Samsung SU12F40 SERIES User manual

English
Vacuum Cleaner
user manual
✻Please read the User Manual thoroughly before operating the vacuum.
✻For indoor use only.
Thank you for purchasing a Samsung product.
SU12F40 SERIES
DJ68-00709E (EN)-00.indd 1 2014. 4. 29. �� 9:06

Contents
YOUR VACUUM CLEANER
07
07 Product view
08 Carton contents
BEFORE USING THE VACUUM
CLEANER
09
09 Assemble the handle and pipe
10 Attaching the accessories
11 Using the accessories
OPERATING THE VACUUM
12
12 Stowing the power cord
13 Extending the Pipe
13 Using upright mode
14 Operating the Brush bar On / Off Switch
14 Resetting the overload protector
14 Using the vacuum's handle
(The dust bin handle)
15 Using the accessory kit (optional)
MAINTENANCE
17
17 Emptying the dust bin
18 Cleaning the grille
19 Cleaning the premotor filter
21 Cleaning the filter
23 Checking Brush
24 Checking for clogs
25 Mini turbo brush (optional)
26 Cleaning the diverter cover
TROUBLESHOOTING
27
DJ68-00709E (EN)-00.indd 2 2014. 4. 29. �� 9:06

English - 03
Safety information
SAFETY INFORMATION
WARNING
Before operating the appliance, please read this manual thoroughly and retain it for
your reference.
WARNING
Because the following operating instructions cover various models, the
characteristics of your vacuum cleaner may differ slightly from those described in
this manual.
CAUTION/WARNING SYMBOLS USED
WARNING Indicates that a risk of death or serious injury exists.
CAUTION Indicates that a risk of personal injury or material damage exists.
OTHER SYMBOLS USED
Indicates something you must NOT do.
Indicates instructions you must follow.
Indicates that you must disconnect the power plug from the socket.
WARNING
This vacuum cleaner is designed for household use only.
Do not use this vacuum cleaner to clean building waste or debris.
Clean the filters regularly to prevent fine dust from collecting in them.
Do not use this vacuum cleaner with any of the filters removed.
Failure to meet these requirements could cause injury, damage the vacuum
cleaner and void your warranty.
DJ68-00709E (EN)-00.indd 3 2014. 4. 29. �� 9:06

English - 04
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, you should always follow these
basic precautions:
READ ALL INSTRUCTIONS BEFORE USING YOUR UPRIGHT
VACCUM
WARNING – TO REDUCE THE RISK OF FIRE, ELECTRIC
SHOCK, OR INJURY:
1. Do not leave the vacuum cleaner unattended when it is plugged
in. Unplug it from the outlet when your are not using it and before
servicing.
2. Do not use outdoors or on wet surfaces.
3. Do not allow the vacuum to be used as a toy.
Pay close attention when the vacuum is used by or near children.
4. Use only as described in this manual. Use only the manufacturer’s
recommended attachments.
5. Do not use with a damaged cord or plug.
If the vacuum is not working as it should, has been dropped,
damaged, left outdoors, or dropped into water, bring it to a service
center.
6. Do not pull or carry the vacuum by the cord, use the cord as a
handle, close a door on the cord, or pull the cord around sharp
edges or corners.
Do not run the vacuum over the cord.
Keep the cord away from heated surfaces.
7. Do not unplug by pulling on the cord.
To unplug, grasp the plug, not the cord.
8. Do not handle the plug or vacuum with wet hands.
Safety information
DJ68-00709E (EN)-00.indd 4 2014. 4. 29. �� 9:06

English - 05
9. Do not put any object into openings or vents.
Do not use with any opening blocked.
Keep free of dust, lint, hair, and anything that may reduce air flow.
10. Keep hair, loose clothing, fingers, and all parts of your body away
from openings and moving parts.
11. Turn off all controls before unplugging.
12. Use extra care when cleaning on stairs.
13. Do not use to pick up flammable or combustible liquids, such as
gasoline, or use in areas where they may be present.
14. Do not pick up anything that is burning or smoking, such as
cigarettes, matches, or hot ashes.
15. Do not use without the dirt cup and/or filters in place.
16. Do not use the vacuum cleaner in an enclosed space filled with
vapors given off by oil base paint, paint thinner, some moth
proofing substances, flammable dust, or other explosive or toxic
materials.
17. Store your vacuum cleaner indoors, in a cool and dry area.
18. Use only on dry, indoor surfaces.
19. Do not modify the polarized plug to fit a non-polarized outlet or
extension cord.
20. Do not touch the brush drum when it is rotating.
21. Keep suction away from your face when using nozzles and pipe.
22. Do not pull the power cord around sharp corners and do not allow
it to become trapped.
23. This vacuum is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning its use by a person
responsible for their safety.
24. Children should be supervised to ensure that they do not play with
the vacuum.
25. You must remove the plug from the socket-outlet before cleaning
or performing maintenence on the vacuum.
26. If the power cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualified person.
DJ68-00709E (EN)-00.indd 5 2014. 4. 29. �� 9:06

English - 06
27. Hold plug when rewinding onto cord reel.
Do not allow plug to whip when rewinding.
28. Do not pick up hard or sharp objects such as glass, nails, screws,
coins, etc.
29. Always turn off the vacuum before connecting or disconnecting
the handy vacuum cleaner.
30. Don’t touch the exhaust vent when the exhaust temperature is
hot.
SAVE THESE INSTRUCTIONS
POLARIZED PLUG INSTRUCTIONS
- To reduce the risk of electric shock, this appliance has a polarized
plug (one blade is wider than the other).
This plug will fit in a polarized outlet only one way.
If the plug does not fit fully in the outlet, reverse the plug.
If it still does not fit, contact a qualified electrician to install a proper
outlet. Do not modify the plug in any way.
DJ68-00709E (EN)-00.indd 6 2014. 4. 29. �� 9:06

English - 07
01 YOUR VACUUM CLEANER
PRODUCT VIEW
Brush bar On/Off
Button
Power On/Off
Button
Dust Bin
Brush bar
Pipe
POWER CORD
Handle
Dust Bin Release
Button
Carrying Handle
(Dust Bin Handle)
CAUTION
Do not plug in your vacuum cleaner until you are familiar with all instructions and
operating procedures.
WARNING
Plastic film can be dangerous.
To avoid the danger of suffocation, keep the film away from babies and children.
Your vacuum cleaner
DJ68-00709E (EN)-00.indd 7 2014. 4. 29. �� 9:06

English - 08
CARTON CONTENTS
(1) (2) (3)
(4) (5) (6)
• Empty carton. Find the parts shown above before disposing of packing materials.
1. Vacuum cleaner body
2. Handle
3. Pipe
4. 2 In 1 Accessory
5. Accessory Kit (Optional depending on the model)
6. Users Manual
DJ68-00709E (EN)-00.indd 8 2014. 4. 29. �� 9:06

English - 09
02
BEFORE USING THE VACUUM CLEANER
ASSEMBLE THE HANDLE AND PIPE
0N/OFF
• Connect the Handle and Body. • Unpack the wrapped screw and then
fasten the screw using a Phillips head (+)
screwdriver as shown.
1
Click
2 3
1. Stand the vaccum upright, and then insert the bottom of the pipe into the body hole
until you hear a click.
2. Insert the hook on the top portion of the pipe into the hole in the handle as shown. The
hook should push the sky-blue button in the handle back.
3. Attach the top of the pipe to the handle, and then cover with the cap.
Before using the vacuum cleaner
DJ68-00709E (EN)-00.indd 9 2014. 4. 29. �� 9:07

English - 10
• Wind cord around the cord hangers and
secure with clip.
ATTACHING THE ACCESSORIES
DJ68-00709E (EN)-00.indd 10 2014. 4. 29. �� 9:07

English - 11
02
BEFORE USING THE VACUUM CLEANER
USING THE ACCESSORIES
• Crevice tool
• Dusting Brush
DJ68-00709E (EN)-00.indd 11 2014. 4. 29. �� 9:07

English - 12
STOWING THE POWER CORD
CAUTION
When removing the plug from an electrical outlet, grasp the plug,
not the cord.
Operating the vacuum
DJ68-00709E (EN)-00.indd 12 2014. 4. 29. �� 9:07

English - 13
03 OPERATING THE VACUUM
EXTENDING THE PIPE
Pipe mode
1 2
• Push up the handle cap, and then separate the pipe from the body.
• Push the button on the pipe to make the pipe longer.
USING UPRIGHT MODE
Upright mode
1 2
• Place a foot on the brush, and then tilt the handle back gently to release the lock.
• Push the power On/Off switch.
DJ68-00709E (EN)-00.indd 13 2014. 4. 29. �� 9:07

English - 14
OPERATING THE BRUSH BAR ON / OFF SWITCH
1
ON/OFF
2
• Push the power On/Off switch, and then push the brush bar On/Off switch.
• The Brush Switch should be in the "On" position for normal carpet cleaning.
• Turn the Brush Switch "Off" for bare floor cleaning or other delicate surfaces.
CAUTION
In the upright position, the Brush bar does not work.
RESETTING THE OVERLOAD PROTECTOR
• The overload protector shuts off the brush
motor if the brush bar becomes obstructed.
To reset the overload protector, use a pen tip
to press the reset switch.
USING THE VACUUM'S HANDLE (THE DUST BIN HANDLE)
CAUTION
When you carry the vacuum cleaner by the handle, do not push the dust bin release
button.
DJ68-00709E (EN)-00.indd 14 2014. 4. 29. �� 9:07

English - 15
03 OPERATING THE VACUUM
USING THE ACCESSORY KIT (OPTIONAL)
Funiture tool
Upholstery
Mini turbo brush
DJ68-00709E (EN)-00.indd 15 2014. 4. 29. �� 9:07

English - 16
Pet Tool
• Rake the hair.
• Seperate the cover from the pet tool, and then throw the hair away.
• Re-attach the cover.
DJ68-00709E (EN)-00.indd 16 2014. 4. 29. �� 9:07

English - 17
04 MAINTENANCE
Maintenance
EMPTYING THE DUST BIN
• Empty the dust bin when dust reaches the
'MAX' mark.
• Take the dust bin out by pushing the
button on the handle.
1
• To empty the dust bin, hold the dust bin
over a garbage can, and then push the
button near the bottom of the bin.
2
Alternately, for asthma or allergy sufferers:
• To empty the dust bin, place the bottom
of the bin into a plastic bag as shown.
Holding the bag firmly, push the button
near the bottom of the bin.
3
• With the bin still in the plastic bag, close
the bottom of the bin.
Remove the bin from the plastic bag, seal
the bag, and then drop it in the trash can.
4
DJ68-00709E (EN)-00.indd 17 2014. 4. 29. �� 9:07

English - 18
CLEANING THE GRILLE
• Separate the dust bin from the vacuum's
body. 1
• Clean the grille with the dusting brush to
remove lint. 2
• To re-attach the dust bin to the vacuum's
body, follow steps 3 and 4. 3
4
DJ68-00709E (EN)-00.indd 18 2014. 4. 29. �� 9:07

English - 19
04 MAINTENANCE
CLEANING THE PREMOTOR FILTER
• Pull the dust bin cover to open. 1
• Remove the filter from the dust bin. 2
• Shake the filter to remove dust, and then
wash the filter. 3
• Leave the filter in the shade until
completely dry. 4
DJ68-00709E (EN)-00.indd 19 2014. 4. 29. �� 9:07

English - 20
• Put the filter into the dust bin. 5
Check the filter regularly and wash every 1~2 months.
Make sure the filter is completely dry before putting it back into the vacuum cleaner.
Allow it to dry for 12 hours.
Do not use a wet filter
Replace the dust filter if it becomes damaged or deformed.
The dust bin cover will not close if the filter is not installed correctly.
DJ68-00709E (EN)-00.indd 20 2014. 4. 29. �� 9:07
