Samsung SVF-129 User manual

SVF-129, 130E/C
SVF-229, 230N/P
SAMSUNG CCTV DOME CAMERA
도큐멘트1 7/3/01 10:49 AM 페이지1
VARIFOCAL DOME CAMERA
INSTRUCTION MANUAL

Thank you for purchasing a SAMSUNG Vari-focal Dome Camera. Before operating the camera,
confirm the camera model that you bought. In order that you can understand this manual
thoroughly,we'llintroduceourmodeldescription.
Topreventelectricshockandriskoffirehazards:
• DoNOTremovecover(orblack),nouserserviceablepartsinsides.
• DoNOTuseotherthanspecifiedpowersource.
• DoNOTexposethisappliancetorainormoisture.
• Manual & Auto Iris Vari-focal Lens
Focallengthis4.0~9.0mm.
• Fine Picture Condition under Very Low Illumination
1/3"highdensityCCDanddigitalprocessorpermithighqualitypictures
tobecapturedinverylowlightcondition.
• Automatic Backlight Compensation
Thebacklightcompensationallowsthecameratofindthebestpicture
conditionsinanyenvironmentandautomaticallygivesanecessarylightlevel
compensation,sothatyoucanalwaysobtaintheclearpicture,thefinestdetail
andperfectlightcontrast.
• High Resolution
Thehorizontalresolutionof420(B/W)/350(Color)TVlinescanbeachieved
byusingahighdensityCCDhavingeffective270,000/320,000pixels,
whichprovidesclean,noiselessandreliablepictures.
• Built-in Flickerless
Inthehighillumination,built-inflickerlesspreventstheflickeringmalfuction.
• Black & Ivory Housing
• Compact Size
2
VARI-FOCALDOMECAMERA
1VARI-FOCALDOMECAMERA
INFORMATION
CAUTION
FEATURES
B/W Vari-focal Dome Camera Color Vari-focal Dome Camera
Manual Iris Auto Iris Manual Iris Auto Iris
SVF-129E SVF-130E SVF-229N SVF-230N
SVF-129C SVF-130C SVF-229P SVF-230P
Model

1. SAFEGUARDS
• Do not install the camera in extreme temperature conditions.
Dousethecameraunderconditionswheretemperaturesarewithin
-10˚C to50˚C(14˚Fto122˚F).
• Do not install the camera under unstable lighting conditions.
Severelightingchangeorflickercancausethecameratoworkimproperly.
• Do not install or use the camera in an environment where the humidity is high.
Itcancausetheimagequalitytobepoor.
• Do not disassemble the camera.
Therearenouser-serviceablepartsinsideit.
• Do not expose the camera to rain or spill beverage on it.
Ifitgetswet,wipeitdryimmediately.Liquidscancontainminerals
thatcorrodetheelectroniccomponents.
• Do not touch the lens window of the camera.
Becarefulnottobestainedbyfingerprint.
• Never keep the camera face to strong light directly.
ItcandamagetheCCD.
4
VARI-FOCALDOMECAMERA
TABLE OF CONTENTS
1. SAFEGUARDS.........................................................................................................................4
2. CONFIRMATION OF CONTENTS..................................................................................................5
3. TITLE OF EACH PARTS ..............................................................................................................................................6
4. SPECIFICATIONS........................................................................................................................................................7
5. INSTALLATION & ADJUSTMENT...........................................................................................................................10
6. TROUBLE SHOOTING ................................................................................................................................................11
3VARI-FOCALDOMECAMERA

3. TITLE OF EACH PARTS
6
VARI-FOCALDOMECAMERA
2. CONFIRMATION OF CONTENTS
5VARI-FOCALDOMECAMERA
The body of Camera
Instruction Manual
BNC & DC J¤ack
Screws
DOME
RING
WINDOW
MOUNTING
HOLES
The front of camera
The back of camera
HOLE
BNC & DC JACK

8
VARI-FOCALDOMECAMERA
7VARI-FOCALDOMECAMERA
FOCALLENGTH 4.0~9.0mm
IRIS F1.6~2.4
OPERATION FOCUS Manual(50cm~∞)
ZOOM Manual
D 92.6º~39.4º
ANGLEOFVIEW H 71.0º~31.6º
V 51.8º~23.6º
Manual lris Lens
Dimensions
(IN AIR) ( unit : mm )
B / W COLOR
Manual Iris Auto Iris Manual Iris Auto Iris
Model SVF - 129E SVF - 130E SVF - 229N SVF - 230N
SVF - 129C SVF - 130C SVF - 229P SVF - 230P
Pick-up Device 1/3”CCD 1/3”CCD
Resolution 420TVLines 350TVLines
S/N Ratio 50dB(AGCoff) 48dB(AGCoff)
Flickerless Selectable Selectable
Video Output 1.0Vp-p Comp. 1.0Vp-p Comp.
Lens f=4.0~9.0mm f=4.0~9.0mm
Operating Temp. -10˚C~+50˚C (14˚F~122˚F) -10˚C~+50˚C (14˚F~122˚F).
Humidity 30 % ~ 90 % 30 % ~ 90 %.
Power DC 12 V DC 12 V DC 12 V DC 12 V
Consumption Max. 130mA Max. 150mA Max. 230mA Max. 250mA
Dimension ( mm ) 120(W)x95(H) 120(W)x95(H)
Weight ( g ) 250 260 255 265
4. SPECIFICATIONS

BROWN DRIVE(+)
RED DRIVE(-)
ORANGE CONTROL(-)
YELLOW CONTROL(+)
5. INSTALLATION & ADJUSTMENT
10
VARI-FOCALDOMECAMERA
9VARI-FOCALDOMECAMERA
5. INSTALLATION
Auto Iris Lens
Dimensions
Wiring Diagram
FOCALLENGTH 4.0~9.0mm
IRIS Auto(F1.6~ 200)
FOCUS Manual(50cm~∞)
ZOOM Manual
D 92.6º~39.4º
H 71.0º~31.6º
V 51.8º~23.6º
DRIVE 190Ω
CONTROL 855Ω
OPERATION
ANGLE OF VIEW
COIL
•Drivescrews(68.6mminterval,2EA)intotheceilingorthewall.
•Connectthepowercableofthecamerabyusingthesuitableadaptor.
•Connectthevideocabletoinputterminalinthemonitor.
•Fixingthebodyofthecamera,byturningitleftafterputtingthescrewsinthecamera.
•Adjustphotographicdirectionofcameraafteropeningthecamera.
(IN AIR) ( unit : mm )
Mark

• The image on the screen flickers.
Doesthecamerafacetodirectlytothesunorfluorescentlighting?
Changethecameraposition.
• Blooming or smearing turns up.
Openthedomecoverandturnvariableresistor(B/W:fix,Color:VR1)
towardcounterclockwiseinthemainboarduntilthebloomingorthesmearing
isdisappeared.
• OFD(Overflow Distortion) turns up.
Openthedomecoverandturnvariableresistor(B/W:fix,Color:VR1)
towardclockwiseinthemainboarduntiltheOFDisdisappeared.
•The brightness is too bright or dark. (MODEL : SVF-130E/C, SVF-230N/P)
Adjustthevariableresistor(VR3)ofautoirisboardtowardclockwiseor
counterclockwise.
12
VARI-FOCALDOMECAMERA
6. TROUBLE SHOOTING
11 VARI-FOCALDOMECAMERA
• Nothing appears on the screen.
Checkthatthepowercordandlineconnectionbetweenthecamera
andmonitoraremadeproperly.
• The image on the screen is dim.
Checkifthelensarestained.Ifdirty,cleanthelenswithsoft andcleancloth.
• The camera is not work properly, and the surface of the camera case is hot.
Checkthatyouhaveconnectedthecameratoaproperpower.
• The contrast on the screen is too weak.
Adjustthecontrastfeatureofthemonitor.
Ifthecameraisexposedundertoostronglight,changethecameraposition.
