Samsung UN KS8500F Series User manual

SUHD TV
SERVICEManual
TFT-LED TV Contents
1. Precautions
2. Product specications
3. Disassembly and Reassembly
4. Troubleshooting
5. Wiring Diagram
UN**KS8500F
Chassis : UWQ60
Model : UN49KS8500F
UN55KS8500F
UN65KS8500F

Contents
1. Precautions...................................................................................................................1-1
1-1. Safety Precautions ..............................................................................................................1-1
1-1-1. Warnings...................................................................................................................1-1
1-1-2. Servicing the LED TV ...............................................................................................1-1
1-1-3. Fire and Shock Hazard.............................................................................................1-1
1-1-4. Product Safety Notices .............................................................................................1-2
1-2. Servicing Precautions..........................................................................................................1-3
1-2-1. General Servicing Precautions .................................................................................1-3
1-3. Static Electricity Precautions ...............................................................................................1-4
1-4. Installation Precautions .......................................................................................................1-5
2. Product Specications.................................................................................................2-1
2-1. Product information .............................................................................................................2-1
2-2. Detail Specication..............................................................................................................2-2
2-3. Other Specication ............................................................................................................2-14
2-4. NEW Key Features............................................................................................................2-15
2-4-1. 16" New UI..............................................................................................................2-15
2-4-2. Smart Things (IoT Dongle required) .......................................................................2-16
2-5. Smart Control ....................................................................................................................2-17
2-5-1. Voice Interaction .....................................................................................................2-18
2-5-2. 123 Key ..................................................................................................................2-18
2-5-3. EXTRA Key.............................................................................................................2-19
2-6. HDMI Color........................................................................................................................2-20
2-6-1. HDMI UHD Color ....................................................................................................2-20
2-6-2. HDMI Black Level ...................................................................................................2-20
2-7. Supported Formats............................................................................................................2-21
2-7-1. Supported image formats and resolutions..............................................................2-21
2-7-2. Supported music formats and codecs ....................................................................2-21
2-7-3. Supported video codecs .........................................................................................2-22
2-8. Accessories .......................................................................................................................2-23
3. Disassembly and Reassembly ....................................................................................3-1
3-1. Disassembly and Reassembly ............................................................................................3-1
4. Troubleshooting ...........................................................................................................4-1
4-1. Previous Check ..................................................................................................................4-1
4-2. How to Check Fault Symptom.............................................................................................4-2
4-2-1. Power .......................................................................................................................4-2
4-2-2. Video.........................................................................................................................4-7
4-2-3. Audio.......................................................................................................................4-12
4-2-4. Network...................................................................................................................4-13
4-2-5. Smart Hub ..............................................................................................................4-14
4-2-6. Bluetooth / WiFi Module .........................................................................................4-16
4-3. Factory Mode.....................................................................................................................4-17
4-4. Factory Mode Adjustments................................................................................................4-21
4-4-1. Detail Factory Option..............................................................................................4-21
4-4-2. Factory Data ...........................................................................................................4-24

4-5. RS-232C............................................................................................................................4-37
4-5-1. RS232C Control ....................................................................................................4-37
4-6. AV Control Tabe.................................................................................................................4-38
4-7. Updating the TV’s Software...............................................................................................4-46
5. Wiring Diagram.............................................................................................................5-1
5-1. Layout..................................................................................................................................5-1
5-2. Wiring Diagram....................................................................................................................5-2
5-2-1. 49" / 55" ....................................................................................................................5-2
5-2-2. 65" ............................................................................................................................5-2
5-3. Connector............................................................................................................................5-3
5-3-1. Main Board ...............................................................................................................5-3
5-3-2. One connect Board...................................................................................................5-8
5-3-3. SMPS Board...........................................................................................................5-10
5-4. Cable .................................................................................................................................5-12
ANNEX. Exploded View & Part List [UN49KS8500FXZA FA01] ......................... ANNEX-1
1-1. Exploded View.......................................................................................................... ANNEX-1
1-1-1. Parts List........................................................................................................ ANNEX-2
1-2. ONE CONNECT Exploded View .............................................................................. ANNEX-3
1-2-1. Parts List........................................................................................................ ANNEX-3
2-1. Electrical Parts List................................................................................................... ANNEX-4
ANNEX. Exploded View & Part List [UN55KS8500FXZA FA01] ......................... ANNEX-1
1-1. Exploded View.......................................................................................................... ANNEX-1
1-1-1. Parts List........................................................................................................ ANNEX-2
1-2. ONE CONNECT Exploded View .............................................................................. ANNEX-3
1-2-1. Parts List........................................................................................................ ANNEX-3
2-1. Electrical Parts List................................................................................................... ANNEX-4
ANNEX. Exploded View & Part List [UN65KS8500FXZA FA01] ......................... ANNEX-1
1-1. Exploded View.......................................................................................................... ANNEX-1
1-1-1. Parts List........................................................................................................ ANNEX-2
1-2. ONE CONNECT Exploded View .............................................................................. ANNEX-3
1-2-1. Parts List........................................................................................................ ANNEX-3
2-1. Electrical Parts List................................................................................................... ANNEX-4

This Service Manual is a property of Samsung Electronics Co.,Ltd.
Any unauthorized use of Manual can be punished under applicable
International and/or domestic law.
© 2016 Samsung Electronics Co.,Ltd.
All rights reserved.
Printed in Korea

Follow these safety, servicing and ESD precautions to prevent damage and to protect against potential hazards such as
electrical shock.
1-1-1. Warnings
WARNING
For continued safety, do not attempt to modify the circuit board.
Disconnect the AC power and DC power jack before servicing.
1-1-2. Servicing the LED TV
When servicing the LED TV, Disconnect the AC line cord from the AC outlet.1.
It is essential that service technicians have an accurate voltage meter available at all times. Check the calibration of this2.
meter periodically.
1-1-3. Fire and Shock Hazard
Before returning the monitor to the user, perform the following safety checks:
Inspect each lead dress to make certain that the leads are not pinched or that hardware is not lodged between the1.
chassis and other metal parts in the monitor.
Inspect all protective devices such as nonmetallic control knobs, insulating materials, cabinet backs, adjustment and2.
compartment covers or shields, isolation resistorcapacitor networks, mechanical insulators, etc.
Leakage Current Hot Check:3.
DEVICE
UNDER
TEST
(READING SHOULD)
NOT BE ABOVE 0.5mA LEAKAGE
CURRENT
TESTER
TEST ALL
EXPOSED METAL
SURFACES
2-WIRE CORD
ALSO TEST WITH
PLUG REVERSED
(USING AC ADAPTER
PLUG AS REQUIRED)
EARTH
GROUND
WARNING
Do not use an isolation transformer during this test.
Use a leakage current tester or a metering system that complies with American National Standards
Institute (ANSI C101.1, Leakage Current for Appliances), and Underwriters Laboratories (UL
Publication UL1410, 59.7).
With the unit completely reassembled, plug the AC line cord directly into a 120V AC outlet. With the unit’s AC switch rst 4.
in the ON position and then OFF, measure the current between a known earth ground (metal water pipe, conduit, etc.)
and all exposed metal parts, including: metal cabinets, screwheads and control shafts.
The current measured should not exceed 0.5 milliamp.
Reverse the power-plug prongs in the AC outlet and repeat the test.
1-1
1. Precautions
1. Precautions
1-1. Safety Precautions

1-2
1. Precautions
1-1-4. Product Safety Notices
Some electrical and mechanical parts have special safetyrelated characteristics which are often not evident from visual
inspection. The protection they give may not be obtained by replacing them with components rated for higher voltage,
wattage, etc. Parts that have special safety characteristics are identied by on schematics and parts lists. A substitute
replacement that does not have the same safety characteristics as the recommended replacement part might create
shock, re and/or other hazards. Product safety is under review continuously and new instructions are issued whenever
appropriate.

WARNING
An electrolytic capacitor installed with the wrong polarity might explode.
CAUTION
Before servicing units covered by this service manual, read and follow the Safety Precautions section of
this manual.
NOTE
If unforeseen circumstances create conict between the following servicing precautions and any of the
safety precautions, always follow the safety precautions.
1-2-1. General Servicing Precautions
Always unplug the unit’s AC power cord from the AC power source and disconnect the DC Power Jack before1.
attempting to: (a) remove or reinstall any component or assembly, (b) disconnect PCB plugs or connectors, (c) connect
a test component in parallel with an electrolytic capacitor.
Some components are raised above the printed circuit board for safety. An insulation tube or tape is sometimes used.2.
The internal wiring is sometimes clamped to prevent contact with thermally hot components. Reinstall all such elements
to their original position.
After servicing, always check that the screws, components and wiring have been correctly reinstalled. Make sure that3.
the area around the serviced part has not been damaged.
Check the insulation between the blades of the AC plug and accessible conductive parts (examples: metal panels, input4.
terminals and earphone jacks).
Insulation Checking Procedure: Disconnect the power cord from the AC source and turn the power switch ON. Connect5.
an insulation resistance meter (500 V) to theblades of the AC plug. The insulation resistance between each blade of the
AC plug and accessible conductive parts (see above) should be greater than 1 megohm.
Always connect a test instrument’s ground lead to the instrument chassis ground before connecting the positive lead;6.
always remove the instrument’s ground lead last.
1-3
1. Precautions
1-2. Servicing Precautions

Some semiconductor (solid state) devices can be easily damaged by static electricity. Such components are commonly
called Electrostatically Sensitive Devices (ESD). Examples of typical ESD are integrated circuits and some eld-effect
transistors. The following techniques will reduce the incidence of component damage caused by static electricity.
Immediately before handling any semiconductor components or assemblies, drain the electrostatic charge from your1.
body by touching a known earth ground. Alternatively, wear a discharging wrist-strap device. To avoid a shock hazard,
be sure to remove the wrist strap before applying power to the monitor.
After removing an ESD-equipped assembly, place it on a conductive surface such as aluminum foil to prevent2.
accumulation of an electrostatic charge.
Do not use freon-propelled chemicals. These can generate electrical charges sufcient to damage ESDs.3.
Use only a grounded-tip soldering iron to solder or desolder ESDs.4.
Use only an anti-static solder removal device. Some solder removal devices not classied as “anti-static” can generate 5.
electrical charges sufcient to damage ESDs.
Do not remove a replacement ESD from its protective package until you are ready to install it. Most replacement ESDs6.
are packaged with leads that are electrically shorted together by conductive foam, aluminum foil or other conductive
materials.
Immediately before removing the protective material from the leads of a replacement ESD, touch the protective material7.
to the chassis or circuit assembly into which the device will be installed.
CAUTION
Be sure no power is applied to the chassis or circuit and observe all other safety precautions.
Minimize body motions when handling unpackaged replacement ESDs. Motions such as brushing clothes together, or8.
lifting your foot from a carpeted oor can generate enough static electricity to damage an ESD.
1-4
1. Precautions
1-3. Static Electricity Precautions

For safety reasons, more than a people are required for carrying the product.1.
Keep the power cord away from any heat emitting devices, as a melted covering may cause re or electric shock.2.
Do not place the product in areas with poor ventilation such as a bookshelf or closet. The increased internal temperature3.
may cause re.
Bend the external antenna cable when connecting it to the product. This is a measure to protect it from being exposed4.
to moisture. Otherwise, it may cause a re or electric shock.
Make sure to turn the power off and unplug the power cord from the outlet before repositioning the product. Also check5.
the antenna cable or the external connectors if they are fully unplugged. Damage to the cord may cause re or electric
shock.
Keep the antenna far away from any high-voltage cables and install it rmly. Contact with the highvoltage cable or the 6.
antenna falling over may cause re or electric shock.
When installing the product, leave enough space (0.4m) between the product and the wall for ventilation purposes.7.
A rise in temperature within the product may cause re.
If an equipment is provided with a replaceable battery, and if replacement by an incorrect type could result in an8.
explosion (for example, with some lithium batteries), the following applies:
CAUTION
Risk of explosion if battery is replaced by an incorrect type dispose of used batteries according to•
the instructions.
Do not dispose of batteries in a re.•
Do not short circuit, disassemble or overheat the batteries.•
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent•
type.
Do not be exposed to excessive heat such as sunshine, re or the like.•
1-5
1. Precautions
1-4. Installation Precautions

ANNEX. Exploded View & Part List [UN55KS8500FXZA FA01]
1-1. Exploded View
ANNEX-1
ANNEX. Exploded View & Part List

1-1-1. Parts List
No. Code No. Description & Specication Q’ty SA/SNA Remark
1 BN95-02606A PRODUCT LCD-SDC; CY-XK055FLLV3V/H,KS7500, 1 SA
1-1 BN96-39565A ASSY COVER P-DECORATION; 55KS7500,PC+GF 1 SA
2 BN44-00878A DC VSS-PD BOARD; L55E7_KSM,AC/DC,192W,100 1 SA
3 BN96-39926A ASSY COVER P-STAND TOP RIGHT; 55KS7500,AL 1 SA
4 BN96-39908A ASSY COVER P-REAR; 55KS7500,PC+ABS+GF20 1 SA
5 BN96-39889A ASSY SPEAKER P-FRONT; 6ohm,40W,2.1Ch 1 SA
6 BN59-01239A NETWORK-WLAN CLIENT; WCK730B,USB 2.0,16P, 1 SA
7 BN96-39802C ASSY BOARD P-FUNCTION TACT; KS7000/7500/K 1 SA
8 BN96-39927A ASSY COVER P-STAND TOP LEFT; 55KS7500,ALD 1 SA
9 BN94-10752A ASSY PCB MAIN; 7K 1 SA
10 BN63-15050A COVER-TERMINAL SIDE; 55KS7000,ABS,T2,HB,B 1 SA
ANNEX-2
ANNEX. Exploded View & Part List

1-2. ONE CONNECT Exploded View
1-2-1. Parts List
No. Code No. Description & Specication Q’ty SA/SNA Remark
1 BN96-40188B ASSY COVER P-TOP; 55KS9000,ABS,V-0,BK0008 1 SA
2 BN94-10924A ASSY PCB MISC-ONE CONNECT MINI; Y16 OCM P 1 SA
3 BN63-15074B COVER-BOTTOM; OCM PLUS,PC+ABS,MOLD,V-0 1 SA
ANNEX-3
ANNEX. Exploded View & Part List

Service Bom (SA: SERVICE AVAILABLE, SNA: SERVICE NOT AVAILABLE)
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
UN55KS8500FXZA (FA01)
1 BN90-07963C ASSY W/I;7K 1 SNA
0.2 BN81-08159Z A/S PART SET-ELEC W/I;LED TV ELEC spec-C 1 SNA
0.2 BN81-12184L A/S PART SET-MECH W/I;UKS7500T,U55KT* 1 SNA
1 R001A BN90-07974A ASSY COVER REAR;LED_7K 1 SNA
0.2 R001A BN96-39908A ASSY COVER P-REAR;55KS7500,PC+ABS+GF20%, 1 SA
..3 BN61-13303A HOLDER-COVER;55KS8000,TPV,BK0008,HB 2 SNA
..3 BN63-07556K SHEET-COVER;TOC,PO,W90,L100M,ST-670PO, 2 1 SNA
..3 BN63-10945F SHEET-COVER;Y13 SF-LED,PO,W110,L100M,ST- 1 SNA
..3 R001 BN63-15029A COVER-REAR;55KS7500,PC+ABS+ED20%,MOLD
,V- 1 SNA
..3 AC220 BN63-15198A COVER-CAP;55KS7500,ABS+PMMA,T0.1,HB,BK00 4 SNA
..3 BN64-03528A INLAY-TERMINAL SIDE;55KS7000,PET,T0.125, 1 SNA
..3 BN68-07835A LABEL-STICKER LICENSE;40K5500,PET,0.125, 1 SNA
1 S001A BN90-07982A ASSY STAND;LED_7K 1 SNA
0.2 BN96-39926A ASSY COVER P-STAND TOP RIGHT;55KS7500,AL 1 SA
..3 BN63-15041A COVER-STAND TOP RIGHT;55KS7500,ALDC,MOLD 1 SNA
0.2 BN96-39927A ASSY COVER P-STAND TOP LEFT;55KS7500,ALD 1 SA
..3 6902-002675 BAG PREMIUM;HDPE,T0.03,W300,L250,TRP,REC 1 SNA
..3 RF01 BN61-13669A FOOT-RUBBER;55KS7500,SI,GRAY,T2.5,7*7 2 SNA
..3 BN63-15040A COVER-STAND TOP LEFT;55KS7500,ALDC,MOLD, 1 SNA
..3 BN68-05603A LABEL-E PASS;ART PAPER 90G,W/W 1 SNA
..3 BN69-13618F PAD PACKING;55KS7500,PAPER,T0.03,W300,L4 1 SNA
1 M0017 BN91-17214A ASSY CHASSIS;7K 1 SNA
0.2 M0014 BN94-10752A ASSY PCB MAIN;7K 1 SA
..3 BN62-00816A HEAT SINK-PS;55KS9000,A1050,T6.3,W145,L1 1 SNA
..3 BN63-15050A COVER-TERMINAL SIDE;55KS7000,ABS,T2,HB,B 1 SA
..3 BN97-10625A ASSY SMD;7K 1 SNA
...4 0403-001164 DIODE-ZENER;MMSZ5232B,5.32~5.88V,500mW,S 1 SA
...4 0403-001831 DIODE-ZENER;KDZ12B,12~13.5V,1000mW,SOD-1 1 SA
...4 0403-002014 DIODE-ZENER;KDZ16B,16.2~18.3V,1000mW,SOD 2 SNA
...4 0404-001307 DIODE-SCHOTTKY;SSC54,40V,5000mA,DO-214AB 1 SA
...4 0404-001640 DIODE-SCHOTTKY;SS1060HEWS,60V,1000mA,S
OD 1 SA
...4 0404-001881 DIODE-SCHOTTKY;SS3040-HE,40V,3000mA,SOD- 1 SA
...4 0404-001953 DIODE-SCHOTTKY;MBRA340F-HAF,40V,3000mA,S 3 SA
...4 0406-001628 DIODE-TVS;AOZ8804ADI,6V,1MAV,5A,TP 1 SA
...4 0406-001643 DIODE-TVS;1SMA33AT3G,36.7V,38.65V,40.6V, 1 SNA
...4 0504-000126 TR-DIGITAL;KSR1101,NPN,200mW,4.7K/4.7K,S 2 SA
...4 0505-001844 FET-SILICON;SI4435DDY-T1-GE3,P,30V,-11.4 4 SA
...4 0505-002598 FET-SILICON;AP2317GN,P,20V,-4.2A,0.052oh 1 SA
...4 0505-002660 FET-SILICON;Si2308BDS,N,60V,2.3A,0.156oh 1 SNA
...4 0505-002893 FET-SILICON;AO4801AS,P,30V,-5A,2W,SOIC-8 1 SA
...4 0505-003205 FET-SILICON;DMG4435SSS-13,P,30V,-7.3A,1. 1 SA
ANNEX-4
ANNEX. Exploded View & Part List
2-1. Electrical Parts List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
...4 0505-003264 FET-SILICON;AO4447AL,P,30V,-17A,7mohm,3. 1 SA
...4 0505-003391 FET-SILICON;AOD2922,N,100V,8A,140Mohm,18 1 SA
...4 0505-003397 FET-SILICON;2N7002K,N,60V,0.38A,1.19ohm, 1 SA
...4 1001-001998 IC-ANALOG MULTIPLEX;NX3DV221GM,USB switc 1 SA
...4 1006-001576 IC-DRIVER/RECEIVER;MAX3221ECPWR,TSSOP,16 1 SA
...4 1103-001564 IC-EEPROM;S-24C512CI-J800,512Kbit,64Kx8, 1 SA
...4 1105-002704 IC-DDR4 SDRAM;K4F8E304HB-MGCH,LPDDR4-
SDR 3 SA
...4 1201-000166 IC-OP AMP;LM358,SOP,ST,8P,150MIL,DUAL,10 1 SA
...4 1201-004003 IC-AUDIO AMP;TAS880021,TSSOP,48P,12.5x6. 2 SA
...4 1203-004364 IC-VOL. DETECTOR;RT9818C-42PV,SOT-23,3P, 1 SA
...4 1203-008102 IC-POSI.FIXED REG.;S-13A1D12-E800,HSOP,8 1 SNA
...4 1203-008105 IC-POSI.FIXED REG.;S-13A1D33-E800,HSOP,8 1 SNA
...4 1203-008391 IC-DC/DC CONVERTER;AOZ1269QI-02,QFN-23L, 1 SA
...4 1203-008392 IC-VOL. DETECTOR;S-6414AAB-L800X,TSOT-23 1 SA
...4 1203-008664 IC-DC/DC CONVERTER;RT6935BGQW,WQFN,56,7x 1 SA
...4 1203-008667 IC-DC/DC CONVERTER;RT6936A,WQFN,40,6x6mm 1 SA
...4 1203-008732 IC-DC/DC CONVERTER;SYD104ADC,TSOT-23,6,3 1 SA
...4 1203-008733 IC-DC/DC CONVERTER;AOZ1236QI-02,QFN,23,4 1 SA
...4 1203-008735 IC-DC/DC CONVERTER;AOZ1267QI-02,QFN,23,4 1 SA
...4 1204-003679 IC-DECODER;SDP1501,FCPBGAH,1230P,35*35mm 1 SA
...4 1205-004822 IC-SWITCH;TPS22965DSGR,SON,8P,2x2x0.75mm 3 SNA
...4 1205-005554 IC-REPEATER;TMDS181,VQFN,48P,7x7mm,PLAST 1 SA
...4 IS01 1209-002183 IC-SENSOR;S-5851AAA-M6T1U,SOT,6Z30,2.9x1 1 SA
...4 1404-001731 THERMISTOR-NTC;33Kohm,4050K,1mW/C,TP,1.6 2 SNA
...4 1405-001271 VARISTOR;35V,20Vdc,5A,1.0x0.5mm,TP,100V, 10 SA
...4 1405-001381 VARISTOR;11V,8Vdc,30A,1.6x0.8mm,TP,25V,5 3 SA
...4 1405-001382 VARISTOR;24.5V,16VDC,120A,2.0x1.25mm,TP, 2 SA
...4 2007-000039 R-CHIP;0ohm,1%,1/10W,TP,1608 9 SA
...4 2007-000040 R-CHIP;150ohm,1%,1/10W,TP,1608 1 SNA
...4 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 2 SA
...4 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 11 SA
...4 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 2 SA
...4 2007-000146 R-CHIP;6.8Kohm,5%,1/16W,TP,1005 1 SNA
...4 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 SA
...4 2007-000736 R-CHIP;30Kohm,1%,1/10W,TP,1608 1 SA
...4 2007-000932 R-CHIP;470ohm,5%,1/16W,TP,1005 1 SA
...4 2007-000939 R-CHIP;47Kohm,1%,1/10W,TP,1608 1 SA
...4 2007-001125 R-CHIP;68Kohm,1%,1/10W,TP,1608 2 SA
...4 2007-001292 R-CHIP;33ohm,5%,1/16W,TP,1005 12 SA
...4 2007-001298 R-CHIP;51ohm,5%,1/16W,TP,1005 8 SNA
...4 2007-002899 R-CHIP;10ohm,1%,1/10W,TP,1608 9 SA
...4 2007-003015 R-CHIP;2.2ohm,5%,1/16W,TP,1005 1 SNA
...4 2007-007131 R-CHIP;13Kohm,1%,1/16W,TP,1005 4 SA
...4 2007-007231 R-CHIP;110Kohm,1%,1/10W,TP,1608 2 SA
...4 2007-007312 R-CHIP;20Kohm,1%,1/16W,TP,1005 12 SA
...4 2007-007313 R-CHIP;6.8Kohm,1%,1/16W,TP,1005 3 SA
ANNEX-5
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
...4 2007-007316 R-CHIP;3.3Kohm,1%,1/16W,TP,1005 2 SNA
...4 2007-007317 R-CHIP;2.2Kohm,1%,1/16W,TP,1005 1 SA
...4 2007-007334 R-CHIP;200Kohm,1%,1/16W,TP,1005 4 SA
...4 2007-007520 R-CHIP;20ohm,1%,1/10W,TP,1608 14 SA
...4 2007-007528 R-CHIP;1.5Kohm,1%,1/16W,TP,1005 7 SA
...4 2007-007627 R-CHIP;16Kohm,1%,1/16W,TP,1005 1 SA
...4 2007-007798 R-CHIP;10ohm,1%,1/16W,TP,1005 10 SA
...4 2007-008136 R-CHIP;36Kohm,1%,1/16W,TP,1005 1 SA
...4 2007-008263 R-CHIP;3Kohm,1%,1/16W,TP,1005 2 SA
...4 2007-008269 R-CHIP;51Kohm,1%,1/16W,TP,1005 1 SA
...4 2007-008298 R-CHIP;49.9ohm,1%,1/16W,TP,1005 13 SA
...4 2007-008391 R-CHIP;6.34Kohm,1%,1/16W,TP,1005 1 SA
...4 2007-008596 R-CHIP;0.1ohm,1%,1/4W,TP,3216 2 SC
...4 2007-009322 R-CHIP;1.3Kohm,1%,1/16W,TP,1005 3 SA
...4 2011-001264 R-NETWORK;10ohm,5%,1/16W,L,CHIP,8P,TP,2. 16 SNA
...4 AD480 2203-000233 C-CER,CHIP;0.1nF,5%,50V,C0G,TP,1005 6 SA
...4 AD480 2203-000278 C-CER,CHIP;0.01nF,0.5pF,50V,C0G,TP,1005 1 SA
...4 AD480 2203-000386 C-CER,CHIP;0.015nF,5%,50V,C0G,TP,1005 3 SA
...4 AD480 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,TP,1005 15 SA
...4 AD480 2203-000489 C-CER,CHIP;2.2nF,10%,50V,X7R,TP,1005 1 SA
...4 AD480 2203-000714 C-CER,CHIP;3.3nF,10%,50V,X7R,TP,1005 6 SA
...4 AD480 2203-002398 C-CER,CHIP;22nF,10%,50V,X7R,TP,1608 1 SNA
...4 AD480 2203-005054 C-CER,CHIP;0.0047nF,0.25pF,50V,NP0,TP,10 2 SA
...4 AD480 2203-006377 C-CER,CHIP;4700nF,10%,25V,X5R,TP,2012 3 SNA
...4 AD480 2203-006698 C-CER,CHIP;1000nF,10%,25V,X7R,TP,1608,0. 7 SA
...4 AD480 2203-006841 C-CER,CHIP;1000nF,10%,16V,X5R,TP,1005 2 SNA
...4 AD480 2203-006844 C-CER,CHIP;470nF,10%,10V,X5R,TP,1005 3 SA
...4 AD480 2203-007176 C-CER,CHIP;10000nF,10%,16V,X5R,TP,2012,1 25 SNA
...4 AD480 2203-008315 C-CER,CHIP;22000nF,20%,25V,X5R,TP,2012,1 4 SA
...4 2409-001240 C-ORGANIC,SMD;33uF,20%,25V,LR,TP,7343(1. 1 SA
...4 2409-001338 C-POLYMER ,CHIP;47uF,20%,6.3V,TP,3.2x1.6 1 SA
...4 2703-003747 INDUCTOR-SMD;22uH,20%,6060,0.135ohm,1300 2 SA
...4 2703-003862 INDUCTOR-SMD;10uH,20%,6060,0.065ohm,1900 3 SA
...4 2703-003913 INDUCTOR-SMD;2.2uH,20%,2520,1.2T,0.116Oh 1 SNA
...4 2703-003937 INDUCTOR-SMD;1uH,20%,7.0x6.47x3.0mm,0.00 3 SA
...4 2703-004724 INDUCTOR-SMD;8.2uH,20%,4T,0.072Ohm,2300m 6 SA
...4 2703-005376 INDUCTOR-SMD;10uH,20%,10x10.7mm,4.0T,0.0 1 SA
...4 2801-004021 CRYSTAL-SMD;24.576MHz,20ppm,28-AAN,12pF, 1 SA
...4 3301-001364 BEAD-SMD;1000ohm,1608,TP,1085ohm/108MHz, 6 SNA
...4 3601-001376 FUSE-SURFACE MOUNT;32V,3A,FAST-ACTING,Hi 1 SNA
...4 3708-003241 CONNECTOR-FPC/FFC/PIC;96P,0.5mm,SMD-A,AU 2 SNA
...4 3711-007587 CONNECTOR-
HEADER;BOX,18P,2R,2mm,ANGLE,SN 1 SA
...4 3711-007741 CONNECTOR-HEADER;BOX,14P,2R,2.0mm,ANGLE, 1 SA
...4 3711-007975 CONNECTOR-HEADER;BOX,10P,1R,1.25mm,SMD-A 1 SA
...4 EH01 3711-008098 HEADER-BOARD TO CABLE;BOX,20P,1R,1.25mm, 1 SNA
...4 3711-009090 CONNECTOR-HEADER;BOX,16P,1R,1.25mm,SMD-A 1 SA
ANNEX-6
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
...4 3711-009106 CONNECTOR-HEADER;BOX,20P,2R,2.0mm,ANGLE, 1 SA
...4 3722-003199 JACK-MODULAR;8P/8C,Y,ANGLE,NONE,AU,1PORT 1 SA
...4 3722-003394 JACK-PHONE;1P/6C,AU,BLK,ANGLE,3.6PI,9x14 1 SA
...4 6302-001376 GASKET-SMD;,,CONDUCTIVE FABRIC,T14,W43,L 6 SNA
...4 BN13-00067B IC-PLD;MAXQ636V-2605+T,9,3.3,1.64,3.6,0t 1 SNA
...4 BN41-02504A PCB-MAIN;KS8000/KS9000,FR-4,4L,1.2T,214x 1 SNA
...4 CB07 BN61-13312B BRACKET-PCB;55KS8000,SK5,0.3,13.7,11.4,S 4 SNA
...4 BN97-10856A ASSY MICOM-SUB;JMMICOM_
TV,UWQ60,W25Q40CL 1 SNA
....5 1107-002226 IC-NOR FLASH;W25Q40CLSSIP,4Mbit,SOIC,8P, 1 SA
...4 BN97-10857A ASSY MICOM-MAIN;T-
JZMAKUC,UWQ60,KLM8G1GE 1 SNA
....5 1107-002362 IC-EMMC;KLM8G1GEND-B031,8GB,64Gb MLC x 1 1 SNA
...4 BN97-10881A ASSY MICOM;TCON,55-SDC-Curved,W25Q80DVSS 1 SNA
....5 1107-002339 IC-NOR FLASH;W25Q80DV,8Mbit,SOP,5.28x5.2 1 SNA
....5 BN46-00508A S/W MICOM;K55ABU0C,SDC,55A1MU*XK,Curved 1 SNA
....5 BN46-00515A S/W MICOM;Jazz M-L,TCON F/W 1 SNA
..3 BN97-10872A ASSY DRM;Jazz M,ATSC,NagSam, MAC, HDCP 1 SNA
...4 BN46-00109H KEY CODE-CERTIFICATION;MAC,TV/AV,General 1 SNA
...4 BN46-00110P KEY CODE-CERTIFICATION;MIRACAST(HDCP2.2) 1 SNA
...4 BN46-00495A KEY CODE-CERTIFICATION;Jazz-M,Nagra CSC 1 SNA
..3 M0131 MD63-00103A GASKET-TAPE;GRANDSLAM,Conductive Fabric, 2 SNA
1 BN91-17228A ASSY SHIELD;7K 1 SNA
0.2 BN02-00102K TAPE-FILAMENT;FILAMENT,T0.15,W25,ROLL,WH 0 SNA
0.2 BN39-02204C LEAD CONNECTOR-SUB ASSY;55KS7500,UL21016 1 SA
0.2 BN39-02206C LEAD CONNECTOR-POWER;49KS7500,UL21016,30 1 SA
0.2 16P250 BN39-02212A LEAD CONNECTOR-SUB ASSY;65KS9000,UL21451 1 SA
0.2 BN44-00878A DC VSS-PD BOARD;L55E7_KSM,AC/DC,192W,100 1 SA
0.2 WIFI BN59-01239A NETWORK-WLAN CLIENT;WCK730B,USB 2.0,16P, 1 SA
0.2 BN96-39802C ASSY BOARD P-FUNCTION TACT;KS7000/7500/K 1 SA
0.2 BN96-39820D FFC CABLE;55KS7500,Fold,L500,96P 1 SA
0.2 SP01A BN96-39889A ASSY SPEAKER P-FRONT;6ohm,40W,2.1Ch 1 SA
0.2 BN96-39891A FFC CABLE;55KS7500,Fold,L400,96P 1 SA
1 BN91-17814A ASSY FIXING-JACKPACK;Y16 OCM 1 SNA
0.2 6902-001408 BAG PE;HDPE/PE FOAM,T0.015/T0.5,W120,L25 1 SNA
0.2 BN39-02248A ONECONNECTMINI CABLE;KS7000~KS9000,44,L2 1 SA
0.2 RB01 BN63-15074B COVER-BOTTOM;OCM PLUS,PC+ABS,MOLD,V-
0,BK 1 SA
0.2 T0527 BN68-00513A LABEL-E PASS;ALL MODEL,WW,YUPO,W50,L15,W 2 SNA
0.2 BN69-13267A BOX ACCESSORY;CB,SW-E,L373,W308,YELLOW 1 SNA
0.2 OCMPBA BN94-10924A ASSY PCB MISC-ONE CONNECT MINI;Y16 OCM P 1 SA
..3 AH020 BN62-00659A HEAT SINK-ES;UN55H6203AFXZA,A6063,W26.8, 1 SNA
..3 BN97-10869A ASSY SMD;7/8/9 SERIES 1 SNA
...4 0202-001976 SOLDER-CREAM;LST-309M-K21,20~38um,96.5Sn 3 SNA
...4 DS01A 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 2 SA
...4 0403-001783 DIODE-ZENER;BZB84-C6V2,5.8~6.6V,300mW,SO 4 SNA
...4 0404-001404 DIODE-SCHOTTKY;BAT721C,40V,200mA,SOT-23, 3 SA
...4 0406-001200 DIODE-TVS;RClamp0504F,6V,1MAV,TP 1 SA
ANNEX-7
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
...4 0406-001317 DIODE-TVS;SMAJ14A,15.6V,17.2V,1MAV,6.5VP 1 SNA
...4 0406-001635 DIODE-TVS;SMF5.0A,6.4V,6.7V,7V,200MAV,20 1 SA
...4 0501-000002 TR-SMALL SIGNAL;KSA812,PNP,150mW,SOT-23, 1 SNA
...4 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 11 SC
...4 0505-003507 FET-SILICON;AO3424,N,30V,3.8A,1.4W,SOT-2 2 SA
...4 0801-003292 IC-CMOS LOGIC;7WB66,Bus Switch,MAB08A,8P 1 SA
...4 0801-003598 IC-CMOS LOGIC;TC7SZ00FU,2-Input NAND Gat 1 SA
...4 0801-003604 IC-CMOS LOGIC;NL17SZ17DFT2G,SC-70,5P,TP, 1 SA
...4 1103-001583 IC-EEPROM;BR24T02FJ-WGE2,2Kbit,256x8,SOP 4 SNA
...4 1203-008104 IC-POSI.FIXED REG.;S-13A1D18-E800,HSOP,8 1 SNA
...4 1203-008345 IC-POSI.ADJUST REG.;S-13A1ADJ-E800X,HSOP 1 SA
...4 1203-008522 IC-DC/DC CONVERTER;SN1501019DDCR,SOT-23, 3 SNA
...4 1204-003677 IC-DECODER;SDP1503,FCPBGAH,396P,18*18mm, 1 SA
...4 1205-005519 IC-SWITCH;ET20163,SOT23-5,5P,2.95x3.02mm 2 SA
...4 1205-005537 IC-REPEATER;TCA9517,VSSOP,8P,3.00x3.00mm 1 SA
...4 2007-000137 R-CHIP;2Kohm,5%,1/16W,TP,1005 2 SNA
...4 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 11 SA
...4 2007-000157 R-CHIP;47Kohm,5%,1/16W,TP,1005 11 SNA
...4 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 16 SA
...4 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 SA
...4 2007-000879 R-CHIP;4.7ohm,1%,1/10W,TP,1608 1 SA
...4 2007-000999 R-CHIP;510ohm,1%,1/10W,TP,1608 1 SA
...4 2007-007107 R-CHIP;100Kohm,1%,1/16W,TP,1005 8 SNA
...4 2007-007108 R-CHIP;43.2Kohm,1%,1/16W,TP,1005 1 SA
...4 2007-007136 R-CHIP;4.7Kohm,1%,1/16W,TP,1005 3 SNA
...4 2007-007138 R-CHIP;27Kohm,1%,1/16W,TP,1005 2 SA
...4 2007-007139 R-CHIP;47Kohm,1%,1/16W,TP,1005,T0.35 2 SA
...4 2007-007142 R-CHIP;10Kohm,1%,1/16W,TP,1005 20 SA
...4 2007-007306 R-CHIP;100ohm,1%,1/16W,TP,1005 3 SNA
...4 2007-007309 R-CHIP;12Kohm,1%,1/16W,TP,1005,T0.35 1 SA
...4 2007-007318 R-CHIP;1Kohm,1%,1/16W,TP,1005 14 SA
...4 2007-007488 R-CHIP;75Kohm,1%,1/16W,TP,1005 1 SNA
...4 2007-007517 R-CHIP;240ohm,1%,1/16W,TP,1005 1 SNA
...4 2007-007587 R-CHIP;3.6Kohm,1%,1/16W,TP,1005 1 SNA
...4 2007-007766 R-CHIP;2Kohm,1%,1/16W,TP,1005 4 SA
...4 2007-007767 R-CHIP;200ohm,1%,1/16W,TP,1005 3 SA
...4 2007-007868 R-CHIP;90.9ohm,1%,1/10W,TP,1608 2 SA
...4 2007-007942 R-CHIP;1Mohm,1%,1/16W,TP,1005 1 SNA
...4 2007-007992 R-CHIP;1ohm,1%,1/10W,TP,1608 1 SA
...4 2007-008015 R-CHIP;75ohm,1%,1/16W,TP,1005 1 SA
...4 2007-008067 R-CHIP;21Kohm,1%,1/10W,TP,1608 1 SA
...4 2007-008134 R-CHIP;12.4Kohm,1%,1/16W,TP,1005 2 SC
...4 2007-008167 R-CHIP;120Kohm,1%,1/16W,TP,1005 1 SNA
...4 2007-008294 R-CHIP;33ohm,1%,1/16W,TP,1005 1 SA
...4 2011-001449 R-NETWORK;22ohm,5%,1/16W,L,4P,TP,1.0x1.0 4 SA
...4 AD480 2203-000359 C-CER,CHIP;0.15nF,5%,50V,C0G,TP,1005,0.5 3 SA
...4 AD480 2203-000425 C-CER,CHIP;0.018nF,5%,50V,C0G,TP,1005 2 SA
ANNEX-8
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
...4 AD480 2203-000585 C-CER,CHIP;0.22nF,10%,50V,X7R,TP,1005 1 SA
...4 AD480 2203-000812 C-CER,CHIP;0.033nF,5%,50V,C0G,TP,1005 2 SA
...4 AD480 2203-000940 C-CER,CHIP;0.47nF,10%,50V,X7R,TP,1005 1 SA
...4 AD480 2203-002285 C-CER,CHIP;10nF,10%,50V,X7R,TP,1005 1 SNA
...4 AD480 2203-005344 C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,0.5T 2 SNA
...4 AD480 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,TP,1005,T0. 89 SA
...4 AD480 2203-006324 C-CER,CHIP;2200nF,10%,10V,X5R,TP,1608 7 SA
...4 AD480 2203-006562 C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005 11 SNA
...4 AD480 2203-006824 C-CER,CHIP;4700nF,10%,10V,X5R,TP,1608 2 SNA
...4 AD480 2203-006890 C-CER,CHIP;10000nF,20%,6.3V,X5R,TP,1608 28 SNA
...4 AD480 2203-007240 C-CER,CHIP;22000nF,20%,6.3V,X5R,TP,1608( 3 SA
...4 AD480 2203-007269 C-CER,CHIP;22000nF,20%,10V,X5R,TP,2012(2 15 SA
...4 AD480 2203-007306 C-CER,CHIP;10000nF,10%,25V,X5R,TP,2012,1 6 SNA
...4 AD480 2203-007513 C-CER,CHIP;10000nF,10%,10V,X5R,TP,1608,0 1 SA
...4 AD480 2203-007544 C-CER,CHIP;100nF,10%,50V,X7R,TP,1005,0.5 4 SA
...4 2703-000213 INDUCTOR-SMD;470nH,10%,1.35Ohm,35mA,15,M 1 SA
...4 2703-001938 INDUCTOR-SMD;56nH,5%,1005,1.5Ohm,200mA,1 3 SA
...4 2703-005191 INDUCTOR-SMD;1.5uH,20%,4.5,0.02Ohm,5300m 1 SA
...4 2703-005193 INDUCTOR-SMD;2.2uH,20%,4.5,0.024Ohm,5100 1 SA
...4 2703-005194 INDUCTOR-SMD;3.3uH,20%,4.5,0.03Ohm,4500m 1 SA
...4 2801-005372 CRYSTAL-SMD;24.576MHz,20ppm,HCX-3SB,12 p 1 SA
...4 3301-002039 BEAD-SMD;26ohm,1608,TP 18 SA
...4 3601-001374 FUSE-SURFACE MOUNT;32V,5A,FAST-ACTING,PL 1 SA
...4 3701-001949 CONNECTOR-HDMI;19P,A,FEMALE,AU,0.5mm,BLK 4 SA
...4 3707-001104 CONNECTOR-OPTICAL;ANGLE,SPDIF 1 SA
...4 3710-004144 CONNECTOR-SOCKET;44P,1R,0.5mm,SMD-A,AU,B 1 SA
...4 3722-003457 JACK-USB;4P/1C,NI,BLK,ANGLE,A,2.0,13.1x1 2 SA
...4 BN40-00321A TUNER-DTV AIR CABLE;DTVS20EH6A,DTVS20EH6 1 SA
...4 BN41-02510A PCB-OCM;KS8000/KS9000,FR-4,4L,1.2T,199x6 1 SNA
...4 BN68-04746A LABEL-SMD;all model,POLY*,polyester,comm 1 SNA
0.2 T001A BN96-40188B ASSY COVER P-TOP;55KS9000,ABS,V-0,BK0008 1 SA
..3 M0131 BN63-00558A GASKET-EMI;GG15AS,Conductive Fabric,T3,W 1 SNA
..3 BN63-07272J SHEET-PROTECTION COVER;OCM+,PE,W205,Roll 0 SNA
..3 F001 BN63-15073B COVER-TOP;OCM PLUS,ABS,HB,K21294,HF-0680 1 SNA
1 BN92-19694A ASSY LABEL;7K 1 SNA
0.2 BN68-05050A LABEL-RATING;ALL MODEL,SS,PE,T0.05,W93,L 1 SNA
0.2 BN68-07834G LEAFLET-QUICK SETUP GUIDE;KS8500,ZA,W/P, 1 SNA
0.2 BN68-07925C LABEL-ENERGY;UN55KS8500FXZA,PET,T0.1,38, 1 SNA
0.2 BN74-00053G TAPE-PAPER;PAPER,3M2307,0.14T,W10,60M,WH 0 SNA
1 BN92-19710A ASSY BOX;7K 1 SNA
0.2 BH68-00697A LABEL BOX;ALL,ART,90g,W60,L100,WHT,NO SI 1 SNA
0.2 BN69-13674B BOX UNIT;55KS8500,CB,DW3,F1,L1313,W157,H 1 SNA
1 BN92-19727A ASSY P/MATERIAL;7K 1 SNA
0.2 6902-001611 BAG ROLL;HDPE/PE FOAM,T0.5/T0.015,W1500, 2 SNA
0.2 6922-000013 BAND;PP,W18,L2300/L2900,TRP 1 SNA
0.2 BH69-00418A WRAP;762,1828M,SAMEX FACTORY 2 SNA
0.2 BN02-00319B TAPE-OPP;OPP,T0.05,W75,L800m,CLEAR 3 SNA
ANNEX-9
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
0.2 BN68-02422B LABEL-WARNING;ALL,ART,T0.05,W240,L100,Wh 1 SNA
0.2 BN69-12806A PACKING ANGLE;40J6400,PAPER 1 SNA
0.2 BN69-13059A CUSHION-SET;55KS7500,EPS,16.7g/l,WHT,BRA 1 SNA
0.2 BN69-13064A CUSHION-SET SIDE;55KS7500,EPS,16.7g/l,WH 1 SNA
0.2 BN69-13622B PAD-CUSHION FRONT;55KS7500,CB,DW2+EPE,W6 1 SNA
1 ACCE1 BN92-19749F ASSY ACCESSORY;7K 1 SNA
0.2 BN96-39640A ASSY ACCESSORY-MANUAL CABLE;UK7T 1 SNA
..3 T0268 3903-000853 CBF-POWER CORD;DT,UL/CSA,LP-11L,125V,7A, 1 SA
..3 4301-000101 BATTERY-ALKALINE;1.5V,1650mAH,LR6,14.5x5 2 SNA
..3 6801-002215 CARD COUPON;7 Series and SUHD, SEA,PLAST 1 SNA
..3 6902-001962 BAG PE;LDPE,BIOBASED,T0.05,W400,L300,TRP 1 SNA
..3 BN59-01241A REMOCON-SMART CONTROL;2016 TV,Samsung,14 1 SA
..3 AH089 BN61-14022A HOLDER-CABLE;55KS7000,ABS,T1.5,BK0007,HB 2 SNA
..3 M9889 BN63-02368B CLOTH-CLEAN;CLOTH,W120,L160,sea blue,ToC 1 SNA
..3 BN68-04972E LEAFLET-REGULATORY
GUIDE;ALL,SAMSUNG,W/W 1 SNA
..3 BN68-05723A LABEL-ACCESSORY;ALL MODELS,YUPO,T0.2,W20 1 SNA
..3 BN68-07900A MANUAL USERS;KS8500,ZA,W/P 1 SNA
..3 EH03A BN96-40460A ASSY HOLDER P-RING;55KS7500,ABS,BLACK,V- 1 SNA
...4 6902-001404 BAG PE;LDPE,T0.05,W80,L100,TRP,N 1 SNA
...4 BN61-13518A HOLDER-WALL RING;55KS7500,ABS,MOLD,BK000 4 SNA
0.2 FC05A BN96-40469A ASSY COVER P-TERMINAL;55KS7500,PC+ABS,V- 1 SA
..3 BN63-11875X SHEET-PROTECTION COVER;55KS7000,PO,T0.06 0 SNA
..3 BN63-15163A COVER-TERMINAL;55KS7500,PC+ABS,T2,V-1,BK 1 SNA
..3 T0527 BN68-00513A LABEL-E PASS;ALL MODEL,WW,YUPO,W50,L15,W 1 SNA
1 PANEL BN95-02606A PRODUCT LCD-SDC;CY-XK055FLLV3V/H,KS7500, 1 SA
0.2 SCREW 6001-003016 SCREW-MACHINE;PWH,+,M3.0,L5.0,ZPC(WHT),S 2 SA
0.2 BN61-13235A BRACKET-STAND RIGHT;55" KS7500,EGI-SECC, 1 SNA
0.2 BN61-13236A BRACKET-STAND LEFT;55" KS7500,EGI-SECC,T 1 SNA
0.2 BN68-05595A LABEL-STICKER;ART 100G,T0.2,W80X23,WHITE 1 SNA
0.2 BN90-07847A ASSY MISC-BLU;LCM 1 SNA
..3 6001-002912 SCREW-MACHINE;CH,+,M3,L3,ZPC(BLK),SWRCH1 12 SA
..3 BN61-13647A OPTICAL SHEET-REFLECTOR;16Y_KS9000_55INC 1 SNA
..3 BN61-13662A OPTICAL SHEET-DBEF;16Y_KS9000_55INCH_DBE 1 SNA
..3 BN61-13663A OPTICAL SHEET-COMPLEX;16Y_KS9000_
COMPLEX 1 SNA
..3 BN61-13664A OPTICAL SHEET-HIGH COLOR;16Y_KS9000_QD,P 1 SNA
..3 BN61-13688A LGP;16Y_KS9000_55INCH_LGP,MS,MS Lenti (V 1 SNA
..3 BN96-39352B ASSY LED BAR P;55inch_SDC_L,ALUMINUM 1 SNA
..3 BN96-39353B ASSY LED BAR P;55inch_SDC_R,ALUMINUM 1 SNA
..3 BN96-39561A ASSY CHASSIS REAR P;55KS7500,EGI-SECC,NA 1 SNA
...4 SCREW 6001-002759 SCREW-MACHINE;CH,+,M3,L4,ZPC(BLK),SWRCH1 4 SA
...4 BN02-00040B TAPE DOUBLE FACE;NNB 32/40/46/55",PET,T0 1 SNA
...4 BN02-00040X TAPE DOUBLE FACE;F-LED ALL,PET,T0.15,W3, 2 SNA
...4 BN02-00352B TAPE-OPP;PET,T0.05,W30,L50M,BLK,ULNO.E16 0 SNA
...4 BN02-00493A TAPE PET;55KS9000,PET,T0.05,W5,L50,BLACK 4 SNA
...4 BN02-00497A TAPE DOUBLE FACE;55KS9000,PET,T0.05,W3,L 2 SNA
...4 BN39-02174A LEAD CONNECTOR-BLU;55KS7500,UL21016,18P, 1 SNA
ANNEX-10
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
...4 BN60-01416A SPACER-FOAM;55KS7500,PU FOAM,L70,BLACK,T 5 SNA
...4 BN61-08235A HOLDER-LGP;SNB,SWRCH10A,BLACK,PRESS 2 SNA
...4 BN61-08235F HOLDER-LGP;55KS7500,SWRCH10A,EXTRUSIO
N,S 2 SNA
...4 BN61-11982B HOLDER-WALL RIVET;55KS7000,CR-SPCC,EXTRU 4 SNA
...4 BN61-13245A BRACKET-LED PCB;55KS7500,Al,T1.6,W200,L9 1 SNA
...4 BN61-13302A BRACKET-CLIP;55KS7500,SK5,NATURAL 4 SNA
...4 BN61-13327A HOLDER-SHEET;55KS7500,ABS,BK0007,HB,COMM 5 SNA
...4 BN61-13557A BRACKET-WIRE;KS7000,SW-C,1,60,SILVER 4 SA
...4 BN61-13557E BRACKET-WIRE;49KS7000,SW-C,T1,NATURAL,ZI 1 SA
...4 BN61-13557H BRACKET-WIRE;55KS7000,SW-C,T1,NATURAL,ZI 3 SA
...4 BN61-13781A HOLDER-LGP LEFT;55KS7500,TPV,BK0008,HB 1 SNA
...4 BN61-13782A HOLDER-LGP RIGHT;55KS7500,TPV,BK0008,HB 1 SNA
...4 AH358 BN61-13908A HOLDER-REAR;55KS9000,ABS,MOLD,BK0007,HB 4 SNA
...4 BN63-15282A INSULATOR-SOURCE PCB LEFT;55KS8500,PET,B 1 SNA
...4 BN63-15283A INSULATOR-SOURCE PCB RIGHT;55KS8500,PET, 1 SNA
...4 BN63-15364A INSULATOR-SMPS;KS7000 49/55IN,PC,BLACK,L 1 SNA
...4 CC04 BN64-03333A CHASSIS-REAR;55KS7500,EGI-SECC,T0.8,NATU 1 SNA
...4 T0527 BN68-00513A LABEL-E PASS;ALL MODEL,WW,YUPO,W50,L15,W 1 SNA
...4 BN74-00053E TAPE-PAPER;PAPER,3M2307,0.14T,W20,50m,WH 0 SNA
..3 BN96-39564A ASSY FRAME P-MIDDLE BOTTOM;55KS7500,ABS+ 1 SNA
...4 BN60-01175H SPACER-SILICONE;55KS9000,Si,L602,GRAY,T0 2 SNA
...4 BN60-01356G SPACER-FOAM;55KS9000,PU FOAM,L603,WHITE, 2 SNA
...4 BN61-13243A FRAME-MIDDLE BOTTOM;55KS7500,PC+GF10%,V- 1 SNA
0.2 BN96-39136A ASSY OPEN CELL;LSF550FJ08-L,16:9,UHD 120 1 SNA
..3 BN81-07437A A/S-ADHESIVE ACF;LSJ400HL02-E,ADHESIVE A 1 SNA
..3 BN81-07943A A/S-ADHESIVE ACF;LSF320AN01-A,0201-00237 1 SNA
..3 BN81-12875A A/S-POLARIZER TFT;POLARIZER TFT,LJ01-107 1 SNA
..3 BN81-12876A A/S-IC DRIVER SOURCE;IC DRIVER SOURCE,LJ 1 SNA
..3 BN81-12877A A/S-POLARIZER CF;POLARIZER CF,LJ01-10863 1 SNA
..3 BN81-12878A A/S-SOURCE PCB LEFT;SOURCE PCB LEFT,LJ94 1 SNA
..3 BN81-12879A A/S-SOURCE PCB RIGHT;SOURCE PCB RIGHT,LJ 1 SNA
0.2 BN96-39384A ASSY COVER P-SOURCE PCB LEFT;SECC AG 1 SNA
0.2 BN96-39386A ASSY COVER P-SOURCE PCB RIGHT;SECC AG 1 SNA
..3 BN60-00554A SPACER-SILICONE;SNB 40/46/55,Si,L10,ID2, 4 SNA
0.2 BN96-39565A ASSY COVER P-DECORATION;55KS7500,PC+GF15 1 SA
..3 BN60-01010D SPACER-CONDUCTIVE;55KS7000,CONDUCTIVE
FA 2 SNA
..3 BN60-01251G SPACER-CONDUCTIVE;55KS7500,CONDUCTIVE
FA 1 SNA
..3 BN60-01359D SPACER-FOAM;55KS7000,PU FOAM,L1180,BLACK 1 SNA
..3 BN63-11875N SHEET-PROTECTION COVER;SD590,AL,T0.068,W 1 SNA
..3 FD01 BN63-15032A COVER-DECORATION;55KS7500,PC+GF15%,T1.5, 1 SNA
..3 BN74-00053E TAPE-PAPER;PAPER,3M2307,0.14T,W20,50m,WH 0 SNA
..3 BN96-39715A ASSY BLU P-DECO;KS7000/7500,SK5EB00070,L 1 SNA
0.2 BN96-39577A ASSY CHASSIS FRONT P;55KS7500,AL,SILVER, 1 SNA
..3 BN02-00467A TAPE PET;KS9000,PET,T0.05,W10,L10,BLACK 2 SNA
..3 BN02-00486A TAPE DOUBLE FACE;55KS9000,PU FOAM,T0.5,W 3 SNA
ANNEX-11
ANNEX. Exploded View & Part List
