Product Features
Small but Strong UMPC (Ultra Mobile PC)
● Intel ULV CPU (Optional)
● 512MB~Up To 1GB DDR2 Memory
7” WSVGA TFT LCD
● Basic Resolution of 1024x600 Pixels, Maximum Resolution of
2048x1536 Pixels (when an external display is connected)
● A Touch Screen and Touch Sensor buttons (optional) have
been adopted allowing convenient input with your fingers.
● A Keypad has been adopted to easily enter characters
● A convenient mouse function (Mouse/Joystick, Mouse Button
applied)
Powerful Multimedia Functions
● Various Multimedia Programs Such as Play AVStation etc.
● Dual camera for photographing and video recording (Optional)

3
Multiple Network Support
● Wired LAN, Wireless LAN, Bluetooth (Optional)
● Resolves Space Restrictions through the Wireless
Communication Function
Compact, Light-Weight Design for Portability /
Polished Design
● A mere 690g (1.52lb) (Without optional items)
● High-Gloss Front Panel
Optional Accessories for Additional Convenience
● USB Data Cable Enabling Data Exchange with another PC.
● USB External ODD(Optical Disk Drive), Ultra-Slim USB
External Keyboard
● Power Bank to Extend Usage Time

4
Before You Start
Before reading the User Guide, first check the following information.
User Guide Information
This product is supplied with an Getting
Started Guide, and a User Guide.
You can even more easily and
conveniently use the computer by using
any of the guides depending on your
needs.
Getting Started Guide
This guide is provided so that you can
conveniently refer to this guide when
using the computer for the first time after
purchasing it.
User Guide
The document you are currently reading
is the User Guide. You can read it by
double-tapping the icon on the Desktop.
This document includes the computer
functions, how to use the functions, and
how to use the program.
Utilizating the User Guide
 Be sure to read the Safety Precautions
before using the computer.
 For basic usage of the computer refer to
the additionally supplied Getting Started
Guide.
 Refer to the User Guide for the
procedures to use the computer.
 Using the Index of the User Guide, you
can easily find any information you are
looking for.
 Using the Glossary of the User Guide,
you can easily find meanings for technical
terms.
 If a problem occurs, refer to the Q & A
included in the User Guide.
■ Some devices and software
referred in the User Guide may
not be provided and/or changed
by upgrade.
Note that the computer
environment referred in the User
Guide may not be the same as
your own environment.
■ The image used for the cover and
text of the User Guide may not be
the same as actual ones.

5
■ This guide decribes procedures
for both the mouse and the stylus
pen together.
A ‘Click’ in this manual refers to
a ‘Single-tap’ for the Stylus Pen.
■ The figures in this guide are
provided assuming that your
operating system is Windows
Vista. The figures are subject to
change.
■ The User guide supplied
with computer may be varied
depending on model.
Safety Precaution Notations
Icon Notation Description
Warning
Failing to follow
instructions marked with
this symbol, may cause
personal injury and or
fatality.
Caution
Failing to follow
instructions marked with
this symbol, may cause
slight injury to yourself or
damage your property.
Text Notations
Icon Notation Description
Before
You
Start
Content included in
this section includes
information required
before using a function.
Caution
Content included in
this section includes
information required
about the function.
Note
Content included in this
section includes helpful
information to use the
function.
Page XX
This notation represents
the page number you can
refer to for information
about related functions or
as a reference.
Start >
All Programs
> Samsung >
User Guide >
User Guide
This represents a menu
path to run a program.
Click the Start button and
then select All Programs
> Samsung > User
Guide > User Guide in
this order from the menu.

6
Copyright
© 2007 Samsung Electronics Co., Ltd.
Samsung Electronics Co., Ltd. owns the
copyright of this manual.
No part of this manual may be
reproduced or transmitted in any form or
by any means, electronic or mechanical,
without the consent of Samsung
Electronics Co., Ltd.
The information in this document is
subject to change without notice due
to improving the performance of the
product.
Samsung Electronics shall not be liable
for any data loss. Please take care to
avoid losing any important data and
backup your data to prevent any such
data loss.
Precautions for
Operating System Support
The operating system (OS) installed
on this product is the latest version of
Windows Vista. You cannot install an
operating system other than Windows
Vista as well as any unauthorized copy of
Windows Vista.
Example) When trying to install Windows
Vista Home Premium when Windows
Vista Home Basic is already installed.
Other operating systems (Windows 98,
Windows ME, Windows 2000, Windows
2003 server, UNIXand LINUX, other
Windows Vista versions, etc.) other than
the operating system already installed on
this computer are not supported.
If a problem occurs because of the
installation of another operating system,
the company will not provide technical
support, a replacement or refund, and if
our service engineer visits you due to this
problem, a service charge will be applied.
In addition, installing a program that does
not support Windows Vista, may cause
the program to not work properly.
In this case, ask the corresponding
software manufacturer about the
problem. If you request our services
to resolve a problem caused by
incompatible software, a service charge
will be applied.

7
Contents
Chapter 1. Getting Started
Product Features 2
Before You Start 4
Contents 7
Safety Precautions 8
Proper Posture During Computer Use 18
Important Safety Information 20
Replacement Parts and Accessories 22
Regulatory Compliance Statements 24
WEEE SYMBOL INFORMATION 33
Overview 34
Turning the Computer On and Off 42
Chapter 2. Using the Computer
Stylus Pen 45
Entering Text 48
Using the Buttons 54
Multi Card Slot 61
Connecting a Monitor 64
Adjusting the Volume 68
Chapter 3. Using Microsoft Windows Vista
About Microsoft Windows Vista 71
Windows Vista Screen Layout 74
Control Panel 83
Chapter 4. Using the Network
Wired Network 96
Wireless Network 99
Using the Easy Network Manager 102
Bluetooth 106
Chapter 5. Using Applications
Introducing Programs 113
Origami Experience 116
CyberLink PowerDVD 118
Samsung Update Plus 120
Play AVStation 122
AVStation Now 136
Play Camera 138
OmniPass (Fingerprint Identification
software) 141
Chapter 6. Settings
BIOS Setup 148
Setting a Boot Password 153
Changing the Boot Priority 156
Battery 157
Chapter 7. Windows Media Center
About Package Contents
and the Program Guide 164
Connecting and Setting Up Media Center 165
Using Media Center 169
Chapter 8. Appendix
Using Samsung Magic Doctor 182
Using McAfee SecurityCenter 183
Reinstalling Software 184
Reinstalling Windows Vista 186
Samsung Recovery Solution II 190
Q & A 200
Intel Media Sharing Software Information 217
Product Specifications 218
Glossary 222
Index 225
Contact SAMSUNG WORLD WIDE 226
