Samsung SC61 Series User manual

imagine the possibilities
Thank you for purchasing a Samsung product.
Vacuum Cleaner
user manual
✻Before operating this unit, please read the instructions carefully.
✻For indoor use only.
English
SC61** Series
DJ68-00660B-02.indb 1DJ68-00660B-02.indb 1 2016. 4. 14.  5:252016. 4. 14.  5:25

safety information
SAFETY INFORMATION
• Before operating the appliance, please read this manual thoroughly and
retain it for your reference.
• Because these following operating instructions cover various models,
the characteristics of your vacuum cleaner may differ slightly from those
described in this manual.
WARNING
WARNING
CAUTION/WARNING SYMBOLS USED
WARNING Indicates that a danger of death or serious injury exists.
CAUTION Indicates that a risk of personal injury or material damage exists.
OTHER SYMBOLS USED
Represents something you must NOT do.
Represents something you must follow.
Indicates that you must disconnect the power plug from the socket.
IMPORTANT SAFEGUARDS
• Read all instructions carefully. Before switching on, make sure
that the voltage of your electricity supply is the same as that
indicated on the rating plate on the bottom of the cleaner.
• WARNING: Do not use the vacuum cleaner when rug or floor is
wet. Do not use to suck up water.
• Close supervision is necessary when any appliance is used by
or near children. Do not allow the vacuum cleaner to be used
as a toy. Do not allow the vacuum cleaner to run unattended at
any time. Use the vacuum cleaner only for its intended use as
described in these instructions.
• Do not use the vacuum cleaner without a dust bag. Change the
dust bag before it is full in order to maintain the best efficiency.
2_ safety information
DJ68-00660B-02.indb 2DJ68-00660B-02.indb 2 2016. 4. 14.  5:252016. 4. 14.  5:25

• Do not use the vacuum cleaner to pick up matches, live ashes
or cigarette butts. Keep the vacuum cleaner away from stoves
and other heat sources. Heat can deform and discolour the
plastic parts of the unit.
• Avoid picking up hard, sharp objects with the vacuum cleaner
as they may damage the cleaner parts. Do not stand on the
hose assembly. Do not put weight on the hose. Do not block the
suction or the exhaust port.
• Switch the vacuum cleaner off on the body of the machine
before unplugging from the electrical outlet. Disconnect the plug
from the electrical outlet before changing the dust bag or dust
container. To avoid damage, please remove the plug by grasping
the plug itself, not by pulling on the cord.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance
by a person responsible for their safety.
Children should be supervised to ensure that they do not play
with the appliance.
• The plug must be removed from the socket outlet before
cleaning or maintaining the appliance.
• The use of an extension cord is not recommended.
• If your vacuum cleaner is not operating correctly, switch off the
power supply and consult an authorized service agent.
• If the supply cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualified person in
order to avoid a hazard.
• Don’t carry the vacuum cleaner by holding the hose.
Use the handle on the vacuum cleaner set.
• Unplug the cleaner when not in use. Turn off the power switch
before unplugging.
safety information
safety information _3
DJ68-00660B-02.indb 3DJ68-00660B-02.indb 3 2016. 4. 14.  5:252016. 4. 14.  5:25

contents
ASSEMBLING THE CLEANER
05
05 Assembling the Cleaner
OPERATING THE CLEANER
06
06 Power cord
06 On/Off Switch
06 Power control
MAINTAIN TOOLS AND FILTER
08
08 Using accessory
10 Maintain floor tools
11 Check filter indicator
12 Changing the dust bag
12 Cleaning inlet filter
12 Cleaning outlet filter
13 Change the battery (Optional)
TROUBLESHOOTING
14
4_ contents
DJ68-00660B-02.indb 4DJ68-00660B-02.indb 4 2016. 4. 14.  5:252016. 4. 14.  5:25

assembling the cleaner
• For storage, park the floor nozzle.
assembling the cleaner _5
01 ASSEMBLING THE CLEANER
OPTION
OPTION
• Features may vary according to model.
DJ68-00660B-02.indb 5DJ68-00660B-02.indb 5 2016. 4. 14.  5:252016. 4. 14.  5:25

operating the cleaner
POWER CORD
• When removing the plug from the electrical outlet, grasp the plug, not the cord.
POWER CONTROL
Remote-control type (OPTIONAL)
- HOSE
1. Vacuum cleaner ON/OFF
Press the ON/OFF button to operate the vacuum cleaner.
Press again to stop the vacuum cleaner.
2. Vacuum cleaner MIN/MID
Press the MIN/MID button to operate the vacuum at a low
level (for curtain cleaning, etc.).
Press again to operate the vacuum in a MID mode.
3. Using at MAX
Press the MAX button to operate the vacuum at maximum
intake.
ON/OFF SWITCH
6_ operating the cleaner
SENDER
HANDLE CONTROL
[The cleaner is controlled by using
infrared signals.]
CAUTION
DJ68-00660B-02.indb 6DJ68-00660B-02.indb 6 2016. 4. 14.  5:252016. 4. 14.  5:25

operating the cleaner _7
02 OPERATING THE CLEANER
- BODY
Press the power ON/OFF button repeatedly to start and to stop
the vacuum cleaner.
(OFF →ON →OFF) 2
1
If the remote handle control is not working, the cleaner
can be operated using the ON/OFF button on the
body of the machine.
1The ON/OFF button operates the vacuum cleanner or stops it.
2The INFRARED light indicates the part that receives the infra-red signal from the
handle control.
Body-control type (OPTIONAL)
- HOSE
To reduce suction for leaning draperies, small rugs, and other light
fabrics, pull the tap air until the hole is open
- BODY (VOLUME TYPE ONLY)
To control power level, just slide the power control bottom
right and left.
MIN = For delicate fabrics, e.g.net curtains.
MAX = For hard floors and heavily soiled carpets.
DJ68-00660B-02.indb 7DJ68-00660B-02.indb 7 2016. 4. 14.  5:252016. 4. 14.  5:25

8_ maintain tools and filter
maintain tools and filter
USING ACCESSORY
Pipe
• Adjust the length of the telescopic pipe by sliding the length
control button located in the center of the telescopic pipe back
and forth.
• To check for blockages, separate the telescopic pipe and adjust
to shorten. This allows for easier removal of waste clogging the
tube.
Accessory (Optional)
• Push the accessory on to the end of the
hose handle.
• Pull out and turn the dusting brush for
cleaning delicate areas.
• To use the upholstery tool, push the
accessory on to the end of the hose
handle in the opposite direction.
DJ68-00660B-02.indb 8DJ68-00660B-02.indb 8 2016. 4. 14.  5:252016. 4. 14.  5:25

maintain tools and filter _9
03 MAINTAIN TOOLS AND FILTER
Elbow Extending Tube (Optional)
• Connect the elbow extending tube to connecting part for hose knob and
telescopic pipe.
• Fit the telescopic pipe to the lower part of the elbow extending tube.
• Press the PUSH button.
• With the PUSH button pressed, the elbow extending tube is folded.
• Using the elbow extending tube allows hard to reach areas
(e.g. under furniture)to be cleaned without having to kneel
down.
DJ68-00660B-02.indb 9DJ68-00660B-02.indb 9 2016. 4. 14.  5:252016. 4. 14.  5:25

MAINTAIN FLOOR TOOLS
2-Step Brush (Option)
• Adjust the inlet lever according to the floor surface.
Carpet Cleaning Floor Cleaning
• Remove waste matter completely if the inlet is blocked.
maintain tools and filter
10_ maintain tools and filter
Parquet brush (Option)
Vacuum dust in wide area at once
• Remove waste matter completely if the inlet is blocked.
DJ68-00660B-02.indb 10DJ68-00660B-02.indb 10 2016. 4. 14.  5:252016. 4. 14.  5:25
