Samsung SP-43H3HT User manual

COLOUR
TELEVISION
SP43H3HT
Owner’s Instructions
Before operating the unit,
please read this manual thoroughly,
and retain it for future reference.
PICTURE INPICTURE (PIP)
TELETEXT
SELF FOCUS
BP68-00341A (J61A_Euro_ENG) 2004/07/29 11:16 AM Page 1

BP68-00341A (J61A_Euro_ENG) 2004/07/29 11:16 AM Page 2

English - 3
Important Warranty Information Regarding Television
Format Viewing
Standard screen format televisions (4:3, the aspect ratio of the screen width to height) are
primarily designed to view standard format full-motion video. The images displayed on them
should primarily be in the standard 4:3 ratio format and constantly moving. Displaying stationary
graphics and images on screen, such as the dark top and bottom letterbox bars (wide screen
pictures), should be limited to no more than 15% of the total television viewing per week.
Wide screen format televisions (16:9, the aspect ratio of the screen width to height) are
primarily designed to view wide screen format full-motion video. The images displayed on them
should primarily be in the wide screen 16:9 ratio format, or expanded to fill the screen if your
model offers this feature, and constantly moving. Displaying stationary graphics and images on
screen, such as the dark side-bars on non-expanded standard format television video and
programming, should be limited to no more than 15% of the total television viewing per week.
Additionally, viewing other stationary images and text such as stock market reports, video
game displays, station logos, web sites or computer graphics and patterns, should be limited as
described above for all televisions. Displaying any stationary images that exceed the above
guidelines can cause uneven aging of picture tubes (CRTs) that leave subtle, but permanent
burned-in ghost images in the television picture. To avoid this, vary the programming and
images, and primarily display full screen moving images, not stationary patterns or dark bars.
On television models that offer picture sizing features, use these controls to view the different
formats as a full screen picture.
Be careful in the selection and duration of television formats used for viewing. Uneven CRT
aging as a result of format selection and use, as well as other burned-in images, is not covered by
your Samsung limited warranty.
BP68-00341A (J61A_Euro_ENG) 2004/07/29 11:16 AM Page 3

English - 4
Contents
◆FOREWORD
■Important Warranty Information Regarding Television Format Viewing ........ 3
◆CONNECTING AND PREPARING YOUR TELEVISION
■Control Panel................................................................................................. 6
■Connection Panel .......................................................................................... 7
■Using a Display Deck .................................................................................... 8
■Inserting the Batteries into the Remote Control............................................. 8
■Infrared Remote Control ................................................................................ 9
■Connecting to an Aerial or Cable Television Network ................................... 10
■Connecting a Satellite Receiver or Decoder.................................................. 11
■Switching Your Television On and Off........................................................... 12
■Placing Your Television in Standby Mode..................................................... 12
■Familiarizing Yourself with the Remote Control............................................. 13
■Plug & Play Feature....................................................................................... 14
■Displaying Information ................................................................................... 15
■Choosing Your Language.............................................................................. 16
■Adjusting the Screen Automatically (Self Focus)........................................... 17
■Deactivating the Automatic Execution of Self Focus..................................... 18
■Removing “Self Focus” from the Display ....................................................... 19
◆SETTING THE CHANNELS
■Storing Channels Automatically..................................................................... 20
■Sorting the Stored Channels ......................................................................... 21
■Storing Channels Manually............................................................................ 22
■Skipping Unwanted Channels ....................................................................... 24
■Assigning Names to Channels ...................................................................... 25
■Locking the Channel...................................................................................... 26
■Fine Tuning Channel Reception.................................................................... 27
◆USING YOUR TELEVISION
■Viewing the Channel Scan Picture ................................................................ 28
■Using the LNA (Low Noise Amplifier) Feature............................................... 28
■Changing the Picture Standard ..................................................................... 29
■Customizing the Picture Settings................................................................... 30
■Selecting the Picture Size (4:3 Models)......................................................... 31
■Selecting the Picture Size (Wide Models) ..................................................... 32
■Selecting the Scan Mode............................................................................... 34
■Using the Digital NR (Noise Reduction) Feature ........................................... 35
■Freezing the Current Picture ......................................................................... 35
■DNIeTM (Digital Natural Image engine) ............................................... 36
■Setting Blue Screen Mode............................................................................. 37
■Viewing Picture In Picture (PIP) .................................................................... 38
■Changing the Sound Standard ...................................................................... 40
■Customizing the Sound Settings ................................................................... 41
■Adjusting the Volume Automatically .............................................................. 42
■Setting up Dolby Digital ................................................................................. 43
■Setting up Dolby Pro LogicII.......................................................................... 45
■Setting up External Digital Sound.................................................................. 46
■Setting the Melody Sound ............................................................................. 47
BP68-00341A (J61A_Euro_ENG) 2004/07/29 11:16 AM Page 4

English - 5
Contents (continued)
◆USING YOUR TELEVISION (continued)
■Selecting the Sound Mode ............................................................................ 48
■Setting and Displaying the Current Time....................................................... 49
■Setting the Sleep Timer ................................................................................. 50
■Switching the Television On and Off Automatically ....................................... 51
■Viewing an External Signal Source ............................................................... 52
◆USING THE DVD FUNCTION
■Playing a Disc................................................................................................ 53
■Using the Search and Skip Functions ........................................................... 54
■Playing a Disc (MP3/WMA) ........................................................................... 55
■Playing a Disc (MPG) .................................................................................... 56
■Playing a Disc (JPEG) ................................................................................... 57
■Using the Disc Menu ..................................................................................... 58
■Using the Title Menu...................................................................................... 58
■Displaying the Disc Information ..................................................................... 59
■Using the Zoom Function (DVD/VCD)........................................................... 60
■Changing the Camera Angle ......................................................................... 60
■Using the Bookmark Function (DVD/VCD).................................................... 61
■Repeat Play................................................................................................... 62
■Programme Play (CD) ................................................................................... 63
■Setting up the Language for the Player Menu............................................... 64
■Setting up the Display Options ...................................................................... 65
■Setting up Parental Control ........................................................................... 66
◆USING THE TELETEXT FEATURE
■Teletext Feature ............................................................................................ 67
■Displaying the Teletext Information ............................................................... 68
■Selecting the Display Options........................................................................ 69
■Selecting a Teletext Page.............................................................................. 70
◆ADDITIONAL INFORMATION AND CONNECTIONS
■Connecting to External Input/Output ............................................................. 71
■Connecting to the RCA Input......................................................................... 72
■Connecting to the S-Video Input.................................................................... 73
■Connecting to the Digital Audio Input ............................................................ 74
■Connecting to the Component Input.............................................................. 75
■Connecting Additional Speakers ................................................................... 76
■Redirecting an Input to the External Output .................................................. 77
◆RECOMMENDATIONS FOR USE
■Programming the Remote Control for Other Components ............................ 78
- VCR Remote Control Codes ....................................................................... 79
- Cable Box (CATV) Remote Control Codes ................................................. 80
- DVD Remote Control Codes ....................................................................... 80
■Disc Type and Characteristics....................................................................... 81
■Troubleshooting: Before Contacting Service Personnel................................ 82
☛➢
Press Important Note
Symbols
BP68-00341A (J61A_Euro_ENG) 2004/07/29 11:16 AM Page 5

English - 6
Control Panel
➢
The actual configuration of your TV may be different, depending on
your model.
( a ) Place the TV in standby mode
( b ) Remote control sensor
( c ) Standby & Timer indicator
( d ) Switch among video input modes
( e ) Display the on-screen menu
( f ) Adjust the volume
( g ) Select channels
( h ) Access to the selected option on the
menu system
( i ) Switch the TV on and off
ŒSkip or search for title, chapter or track
´Stop the disc
ˇPlay or pause the disc
¨Open and close the disc tray
ˆDisc tray
54321
➢◆You can use the C/P.buttons to switch on the TV when it is in standby mode depending on
the model.
◆The - +and C/P.buttons have the same function as the ▲/▼/œ/√buttons
on the remote control.
◆If the remote control no longer works or you have misplaced it, you can use the controls on the panel
of the TV.
Side of the TVFront of the TV
BP68-00341A (J61A_Euro_ENG) 2004/08/04 03:56 PM Page 6

English - 7
Connection Panel
➢
The actual configuration of your TV may be different, depending on
your model.
➢For further details about the connections, refer to pages 71~76.
☛Whenever you connect an audio or video system to your television, ensure that all elements are switched
off. Refer to the documentation supplied with your equipment for detailed connection instructions and
associated safety precautions.
Side of the TV
Rear of the TV
Video Input
S-Video Input
Audio Input
SCART Audio/Video
Input/Output
Digital Audio Input
Surround External
Speaker Output
Surround External Speaker
Output Selection
Component Input
75ΩCoaxial Connector for
Aerial or Cable Network
BP68-00341A (J61A_Euro_ENG) 2004/07/29 11:16 AM Page 7

English - 8
Using a Display Deck
You can display a VCR or DVD Player, etc. by using the display
deck.
You must insert or replace the batteries in the remote control when
you:
◆Purchase the television
◆Find that the remote control is no longer operating
correctly
1Remove the cover on the rear of the remote control by pressing
the symbol ( ) downwards and then pulling firmly to remove it.
2Insert two R03, UM4, “AAA” 1.5V or equivalent batteries taking
care to respect the polarities:
◆ - on the battery against - on the remote control
◆ + on the battery against + on the remote control
3Replace the cover by aligning it with the base of the remote
control and pressing it back into place.
➢Do not mix battery types, i.e. alkaline and manganese.
Inserting the Batteries into the Remote Control
BP68-00341A (J61A_Euro_ENG) 2004/07/29 11:16 AM Page 8

English - 9
Infrared Remote Control
DVD INFORMATION DISPLAY /
ONE, TWO, OR THREE-DIGIT
CHANNEL SELECTION
MENU DISPLAY/
TELETEXT INDEX
TELEVISION STANDBY
INFORMATION DISPLAY/
TELETEXT REVEAL
EXIT FROM ANY DISPLAY/
TUNER/CABLE NETWORK SELECTION
DELETE A BOOKMARK NUMBER AND
CANCEL THE PROGRAMME PLAY/
PICTURE EFFECT SELECTION
SOUND MODE SELECTION
DIRECT CHANNEL SELECTION
PICTURE FREEZE/
TELETEXT PAGE HOLD
EXTERNAL INPUT SELECTION
SWITCH REPEATEDLY BETWEEN THE
LAST TWO CHANNELS DISPLAYED/
RETURN TO PREVIOUS MENU
NEXT CHANNEL/
TELETEXT NEXT PAGE
IF YOUR REMOTE CONTROL IS NOT
FUNCTIONING PROPERLY, REMOVE
THE BATTERIES AND PRESS THE
RESET BUTTON FOR ABOUT 2~3
SECONDS. RE-INSERT THE
BATTERIES AND TRY USING THE
REMOTE CONTROL AGAIN.
PREVIOUS CHANNEL/
TELETEXT PREVIOUS PAGE
DNIe ON/OFF/DEMO
PICTURE SIZE/
TELETEXT SUB-PAGE
PIP FUNCTIONS;
-PIP ACTIVATION OR DEACTIVATION
(PIP)
-SWAPPING THE MAIN AND THE SUB-
PICTURE (SWAP)
-SELECTING THE CHANNEL OF THE
SUB-PICTURE (P / )
SELECT THE DEVICE (TV, VCR, DVD
PLAYER, STB) FOR THE REMOTE
CONTROL
FASTEXT TOPIC SELECTION/
VCR/DVD FUNCTIONS;
-SEARCH BACKWARDS ( )/
SKIP TO PREVIOUS THE TITLE,
CHAPTER, OR TRACK ( )
-STOP ( )
-PLAY/PAUSE ( )
-SEARCH FORWARDS ( )/
SKIP TO THE NEXT TITLE, CHAPTER,
OR TRACK ( )
SWITCH BETWEEN
TV AND DVD MODE
INCREASE VOLUME
TEMPORARY SOUND SWITCH-OFF
DECREASES VOLUME
TELETEXT DISPLAY/
MIX BOTH TELETEXT INFORMATION
AND THE NORMAL BROADCAST
ACCESS VARIOUS CAMERA
ANGLES ON A DVD /
TELETEXT SIZE SELECTION
SELF FOCUS
➢The performance of the remote control may be affected by bright light.
WHEN YOU PRESS A BUTTON , ‘
’
APPEARS ALONG WITH THE SELECTED
MODE (TV, VCR, CATV, DVD OR STB) AND
THE REMAINING BATTERIES ON THE LCD
OPEN/CLOSE THE DISC TRAY
CONTROL THE CURSOR
IN THE ON-SCREEN MENU
CONFIRM YOUR CHOICE
(STORE OR ENTER)
REMOTE CONTROL SETUP
SOUND EFFECT SELECTION/
SELECTION TELETEXT CANCEL
BP68-00341A (J61A_Euro_ENG) 2004/08/05 06:00 PM Page 9

English - 10
To view television channels correctly, a signal must be received by
the set from one of the following sources:
◆An outdoor aerial
◆A cable television network
◆A satellite network
1In the first three cases, connect the aerial or network input cable to
the ANT IN jack on the rear of the television.
2If you are using an indoor aerial, you may need to adjust it when
tuning your television until you obtain a picture that is both sharp
and clear.
For further details, refer to:
◆“Storing Channels Automatically” on page 20.
◆“Storing Channels Manually” on page 22.
Connecting to an Aerial or Cable Television Network
Rear of the TV
Cable Television
Network
or
BP68-00341A (J61A_Euro_ENG) 2004/08/05 06:00 PM Page 10

English - 11
Connecting a Satellite Receiver or Decoder
In order to watch television programmes broadcast via a
satellite network, you must connect a satellite receiver to
the rear of TV. Also, in order to descramble a coded
transmission signal, you must connect a decoder to the
rear of TV.
◆Using a SCART cable
Connect the receiver (or decoder) SCART cable to one
of the SCART connectors on the rear of the television.
◆Using a coaxial cable
Connect a coaxial cable to the:
- Receiver (or Decoder) output socket.
- Television aerial input socket.
➢If you wish to connect both a satellite receiver
(or decoder) and a VCR, you should connect the:
◆Receiver (or Decoder) to the VCR
◆VCR to the television
Otherwise, connect the receiver (or decoder) directly
to the television.
Rear of the TV
Satellite receiver/
Decoder
BP68-00341A (J61A_Euro_ENG) 2004/07/29 11:16 AM Page 11

English - 12
Switching Your Television On and Off
TV
The mains lead is attached to the rear of your television.
1Plug the mains lead into an appropriate socket.
➢
The main voltage is indicated on the rear of the television
and the frequency is 50 or 60Hz.
2Press the power switch on the side of the television to “ON” (I).
Result:The Standby indicator on the front of the television
lights up.
3Press the POWER ()button on the remote control to switch the
television on.
Result :The programme that you were watching last is re-
selected automatically.
➢
◆If your television isn’t turned on when the POWER ()
button is pressed, press the SELECT button to check if
“TV” mode has been chosen.
◆If you have not yet stored any channels, no clear picture
appears. Refer to “Storing Channels Automatically” on
page 20 or “Storing Channels Manually” on page 22.
4To switch your television off, press the power switch to “OFF”.
Placing Your Television in Standby Mode
Your television can be placed in Standby mode, in order to reduce
the power consumption.
Standby mode can be useful when you wish to interrupt
viewing temporarily (during a meal, for example).
1Press the POWER ()button on the remote control.
Result:The screen is turned off and the Standby indicator on
the front of the television lights up.
2To switch the television back on, simply press the POWER ()
button again or a numeric button.
➢
You can also switch the TV back on by pressing the TV (),
P /or numeric button.
☛Do not leave your television in Standby mode for long
periods of time (when you are away on holiday, for
example). Turn your television off by pressing the
power switch to “OFF”. It is best to unplug the set from
the mains and aerial.
TV
BP68-00341A (J61A_Euro_ENG) 2004/07/29 11:16 AM Page 12

English - 13
Familiarizing Yourself with the Remote Control
The remote control is used mainly to:
◆Change channels and adjust the volume
◆Set up the television using the on-screen menu system
The following table presents the most frequently used buttons and
their functions.
Button Viewing Function Menu Function
Used to display the next -
stored channel.
Used to display the
-
previous stored channel.
to Used to display the corresponding channels.
➢For double digit channels, the second digit must be
pushed immediately after the first. Failure to do this will
result in a single digit channel being displayed.
-/--/--- Used to select a channel numbered ten or over.
Press this button, and the “
-- ” or “ --- ” symbol is displayed.
Enter the two or three-digit channel number.
PRE-CH Press the PRE-CH button. The TV will switch to the last
channel viewed.
To quickly switch between two channels that are far apart,
select the frist channel, then use the numeric buttons to
select the second channel. Then, use the PRE-CH button to
quickly alternate between them.
Used to increase the -
volume.
Used to decrease the
-
volume.
MUTE Used to switch the sound off temporarily.
() ➢To turn the sound back on, press this button again, or
press the or button.
MENU Used to display the Used to return to the previous
() on-screen menu system. menu or normal viewing.
- Used to:
◆Display a sub-menu
containing selections for
the current menu option
◆Increase/decrease a
menu option value
- Used to confirm your choice.
TV Used to switch the Used to exit from the menu
() television on when it is system and return to normal
in Standby mode. viewing directly
EXIT - Used to exit from any
() display.
BP68-00341A (J61A_Euro_ENG) 2004/08/04 03:31 PM Page 13

English - 14
When the television is initially powered on several basic customer
settings proceed automatically and subsequently. The following
settings are available.
1If the television is in Standby mode, press the POWER ()button
on the remote control.
Result:The message Start Plug & Play is displayed.
2To start Plug & Play, press the ENTER ()button.
Result:The Language menu is displayed.
3Select the appropriate language by pressing the ▲or ▼button.
Press the ENTER ()button to confirm the language.
Result:The message Check antenna input. is displayed.
4Make sure that the antenna is connected to the TV, then press the
ENTER ()button.
Result:The Country menu is displayed.
5Select your country by pressing the ▲or ▼button. Press the
ENTER ()button to confirm your choice.
Result:The Search menu is displayed.
6To start channel store, press the ENTER ()button.
Result:The search will end automatically. Channels are sorted
and stored in the order which reflects their position in
the frequency range (with lowest first and highest last).
When it has finished, the Clock menu is displayed.
➢To stop the search before it has finished or return to normal
viewing, press the MENU ()button.
7Press the œor √button to move to the Hour or Minute.
Set these by pressing the ▲or ▼button.
➢You can also set the Hour and Minute by pressing the
numeric buttons directly.
8Press the ENTER ()button.
9When the settings are all finished, the message Enjoy your
watching. is displayed, and then the channel which has been
stored will be activated.
Plug & Play Feature
Plug & Play
œœ√√
Move Adjust
Enter Skip
Hour Minute
-- --
Enjoy your watching.
Plug & Play
OK
Language
English
ългарски
Hrvatski
Čeština
Nederlands
Français
††
Plug & Play
Move Enter Skip
Country
Belgium
Germany
Spain
France
Italy
Netherlands
††
Plug & Play
Move Enter Skip
Start Plug & Play
Plug & Play
Enter Exit
OK
Check antenna input.
Plug & Play
Enter Skip
OK
Plug & Play
Enter Skip
Start
BP68-00341A (J61A_Euro_ENG) 2004/07/29 11:17 AM Page 14

English - 15
If you want to reset this feature...
1Press the MENU ()button.
Result:The main menu is displayed.
2Press the ▲or ▼button until the Setup is selected.
Result:The options available in the Setup group are displayed.
3Press the ENTER ()button.
4Press the ▲or ▼button until the Plug & Play is selected.
Press the ENTER ()button.
Result:This feature starts with the message Start Plug &
Play displayed.
5For further details on setting up options, refer to the opposite
page.
Plug & Play Feature (continued)
Setup
Move Enter Return
Time √√
Plug & Play √√
Language : English √√
Self Focus √√
Blue Screen : Off √√
Melody : On √√
▼ More
TV
You can view the channel information and setting status you
selected by pressing the “INFO ( )” button on the remote
control.
Displaying Information
P 1
Mono
Picture : Dynamic
Sound : Custom
Dolby Pro Logic II : Off
12 : 02
BP68-00341A (J61A_Euro_ENG) 2004/07/29 11:17 AM Page 15

English - 16
When you start using your television for the first time, you must
select the language which will be used for displaying menus and
indications.
1Press the MENU ()button.
Result:The main menu is displayed.
2Press the ▲or ▼button until the Setup is selected.
Result:The options available in the Setup group are displayed.
3Press the ENTER ()button.
4Press the ▲or ▼button until the Language is selected. Press the
ENTER ()button.
Result:The available languages are listed.
5Select the appropriate language by pressing the ▲or ▼button.
Press the ENTER ()button to confirm your choice.
Choosing Your Language
Setup
Move Enter Return
Time √√
Plug & Play √√
Language : English √√
Self Focus √√
Blue Screen : Off √√
Melody : On √√
▼ More
TV
Setup
Move Enter Return
Time √√
Plug & Play √√
Language : English √√
Self Focus √√
Blue Screen : Off √√
Melody : On √√
▼ More
TV
English
ългарски
Hrvatski
Čeština
Nederlands
Français
Deutsch
†
BP68-00341A (J61A_Euro_ENG) 2004/07/29 11:17 AM Page 16

English - 17
Setup
Move Enter Return
Time √√
Plug & Play √√
Language : English √√
Self Focus √√
Blue Screen : Off √√
Melody : On √√
▼ More
TV
Self Focus
Move Enter Return
Self Focus √√
Auto : On √√
Message Display : On √√
TV
The “Self Focus” feature automatically finds the optimum picture
quality when blurring, overlapping colours or incorrect focus
occurs. These conditions may be caused by moving your TV.
1Press the MENU ()button.
Result:The main menu is displayed.
2Press the ▲or ▼button until the Setup is selected.
Result:The options available in the Setup group are displayed.
3Press the ENTER ()button.
4Press the ▲or ▼button until the Self Focus is selected.
Press the ENTER ()button.
Result:The Self Focus is selected.
5Press the ENTER ()button again
Result:The self focus process begins with the message Self
Focus and a horizontal bar is displayed. During the
process, minor distortions of the picture may occur.
At this time, the colours may diffuse and a searching
action will appear on the edges of the screen. This is a
normal part of the adjustment. When it is finished, this
will disappear and optimum picture quality can be
enjoyed.
➢It can be displayed simply by pressing the SELF FOCUS
button.
➢
◆Changing channels and any other signal changes will
pause self focus until a stable signal has returned.
It resumes after the signal has been stabilised.
This feature will not work without a signal.
◆Ambient light that is too bright may affect the self focus.
If this occurs, darken the environment and try again.
Adjusting the Screen Automatically (Self Focus)
Self Focus
BP68-00341A (J61A_Euro_ENG) 2004/07/29 11:17 AM Page 17

English - 18
Setup
Move Enter Return
Time √√
Plug & Play √√
Language : English √√
Self Focus √√
Blue Screen : Off √√
Melody : On √√
▼ More
TV
Self Focus
Move Enter Return
Self Focus √√
Auto : On √√
Message Display : On √√
TV
Self Focus
Move Enter Return
Self Focus √√
Auto : On √√
Message Display : On √√
TV
The “Self Focus” feature starts by default. It will automatically
begin 10 minutes after switching on the power and the appearance
of the screen image. To set the optimum picture quality, “Self
Focus” will automatically begin again after another 30 minutes, as
the screen image is then fully stabilised.
1Press the MENU ()button.
Result:The main menu is displayed.
2Press the ▲or ▼button until the Setup is selected.
Result:The options available in the Setup group are displayed.
3Press the ENTER ()button.
4Press the ▲or ▼button until the Self Focus is selected.
Press the ENTER ()button.
Result:The options available in the Self Focus group are
displayed.
5Press the ▲or ▼button until the Auto is selected.
Press the ENTER ()button.
6To turn off the automatic execution of the self focus feature, select
Off by pressing the ▲or ▼button. Press the ENTER ()
button to confirm.
Deactivating the Automatic Execution of Self Focus
Off
On
BP68-00341A (J61A_Euro_ENG) 2004/07/29 11:17 AM Page 18

English - 19
Setup
Move Enter Return
Time √√
Plug & Play √√
Language : English √√
Self Focus √√
Blue Screen : Off √√
Melody : On √√
▼ More
TV
Self Focus
Move Enter Return
Self Focus √√
Auto : On √√
Message Display : On √√
TV
Self Focus
Move Enter Return
Self Focus √√
Auto : On √√
Message Display : On√√
TV
1Press the MENU ()button.
Result:The main menu is displayed.
2Press the ▲or ▼ button until the Setup is selected.
Result:The options available in the Setup group are displayed.
3Press the ENTER ()button.
4Press the ▲or ▼button until the Self Focus is selected.
Press the ENTER ()button.
Result:The options available in the Self Focus group are
displayed.
5Press the ▲or ▼button until the Message Display is selected.
Press the ENTER ()button.
6To remove the message Self Focus and the horizontal bar on
the screen during the self focus process, select Off by pressing
the ▲or ▼button. Press the ENTER ()button to confirm.
Removing “Self Focus” from the Display
Off
On
BP68-00341A (J61A_Euro_ENG) 2004/07/29 11:17 AM Page 19

English - 20
You can scan for the frequency ranges available to you, (availability
depends on your country). Automatically allocated programme
numbers may not correspond to actual or desired programme
numbers. However you can sort numbers manually and clear any
channels you do not wish to watch.
1Press the MENU ()button.
Result:The main menu is displayed.
2Press the ▲or ▼button until the Channel is selected.
Result:The options available in the Channel group are
displayed.
3Press the ENTER ()button.
Result:The Auto Store is selected.
4Press the ENTER ()button again.
Result:The Auto Store menu is displayed with the Country
selected.
5Press the ENTER ()button once again. Select your country
by pressing the ▲or ▼button.
The countries are displayed in the following order:
Belgium - Germany - Spain - France - Italy - Netherlands -
Switzerland - Sweden - United Kingdom - Eastern Europe -
Others.
➢If you have selected the Others but do not wish to scan the
PAL frequency range, store the channels manually (see
page 22).
6Press the ENTER ()button to confirm your choice
7Press the ▲or ▼button until the Search is selected. Press the
ENTER ()button.
8Press the ENTER ()button to start the search.
Result:The search will end automatically. Channels are sorted
and stored in the order which reflects their position in
the frequency range (with lowest first and highest last).
The programme originally selected is then displayed.
➢To stop the search before it has finished or return to normal
viewing, press the MENU ()button.
9When searching and storing are complete, the Sort menu is
displayed.
◆ To sort the stored channels into the desired numerical order,
go to step 5of the “Sorting the Stored Channels” procedure on
page 21.
◆ To exit from the channel store function without sorting the
channels, press the MENU ()button repeatedly until the
menus disappear.
10 When the channels have been stored, you can:
◆ Sort them in the order required (see page21)
◆ Assign names to the stored channels (refer to page 25)
◆ Clear a channel (see page 24)
◆ Fine-tune channel reception if necessary (see page 27)
◆ Activate/deactivate the LNA (Low Noise Amplifier) feature
(see page 28)
◆ Activate/deactivate the Digital NR (Digital Noise Reduction)
feature (see page 35)
Storing Channels Automatically
Channel
Auto Store √√
Manual Store √√
Add/Delete √√
Sort √√
Name √√
Child Lock √√
▼ More
TV
Move Enter Return
Auto Store
Country :Off √√
Search √√
TV
Move Enter Return
Belgium
Germany
Spain
France
Italy
Netherlands
▼
Auto Store
Country : Belgium √√
Search √√
TV
Move Enter Return
Search
Enter Return
Start
Search
Enter Return
Stop
P 1 C --
----- 65 MHz
Sort
TV
Move Enter Return
1C -- -----
2C -- -----
3C -- -----
4C -- -----
5C -- -----
Prog.
BP68-00341A (J61A_Euro_ENG) 2004/07/29 11:17 AM Page 20
