Samsung DA-F680 User manual

DA-F680
Wireless Audio with Dock
user manual
imagine the possibilities
Thank you for purchasing this Samsung product.
To receive more a complete service, please register
your product at
www.samsung.com/register

2 English
features
NFC support
Connect your NFC compatible device via Bluetooth to the Wireless Audio with Dock using this simple set-up procedure
and play music on the device through the Wireless Audio with Dock.
Galaxy Docking Audio Speaker System
Using the system's docking station, dock, charge and then play some Samsung Galaxy devices released after
S3(Android OS 4.1.2 or later) through the system's built-in speakers.
Bluetooth Function
Connect a Bluetooth device to the Wireless Audio with Dock and enjoy music from the device with high quality stereo
sound, all without wires!

3
EnG
English
safety information
SAFETY WARNINGS
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER(OR BACK).
NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol indicates “dangerous voltage”
inside the product that presents a risk of
electric shock or personal injury.
This symbol indicates important instructions
accompanying the product.
WARNING : To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture.
CAUTION : TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
• This apparatus shall always be connected to a AC outlet with a protective grounding connection.
• To disconnect the apparatus from the mains, the plug must be pulled out from the mains socket, therefore the mains
plug shall be readily operable.
CAUTION
• Do not expose this apparatus to dripping or splashing. Do not put objects filled with liquids, such as vases on the
apparatus.
• To turn this apparatus off completely, you must pull the power plug out of the wall socket. Consequently, the power
plug must be easily and readily accessible at all times.

4 English
PRECAUTIONS
Ensure that the AC power supply in your house complies with the power requirements listed on the identification
sticker located on the back of your product. Install your product horizontally, on a suitable base (furniture), with
enough space around it for ventilation (70~100 mm). Make sure the ventilation slots are not covered. Do not place
the unit on amplifiers or other equipment which may become hot. This unit is designed for continuous use. To fully
turn off the unit, disconnect the AC plug from the wall outlet. Unplug the unit if you intend to leave it unused for a
long period of time.
Ensure that the AC power supply in your house complies with the power requirements listed on the identification
3.9 inch 3.9 inch
2.7 inch
3.9 inch
During thunderstorms, disconnect the AC plug from
the wall outlet. Voltage peaks due to lightning could
damage the unit.
Protect the product from moisture (i.e. vases) , and
excess heat (e.g.fireplaces) or equipment creating
strong magnetic or electric fields Disconnect the power
cable from the AC supply if the unit malfunctions. Your
product is not intended for industrial use. This product
is for personal use only.
Condensation may occur if your product has been
stored in cold temperatures. If transporting the unit
during the winter, wait approximately 2 hours until the
unit has reached room temperature before using.
Do not expose the unit to direct sunlight or other heat
sources.
This could cause the unit to overheat and malfunction.
The batteries used with this product contain chemicals
that are harmful to the environment.
Do not dispose of batteries in the general household
trash.
Phones
99.1mm
99.1mm
68.6mm
99.1mm

5
EnG
English
contents
FEATURES
2
2 Features
SAFETY INFORMATION
3
3 Safety warnings
4 Precautions
GETTING STARTED
6
6 Before reading the user’s manual
6 What’s included
DESCRIPTIONS
7
7 Top/Front/Rear Panel
REMOTE CONTROL
9
9 Tour of the remote control
POWER ON AND VOLUME
CONTROL
10
10 Turning the Power on/off
10 Adjusting the volume
CONNECTIONS
11
11 Using the Spacer Cover
12 Connecting a device to the Galaxy Dock
13 Connecting an audio device using AUX IN
14 Connecting the NFC function
15 Using Bluetooth
FUNCTIONS
18
18 Using the TV mode (SoundShare)
18 Using the docking mode with Samsung
Galaxy Devices
19 Using the Bluetooth mode
20 Using the USB mode
21 Software upgrade (only USB mode)
TROUBLESHOOTING
22
22 Troubleshooting
APPENDIX
23
23 Specifications

English6
getting started
BEFORE READING THE USER’S MANUAL
Note the following terms before reading the user manual.
Icons used in this manual
Icon Term Definition
Caution
Indicates a situation where a function does not operate or settings may be canceled.
Note
Indicates tips or instructions on the page that help a function operate.
Safety Instructions and Troubleshooting
1) Familiarise yourself with the Safety Instructions before using this product. (See page 3)
2) If a problem occurs, check Troubleshooting. (See page 22)
Copyright
©2013 Samsung Electronics Co.,Ltd.
All rights reserved; no part or whole of this user’s manual may be reproduced or copied without the prior written
permission of Samsung Electronics Co.,Ltd.
WHAT’S INCLUDED
Check for the supplied accessories shown below.
MUTE
VOL
BASS
FUNCTION
Remote Control /
Lithium Battery (3V)
Power Adapter Power Cable Audio Cable
Spacer Cover/
Protection Cover Cloth User Manual
`The appearance of the accessories may differ slightly from the illustrations above.

7
EnG
English
●DESCRIPTIONS
descriptions
TOP/FRONT/REAR PANEL
DOCK
PUSH
AUX IN ONLYFOR
SERVICE
LAN
USB 5V 500mA
DC 14V 4A
AUX IN ONLYFOR
SERVICE
LAN
USB 5V 500mA
DC 14V 4A
PUSH
1
2
3
4
5
<TOP>
DOCK
PUSH
AUX IN ONLYFOR
SERVICE
LAN
USB 5V 500mA
DC 14V 4A
AUX IN ONLYFOR
SERVICE
LAN
USB 5V 500mA
DC 14V 4A
PUSH
<FRONT>
DOCK
PUSH
AUX IN ONLYFOR
SERVICE
LAN
USB 5V 500mA
DC 14V 4A
AUX IN ONLYFOR
SERVICE
LAN
USB 5V 500mA
DC 14V 4A
PUSH
DOCK
PUSH
AUX IN ONLYFOR
SERVICE
LAN
USB 5V 500mA
DC 14V 4A
AUX IN ONLYFOR
SERVICE
LAN
USB 5V 500mA
DC 14V 4A
PUSH
DOCK
PUSH
AUX IN ONLY FOR
SERVICE
LAN
USB 5V 500mA
DC 14V 4A
AUX IN ONLY FOR
SERVICE
LAN
USB 5V 500mA
DC 14V 4A
PUSH
6
8
9
7
10
<REAR>

English8
1PLAY/PAUSE
BUTTON
Play or pause a music file.
Press the button for 3 seconds to turn off.
2FUNCTION
BUTTON
Switches the mode as follows :
; ; ; ;
3VOLUME
+/- BUTTON
Controls the volume level.
4FUNCTION
DISPLAY
When you change the mode with the Function button, the icon of the
selected mode is displayed in white on the Function Display.
The LED blinks when you turn the power on and stops blinking when
the unit is on and ready to play.
5NFC TAG
Connect your NFC compatible device via Bluetooth to the using this
simple set-up procedure.
6GALAXY DOCK
Provides a 5-pin dock for Samsung Galaxy devices and a 30-pin
dock for Samsung Galaxy Tab devices.
7DC 14V
Connect the unit's DC adapter to this jack.
8USB PORT
Connect a regular stick type USB storage device such as a thumb
drive to play files stored in the device.
9
AUX IN
Connect to the Analog output of an external device.
10
ONLY FOR
SERVICE
This jack is for service only.
`When you turn on this unit, there will be a 4 to 5 second delay before it produces sound.
`To update the product’s software via USB port, it is required to use a USB memory device.
`This unit can connect to mobile devices with high audio output levels. When you connect this
unit to external devices with high output levels, it may lower the audio output to protect the
amp and speakers.
`When disconnecting the power cable from the wall outlet, hold the plug. Do not pull the
cable.

9
EnG
English
●REMOTE CONTROL
remote control
TOUR OF THE REMOTE CONTROL
MUTE
VOL
BASS
FUNCTION
POWER BUTTON
Turns the unit on and off.
CONTROL BUTTON
Search for the next or
previous music file.
VOLUME
Adjusts the volume level of
the unit.
PLAY/PAUSE BUTTON
Play or pause a music file.
FUNCTION BUTTON
Selects the Function mode.
MUTE BUTTON
Mutes the sound from this
unit. Press again to restore
the sound to the previous
volume level.
BASS BUTTON
Optimise the sound based on
your tastes.
Installing battery in the Remote Control
1. Open the cover of the remote
control by putting your fingernail
into the gap between the cover
and body of the remote control.
Then, lift the cover and separate
it completely.
2. Install a 3V Lithium battery.
Insert the battery into the battery
compartment with the + side
facing up.
3. Fit the remote control's cover to
the remote control. Next, lower the
cover so that it is flush with the
body of the remote, and then press
the cover into the body by pushing
the edges down with your hand.
`Be careful not to catch your fingernail in the gap when you lift the cover. You can damage your fingernail.
Operation Range of the Remote Control
You can use the remote control up to 7 meters in a straight line from the unit. You can also operate the remote at a
horizontal angle of up to 30° from the remote control sensor.

English10
power on and volume control
TURNING THE POWER ON/OFF
MUTE
VOL
BASS
FUNCTION
MUTE
VOL
BASS
FUNCTION
DOCK
DOCK
DOCK DOCK
DOCK DOCK
DOCK DOCK
or
1. To turn on this unit, press any button on the unit's top panel when the unit is in Standby mode.
or,
Press POWER on the remote control.
2. To turn off this unit, press the
+# button on the unit's top panel for more than 3 seconds.
or,
Press POWER on the remote control again.
`The unit turns off automatically in the following situations:
- BT/Dock/SoundShare mode : If there is not connected for about 25 minutes.
- USB mode : If there is no audio signal for about 25 minutes.
- AUX mode : If no KEY input is entered for 8 hours when the cable is connected.
ADJUSTING THE VOLUME
Use +,- buttons to adjust the volume. The function LEDs light from left to right when you turn the volume up and from
right to left when you turn the volume down. The LEDs do not flicker if you try to increase the volume when it has
already been set to maximum or try to decrease the volume when it has already been set to minimum.
MUTE
VOL
BASS
FUNCTION
MUTE
VOL
BASS
FUNCTION
DOCK
DOCK
DOCK DOCK
DOCK DOCK
DOCK DOCK
or
Press the +/– button on the right side of the top panel.
or,
Press VOL +/– on the remote control.
`The volume level increases or decreases when you press VOL +/–.
`You can also use the volume controls of devices connected using the Galaxy Dock or Bluetooth to control
the volume. However, your ability to control the volume using the volume controls of devices connected
using Bluetooth may be limited.
