Samsung DJ68-00461H User manual

Vacuum Cleaner
user manual
English
✻ Before operating this unit, please read the instructions carefully.
✻ For indoor use only.
Code No. DJ68-00461H REV(0.2)
imagine the possibilities
Thank you for purchasing a Samsung product.
To receive a more complete service,
please register your product at
www.samsung.com/register
DJ68-00461H(0.2)-EN.indd 1 2010.2.23 11:9:2 PM

2_ safety information
safety information _3
safety information
SAFETY INFORMATION
• Before operating the appliance, please read this manual thoroughly and
retain it for your reference.
• Because these following operating instructions cover various models,
the characteristics of your vacuum cleaner may differ slightly from those
described in this manual.
CAUTION/WARNING SYMBOLS USED
WARNING Indicates that a danger of death or serious injury exists.
CAUTION Indicates that a risk of personal injury or material damage exists.
OTHER SYMBOLS USED
Represents something you must NOT do.
Represents something you must follow.
Indicates that you must disconnect the power plug from the socket.
WARNING
WARNING
DJ68-00461H(0.2)-EN.indd 2 2010.2.23 11:9:2 PM

2_ safety information
safety information _3
safety information
IMPORTANT SAFEGUARDS
1. Read all instructions carefully. Before switching on, make sure that the voltage of your
electricity supply is the same as that indicated on the rating plate on the bottom of the
cleaner.
2. WARNING: Do not use the vacuum cleaner when rug or floor is wet.
Do not use to suck up water.
3. Close supervision is necessary when any appliance is used by or near children. Do not
allow the vacuum cleaner to be used as a toy. Do not allow the vacuum cleaner to run
unattended at any time. Use the vacuum cleaner only for its intended use as described in
these instructions.
4. Do not use the vacuum cleaner without a dust bin.
Empty the dust bin before it is full in order to maintain the best efficiency.
5. Slide to the Stop(or Min)position before inserting a plug into the electrical outlet.
6. Do not use the vacuum cleaner to pick up matches, live ashes or cigarette butts.
Keep the vacuum cleaner away from stoves and other heat sources. Heat can deform and
discolour the plastic parts of the unit.
7. Avoid picking up hard, sharp objects with the vacuum cleaner as they may damage the
cleaner parts. Do not stand on the hose assembly. Do not put weight on the hose.
Do not block the suction or the exhaust port.
8. Switch the vacuum cleaner off on the body of the machine before unplugging from the
electrical outlet. Disconnect the plug from the electrical outlet before changing the dust bag
or dust container. To avoid damage, please remove the plug by grasping the plug itself, not
by pulling on the cord.
9. This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety.
10. Children should be supervised to ensure that they do not play with the appliance.
11. The plug must be removed from the socket outlet before cleaning or maintaining the
appliance.
12. The use of an extension cord is not recommended.
13. If your vacuum cleaner is not operating correctly, switch off the power supply and consult an
authorized service agent.
14. If the supply cord is damaged, it must be replaced by the manufacturer or its service agent
or a similarly qualified person in order to avoid a hazard.
15. Don’t carry the vacuum cleaner by holding the hose.
Use the handle on the vacuum cleaner set.
16. Unplug the cleaner when not in use. Turn off the power switch before unplugging.
DJ68-00461H(0.2)-EN.indd 3 2010.2.23 11:9:2 PM

4_ contents assembling the cleaner _5
AssemblING The CleANeR
05
05 Assembling the Cleaner
OpeRATING The CleANeR
06
06 On/Off Switch
06 Power cord
07 Power control
mAINTAIN TOOls ANd fIlTeR
08
08 Using accessory
09 Maintain floor tools
10 Emptying the dust bin
11 When to clean the dust pack
12 Cleaning the dust pack
13 Cleaning the motor protection filter
13 Cleaning the outlet filter
TROUbleshOOTING
14
contents
DJ68-00461H(0.2)-EN.indd 4 2010.2.23 11:9:2 PM

4_ contents assembling the cleaner _5
01 ASSEMBLING THE CLEANER
assembling the cleaner
• Please do not press the button
of dust bin handle when carrying
machine.
OPTION
OPTION
• For storage, park the oor nozzle.
DJ68-00461H(0.2)-EN.indd 5 2010.2.23 11:9:4 PM

6_ operating the cleaner
operating the cleaner
operating the cleaner _7
ON/OFF SWITCH
CAUTION
• When removing the plug from the electrical outlet, grasp
the plug, not the cord.
1) BODY CONTROL TYPE 2) ON/OFF TYPE
POWER CORD
DJ68-00461H(0.2)-EN.indd 6 2010.2.23 11:9:6 PM

6_ operating the cleaner
operating the cleaner _7
02 OPERATING THE CLEANER
POWER-CONTROL
1) SLIDE CONTROL TYPE ONLY (OPTION)
• SLIDE TO THE STOP POSITION
Vacuum-cleaner switches off (stand by mode)
• SLIDE FORWARD TO MAX
Suction capacity increases smoothly up to
maximum.
- BODY (BODY-CONTROL TYPE ONLY)
MIN = For delicate surface e.g. net curtains.
MAX = For hard oors and heavily soiled carpets.
2) BODY-CONTROL TYPE / ON/OFF TYPE
- HOSE
To reduce suction for cleaning draperies, small rugs,
and other light fabrics, pull the tap air until the hole
is open.
DJ68-00461H(0.2)-EN.indd 7 2010.2.23 11:9:8 PM

8_ maintain tools and filter
maintain tools and filter
maintain tools and filter _9
PIPE (OPTION)
• Adjust the length of the telescopic pipe by sliding
the length control button located in the center of
the telescopic pipe back and forth.
USING ACCESSORY
• To check for blockages, separate the telescopic
pipe and adjust to shorten. This allows for easier
removal of waste clogging the tube.
ACCESSORY (OPTION)
• Dusting brush for furniture. shelves, books, etc.
• Crevice tool for radiators, crevices, corners, between
cushions.
DJ68-00461H(0.2)-EN.indd 8 2010.2.23 11:9:10 PM

8_ maintain tools and filter
maintain tools and filter _9
03 MAINTAIN TOOLS AND FILTER
MAINTAIN FLOOR TOOLS
BLANKET BRUSH (OPTION)
Clogs on turbine keep brush from turning, thus need to be unclogged as follows.
For picking up pet hair and fibre on upholstery and bed linen.
Remove waste matter completely when inlet is blocked.
PET BRUSH (OPTION)
For improved pick-up of pet hair and fibre on carpets.
Frequent vacuuming of hair or pet fur may cause a falling-off of the rotation due to
matters tangled around the drum. In this case, clean the drum with care.
2-STEP BRUSH (OPTION)
• Adjust the inlet lever according to the oor surface. • Remove waste matter
completely if the inlet is
blocked.
Carpet Cleaning Floor Cleaning
Turbine
Brush
Turn the lock button to ‘UNLOCK’, and remove waste
matter.
To reassemble, align the cover to the front of the main body
and close. After closing the cover, ensure that the lock
button is turned to the ‘LOCK’ position.
WARNING
Use for bedclothes only. Be cautious not to damage brush during
unclogging.
DJ68-00461H(0.2)-EN.indd 9 2010.2.23 11:9:49 PM

10_ maintain tools and filter
maintain tools and filter
maintain tools and filter _11
EMPTYING THE DUST BIN
Once dust reaches the
dust full mark, or sution is
noticeably reduced during
cleaning, empty the dust bin.
4 5 6
Take the dust bin out by
pressing the button. Separate the dust bin cover.
Throw away dust into the bin. Close the dust bin cover.
Before use, push the dust
bin into the main body of the
vacuum cleaner until you hear
the “click” sound.
1 2 3
- Empty into a plastic bag
(recommended for asthma/allergy
sufferers)
You may rinse the dust bin with cold water.
DJ68-00461H(0.2)-EN.indd 10 2010.2.23 11:9:58 PM

10_ maintain tools and filter
maintain tools and filter _11
03 MAINTAIN TOOLS AND FILTER
maintain tools and filter
WHEN TO CLEAN THE DUST PACK
- If suction is noticeably reduced during cleaning, please check the dust pack as indicated
below.
If suction is noticeably reduced with the inlet floating
10cm above flat floor, clean it.
Turn the vacuum power to
'MAX'.
HANDLE CONTROL
When suction is noticeably reduced continuously,
please cleaning the Dust Pack as shown in the following illustration.
DJ68-00461H(0.2)-EN.indd 11 2010.2.23 11:10:1 PM

12_ maintain tools and filter
maintain tools and filter _13
CLEANING THE DUST PACK
2. Remove the sponge and filter from the dust pack.
1. Remove the dust bin and dust pack as shown.
Make sure the filter is completely dry
before putting it back into the vacuum
cleaner. Allow 12 hours for it to dry.
3. Wash the sponge and the filter of the dust pack with water.
4. Let the sponge and filter dry in the shade for more than
12 hours.
5. Put the sponge and lter into the dust pack.
6. Put the assembled dust pack into the main body.
DJ68-00461H(0.2)-EN.indd 12 2010.2.23 11:10:3 PM

12_ maintain tools and filter
maintain tools and filter _13
03 MAINTAIN TOOLS AND FILTER
maintain tools and filter
CLEANING THE MOTOR PROTECTION FILTER
Remove the motor protection filter from the
vacuum cleaner.
Shake and tap the dust from it and put back in
machine.
Take out both the dust bin and the dust pack.
Replacement filters are available at your local
Samsung distributor.
Press the xed frame part at the
back of the main body to remove.
CLEANING THE OUTLET FILTER
OPTION - MICRO FILTER
Remove and replace the blocked
outlet filter.
OPTION
DJ68-00461H(0.2)-EN.indd 13 2010.2.23 11:10:5 PM

14_ troubleshooting
pROblem sOlUTION
Motor dows not start.
• Check cable, pulg and socket.
• Leave to cool.
Suction force is gradually
decreasing.
• Check for blockage and remove.
Cord does not rewind fully.
• Pull the cord out 2-3m and push down the
cord rewind button.
Vacuum cleaner dows not pick up
dirt.
• Check hose and replace if required.
Low or decreasing suction
• Please check lter and, if required, clean as
illustrated in the instructions. if filters are out
of condition change them to new ones.
Body overheating
• Please check lters, If required clean as
illustrated in the instruction.
Static electicity discharge • Please decrease power suction.
troubleshooting
