Samsung iPolis SNO-5080R User manual

NETWORK CAMERA
User Manual SNO-5080R

Copyright
©2011 Samsung Techwin Co., Ltd. All rights reserved.
Trademark
is the registered logo of Samsung Techwin Co., Ltd.
The name of this product is the registered trademark of Samsung Techwin Co., Ltd.
Other trademarks mentioned in this manual are the registered trademark of their respective company.
Restriction
Samsung Techwin Co., Ltd shall reserve the copyright of this document. Under no circumstances, this
document shall be reproduced, distributed or changed, partially or wholly, without formal authorization of
Samsung Techwin.
Disclaimer
Samsung Techwin makes the best to verify the integrity and correctness of the contents in this document, but
no formal guarantee shall be provided. Use of this document and the subsequent results shall be entirely on
the user’s own responsibility. Samsung Techwin reserves the right to change the contents of this document
without prior notice.
Warranty
If the product does not operate properly in normal conditions, please let us know. Samsung Techwin will
resolve the problem for free of charge. The warranty period is 3 years. However, the followings are excluded:
If the system behaves abnormally because you run a program irrelevant to the system operation.
Deteriorated performance or natural worn-out in process of time
•
•
Network Camera
User Manual

English _3
●OVERVIEW
IMPORTANT SAFETY INSTRUCTIONS
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any ventilation openings, Install in accordance with the manufacturer’s
instructions.
Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized
plug has two blades with one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the third prong are provided for
your safety. If the provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
Only use attachments/ accessories specified by the manufacturer.
Use only with the cart, stand, tripod, bracket, or table specified by
the manufacturer, or sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus combination to avoid
injury from tip-over.
Unplug this apparatus during lighting storms or when unused for
long periods of time.
Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate normally, or has been dropped.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
overview

overview
4_ overview
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS PRODUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC
OBJECT THROUGH THE VENTILATION GRILLS OR OTHER OPENNINGS
ON THE EQUIPMENT.
Apparatus shall not be exposed to dripping or splashing and that no objects
filled with liquids, such as vases, shall be placed on the apparatus.
CAUTION
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN
CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
EXPLANATION OF GRAPHICAL SYMBOLS
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of “dangerous voltage” within the product’s
enclosure that may be of sufficient magnitude to constitute a
risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended
to alert the user to the presence of important operating
and maintenance (servicing) instructions in the literature
accompanying the product.

English _5
●OVERVIEW
Class construction
An apparatus with CLASS construction shall be connected to a MAINS
socket outlet with a protective earthing connection.
Disconnection Device
Disconnect the main plug from the apparatus, if it’s defected. And please call
a repair man in your location.
When used outside of the U.S., it may be used HAR code with fittings of
an approved agency is employed.
CAUTION
These servicing instructions are for use by qualified service personnel only.
To reduce the risk of electric shock do not perform any servicing other than
that contained in the operating instructions unless you are qualified to do so.
The BNC Out terminal of the product is provided for easier installation, and is
not recommended for monitoring purposes.
If you keep the BNC cable connected, a risk of lightening may cause damage
or malfunction to the product.
Please use the input power with just one camera and other devices must not
be connected.

overview
6_ overview
Please read the following recommend safety precautions carefully.
Do not place this apparatus on an uneven surface.
Do not install on a surface where it is exposed to direct sunlight, near
heating equipment or heavy cold area.
Do not place this apparatus near conductive material.
Do not attempt to service this apparatus yourself.
Do not place a glass of water on the product.
Do not install near any magnetic sources.
Do not block any ventilation openings.
Do not place heavy items on the product.
User’s Manual is a guidance book for how to use the products.
The meaning of the symbols are shown below.
Reference : In case of providing information for helping of product’s usages
Notice : If there’s any possibility to occur any damages for the goods and
human caused by not following the instruction
ÚPlease read this manual for the safety before using of goods and keep it in
the safe place.
y
y
y
y
y
y
y
y
y
y

English _7
●OVERVIEW
CONTENTS
OVERVIEW
3
3Important Safety Instructions
9Product Features
9Recomended PC Specifications
10 What’s Included
11 At a Glance
INSTALLATION &
CONNECTION
13
13 To adjust the zoom factor or
focus
14 Connecting with other Device
NETWORK CONNECTION
AND SETUP
16
16 Connecting the Camera Directly
to Local Area Networking
17 Connecting the Camera Directly
to a DHCP Based DSL/Cable
Modem
18 Connecting the Camera Directly
to a PPPoE Modem
19 Connecting the Camera to a
Broadband Router with the
PPPoE/Cable Modem
20 Buttons used in IP Installer
21 Static IP Setup
24 Dynamic IP Setup
25 Port Range Forward (Port Mapping)
Setup
27 Connecting to the Camera from a
Shared Local PC
27 Connecting to the Camera from a
Remote PC via the Internet

overview
8_ overview
SETUP SCREEN
34
34 Setup
34 Video Setup
42 Network Setup
48 Event Setup
55 System Setup
APPENDIX
60
60 Specification
64 Product Overview
66 Troubleshooting
68 Open Source Announcement
70 GPL/LGPL Software License
WEB VIEWER
28
28 Connecting to the Camera
29 Login
30 Installing Silverlight Runtime
32 Using the Live Screen

English _9
●OVERVIEW
PRODUCT FEATURES
HD Video Quality
Multi-Streaming
This network camera can display videos in different resolutions and qualities
simultaneously using different CODECs.
MHowever, MPEG-4 video can not be played on a web page. Use CMS software if you want to play
the video on a web page.

Web Browser-based Monitoring
Using the Internet web browser to display the image in a local network environment.
Alarm
If an event occurs, the event-related video will be transferred to the email specified by the
user or the event signal will be sent to the Alarm Out port.
Intelligent Video Analysis
Analyzes the event video according to the user-specified rules to recognize the event.
ONVIF (Spec 1.01) Compliance
This product supports ONVIF Core Spec. 1.01.
For more information, refer to www.onvif.org.
RECOMENDED PC SPECIFICATIONS
CPU : Intel(R) Core(TM)2 2.00 GHz or higher
Operating System : Windows XP, VISTA, 7
Mac OS
Resolution : 1280X1024 pixels or higher
RAM : 1GB or higher
Web Browser : Internet Explorer 7.0 or higher, Firefox, Chrome, Safari
Neither a beta test version unlike the version released in the company website nor the developer version will
be supported.
On Firefox v3.5 or higher, displaying warning message dialog may cause an error.
If connecting to IPv6 in Windows XP, it can cause some problem.
It is recommended to connect to IPv6 in Windows 7.
Video Memory : 128MB or higher
•
•
•
•
•
•
•
•
•
•
•



•

overview
10_ overview
WHAT’S INCLUDED
Please check if your camera and accessories are all included in the product package.
Appearance Item Name Quantity Description
User Manual,
Installer S/W DVD,
CMS S/W DVD
2
Quick Guide 1
Template 1Product installation guide
Tapping Screw 3 Used for installation on the wall or ceiling
L Wrench 1Used to adjust the camera orientation
Cable for the testing monitor 1Used to test the camera connection to a
portable display device
Sunshield 1 It protects the camera from the direct
sunlight.
Sunshield Hold 1 It fixes the sunshield with the camera.

English _11
●OVERVIEW
AT A GLANCE
Front Side
Item Description

Sunshield It protects the camera from the direct sunlight.
b
Sunshield Hold It fixes the sunshield with the camera.
c
Video Output Port Connected to the monitor so that you can check the video from the camera.

Reset Button
Resets the camera settings to the default. Press and hold it for about 5
seconds to turn off the system indicator and restart the system.
J
If you reset the camera, the network settings will be adjusted so that
DHCP can be enabled. If there is no DHCP server in the network, you
must run the IP Installer program to change the basic network settings
such as IP address, Subnet mask, Gateway, etc., before you can
connect to the network.

Zoom Lever Turn left or right to adjust the size of an object.

Focus Lever Turn left or right to fit the focus.
Wipe out a dirty surface of the lens softly with a lens tissue or cloth to which you have applied
ethanol.
M

overview
12_ overview
Rear Side
Item Description

Power Port Used to plug the power cable.
b
Network Port Used to connect a PoE or LAN cable.
c
I/O Port
ARM-OUT WHITE : Used to connect the alarm output signal.
ARM-IN BLUE : Used to connect the alarm input signal.
A-COM GRAY : Common port where the alarm output signal is
connected.
GND YELLOW : Used for earth-grounding.

English _13
●INSTALLATION & CONNECTION
TO ADJUST THE ZOOM FACTOR OR FOCUS
Loosen the front cover as shown.
Loosen the zoom/focus lever slightly.
Position the zoom/focus lever to WIDE (NEAR) or TELE (FAR) as appropriate.
Then, tighten the zoom/focus lever to fix the adjusted position.
Turn the front cover to tighten it.
To ensure seamless waterproofing, tighten up the front cover by turning it to the end.
When fixing the front cover, ensure that the triangle of the main body faces the triangle of the
front cover.
Use the lever to adjust the zoom factor or focus, and turn the lever clockwise to fix it.
Before you can adjust the zoom factor/focus of the lens, loosen and remove the front cover.
1.
2.
3.
4.
5.
J


installation & connection
Front cover
Zoom Lever
Focus Lever
WIDE
WIDE
↔
↔
TELE
TELE
FAR
FAR
↔
↔
NEAR
NEAR

installation & connection
14_ installation & connection
CONNECTING WITH OTHER DEVICE
Connecting to the monitor
Use the test monitor cable to connect the video output port of the camera with the video
input port of the monitor.
In the initial installation of the camera, you can connect the camera to the monitor for checking
the connection status.
You must set <Video output> to <On> before the display screen can be activated. (page 36)
The BNC Out terminal of the product is provided for easier installation, and is not recommended
for monitoring purposes.
If you keep the BNC cable connected, a risk of lightening may cause damage or malfunction to
the product.
M
J
Power
Ethernet

English _15
●INSTALLATION & CONNECTION
Ethernet Connection
Connect the Ethernet cable to the local network or to the Internet.
Power Supply
Use the screwdriver to connect each line (+, –) of the power cable to the corresponding
power port of the camera.
Be careful not to reverse the polarity when you connect the power cable.
You can also use a router featuring PoE (Power over Ethernet) to supply power to the camera.
If PoE and DC 12V are both applied, this camera will get supplied with power from PoE.
Please make sure the monitor and camera are turned off when connecting them.
J



16_ network connection and setup
You can set up the network settings according to your network configurations.
CONNECTING THE CAMERA DIRECTLY TO LOCAL AREA
NETWORKING
Connecting to the camera from a local PC in the LAN
Launch an Internet browser on the local PC.
Enter the IP address of the camera in the address bar of the browser.
A remote PC in an external Internet out of the LAN network may not be able to connect to the
camera installed in the intranet if the port-forwarding is not properly set or a firewall is set.
In this case, to resolve the problem, contact your network administrator.
By factory default, the IP address will be assigned from the DHCP server automatically. If there is
no DHCP server available, the IP address will be set to 192.168.1.100.
To change the IP address, use the IP Installer.
For further details on IP Installer use, refer to “Static IP Setup”. (Page 21)
1.
2.
M

network connection and setup
Camera
Camera
Local PC
Firewall External Remote PC
DDNS Server
(Data Center, KOREA)
INTERNET
<Local Network>
Switch
HUB

English _17
●
NETWORK CONNECTION AND SETUP
CONNECTING THE CAMERA DIRECTLY TO A DHCP
BASED DSL/CABLE MODEM
Use the cross LAN cable to connect the network cable directly to your PC.
Run the IP Installer and change the IP address of the camera so that you can use
the web browser on your desktop to connect to the Internet.
Use the Internet browser to connect to the camera.
Move to [Setup] page.
Move to [Network] – [DDNS] and configure the DDNS settings.
Move to [Network] – [Interface], and set the network type to [DHCP].
Connect the camera, which was removed from your PC, directly to the modem.
Restart the camera.
For registering the DDNS settings, refer to “Registering with DDNS”. (page 44)
For configuring the DDNS settings, refer to “DDNS”. (page 44)
For setting the network type, refer to “Interface”. (page 42)
1.
2.
3.
4.
5.
6.
7.
8.
M


Camera
External Remote PC
DDNS Server
(Data Center, KOREA)
DSL/Cable
Modem
INTERNET

18_ network connection and setup
network connection and setup
CONNECTING THE CAMERA DIRECTLY TO A PPPoE
MODEM
Use the cross LAN cable to connect the network cable directly to your PC.
Run the IP Installer and change the IP address of the camera so that you can use
the web browser on your desktop to connect to the Internet.
Use the Internet browser to connect to the camera.
Move to [Setup] page.
Move to [Network] – [DDNS] and configure the DDNS settings.
Move to [Network] – [Interface], and set the network type to [PPPoE].
Connect the camera, which was removed from your PC, directly to the modem.
Restart the camera.
For registering the DDNS settings, refer to “Registering with DDNS”. (page 44)
For configuring the DDNS settings, refer to “DDNS”. (page 44)
For setting the network type, refer to “Interface”. (page 42)
1.
2.
3.
4.
5.
6.
7.
8.
M


Camera
External Remote PC
DDNS Server
(Data Center, KOREA)
PPPoE Modem
INTERNET

English _19
●
NETWORK CONNECTION AND SETUP
CONNECTING THE CAMERA TO A BROADBAND ROUTER
WITH THE PPPoE/CABLE MODEM
This is for a small network environment such as homes, SOHO and ordinary shops.
Configuring the network settings of the local PC connected to a
Broadband Router
Configuring the network settings of the local PC connected to a Broadband Router, follow
the instructions below.
Select : <Network Neighborhood> <Properties> <Local Area Connection>
<Properties> <General> <Internet Protocol (TCP/IP)> <Properties>
<Obtain an IP address automatically> or <Use the following IP address>.
Follow the instructions below if you select <Use the following IP address>:
ex1) If the address (LAN IP) of the Broadband Router is 192.168.1.1
IP address : 192.168.1.100
Subnet Mask : 255.255.255.0
Default Gateway : 192.168.1.1
ex2) If the address (LAN IP) of the Broadband Router is 192.168.0.1
IP address : 192.168.0.100
Subnet Mask : 255.255.255.0
Default Gateway : 192.168.0.1
ex3) If the address (LAN IP) of the Broadband Router is 192.168.xxx.1
IP address : 192.168.xxx.100
Subnet Mask : 255.255.255.0
Default Gateway : 192.168.xxx.1
For the address of the Broadband Router, refer to the product’s documentation.
Refer to the “Port Range Forward (Port Mapping) Setup” section of the Broadband Router’s
documentation. (Page 25)
•
•
M

Camera
Camera
Local PC
Broadband
Router
PPPoE or
Cable Modem
PPPoE or
Cable Modem External Remote
PC
DDNS Server
(Data Center, KOREA)
INTERNET

20_ network connection and setup
network connection and setup
BUTTONS USED IN IP INSTALLER
Item Description

Device Name
Model name of the connected camera.
Click the column to sort the list by model name.
However, search will be stopped if clicked during the search.
b
Mode Displays either <Static> or <Dynamic> for the current network connection
status.
c
MAC(Ethernet)
Address
Ethernet address for the connected camera.
Click the column to sort the list by Ethernet address.
However, search will be stopped if clicked during the search.

IP Address
IP address.
Click the column to sort the list by IP address.
However, search will be stopped if clicked during the search.
The factory default is “192.168.1.100”.

Protocol
Network setting for the camera.
The factory default is “IPv4”.
Cameras with the IPv6 setting will be displayed “IPv6”.

UPnP Status This function is not currently implemented.
