The SNP-6200/6200H is a PTZ dome camera which provides 20x images in Full HD resolution. This ONVIF compliant PTZ
dome camera features multiple displaying resolution from CIF (320 x 240) through to 16:9 format 1080p Full High Definition
and provide the ability to be transmitted simultaneously, allowing the most relevant stream to be transmitted to your viewing
or recording device simultaneous transmitting for your viewing or recording. Now users can monitor a scene far away from the
camera in more detail, at higher quality of image. Its intelligent video analytics functions includes Tampering, Virtual Line,
Enter/Exit, Appear/Disappear to help efficient monitoring. The SNP-6200/6200H can be installed both indoor and outdoor where
it needs a wide range of viewing. Especially, the SNP-6200H is incorporating housing PTZ dome camera and can to withstand
extreme environment which -50 ˚C ~ +55 ˚C circumstance with Fan/Heater.
SNP-6200/6200H
2 Megapixel Full HD Network 20x PTZ Dome Camera
Capture crystal-clear detail with
Full HD 20x PTZ Dome Camera
FIRST EDITION 03-2012
• Max. 2 Megapixel resolution
• 16:9 Full HD (1080p) resolution support
• Built-in 20x optical zoom lens (4.45~89mm)
• H.264 & MJPEG dual codec
• Bi-directional audio
• Built-in SD memory clot
• Intelligent Video Analytics
• IP66 (SNP-6200H)

The Eco mark represents
Samsung Techwin’s will to create
environment-friendly products,and indicates
that the product satisfies the EU RoHS Directive.
2M
D&NICR
20x PoE+
2 Megapixel Full HD Network 20x PTZ Dome Camera
I.E-1203
DISTRIBUTED BY
SAMSUNG TECHWIN EUROPE LTD.
Samsung House, 1000 Hillswood Drive, Hillswood Business Park
Chertsey, Surrey, UNITED KINGDOM KT16 OPS
Tel : [phone] Fax : [phone]
TIANJIN SAMSUNG TECHWIN OPTO-ELECTRONICS CO., LTD.
No.11 Wei 6 Street. Micro-Electronic Industrial Park
Jingang Road, Tianjin, P.R. CHINA 300385
Tel : [phone] Fax : [phone]
Specifications
SNP-6200/6200H
SNP-6200N/P SNP-6200HN/HP
VIDEO
Imaging Device 1/3" Progressive Scan CMOS
Total Pixels 2,010(H) x 1,108(V), 2.2M Pixels
Effective Pixels 1,944(H) x 1,092(V), 2.1M Pixels
Scanning System Progressive
Min. Illumination Color : 1.5 Lux @ F1.6 (50IRE), B/W : 0.1 Lux @ F1.6 (50IRE)
S / N Ratio 50dB
Video Output CVBS : 1.0 Vp-p / 75Ω composite, 704x480(N), 704x576(P), for installation
LENS
Focal Length (Zoom Ratio) 4.45 ~ 89mm (20X)
Max. Aperture Ratio F1.6(Wide) / F2.9(Tele)
Angular Field of View H : 56.56˚(Wide) ~ 3.10˚(Tele) / V : 43.32˚(Wide) ~ 2.34˚(Tele)
Min. Object Distance 1m
Focus Control Auto / Manual / One shot
Lens Type DC Auto Iris
Mount Type Board-in type
PAN / TILT / ROTATE
Pan Range 360˚ Endless
Pan Speed Preset : 500˚/sec, Manual : 0.024˚/sec ~ 120˚/sec
Tilt Range 190˚(-5˚ ~185˚ )
Tilt Speed Preset : 500˚/sec, Manual : 0.024˚/sec ~ 120˚/sec
Preset 255ea
Preset Accuracy ±0.1˚
OPERATIONAL
Camera Title Off / On (Displayed up to 15 characters)
Day & Night Auto (ICR) / Color / B/W
Backlight Compensation Off / BLC / HLC
Wide Dynamic Range Off / On
Contrast Enhancement SSDR (Samsung Super Dynamic Range) (Off / On)
Digital Noise Reduction SSNRIII (2D+3D Noise Filter) (Off / Low / Medium / High)
Digital Image Stabilization Off / On
Motion Detection Off / On (1 programmable zones)
Privacy Masking Off / On (8 programmable zones)
Sens-up (Frame Integration) Off / Auto (2x ~ 60x)
Gain Control Off / Low / Medium / High / Manual
White Balance ATW / AWC / Manual / Indoor / Outdoor
Electronic Shutter Speed Auto / A.FLK / Manual (1/30 ~ 33,000sec)
Digital Zoom Off / On (1x~8x)
Flip / Mirror Off / On
Intelligent Video Analytics Tampering, Virtual Line, Enter/Exit, Appear/Disappear
Alarm I/O Input 4ea / Output 2ea (Relay)
Remote Control Interface RS-485/422
RS-485 Protocol SAMSUNG T/E, PELCO-P/D, Panasonic, Bosch, Honeywell, Vicon, AD, GE
NETWORK
Ethernet RJ-45 (10/100BASE-T)
Video Compression Format H.264, MJPEG
Resolution
1920X1080P(FULL HD), 1280X1024, 1280X960, 1280X720P(HD), 1024X768, 800X600, 800X450, 640X480, 640X360, 320X240, 320X180
Max. Framerate Max 30fps at all resolutions * When WDR ON, Max. framerate is Max 15fps.
Smart Codec Yes (Area Based Method, Face Detection Method)
Video Quality Adjustment H.264 : Compression level, Target bitrate level control, MJPEG : Quality level control
Bitrate Control Method H.264 : CBR or VBR, MJPEG : VBR
Streaming Capability Multiple streaming (Up to 6 profiles)
Audio I/O Mic / Line in, Line out
Audio Compression Format G.711 u-law
Audio Communication Bi-direction
IP IPv4, IPv6
Protocol
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPOE, FTP, SMTP, ICMP, IGMP, SNMPV1/V2C/V3(MIB-2), ARP, DNS, DDNS, QoS
Security HTTPS(SSL) Login Authentication, Digest Login Authentication, IP Address Filtering, User access Log, 802.1x Authentication
Streaming Method Unicast / Multicast
Max. User Access 10 users at unicast mode
Memory Slot SD/SDHC memory slot
ONVIF Conformance Yes
Webpage Language English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish,
Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek
Web Viewer Supported OS : Windows XP / VISTA / 7, MAC OS, Supported Browser : Internet Explorer 7.0 or Higher, Firefox, Google Chrome, Apple Safari
Central Management Software NET-i viewer
ENVIRONMENTAL
Operating Temperature / Humidity -10°C ~ +55°C (+14°F ~ +131°F) / Less than 90% RH -10°C ~ +55°C (+14°F ~ +131°F) / Less than 90% RH (Heater Off)
-50°C ~ +55°C (-58°F ~ +131°F) / Less than ~ 90% RH (Heater On)
Storage Temperature / Humidity -30°C ~ +60°C / Less than 90%RH -30 °C ~ +60 °Ct / Less than 90%RH
Ingress Protection - IP66 Grade (Waterproof)
ELECTRICAL
Input Voltage / Current 24V AC, PoE+ (IEEE 802.3at)
Power Consumption Max. 21W
Max. 25W (Heater off), Max. 60W (Heater on)
* Heater works at AC input only.
MECHANICAL
Color / Material Ivory / Plastic Ivory / Aluminum / Plastic sun-shield
Dimensions (WxH) Ø155 x 243.4mm (Ø6.1" x 9.58") Ø248 x 316.5mm (9.76" x 12.46")
Weight 2.2Kg (4.85 lb) 4.6Kg (10.14 lb)
Design and specifications are subject to change without notice.
Unit : mm (inch)
Dimensions
316.5 (12.46")
248.0 (9.76")
162.0 (6.38")
248.0 (9.76")
215.7 (8.49")
243.4 (9.58")
155.0 (6.1")
155.0 (6.1")
SNP-6200
SNP-6200H
