Samsung Jet Bot User manual

Jet Bot
User manual
VR30T85**** series
• Before operating this unit, please read the instructions carefully.
• For indoor use only
1_VR8500_EN_00858C-02_SW.indd 1 2022-10-13 오후 6:06:07

Contents
PREPARATION
Safety information 3
INSTALLATION
Installing a Clean Station 13
OPERATION
Charging the Jet Bot 14
Using the Jet Bot 17
Basic use 17
Operation status on the LED Status Indicator 18
Cleaning Functions 19
Additional functions 20
Attaching Boundary Markers 21
Parts diagram 22
Jet Bot 22
Clean Station 22
MAINTENANCE
Cleaning the Jet Bot 23
Emptying and cleaning the Dustbin 23
Cleaning the brush 24
Cleaning the Sensor Window 25
Cleaning the Driving Wheel 25
Cleaning the Side Brush 26
Cleaning the Clean Station 27
Replacing the Dust Bag 27
Cleaning the Fine dust Filter 27
Cleaning the bottom cover 28
APPENDIX
SmartThings App 29
Setting up the wireless router 29
Downloading the SmartThings App 30
Setting up a SAMSUNG account 30
Registering a device to the SmartThings App 30
Software Update 31
Functions of the SmartThings App 32
Notes and cautions 34
Installation 34
Charging 34
Using 35
Cleaning and maintenance 36
Battery usage 37
Corrective measures before reporting a
problem 38
Troubleshooting 40
Open Source Announcement 45
How to reset to the factory default 45
Product Specication 46
English
2
1_VR8500_EN_00858C-02_SW.indd 2 2022-10-13 오후 6:06:07

PREPARATION
PREPARATION
Safety information
• Before operating the appliance, please read this manual thoroughly and
retain it for your reference.
• Because the following operating instructions cover various models, the
characteristics of your vacuum cleaner may differ slightly from those
described in this manual.
Caution/Warning symbols used
WARNING
Indicates that a danger of death or serious injury exists.
CAUTION
Indicates that a risk of personal injury or material damage exists.
Other symbols used
NOTE
Indicates that the following text contains additional important information.
Accessories
Accessories may differ depending on the models.
Side Brush: 2units
(Inside the product:
1unit, Spare: 1unit)
Dust Bag: 2units
(Inside the product:
1unit, Spare: 1unit)
Pre-motor Filter:
2units
(Inside the product:
1unit, Spare: 1unit)
Clean Station Power cord Boundary Markers User Manual
 If you want to purchase an additional Dust Bag, check the model name (VCA-RDB95) and
Samsung logo ( ) rst, then contact your nearest Samsung Electronics retailer or
Samsung service center.
English
3
1_VR8500_EN_00858C-02_SW.indd 3 2022-10-13 오후 6:06:08

PREPARATION
Failure to meet these requirements could cause damage to the internal parts
of the vacuum and void your warranty.
General
• Do not allow to be used as a toy. Close attention is necessary when used
by or near children.
• Use only as described in this manual.
• Do not operate the Jet Bot or the Clean Station if it has been damaged in
any way.
• If the vacuum cleaner is not working as it should, has been dropped,
damaged, left outdoors, or dropped in water, return it to a customer care
center.
• Do not handle the Clean Station or the Jet Bot if your hands are wet.
• Use only on dry, indoor surfaces.
• This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack
of experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved. Children should not play with the appliance.
Children should not clean or perform maintenance on the vacuum without
adult supervision.
• Move the cords of other appliances so they are not in the area that is to
be cleaned.
• Do not operate the vacuum in a room where an infant or child is sleeping.
• Do not operate the vacuum in an area where there are lit candles or
fragile objects on the oor.
• Do not operate the vacuum in a room that has lit candles on furniture that
the vacuum may accidentally hit or bump into.
• Do not allow children to sit on the vacuum.
• Do not use the vacuum on a wet surface.
• If the supply cord is damaged, it must be replaced by the manufacturer or
its service agent or a similarly qualied person in order to avoid a hazard.
English
4
1_VR8500_EN_00858C-02_SW.indd 4 2022-10-13 오후 6:06:08

PREPARATION
• For information on Samsung’s environmental commitments and product
specic regulatory obligations e.g. REACH (WEEE, Batteries) visit:
samsung.com/uk/aboutsamsung/samsungelectronics/corporatecitizenship/
data_corner.html
Clean Station
• Do not modify the polarized plug to t a non-polarized outlet or extension
cord.
• Do not use outdoors or on wet surfaces.
• Unplug the Clean Station from the outlet when not in use and before
servicing.
• Use only the Clean Station supplied by the manufacturer to recharge.
• Do not use with a damaged cord or a plug or a loose power outlet.
• Do not pull or carry by the cord, use the cord as a handle, close the door
on the cord, or pull the cord around sharp edges or corners. Keep the cord
away from heated surfaces.
• Do not use extension cords or outlets with inadequate current carrying
capacity.
• Do not unplug by pulling on the cord. To unplug, grasp the plug, not the
cord.
• Do not mutilate or incinerate batteries as they will explode at high
temperatures.
• Do not attempt to open the Clean Station. Repairs should only be carried
out by a qualied customer care center.
• Do not expose the Clean Station to high temperatures or allow moisture or
humidity of any kind to come into contact with the Clean Station.
• Do not charge the non-rechargeable batteries with the Clean Station.
English
5
1_VR8500_EN_00858C-02_SW.indd 5 2022-10-13 오후 6:06:08

PREPARATION
Jet Bot
• Do not pick up hard or sharp objects such as glass, nails, screws, coins,
and etc.
• Do not use without a lter in place. When servicing the unit, never put
ngers or other objects into the fan chamber in case the unit accidentally
turns on.
• Do not put any objects into openings. Do not use with any openings
blocked; keep openings free of dust, lint, hair, and anything that may
reduce air ow.
• Do not pick up toxic materials (chlorine bleach, ammonia, drain cleaner,
etc.).
• Do not pick up anything that is burning or smoking, such as cigarettes,
matches, or hot ashes.
• Do not use to pick up ammable or combustible liquids such as gasoline
or use in areas where they may be present.
• Also do not use in:
– Locations with candles or desk lamps on the oor.
– Locations with unattended res (re or embers).
– Locations with distilled alcohol, thinner, ashtrays with burning
cigarettes, etc.
• Do not use the Jet Bot in an enclosed space lled with vapors given off by
oil based paint, paint thinner, moth proong substances, ammable dust,
or other explosive or toxic vapors.
• Leaks from battery cells can occur under extreme usage or temperature
conditions. If the liquid gets on the skin, wash quickly with water. If the
liquid gets into the eyes, ush them immediately with clean water for a
minimum of 10 minutes. Seek medical attention.
English
6
1_VR8500_EN_00858C-02_SW.indd 6 2022-10-13 오후 6:06:08

PREPARATION
Power related
WARNING
• Please prevent any risk of electric shock or re.
– Do not damage the power cord.
– Do not pull the power cord too hard or touch the power plug with wet
hands.
– Do not use a power source other than rated volatge of the charger and
also do not use a multi-outlet to supply power to a number of devices at
the same time. (Do not leave the cord carelessly on the oor.)
– Do not use a damaged power plug, a power cord or a loose power outlet.
• Clean dust or any foreign matter on the pin and the contact part of the
power plug.
– There is a risk of electric shock or malfunction.
Before use
WARNING
• Do not use the Jet Bot near a heater or combustible materials.
– Do not use the Jet Bot near re or ame such as a movable heater, a
candlelight, a desk lamp, a replace, etc. or in a place where combustible
materials such as gasoline, alcohol, thinner, etc. exist.
• Make sure there are no dangerous objects around the Jet Bot’s cleaning
area to prevent collision and unplug any electric heaters or fans.
– The Jet Bot can be damaged or malfunction.
• The Jet Bot is intended for household use therefore do not use it in an
attic, basement, storage, an industrial building, out of indoor space, places
with moisture (such as a bathroom, a laundry room), on the table or
shelves.
– The Jet Bot can be damaged or malfunction.
• Attach the Boundary Markers to a place where the Jet Bot may fall such
as a stair or a banister to prevent product damage and injury.
– Please keep the Cliff Sensor clean all the time for safety.
English
7
1_VR8500_EN_00858C-02_SW.indd 7 2022-10-13 오후 6:06:08

PREPARATION
• Be sure the Jet Bot does not suck in or touch any kind of liquids (water,
beverage, lth, etc.).
– The Jet Bot can be severely damaged and it may contaminate other
areas if the wheels pass through liquid.
• Do not spill any liquids on the Clean Station.
– There is a risk of re or electric shock.
• Do not use the Clean Station for anything other than its intended
purposes.
– There is a risk of re or severe damage to the Clean Station.
• Always keep the Cliff Sensor clean for your safety.
• As this wireless installation may cause radio interference, it cannot
provide a service related with human safety.
CAUTION
• Insert the Dustbin before using the Jet Bot.
• When installing the Clean Station, do not leave the cord carelessly on the
oor since the Jet Bot may get tangled by it.
• To clean all areas of your house, open all rooms and set the No-go Zones
with the SmartThings App or attach the Boundary Markers to the places
where the Jet Bot may get damaged such as a front door, a veranda, a
bathroom, and stairs for safety.
• Follow these recommendations for proper automatic recharging.
– Always turn on the power of the Clean Station.
– Install the Clean Station where the Jet Bot can easily nd.
– Do not leave any objects in front of the Clean Station.
• Do not use the Jet Bot on black colored oors.
– The Jet Bot may not be able to operate normally.
• Do not place any objects within 0.5 m of either side of the Clean Station
or within 1m of the front of the Clean Station.
• Make sure the Clean Station’s charging contact is not damaged or have
any foreign matter on it.
English
8
1_VR8500_EN_00858C-02_SW.indd 8 2022-10-13 오후 6:06:08

PREPARATION
• For the very low areas where the Jet Bot may get stuck, set the No-
go Zones with the SmartThings App or attach the Boundary Markers to
prevent the Jet Bot from getting in.
• Do not install the Clean Station in an area with a dark oor.
– If the oor around the Clean Station is dark, recharging is hindered.
• Move any obstacles that may disturb the Jet Bot’s movement (such as
children’s indoor swing or slides) before cleaning.
• Do not use the Jet Bot in a place which is narrower than its turning radius
0.5m or less.
• Before operating the Jet Bot, remove the objects which could break such
as glass, a frame, a mirror, and porcelain items so that the Jet Bot works
without interruption.
• If a brush or a brush cover is not assembled correctly, scratches may occur
on the oor, or product malfunction may occur.
• Use both hands to carry the product.
• Do not place the Clean Station in a place where people pass by frequently,
in entrance way or narrow passage.
– People may trip over it and be injured, or product damage may occur.
• Do not push the Clean Station.
English
9
1_VR8500_EN_00858C-02_SW.indd 9 2022-10-13 오후 6:06:08

PREPARATION
In use
WARNING
• If any abnormal sounds, smells or smoke come from the Jet Bot,
immediately shut off the power switch of the Jet Bot and contact a service
center.
CAUTION
• Using the Jet Bot on a thick carpet may damage both the Jet Bot and the
carpet.
– The Jet Bot cannot pass over a carpet with ber longer than 2 cm.
• Do not use the Jet Bot on tables or other high surfaces.
– There is a risk of damage if it falls.
• The Jet Bot may bump into chairs or desk legs, therefore move them away
for faster and efcient cleaning.
• When the Jet Bot is operating, do not lift it up or carry it to another area.
• Do not hold by Driving Wheels of the Jet Bot when carrying it to another
area.
• Do not put any objects on top of the Jet Bot since it may cause
malfunction of the LiDAR sensor or the Jet Bot.
• Remove any large papers or plastic bags immediately when using the Jet
Bot since they may block the intake.
• Do not lie down around the Jet Bot that is running.
– Your hair may be caught in the brush, resulting in physical injury.
• Do not allow children to play with the Jet Bot.
• Make sure hair, ngers, clothes do not get caught in a Side brush or
Driving Wheels.
• Do not allow children to sit on the Jet Bot and do not place an object on
the Jet Bot.
• Leave over 3 cm space from the inner doorstep placed in the entrance.
Otherwise, the Jet Bot can ride on it and go outside.
English
10
1_VR8500_EN_00858C-02_SW.indd 10 2022-10-13 오후 6:06:08

PREPARATION
Cleaning and maintenance
WARNING
• When the power cord is damaged, contact a service center to get it
replaced by a certied repairman.
– There is a risk of re or electric shock.
• Please check with a SAMSUNG Electronics service center when replacing
batteries.
– Using batteries from other products can cause malfunction.
• Be careful not to put your nger into the revolving LiDAR sensor.
Otherwise, your nger may get injured.
CAUTION
• Prevent any damage to the Jet Bot by complying with the following.
– Do not clean the Jet Bot by spraying water directly onto it or use a
volatile substance such as benzene, thinner, or alcohol to clean it.
• Do not disassemble or repair the Jet Bot. This should only be done by a
certied repairman.
• Always keep the Obstacle Sensor Window and the Cliff Sensor Window
clear.
– If foreign matter accumulates, sensors may malfunction.
• Do not store the Jet Bot in a car.
• Be careful that the LiDAR sensor is not exposed to a direct light such as
sun light, infrared light, etc.
– The direct light can affect the performance of the LiDAR sensor.
• When carrying the Jet Bot, be careful not to let it drop.
– The impact from the drop can affect the operation or performance of the
LiDAR sensor.
• Do not look at the transmitting part (a laser) of the revolving LiDAR
sensor horizontally.
• Be careful not to insert a tool such as a chopstick into the revolving LiDAR
sensor. Otherwise, the LiDAR sensor may work abnormally or malfunction.
English
11
1_VR8500_EN_00858C-02_SW.indd 11 2022-10-13 오후 6:06:09

PREPARATION
• Before cleaning, remove objects which are less than 9 cm height and are
lightly on the oor as the Jet Bot can push along them, or the objects can
be caught in the Jet Bot’s Side Brush or Driving Wheels. (Fixed objects
can be detected by the Jet Bot when its bumper is pressed and will avoid
them.)
• If oil such as cooking oil is on the oor, the Jet Bot may become stationary
because the oor is slippery. Remove the oil rst before cleaning with the
Jet Bot.
English
12
1_VR8500_EN_00858C-02_SW.indd 12 2022-10-13 오후 6:06:09

INSTALLATION
INSTALLATION
Installing a Clean Station
Approximately
0.5 m
Approximately
0.5 m
Status Indicator
Approximately
1m
1 Connect the provided power cord to the
bottom of the Clean Station.
2 Position the power cord into the xing
groove at the rear of the Clean Station.
3 Place the Clean Station on an even oor
and near an electrical outlet and plug it in.
 When the Clean Station is plugged in, the
Status Indicator at the top of the Clean
Station turns white for a short time.
NOTE
• Install the Clean Station in a place where the oor and wall are level.
• If the power cord is too long for the installation environment, coil the power cord around the
cable management post, then put it in the xing groove at the rear of the Clean Station.
• If you reinstall the Clean Station to a position 1 m or more from the previous installed place,
recreate the map using the SmartThings App. (If you use the existing map, some places may
not be cleaned.)
English
13
1_VR8500_EN_00858C-02_SW.indd 13 2022-10-13 오후 6:06:09

OPERATION
Charging the Jet Bot
Before using the Jet Bot for the rst time, charge it completely. (For the charging time and
cleaning time, refer to the ‘Product specication’.)
1 Open the upper cover of the Jet Bot and
remove the white gasket.
OFF ON
2 Remove the yellow gasket attached to the
power switch at the side of the Jet Bot and
press the power switch to turn the Jet Bot
on.
– During booting, the Jet Bot’s Status
Indicator turns on with a melody which
stops when the booting is complete.
– When you turn the Jet Bot on for the
rst time after purchase, check the
SmartThings App connection (refer to
p.29-33) and installation of the Clean
Station following the voice guide of the
Jet Bot.
3 Place the Jet Bot on the Clean Station
manually to start charging.
– Make sure the charging terminals on the
Jet Bot and the Clean Station are aligned.
– When the Jet Bot starts charging, the
Status Indicator of the Clean Station
turns white and after 1 minute, the
Status Indicator turns off automatically.
(Charging continues though the Status
Indicator has turned off.)
OPERATION
English
14
1_VR8500_EN_00858C-02_SW.indd 14 2022-10-13 오후 6:06:10

OPERATION
Status
Indicator
4 Check the charging status.
– When charging starts, the Status
Indicator of the Jet Bot turns on (red,
orange, or yellow depending on charging
progress), it rises gradually, and changes
to green when the charging is complete.
Auto charging
The Jet Bot automatically returns to the Clean
Station when it completes cleaning or when
the battery is low to recharge.
Docking (Recharging)
You can return the Jet Bot to the Clean
Station while cleaning to recharge.
• Press the [ ] on the Jet Bot or use the
SmartThings App to select the recharging
function.
 If the Jet Bot fails to return to the Clean
Station for charging, it turns to the Sleep
Mode. To cancel the Sleep Mode, press the
[ ].
Discharged Jet Bot
Move the Jet Bot manually onto the Clean
Station to recharge.
English
15
1_VR8500_EN_00858C-02_SW.indd 15 2022-10-13 오후 6:06:10

OPERATION
Checking if the docking (recharging) does not work
Check the Clean Station’s installation status
• Check whether the Clean Station has been
installed in a place where the Clean Station
cannot guide the Jet Bot to return.
• Check whether the distance between the
Clean Station and the Jet Bot is over 5 m.
– It may take a longer time for the Jet Bot
to return to the Clean Station.
Charge the Jet Bot manually for the following
conditions.
• When the Clean Station is installed in a
corner
• When the battery is completely discharged
• When the Jet Bot is stuck in an obstacle
(e.g., furniture)
• When the Jet Bot cannot climb a threshold
near the Clean Station. (It should be less
than 1.5 cm.)
• When the Jet Bot’s Status Indicator turns
red and stays red with the Jet Bot not
working
NOTE
• If the power switch of the Jet Bot is off, the Jet Bot will not charge even if it is docked on the
Clean Station.
– Keep the Clean Station on at all times.
– If power is not supplied to the Clean Station, the Jet Bot cannot nd the Clean Station and
cannot automatically recharge.
• If the Jet Bot is left detached from the Clean Station, the battery drains naturally.
• When the Dustbin is full, the Jet Bot automatically returns to the Clean Station for recharging.
English
16
1_VR8500_EN_00858C-02_SW.indd 16 2022-10-13 오후 6:06:11

OPERATION
Using the Jet Bot
Before using the Jet Bot, press the power switch at the side of the Jet Bot to turn the Jet Bot
on.
 For the normal use of the Jet Bot’s functions, the SmartThings connection is required.
– For downloading and installing the SmartThings App, refer to the ‘SmartThings App (P.29-
33)’.
Basic use
OFF ON
Power on / off
Press the power switch at the side of the Jet
Bot to turn the Jet Bot on.
• During booting, the Jet Bot’s Status
Indicator turns on with a melody which
stops when the booting is complete.
Starting cleaning
Press the [ ] on the Jet Bot to start
cleaning in Auto Clean.
Stopping cleaning
• Press the [ ] on the Jet Bot to stop
operation while cleaning.
– When pressing the [ ], the Jet Bot
returns to the Clean Station and starts
charging.
 If the Jet Bot does not operate for
20 minutes after it stops operation, it
automatically returns to the Clean Station
to recharge.
Sleep Mode
• When the Jet Bot is not in operation, press
and hold the [ ] to set the Sleep Mode.
• In the Sleep Mode, press the [ ] to cancel
the Sleep Mode.
English
17
1_VR8500_EN_00858C-02_SW.indd 17 2022-10-13 오후 6:06:12

OPERATION
Operation status on the LED Status Indicator
Classication Color Meaning
Jet Bot
While
operating Red
Blinking without
moving An error occurs.
Blinking while
moving
Auto returning to the Clean Station
due to low battery
On Operating stops due to low battery
While
charging
Red, orange, or yellow
(depending on charging progress) While charging
Green Charging is complete.
Violet Software is being updated.
Clean Station
White
On (5 seconds) Clean Stations’ power is on.
On
Jet Bot’s Empty Dust function
is working, Jet Bot is docked
(1minute after the docking, it is
off.).
Red Blinking Clean Station’s cover is open. The
suction motor has a problem.
On Clean Station’s Dust Bag is full.
 If the Jet Bot starts charging from the depleted status, the Status Indicator turns red and
slowly blinks for about 20minutes.
English
18
1_VR8500_EN_00858C-02_SW.indd 18 2022-10-13 오후 6:06:12

OPERATION
Cleaning Functions
Cleaning Functions Operation
Cleaning Methods
• Auto Clean: Cleans automatically until the Jet Bot completes cleaning
all rooms one time.
• Room Clean: You can select a room you want to clean.
• Spot Clean: You can set a specic area you want to clean.
Cleaning Mode
• You can select one out of three modes.
 You can set the Cleaning Mode only when the Jet Bot is in Room
Clean.
Suction Power
• You can select the suction power from Max, Smart or Normal.
 When the Jet Bot is in ‘Smart’ suction power, the Intelligent Power
Control Clean work.
Repeat Clean
• The Jet Bot cleans repeatedly until its battery is discharged.
 After the Jet Bot completes cleaning one time and returns to the
Clean Station due to battery shortage, it does not clean again after
charging is complete.
Empty Dust
• You can select the Empty Dust conditions at the SmartThings App.
• When the Jet Bot returns to the Clean Station, it automatically
empties its Dustbin. (However, after the Spot Clean, the Jet Bot does
not empty its Dustbin automatically.)
 If the Empty Dust function does not work, check whether the top
cover of the Clean Station is open or the Dust Bag is full.
 While the Jet Bot is docked onto the Clean Station, press the [ ] to
start emptying its Dustbin.
Intelligent Power
Control Clean
 When the Jet Bot detects a carpet during cleaning, it increases its
suction power. (Suction Power: ‘Smart’ only)
 You can set the Cleaning Functions, the Repeat Clean or the Cleaning Mode at the SmartThings
App.
 When the Jet Bot does not have a saved map, it studies cleaning space through Auto Clean
function which starts from the Clean Station. After studying the cleaning space, a map is
saved. (The map creation is enabled through the SmartThings App only.)
 You can edit or delete the map at the SmartThings App.
 Room Clean or Spot Clean works regardless of choice sequences of the areas.
 If the Jet Bot is surrounded by low height obstacles, it may take more than 2 minutes to nd
its way out of them.
English
19
1_VR8500_EN_00858C-02_SW.indd 19 2022-10-13 오후 6:06:12

OPERATION
Additional functions
Additional functions Operation
Energy-Saving
Mode
• When charging is complete, the Jet Bot automatically enters the
Sleep Mode. While the Jet Bot is docked on the Clean Station,
press and hold the [ ] for 7 seconds to set it to the Sleep Mode.
To cancel the Sleep Mode, start cleaning or press the [ ] for
7seconds.
 When the Jet Bot is in the Energy-Saving Mode, the power is turned
off after charging is complete which means the Wi-Fi reception
waiting is not enabled, therefore the Jet Bot cannot be controlled
with the mobile app.
Downtime Mode
• You can set the Jet Bot not to clean within the Downtime at the
Settings.
 When Downtime comes, the Jet Bot returns to the Clean Station.
Scheduled Cleaning
• You can set the Jet Bot to clean at the Schedule.
 If the Jet Bot is detached from the Clean Station at the scheduled
time, the scheduled cleaning does not work.
Setting the No-go
Zones
• When the Jet Bot has saved a map, you can set the Jet Bot not to
enter a designated area.
 If the Jet Bot does not start cleaning from the Clean Station or the
installation place of the Clean Station has been changed, the Jet Bot
may clean the set No-go Zones.
 When setting the No-go Zones, you cannot include the Clean Station.
 You can set the Downtime mode, Scheduled Cleaning or No-go Zones at the SmartThings App.
NOTE
• When a Check Notice occurs or when you carry the Jet Bot to another place and start
cleaning, the Jet Bot spins left and right at a 30 degree angle to recognize its location before
it starts cleaning.
• If the Jet Bot cannot recognize its current location, it starts Auto Clean.
• The Jet Bot automatically performs a system check and restarts once a week.
English
20
1_VR8500_EN_00858C-02_SW.indd 20 2022-10-13 오후 6:06:13
