Samsung UE48JS9000L User manual

SUHD TV
SERVICEManual
SUHD TV Contents
1. Precautions
2. Product specications
3. Disassembly and Reassembly
4. Troubleshooting
5. Wiring Diagram
UE**JS9000L
Chassis : UWH50
Model : UE48JS9000L
UE55JS9000L
UE65JS9000L

Contents
1. Precautions...................................................................................................................1-1
1-1-1. Warnings...................................................................................................................1-1
1-1-2. Servicing the LED TV ...............................................................................................1-1
1-1-3. Fire and Shock Hazard.............................................................................................1-1
1-1-4. Product Safety Notices .............................................................................................1-2
1-2. Servicing Precautions..........................................................................................................1-3
1-2-1. General Servicing Precautions .................................................................................1-3
1-3. Static Electricity Precautions ...............................................................................................1-4
1-4. Installation Precautions .......................................................................................................1-5
2. Product Specications.................................................................................................2-1
2-1. Product information .............................................................................................................2-1
2-2. Product specication ...........................................................................................................2-2
2-2-1. Feature & Specications...........................................................................................2-2
2-2-2. Detailed Specications .............................................................................................2-3
2-3. Accessories ......................................................................................................................2-15
2-4. Viewing the Functions .......................................................................................................2-16
2-4-1. The Samsung Smart Control ..................................................................................2-16
2-4-2. Learning motion control basics...............................................................................2-19
2-4-3. Viewing the Panel...................................................................................................2-20
2-4-4. Displaying Multiple Screens ...................................................................................2-25
2-4-5. Enabling the TV to boot faster ................................................................................2-26
2-4-6. HDMI UHD Color ....................................................................................................2-27
2-4-7. Supported Formats.................................................................................................2-28
3. Disassembly and Reassembly ....................................................................................3-1
3-1. Disassembly and Reassembly ............................................................................................3-1
4. Troubleshooting ...........................................................................................................4-1
4-1. Previous Check ..................................................................................................................4-1
4-2. How to Check Fault Symptom.............................................................................................4-2
4-2-1. Video.........................................................................................................................4-2
4-2-2. Bluetooth / WIFI Module ...........................................................................................4-4
4-2-3. One Connect Box (Jack-Pack) .................................................................................4-7
4-2-4. 3D Picture.................................................................................................................4-8
4-2-5. Testing Smart Hub Connections .............................................................................4-10
4-2-6. Jog Function Control .............................................................................................. 4-11
4-2-7. T-CON Board ..........................................................................................................4-12
4-3. Factory Mode Adjustments ................................................................................................4-13
4-3-1. Detail Factory Option..............................................................................................4-13
4-3-2. Entering Factory Mode ...........................................................................................4-16
4-3-3. Factory Data ...........................................................................................................4-17

4-4. White Balance ...................................................................................................................4-24
4-4-1. Calibration ..............................................................................................................4-24
4-4-2. Service Adjustment .................................................................................................4-24
4-4-3. Adjustment..............................................................................................................4-26
4-5. RS-232C............................................................................................................................4-27
4-6. AV Control Tabe.................................................................................................................4-28
4-7. Updating the TV’s Software...............................................................................................4-34
5. Wiring Diagram.............................................................................................................5-1
5-1. Wiring Diagram....................................................................................................................5-1
5-2. Connector............................................................................................................................5-2
5-2-1. Main Board ...............................................................................................................5-2
5-2-2. Jackpack Board (One connect) ................................................................................5-5
5-2-3. SMPS Board.............................................................................................................5-8
5-2-4. LDC Board................................................................................................................5-9
5-2-5. T-CON Board ..........................................................................................................5-10
5-3. Service Part.......................................................................................................................5-13
ANNEX. Exploded View & Part List [UE48JS9000LXXH TS01].......................... ANNEX-1
1-1. Exploded View.......................................................................................................... ANNEX-1
1-1-1. Parts List........................................................................................................ ANNEX-1
1-2. ONE CONNECT Exploded View .............................................................................. ANNEX-2
1-2-1. Parts List........................................................................................................ ANNEX-2
2-1. Electrical Parts List................................................................................................... ANNEX-3
ANNEX. Exploded View & Part List [UE55JS9000LXXH TS01].......................... ANNEX-1
1-1. Exploded View.......................................................................................................... ANNEX-1
1-1-1. Parts List........................................................................................................ ANNEX-1
1-2. ONE CONNECT Exploded View .............................................................................. ANNEX-2
1-2-1. Parts List........................................................................................................ ANNEX-2
2-1. Electrical Parts List................................................................................................... ANNEX-3
ANNEX. Exploded View & Part List [UE65JS9000LXXH TS01].......................... ANNEX-1
1-1. Exploded View.......................................................................................................... ANNEX-1
1-1-1. Parts List........................................................................................................ ANNEX-1
1-2. ONE CONNECT Exploded View .............................................................................. ANNEX-2
1-2-1. Parts List........................................................................................................ ANNEX-2
2-1. Electrical Parts List................................................................................................... ANNEX-3

This Service Manual is a property of Samsung Electronics Co.,Ltd.
Any unauthorized use of Manual can be punished under applicable
International and/or domestic law.
© 2015 Samsung Electronics Co.,Ltd.
All rights reserved.
Printed in Korea

3-1
3. Disassembly and Reassemble
3. Disassembly and Reassembly
This section of the service manual describes the disassembly and reassembly procedures for the LED TV.
WARNING
This LED TV contains electrostatically sensitive devices. Use caution when handling these components.
3-1. Disassembly and Reassembly
CAUTION
Disconnect the LED TV from the power source before disassembly.1.
Follow these directions carefully; never use metal instruments to pry apart the cabinet.2.
If there is no additional coment, it is same for all inches.3.
Description Picture Description Screws
1
Carefully position the TV so that the
screen is facing downwards.
CAUTION
Make sure to place the TV upon a soft
curved cushion or any material that
will prevent damage to the screen.
2
Remove the screws from the BRACKET-
STAND, LEG (R/L).
48" : 4EA•
55" : 4EA•
65" : 4EA•
Torque :
7~8Kgf.cm
6003-001494
M4,L12
3
Remove the ASSY STAND P-BASE.

3-2
3. Disassembly and Reassemble
Description Picture Description Screws
4
Remove the screws from the ASSY
COVER REAR.
48" : 15EA•
55" : 19EA•
65" : 21EA•
Torque :
7~8Kgf.cm
6002-001619
M3,L5,ZPC(WHT)
ASSY COVER REAR removed•
form
5
Remove the Wires and cable from
1~ 6connectors.
NOTE
When assembling the TV, the•
electric tapes must be applied on
the same locations.
Please remember to take a•
picture of where the tapes were
rstapplied.
1
5
2
6
3
6
5
4
6
1
2

3-3
3. Disassembly and Reassemble
Description Picture Description Screws
3
4
5
6
6
Remove the Wires and cable from
1~ 3connectors.
1
2
3

3-4
3. Disassembly and Reassemble
Description Picture Description Screws
7
Remove the NETWORK and ASSY
BOARD P-JOG FUNCTION.
ASSY BOARD P-JOG FUNCTION
NETWORK
8
Remove the ASSY SPEAKER P (L/R).
9
After removing the screws of the
marked section, LED DRIVER (DC
VSS-LED TV PD BD), MAIN (ASSY
PCB MAIN), SMPS (DC VSS-LED TV
PD BD).
48"•
LED DRIVER : 4EA-
SMPS : 6EA-
MAIN : 4EA-
55"•
LED DRIVER : 4EA-
SMPS : 6EA-
MAIN : 4EA-
65"•
LED DRIVER : 4EA-
SMPS : 6EA-
MAIN : 4EA-
MAIN SMPS
LED DRIVER Torque :
7~8Kgf.cm
6001-003016
M3.0,L5.0,ZPC(WHT)
10
/ After removing the screws of the
marked section, Frame Top, remove
the Frame Bottom.
48" : Top 4EA / Bottom 5EA•
55" : Top 5EA / Bottom 7EA•
65" : Top 6EA / Bottom 7EA•
Torque :
7~8Kgf.cm
6001-003016
M3.0,L5.0,ZPC(WHT)

3-5
3. Disassembly and Reassemble
Description Picture Description Screws
48" : Top 2EA / Bottom 2EA•
55" : Top 2EA / Bottom 2EA•
65" : Top 2EA / Bottom 2EA•
Torque :
4~5Kgf.cm
6003-001206
M3,L4,BLK
11
Completed the disassembly.
NOTE
Reassembly procedures are in the reverse order of disassembly procedures.

ANNEX. Exploded View & Part List [UE48JS9000LXXH TS01]
1-1. Exploded View
1-1-1. Parts List
No. Code No. Description & Specication Q’ty SA/SNA Remark
1 BN95-01959A PRODUCT LCD-SDC; CY-XJ048FLLV1V,JN8500,Ba 1 SA
2 BN96-34997A ASSY SPEAKER P-N8.5K 48INCH; 6ohm,12pin,1 1 SA
3 BN63-13318A COVER-DECO, BOT-SIDE; JS9000 48",PC,V2 2 SNA
4 BN63-13324A COVER-DECO, BOT-C; JS9000 48",PC,V2 1 SNA
5 BN63-13314A COVER-FRAME, BOT; JS8000 48",PC+ABS+MF17% 1 SNA
6 BN63-13391A COVER-FRAME, TOP; Q8000 48",AL 1 SNA
7 BN44-00814A DC VSS-LED TV PD BD; L48EM8A_FSM,L48EM8A_ 1 SA
8 BN44-00817A DC VSS-LED TV PD BD; L65EM8NC_FSM,L65EM8N 1 SA
9 BN94-08310F ASSY PCB MAIN; UJ9X,48",EUROPE,CIS 1 SA
10 BN63-13614B COVER-USB; JS9000 48",PC+ABS+GF15%,metal 1 SNA
11 BN96-35811A ASSY BLU P-LOGO; JQ9000,M14-JQ9000,121.2m 1 SA
12 BN96-35345J ASSY BOARD P-JOG FUNCTION; JS9000,FR-4,Jo 1 SA
13 BN59-01194D NETWORK; 11ac Combo,Internal WiFi,USB 2.0 1 SA
14 BN96-35882A ASSY COVER P-REAR; JS9K 48'',PC+ABS GF15% 1 SA
15 BN96-35577C ASSY GUIDE P-STAND; JS9K 55'',metal silve 1 SA
16 BN96-35571C ASSY STAND P-BASE; JS9K 48'',metal silver 1 SA
ANNEX-1
ANNEX. Exploded View & Part List

1-2. ONE CONNECT Exploded View
1-2-1. Parts List
No. Code No. Description & Specication Q’ty SA/SNA Remark
1 BN63-13593E COVER-TOP; JS9000 ONE-CONNECT,ABS+PC,Euro 1 SA
2 BN62-00729A HEAT SINK-FAN MODULE; Jackpack,A1050,BLAC 1 SNA
3 BN94-08353C ASSY PCB MISC-JACKPACK; JS9K,65",JACKAPCK 1 SA
4 BN96-35586B ASSY COVER P-BOTTOM; JQ9000 65",ABS+PC 1 SA
5 6003-001086 SCREW-TAPTYPE; BH,+,-,B,M3,L12,ZPC(BLK),S 6 SA
ANNEX-2
ANNEX. Exploded View & Part List

Service Bom (SA: SERVICE AVAILABLE, SNA: SERVICE NOT AVAILABLE)
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
UE48JS9000LXXH (TS01)
1 S001A BN90-06580C ASSY STAND;JS9K,48",EUROPE 1 SNA
0.2 SB04A BN96-35571C ASSY STAND P-BASE;JS9K 48'',metal silver 1 SA
..3 SCREW 6003-001001 SCREW-TAPTYPE;FH,+,-,B,M3,L8,ZPC(BLK),SW 4 SA
..3 SCREW 6003-001208 SCREW-TAPTYPE;BH,+,S,M4,L12,ZPC(BLK),SWR 4 SA
..3 6902-002463 BAG PE;HDPE/PE FOAM,T0.015/T0.5,W100,L40 2 SNA
..3 6902-002469 BAG PE;HDPE/PE FOAM,T0.015/T0.5,W160,L30 1 SNA
..3 BN61-11785A BRACKET-STAND, LEG-L;N8.5K 48",AL 1 SNA
..3 BN61-11787A BRACKET-STAND, LEG-R;N8.5K 48",AL 1 SNA
..3 BN63-07556H SHEET-COVER;TOC,PO,T0.068,W75mm,100M,ST- 1 SNA
..3 BN63-07556S SHEET-COVER;TOC,PO,T0.068,W150mm,100M,ST 0 SNA
..3 BN63-13602B COVER-STAND, TOP;JS9000 48",ABS+PC,metal 1 SNA
..3 BN63-13603B COVER-STAND, BOT;JS9000 48",ABS+PC 1 SNA
...4 0103-005041 RESIN PC ABS;FR3200TV,901408,BK0008,1.2m 110 SNA
..3 BN67-00398L RUBBER-FOOT;RUBBER,SILICONE,15.5*8,2,GRA 6 SNA
0.2 SG01A BN96-35577C ASSY GUIDE P-STAND;JS9K 55'',metal silve 1 SA
..3 SCREW 6003-000133 SCREW-TAPTYPE;BH,+,-,S,M4,L8,ZPC(BLK),SW 8 SA
..3 SCREW 6003-000282 SCREW-TAPTYPE;BH,+,-,B,M3,L8,ZPC(BLK),SW 1 SA
..3 6902-002059 BAG PE;HDPE/PE FOAM,T0.015/T0.5,W300,L40 1 SNA
..3 BN61-11626A BRACKET-STAND, NECK;Q8000 55",HGI 1 SNA
..3 BN61-11628A BRACKET-STAND, NECK-LINK;JS9000 55",EGI- 1 SNA
..3 BN61-12069A BRACKET-STAND,NECK-FRONT;JQ9000 55",HGI, 1 SNA
..3 AS080 BN63-04755W SHEET-COVER;UF7000,PE,T0.05,W300mm,200M, 1 SNA
..3 BN63-13338A COVER-STAND, NECK-FRONT;JS9000 55",ABS,d 1 SNA
...4 0103-004609 RESIN ABS;HF-0680U,K21294,BK0007,1.5mm H 16 SNA
..3 BN63-13398B COVER-STAND, NECK-REAR;JS9000 55",ABS+PC 1 SNA
..3 BN63-13529B COVER-STAND, NECK-SUB;JS9000 55",PC+ABS+ 1 SNA
..3 BN95-02164B ASSY COVER STAND SMT-HOLDER CABLE;JS9000 1 SNA
...4 0203-001269 TAPE-OPP MASKING;#301,T0.06,W75,L50000,N 2 SNA
...4 AA69-07212Z PAD-PLATE;CB,SW,535,450 1 SNA
...4 AA69-07308Y MASTER BOX;CB,DW,545,460,205 1 SNA
...4 AA69-07310B PAD-CROSS;CB,DW,534,60 1 SNA
...4 AA69-07310C PAD-CROSS;CB,DW,452,60 1 SNA
...4 BN01-00160A TARGET-CHROMIUM-CY;Chromium target,99.95 0 SNA
...4 BN01-00161A TARGET-CHROMIUM-PL;chromium target,over 0 SNA
...4 BN02-00353A COATING-AFS;SSVD-39,2%,1~10 cps,1.78 1 SNA
...4 AH089 BN61-11739A HOLDER-CABLE;JS90000,ABS 1 SNA
....5 0103-004609 RESIN ABS;HF-0680U,K21294,BK0007,1.5mm H 7 SNA
...4 BN68-03920A LABEL BOX;All Monitor,ART-PAPER 100G,WHT 1 SNA
...4 BN81-12182A A/S PACKING-SHEET SMT;JS9000 HOLDER-CABL 1 SNA
..3 BN96-36799A ASSY ACCESSORY-SCREW;JS9K,6003-001494 (8 1 SNA
...4 SCREW 6003-001494 SCREW-TAPTYPE;BH,+,S,M4,L12,NI PLT,SWRCH 8 SA
...4 6902-002484 BAG SCREW;LDPE,T0.05,W70,L90,TRP,RECYCLE 1 SNA
1 BN90-06585A ASSY W/I;JS9K,48" 1 SNA
ANNEX-3
ANNEX. Exploded View & Part List
2-1. Electrical Parts List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
0.2 BN81-08159Z PART SET-ELEC W/I;UF**,UH**,UG**,ELEC 1 SNA
0.2 BN81-09501G A/S PART SET-MECH W/I;UJ9X,U48JX* 1 SNA
1 R001A BN90-07349A ASSY COVER REAR;JS9K,48",EUROPE,CIS 1 SNA
0.2 6002-001619 SCREW-TAPPING;CH,+,S type,M3,L5,ZPC(WHT) 15 SA
0.2 R001A BN96-35882A ASSY COVER P-REAR;JS9K 48'',PC+ABS GF15% 1 SA
..3 R001 BN63-13328A COVER-REAR;JS9000 48",PC+ABS+GF15%,metal 1 SNA
..3 FD12 BN63-13614B COVER-USB;JS9000 48",PC+ABS+GF15%,metal 1 SNA
...4 0103-010573 RESIN PC ABS;HM-1159/G33168,GRAY,GY0294, 10 SNA
...4 BN68-00513D LABEL-RESIN;resin,-,art paper,-,10,25,-, 1 SNA
..3 BN68-05603A LABEL-E,PASS;ALL MODEL,ART PAPER 90G,60, 1 SNA
..3 BN68-07315C LABEL-LICENSE;JS9000,PP,T0.08,81,73,SILV 1 SNA
1 BN91-13745A ASSY LCM-SDC;CY-XJ048FLLV1V,BN95-01959A 1 SNA
0.2 PANEL BN95-01959A PRODUCT LCD-SDC;CY-XJ048FLLV1V,JN8500,Ba 1 SA
..3 SCREW 6001-002759 SCREW-MACHINE;CH,+,M3,L4,ZPC(BLK),SWRCH1 22 SA
..3 SCREW 6001-003016 SCREW-MACHINE;PWH,+,M3.0,L5.0,ZPC(WHT),S 4 SA
..3 SCREW 6001-003075 SCREW-MACHINE;BH,+,M3,L4,ZPC(WHT),SWRCH1 12 SA
..3 BN02-00352K TAPE PET;JS9000,PET,0.05T,15,35,BLK 4 SNA
..3 BN68-05722A LABEL-STICKER;ALL MODEL,POLYPROPYLENE,0. 1 SNA
..3 BN90-06315A ASSY MISC-BLU;CY-XJ048FLLV1V 1 SNA
...4 SCREW 6001-002759 SCREW-MACHINE;CH,+,M3,L4,ZPC(BLK),SWRCH1 10 SA
...4 BN02-00102B TAPE-FILAMENT;#8917,0.15,25,50,WHITE 1 SNA
...4 BN02-00231H TAPE ABSORBER-SHEET FIXING;JQ9000,PC,0.3 4 SNA
...4 BN02-00231J TAPE ABSORBER-SHEET-FIXING;JS9000,PET,0. 2 SNA
...4 BN61-11633A LGP-LED;48inch N8, Lenticular,MS,1059.1 1 SNA
...4 BN63-13415A SHEET-QD;UTQ10-9B,PET,0.34,1056.67,602.5 1 SNA
...4 BN63-13423A SHEET-COMPLEX;G220W,PET,0.325,1055.29,60 1 SNA
...4 BN63-13426A SHEET-DBEF;DLF250,PET,0.25,1055.29,595.9 1 SNA
...4 BN63-13427A SHEET-REFLECTOR;SRE885C,PET,0.285,1055.1 1 SNA
...4 BN96-34772A ASSY LED BAR P-LED BAR;48"_N9K_L_SDC,72e 1 SNA
...4 BN96-34773A ASSY LED BAR P-LED BAR;48"_N9K_R_SDC,72e 1 SNA
...4 BN96-35143A ASSY MISC P-CHASSIS BOTTOM;Y15 JS9000 48 1 SNA
....5 6001-002617 SCREW-MACHINE;CH,+,M3,L4,NI PLT (White), 3 SNA
....5 SCREW 6001-002755 SCREW-MACHINE;BH,+,M3,L6,ZPC(BLK),SWRCH1 3 SA
....5 M0909 AA63-01387A GASKET-EMI,SPONGE;SP-P300M,Conductive Fa 4 SNA
....5 BN02-00040B TAPE DOUBLE FACE-DIFFUSER FIXING;NNB 32/ 1 SNA
....5 BN02-00041A TAPE ETC-HEAT-SINK;NNB 32/40/46/55,MTU 1 10 SNA
....5 BN02-00102B TAPE-FILAMENT;#8917,0.15,25,50,WHITE 1 SNA
....5 BN02-00352J TAPE PET;JS9000,PET,0.05T,30,45,BLK 1 SNA
....5 BN02-00384J GRAPHITE THERMAL SHEET-UP L;JS9000 48",G 1 SNA
....5 BN02-00384K GRAPHITE THERMAL SHEET-UP R;JS9000 48",G 1 SNA
....5 BN02-00384L GRAPHITE THERMAL SHEET-DN L;JS9000 48",G 1 SNA
....5 BN02-00384M GRAPHITE THERMAL SHEET-DN R;JS9000 48",G 1 SNA
....5 EC13 BN39-01978A LEAD CONNECTOR;48inch N9K_left,Lead Conn 1 SNA
....5 EC13 BN39-01979A LEAD CONNECTOR;48inch N9K_right,Lead Con 1 SNA
....5 BN60-00162A SPACER-FOAM;FOAM,50000L,BLK,0.35T,20W 0 SNA
....5 BN60-01127A SPACER-RUBBER-LGP;JN9000 65",RUBBER,7,GR 2 SNA
....5 BN61-09449A BRACKET-STOPPER NUT;Y13 SF-LED,M2.6*D4.5 4 SNA
ANNEX-4
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
....5 BN61-10550A BRACKET-STAND-OFF;D5, H4,SUM24L,2.5,Blac 6 SNA
....5 BN61-10694B SUPPORT-PCB;Y15 N8500 48",NYLON66,NTR,CN 2 SNA
....5 BN61-10711A HOLDER-RIVET;Y14 VDTV H8000 U9000 55 65, 12 SNA
....5 BN61-11700A HANGER-QD;JS9000 48/55/65,POM,BLK 3 SNA
....5 BN61-11801A BRACKET-GUIDE,BOT;N8.5K,EGI-SECC,1.0T 3 SNA
....5 BN62-00702B INSULATION-LED DRIVER;JN9000 48",PC,0.4, 1 SNA
....5 BN62-00702D INSULATION-PD BOARD;JN9000 48",PC,0.4,29 1 SNA
....5 BN62-00703E INSULATION-S-PCB L;JN9000 48",PET,0.1,BL 1 SNA
....5 BN62-00703F INSULATION-S-PCB R;JN9000 48",PET,0.1,BL 1 SNA
....5 M0131 BN63-01256A GASKET;VN30,Conductive Fabric,3mm,10mm,3 2 SNA
....5 CC02 BN64-02849A CHASSIS-BOTTOM;Q8000 48",EGI-SECC,T0.8 1 SNA
.....6 BN01-00143A STEEL;EGI-SECC,T0.8,660,SECC,AG 4867 SNA
....5 BN67-00398W RUBBER-FOOT;JS9000,SILICONE,26*12.5,10T, 1 SNA
....5 BN96-35146A ASSY MISC P-BRKT REAR SUPPORT BOT;Y15 N8 2 SNA
.....6 BN61-10712B HOLDER-WALL RIVET;JS9000,SWRCH10A,BLK,M8 4 SNA
.....6 BN61-11322A BRACKET-REAR,SUPPORT;JS9000 48",EGI-SECC 2 SNA
...4 BN96-35151A ASSY FRAME P-MOLD MIDDLE U;Y15 N8500 48, 1 SNA
....5 BN60-01122Q SPACER-PANEL U A;JN9000 48",SI,GRAY,0.4 1 SNA
....5 BN60-01122R SPACER-PANEL U B;JN9000 48",SI,GRAY,0.4 1 SNA
....5 BN60-01122S SPACER-PANEL U C;JN9000 48",SI,GRAY,0.4 1 SNA
....5 BN60-01122T SPACER-PANEL U D;JN9000 48",SI,GRAY,0.4 1 SNA
....5 BN61-11328A FRAME-MOLD,MIDDLE-U;Q8000 48",PC+GF10%,W 1 SNA
...4 BN96-35154A ASSY FRAME P-MOLD MIDDLE D;Y15 N8500 48, 1 SNA
....5 BN02-00050A TAPE DOUBLE FACE;SNB 55",SK2100HE,0.05,2 1 SNA
....5 BN60-00919E SPACER-LGP UD;Y14 VDTV H8000C 48",SI,524 2 SNA
....5 BN60-01122Z SPACER-PANEL D A;JQ9000 48",SI,200,GRAY, 1 SNA
....5 BN60-01130A SPACER-PANEL D B;JQ9000 48",SI,305.5,GRA 1 SNA
....5 BN60-01130B SPACER-PANEL D C;JQ9000 48",SI,217.5,GRA 1 SNA
....5 BN60-01130C SPACER-PANEL D D;JQ9000 48",SI,200,GRAY, 1 SNA
....5 BN61-11331A FRAME-MOLD,MIDDLE-D;Q8000 48",PC+GF10%,W 1 SNA
...4 BN96-35157A ASSY FRAME P-MOLD MIDDLE LR;Y15 N8500 48 2 SNA
....5 BN60-01122U SPACER-PANEL LR;JN9000 48",SI,GRAY,0.6 2 SNA
....5 BN60-01125C SPACER-LGP LR;JS9000 48",PET,584.5,WHITE 2 SNA
....5 BN61-11334A FRAME-MOLD,MIDDLE-LR;Q8000 48",PC+GF10%, 2 SNA
..3 TCON BN95-01983A ASSY T CON;LSF480FJ03-K,48U120Hz N9000 1 SA
...4 BN62-00705A HEAT SINK-PS;JU 7.5K,A1050,BLACK,135*98. 1 SNA
...4 BN97-09256A ASSY SMD;BN95-01983A 1 SNA
....5 0403-001164 DIODE-ZENER;MMSZ5232B,5.32-5.88V,500MW,S 1 SA
....5 0403-001831 DIODE-ZENER;KDZ12B,12/13.5V,1000mW,SOD-1 3 SA
....5 0404-001640 DIODE-SCHOTTKY;SS1060HEWS,60V,1000mA,SOD 1 SA
....5 0404-001643 DIODE-SCHOTTKY;B360A,60V,3000mA,SMA,TP 2 SA
....5 0406-001643 DIODE-TVS;1SMA33AT3G,36.7/38.65/40.6V,40 1 SNA
....5 0406-001689 DIODE-TVS;SMH14A,15.6V,17.9V,1MAV,40A,TP 1 SA
....5 0406-001691 DIODE-TVS;5.5V,7.0V,8.5V,0.5MAV,TP 2 SA
....5 0501-000465 TR-SMALL SIGNAL;MMBT3904,NPN,350mW,SOT-2 1 SA
....5 0502-001346 TR-POWER;FCX591A,PNP,1000mW,SOT89,TR,30/ 1 SA
....5 0505-002660 FET-SILICON;Si2308BDS,N,60V,2.3A,0.156oh 1 SNA
ANNEX-5
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
....5 0505-003224 FET-SILICON;AO6405,P,-30V,-5A,0.052ohm,2 2 SA
....5 EL02 0601-002037 LED;SMD(TOP VIEW),BLUE,1.6x0.8mm,465/470 2 SA
....5 0801-002345 IC-CMOS LOGIC;7S04,INVERTER,SOT-353,5P,2 1 SA
....5 0801-003580 IC-CMOS LOGIC;TC7WB66CFK,SSOP,8P,2.0X2.3 3 SA
....5 1203-007955 IC-DC/DC CONVERTER;BM81222MWV,QFN,48P,6x 2 SNA
....5 1203-008319 IC-DC/DC CONVERTER;BM81233,QFN,32P,5x5mm 1 SNA
....5 1203-008391 IC-DC/DC CONVERTER;AOZ1269QI-02,QFN-23L, 1 SA
....5 1204-003617 IC-VIDEO PROCESS;SDP1409.3,FCBGA,1023P,3 1 SA
....5 IS01 1209-002183 IC-SENSOR;S-5851AAA-M6T1U,SOT,6Z30,2.9x1 1 SA
....5 1405-001381 VARISTOR;11V,8VDC,30A,1.6x0.8x0.9mm,TP,2 4 SA
....5 2007-000039 R-CHIP;0ohm,1%,1/10W,TP,1608 5 SA
....5 2007-000067 R-CHIP;15Kohm,1%,1/10W,TP,1608 2 SNA
....5 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 5 SA
....5 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 3 SA
....5 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 SA
....5 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 2 SA
....5 2007-000109 R-CHIP;1Mohm,5%,1/10W,TP,1608 1 SA
....5 2007-000157 R-CHIP;47Kohm,5%,1/16W,TP,1005 1 SNA
....5 2007-000165 R-CHIP;200Kohm,5%,1/16W,TP,1005 4 SNA
....5 2007-000219 R-CHIP;1.2Kohm,1%,1/10W,TP,1608 1 SA
....5 2007-000239 R-CHIP;1.5Kohm,1%,1/10W,TP,1608 1 SA
....5 2007-000256 R-CHIP;1.6Kohm,1%,1/10W,TP,1608 1 SA
....5 2007-000265 R-CHIP;1.8Kohm,1%,1/10W,TP,1608 1 SA
....5 2007-000287 R-CHIP;100ohm,1%,1/10W,TP,1608 3 SNA
....5 2007-000336 R-CHIP;120Kohm,1%,1/10W,TP,1608 1 SA
....5 2007-000516 R-CHIP;2.7Kohm,1%,1/10W,TP,1608 3 SNA
....5 2007-000614 R-CHIP;24Kohm,1%,1/10W,TP,1608 1 SNA
....5 2007-000651 R-CHIP;27Kohm,1%,1/10W,TP,1608 1 SA
....5 2007-000669 R-CHIP;2Kohm,1%,1/10W,TP,1608 1 SNA
....5 2007-000683 R-CHIP;3.3Kohm,1%,1/10W,TP,1608 1 SA
....5 2007-000708 R-CHIP;3.9Kohm,1%,1/10W,TP,1608 1 SNA
....5 2007-000726 R-CHIP;300ohm,1%,1/10W,TP,1608 1 SA
....5 2007-000803 R-CHIP;36Kohm,1%,1/10W,TP,1608 1 SA
....5 2007-000869 R-CHIP;4.7Kohm,1%,1/10W,TP,1608 3 SA
....5 2007-000939 R-CHIP;47Kohm,1%,1/10W,TP,1608 1 SA
....5 2007-000962 R-CHIP;5.1Kohm,1%,1/10W,TP,1608 4 SA
....5 2007-000999 R-CHIP;510ohm,1%,1/10W,TP,1608 2 SA
....5 2007-001068 R-CHIP;6.8Kohm,1%,1/10W,TP,1608 1 SA
....5 2007-001090 R-CHIP;620ohm,1%,1/10W,TP,1608 1 SA
....5 2007-001125 R-CHIP;68Kohm,1%,1/10W,TP,1608 1 SA
....5 2007-001139 R-CHIP;7.5Kohm,1%,1/10W,TP,1608 1 SA
....5 2007-001153 R-CHIP;750ohm,1%,1/10W,TP,1608 2 SA
....5 2007-002437 R-CHIP;2ohm,5%,1/10W,TP,1608 1 SNA
....5 2007-007315 R-CHIP;3.9Kohm,1%,1/16W,TP,1005 1 SNA
....5 2007-007590 R-CHIP;82Kohm,1%,1/16W,TP,1005 2 SNA
....5 2007-007627 R-CHIP;16Kohm,1%,1/16W,TP,1005 2 SA
....5 2007-007651 R-CHIP;9.1Kohm,1%,1/10W,TP,1608 1 SA
ANNEX-6
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
....5 2007-007768 R-CHIP;13Kohm,1%,1/10W,TP,1608 1 SA
....5 2007-008332 R-CHIP;11.5Kohm,1%,1/16W,TP,1005 1 SA
....5 2007-008596 R-CHIP;0.1ohm,1%,1/4W,TP,3216 1 SC
....5 2011-001264 R-NETWORK;10ohm,5%,1/16W,L,CHIP,8P,TP,2. 16 SNA
....5 AD480 2203-000332 C-CER,CHIP;0.012nF,5%,50V,C0G,TP,1608 2 SA
....5 AD480 2203-000491 C-CER,CHIP;2.2nF,10%,50V,X7R,TP,1608 1 SA
....5 AD480 2203-000715 C-CER,CHIP;3.3nF,10%,50V,X7R,TP,1608 2 SNA
....5 AD480 2203-000838 C-CER,CHIP;0.39nF,5%,50V,C0G,TP,1608 1 SNA
....5 AD480 2203-002711 C-CER,CHIP;100nF,10%,25V,X7R,TP,1608 4 SA
....5 AD480 2203-005918 C-CER,CHIP;1000nF,10%,6.3V,X7R,TP,1608 4 SNA
....5 AD480 2203-005968 C-CER,CHIP;4.7nF,10%,50V,X7R,TP,1005,0.5 2 SNA
....5 AD480 2203-006320 C-CER,CHIP;2200nF,10%,16V,X7R,TP,2012 2 SNA
....5 AD480 2203-006698 C-CER,CHIP;1000nF,10%,25V,X7R,TP,1608,0. 7 SNA
....5 AD480 2203-006741 C-CER,CHIP;470nF,10%,25V,X5R,TP,1608,0.8 3 SNA
....5 AD480 2203-006841 C-CER,CHIP;1000nF,10%,16V,X5R,TP,1005 1 SNA
....5 AD480 2203-007176 C-CER,CHIP;10000nF,10%,16V,X5R,TP,2012,1 56 SNA
....5 AD480 2203-007193 C-CER,CHIP;10000nF,10%,6.3V,X7R,TP,2012 7 SA
....5 2703-003747 INDUCTOR-SMD;22uH,20%,6060,0.135ohm,1300 4 SA
....5 2703-003862 INDUCTOR-SMD;10uH,20%,6060,0.065ohm,1900 1 SA
....5 2703-003913 INDUCTOR-SMD;2.2uH,20%,2520,1.2T,0.116Oh 1 SNA
....5 2703-004199 INDUCTOR-SMD;10uH,20%,6.6x7.0mm,2.2mm,0. 2 SNA
....5 2703-004589 INDUCTOR-SMD;2.2uH,20%,5050,2T,0.048Ohm, 2 SA
....5 2703-004847 INDUCTOR-SMD;4.7uH,20%,3838,1.8T,0.075Oh 1 SA
....5 2801-005324 CRYSTAL-SMD;27MHz,30ppm,Ceramic SMD(4pin 1 SA
....5 3601-001376 FUSE-SURFACE MOUNT;32V,3A,FAST-ACTING,Hi 3 SNA
....5 3601-001402 FUSE-SURFACE MOUNT;125V,7A,FAST ACTING,C 1 SNA
....5 3708-003073 CONNECTOR-FPC/FFC/PIC;51P,0.5mm,SMD,AU,N 1 SA
....5 3708-003241 CONNECTOR-FPC/FFC/PIC;96P,0.5mm,SMD-A,AU 2 SNA
....5 3711-007839 CONNECTOR-HEADER;BOX,15P,1R,1.25mm,SMD-A 1 SA
....5 EH01 3711-008098 HEADER-BOARD TO CABLE;BOX,20P,1R,1.25mm, 1 SNA
....5 6302-001290 GASKET;SMR-TS-4-4.5-3,4.0mm,Ni+Au+SUS+Mg 6 SNA
....5 BN41-02297A PCB MAIN;2015 SDC UHD,FR-4,4,1.6T,160*14 1 SNA
....5 BN97-09442A ASSY MICOM;1107-002265,BN95-01983A,J48A1 1 SNA
.....6 IC 1107-002265 IC-NOR FLASH;W25Q32FVSSIG,32Mbit,SOP,8P, 1 SA
..3 BN96-34890A ASSY OPEN CELL;LSF480FJ03-K,10bit,48INCH 1 SNA
...4 BN81-07436A A/S-ADHESIVE-A.C.F;ADHESIVE-A.C.F,3-ADHE 1 SNA
...4 BN81-07943A A/S-ADHESIVE-A.C.F(TP500B);ADHESIVE-A.C. 1 SNA
...4 BN82-01508A A/S ASSY-IC DRIVER SOURCE;IC DRIVER SOUR 1 SNA
...4 BN82-01543A A/S ASSY-IC DRIVER SOURCE;IC DRIVER SOUR 1 SNA
...4 BN82-01545A A/S ASSY-POLARIZER C/F;POLARIZER C/F,LJ0 1 SNA
...4 BN82-01547A A/S ASSY-POLARIZER TFT;POLARIZER TFT,LJ0 1 SNA
...4 BN82-01549A A/S ASSY-ASSY PCB-SOURCE(L);ASSY PCB-SOU 1 SNA
...4 BN82-01551A A/S ASSY-ASSY PCB-SOURCE(R);ASSY PCB-SOU 1 SNA
..3 FL06 BN96-34970B ASSY CABLE P-FFC;UHD,FFC,NH,67mm짹1.0,96 2 SNA
..3 BN96-35133A ASSY COVER P-SOURCE L;Y15 N8500 48,SECC, 1 SNA
...4 BN62-00703L INSULATION-S-COVER L;JN9000 48",PET,0.1, 1 SNA
...4 BN63-13130A SHIELD-SOURCE,COVER-L;Q8000 48",EGI-SECC 1 SNA
ANNEX-7
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
..3 BN96-35136A ASSY COVER P-SOURCE R;Y15 N8500 48,SECC, 1 SNA
...4 AA63-00099G SPACER-FELT;JS9000,FELT,BLK,T0.35,120*30 1 SNA
...4 BN60-00554Q SPACER-SOURCE;SNB 40/46/55,SI RUBBER,10, 2 SNA
...4 BN60-00554R SPACER-SOURCE;Y15 VD,SI RUBBER,10,BLACK, 1 SNA
...4 BN60-00804A SPACER-SOURCE;SNB 40/46/55,SI RUBBER,10, 1 SNA
...4 BN61-10535A BRACKET-STOPPER NUT;SUM24L,M3,L10.6,WHT, 2 SNA
...4 BN62-00703M INSULATION-S-COVER R;JN9000 48",PET,0.1, 1 SNA
...4 BN63-13133A SHIELD-SOURCE,COVER-R;Q8000 48",EGI-SECC 1 SNA
..3 TC01A BN96-35140A ASSY MISC P-CHASSIS TOP;Y15 JS9000 48,ST 1 SNA
...4 0201-002972 ADHESIVE-STRL;JS9000,YELLOW,HF-8000R 0 SNA
...4 BN60-00920Q SPACER-TOP;H8000 55,PUR FOAM,ROLL TYPE,B 3 SNA
...4 BN61-04692A BOSS-PRIMER;#94,SHEET,clear,35cps 2 SNA
...4 BN61-07463Q TAPE-DOUBLE FACE;ACRYL,T0.25,W4.0,CLEAR 1 SNA
...4 AS080 BN63-10029A SHEET-COVER;UE9500 75",PUR,T0.052,W13mm, 2 SNA
...4 BN63-10029B SHEET-COVER;JN9000,PET,0.052,W22mm,100M, 3 SNA
...4 BN64-02130J BADGE-BRAND;JS9000,Ni,0.05,30.0,DARK SIL 1 SNA
...4 AC157 BN64-02846A CHASSIS-TOP;Q8000 48",SPCC,T0.6 1 SNA
...4 BN64-02961A CHASSIS-TOP, SIDE-L;N8K 48,PC+GF10% 1 SNA
...4 BN64-02964A CHASSIS-TOP, SIDE-R;N8K 48,PC+GF10% 1 SNA
...4 BN64-03143A BADGE-UHD;JS9000,NI,0.09,19.99,Dark Silv 1 SNA
..3 BN96-36566A ASSY BRACKET P-STAND,LINK;Y15 JS9000 48" 1 SNA
...4 BN61-11535A BRACKET-STAND, LINK;JS9000 48",EGI-SECC, 1 SNA
....5 BN61-02932L BRACKET-STOPPER NUT;LED TV,M3,D5.5,L7.5, 1 SNA
....5 BN61-09605A BRACKET-STOPPER NUT;LED TV F6100,Others 4 SNA
...4 BN63-04077A GASKET;PS63P71FHX,CONDUCTIVE ADHESIVE sp 1 SNA
1 M0017 BN91-14324F ASSY CHASSIS;JS9K,48",EU,CIS 1 SNA
0.2 M0014 BN94-08310F ASSY PCB MAIN;UJ9X,48",EUROPE,CIS 1 SA
..3 BN62-00620A HEAT SINK-ES;HU8500,A6063*,ANODIZING,31. 1 SNA
..3 BN97-09356B ASSY SMD;JQ9K,BN41 1 SNA
...4 0202-001899 SOLDER-CREAM;M705-GRN360-K2-VT,20-38um,S 2 SNA
...4 DS01A 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 2 SA
...4 0404-001404 DIODE-SCHOTTKY;BAT721C,40V,200mA,SOT-23, 1 SA
...4 0406-001200 DIODE-TVS;RCLAMP0504F,6/-/-V,150W,SC-70 2 SA
...4 0406-001317 DIODE-TVS;SMAJ14A,15.6/-/17.2V,400W,SMA 1 SNA
...4 0406-001635 DIODE-TVS;SMF5.0A,6.4V, 6.7V, 7V,200W,SM 3 SA
...4 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 SA
...4 0504-000126 TR-DIGITAL;KSR1101,NPN,200mW,4.7K/4.7Koh 2 SA
...4 0505-001844 FET-SILICON;SI4435DDY-T1-GE3,P,-30V,-11. 1 SA
...4 0505-002598 FET-SILICON;AP2317GN,P,-20V,-4.2A,0.052o 1 SA
...4 0505-003397 FET-SILICON;2N7002K,N,60V,380mA,1.19ohm, 1 SA
...4 0801-000796 IC-CMOS LOGIC;7S32,OR GATE,SOT-353,5P,51 1 SA
...4 0801-003292 IC-CMOS LOGIC;7WB66,Bus Switch,MAB08A,8P 1 SA
...4 0801-003424 IC-CMOS LOGIC;74VHCV541,Octal schmitt bu 1 SA
...4 0904-002882 IC-USC;GL852G-OHY38,QFN,28P,5x5mm,12MHz, 1 SA
...4 1006-001576 IC-DRIVER/RECEIVER;MAX3221ECPWR,TSSOP,16 1 SA
...4 1201-000166 IC-OP AMP;LM358,SOP,ST,8P,150MIL,DUAL,10 1 SA
...4 1201-003891 IC-AUDIO AMP;NTP7415,MLF,48P,7x7mm,DUAL, 3 SA
ANNEX-8
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
...4 1203-006109 IC-POSI.FIXED REG.;S-1206B33-M3T1G,SOT-2 1 SA
...4 1203-006330 IC-POWER SUPERVISOR;TPS2065DBV,SOT-23,5P 1 SA
...4 1203-007238 IC-PWM CONTROLLER;TPS54427,DDA,8P,4.8x3. 1 SNA
...4 1203-007695 IC-DC/DC CONVERTER;AOZ3018,SO-8,8Z30,4.9 2 SA
...4 1203-007728 IC-VOL. DETECTOR;RT9831GQW,QW : WQFN-20L 1 SA
...4 1203-007757 IC-POSI.ADJUST REG.;TPS7A7001DDAR,SOIC-8 1 SA
...4 1203-008118 IC-DC/DC CONVERTER;AOZ3013PI,SO-8,8P,4.9 1 SA
...4 1204-003579 IC-VIDEO PROCESS;SDP1407,FCLBGA,510P,21x 1 SA
...4 1205-004855 IC-SWITCH;TPS25910RSAR,QFN,16P,4x4x0.8mm 1 SA
...4 1205-004983 IC-SWITCH;BD82032FVJ,TSSOP-B8J,8P,3.0x4. 1 SA
...4 1405-001271 VARISTOR;35V,20Vdc,5A,1.0x0.5x0.6mm,TP,1 3 SA
...4 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 4 SA
...4 2007-000060 R-CHIP;100Kohm,1%,1/10W,TP,1608 3 SNA
...4 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 29 SNA
...4 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 11 SNA
...4 2007-000172 R-CHIP;10ohm,5%,1/16W,TP,1005 1 SNA
...4 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 9 SNA
...4 2007-000219 R-CHIP;1.2Kohm,1%,1/10W,TP,1608 2 SA
...4 2007-000242 R-CHIP;1.5Kohm,5%,1/16W,TP,1005 1 SNA
...4 2007-000512 R-CHIP;2.4Kohm,5%,1/10W,TP,1608 1 SNA
...4 2007-000614 R-CHIP;24Kohm,1%,1/10W,TP,1608 2 SNA
...4 2007-000651 R-CHIP;27Kohm,1%,1/10W,TP,1608 1 SA
...4 2007-000695 R-CHIP;3.3ohm,5%,1/10W,TP,1608 12 SNA
...4 2007-000828 R-CHIP;39Kohm,1%,1/10W,TP,1608 3 SA
...4 2007-000857 R-CHIP;4.3Kohm,1%,1/10W,TP,1608 2 SNA
...4 2007-000932 R-CHIP;470ohm,5%,1/16W,TP,1005 1 SNA
...4 2007-000939 R-CHIP;47Kohm,1%,1/10W,TP,1608 1 SA
...4 2007-001090 R-CHIP;620ohm,1%,1/10W,TP,1608 1 SA
...4 2007-001125 R-CHIP;68Kohm,1%,1/10W,TP,1608 1 SA
...4 2007-001325 R-CHIP;3.3Kohm,5%,1/16W,TP,1005 4 SNA
...4 2007-003015 R-CHIP;2.2ohm,5%,1/16W,TP,1005 1 SNA
...4 2007-003112 R-CHIP;27ohm,5%,1/16W,TP,1005 1 SNA
...4 2007-007107 R-CHIP;100Kohm,1%,1/16W,TP,1005 2 SNA
...4 2007-007132 R-CHIP;15Kohm,1%,1/16W,TP,1005 1 SA
...4 2007-007135 R-CHIP;18Kohm,1%,1/16W,TP,1005 1 SNA
...4 2007-007139 R-CHIP;47Kohm,1%,1/16W,TP,1005 1 SA
...4 2007-007142 R-CHIP;10Kohm,1%,1/16W,TP,1005 6 SNA
...4 2007-007189 R-CHIP;9.1ohm,5%,1/16W,TP,1005 4 SA
...4 2007-007306 R-CHIP;100ohm,1%,1/16W,TP,1005 15 SNA
...4 2007-007311 R-CHIP;22Kohm,1%,1/16W,TP,1005 1 SA
...4 2007-007312 R-CHIP;20Kohm,1%,1/16W,TP,1005 3 SA
...4 2007-007314 R-CHIP;5.6Kohm,1%,1/16W,TP,1005 1 SA
...4 2007-007318 R-CHIP;1Kohm,1%,1/16W,TP,1005 9 SNA
...4 2007-007470 R-CHIP;7.5Kohm,1%,1/16W,TP,1005 2 SNA
...4 2007-007517 R-CHIP;240ohm,1%,1/16W,TP,1005 1 SNA
...4 2007-007698 R-CHIP;5.1Kohm,1%,1/16W,TP,1005 2 SNA
...4 2007-007766 R-CHIP;2Kohm,1%,1/16W,TP,1005 12 SNA
ANNEX-9
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
...4 2007-007797 R-CHIP;44.2ohm,1%,1/10W,TP,1608 1 SA
...4 2007-007942 R-CHIP;1Mohm,1%,1/16W,TP,1005 1 SNA
...4 2007-008133 R-CHIP;56.2Kohm,1%,1/10W,TP,1608 2 SA
...4 2007-008199 R-CHIP;1.18Kohm,1%,1/10W,TP,1608 5 SNA
...4 2007-008391 R-CHIP;6.34Kohm,1%,1/16W,TP,1005 2 SA
...4 2007-008649 R-CHIP;220ohm,1%,1/16W,TP,1005 1 SNA
...4 2011-001449 R-NETWORK;22ohm,5%,1/16W,L,4P,TP,1010 7 SA
...4 2011-001506 R-NETWORK;10Kohm,5%,1/16W,L,CHIP,4P,TP,1 2 SNA
...4 2011-001527 R-NETWORK;4.7Kohm,5%,1/16W,L,CHIP,4P,TP, 3 SNA
...4 2011-001587 R-NETWORK;100ohm,5%,1/16W,L,CHIP-V,4P,TP 1 SNA
...4 AD480 2203-000233 C-CER,CHIP;0.1nF,5%,50V,C0G,TP,1005 3 SA
...4 AD480 2203-000278 C-CER,CHIP;0.01nF,0.5pF,50V,C0G,TP,1005 3 SA
...4 AD480 2203-000330 C-CER,CHIP;0.012nF,5%,50V,C0G,TP,1005 1 SA
...4 AD480 2203-000425 C-CER,CHIP;0.018nF,5%,50V,C0G,TP,1005 2 SA
...4 AD480 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,TP,1005 6 SA
...4 AD480 2203-000489 C-CER,CHIP;2.2nF,10%,50V,X7R,TP,1005 3 SA
...4 AD480 2203-000714 C-CER,CHIP;3.3nF,10%,50V,X7R,TP,1005 12 SA
...4 AD480 2203-001124 C-CER,CHIP;0.68nF,10%,50V,X7R,TP,1005 12 SA
...4 AD480 2203-001634 C-CER,CHIP;33nF,10%,50V,X7R,TP,1608 1 SNA
...4 AD480 2203-002285 C-CER,CHIP;10nF,10%,50V,X7R,TP,1005 7 SNA
...4 AD480 2203-002711 C-CER,CHIP;100nF,10%,25V,X7R,TP,1608 1 SA
...4 AD480 2203-003039 C-CER,CHIP;0.008nF,0.25pF,50V,C0G,TP,100 2 SNA
...4 AD480 2203-005083 C-CER,CHIP;220nF,10%,50V,X7R,TP,1608,0.8 6 SA
...4 AD480 2203-005221 C-CER,CHIP;15nF,10%,50V,X7R,TP,1608 1 SNA
...4 AD480 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608 32 SNA
...4 AD480 2203-005344 C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,0.5T 6 SNA
...4 AD480 2203-005565 C-CER,CHIP;1nF,5%,50V,C0G,TP,1608 1 SA
...4 AD480 2203-005968 C-CER,CHIP;4.7nF,10%,50V,X7R,TP,1005,0.5 2 SNA
...4 AD480 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,TP,1005 47 SA
...4 AD480 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,TP,1005,0.5 124 SNA
...4 AD480 2203-006307 C-CER,CHIP;1000nF,10%,25V,X5R,TP,2012 1 SNA
...4 AD480 2203-006348 C-CER,CHIP;1000nF,10%,25V,X5R,TP,1608,0. 5 SA
...4 AD480 2203-006562 C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005 26 SNA
...4 AD480 2203-006741 C-CER,CHIP;470nF,10%,25V,X5R,TP,1608,0.8 1 SNA
...4 AD480 2203-006824 C-CER,CHIP;4700nF,10%,10V,X5R,TP,1608 3 SNA
...4 AD480 2203-006842 C-CER,CHIP;0.47nF,5%,50V,C0G,TP,1005 2 SNA
...4 AD480 2203-006844 C-CER,CHIP;470nF,10%,10V,X5R,TP,1005 5 SA
...4 AD480 2203-006890 C-CER,CHIP;10000nF,20%,6.3V,X5R,TP,1608 13 SNA
...4 AD480 2203-007240 C-CER,CHIP;22000nF,20%,6.3V,X5R,TP,1608( 8 SA
...4 AD480 2203-007269 C-CER,CHIP;22000nF,20%,10V,X5R,TP,2012(2 23 SA
...4 AD480 2203-007306 C-CER,CHIP;10000nF,10%,25V,X5R,TP,2012,1 12 SNA
...4 AD480 2203-007513 C-CER,CHIP;10000nF,10%,10V,X5R,TP,1608,0 30 SA
...4 AD480 2203-007544 C-CER,CHIP;100nF,10%,50V,X7R,TP,1005,0.5 3 SA
...4 2402-001398 C-AL,SMD;220uF,20%,35V,TP,8X10 6 SA
...4 2503-001051 C-NETWORK;100nFx4,20%,16V,2012 1 SA
...4 2703-003135 INDUCTOR-SMD;4.7uH,20%,6965,0.04Ohm,7000 2 SNA
...4 2703-004724 INDUCTOR-SMD;8.2uH,20%,5050,4mm,0.072Ohm 12 SA
ANNEX-10
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
...4 2703-005191 INDUCTOR-SMD;1.5uH,20%,6060,4.5,0.02ohm, 2 SA
...4 2801-000102 CRYSTAL-SMD;12MHz,30ppm,12pF,100ohm,TP 1 SA
...4 2801-003856 CRYSTAL-SMD;0.032768MHz,20ppm,28-ACP,7pF 1 SNA
...4 2801-004813 CRYSTAL-SMD;24MHz,50ppm,8pF,100ohm,TP 1 SA
...4 2801-005419 CRYSTAL-SMD;156.25MHz,50ppm,SMD,2pF,50Oh 1 SA
...4 3301-000314 BEAD-SMD;120ohm,1608,TP,120ohm/100MHz 5 SNA
...4 3301-002039 BEAD-SMD;26ohm,1608,TP 55 SA
...4 3601-001829 FUSE-SURFACE MOUNT;32V,6A,FAST-ACTING,Ad 3 SA
...4 3708-003073 CONNECTOR-FPC/FFC/PIC;51P,0.5mm,SMD,AU,N 1 SA
...4 3710-003901 SOCKET-INTERFACE;34P,2R,0.5mm,SMD-A,AU,B 1 SA
...4 3711-007741 CONNECTOR-HEADER;BOX,14P,2R,2.0mm,ANGLE, 1 SA
...4 EH01 3711-007838 HEADER-BOARD TO CABLE;BOX,6P,1R,1.25mm,S 1 SA
...4 EH01 3711-008488 HEADER-BOARD TO CABLE;BOX,14P,2R,2mm,ANG 1 SA
...4 EH01 3711-008659 HEADER-BOARD TO CABLE;BOX,16P,2R,2mm,ANG 1 SA
...4 EH01 3711-008913 HEADER-BOARD TO CABLE;BOX,24P,2R,2.0mm,S 1 SNA
...4 3722-003457 JACK-USB;4P/1C,NI,BLK,A 1 SA
...4 BN41-02328A PCB MAIN;FR-4,4,1.2T,160*123,1 1 SNA
...4 BN97-09485B ASSY MICOM-SUB;T-HKPDEUS,JS9000,EUROPE,W 1 SNA
....5 0903-002079 IC-MICROCONTROLLER;61P809-RG48AWT,LQFP 4 1 SA
...4 BN97-09486A ASSY MICOM-SPI;HAWK_N SPI,JS9000,W25Q128 1 SNA
....5 1107-002210 IC-NOR FLASH;W25Q128FVSIG,128Mbit,128Mx1 1 SA
1 BN91-14657B ASSY SHIELD;JS9K,48" 1 SNA
0.2 SCREW 6001-003016 SCREW-MACHINE;PWH,+,M3.0,L5.0,ZPC(WHT),S 23 SA
0.2 SCREW 6003-001206 SCREW-TAPTYPE;BH,+,B,M3,L4,BLK,SWRCH18A 4 SA
0.2 BN02-00102B TAPE-FILAMENT;#8917,0.15,25,50,WHITE 0 SNA
0.2 EC13 BN39-02006B LEAD CONNECTOR;48JQ9000,Lead Connector*, 1 SA
0.2 EC13 BN39-02009C LEAD CONNECTOR;JS9000 48",Lead Connector 1 SA
0.2 EC13 BN39-02010A LEAD CONNECTOR;55JQ9000,Lead Connector*, 1 SA
0.2 EC13 BN39-02035A LEAD CONNECTOR;48JQ9000,Lead Connector*, 1 SA
0.2 P001A BN44-00814A DC VSS-LED TV PD BD;L48EM8A_FSM,L48EM8A_ 1 SA
0.2 P001A BN44-00817A DC VSS-LED TV PD BD;L65EM8NC_FSM,L65EM8N 1 SA
0.2 NW01 BN59-01194D NETWORK;11ac Combo,Internal WiFi,USB 2.0 1 SA
0.2 BN95-02198A ASSY COVER FRAME SMT-BOTTOM;JS9000,48",L 1 SA
..3 0203-001269 TAPE-OPP MASKING;#301,T0.06,W75,L50000,N 0 SNA
..3 BN01-00160A TARGET-CHROMIUM-CY;Chromium target,99.95 0 SNA
..3 BN01-00161A TARGET-CHROMIUM-PL;chromium target,over 1 SNA
..3 BN02-00353A COATING-AFS;SSVD-39,2%,1~10 cps,1.78 6 SNA
..3 BN63-13314A COVER-FRAME, BOT;JS8000 48",PC+ABS+MF17% 1 SNA
...4 0103-010339 RESIN PC ABS;HRM1530D/BK00749,Black,BK00 200 SNA
..3 BN63-13318A COVER-DECO, BOT-SIDE;JS9000 48",PC,V2 2 SNA
..3 BN63-13324A COVER-DECO, BOT-C;JS9000 48",PC,V2 1 SNA
...4 0103-010379 RESIN PC;SC-1220R/LD0204,BLACK,BK0115,V2 15 SNA
..3 BN68-03920A LABEL BOX;All Monitor,ART-PAPER 100G,WHT 1 SNA
..3 BN69-10522H P/TRAY;-,305,501,160,PAPER,-,-,-,TRAY 48 1 SNA
..3 BN69-10523E BOX UNIT-SMT;48"-50" SMT DECORATION,PAPE 1 SNA
..3 BN69-10617S PACKING SHEET;48" 6500 INHOUSE,HDPE,PE F 1 SNA
0.2 BN96-34997A ASSY SPEAKER P-N8.5K 48INCH;6ohm,12pin,1 1 SA
ANNEX-11
ANNEX. Exploded View & Part List
