Samsung UN40D6500 Guide

E-MANUAL
Thank you for purchasing this Samsung product.
To receive more complete service, please register
your product at
www.samsung.com/register
Model _____________ Serial No. _____________

Contents
Channel Menu
• Using the INFO button (Now & Next Guide) 1
• Using the Channel Menu 2
• Using the Favorites Channels 14
• Memorizing Channels 16
Basic Features
• Changing the Preset Picture Mode 20
• Adjusting Picture Settings 21
• Changing the Picture Size 22
• Changing the Picture Options 26
• Setting up the TV with Your PC 36
• Changing the Preset Sound Mode 40
• Adjusting Sound Settings 41
• Selecting the Sound Mode t51
Preference Features
• Connecting to a Wired Network 52
• Connecting to a Wireless Network 62
• Setting the Time 86
• Locking Programs 94
• Economical Solutions 96
• Picture In Picture (PIP) 99
• Other Features 102
• Support Menu 110
Advanced Features
• Using the 3D function 117
• Getting Started with Smart Hub 127
• Setting up Smart Hub 141
• Using the Smart Hub 156
• Connecting a USB Device 157
• Connecting to the PC through network 158
• Recorded TV for LED 6500 series 166
• Videos 181
• Music 188
• Photos 192
• Smart Hub - Additional Function 194
• Using the Samsung Apps 201
• Troubleshooting for SMART HUB 207
• AllShare™ 214
• Setting Up AllShare™ 216
• Anynet+ (HDMI-CEC) 220
• Setting Up Anynet+ 224
• Switching between Anynet+ Devices 225
• Listening through a Receiver 226
• Troubleshooting for Anynet+ 227
Other Information
• TroubleShooting 230
• Anti-theft Kensington Lock 244
• License 246

▶
English
Channel Menu
❑Using the INFO button (Now & Next Guide)
The display identifies the current channel and the status of certain audio-video
settings. The Now & Next guide shows daily TV program information for each
channel according to the broadcasting time.
●Scroll l, rto view information for a desired program while watching the current
channel.
●Scroll u, dto view information for a desired program while watching the
current channel.
●The displayed image may differ depending on the model.
DESVENTURAS EM SERIE (HD) a Information
Mon, 29 Sep 10:15 pm
10:06 pm - 12:10 am
Globo HD
DTV Air
5

◀
◀
▶
English
❑Using the Channel Menu
Press the SMART HUB button to select the
menu you want to use. Each screen will be
displayed.
■Guide
The EPG (Electronic Program Guide) information is provided by broadcasters.
Using program schedules provided by broadcasters, you can specify programs
you want to watch in advance so that the channel automatically changes to the
selected program channel at the specified time. Program entries may appear blank
or out of date depending on a channel status.
●The displayed image may differ depending on the
model.
Recommended
Search
Favorites VideosChannel
Photos Schedule ManagerMusic Source
Guide Recorded TV Web Browser
aLogin bSort by {Edit Mode }Settings

◀ ▶
English
NUsing the operation buttons with the Guide.
●aRed (Schedule Mgr): Displays
the Schedule Manager.
●bGreen (-24 Hours): Viewing the
list of program to be broadcasted
before 24 hours.
●{Yellow (+24 Hours): Viewing the
list of program to be broadcasted
after 24 hours.
●}Blue (CH Mode): Set the desired
channel mode.
●The displayed image may differ depending on the model.
aSchedule Mgr b-24 Hours {+24 Hours }CH Mode `Information kPage ESchedule
DTV Air 5 Globo HD
TELA QUENTE (HD)
10:05 pm - 12:10 pm
10
DESVENTURAS EM SERIE (HD)
Today 10:00 pm - 11:00 pm 11:00 pm - 12:00 pm
Guide Fri, 1 Jan 2:10 am
Channel View - All
Programs resume at 06:00
Home and...
No Information
QVC Selection
No Information
4 Globo HD
5 DiscoveryH&L
6 TV GloboSD
7 price-drop.tv
8 QVC
9 R4DTT
Tine Team
Fiv...No Information Dark Angel
American Chopper

◀
◀
▶
English
●`(Information): Displays details of the selected program.
●k(Page): Move to next or previous page.
●E (Watch / Schedule)
–When selecting the current programe, you can watch the selected
programe.
–When selecting the future programe, you can reserve to watch the selected
programe. To cancel the schedule, press the ENTEREbutton again and
select Cancel Schedules.

◀ ▶
English
■Schedule Manager
OSMART HUB →Schedule Manager →ENTERE
You can view, modify or delete a channel you have reserved to watch.
Using the Timer Viewing
You can set a desired channel to be displayed automatically at the intended time. Set
the current time first to use this function.
1. Press the ENTEREbutton to add manual booking.
2. Press the lor rbutton to select the Timer Viewing.

◀
◀
▶
English
3. Press the l/ r/ u/ dbuttons to set the Antenna, Channel, Repeat or Start
Time.
●Antenna: Select the desired broadcasting signal.
●Channel: Select the desired channel.
●Repeat: Select Once, Manual, Sat~Sun, Mon~Fri or Everyday to set at your
convenience. If you select Manual, you can set the day you want.
NThe cindicates the date you’ve selected.

◀ ▶
English
●Date: you can set the desired date.
NIt is available when you select Once in Repeat.
●Start Time: You can set the start time you want.
NOnly memorized channels can be reserved.
NOn the Information screen, you can change or cancel a reserved information.
●Cancel Schedules: Cancel a show you have reserved to watch.
●Edit: Change a show you have reserved to watch.
●Return: Return to the previous screen.

◀
◀
▶
English
■Channel List
You can view channel information, All, TV,
Radio, Data/Other, Analog or Favorites 1-5.
OWhen you press the CH LIST button on
the remote control, Channel List screen
will be displayed at once.
●All: Shows all currently available channels.
●Favorites: Shows all favorite channels
when Favorites is set.
NIf you want to view favorite channels you added, press the CH LIST button
and use the lor r(CH Mode) button to move Favorites 1-5.
●The displayed image may differ depending on the
model.
No Information
2 FGHIJK
3 LMNOP
2 -----(Air)
1 ABCDE
4 -----(Air)
6 -----(Air)
8 -----(Air)
10 -----(Air)
13 -----(Air)
14 -----(Air)
28 -----(Air)
Channel List
All
Air aAntenna {Program View LCH Mode EWatch kPage

◀ ▶
English
NUsing the operation buttons with the Channel List.
●aRed (Antenna): Switches to Air or Cable.
●{Yellow (Program View / Channel View): Displays the program when digital
channel is selected. Returns to the channel view.
●lr (CH Mode / Channel): Move to the Favorites when Favorites is set.
●E(Watch / Information): Watches the channel you select. /
Displays details of the selected program.
●k(Page): Move to next or previous page.
Channel Status Display Icons
Icon Operations
aAn analog channel.
)A reserved program.

◀
◀
▶
English
How to use Timer Viewing in Channel List (digital channels only)
When you set the Timer Viewing in Channel List, you can only set the program in
Program View.
1. Press the CH LIST button, then select a desired digital channel.
2. Press the {(Program View) button.
3. Press the u/ dbuttons to select the desired program, then press the E
(Information) button.
4. Select Timer Viewing, then press the ENTEREbutton when done.
NIf you want to cancel Timer Viewing, follow steps 1 through 3. Select Cancel
Schedules.

◀ ▶
English
■Channel
OSMART HUB →Channel →ENTERE
Delete added channels or set favorites
channels and use the program guide for digital
broadcasts. Select a channel in the All, TV,
Radio, or Data/Other screen. Change the
view mode, antenna, or channel settings using
the menus in the top right corner of the screen.
●Antenna: Toggle among Air or Cable.
●Sort: Toggles between sorting favorites by Channel Name and sorting by
Channel Number.
●Edit Mode: Delete channels assigned to Favorites.
●Select All: Select all the channels.
NIf you want to change a channel mode, select a channel mode among the All,
TV, Radio, or Data/Other. The selected screen will appear.
●The displayed image may differ depending on the
model.
2 ABCDE
3 FGHIJK
4 -----(Air)
5 -----(Air)
6 -----(Air)
7 -----(Air)
8 -----(Air)
9 -----(Air)
10 -----(Air)
11 LMNOP
14 -----(Air)
15 -----(Air)
16 -----(Air)
18 -----(Air)
19 -----(Air)
17 -----(Air)
12 -----(Air)
13 -----(Air)
TV
Channel
All channels

◀
◀
▶
English
NUsing the TOOLS button with the Channel
●Delete: Delete a channel to display the channels you want.
●Edit Favorites: Set channels you watch frequently as favorites.
NRefer to “Using the Favorite Channels” for details on how to assign a
channel to favorite.
●Channel Name Edit (analog channels only): Assign your own channel
name.
●Upcoming Program (digital channels only): View details on the program
being aired on a selected digital channel.
●Edit Channel Number (digital channels only): Edit the number by pressing
the number buttons desired.
NThis function may not be supported depending on the region.

◀ ▶
English
●Lock /Unlock: Lock a channel so that the channel cannot be selected and
viewed.
NNOTE
●This function is available only when the Channel Lock is set to On.
●The PIN input screen appears. Enter your 4-digit PIN, the default of
which is “0-0-0-0”. Change the PIN using the Change PIN option.
Channel Status Display Icons
Icon Operations
aAn analog channel.
cA channel selected.
FA channel set as a Favorites 1-5.
\A locked channel.

◀
◀
▶
English
❑Using the Favorites Channels
■Favorites
OSMART HUB →Favorites →ENTERE
View all of your favorite channels. If you want to change the favorite group among
Favorites 1-5, move the cursor to group name. And then press the ENTERE
button to change the group you want.

◀ ▶
English
How to assign a channel to favorite
1. On the Channel screen, Select Edit Mode. The Edit Mode screen will
appear.
2. Press the l/ r/ u/ dbutton to select a channel you want to add and press
the ENTEREbutton.
NIf you want to select all channels, press the l/ r/ u/ dbuttons to select
Select All.
NThe cmark appears to the left of the selected files.
3. When done, press the dbutton to select Edit Favorites.
4. Add a channel in the favorite groups you want among 1, 2, 3, 4 and 5.
NOne or more groups can be selected.
5. After you have changed the settings, the channel list for each group can be
viewed in favorites.
NThe “F” symbol will be displayed and the channel will be set as a favorite.

◀
◀
▶
English
❑Memorizing Channels
OMENUm→Channel →ENTERE
■Antenna (Air / Cable)t
Before your television can begin memorizing the available channels, you must
specify the type of signal source that is connected to the TV (i.e. an Air or a Cable
system).

◀ ▶
English
■Auto Tuning
Scan for all channels with active broadcast stations and stores them in the TV.
NIf the antenna is connected to ANT 2 IN (CABLE), select Cable and if it is
connected to ANT 1 IN (AIR), select Air.
NIf a channel is locked using the Channel Lock function, the PIN input window
appears.
NSet the auto tuning search options.
Air mode: Digital / Analogue
Cable mode: Analogue
Cable mode, you can select the Analog Cable System among STD, HRC,
and IRC by pressing the u, d, lor rbutton, then press the ENTERE
button.

◀
◀
▶
English
■Digital Manual Tuning
Scans for a channel manually and stores in the TV
NIf a channel is locked using the Channel Lock function, the PIN input window
appears.
1. Press the u/ d/ l/ rbutton to select New.
2. Set the Channel, Frequency.
3. Press the dbutton to select Search. When scanning has finished a
channel is updated in the channel list.
NIf you want to rescan a values of digital channel, select a digital channel, and
then select Rescan. You can edit a values of selected digital channel.
