Samsung SP-42Q2 User manual

COLOR
TELEVISION
SP42Q2
SP43W6
SP43T7
SP43T8/54T8
Owner’s Instructions
Before operating the unit,
please read this manual thoroughly,
and retain it for future reference.
ON-SCREEN MENUS
TELETEXT
SELF FOCUS
BP68-00303A(J60A_Asia_ENG) 5/4/04 5:24 PM Page 1

BP68-00303A(J60A_Asia_ENG) 5/4/04 5:24 PM Page 2

3
ENG
Important Warranty Information Regarding Television
Format Viewing
Standard screen format televisions (4:3, the aspect ratio of the screen width to height) are
primarily designed to view standard format full-motion video. The images displayed on them
should primarily be in the standard 4:3 ratio format and constantly moving. Displaying stationary
graphics and images on screen, such as the dark top and bottom letterbox bars (wide screen
pictures), should be limited to no more than 15% of the total television viewing per week.
Wide screen format televisions (16:9, the aspect ratio of the screen width to height) are
primarily designed to view wide screen format full-motion video. The images displayed on them
should primarily be in the wide screen 16:9 ratio format, or expanded to fill the screen if your
model offers this feature, and constantly moving. Displaying stationary graphics and images on
screen, such as the dark side-bars on non-expanded standard format television video and
programming, should be limited to no more than 15% of the total television viewing per week.
Additionally, viewing other stationary images and text such as stock market reports, video
game displays, station logos, web sites or computer graphics and patterns, should be limited as
described above for all televisions. Displaying any stationary images that exceed the above
guidelines can cause uneven aging of picture tubes (CRTs) that leave subtle, but permanent
burned-in ghost images in the television picture. To avoid this, vary the programming and
images, and primarily display full screen moving images, not stationary patterns or dark bars.
On television models that offer picture sizing features, use these controls to view the different
formats as a full screen picture.
Be careful in the selection and duration of television formats used for viewing. Uneven CRT
aging as a result of format selection and use, as well as other burned-in images, is not covered by
your Samsung limited warranty.
BP68-00303A(J60A_Asia_ENG) 5/4/04 5:24 PM Page 3

4
ENG
Contents
◆FOREWORD
■Important Warranty Information Regarding Television Format Viewing ........ 3
◆CONNECTING AND PREPARING YOUR TELEVISION
■Control Panels (depending on the model)..................................................... 6
■Connection Panels (depending on the model) .............................................. 7
■Using a Display Deck (depending on the model) .......................................... 8
■Inserting the Batteries in the Remote Control................................................ 8
■Infrared Remote Control ................................................................................ 9
■Connecting to an Aerial or Cable Television Network ................................... 10
■Connecting a Satellite Receiver or Decoder.................................................. 11
■Switching Your Television On and Off........................................................... 12
■Placing Your Television in Standby Mode..................................................... 12
■Becoming Familiar with the Remote Control ................................................. 13
■Plug and Play Feature................................................................................... 14~15
■Displaying Information ................................................................................... 15
■Choosing Your Language.............................................................................. 16
■Adjusting the Screen Automatically (Self Focus)........................................... 17
■Deactivating the Automatic Execution of the Self Focus............................... 18
■Removing the “Self Focus” from the Display ................................................. 19
◆SETTING THE CHANNELS
■Storing Channels Automatically..................................................................... 20
■Sorting the Stored Channels ......................................................................... 21
■Storing Channels Manually............................................................................ 22~23
■Skipping Unwanted Channels ....................................................................... 24
■Fine Tuning Channel Reception.................................................................... 25
◆USING YOUR TELEVISION
■Using the LNA (Low Noise Amplifier) Feature............................................... 26
■Changing the Picture Standard ..................................................................... 27
■Customizing the Picture Settings................................................................... 28
■Selecting the Picture Size (4:3 Model) .......................................................... 29
■Selecting the Picture Size (Wide Model) ....................................................... 30~31
■Selecting the Scan Mode............................................................................... 32
■Using the Digital NR (Digital Noise Reduction) Feature ................................ 32
■Locking the Channel...................................................................................... 33
■Setting the Blue Screen Mode....................................................................... 34
■Freezing the Current Picture ......................................................................... 34
■Changing the Sound Standard ...................................................................... 35
■Adjusting the Sound Settings ........................................................................ 36
BP68-00303A(J60A_Asia_ENG) 5/4/04 5:24 PM Page 4

5
ENG
Contents (continued)
◆USING YOUR TELEVISION (continued)
■Extra Sound Settings..................................................................................... 37
-AUTO VOLUME
-VIRTUAL SURROUND
■Setting the Melody Sound ............................................................................. 38
■Selecting the Sound Mode (depending on the model) .................................. 39
■Setting and Displaying the Current Time....................................................... 40
■Setting the Sleep Timer ................................................................................. 41
■Switching the Television On and Off Automatically ....................................... 42
■Viewing an External Signal Source ............................................................... 43
◆USING THE TELETEXT FEATURE
■Teletext Feature ............................................................................................ 44
■Displaying the Teletext Information ............................................................... 45
■Selecting Display Options.............................................................................. 46
■Selecting a Teletext Page.............................................................................. 47
■Storing Teletext Pages (depending on the model) ........................................ 48
◆ADDITIONAL INFORMATION ON CONNECTIONS
■Connecting to the External Devices .............................................................. 49
■Connecting to the Audio Outputs................................................................... 50
■Connecting to the S-Video Input.................................................................... 51
■Connecting to the Component Input.............................................................. 52
◆RECOMMENDATIONS FOR USE
■Programming the Remote Control for Other Components ............................ 53~54
-VCR Remote Control Codes ...................................................................... 54
-Cable Box (CATV) Remote Control Codes ................................................ 54
-DVD Remote Control Codes ...................................................................... 54
■Troubleshooting: Before Contacting Service Personnel................................ 55
☛➢
Press Important Note
Symbols
BP68-00303A(J60A_Asia_ENG) 5/4/04 5:24 PM Page 5

6
ENG
Control Panels (depending on the model)
➢The actual configuration on your TV may be different, depending on
your model.
( a ) Switch among video input modes
( b ) Display the on-screen menu
( c ) Select the channels
( d ) Adjust the volume
( e ) Switch the TV on and off
( f ) Standby & Timer indicator
( g ) Remote control sensor
( h ) Access to the selected option on the
menu system
( i ) Place the TV in standby mode
SP43T8
SP54T8
SP43T7
SP43W6
SP42Q2
➢◆You can use the CH buttons to switch on the TV when it is in standby mode depending on
the model.
◆The -
VOL +and CH buttons have the same function as the ▲/▼/œ/√buttons
on the remote control.
◆If the remote control no longer works or your have lost it, you can use controls on the panel of the TV.
BP68-00303A(J60A_Asia_ENG) 5/4/04 5:24 PM Page 6

7
ENG
Connection Panels (depending on the model)
➢The actual configuration on your TV may be different, depending on
your model.
Side of the TV
( a ) Video Input
( b ) Audio Input
( c ) S-Video Input
➢For further details about connection, refer to pages 49~52.
☛Whenever you connect an audio or video system to your television, ensure that all elements are
switched off. Refer to the documentation supplied with your equipment for detailed connection
instructions and associated safety precautions.
Rear of the TV
d
ab
c
( a ) ANT IN VHF/UHF (75Ω)
( b ) AV INPUT
(VIDEO/L-AUDIO-R)-1, 2
( c ) AV OUTPUT
(VIDEO / L-AUDIO-R)
( d ) COMPONENT
VIDEO/AUDIO INPUT
.
BP68-00303A(J60A_Asia_ENG) 5/4/04 5:24 PM Page 7

8
ENG
Using a Display Deck (depending on the model)
You can display a VCR or DVD Player, etc. by using the display
deck.
SP54T8
1Hold the center of the door and lift it up in the direction of arrow.
2After placing a component you have in the display deck, hold the
center of the door and pull it down.
➢
You should display only the component that is within
126mm high. When displaying a component in the
display deck, please space it out 30mm from the front,
20mm from either end.
SP43W6
Inserting the Batteries in the Remote Control
You must insert or replace the batteries in the remote control when
you:
◆Purchase the television
◆Find that the remote control is no longer operating
correctly
1Remove the cover on the rear of the remote control by pressing
the symbol ( ) downwards and then pulling firmly to remove it.
2Insert two R03, UM4, “AAA” 1.5V or equivalent batteries taking
care to respect the polarities:
◆ + on the battery against + on the remote control
◆ - on the battery against - on the remote control
3Replace the cover by aligning it with the base of the remote
control and pressing it back into place.
SP54T8
BP68-00303A(J60A_Asia_ENG) 5/4/04 5:24 PM Page 8

9
ENG
Infrared Remote Control
➢The performance of the remote control may be affected by bright light.
DIRECT CHANNEL SELECTION
MENU DISPLAY/
TELETEXT INDEX
CONTROL THE CURSOR
IN THE ON-SCREEN MENU
SURROUND ON/OFF DIRECTLY
TELEVISION STANDBY
FASTEXT TOPIC SELECTION
AUTOMATIC SWITCH-OFF
TELETEXT PAGE HOLD
INFORMATION DISPLAY/
TELETEXT REVEAL
EXIT FROM ANY DISPLAY
ONE OR TWO-DIGIT CHANNEL
SELECTION/
TELETEXT STORE
SELF FOCUS
PICTURE FREEZE
TELETEXT SUB-PAGE
TELETEXT CANCEL
EXTERNAL INPUT SELECTION/
TELETEXT MODE (LIST/FLOF)
SELECTION
SWITCH REPEATEDLY BETWEEN THE
LAST TWO CHANNELS DISPLAYED
CONFIRM YOUR CHOICE
(STORE OR ENTER)
NEXT CHANNEL/
TELETEXT NEXT PAGE
PICTURE EFFECT SELECTION
IF YOUR REMOTE CONTROL IS
NOT FUNCTIONING PROPERLY,
TAKE OUT THE BATTERIES AND
PRESS THE RESET BUTTON FOR
ABOUT 2~3 SECONDS. RE-INSERT
THE BATTERIES AND TRY USING
THE REMOTE CONTROL AGAIN.
SOUND MODE SELECTION
PREVIOUS CHANNEL/
TELETEXT PREVIOUS PAGE
MAKE THE REMOTE CONTROL WORKS
FOR TV, STB, VCR, CABLE, DVD
PLAYER
TUNER/CABLE NETWORK
SELECTION
VOLUME INCREASE
TEMPORARY SOUND SWITCH-OFF
VOLUME DECREASE
TELETEXT DISPLAY/
MIX BOTH TELETEXT INFORMATION
AND THE NORMAL BROADCAST
SOUND EFFECT SELECTIOND
PICTURE SIZE/
TELETEXT SIZE SELECTION
VCR/DVD FUNCTIONS;
-REWIND ( )
-STOP ( )
-PLAY/PAUSE ( )
-FAST FORWARD ( )
REMOTE CONTROL SETUP
BP68-00303A(J60A_Asia_ENG) 5/4/04 5:24 PM Page 9

10
ENG
To view television channels correctly, a signal must be received by
the set from one of the following sources:
◆An outdoor aerial
◆A cable television network
◆A satellite network
1In the first three cases, connect the aerial or network input cable to
the 75Ωcoaxial socket on the rear of the television.
2If you are using an indoor aerial, you may need to turn it when
tuning your television until you obtain a picture that is both sharp
and clear.
For further details, refer to:
◆“Storing Channels Automatically” on page 20
◆“Storing Channels Manually” on page 22.
Connecting to an Aerial or Cable Television Network
Rear of the TV
Cable Television
Network
or
BP68-00303A(J60A_Asia_ENG) 5/4/04 5:24 PM Page 10

11
ENG
Connecting a Satellite Receiver or Decoder
In order to watch television programmes broadcast via a satellite
network, you must connect a satellite receiver to the rear of TV.
Also, in order to descramble a coded transmission signal, you must
connect a decoder to the rear of TV.
Using a Coaxial cable
Connect a coaxial cable to the:
◆Receiver (or Decoder) output socket.
◆Television aerial input socket.
➢If you wish to connect both a satellite receiver (or decoder)
and a VCR, you should connect the:
◆Receiver (or Decoder) to the VCR
◆VCR to the television
Otherwise, connect the receiver (or decoder) directly to the
television.
Rear of the TV
Satellite receiver/
Decoder
BP68-00303A(J60A_Asia_ENG) 5/4/04 5:24 PM Page 11

12
ENG
The mains lead is attached to the rear of your television.
1Plug the mains lead into an appropriate socket.
➢
The main voltage is indicated on the rear of the television
and the frequency is 50 or 60Hz.
2Press the “ I” button (On/Off) on the front or side of the television.
Result:The Standby indicator on the front of the television
lights up.
3Press the POWER ()button on the remote control to switch the
television on.
Result:The programme that you were watching last is re-
selected automatically.
➢
If you have not yet stored any channels, No clear picture
appears. Refer to “Storing Channels Automatically” on page
20 or “Storing Channels Manually” on page 22.
4To switch your television off, press the “ I” button (On/Off) again.
Placing Your Television in Standby Mode
Your television can be placed in Standby mode, in order to reduce
the power consumption.
The Standby mode can be useful when you wish to interrupt
viewing temporarily (during a meal, for example).
1Press the POWER ()button on the remote control.
Result:The screen is turned off and the Standby indicator on
the front of the television lights up in red.
2To switch the television back on, simply press the POWER ()
button again.
➢
You can also switch on by pressing the TV ()or P /
button.
☛Do not leave your television in Standby mode for long
periods of time (when you are away on holiday, for
example). Turn your television off by pressing the “ I”
button (On/Off) on the front or side of the television. It is
best to unplug the set from the mains and aerial.
Switching Your Television On and Off
BP68-00303A(J60A_Asia_ENG) 5/4/04 5:24 PM Page 12

13
ENG
Becoming Familiar with the Remote Control
The remote control is used mainly to:
◆Change channels and adjust the volume
◆Set up the television using the on-screen menu system
The following table presents the most frequently used buttons and
their functions.
Button Viewing Function Menu Function
Used to display the next -
stored channel.
Used to display the
-
previous stored channel.
to Used to display the corresponding channels.
➢For double digit channels, the second digit must be
pushed immediately after the first. Failure to do this will
result in a single digit channel being displayed.
-/-- Used to select a channel numbered ten or over.
Press this button, and the “
-- ” symbol is displayed.
Enter the two-digit channel number.
PRE-CH Press the PRE-CH button. The TV will switch to the last
() channel viewed.
To quickly switch between two channels that are far apart,
tune to one channel, then use the numeric buttons to select
second channel. Then, use the PRE-CH button to quickly
alternate between them.
Used to increase the -
volume.
Used to decrease the
-
volume.
MUTE Used to switch the sound off temporarily.
() ➢To turn the sound back on, press this button again, or
press the or button.
MENU Used to display the Used to return to the previous
() on-screen menu system. menu or normal viewing.
- Used to:
◆Display a submenu
containing selections for
the current menu option.
◆Increase/decrease a
menu option value.
- Used to confirm your choice.
TV Used to switch the Used to exit from the menu
() television on when it is system and return to normal
in Standby mode. viewing directly.
EXIT - Used to exit from the any
() display.
BP68-00303A(J60A_Asia_ENG) 5/4/04 5:24 PM Page 13

14
ENG
Plug and Play Feature
RETURN
SEARCH
P 1 C--
106 MHZ 0 %
When the television is initially powered ON, several basic customer
settings proceed automatically and subsequently. The following
settings are available.
1If the television is in Standby mode, press the POWER ()
button on the remote control.
Result:The message PLUG & PLAY is displayed. It flickers for
a little while and then LANGUAGE menu is automatically
displayed.
2Select the appropriate language by pressing the ▼or ▲button.
Press the MENU ()button to enter the language.
Result:The message ANT. INPUT : CHECK is displayed.
➢If any language is not selected on the LANGUAGE menu, the
LANGUAGE menu will disappear about 30 seconds later.
3Make sure that the antenna is connected to the TV, and then
press the œor √button.
Result:The AUTO STORE menu is displayed with AREA is
selected
4Select your area by pressing the ▲or ▼button. Press the ENTER
()button to confirm your choice.
Result:The AUTO STORE menu is displayed again.
5To search the channels, select SEARCH by pressing the ▼or ▲
button, and then press the œor √ button. To stop the search
before it has finished or return to normal viewing, press the MENU
()button.
Result:The options available in the TIME group are displayed
with CLOCK is selected.
➢Refer to “Storing Channels Automatically” on page 20.
6Press the ENTER ()button.
7Press the œor √button to move to the hour or minute.
Set the hour or minute by pressing the ▲or ▼button.
➢Refer to “Setting and Displaying the Current Time” on page
40.
8When you have finished, press the MENU ()button.
Result:The message ENJOY YOUR WATCHING is displayed,
and then the channel which has been stored will be
activated.
PLUG & PLAY
ENJOY YOUR WATCHING
LANGUAGE
ENGLISH
TV AUTO STORE
AREA : CHINA
SEARCH : -/+
SELECT ENTER
MOVE ENTER RETURN
ANT. INPUT : CHECK
œœ√√
SELECT RETURN
ASIA W/EUROPE
CIS E/EUROPE
CHINA
HONKONG U/K
AUSTRALIA
††
MORE
TV CLOCK
ADJUST
œœ√√
MOVE RETURN
CLOCK
11 :00AM
BP68-00303A(J60A_Asia_ENG) 5/4/04 5:24 PM Page 14

15
ENG
If you want to reset this feature...
1Press the MENU ()button.
Result:The main menu is displayed.
2Press the ▲or ▼button until the SETUP is selected.
Result:The options available in the SETUP group are displayed.
3Press the ENTER ()button.
4Press the ▲or ▼button until the PLUG & PLAY option is selected.
Press the ENTER ()button.
Result:This feature starts with the message PLUG & PLAY is
displayed.
5For further details on how to set, refer to the opposite page.
Plug and Play Feature (continued)
TV SETUP
TIME √√
PLUG & PLAY √√
LANGUAGE : ENGLISH √√
SELF FOCUS √√
BLUE SCREEN : OFF √√
▼ MORE
MOVE ENTER RETURN
You can view the channel information and setting status you select
by pressing the “INFO ( )” button on the remote control.
Displaying Information
P 1
Mono
Picture : Dynamic
Sound : Standard
Time : -- : -- am
BP68-00303A(J60A_Asia_ENG) 5/4/04 5:24 PM Page 15

16
ENG
Choosing Your Language
When you start using your television for the first time, you must
select the language which will be used for displaying menus and
indications.
1Press the MENU ()button.
Result:The main menu is displayed.
2Press the ▲or ▼button until the SETUP is selected.
Result:The options available in the SETUP group are displayed.
3Press the ENTER ()button.
4Press the ▲or ▼button until the LANGUAGE is selected.
Select your language by pressing the ENTER ()button.
TV SETUP
TIME √√
PLUG & PLAY √√
LANGUAGE : ENGLISH √√
SELF FOCUS √√
BLUE SCREEN : OFF √√
▼ MORE
MOVE ENTER RETURN
BP68-00303A(J60A_Asia_ENG) 5/4/04 5:24 PM Page 16

17
ENG
The “Self Focus” feature automatically finds the optimum picture
quality when blurring, overlapping colors or incorrect focus occurs.
These conditions may be caused by moving your TV.
1Press the MENU ()button.
Result:The main menu is displayed.
2Press the ▲or ▼button until the SETUP is selected.
Result:The options available in the SETUP group are displayed.
3Press the ENTER ()button.
4Press the ▲or ▼button until the SELF FOCUS is selected.
Press the ENTER ()button.
Result:The SELF FOCUS is selected.
5Press the ENTER ()button again
Result:The self focus process begins with the message SELF
FOCUS and horizontal bar is displayed. During the
process, minor distortions of the picture may occur. At
this time, the colors may diffuse and a searching action
will appear on the edges of the screen. This is a normal
part of the adjustment. When it is finished, all of things
will disappear and the optimum picture quality can be
enjoyed.
➢You can also set these options simply by pressing the
SELF FOCUS button.
➢
◆Changing channels and any other signal changes will
pause the self focus until a stable signal has returned.
It resumes after the signal has been stabilised. This
feature will not work without a signal.
◆Ambient light that is too bright may affect the self focus.
If this occurs, darken the environment and try again.
Adjusting the Screen Automatically (Self Focus)
SELF FOCUS
TV SETUP
TIME √√
PLUG & PLAY √√
LANGUAGE : ENGLISH √√
SELF FOCUS √√
BLUE SCREEN : OFF √√
▼ MORE
MOVE ENTER RETURN
TV SELF FOCUS
SELF FOCUS √√
AUTO : ON √√
MESSAGE : ON √√
MOVE ENTER RETURN
BP68-00303A(J60A_Asia_ENG) 5/4/04 5:24 PM Page 17

18
ENG
The “Self Focus” feature starts on default. It will automatically
begin 1 minutes after switching on the power and the appearance of
the screen image. To set the optimum picture quality, the
“Self Focus” will automatically begin again after another 10
minutes, as the screen image is then fully stabilised.
1Press the MENU ()button.
Result:The main menu is displayed.
2Press the ▲or ▼button until the SETUP is selected.
Result:The options available in the SETUP group are displayed.
3Press the ENTER ()button.
4Press the ▲or ▼button until the SELF FOCUS is selected.
Press the ENTER ()button.
Result:The options available in the SELF FOCUS group are
displayed.
5Press the ▲or ▼button until the AUTO is selected.
Press the ENTER ()button.
6To turn off the automatic execution of the self focus feature, select
OFF by pressing the ▲or ▼button. Press the ENTER ()
button to confirm.
Deactivating the Automatic Execution of the Self Focus
TV SETUP
TIME √√
PLUG & PLAY √√
LANGUAGE : ENGLISH √√
SELF FOCUS √√
BLUE SCREEN : OFF √√
▼ MORE
MOVE ENTER RETURN
TV SELF FOCUS
SELF FOCUS √√
AUTO : ON √√
MESSAGE : ON √√
MOVE ENTER RETURN
OFF
ON
BP68-00303A(J60A_Asia_ENG) 5/4/04 5:24 PM Page 18

19
ENG
1Press the MENU ()button.
Result:The main menu is displayed.
2Press the ▲or ▼button until the SETUP is selected.
Result:The options available in the SETUP group are displayed.
3Press the ENTER ()button.
4Press the ▲or ▼button until the SELF FOCUS is selected.
Press the ENTER ()button.
Result:The options available in the SELF FOCUS group are
displayed.
5Press the ▲or ▼button until the MESSAGE is selected. Press the
ENTER ()button.
6To remove the message SELF FOCUS and horizontal bar on the
screen during the self focus process, select OFF by pressing the
▲or ▼button. Press the ENTER ()button to confirm.
Removing the “SELF FOCUS” from the Display
TV SETUP
TIME √√
PLUG & PLAY √√
LANGUAGE : ENGLISH √√
SELF FOCUS √√
BLUE SCREEN : OFF √√
▼ MORE
MOVE ENTER RETURN
TV SELF FOCUS
SELF FOCUS √√
AUTO : ON √√
MESSAGE : ON √√
MOVE ENTER RETURN
OFF
ON
BP68-00303A(J60A_Asia_ENG) 5/4/04 5:24 PM Page 19

20
ENG
You can scan for the frequency ranges available to you (and
availability depends on your country). Automatically allocated
programme numbers may not correspond to actual or desired
programme numbers. However you can sort numbers manually and
clear any channels you do not wish to watch.
1Press the MENU ()button.
Result:The main menu is displayed.
2Press the ▲or ▼button until the CHANNEL is selected.
Result :
The options available in the CHANNEL group are
displayed.
3Press the ENTER ()button.
Result :The AUTO STORE is selected.
4Press the ENTER ()button again.
Result :The AUTO STORE menu is displayed with Area option
selected.
5Press the ENTER ()button once again. Select your country
by pressing the ▲or ▼button.
The countries are displayed in the following order:
ASIA W/EUROPE - CIS E/EUROPE - CHINA - HONKONG U/K -
AUSTRALIA - NZ/INDONESIA - SOUTH AFRICA - AMERICA.
76Press the ENTER ()button to confirm your choice
7Press the ▲or ▼button until the SEARCH is selected. Press the œ
or √button to start the search.
Result :The search will end automatically. Channels are sorted
and stored in an order which reflects their position in
the frequency range, (with lowest first and highest last).
The programme originally selected is then displayed.
➢To stop the search before it has finished or return to normal
viewing, press the MENU ()button.
9When searching and storing are complete, the SORT menu is
displayed.
◆ To sort the stored channels into the desired numerical order,
go to Step 6of the “Sorting the Stored Channels” procedure
on page 21.
◆ To exit from the channel store function without sorting the
channels, press the MENU ()button repeatedly until the
menus disappear.
10 When the channels have been stored, you can:
◆ Sort them in the order required (see page 21)
◆ Clear a channel (see page 24)
◆ Fine-tune channel reception if necessary (see page 25)
◆ Activate/deactivate the LNA (Low Noise Amplifier) feature
(see page 26)
◆ Activate/deactivate the Digital NR (Digital Noise Reduction)
feature (see page 32)
Storing Channels Automatically
TV CHANNEL
AUTO STORE √√
MANUAL STORE √√
ADD/DELETE √√
SORT √√
FINE TUNE √√
LNA : OFF √√
MOVE ENTER RETURN
TV SORT
FROM : P 1
TO : P--
STORE : ?
MOVE
œœ√√
ADJUST RETURN
TV
MOVE
œœ√√
SEARCH RETURN
AUTO STORE
AREA : ASIA W/EUROPE √√
SEARCH : -/+ √√
TV AUTO STORE
AREA : CHINA
SEARCH : -/+
MOVE ENTER RETURN
ASIA W/EUROPE
CIS E/EUROPE
CHINA
HONKONG U/K
AUSTRALIA
††
MORE
RETURN
SEARCH
P 1 C--
106 MHZ 20 %
BP68-00303A(J60A_Asia_ENG) 5/4/04 5:24 PM Page 20
