Samsung Galaxy View SM-T670 User manual

www.samsung.com
User Manual
SM-T670
SM-T677
SM-T677Y
English (EU). 11/2015. Rev.1.1

2
Table of Contents
Basics
4 Read me first
5 Package contents
6 Device layout
9 Battery
12 SIM or USIM card (mobile network-
enabled models)
14 Memory card
16 Turning the device on and off
16 Touchscreen
19 Home screen
24 Lock screen
25 Notification panel
28 Entering text
30 Screen capture
30 Opening apps
31 Multi window
36 Device and data management
40 Connecting to a TV
Applications
42 Installing or uninstalling apps
44 Video
45 Music
46 Internet
47 My Files
47 Family Square
49 Camera
51 Gallery
52 Email
53 Contacts
55 Smart Manager
57 S Planner
59 SideSync
67 Memo
68 Clock
70 Calculator
70 Google apps
Settings
72 Introduction
72 Wi-Fi
74 Bluetooth
76 Flight mode
76 Mobile hotspot and tethering (mobile
network-enabled models)
77 Data usage
77 Data usage (mobile network-enabled
models)
78 Mobile networks (mobile network-
enabled models)
78 More connection settings
80 Sounds and notifications
81 Display
81 Applications

Table of Contents
3
81 Users
83 Wallpaper
84 Lock screen and security
84 Privacy
85 Accessibility
85 Accounts
86 Backup and reset
87 Language and input
88 Battery
88 Storage
89 Date and time
89 User manual
89 About device
Appendix
90 Troubleshooting
95 Removing the battery

4
Basics
Read me first
Please read this manual before using the device to ensure safe and proper use.
•
Descriptions are based on the device’s default settings.
•
Some content may differ from your device depending on the region, service provider,
model specifications, or device’s software.
•
Content (high quality content) that requires high CPU and RAM usage will affect the
overall performance of the device. Apps related to the content may not work properly
depending on the device’s specifications and the environment that it is used in.
•
Samsung is not liable for performance issues caused by apps supplied by providers other
than Samsung.
•
Samsung is not liable for performance issues or incompatibilities caused by edited
registry settings or modified operating system software. Attempting to customise the
operating system may cause the device or apps to work improperly.
•
Software, sound sources, wallpapers, images, and other media provided with this device
are licensed for limited use. Extracting and using these materials for commercial or other
purposes is an infringement of copyright laws. Users are entirely responsible for illegal
use of media.
•
You may incur additional charges for data services, such as messaging, uploading and
downloading, auto-syncing, or using location services depending on your data plan. For
large data transfers, it is recommended to use the Wi-Fi feature.
•
Default apps that come with the device are subject to updates and may no longer be
supported without prior notice. If you have questions about an app provided with
the device, contact a Samsung Service Centre. For user-installed apps, contact service
providers.
•
Modifying the device’s operating system or installing softwares from unofficial sources
may result in device malfunctions and data corruption or loss. These actions are violations
of your Samsung licence agreement and will void your warranty.

Basics
5
•
Depending on the region or model, some devices are required to receive approval from
the Federal Communications Commission (FCC). If your device is approved by the FCC,
you can view the FCC ID of the device. To view the FCC ID, tap
Apps
→
Settings
→
About device .
•
Depending on the region, you can view the regulatory information on the device. To view
the information, tap
Apps
→
Settings
→
About device
→
Regulatory information .
Instructional icons
Warning: situations that could cause injury to yourself or others
Caution: situations that could cause damage to your device or other equipment
Notice: notes, usage tips, or additional information
Package contents
Check the product box for the following items:
•
Device
•
Quick start guide
•
The items supplied with the device and any available accessories may vary
depending on the region or service provider.
•
The supplied items are designed only for this device and may not be compatible
with other devices.
•
Appearances and specifications are subject to change without prior notice.
•
You can purchase additional accessories from your local Samsung retailer. Make
sure they are compatible with the device before purchase.
•
Use only Samsung-approved accessories. Using unapproved accessories may cause
the performance problems and malfunctions that are not covered by the warranty.
•
Availability of all accessories is subject to change depending entirely on
manufacturing companies. For more information about available accessories, refer
to the Samsung website.

Basics
6
Device layout
Device
Touchscreen
Volume key
Power key
Camera
Light sensor
Loud speaker
Microphone
Microphone
Loud speaker
Card slot cover
Main antenna
(mobile
network-enabled
models)
GPS antenna
Headset jack
USB port
DC jack
•
Do not cover the antenna area with your hands or other objects. This may cause
connectivity problems or drain the battery.
•
Using a Samsung-approved screen protector is recommended. Unapproved screen
protectors may cause the sensors to malfunction.
•
Do not allow water to contact the touchscreen. The touchscreen may malfunction
in humid conditions or when exposed to water.

Basics
7
Keys
Key Function
Power
•
Press and hold to turn the device on or off.
•
Press to turn on or lock the screen.
Volume
•
Press to adjust the device volume.
Stand
Use you device as a monitor for watching TV or movies, or for sharing content. You can also
use the handle on the stand to carry the device.
Be careful not to get your fingers caught between the device and the stand.
Always leave the stand attached to the device.
Using the stand
When you stand the device up, always ensure that the upper part of the stand and the device
are connected. Also, place the device on a flat surface. If you do not, the device may fall and
be damaged.

Basics
8
Carrying the device
You can hold the stand’s handle and carry the device.
To hold the device safely, put your fingers through the handle and place them between the
device and the stand.

Basics
9
Battery
Charging the battery
Charge the battery before using it for the first time or when it has been unused for extended
periods.
Use only Samsung-approved chargers, batteries, and cables. Unapproved chargers or
cables can cause the battery to explode or damage the device.
•
You cannot charge the battery using a USB cable. Use the charger to charge the
battery.
•
The provided charger and charging method may differ depending on the region.
1 Plug the small end of the charger into the DC jack of the device, and plug the large end of
the charger into an electric socket.
•
Connecting the charger improperly may cause serious damage to the device. Any
damage caused by misuse is not covered by the warranty.
•
Do not plug the charger into the headset jack.

Basics
10
2 After fully charging, disconnect the device from the charger. First unplug the charger
from the device, and then unplug it from the electric socket.
To save energy, unplug the charger when not in use. The charger does not have a
power switch, so you must unplug the charger from the electric socket when not in
use to avoid wasting power. The charger should remain close to the electric socket
and easily accessible while charging.
Viewing the remaining charging time
While charging, open the Home screen and tap Apps
→
Settings
→
Battery .
The actual charging time may vary depending on the status of your device and the
charging conditions. The remaining charging time may not be displayed when you
charge the device in very cold or very hot conditions.
Reducing the battery consumption
Your device provides various options that help you conserve battery power.
•
Optimise the device using the Smart manager.
•
When you are not using the device, switch to sleep mode by pressing the Power key.
•
Activate power saving mode.
•
Close unnecessary apps.
•
Deactivate the Bluetooth feature when not in use.
•
Deactivate the Wi-Fi feature when not in use.
•
Deactivate auto-syncing of apps.
•
Decrease the backlight time.
•
Decrease the screen brightness.

Basics
11
Battery charging tips and precautions
•
When the battery power is low, the battery icon appears empty.
•
If the battery is completely discharged, the device cannot be turned on immediately
when the charger is connected. Allow a depleted battery to charge for a few minutes
before turning on the device.
•
If you use multiple apps at once, network apps, or apps that need a connection to
another device, the battery will drain quickly. To avoid disconnecting from the network
or losing power during a data transfer, always use these apps after fully charging the
battery.
•
The device can be used while it is charging, but it may take longer to fully charge the
battery.
•
If the device receives an unstable power supply while charging, the touchscreen may not
function. If this happens, unplug the charger from the device.
•
While charging, the device and the charger may heat up. This is normal and should not
affect the device’s lifespan or performance. If the battery gets hotter than usual, the
charger may stop charging.
•
If the device is not charging properly, take the device and the charger to a Samsung
Service Centre.
Power saving mode
Save the battery power by limiting the device’s functions.
On the Home screen, tap
Apps
→
Settings
→
Battery
→
Power saving mode , and then tap
the switch to activate it.
To automatically activate power saving mode when the remaining battery power reaches the
preset level, tap
Start power saving and select an option.

Basics
12
SIM or USIM card (mobile network-enabled
models)
Installing the SIM or USIM card
Insert the SIM or USIM card provided by the mobile telephone service provider.
•
Only nano-SIM cards work with the device.
•
Some LTE services may not be available depending on the service provider. For
more information about service availability, contact your service provider.
2
13
1 Slide the card slot cover to open.
The card slot cover is not detachable. If you forcibly remove the card slot cover, the
cover and the device may be damaged. Do not slide the cover excessively.

Basics
13
2 Insert the SIM or USIM card with the gold-coloured contacts facing downwards. Then,
push the SIM or USIM card into the slot until it locks in place.
•
Do not insert a memory card into the SIM card slot. If a memory card happens to
be lodged in the SIM card slot, take the device to a Samsung Service Centre to
remove the memory card.
•
Use caution not to lose or let others use the SIM or USIM card. Samsung is not
responsible for any damages or inconveniences caused by lost or stolen cards.
3 Slide the card slot cover to close.
Removing the SIM or USIM card
1 Slide the card slot cover to open.
2 Push the SIM or USIM card until it disengaged from the slot, and then pull it out.
3 Slide the card slot cover to close.

Basics
14
Memory card
Installing a memory card
Your device accepts memory cards with maximum capacities of 128 GB. Depending on the
memory card manufacturer and type, some memory cards may not be compatible with your
device.
•
Some memory cards may not be fully compatible with the device. Using an
incompatible card may damage the device or the memory card, or corrupt the data
stored in it.
•
Use caution to insert the memory card right-side up.
•
The device supports the FAT and the exFAT file systems for memory cards. When
inserting a card formatted in a different file system, the device asks to reformat the
memory card.
•
Frequent writing and erasing of data shortens the lifespan of memory cards.
•
When inserting a memory card into the device, the memory card’s file directory
appears in the
My Files
→
SD card folder.
2
13

Basics
15
1 Slide the card slot cover to open.
The card slot cover is not detachable. If you forcibly remove the card slot cover, the
cover and the device may be damaged. Do not slide the cover excessively.
2 Insert a memory card with the gold-coloured contacts facing downwards. Then, push the
memory card into the slot until it locks in place.
3 Slide the card slot cover to close.
Removing the memory card
Before removing the memory card, first unmount it for safe removal.
On the Home screen, tap
Apps
→
Settings
→
Storage
→
Unmount SD card .
1 Slide the card slot cover to open.
2 Push the memory card until it disengages from the slot, and then pull it out.
3 Slide the card slot cover to close.
Do not remove the memory card while the device is transferring or accessing
information. Doing so can cause data to be lost or corrupted or damage to the
memory card or device. Samsung is not responsible for losses that result from the
misuse of damaged memory cards, including the loss of data.
Formatting the memory card
A memory card formatted on a computer may not be compatible with the device. Format the
memory card on the device.
On the Home screen, tap
Apps
→
Settings
→
Storage
→
Format SD card
→
FORMAT SD
CARD
→
ERASE EVERYTHING .
Before formatting the memory card, remember to make backup copies of all
important data stored in the memory card. The manufacturer’s warranty does not
cover loss of data resulting from user actions.

Basics
16
Turning the device on and off
Press and hold the Power key for a few seconds to turn on the device.
When you turn on your device for the first time or after performing a data reset, follow the on-
screen instructions to set up your device.
To turn off the device, press and hold the Power key, and then tap
Power off .
•
If your device is frozen and unresponsive, press and hold the Power key and the
Volume key down simultaneously for more than 7 seconds to restart it.
•
Follow all posted warnings and directions from authorised personnel in areas
where the use of wireless devices is restricted, such as aeroplanes and hospitals.
Touchscreen
•
Do not allow the touchscreen to come into contact with other electrical devices.
Electrostatic discharges can cause the touchscreen to malfunction.
•
To avoid damaging the touchscreen, do not tap it with anything sharp or apply
excessive pressure to it with your fingertips.
•
The device may not recognise touch inputs close to the edges of the screen, which
are outside of the touch input area.
•
Leaving the touchscreen idle for extended periods may result in afterimages
(screen burn-in) or ghosting. Turn off the touchscreen when you do not use the
device.
•
It is recommended to use fingers when you use the touchscreen.

Basics
17
Tapping
To open an app, to select a menu item, to press an on-screen button, or to enter a character
using the keyboard on the screen, tap it with your finger.
Tapping and holding
Tap and hold an item or the screen for more than 2 seconds to access available options.
Dragging
To move an item, tap and hold it and drag it to the target position.

Basics
18
Double-tapping
Double-tap on a webpage or image to zoom in. Double-tap again to return.
Swiping
Swipe to the left or right on the Home screen or the Apps screen to view other panels. Swipe
upwards or downwards to scroll through a webpage or a list of items, such as contacts.
Spreading and pinching
Spread two fingers apart on a webpage, map, or image to zoom in a part. Pinch to zoom out.

Basics
19
Home screen
Home screen
The Home screen is the starting point for accessing all of the device’s features. It displays
widgets, shortcuts to apps, and more.
To view other panels, swipe to the left or right.
A widget
A folder
Screen indicators
Favourite apps
Launch Family
Square.
Apps screen icon
Keys
Keys
Key Function
Recents
•
Tap to open the list of recent apps.
•
Tap and hold to launch the split screen view.
TV service
•
Tap to go to the TV page. This feature may not be available
depending on the region or service provider.
Home
•
Tap to return to the Home screen. If TV services are
available, you will go to the TV page when you tap this
key.
•
Tap and hold to launch Google .
Back
•
Tap to return to the previous screen.

Basics
20
Home screen options
On the Home screen, tap and hold an empty area, or pinch your fingers together to access
the available options. Customise the Home screen by adding, deleting, or rearranging Home
screen panels. You can also set the Home screen wallpaper, add widgets to the Home screen,
and more.
•
Wallpapers : Change the wallpaper settings for the Home screen and the locked screen.
•
Widgets : Add widgets to the Home screen. Widgets are small apps that launch specific
app functions to provide information and convenient access on your Home screen.
Adding items
Tap and hold an app or a folder from the Apps screen, and then drag it to the Home screen.
To add widgets, tap and hold an empty area on the Home screen, tap
Widgets , tap and hold a
widget, and then drag it to the Home screen.
