Vacuum Cleaner
user manual
imagine the possibilities
Thank you for purchasing a Samsung product.
To receive a more complete service,
please register your product at
www.samsung.com/register
✻Before operating this unit, please read the instructions carefully.
✻For indoor use only. English
SC44** Series
This manual is made with 100% recycled paper.
DJ68-00643A.indd 01DJ68-00643A.indd 01 2011.11.30 3:12:31 PM2011.11.30 3:12:31 PM

02_ safety information
safety information
SAFETY INFORMATION
• Before operating the appliance, please read this manual thoroughly and
retain it for your reference.
• Because these following operating instructions cover various models,
the characteristics of your vacuum cleaner may differ slightly from those
described in this manual.
CAUTION/WARNING SYMBOLS USED
WARNING
Indicates that a danger of death or serious injury exists.
CAUTION
Indicates that a risk of personal injury or material damage exists.
OTHER SYMBOLS USED
Represents something you must NOT do.
Represents something you must follow.
Indicates that you must disconnect the power plug from the socket.
WARNING
WARNING
DJ68-00643A.indd 02DJ68-00643A.indd 02 2011.11.30 3:12:31 PM2011.11.30 3:12:31 PM

safety information _03
safety information
IMPORTANT SAFEGUARDS
Read all instructions carefully. Before switching on, make sure that the voltage1.
of your electricity supply is the same as that indicated on the rating plate on the
bottom of the cleaner.
WARNING : Do not use the vacuum cleaner when rug or floor is wet.2.
Do not use to suck up water.
Do not use the vacuum cleaner without a dust bin.3.
Empty the dust bin before it is full in order to maintain the best efficiency.
Do not use the vacuum cleaner to pick up matches, live ashes or cigarette butts.4.
Keep the vacuum cleaner away from stoves and other heat sources. Heat can5.
deform and discolour the plastic parts of the unit.
Avoid picking up hard, sharp objects with the vacuum cleaner as they may6.
damage the cleaner parts. Do not stand on the hose assembly. Do not put
weight on the hose.
Do not block the suction or the exhaust port.
Switch the vacuum cleaner off on the body of the machine before unplugging7.
from the electrical outlet. Disconnect the plug from the electrical outlet before
changing the dust bag or dust container. To avoid damage, please remove the
plug by grasping the plug itself, not by pulling on the cord.
This appliance is not intended for use by persons (including children) with8.
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.9.
The plug must be removed from the socket outlet before cleaning or maintaining10.
the appliance.
The use of an extension cord is not recommended.11.
If your vacuum cleaner is not operating correctly, switch off the power supply and12.
consult an authorized service agent.
If the supply cord is damaged, it must be replaced by the manufacturer or its13.
service agent or a similarly qualified person in order to avoid a hazard.
Don’t carry the vacuum cleaner by holding the hose.14.
Use the handle on the vacuum cleaner set.
Unplug the cleaner when not in use. Turn off the power switch before unplugging.15.
DJ68-00643A.indd 03DJ68-00643A.indd 03 2011.11.30 3:12:31 PM2011.11.30 3:12:31 PM

04_ contents
contents
ASSEMBLING THE CLEANER
05
OPERATING THE CLEANER
06
06 ON/OFF Switch
06 Power Cord
06 Suction Control
MAINTAIN TOOLS AND FILTER
07
07 Using accessory
08 Maintain floor tools
10 Emptying the dust bin
11 When to clean the dust pack
12 Cleaning the dust pack
13 Cleaning the motor protection filter
13 Cleaning the outlet filter
TROUBLESHOOTING
14
DJ68-00643A.indd 04DJ68-00643A.indd 04 2011.11.30 3:12:32 PM2011.11.30 3:12:32 PM

assembling _05
01 ASSEMBLING
assembling the cleaner
• Please do not press the button
of dust bin handle when carrying
machine.
• For storage, park the floor nozzle.
OPTION
• Features may vary according to model.
OPTION
DJ68-00643A.indd 05DJ68-00643A.indd 05 2011.11.30 3:12:32 PM2011.11.30 3:12:32 PM

06_ operating
operating the cleaner
ON/OFF SWITCH
• When removing the plug from the electrical outlet, grasp
the plug, not the cord.
POWER CORD
SUCTION CONTROL
• HOSE
To reduce suction for cleaning draperies,
small rugs, and other light fabrics, pull
the tap air until the hole is open.
CAUTION
DJ68-00643A.indd 06DJ68-00643A.indd 06 2011.11.30 3:12:32 PM2011.11.30 3:12:32 PM

maintain _07
03 MAINTAIN
maintain tools and filter
USING ACCESSORY
Pipe (Option)
• Adjust the length of the telescopic pipe by
sliding the length control button located in the
center of the telescopic pipe back and forth.
• To check for blockages, separate the
telescopic pipe and adjust to shorten. This
allows for easier removal of waste clogging the
tube.
Accessory
• Dusting brush for furniture. shelves, books,
etc.
• Crevice tool for radiators, crevices, corners,
between cushions.
DJ68-00643A.indd 07DJ68-00643A.indd 07 2011.11.30 3:12:34 PM2011.11.30 3:12:34 PM

08_ maintain
MAINTAIN FLOOR TOOLS
2-Step Brush (Option)
• Adjust the inlet lever according to the floor
surface.
• Remove waste matter
completely if the inlet is
blocked.
Carpet Cleaning
Carpet Cleaning
Floor Cleaning
Floor Cleaning
Pet Brush (Option)
For improved pick-up of pet hair and fibre on carpets.
Frequent vacuuming of hair or pet fur may cause a falling-off of the rotation due to
matters tangled around the drum. In this case, clean the drum with care.
Blanket brush (Option)
Clogs on turbine keep brush from turning, thus need to be unclogged
as follows. For picking up pet hair and fibre on upholstery and bed
linen.
Remove waste matter completely when inlet is blocked.
Turn the lock button to ‘UNLOCK’, and remove waste
matter.
To reassemble, align the cover to the front of the main
body and close. After closing the cover, ensure that the
lock button is turned to the ‘LOCK’ position.
Use for bedclothes only. Be cautious not to
damage brush during unclogging.
Turbine
Turbine
Brush
Brush
WARNING
DJ68-00643A.indd 08DJ68-00643A.indd 08 2011.11.30 3:12:35 PM2011.11.30 3:12:35 PM

maintain _09
03 MAINTAIN
maintain tools and filter
Mini turbo brush (Optional)
- TO REPLACE BRUSHROLL
1. If a clog is present or debris is visible, unscrew the
two screws on the back of the Mini turbo brush to
remove the faceplate and clear any obstructions.
2. Inspect condition of brushroll.
Replace brushroll if brushes are worn down.
To remove brushroll, pull up and out of end slots in
nozzle housing.
Insert ends of brushroll into same slots to replace.
Inspect belt to ensure that it is in good
condition.
If belt is broken or cracked, replace belt
according to To Replace Belt instructions.
3. Using at MAX.
Press the MAX button to operate the vacuum at
maximum intake.
- TO REPLACE BELT
1. Remove bottom plate.
See figure in To Replace Brushroll instructions.
2. Loop one end of new belt around shaft of pulley.
3. Loop other end of belt around designated area for
it on brushroll. Insert brushroll into slots in nozzle
housing.
See figure in To Replace Brushroll instructions.
4. Fit Mini turbo brush back together as described in
To Replace Brushroll instructions.
DJ68-00643A.indd 09DJ68-00643A.indd 09 2011.11.30 3:12:35 PM2011.11.30 3:12:35 PM

10_ maintain
EMPTYING THE DUST BIN
1. Once dust reaches the
dust full mark, light on
the lamp of filter check,
or suction is noticeably
reduced during
cleaning. Empty.
2. Take the dust bin out
by pressing the button.
3. Separate the dust bin
cover.
4. Throw away dust into
the bin.
5. Close the dust bin
cover.
6. Before use, push the
dust bin into the main
body of the vacuum
cleaner until you hear
the “click” sound.
- Empty into a plastic bag
(recommended for asthma/
allergy sufferers)
You may rinse the dust bin with cold water.
DJ68-00643A.indd 10DJ68-00643A.indd 10 2011.11.30 3:12:36 PM2011.11.30 3:12:36 PM

maintain _11
03 MAINTAIN
maintain tools and filter
WHEN TO CLEAN THE DUST PACK
- If suction is noticeably reduced during cleaning, please check the dust pack as
indicated below.
Push the button to working
If suction is noticeably reduced with the inlet floating 10cm
above flat floor, clean it.
When suction is noticeably reduced continuously, please cleaning the Dust Pack as
shown in the following illustration.
DJ68-00643A.indd 11DJ68-00643A.indd 11 2011.11.30 3:12:36 PM2011.11.30 3:12:36 PM

12_ maintain
CLEANING THE DUST PACK
1. Remove the dust bin and dust pack as
shown.
2. Remove the sponge and filter from the dust pack.
3. Wash the sponge and the filter of the dust pack with
water.
4. Let the sponge and filter dry in the shade for more
than 12 hours.
5. Put the sponge and filter into the dust pack.
6. Put the assembled dust pack into the main
body.
Make sure the filter is completely dry before
putting it back into the vacuum cleaner. Allow
12 hours for it to dry.
DJ68-00643A.indd 12DJ68-00643A.indd 12 2011.11.30 3:12:37 PM2011.11.30 3:12:37 PM

maintain _13
03 MAINTAIN
maintain tools and filter
CLEANING THE MOTOR PROTECTION FILTER
Take out both the dust bin and the dust
pack.
Remove the motor protection filter from the
vacuum cleaner.
Shake and tap the dust from it and put back in
machine.
CLEANING THE OUTLET FILTER
Replacement filters are available at your local
Samsung distributor.
OPTION
Press the fixed frame part at
the back of the main body to
remove.
OPTION - MICRO FILTER
Remove and replace the blocked
outlet filter.
DJ68-00643A.indd 13DJ68-00643A.indd 13 2011.11.30 3:12:37 PM2011.11.30 3:12:37 PM

troubleshooting
PROBLEM SOLUTION
Motor dows not start. • Check cable, pulg and socket.
• Leave to cool.
Suction force is gradually
decreasing. • Check for blockage and remove.
Cord does not rewind fully. • Pull the cord out 2-3m and push down the cord
rewind button.
Vacuum cleaner dows not pick
up dirt. • Check hose and replace if required.
Low or decreasing suction
• Please check filter and, if required, clean as
illustrated in the instructions. if filters are out of
condition change them to new ones.
Body overheating • Please check filters, If required clean as
illustrated in the instruction.
Static electicity discharge • Please decrease power suction.
This Vacuum cleaner is approved the following.
EMC Directive : 2004/108/EEC
Low Voltage Directive : 2006/95/EC
