Samsung H32B User manual

User Manual
H32B H40B
The colour and the appearance may differ depending on
the product, and the specifications are subject to
change without prior notice to improve the performance.
BN46-00281B-02

Table Of Contents 1
Table Of Contents
BEFORE USING THE
PRODUCT
7 Copyright
8 Important Warranty Information Regarding
Television Format Viewing
9 Cleaning
9Storage
10 Safety Precautions
10 Symbols
11 Electricity and Safety
12 Installation
14 Operation
PREPARATIONS 19 Checking the Contents
19 Removing the Packaging
20 Checking the Components
22 Parts
22 Control Panel
24 Reverse Side
25 Anti-theft Lock
26 Remote Control
29 Teletext Feature
31 Before Installing the Product (Installation
Guide)
31 Tilting Angle and Rotation
32 Ventilation
33 Dimensions
34 Installing the Wall Mount
34 Installing the Wall Mount KIT
34 Wall Mount KIT Specifications (VESA)
36 RS232C Connection
36 Cable Connection
CONNECTING AND USING
A SOURCE DEVICE
46 Before Connecting
46 Pre-connection Checkpoints

Table Of Contents
Table Of Contents 2
47 Connecting and Using a PC
47 Connecting to a PC
49 Changing the Resolution
51 Connecting to a Video Device
51 Connection Using the Video Cable
51 Connection Using the Component Cable
52 Connection Using an HDMI Cable
53 Connecting to an Ext.
53 Connecting to an Antenna
54 Connecting to a COMMON INTERFACE
slot
54 Using the “CI or CI+ CARD”
55 Changing the Input source
55 Source
SCREEN ADJUSTMENT 56 Picture Mode
56 If the input source is PC
57 If the input source is AV, Component, HDMI or
TV
57 Backlight / Contrast / Brightness /
Sharpness / Colour / Tint (G/R)
58 Screen Adjustment
58 Picture Size
59 Position
60 Zoom/Position
60 4:3 Screen Size
60 PC Screen Adjustment
60 Auto Adjustment

Table Of Contents
Table Of Contents 3
61 Advanced Settings
61 Dynamic Contrast
61 Black Tone
61 Flesh Tone
61 RGB Only Mode
62 Colour Space
62 White Balance
62 Gamma
62 Motion Lighting (Off / On)
63 Picture Options
63 Colour Tone
64 Digital Noise Filter
64 MPEG Noise Filter
64 HDMI Black Level
64 Film Mode
64 LED Motion Plus (Off / On) - (H40B Model
Only)
65 Reset Picture
SOUND ADJUSTMENT 66 Sound Mode
67 Sound Effect
67 Broadcast Audio Options
68 Additional Settings
69 Speaker Settings
69 Reset Sound
USING THE CHANNEL
MENU
70 Channel
70 Aerial
70 Country
71 Auto Tuning
72 Manual Tuning
72 Transfer Channel List
72 Fine Tune

Table Of Contents
Table Of Contents 4
SYSTEM 73 Setup
74 Time
74 Clock
74 Sleep Timer
74 On Timer
76 Off Timer
76 Language
77 Eco Solution
77 Energy Saving
77 No Signal Power Off
77 Auto Power Off (Off / On)
78 Subtitle
78 Subtitle
78 Subtitle Mode
78 Subtitle Language
78 Digital Text
79 Security
79 Channel Lock (Off / On)
79 Programme Rating Lock
79 Change PIN
80 PIP
81 Auto Protection Time
81 General
81 Game Mode
81 Panel Lock
82 Boot Logo
82 Anynet+(HDMI-CEC)
82 Anynet+(HDMI-CEC)
83 Auto Turn Off (No / Yes)
84 Receiver
85 DivX® Video On Demand
86 Common Interface

Table Of Contents
Table Of Contents 5
SUPPORT 87 Self Diagnosis
87 Picture Test (Yes / No)
87 Sound Test (Yes / No)
87 Signal Information
87 Reset
88 Software Update
88 By USB
89 Alternative Software
89 Contact Samsung
90 Contents Home
90 Channel List
93 Guide
94 Media Play
104 Schedule Manager
105 Source
TROUBLESHOOTING
GUIDE
107 Requirements Before Contacting
Samsung Customer Service centre
107 Testing the Product
107 Checking the Resolution and Frequency
108 Check the followings.
111 Q & A
SPECIFICATIONS 113 General
114 PowerSaver
115 Preset Timing Modes
117 Licence
APPENDIX 118 Contact SAMSUNG WORLDWIDE

Table Of Contents
Table Of Contents 6
120 Responsibility for the Pay Service (Cost
to Customers)
120 Not a product defect
120 A Product damage caused by customer's fault
120 Others
121 Optimum Picture Quality and Afterimage
Burn-in Prevention
121 Optimum Picture Quality
122 Prevention of Afterimage Burn-in
124 Correct Disposal of This Product (Waste
Electrical & Electronic Equipment)
124 Correct Disposal of batteries in this
product
125 Terminology
INDEX

7
Before Using the Product
Before Using the Product
Copyright
The contents of this manual are subject to change without notice to improve quality.
2012 Samsung Electronics
Samsung Electronics owns the copyright for this manual.
Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is
prohibited.
The SAMSUNG and SyncMaster logos are registered trademarks of Samsung Electronics.
Microsoft, and Windows are registered trademarks of Microsoft Corporation.
VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.
Ownership of all other trademarks is attributed to their due owner.
zAn administration fee may be charged if either
(a) an engineer is called out at your request and there is no defect in the product
(i.e. where you have failed to read this user manual).
(b) you bring the unit to a repair centre and there is no defect in the product
(i.e. where you have failed to read this user manual).
zThe amount of such administration charge will be advised to you before any work or home visit is
carried out.
©

8
Before Using the Product
Before Using the Product
Important Warranty Information Regarding Television Format Viewing
1Functionalities related to Digital TV (DVB) are only available in countries/areas where DVB-T (MPEG2
and MPEG4 AVC) digital terrestrial signals are broadcasted or where you are able to access to a
compatible DVB-C (MPEG2 and MPEG4 AAC) cable-TV service. Please check with your local dealer
the possibility to receive DVB-T or DVB-C signal.
2DVB-T is the DVB European consortium standard for the broadcast transmission of digital terrestrial
television and DVB-C is that for the broadcast transmission of digital TV over cable. However, some
differentiated features like EPG (Electric Programme Guide), VOD (Video On Demand) and so on, are
not included in this specification. So, they cannot be workable at this moment.
3Although this product meets the latest DVB-T and DVB-C standards, as of [August, 2008], the
compatibility with future DVB-T digital terrestrial and DVB-C digital cable broadcasts cannot be
guaranteed.
4Depending on the countries/areas where this product is used, some cable-TV providers may charge
an additional fee for such a service and you may be required to agree to terms and conditions of
their business.
5Some Digital TV functions might be unavailable in some countries or regions and DVB-C might not
work correctly with some cable service providers.
6For more information, please contact your local Samsung customer care centre.
The reception quality of this product may be affected due to differences in broadcasting method
between the countries. Please check the product performance in the local SAMSUNG Authorized
Dealer, or the Samsung Call Centre whether it can be improved by reconfiguring product setting or
not.

9
Before Using the Product
Before Using the Product
Cleaning
Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.
Take the following steps when cleaning.
The following images are for reference only. Real-life situations may differ from what is shown in the
images.
Storage
High-glossy models can develop white stains on the surface if an ultrasonic wave humidifier is used
nearby.
Contact Customer Service Centre if the inside of the product needs cleaning (service fee will be
charged).
1. Power off the product and computer.
2. Disconnect the power cord from the product.
Hold the power cable by the plug and do not touch the cable with wet
hands. Otherwise, an electric shock may result.
3. Wipe the product with a clean, soft and dry cloth.
zDo not use detergents that contain alcohol, solvent or
surface-active agents.
zDo not spray water or detergent directly on the product.
4. Wet a soft and dry cloth in water and wring thoroughly to clean the exterior
of the product.
5. Connect the power cord to the product when cleaning is finished.
6. Power on the product and computer.
!

10
Before Using the Product
Before Using the Product
Safety Precautions
Symbols
Caution
RISK OF ELECTRIC SHOCK DO NOT OPEN
Caution : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR
BACK).
THERE ARE NO USER SERVICEABLE PARTS INSIDE.
REFER ALL SERVICING TO QUALIFIED PERSONNEL.
This symbol indicates that high voltage is present inside.
It is dangerous to make any kind of contact with any internal part of this
product.
This symbol alerts you that important literature concerning operation and
maintenance has been included with this product.
Warning A serious or fatal injury may result if instructions are not followed.
Caution
Personal injury or damage to properties may result if instructions are
not followed.
Activities marked by this symbol are prohibited.
Instructions marked by this symbol must be followed.

11
Before Using the Product
Before Using the Product
Electricity and Safety
The following images are for reference only. Real-life situations may differ from what is shown in the
images.
Warning
Do not use a damaged power cord or plug, or a loose power socket.
zAn electric shock or fire may result.
Do not use multiple products with a single power socket.
zOverheated power sockets may cause a fire.
Do not touch the power plug with wet hands. Otherwise, an electric shock may
result.
Insert the power plug all the way in so it is not loose.
zAn unsecure connection may cause a fire.
Connect the power plug to a grounded power socket (type 1 insulated devices
only).
zAn electric shock or injury may result.
Do not bend or pull the power cord with force. Be careful not to leave the power
cord under a heavy object.
zDamage to the cord may result in a fire or electric shock.
Do not place the power cord or product near heat sources.
zA fire or electric shock may result.
Clean any dust around the pins of the power plug or the power socket with a dry
cloth.
zA fire may result.
!
!
!

12
Before Using the Product
Before Using the Product
Caution
Installation
Warning
Do not disconnect the power cord while the product is being used.
zThe product may become damaged by an electric shock.
Only use the power cord provided with your product by Samsung. Do not use the
power cord with other products.
zA fire or electric shock may result.
Keep the power socket where the power cord is connected unobstructed.
zThe power cord must be disconnected to cut off power to the product when
an issue occurs.
zNote that the product is not completely powered down by using only the
power button on the remote.
Hold the plug when disconnecting the power cord from the power socket.
zAn electric shock or fire may result.
DO NOT PLACE CANDLES, INSECT REPELLANTS OR CIGARETTES ON TOP
OF THE PRODUCT. DO NOT INSTALL THE PRODUCT NEAR HEAT SOURCES.
zA fire may result.
Have a technician install the wall-mount hanger.
zInstallation by an unqualified person can result in an injury.
zOnly use approved cabinets.
Do not install the product in poorly ventilated spaces such as a bookcase or
closet.
zAn increased internal temperature may cause a fire.
Install the product at least 10cm away from the wall to allow ventilation.
zAn increased internal temperature may cause a fire.
!
!
!
!
!

13
Before Using the Product
Before Using the Product
Keep the plastic packaging out of the reach of children.
zChildren may suffocate.
Do not install the product on an unstable or vibrating surface (insecure shelf,
sloped surface, etc.)
zThe product may fall and become damaged and/or cause an injury.
zUsing the product in an area with excess vibration may damage the product
or cause a fire.
Do not install the product in a vehicle or a place exposed to dust, moisture (water
drips, etc.), oil, or smoke.
zA fire or electric shock may result.
Do not expose the product to direct sunlight, heat, or a hot object such as a
stove.
zThe product lifespan may be reduced or a fire may result.
Do not install the product within the reach of young children.
zThe product may fall and injure children.
zAs the front is heavy, install the product on a flat and stable surface.
Bend and keep part of the outdoor TV antenna cable hanging downwards (the
part inside the room) to prevent rainwater from entering the product.
zIf rainwater enters the product, a fire or electric shock can occur.
When using an outdoor antenna, be sure to install the antenna away from nearby
power lines to prevent the antenna from collapsing onto them in strong winds.
zA collapsed antenna can cause an electric shock or injury.
Edible oil, such as soybean oil, can damage or deform the product. Do not install
the product in a kitchen or near a kitchen counter.
!
!
!
!

14
Before Using the Product
Before Using the Product
Caution
Operation
Warning
Do not drop the product while moving.
zProduct failure or personal injury may result.
Do not set down the product on its front.
zThe screen may become damaged.
When installing the product on a cabinet or shelf, make sure that the bottom
edge of the front of the product is not protruding.
zThe product may fall and become damaged and/or cause an injury.
zInstall the product only on cabinets or shelves of the right size.
Set down the product gently
zProduct failure or personal injury may result.
Installing the product in an unusual place (a place exposed to a lot of fine
particles, chemical substances or extreme temperatures, or an airport or train
station where the product should operate continuously for an extended period of
time) may seriously affect its performance.
zBe sure to consult Samsung Customer Service Centre if you want to install
the product at such a place.
There is a high voltage inside the product. Never disassemble, repair or modify
the product yourself.
zA fire or electric shock may result.
zContact Samsung Customer Service Centre for repairs.
Before moving the product, turn off the power switch and disconnect the power
cable and all other connected cables.
zDamage to the cord may result in a fire or electric shock.
!
!
SAMSUNG
!
!

15
Before Using the Product
Before Using the Product
If the product generates abnormal sounds, a burning smell or smoke, disconnect
the power cord immediately and contact Samsung Customer Service Centre.
zAn electric shock or fire may result.
Do not let children hang from the product or climb on top of it.
zChildren may become injured or seriously harmed.
If the product is dropped or the outer case is damaged, turn off the power switch
and disconnect the power cord. Then contact Samsung Customer Service
Centre.
zContinued use can result in a fire or electric shock.
Do not leave heavy objects or items that children like (toys, sweets, etc.) on top of
the product.
zThe product or heavy objects may fall as children try to reach for the toys or
sweets resulting in a serious injury.
During a lightning or thunderstorm, power off the product and remove the power
cable.
zA fire or electric shock may result.
Do not drop objects on the product or apply impact.
zA fire or electric shock may result.
Do not move the product by pulling the power cord or any cable.
zProduct failure, an electric shock or fire may result from a damaged cable.
If a gas leakage is found, do not touch the product or power plug. Also, ventilate
the area immediately.
zSparks can cause an explosion or fire.
Do not lift or move the product by pulling the power cord or any cable.
zProduct failure, an electric shock or fire may result from a damaged cable.
Do not use or keep combustible spray or an inflammable substance near the
product.
zAn explosion or fire may result.
!
!
!
!
GAS
!

16
Before Using the Product
Before Using the Product
Caution
Ensure the vents are not blocked by tablecloths or curtains.
zAn increased internal temperature may cause a fire.
Do not insert metallic objects (chopsticks, coins, hairpins, etc) or objects that
burn easily (paper, matches, etc) into the product (via the vent or input/output
ports, etc).
zBe sure to power off the product and disconnect the power cord when water
or other foreign substances have entered the product. Then contact
Samsung Customer Service Centre.
zProduct failure, an electric shock or fire may result.
Do not place objects containing liquid (vases, pots, bottles, etc) or metallic
objects on top of the product.
zBe sure to power off the product and disconnect the power cord when water
or other foreign substances have entered the product. Then contact
Samsung Customer Service Centre.
zProduct failure, an electric shock or fire may result.
Leaving the screen fixed on a stationary image for an extended period of time
may cause afterimage burn-in or defective pixels.
zActivate power-saving mode or a moving-picture screen saver if you will not
be using the product for an extended period of time.
Disconnect the power cord from the power socket if you do not plan on using the
product for an extended period of time (vacation, etc).
zDust accumulation combined with heat can cause a fire, electric shock or
electric leakage.
Use the product at the recommended resolution and frequency.
zYour eyesight may deteriorate.
Do not hold the product upside-down or move it by holding the stand.
zThe product may fall and become damaged or cause an injury.
100
!
!
-_-
!
!

17
Before Using the Product
Before Using the Product
Looking at the screen too close for an extended period of time can deteriorate
your eyesight.
Do not use humidifiers or stoves around the product.
zA fire or electric shock may result.
Rest your eyes for more than 5 minutes for every 1 hour of product use.
zEye fatigue will be relieved.
Do not touch the screen when the product has been turned on for an extended
period of time as it will become hot.
Store small accessories out of the reach of children.
Exercise caution when adjusting the product angle or stand height.
zYour hand or finger may get stuck and injured.
zTilting the product at an excessive angle may cause the product to fall and
an injury may result.
Do not place heavy objects on the product.
zProduct failure or personal injury may result.
When using headphones or earphones, do not turn the volume too high.
zHaving the sound too loud may damage your hearing.
Be careful that children do not place the battery in their mouths when removed
from the remote control. Place the battery in a location that children or infants
cannot reach.
zIf children have had the battery in their mouths, consult your doctor
immediately.
When replacing the battery, insert it with the right polarity (+, -).
zOtherwise, the battery may become damaged or it may cause fire, personal
injury or damage due to leakage of the internal liquid.
!
!
!
!
!

18
Before Using the Product
Before Using the Product
Use only the specified standardized batteries, and do not use a new battery and
a used battery at the same time.
zOtherwise, the batteries may be damaged or cause fire, personal injury or
damage due to a leakage of the internal liquid.
The batteries (and rechargeable batteries) are not ordinary refuse and must be
returned for recycling purposes. The customer is responsible for returning the
used or rechargeable batteries for recycling.
zThe customer can return used or rechargeable batteries to a nearby public
recycling Centre or to a store selling the same type of the battery or
rechargeable battery.
!

19
1 Preparations
1 Preparations
1.1 Checking the Contents
1.1.1 Removing the Packaging
1Open the packaging box. Be careful not to damage the product when you open the packaging with
a sharp instrument.
2Remove the styrofoam from the product.
3Check the components and remove the styrofoam and plastic bag.
zThe appearance of actual components may differ from the image shown.
zThis image is for reference only.
4Store the box in a dry area so that it can be used when moving the product in the future.
