Samsung SC88 series User manual

imagine the possibilities
Thank you for purchasing a Samsung product.
Vacuum Cleaner
user manual
✻Before operating this unit, please read the instructions carefully.
✻For indoor use only.
English
SC88** series
DJ68-00597H-05.indb 1DJ68-00597H-05.indb 1 14. 7. 4.  1:3214. 7. 4.  1:32

2_ safety information
safety information
SAFETY INFORMATION
•Before operating the appliance, please read this manual thoroughly and retain it for
your reference.
•Because these following operating instructions cover various models, the
characteristics of your vacuum cleaner may differ slightly from those described in this
manual.
CAUTION/WARNING SYMBOLS USED
WARNING Indicates that a danger of death or serious injury exists.
CAUTION Indicates that a risk of personal injury or material damage exists.
OTHER SYMBOLS USED
Represents something you must NOT do.
Represents something you must follow.
Indicates that you must disconnect the power plug from the socket.
This vacuum cleaner is designed for domestic household use only. Do not use this
vacuum cleaner to clean building waste or debris. Do not use this vacuum cleaner with
any of the filters removed as this could cause damage to the internal components and
void your warranty.
WARNING
WARNING
WARNING
DJ68-00597H-05.indb 1:2DJ68-00597H-05.indb 1:2 14. 7. 4.  1:3214. 7. 4.  1:32

safety information _3
IMPORTANT SAFEGUARDS
1. Read all instructions carefully. Before switching on, make sure that the
voltage of your electricity supply is the same as that indicated on the
rating plate on the bottom of the cleaner.
2. WARNING : Do not use the vacuum cleaner when rug or floor is wet.
Do not use to suck up water.
3. Close supervision is necessary when any appliance is used by or
near children. Do not allow the vacuum cleaner to be used as a toy.
Do not allow the vacuum cleaner to run unattended at any time.
Use the vacuum cleaner only for its intended use as described in
these instructions.
4. Do not use the vacuum cleaner without a dust bin.
Empty the dust bin before it is full in order to maintain the best
efficiency.
5. Do not use the vacuum cleaner to pick up matches, live ashes or
cigarette butts.
Keep the vacuum cleaner away from stoves and other heat sources.
Heat can deform and discolour the plastic parts of the unit.
6. Avoid picking up hard, sharp objects with the vacuum cleaner as
they may damage the cleaner parts.
Do not stand on the hose assembly.
Do not put weight on the hose. Do not block the suction or the
exhaust port.
7. Switch the vacuum cleaner off on the body of the machine before
unplugging from the electrical outlet. Disconnect the plug from the
electrical outlet before emptying the dust bin.
To avoid damage, please remove the plug by grasping the plug itself,
not by pulling on the cord.
8. This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved.
safety information
DJ68-00597H-05.indb 1:3DJ68-00597H-05.indb 1:3 14. 7. 4.  1:3214. 7. 4.  1:32

4_ safety information
9. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children
without supervision.
10. The plug must be removed from the socket outlet before cleaning or
maintaining the appliance.
11. The use of an extension cord is not recommended.
12. If your vacuum cleaner is not operating correctly, switch off the
power supply and consult an authorized service agent.
13. If the supply cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualified person in
order to avoid a hazard.
14. Don’t carry the vacuum cleaner by holding the hose.
Use the handle on the vacuum cleaner set.
15. Unplug the cleaner when not in use.
Turn off the power switch before unplugging.
safety information
DJ68-00597H-05.indb 1:4DJ68-00597H-05.indb 1:4 14. 7. 4.  1:3214. 7. 4.  1:32

contents _5
contents
ASSEMBLING THE CLEANER
06
06 Assembling the Cleaner
OPERATING THE CLEANER
07
07 Power cord
07 On/Off switch
07 Power control
MAINTAIN TOOLS AND FILTER
09
09 Using accessory
10 Maintain floor tools
11 Emptying the dust bin
12 Cleaning the dust pack
14 Cleaning the outlet filter
15 Change the battery (optional)
TROUBLESHOOTING
16
DJ68-00597H-05.indb 2:5DJ68-00597H-05.indb 2:5 14. 7. 4.  1:3214. 7. 4.  1:32

6_ assembling the cleaner
assembling the cleaner
• Please do not push the button
of dust bin handle when carrying
machine.
• For storage, park the floor nozzle.
OPTION
DJ68-00597H-05.indb 3:6DJ68-00597H-05.indb 3:6 14. 7. 4.  1:3214. 7. 4.  1:32

02 OPERATING THE CLEANER
operating the cleaner _7
operating the cleaner
POWER CORD
ON/OFF SWITCH
• When removing the plug from the electrical outlet, grasp the
plug, not the cord.
CAUTION
Don’t cover the handle sender when you use a
handle control button.
POWER CONTROL
1. Vacuum cleaner ON/OFF( )
Press the ON/OFF button to operate the
vacuum cleaner. Press again to stop the
vacuum cleaner.
2. Vacuum cleaner (+, -)
Press the (+) button to operate the
vacuum to high suction power. Press the
(-) button to operate the vacuum to low
suction power.
REMOTE-CONTROL TYPE (INFRARED CONTROL) (OPTIONAL)
- HOSE
Handle Control
The cleaner is controlled by using
infrared signals.
sender
DJ68-00597H-05.indb 4:7DJ68-00597H-05.indb 4:7 14. 7. 4.  1:3214. 7. 4.  1:32

8_ operating the cleaner
BODY-CONTROL TYPE (OPTIONAL)
- HOSE
To reduce suction for leaning draperies, small rugs, and
other light fabrics, pull the tap air until the hole is open.
- BODY (VOLUME TYPE ONLY)
To control power level, just slide the power control
bottom right and left.
MIN = For delicate fabrics, e.g.net curtains.
MAX = For hard floors and heavily soiled carpets.
- BODY
Press the power ON/OFF button repeatedly to start
and to stop the vacuum cleaner.
(OFF →ON →OFF)
If the remote handle control is not working, the
cleaner can be operated using the ON/OFF
button on the body of the machine.
1The ON/OFF button operates the vacuum cleanner or stops it.
2The INFRARED light indicates the part that receives the infra-red
signal from the handle control.
3The filter light is illuminated when the dust pack requires checking or
emptying. An audio signal will also sound.
1
3 2
DJ68-00597H-05.indb 4:8DJ68-00597H-05.indb 4:8 14. 7. 4.  1:3214. 7. 4.  1:32

03 MAINTAIN TOOLS AND FILTER
maintain tools and filter _9
maintain tools and filter
USING ACCESSORY
PIPE
• Adjust the length of the telescopic pipe by sliding
the length control button located in the center of the
telescopic pipe back and forth.
• To check for blockages, separate the telescopic pipe
and adjust to shorten. This allows for easier removal of
waste clogging the tube.
ACCESSORY (OPTIONAL)
• Push the accessory on to the end of
the hose handle.
• Pull out and turn the dusting brush
for cleaning delicate areas.
• To use the upholstery tool, push the
accessory on to the end of the hose
handle in the opposite direction.
DJ68-00597H-05.indb 5:9DJ68-00597H-05.indb 5:9 14. 7. 4.  1:3214. 7. 4.  1:32

10_ maintain tools and filter
MAINTAIN FLOOR TOOLS
2-STEP BRUSH (OPTION)
• Adjust the inlet lever according to the floor surface.
• Remove waste matter completely if the inlet is blocked.
Carpet Cleaning Floor Cleaning
• Vacuum dust in wide area at once.
• Remove waste matter completely if
the inlet is blocked.
PARQUET MASTER BRUSH (OPTION)
POWER PET PLUS BRUSH (OPTION)
Frequent vacuuming of hair or pet fur may cause a falling-off of the rotation due to
matters tangled around the drum. In this case, clean the drum with care.
1. Push the Open button of the transparent screen cover to separate the cover.
2. Remove the brushbar from the transparent screen.
3.
Remove waste matter such as dust and hair tangled around the brushbar using scissors.
4. Remove dust inside the brush housing using a dry duster or crevice tool.
5. Insert brushbar into rotating belt and assemble.
6. Click the transparent screen cover back into place to reassemble.
1 2 3
456
For improved
pickup of pet
hair and fibre on
carpets.
DJ68-00597H-05.indb 5:10DJ68-00597H-05.indb 5:10 14. 7. 4.  1:3214. 7. 4.  1:32

03 MAINTAIN TOOLS AND FILTER
maintain tools and filter _11
maintain tools and filter
EMPTYING THE DUST BIN
Once dust reaches the dust
full mark, empty the dust bin.
Take the dust bin out by
pushing the button. Separate the dust bin cover.
Throw the dust away in the
bin. Close the dust bin cover.
Before use, push the dust
bin into the main body of
the vacuum cleaner until
you hear the “click” sound.
45 6
12 3
You may rinse the dust bin
with cold water.
- Empty into a plastic bag.
(recommended for asthma/allergy sufferers)
DJ68-00597H-05.indb 5:11DJ68-00597H-05.indb 5:11 14. 7. 4.  1:3214. 7. 4.  1:32

12_ maintain tools and filter
When suction is noticeably reduced continuously, please cleaning the dust pack.
CLEANING THE DUST PACK
WHEN TO CLEAN THE DUST PACK
• The lamp will turn red
when suction is reduced.
If the light comes on,
please clean the dust
pack.
• If the filter check indicator turns red with the inlet
floating 10cm above flat floor, clean the dust pack.
• Turn the vacuum power to ‘MAX’.
ON(MAX) ➞OFF
Handle Control Body Control
DJ68-00597H-05.indb 5:12DJ68-00597H-05.indb 5:12 14. 7. 4.  1:3214. 7. 4.  1:32

03 MAINTAIN TOOLS AND FILTER
maintain tools and filter _13
maintain tools and filter
Make sure the filter is completely dry
before putting it back into the vacuum
cleaner. Allow 12 hours for it to dry.
CLEANING THE DUST PACK
1
4
7
10
2
5
8
11 12
3
Remove the dust bin. Separate the dust bin cover.
Before reassembly, align the
dust pack cover and dust
pack correctly. Close the dust bin cover.
Before use, push the dust
bin into the main body of
the vacuum cleaner until
you hear the “click” sound.
Remove the fixed frame of
the dust pack cover.
Separate the dust pack.
Let the sponge and filter dry
in the shade for more than
12 hours.
Put the sponge and filter into
the dust pack.
Remove the sponge and
filter from the dust pack.
Wash the sponge and the
filter of the dust pack with
water.
Put the assembled dust
pack into the cover.
6
9
DJ68-00597H-05.indb 5:13DJ68-00597H-05.indb 5:13 14. 7. 4.  1:3214. 7. 4.  1:32

14_ maintain tools and filter
CLEANING THE OUTLET FILTER
12
Press the fixed frame part at the back of
the main body to remove. Remove the dust bin and Filter as shown.
Remove and replace the
blocked outlet filter.
Replacement filters are available at
your local Samsung distributor.
DJ68-00597H-05.indb 5:14DJ68-00597H-05.indb 5:14 14. 7. 4.  1:3214. 7. 4.  1:32

03 MAINTAIN TOOLS AND FILTER
maintain tools and filter _15
maintain tools and filter
CHANGE THE BATTERY (OPTIONAL)
1. When the vacuum cleaner dows not work, replace the batteries.
If the problem persists, please contact our authorized dealer.
2. Use 2 batteries of size AAA.
1. Never disassemble or recharge the batteries.
2. Never heat up the batteries or throw them into fire.
3. Do not reverse (+), (-) poles.
4. Dispose of the batteries property.
WARNING
BATTERY TYPE : AAA Size
DJ68-00597H-05.indb 5:15DJ68-00597H-05.indb 5:15 14. 7. 4.  1:3214. 7. 4.  1:32

16_ troubleshooting
troubleshooting
PROBLEM SOLUTION
Motor does not start • Check cable, pulg and socket.
• Leave to cool.
Suction force is gradually
decreasing • Check for blockage and remove.
Cord does not rewind
fully
• Pull the cord out 2-3m and push down the cord rewind
button.
Vacuum cleaner does
not pick up dirt • Check hose and replace if required.
Low or decreasing
suction
• Please check filter and, if required, clean as illustrated in the
instructions. if filters are out of condition change them to new
ones.
Body overheating • Please check filters, If required clean as illustrated in the
instruction.
Static electicity discharge • Please decrease power suction.
This Vacuum cleaner is approved the following.
EMC Directive : 2004/108/EEC
Low Voltage Directive : 2006/95/EC
DJ68-00597H-05.indb 6:16DJ68-00597H-05.indb 6:16 14. 7. 4.  1:3214. 7. 4.  1:32

Product fiche
[English]
According to Comission Regulation(EU) No 665/2013
ASupplier Samsung Electronics., Co. Ltd
BModel SC88H0
CType General purpose vacuum cleaner
DEnergy Efficiency Class F
EAnnual Energy Consumption (kWh/yr) 58.0
FCarpet Cleaning Performance Class D
GHard-floor Cleaning Performance Class D
HDust Re-Emission Class A
ISound Power Level (dBA) 81
JPower Consumption (W) 1300
KEco Label No
1) Annual energy consumption is calculated based on 50 cleaning tasks per year.
2) Actual annual energy consumption will depend on how the appliance is used.
DJ68-00597H-05.indb 6:17DJ68-00597H-05.indb 6:17 14. 7. 4.  1:3214. 7. 4.  1:32

memo
DJ68-00597H-05.indb 6:18DJ68-00597H-05.indb 6:18 14. 7. 4.  1:3214. 7. 4.  1:32

memo
DJ68-00597H-05.indb 6:19DJ68-00597H-05.indb 6:19 14. 7. 4.  1:3214. 7. 4.  1:32

DJ68-00597H-05.indb 6:20DJ68-00597H-05.indb 6:20 14. 7. 4.  1:3214. 7. 4.  1:32
