E-MANUAL
Thank you for purchasing this Samsung product.
To receive more complete service, please register
your product at
www.samsung.com/register
Model Serial No.

Broadcast Audio
Screen Menu > Broadcasting > Audio Options
The displayed image may differ depending on the model,
Configure the program's audio language. Using this option is different for analog and digital channels.
Digital Broadcast Audio Options
Preferred Language: Digital broadcasts are embedded with audio signals in multiple languages
which users can choose from. You do not need to manually configure digital broadcasts that
support the designated language. If the designated language is not supported, the default audio
language chosen by the TV station will be heard.
o Visual _mpaired: Activate the audio guide for the visually impaired. This is only available with
broadcasts that provide this service.
Analog Broadcast Audio Options
Mumti-Traok Sound: Configure the audio for the current broadcast. You can select a sound you
want to listen from among the ones being broadcasted. Multi-Track Sound may differ depending
on the program being broadcast or broadcast signal. Although user set this option to stereo,
if the broadcast signal or program is not supported a stereo, this option will be set to mono
automatically, i_!: !i!_ /_
Setect the virtual remote panel's INFO button to view the current broadcast's audio signal information.
Select the virtua remote panel's TOOLS button whie watching TV to access and configure the Multi-Track
Sound setting,

Screen Menu > Smart Features > Sports Mode
This functions is not available on U.S.A. and Canada.
Enable Sports Mode for the optimal sports viewing experience. However, enabling Sports Mode
disables the Picture, Sound and Broadcasting menu options. Disabling Sports Mode restores the
previous Picture and Sound settings.
Subtitles
Screen Menu > Broadcasting > Caption
The displayed image may differ depending on the model,
View subtitles along with subtitle-enabled digital and analog broadcasts.
Show Subtitles
Screen Menu > Broadcasting > Caption > Caption
Show subtitles. Subtitles will be displayed when you choose a broadcast that supports subtitles.
DVD Subtitles are only available when connected to an external input connector:

SubtitMe Options
Screen Menu > Broadcasting > Caption > Caption Mode :_
Select a subtitle mode. The list of modes may vary depending on the broadcast.
o Default /001 ~ 004 /Text1 ~ Text4: (analog channels only) The analog caption function
operates in either analog TV channel mode or when a signal is supplied from an external device
to the TV. (Depending on the broadcasting signal, the analog caption function may or may not
work with digital channels.)
DefauNt /Service1 ~ Service6 /COl ~ 004 /Text1 ~ Text4: (Digital channels only) The digital
caption function works with digital channels. Service1 - Service6 may not be available in digital
caption mode depending on the broadcast.
SubtitMe DispMay Options
Screen Menu > Broadcasting > Caption > Digital Caption Options
Specify the foreground and background settings. This option is available for digital channels.
Size: Choose the subtitle size from the list.
Font Styme: Choose the foreground style from the list.
Font Color: Choose a foreground color from the list.
Background Color: Choose a background color from the list.
Font Opacity: Choose a foreground opacity level from the list.
Background Opacity: Choose a background opacity level from the list.
Return to Default: Restores all subtitle display options to the DefauNt settings. Default applies
settings chosen by the TV station.
The foreground and background color and opac ty sett ngs cannot be the same_

Basic Picture Settings
Screen Menu ) Picture
The dispIayed image may differ depending on the modet,
The basic image settings alter the look and feel of the image displayed on the TV screen.
Changing the Picture Mode
Screen Menu ) Picture > Picture Mode
Choose the optimal picture mode for your TV viewing conditions. When connected to a Computer via
an HDMI-to-DVl cable, only the Standard and Entertain modes can be chosen.
o Dynamic: This increases the brightness of the screen. It is most suitable for bright environments.
o Standard: This is the default mode.
o Natural: This is useful for reducing eye strain. This mode is available for LED TVs only.
o Relax: Consumes less power and reduces eye strain. This mode is only available for PDP TVs.
o Movie: Darkens the screen and reduces glare. Appropriate for darkened rooms, for watching
movies, and when experiencing eye fatigue.
o Entertain: Sharpens images for a more dynamic viewing experience. This mode is only available
when connected to a computer via an HDMI-to-DVl cable.

Picture Quality
Screen Menu > Picture
Choose a Picture Mode and then select the following options to display a slide bar that allows the
corresponding setting to be adjusted. Adjust the value by dragging left/right on the touch pad and
change the setting by dragging up/down on the touch pad. Adjusted values are applied to the current
source and will remain in effect the next time the source is selected. When connected to a computer
via an HDMI-to-DVI cable, only the Color and Tint (G/R} adjustment options can be chosen.
Adjusts the brightness of individual pixels. Decreasing the brightness reduces power
consumption. This option is only available for LED TVs.
Cell Light
Adjusts the brightness of the panel. Decreasing the brightness reduces power consumption. This
option is only available for PDP TVs.
Contrast
Adjusts the screen contrast.
Adjusts the overall brightness.
Sharpens or dulls the edges of objects.
Color
Adjusts the overa II co Ior saturati on.
Tint (G/R}
Adjusts the ratio of green to red. Increase the green value to saturate the greens and the red
value to saturate the reds.
Applying the Cup'rent Pictu_e Quality Setting to Another _nput
Screen Menu> Picture > AppNy Picture Mode
You can apply the picture quality setting that you configured for the TV to all external devices
connected to the TV.
To apply the setting to all external devices connected to the TV, select ANI Sources. To only apply the
setting to the current input, select Current Source.

Picture Size
Screen Menu ) Picture ) Picture Size ) Picture Size
Most TV programs and videos are displayed in full screen, but some programs and videos don't fit the
screen. Users can change the picture size for such programs and videos. However, the available size
options may differ, depending on the video source. For details, see "Picture Size and Input Signal".
o 16:9: Set the picture to the 16:9 wide-screen format.
Zoom1: Magnifies the 16:9 screen size to up and down. A magnified picture can be moved up
and down.
Zoom2: Magnifies the Zoom1 screen size to up and down. A magnified picture can be moved up
and down.
Wide Fit: Enlarge the aspect ratio of the picture so it fits the entire screen. Enjoy 4:3 images as
undistorted 16:9 images.
4:3: Sets the picture to basic 4:3 mode.
ADo not leave the TV in 4:3 mode for an extended period. The dark borders displayed on the left
and right/top and bottom of the screen may cause image retention (screen burn). This is not
covered by the warranty. This mode is available for PDP TVs only.
Screen Fit: Displays the full image without any cutoff,
Smart View 1: Reduces a 16:9 picture by 50%. This mode is only available for LED TVs and in
HDMI mode.
Smart View 2: Reduces a 16:9 picture by 25%. This mode is only available for LED TVs and in
HDMI or DTV mode.
The Picture Size opton s not ava lable with mages n the UHD resolut on because the supported screen
sze s fxed,

Screen Position
Screen Menu ) Picture ) Picture Size ) Position
The screen position can be adjusted if Picture Size is set to Zoom1, Zoom2, Wide Fit, or Screen Fit. In
DTV mode, the screen position cannot be adjusted if the Picture Size is set to Screen Fit.
To adjust the screen position, select Position and then Position from the popup window.
2, Drag on the touch pad to move the screen. Once done, select Position and then Close. Select
Reset to reset the screen position.
The Position opton s not ava lable with mages n the UHD resolut on because the supported screen sze s
fxed.
Picture Off
Screen Menu ) Picture ) Picture Off
Turns off the screen and plays audio only. To turn the screen back on, press any button except TV and
volume buttons.
Reset mmage Settings
Screen Menu ) Picture ) Reset Picture i !c
Reset all image settings for the current Picture Mode to the default settings. This does not affect other
Picture Modes.

Advanced ngs
Screen Menu > Picture > Advanced Settings
The disp ayed image may differ depending on the mode,
Use Advanced Settings to fine-tune how images are displayed on the TV screen. The Advanced
Settings option is only available when Picture Mode is set to Standard or Movie. When the TV is
connected to a computer via an HDMI-DVl cable, only White Balance and Gamma can be adjusted.
o Dynamic Contrast
Automatically adjusts the screen contrast. Use this option to achieve the optimal contrast setting.
o Black Tone
Adjuststheblackcolordepth.
o Flesh Tone
Adjusts the amount of red in skin-color tones.
o RGB Only Mode
Adjusts the red, green, and blue levels individually.

o ColorSpace
Adjuststhe rangeof colorsthat canbeexpressedon screen.Auto automaticallyadjuststhe
colorspacedependingon the inputsignal,andNativeappliesa rangethat is widerthanthe input
signal.Customallow the userto manuallyadjusta rangeof the desiredcolor in the colorsof the
inputsignal._i:i!_:i:::::_
WhiteBalance
Adjuststhe colortemperatureof the pictureto makewhite objectslook whiteandtheoverall
pictureappearnatural.Adjust eachcolor's luminositywith the offset menuandthe brightness
with the gainmenu.To restorethedefaultvalues,selectReset.
10pWhiteBalance
Adjuststhe white balanceby adjustingthe brightnessof the red,green,andblueelementsin
10-pointintervals.Thisoption isonly availablewhenPictureModeissetto Movieandmaynot
be supportedby someexternaldevices.
Gamma
Adjuststhe primarycolor intensity.
ExpertPattern
Displayspicturecalibrationpatternson thescreenwithout usingaseparatepatterngeneratoror
filter.Pattern1isusedto calibratethe contrast,andPattern2isusedfor calibratingthecolor and
color saturation.If the screenmenudisappearsoradifferent menuisactivatedwhile thescreen
is beingcalibrated,this option will savethechangesup to that pointandautomaticallydeactivate
that menu.Thisfeatureis enabledin ComponentandHDMImodesonly. _1:ii::::,:!:_j'
• Motion Lighting
Adjuststhe picturebrightnessdependingonthe on-screenmovementsfor reducedpower
consumption.Thisfeatureisonly availablewhenPictureModeissetto Standardandisnot
availablein 3Dmode.Inaddition,adjustingContrastor Brightnessautomaticallydeactivatesthis
feature.
