Samsung VS20A95 Series User manual

Viewing the usermanuals
STEP1 Launch a QR code reader app and then
scan the QR image attached to the
product.
STEP 2 Select a menu from the product
registration, viewing the manuals, or
connecting a service. When you select
a manual, you can view the manual of
your purchased product.
Vacuum cleaner
Usermanual
VS20A95**** Series
• In order to save valuable resources, we are reducing paper manuals and
providing electronic user manuals that you can check on your smartphone
or a website.
• For the instructions of how to use the product, please refer to the user
manuals provided as QR code or the Samsung Electronics’ website
(www.samsung.com).
Untitled-4 1 2022-09-05  2:49:52

English2
Safety information
• Before operating the appliance, please read this manual thoroughly
and retain it foryour reference.
• Because the following operating instructions covervarious models,
the characteristics of yourvacuum cleaner may differ slightly from
those described in this manual.
Important safety symbols
WARNING
Indicates that a danger of death or serious injury exists.
CAUTION
Indicates that a risk of personal injury or material damage exists.
NOTE
Indicates that the following text contains additional important
information.
Safety information
Untitled-4 2 2022-09-05  2:49:53

English 3
Safety information
General
For information on Samsung’s environmental commitments and
product specific regulatory obligations e.g. REACH (WEEE, Batteries)
visit: samsung.com/uk/aboutsamsung/samsungelectronics/
corporatecitizenship/data_corner.html
Failure to meet these requirements could cause damage to the internal
parts of the vacuum and void yourwarranty.
• Read all instructions carefully. Before switching the vacuum on, make
sure that the voltage of your electricity supply is the same as that
indicated on the rating plate at the rear of the handy vacuum cleaner
(battery contact side).
• This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children should not play with the
appliance. Children should not clean or perform maintenance on the
vacuum without adult supervision.
• Do not allow the vacuum cleaner to run unattended at any time.
• This product is intended for household use only. (Do not use this
product for other than its intended purposes.)
• Do not allow children to ride on or play with the product.
–An injury or product damage may occur.
Vacuum cleaner
• When assembling the vacuum, be careful not to catch your fingers or
hands in the movement fold of the handle.
Untitled-4 3 2022-09-05  2:49:53

Safety information
English4
Safety information
• Do not use the vacuum cleaner on a wet rug or floor.
• Do not use the product at the following places;
–In a place where a burning candle or a desk lamp is placed on the
floor.
–In a place where heaters are turned on or unextinguished embers
exist in an unattended fireplace or an ashtray etc.
–In a place where there are combustible materials such as oil paint,
paint thinner, mothproofing substances, gasoline, alcohol, thinner,
ashtrays with unextinguished cigarettes, etc.
–In a closed place filled with explosive or toxic vapor.
• Do not pick up the following things. Abnormal operation or product
damage may occur.
–A match or unextinguished ashes or cigarettes
–Hard or sharp objects
–Toxic materials (chlorine bleach, ammonia, drain cleaner etc.)
–Liquid such as water or beverage or pet's waste
–Chalk powder
• If there is a gas leak or combustible spray such as a dust remover
is used, do not touch the power outlet and open the window for
ventilation.
–An explosion or fire may occur.
• If the product makes a strange sound or emits a smell or smoke, turn
off the product immediately, and then contact a Samsung service
center.
–Electric shock or fire may occur.
Untitled-4 4 2022-09-05  2:49:53

English 5
Safety information
• When using the vacuum cleaner, be careful not to hurt yourself on the
moving or spinning parts.
–Keep your body parts (Hair, hands, etc.) from the spin brush or the
spin disk.
• When cleaning the wall or ceiling, you should use both hands.
–If you clean with one hand, you can damage your wrist or drop the
vacuum and cause an injury or damage the vacuum.
• Do not use the vacuum cleaner on objects that can be easily scratched
(monitors, stainless steel appliances, etc.).
• Sometimes the wheel of a brush can scratch the floor. Before using
the vacuum cleaner, check the wheels of the brush.
–If there is foreign matter on the wheel of the brush which cannot
be removed easily, contact a Samsung service center.
• When the spin brush inside a brush is working, do not touch the
brush.
–Otherwise, your hand can be caught and it may cause an injury.
• Do not use the vacuum cleaner in direct sunlight or high heat.
• If excessive force is applied to an accessory with motor or foreign
matter is caught in the spin brush (or spin disk), the accessory may
stop working to protect the motor or the product. Turn the vacuum
cleaner off, remove the foreign matter, and then turn it back on.
• Static electricity may occur depending on the humidity, temperature,
or floor material, etc. in your home. If it happens repeatedly, contact a
Samsung service center.
• Do not use Pet Tool in a small area for a long time and do not let Pet
Tool keep spinning in one place.
–Damage may occur if used on sensitive materials
Untitled-4 5 2022-09-05  2:49:53

Safety information
English6
Safety information
• Do not use Combination Tool on hard materials such as leather or
wood while bristles are not extended.
Maintenance
• While using or after using the vacuum cleaner, you should lay the
vacuum cleaner down or place it on the Clean Station to store.
–The product may fall and an injury and severe product damage
occur. In addition, you may not be compensated for the damage.
• Do not store the vacuum cleaner inside a car.
• Before removing foreign matter inside the product, turn off the
product first.
–If the product is on while you are removing the foreign matter, you
can hurt yourself or damage the product.
• When cleaning the exterior of the product, turn off the product first
and then wipe it with a dry towel. Do not spray water directly onto the
product or wipe it with volatile materials such as benzene, thinner, or
alcohol.
–If water gets into the product and an error occurs, turn off the
product and contact a Samsung service center.
• When cleaning the washable parts, do not use alkaline detergent,
acid, industrial detergent, air freshener, acetic acid, etc.
–Product damage such as plastic breakage, deformation,
discoloration, printing deterioration, etc. may occur.
Untitled-4 6 2022-09-05  2:49:53

English 7
Safety information
Washable Parts Dustbin, Washable Micro Filter, Fine Dust Filter, Metal Mesh
Grille Filter, dry cloth
Acceptable
detergent Neutral Dish washing detergent
Prohibited
detergent
Alkaline Lox, mold cleaner, etc.
Acid Paraffin oil, an emulsifier, etc.
Industrial
cleaners NV-I, PB-I, Opti, alcohol, acetone, benzene, thinner, etc.
Air freshener Jet spray air fresheners (coffee flavor, herb, etc.)
Oils Animal oils, vegetable oils
Etc. Edible acetic acid, vinegar, glacial acetic acid, etc.
• Storing the product in sunlight for long hours may cause parts of
the product to deform or discolor. Therefore, store the product in the
shade.
• After cleaning the dustbin, Metal Mesh Grille Filter, orWashable
Micro Filterwith water, dry them in the shade.
–When heat is applied, part deformation may occur.
Clean Station
• Do not pull or carry by the cord, use the cord as a handle, close a door
on the cord, or pull the cord around sharp edges or corners. Keep the
cord away from heated surfaces.
• Do not unplug by pulling on the cord. To unplug, grasp the plug, not
the cord.
• Do not pull the power cord and do not touch the power plug with wet
hands.
–Electric shock or fire may occur.
• Do not use extension cords or outlets with inadequately rated current.
Untitled-4 7 2022-09-05  2:49:53

Safety information
English8
Safety information
• If there is dust, water, etc. on a pin or contact point of the power plug
pin, wipe them carefully.
–Abnormal operation or electric shock may occur.
• Do not use a damaged power plug, power cord, or loose power outlet.
–Electric shock or fire may occur.
• Unplug the Clean Station from the outlet before servicing.
• Do not expose the Clean Station to high temperatures or allow
moisture or humidity of any kind to come into contact with the Clean
Station.
• Do not plug the Clean Station into a power source with the incorrect
voltage. Do not plug the Clean Station into a multi-plug outlet or
power strip.
–Electric shock or fire may occur.
• If the power cord is damaged, have a Samsung authorized service
center replace the power cord with a new power cord.
–Electric shock or fire may occur.
• Make sure that the charging terminals of the vacuum cleaner and the
Clean Station do not come into contact with a conductor such as a
bracelet, watch, metal rod, nail, etc.
–Product malfunction or electric shock may occur.
• As the Clean Station is designed for the use of Samsung Jet cordless
vacuum cleaner only, do not use the Clean Station for other electronic
appliances and other purposes.
–Severe damage to the Clean Station or fire may occur.
• Do not allow children to cling to or push the Clean Station.
–Personal injury, product and floor damage may occur.
• Do not charge the product near a window, heater, toilet, bathroom,
etc.
Untitled-4 8 2022-09-05  2:49:53

English 9
Safety information
• Do not attempt to open the Clean Station. Repairs should be only
carried out by a qualified Samsung service center.
• Injury or product malfunction from incorrect installation of the Clean
Station may not be compensated.
• Do not bend the power cord with excessive force or put heavy objects
on the power cord.
–Electric shock or fire may occur.
• Before unplugging or plugging in the Clean Station, turn off the
vacuum cleaner and make sure that the pins of the power plug do not
come into contact with your hands.
–Fire or electric shock may occur.
Battery
• Do not mutilate or incinerate batteries as they will explode at high
temperatures.
• Do not drop or strike the battery or subject it to a sudden shock.
• Do not disassemble the battery and make sure that you do not create
a short circuit across the plus (+) and minus (-) terminals.
• As the battery is manufactured only for this product, do not use the
battery for other electronic appliances or other purposes.
• When you purchase a new battery, make sure to check the model
name (VCA-SBTA95) and the genuine logo.
–Contact your nearest Samsung Electronics retailer or Samsung
service center to purchase any consumable accessories.
Untitled-4 9 2022-09-05  2:49:53

Safety information
English10
Safety information
• Leaks from battery cells can occur under extreme usage or
temperature conditions. If the liquid gets on your skin, wash the
affected area quickly with water. If the liquid gets into your eyes, flush
them immediately with clean water for a minimum of 10 minutes.
Seek medical attention.
• When attaching the battery to the vacuum cleaner, insert it until you
hear a click. This assures that the battery is firmly attached.
–Otherwise, the battery may fall and could cause product damage
or injury.
• If you are not going to use the vacuum cleaner for a long period of
time oryou are going to be away from home for a long period of
time, unplug the Clean Station, and then detach the battery from the
vacuum cleaner. When the battery is not being charged and not being
used, it will slowly discharge.
• To protect the motor and the battery, the product may not operate
when the temperature is lower than 5 °C or higher than 45 °C.
• Dispose of the dead battery in compliance with the local regulations.
Untitled-4 10 2022-09-05  2:49:53

English 11
Preparation
Accessories
The accessories with the ' * ' mark may differ depending on the models.
Telescopic pipe Pet Tool Combination Tool
Extension Crevice Tool Flexible Tool Dust bags (1 installed, 2 extra)
User manual
* Charger Accessory Cradle Clean Station
* Jet Dual Brush * Slim Action Brush * Accessory Cradle Holder
* Spray Spinning Sweeper /
Reusable wet pads
* Disposable wet pads /
Attachable pad
* Battery
(VS20A959***: 2 units)
* Optional
• VS20A958*** model: The additional battery and charger can be purchased separately.
• The Spray Spinning Sweeper includes reusable wet pads and disposable wet pads.
• The Spray Spinning Sweeper and Jet Dual Brush are only compatible with VS20A95**** model.
Preparation
Untitled-4 11 2022-09-05  2:49:54

Preparation
English12
Preparation
Parts overview
01
03
04
05
12
15
14
22
16
19
13
06
09
07
08
10
02
17
20
18
21
11
01 Power ( ) button
02 Suction power control buttons
03 Washable Micro Filter
04 Metal Mesh Grille Filter
05 Display
06 Dustbin release button
07 Fine Dust Filter
08 Dustbin
09 Adjustable pipe
10 Handle
11 Battery level indicator
12 Battery release button
13 Pipe release button
14 Pipe length adjustment button
15 Brush release button
16 Dustbin joint
17 Clean Station START/STOP button
18 Dust bag
19 Clean Station front cover
20 Clean Station Premotor Filter
21 Clean Station Fine Dust Filter
22 Power cord
NOTE
The wave pattern on the exterior of the product is a natural appearance due to the use of pearl plastic
materials and its pearl distribution. In addition, the shining pearl used in the material gives an excellent
gloss coating, no extra coating necessary.
Untitled-4 12 2022-09-05  2:49:55

English 13
Operation
For detailed information, please refer to the QR code.
Installing the Clean Station
1. Run the powercord of the Clean Station along the round groove at the bottom.
-Make sure the power cord is correctly placed so that the Clean Station stands without tilting.
2. Before plugging in the Clean Station, arrange the power cord neatly.
3. When plugging in the Clean Station, the START/STOP button turns blue for 5 seconds and goes off.
Using the Clean Station
START/STOP button
• After inserting the vacuum cleaner into the Clean Station, press the START/STOP button to empty the
dustbin.
-Press the START/STOP button again to stop its operation.
• Close the bottom cover of the dustbin before using the vacuum cleaner as the bottom cover is open
after emptying dustbin at the Clean Station.
Operation
Untitled-4 13 2022-09-05  2:49:55

Operation
English14
Operation
Using the buttons and display
8:
89
8;
01 Display
-Displays the current mode (‘MIN, MID, MAX, JET, or WET’) or the
alert message.
02 Power ( )
-Press this button to turn on or off the vacuum cleaner.
-When you turn on the power, the vacuum cleaner starts in the ‘MID’
mode.
-If you assemble the Spray Spinning Sweeper, the vacuum cleaner
starts in the ‘WET’ mode.
03 Suction power control (+/ -)
-You can change the suction power mode (‘MIN, MID, MAX, or JET’).
-In the ‘WET’ mode, press the +button to spray water once or press
and hold the +button to spray waterfor up to 2 seconds.
-Press and hold the +button for 3 seconds to enter or exit the
language setting. Press the +or –button to select a language.
-While the vacuum cleaner is on the Clean Station, press and hold the
+button for 5 seconds to enable or disable the Energy Saving mode.
NOTE
• Only the +button works when the vacuum cleaner is in the ‘WET’ mode.
• You cannot enter the language settings when the vacuum cleaner is in the ‘WET’ mode.
• The Energy Saving mode is automatically disabled if you use the vacuum cleaner.
• The brush may cling to the floor or does not turn properly depending on the floor material (a carpet, a
mat, bedding, etc.). If such a problem occurs, change the suction powermode to ‘MIN or MID’.
Alert messages
Message Explanation
Low battery Displays when battery is low.
Object stuck in brush/tool Error displays when something is caught in the brush or tool.
Filter not inserted Error displays when Micro Filter is missing.
Clogged Error displays when the vacuum cleaner is clogged.
Check brush, tool, or filter Alerts the user to check the brush, tool, or filter in order to
solve the clogging error.
Clean Micro filter Alerts and recommends the user to regularly check and wash
the Micro Filter.
Energy Saving on Displays when the Energy Saving mode is on.
Energy Saving off Displays when the Energy Saving mode is off.
Untitled-4 14 2022-09-05  2:49:55

English 15
Appendix
Product specification
Charging and cleaning time may differ depending on the brushes and the conditions of use.
Model VS20A95**** Series
Power consumption (Vacuum cleaner) Based on a handy vacuum cleaner: 580 W
Battery specification Li-ion 25.2 V, 2200 mAh, 7 cell
Weight (Vacuum cleaner) 2.7 kg (Jet Dual Brush)
Size Vacuum cleaner Width 250 mm x Depth 210 mm x Height 1,000 mm
Clean Station Width 300 mm x Depth 300 mm x Height 850 mm
Charging time 3.5 hours
Cleaning time (Default
mode: MID)
Combination Tool /
Extension Crevice Tool
MIN: Approx. 60 min. MID: Aprrox. 30 min.
MAX: Approx. 10 min. JET: Approx. 3 min.
Jet Dual Brush MIN: Approx. 42 min. MID: Aprrox. 24 min.
MAX: Approx. 14 min. JET: Approx. 8 min.
Slim Action Brush MIN: Approx. 50 min. MID: Aprrox. 25 min.
MAX: Approx. 15 min. JET: Approx. 9 min.
Spray Spinning Sweeper Approx. 100 min.
NOTE
Cleaning time stated in the above table is based on a test after using one battery. Cleaning time doubles
when you use two batteries consecutively.
Appendix
Untitled-4 15 2022-09-05  2:49:55

DJ68-00859F-01
Untitled-4 16 2022-09-05  2:49:55

Pregledanje korisničkih priručnika
1. KORAK Pokrenite aplikaciju za skeniranje QR
koda, pa skenirajte QR kôd koji se nalazi na
proizvodu.
2. KORAK Iz menija izaberite registraciju proizvoda,
pregledanje priručnika ili povezivanje
usluge. Kada izaberete priručnik, možete da
pregledate priručnik za kupljeni proizvod.
Usisivač
Korisnički priručnik
Serija VS20A95****
• Da bismo sačuvali dragocene resurse, smanjujemo količinu papirnih priručnika i
obezbeđujemo elektronske korisničke priručnike koje možete da pogledate na vašem
pametnom telefonu ili veb lokaciji.
• Uputstva za korišćenje proizvoda potražite u korisničkim priručnicima obezbeđenim u
vidu QR koda ili na veb lokaciji kompanije Samsung Electronics (www.samsung.com).
Untitled-22 1 2022-09-05  12:04:25

Srpski2
Bezbednosne informacije
• Pre rukovanja uređajem pažljivo pročitajte ovaj priručnik i sačuvajte ga za
buduću upotrebu.
• Karakteristike vašeg modela usisivača mogu neznatno da se razlikuju u
odnosu na one opisane u ovom priručniku jer se ova uputstva za rukovanje
odnose na različite modele.
Važni bezbednosni simboli
UPOZORENJE
Ukazuje na moguću opasnost od smrtnog ishoda ili ozbiljnih povreda.
OPREZ
Ukazuje na moguću opasnost od telesnih povreda ili oštećenja imovine.
NAPOMENA
Ukazuje na tekst koji sadrži dodatne važne informacije.
Bezbednosne informacije
Untitled-22 2 2022-09-05  12:04:26

Srpski 3
Bezbednosne informacije
Opšte
Za informacije o posvećenosti kompanije Samsung zaštiti životne sredine i
regulatornim obavezama specifičnim za proizvod, npr. REACH (Registracija,
evaluacija, autorizacija i restrikcije hemikalija) (WEEE, baterije), posetite
sledeću stranicu: samsung.com/uk/aboutsamsung/samsungelectronics/
corporatecitizenship/data_corner.html
Ukoliko se ne budete pridržavali ovih smernica, unutrašnji delovi usisivača
mogu biti oštećeni, a garancija poništena.
• Pažljivo pročitajte sva uputstva. Pre uključivanja usisivača proverite da li
se napon u naponskoj mreži podudara sa vrednošću koja je navedena na
pločici sa oznakama sa zadnje strane ručnog usisivača (strana na kojoj je
kontakt baterije).
• Uređaj mogu da koriste deca starija od 8 godina i osobe sa umanjenim
fizičkim, čulnim ili psihičkim sposobnostima i osobe koje ne poseduju
odgovarajuće iskustvo i znanje ako su pod nadzorom ili su dobile uputstva
za bezbedno korišćenje uređaja i ako razumeju opasnosti koje korišćenje
uređaja sa sobom nosi. Deca ne smeju da se igraju sa uređajem. Deca ne
smeju da čiste ili održavaju usisivač bez nadzora odrasle osobe.
• Nemojte da dozvolite da usisivač radi bez nadzora ni u jednom trenutku.
• Ovaj uređaj namenjen je isključivo za kućnu upotrebu. (Uređaj koristite
isključivo za predviđenu namenu.)
• Nemojte dozvoljavati deci da se penju na uređaj ili igraju sa njim.
–U suprotnom, može doći do povreda ili oštećenja uređaja.
Usisivač
• Prilikom sklapanja usisivača, vodite računa da ne prikleštite prste ili ruke u
prevoju ručke.
Untitled-22 3 2022-09-05  12:04:26

Bezbednosne informacije
Srpski4
Bezbednosne informacije
• Nemojte da koristite usisivač na vlažnom tepihu ili podu.
• Nemojte da koristite uređaj na sledećim mestima:
–na mestima na kojima je sveća koja gori ili stona lampa postavljena na
pod,
–na mestima na kojima su uključene grejalice ili na kojima postoji žar u
kaminu bez nadzora ili pepeljari itd.
–na mestima sa zapaljivim supstancama, poput uljanih farbi, razređivača,
sredstava za zaštitu od insekata, benzina, alkohola, razređivača,
pepeljare sa upaljenom cigaretom itd.
–u zatvorenom prostoru punom eksplozivnih ili toksičnih isparenja.
• Ne usisavajte sledeće stvari. Uređaj možda neće normalno raditi ili se može
oštetiti.
–šibica ili pepeo sa žarom ili cigarete
–čvrsti ili oštri predmeti
–toksična sredstva (izbeljivač, amonijak, sredstvo za odmašćivanje cevi
itd.)
–tečnosti poput vode ili pića ili izmeta kućnih ljubimaca
–prah od krede
• Ako dođe do curenja gasa, odnosno ako koristite zapaljivi sprej poput onog
za uklanjanje prašine, nemojte da dodirujete utičnicu i otvorite prozor da
biste provetrili prostoriju.
–Može doći do eksplozije ili požara.
• Ako se iz uređaja čuje neobičan zvuk, oseća miris ili se pojavi dim, odmah
ga isključite i pozovite servisni centar kompanije Samsung.
–Može doći do strujnog udara ili požara.
Untitled-22 4 2022-09-05  12:04:26
