches off and the freezer
switches back to the previous temperature setting.
When you use this function, the energy
consumption will increase.
Remember to turn it off when you do not need it
and return the freezer to your original temperature
setting. To deactivate this function, press the
Freezer button for 3 seconds.
If you need to freeze large amount of food stuff,
activate Power Freeze function 20 hours before.
DA68-02833Q-18.indb 20 2018. 2. 2. �� 9:15
