Samsung SVR-433 User manual

VIDEO CASSETTE RECORDER
SVR-433
SVR-233
SVR-230B
SVR-230W
SVR-2301
SVR-131
SERVICE
1. Precautions
2. Alignment and Adjustment
3. Exploded View and Parts List
4. Electrical Parts List
5. Schematic Diagrams
Manual
VIDEO CASSETTE RECORDER CONTENTS
For mechanical disassembly and adjustment, refer to the “Mechanical Manual” (DX-9R AC68-00001A).
SERVICE MANUAL SVR-433/233/230B/230W/2301/131
ELECTRONICS
© Samsung Electronics Co., Ltd. APR. 2000
Printed in Korea
AC68-00906A
SVR-433/233
SVR-230B/230W
SVR-2301
SVR-131
REC STOP PLAY
PROG
EJECT STANDBY/ON
LINEIN 2
REW
F.F
VIDEO AUDIO
EJECT STANDBY/ON
REW F.F
PLAY
PROG REC STOP
EJECT
PROG
REC STOP
REW F.F
PLAY
STANDBY/ON
EJECT STANDBY/ON
REC STOP
PLAY
R
E
W
F
.
F
SHARPNESS

Samsung Electronics 1-1
1. Precautions
1. Be sure that all of the built-in protective devices are
replaced. Restore any missing protective shields.
2. When reinstalling the chassis and its assemblies, be
sure to restore all protective devices, including :
control knobs and compartment covers.
3. Make sure that there are no cabinet openings
through which people--particularly children
--might insert fingers and contact dangerous
voltages. Such openings include the spacing
between the picture tube and the cabinet mask,
excessively wide cabinet ventilation slots, and
improperly fitted back covers.
If the measured resistance is less than 1.0 megohm
or greater than 5.2 megohms, an abnormality exists
that must be corrected before the unit is returned
to the customer.
4. Leakage Current Hot Check (See Fig. 1-1) :
Warning : Do not use an isolation transformer
during this test. Use a leakage current tester or a
metering system that complies with American
National Standards Institute (ANSI C101.1,
Leakage Current for Appliances), and Underwriters
Laboratories (UL Publication UL1410, 59.7).
5. With the unit completely reassembled, plug the AC
line cord directly the power outlet. With the unit’s
AC switch first in the ON position and then OFF,
measure the current between a known earth
ground (metal water pipe, conduit, etc.) and all
exposed metal parts, including : antennas, handle
brackets, metal cabinets, screwheads and control
shafts. The current measured should not exceed
0.5 milliamp. Reverse the power-plug prongs in the
AC outlet and repeat the test.
6. X-ray Limits :
The picture tube is designed to prohibit X-ray
emissions. To ensure continued X-ray protection,
replace the picture tube only with one that is the
same type as the original.
Fig. 1-1 AC Leakage Test
7. Antenna Cold Check :
With the unit’s AC plug disconnected from the
AC source, connect an electrical jumper across the
two AC prongs. Connect one lead of the ohmmeter
to an AC prong.
Connect the other lead to the coaxial connector.
8. High Voltage Limit :
High voltage must be measured each time
servicing is done on the B+, horizontal deflection
or high voltage circuits.
Heed the high voltage limits. These include the
X-ray protection Specifications Label, and the
Product Safety and X-ray Warning Note on the
service data schematic.
9. Some semiconductor (“solid state”) devices are
easily damaged by static electricity.
Such components are called Electrostatically
Sensitive Devices (ESDs); examples include
integrated circuits and some field-effect transistors.
The following techniques will reduce the
occurrence of component damage caused by static
electricity.
10. Immediately before handling any semiconductor
components or assemblies, drain the electrostatic
charge from your body by touching a known
earth ground. Alternatively, wear a discharging
Wrist-strap device. (Be sure to remove it prior to
applying power--this is an electric shock
precaution.)
DEVICE
UNDER
TEST
(READING SHOULD
NOT BE ABOVE
0.5mA)
LEAKAGE
CURRENT
TESTER
EARTH
GROUND
TEST ALL
EXPOSED METER
SURFACES
ALSO TEST WITH
PLUG REVERSED
(USING AC ADAPTER
PLUG AS REQUIRED)
2-WIRE CORD

Precautions
1-2 Samsung Electronics
11. High voltage is maintained within specified limits
by close-tolerance, safety-related components and
adjustments. If the high voltage exceeds the
specified limits, check each of the special
components.
12. Design Alteration Warning :
Never alter or add to the mechanical or electrical
design of this unit. Example : Do not add
auxiliary audio or video connectors.
Such alterations might create a safety hazard.
Also, any design changes or additions will void
the manufacturer’s warranty.
13. Hot Chassis Warning :
Some TV receiver chassis are electrically
connected directly to one conductor of the AC
power cord. If an isolation transformer is not
used, these units may be safely serviced only if
the AC power plug is inserted so that the chassis
is connected to the ground side of the AC source.
To confirm that the AC power plug is inserted
correctly, do the following : Using an AC
voltmeter, measure the voltage between the
chassis and a known earth ground. If the reading
is greater than 1.0V, remove the AC power plug,
reverse its polarity and reinsert. Re-measure the
voltage between the chassis and ground.
14. Some TV chassis are designed to operate with 85
volts AC between chassis and ground, regardless
of the AC plug polarity. These units can be safely
serviced only if an isolation transformer inserted
between the receiver and the power source.
15. Never defeat any of the B+ voltage interlocks.
Do not apply AC power to the unit (or any of its
assemblies) unless all solid-state heat sinks are
correctly installed.
16. Always connect a test instrument’s ground lead to
the instrument chassis ground before connecting
the positive lead; always remove the instrument’s
ground lead last.
17. Observe the original lead dress, especially near
the following areas : Antenna wiring, sharp
edges, and especially the AC and high voltage
power supplies. Always inspect for pinched, out-
of-place, or frayed wiring. Do not change the
spacing between components and the printed
circuit board. Check the AC power cord for
damage. Make sure that leads and components
do not touch thermally hot parts.
18. Picture Tube Implosion Warning :
The picture tube in this receiver employs
“integral implosion” protection. To ensure
continued implosion protection, make sure that
the replacement picture tube is the same as the
original.
19. Do not remove, install or handle the picture tube
without first putting on shatterproof goggles
equipped with side shields. Never handle the
picture tube by its neck. Some “in-line” picture
tubes are equipped with a permanently attached
deflection yoke; do not try to remove such
“permanently attached” yokes from the picture
tube.
20. Product Safety Notice :
Some electrical and mechanical parts have special
safety-related characteristics which might not be
obvious from visual inspection. These safety
features and the protection they give might be
lost if the replacement component differs from the
original--even if the replacement is rated for
higher voltage, wattage, etc.
Components that are critical for safety are
indicated in the circuit diagram by shading,
( or ).
Use replacement components that have the same
ratings, especially for flame resistance and
dielectric strength specifications. A replacement
part that does not have the same safety
characteristics as the original might create shock,
fire or other hazards.

IMPORTANT SERVICE GUIDE
MODE SWITCH (PROGRAM SWITCH) ASSEMBLY POINT
1) When installing the ass’y full deck on the Main PCB, be sure to align the assembly point of mode switch.
ASSEMBLY POINT
Fig. 1
HOW TO EJECT THE CASSETTE TAPE
(If the unit does not operate on condition that tape is inserted into housing ass’y)
1) Remove the Holder Worm Œand the gear worm ´. (See Fig. 2)
2) Turn the Gear Worm Wheel ˇcounterclockwise in the direction of arrow with screw driver. (See Fig. 2)
3) When Slider S, T are approached in the position of unloading, rotate holder Clutch counterclockwise after inserting screw driver in the
hole of frame’s bottom in order to wind the unwounded tape. (Refer to Fig. 3)
(If you rotate Gear Worm Wheel continuously when tape is in state of unwinding, you may cause a tape contamination by grease and
tape damage. Be sure to wind the unwounded tape in the state of set horizontally.)
4) Rotate Gear Worm Wheel ˇcounterclockwise using screw driver again up to the state of eject mode and then pick out the tape.
(Refer to Fig. 2)
Fig. 2 Fig. 3
ΠHOLDER WORM
´ GEAR WORM
SCREW DRIVER
ˇ GEAR WORM WHEEL
FRAME

Samsung Electronics 2-1
2. Alignment and Adjustment
2-1 Reference
1) X-Point (Tracking center) adjustment, “Head switching adjustment” and “NVRAM option setting” can be adjusted with remote control.
2) When replacing the Micom (IC601) and NVRAM (IC605 ; EEPROM) be sure to adjust the “Head switching adjustment” and
“NVRAM option setting”.
3) When replacing the cylinder ass’y, be sure to adjust the “X-Point” and “Head switching adjustment”.
4) Among Samsung VCR remote control used for adjustment as a accessory, only the remote control that has figures buttons (0 ~ 9) is
available for all adjustment regardless of chassis.
5) How to adjustment.
- Press the “SW718 (TEST)” button on Main PCB to set the adjustment mode.
- If the corresponding adjustment button is pressed, the adjustment is performed automatically.
- If the adjustment is completed, be sure to turn the power off.
2-1-1 Location of adjustment button of remote control
Fig. 2-1
Q-PRO
IPC
DISPLAY
SHUTTLE
V-LOCK
CLR/RST F.ADV
INPUT INDEX TRK PROG
R
E
C
M
E
N
U
A
U
D
I
O
S
P
E
E
D
T
V
/
V
C
R
REPEAT
OK
<This type of remote control can adjust.> <This type of remote control can not adjust.>
Remote Control for adjustment is not supplied as a Service Jig.
R
E
P
E
A
T
STANDBY/ON DISPLAY
CNT.RESET SPEED
IIP/S IPC TRK
REC MENU
Head Switching Adjustment
("SPEED" Button)
NVRAM Option Setting
("MENU" Button)
X-Point (Tracking Center) Adjustment
("5" Button)
STANDBY/ON EJECT

2-2 Samsung Electronics
Alignment and Adjustment
2-1-2 SW718 (TEST) location for adjustment mode setting
Fig. 2-2 Main PCB (Top View)
PRESS

Alignment and Adjustment
Samsung Electronics 2-3
2-2 Mechanical Adjustment
Note : Refer to the Mechanical Manual “DX-9R (AC68-00001A)” for the adjustment and confirmation of
ass’y full deck.
2-2-1 The number and position of test point
Test point : TP601 (Control Pulse)
TP602 (H’D S/W -Trigger)
TP301 (Envelope)
TP302 (Audio output)
TP303 (Video output)
Fig. 2-3 Location of Test point (Main PCB-Top View)
AUDIO OUTPUT
HEAD SWITCHING
ENVELOPE
2-2-2 ACE Head Position (X-Point) Adjustment
(See the 2-2-1(d) ACE Head Position (X-Point) Adjustment
on page 2-2 of the Mechanical Manual)
1) Playback the alignment tape (Color bar).
2) Press the “SW718 (TEST)” button on Main PCB to
set the adjustment mode. (See Fig. 2-2)
3) Press the “5” button of remote control then
adjustment is operated automatically. (See Fig. 2-1)
4) Connect the CH-1 probe to TP301 (Envelope) the
CH-2 probe to TP602 (H’D switching pulse) and
then trigger to CH-1.
5) Insert the (-) driver into the X-Point adjustment
hole and adjust it so that envelope waveform is
maximum.
6) Turn the Power off.

2-4 Samsung Electronics
Alignment and Adjustment
2-3 Head Switching Point Adjustment
1) Playback the alignment tape.
2) Press the “SW718 (TEST)” button on Main PCB to set the adjustment mode. (See Fig. 2-2)
3) Press the “SPEED” button of remote control then adjustment is operated automatically. (See Fig. 2-1)
4) Turn the Power off.
2-4 NVRAM Option Setting
1) Press the “SW718 (TEST)” button on Main PCB to set the adjustment mode. (See Fig. 2-2)
2) Press the “MENU” button on the remote control about 5 seconds then option setting display is appeared.
(See Fig. 2-4 and 2-5)
3) Select the option number (See Table 2-1 ; Page 2-5) of corresponding model with “FF” and “REW” button on
the remote control.
4) If selecting the option number is completed, press the “PLAY” button of remote control.
(If “PLAY” button is pressed, the selected number is changes reversed color. ; See Fig. 2-4 and 2-5)
5) Press the “OK (VCR)”, “MENU (VCP)” button of remote control again to store the option number.
(“PLEASE WAIT” is displayed for a second as shown Fig. 2-6, 2-7 and this setting is completed.)
6) Turn the Power off.
1) NVRAM Option is adjusted at production line basically.
2) In case Micom (IC601) and NVRAM (IC605 ; EEPROM) is replaced, be sure to set the corresponding option number of the repaired
model. (If the option is not set, the unit is not operated.)
01 02 03 04 05 06 07 08
09 10 11 12 13 14 15 16
17 18 19 20 21 22 23 24
25 26 27 28 29 30 31 32
33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48
49 50 51 52 53 54 55 56
**OPTION DIODE **
CNG : SAVE : OK
Fig. 2-4 (VCR)
01 02 03 04 05 06 07 08
09 10 11 12 13 14 15 16
17 18 19 20 21 22 23 24
25 26 27 28 29 30 31 32
33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48
49 50 51 52 53 54 55 56
**OPTION DIODE **
CNG : SAVE : MENU
Fig. 2-5 (VCP)
01 02 03 04 05 06 07 08
09 10 11 12 13 14 15 16
17 18 19 20 21 22 23 24
25 26 27 28 29 30 31 32
33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48
49 50 51 52 53 54 55 56
**OPTION DIODE **
CNG : SAVE : OK
PLEASE WAIT
Fig. 2-6 (VCR)
01 02 03 04 05 06 07 08
09 10 11 12 13 14 15 16
17 18 19 20 21 22 23 24
25 26 27 28 29 30 31 32
33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48
49 50 51 52 53 54 55 56
**OPTION DIODE **
CNG : SAVE : MENU
PLEASE WAIT
Fig. 2-7 (VCP)

Alignment and Adjustment
Samsung Electronics 2-5
COUNTRY MODELS OPTION NUMBER
RUSSIA SVR-433 6, 8, 11, 12, 17, 18, 22, 25, 30, 31, 32, 35, 41, 42, 45, 50, 54
SVR-233 6, 8, 11, 17, 18, 22, 25, 30, 31, 32, 34, 41, 42, 45, 50, 54
SVR-230B 8, 11, 17, 18, 22, 25, 30, 31, 32, 34, 37, 38, 41, 42, 50, 54
SVR-230W 8, 11, 17, 18, 22, 25, 30, 31, 32, 34, 37, 38, 41, 42, 50, 54
SVR-2301 8, 11, 17, 18, 22, 25, 30, 31, 32, 34, 37, 38, 42, 50, 54
SVR-131 8, 9, 10, 11, 17, 18, 22, 30, 31, 32, 34, 39, 42, 45
<Table 2-1>

2-6 Samsung Electronics
Alignment and Adjustment
MEMO

Samsung Electronics 3-1
3. Exploded View and Parts List
3-1 Cabinet Assembly - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
3-2 Mechanical Parts (Top Side) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
3-3 Mechanical Parts (Bottom Side) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Page
3-2
3-4
3-6

Exploded View and Parts List
3-2 Samsung Electronics
3-1 Cabinet Assembly
S.N.A. : Service Not Available
157
153
FULL DECK (S.N.A.)
BOTTOM-COVER (S.N.A.)
TM401B
MAIN PCB (S.N.A.)
157
BRACKET-FRAME
(S.N.A.)
S601A
LD601S S602A
CN602S
CN3A1S
101
155
F-A/V JACK PCB (S.N.A.)
200
LED PCB (S.N.A.)
157
SHUTTLE PCB (S.N.A.)
CN703S
21
22 1
SVR-131
51
SVR-230B/230WSVR-433/233
1
21
22
21
22 1
SVR-2301
21
22 1
55
UT01
Q-PRO
IPC
DISPLAY
SHUTTLE
V-LOCK
CLR/RST F.ADV
INPUT INDEX TRK PROG
R
E
C
M
E
N
U
A
U
D
I
O
S
P
E
E
D
T
V
/
V
C
R
REPEAT
OK
R
E
P
E
A
T
STANDBY/ON DISPLAY
CNT.RESET SPEED
IIP/S IPC TRK
REC MENU
STANDBY/ON EJECT

Exploded View and Parts List
Samsung Electronics 3-3
Loc. No Parts No. Description ; Specification Remark
MODELS 1 21 51 101 TM401B UT01
SVR-433 AC97-00872A AC64-00203N AC64-00319A AC64-30892A AC61-11063C AC59-00016F
SVR-233 AC97-00873A AC64-00203P AC64-00319A AC64-30892A AC61-11063C AC59-00016F
SVR-230B AC97-00621H AC64-00177X - AC64-30892A AC61-11063C AC59-00016F
SVR-230W AC97-00621Y AC64-00177D - AC64-00293D AC61-11063C AC59-00016H
SVR-2301 AC97-00850A AC64-00097P - AC64-30892A AC61-11063C AC59-00017B
SVR-131 AC97-00621J AC64-00069D AC64-00216G AC64-30892A AC61-11063C AC59-00013C
1 Refer to table below ASSY-PANEL FRONT;ABS94HB,-
21 Refer to table below DOOR-CASSETTE;-,ABS,-,T2.5,189*28,GRAY,-
22 AC61-62032A SPRING-MASK;X-9,-,SUS,-,4.4,-,SV-C130
51 Refer to table below KNOB-SHUTTLE;-,ABS,-,GRAY,HB,SV-130G,-
101 Refer to table below CABINET-TOP;X-9,SECC,PCM,0.5,360*208*41,
153 AC60-12126A SCREW-BH;-,BH,-,4*12,FE,FZY,-,-,-
155 AC60-12134A SCREW-TAP BH;-,BH,-,2-4X16,-,FE
157 AC60-10063A SCREW-TAPTITE;BH,+,-,M3,L12,ZPC3,SWRCH18
200 AC39-10019A POWER CORD;KKP-419C,H03VVH2-F,VDE/KEMA-K
CN3A1S 3809-001110 CABLE-FLAT;30V,80C,150mm,7P,1.25mm,UL289
CN602S 3809-001112 CABLE-FLAT;30V,80C,130mm,5P,1.25mm,UL289
CN703S 3809-001112 CABLE-FLAT;30V,80C,130mm,5P,1.25mm,UL289 SHUTTLE MODELS ONLY
LD601A AC61-21009A HOLDER-LED;-,POM(M90-44),-,BLK,-,X-9
S601A AC61-21008A HOLDER-SENSOR;-,POM(M90-44),-,BLK,-,X-9
S602A AC61-21008A HOLDER-SENSOR;-,POM(M90-44),-,BLK,-,X-9
TM401B Refer to table below CON-BOARD ASSY;-,HIPS,-,T2,61,-,BLK,-,-,
UT01 Refer to table below REMOCON-ASSY;-,NR4834,-,34KEY,TWIN_M_PAL

Exploded View and Parts List
3-4 Samsung Electronics
3-2 Mechanical Parts (Top Side)
G001
K250 K248
K110
K502
K350 K330
K182 K140
K490
K530
K240
G532 G420
G450 K546
G510
B410
B440 B444 B446
B448 B452
G527
G520
G480
G680
S.N.A. S.N.A.
S.N.A.
S.N.A.
S.N.A.
G530
K340
B473
K188
G555
G546
S.N.A. : Service Not Available
S.N.A.

Exploded View and Parts List
Samsung Electronics 3-5
Loc. No Parts No. Description ; Specification Remark
B410 AC31-12016D MOTOR-LOADING ASSY;-,SNHNE,-,-
B440 AC60-10515A SCREW-MACHINE;-,PH,+,-,M3,L3,ZPC,-,YEL
B444 AC66-20571A GEAR-WORM;-,POM SW-01,0.5,2,-,4.5,X-9
B446 AC61-21005A HOLDER-WORM;-,POM M90-44,-,-,-,X-9
B448 AC66-20573A GEAR-WORM WHEEL;-,POM SW-01,0.6,11,-,6.6
B452 AC66-20575A GEAR-FL CAM;-,POM SW-01,M0.6,Z88,-,PCD58
B473 AC61-60559A SPRING-PINCH DRIVE;-,TS,SUS304,PI0.5,OD4
G001 AC97-00558A ASSY-CYLINDER;CX-9T,PAL 4HD/DLC (SVR-433)
AC97-00554A ASSY-CYLINDER;CX-9T, PAL 2HD(LP)/DLC (SVR-233/230B/230W/2301)
AC97-00555A ASSY-CYLINDER;CX-9T, PAL 2HD(LP) (SVR-131)
G420 AC66-80142A SLIDER-SUPPLY ASSY;-,X-9(TS),-,-,-,X-9
G450 AC66-80141A SLIDER-TAKE UP ASSY;-,X-9(TS),-,-,-,X-9
G480 AC33-00003A HEAD-ACE ASSY;SHINHEUNG;-,-,-,-,X-9
G510 6006-001075 SCREW-ASSY TAPT;WSP,PH,+,M2.6,L5.0,ZPC
G520 AC66-30539A LEVER-#9 GUIDE ASSY;-,X-9(TS),-,-,-,X-9
G527 AC61-60553A SPRING-#9 GUIDE;-,ES,SUS304-WPB,OD3.1,0.
G530 AC33-00002A HEAD-FE;-,HVFHP0038A,-,-,-,X-9
G532 AC60-10519A SCREW-TAP TITE;-,PH,+,-,M2.6,L8,ZPC
G546 AC66-30535A LEVER-FL DOOR;-,POM M90-44,-,-,BLK,X-9
G555 AC59-90403A UNIT-PINCH ASSY;X-9,-
G680 AC66-30557A LEVER-H/CLEANER ASSY;-,POM+URETHANE,-,- (OPTIONAL)
K110 AC66-10267A REEL-DISK S;-,POM M90-44,-,-,X-9
K140 AC66-10268A REEL-DISK T;-,POM M90-44,-,-,X-9
K182 AC66-30524A LEVER-IDLER;-,POM9044,-,-,-,-
K188 AC66-20577A GEAR-IDLER;-,PEBAX 7033,-,-,-,-,X-9
K240 AC66-30538A LEVER-TENSION ASSY;-,X-9(TS),-,-,-,X-9
K248 AC61-60554A SPRING-TENSION LEVER;-,ES,SUS304-WPB,OD3
K250 AC63-12029A BAND-BRAKE ASSY;-,X-9(TS),-,-,-,X-9
K330 AC66-30550A LEVER-S.BRAKE ASSY;-,POM+SUS,-,-,-,X-9
K340 AC66-30549A LEVER-T.BRAKE ASSY;-,POM+SUS,-,-,-,X-9
K350 AC61-60564A SPRING-BRAKE;-,TENSION,SWP-A,0.25,3,-,X-
K490 AC61-21010B HOLDER-CASS ASSY;-,SECC+POM+SUS,-,-,-,X-
K502 AC61-60561A SPRING-FL.LEVER-LR;-,ES,SUS304 WPB,PI2.7
K530 AC66-30546A LEVER-FL.ARM ASS’Y;-,SECC+POM+SUS,-,-,-,
K546 AC61-50658A GUIDE-CASS. DOOR;-,POM M90-44,-,-,NTR,-,

Exploded View and Parts List
3-6 Samsung Electronics
3-3 Mechanical Parts (Bottom Side)
G542 B560
B484
B458
B500
B488
B462
(OPTIONAL)
S.N.A.
S.N.A.
S.N.A.
S.N.A.
B456
K222 K200 K225 K221
B570
B238
S.N.A. : Service Not Available

Exploded View and Parts List
Samsung Electronics 3-7
Loc. No Parts No. Description ; Specification Remark
B238 AC61-50660A SLEEVE-TENSION;-,POM M90-44,-,-,ID3,-,-,
B456 AC66-20576A GEAR-JOINT 1;-,POM SW-01,M1.0,Z22,-,PCD2
B458 AC66-20574A GEAR-JOINT 2;-,POM SW-01,M1.0,Z14,-,PCD1
B462 AC60-10517A SCREW-TAP TITE;-,PH,+,-,M2.6,L5,ZPC,-,YE
B484 AC66-20580A GEAR-LOADING DRIVE;-,POM SW-01,M1.0,Z32,
B488 AC66-30543A LEVER-S LOAD ASSY;-,-,-,-,-,X-9
B500 AC66-30542A LEVER-T LOAD ASSY;-,-,-,-,-,X-9
B560 AC31-00005A MOTOR-CAPSTAN;-,F2QSB02,-,-
B570 AC60-10514A SCREW-CAPSTAN;-,PH,+,M2.6,L6,-
G542 AC66-60051A BELT-PULLEY;-,5CM-70,2 * 2,-,71.3,-,X-9
K200 AC61-21012A HOLDER-CLUTCH ASSY;-,-,-,-,-,X-9
K221 AC66-20581A GEAR-CENTER ASSY;-,POM,M=O.5,-,HIGHT T.,
K222 AC60-30306A WASHER-SLIT;-,-,ID2.1,OD5.0,T0.5,-,POLYS
K225 AC66-30547A LEVER-UP DOWN ASSY;-,POM+SUS,-,-,-,X-9

Exploded View and Parts List
3-8 Samsung Electronics
MEMO

Samsung Electronics 4-1
- - ASSY PCB-MAIN S.N.A.
S.M.P.S. PARTS
BD1SD1 AC27-92001M INDUCTOR;70UH-M RT BFS3565R2F,-,-,-,-
BD1SF1 3301-000297 CORE-FERRITE BEAD;AA,3.6x1.2x5.7mm,1400, SVR-2301 NOT USER
BD1SF3 AC27-92001M INDUCTOR;70UH-M RT BFS3565R2F,-,-,-,- SVR-2301 NOT USER
BD1SR1 3301-000297 CORE-FERRITE BEAD;AA,3.6x1.2x5.7mm,1400, SVR-2301 ONLY
BD1SS3 AC27-92001M INDUCTOR;70UH-M RT BFS3565R2F,-,-,-,-
C1SD03 2201-000828 C-CERAMIC,DISC;3.3nF,20%,400V,Y5U,TP,15x
C1SD04 2201-000828 C-CERAMIC,DISC;3.3nF,20%,400V,Y5U,TP,15x
C1SD11 2401-003303 C-AL;82uF,20%,400V,GP,BK,22X30,10
C1SD11 2401-003302 C-AL;47uF,20%,400V,GP,TP,18X31.5,7. SVR-2301 ONLY
C1SD12 2305-001029 C-FILM,MPEF;10nF,10%,630V,TP,12x9x12.5,5
C1SD12 2201-000828 C-CERAMIC,DISC;3.3nF,20%,400V,Y5U,TP,15x SVR-2301 ONLY
C1SD13 2301-000361 C-FILM,PEF;1.2nF,10%,50V,TP,-,5mm SVR-2301 ONLY
C1SD13 2201-000376 C-CERAMIC,DISC;0.22nF,5%,50V,SL,TP,6.3x3
C1SF12 2401-001200 C-AL;33uF,20%,50V,WT,TP,6.3x11,5 SVR-2301 NOT USER
C1SR12 2401-000905 C-AL;22uF,20%,16V,BP,-,6x11,2.5mm SVR-2301 ONLY
C1SR14 2301-000445 C-FILM,PEF;4.7nF,5%,50V,TP,5.5x7x3mm,5mm SVR-2301 ONLY
C1SS01 2305-001021 C-FILM,MPEF;100nF,20%,275V,TP,17.5x7x13.
C1SS02 2305-001021 C-FILM,MPEF;100nF,20%,275V,TP,17.5x7x13.
C1SS12 2201-000129 C-CERAMIC,DISC;0.1nF,10%,1kV,Y5P,TP,7x4,
C1SS31 2401-000385 C-AL;10uF,20%,100V,GP,TP,6.3x11,5
C1SS33 2401-001126 C-AL;330uF,20%,25V,WT,TP,10x12.5,5
C1SS34 2401-003477 C-AL;330UF,20%,25V,LZ,TP,10X12.5MM,
C1SS35 2401-003480 C-AL;1000UF,20%,10V,LZ,TP,10X16MM,5
C1SS36 2401-003480 C-AL;1000UF,20%,10V,LZ,TP,10X16MM,5
C1SS39 2301-000129 C-FILM,PEF;100nF,5%,50V,TP,10X9X4.3X5,5m
CN1SS1 3711-000178 CONNECTOR-HEADER;1WALL,2P,1R,3.96mm,STRA
D1SD11 0402-001195 DIODE-RECTIFIER;F1T4,400V,1.0A,TS-1,TP
D1SD31 0402-001195 DIODE-RECTIFIER;F1T4,400V,1.0A,TS-1,TP
D1SF05 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP SVR-2301 NOT USER
D1SF12 0402-001195 DIODE-RECTIFIER;F1T4,400V,1.0A,TS-1,TP SVR-2301 NOT USER
D1SR11 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, SVR-2301 ONLY
D1SS01 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP
D1SS02 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP
D1SS03 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP
D1SS04 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP
D1SS11 0402-000276 DIODE-RECTIFIER;UF4007,1KV,1A,DO-41,TP
D1SS32 0402-001194 DIODE-RECTIFIER;UG2D,200V,2A,DO-204AC,TP
D1SS33 0402-000431 DIODE-RECTIFIER;FML-M02S,200V,2.5A,TO-22
F1SS01 3601-001208 FUSE-CARTRIDGE;250V,1.6A,TIME-LAG,GLASS
IC1SF1 1203-001802 IC-PWM CONTROLLER;STR-G6551,TO-220F,5P,- SVR-2301 NOT USER
IC1SS1 0604-001028 PHOTO-COUPLER;TR,50-600%,250mW,DIP-4,ST
IC1SS2 AC14-12006D IC;KA431Z,TO-92,TAPING
L1SS02 AC29-30050C FILTER-LINE NOISE;-,25MH,0.35A,AC250V,BS
L1SS31 AC27-12001N COIL-CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,-
L1SS32 AC27-12001N COIL-CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,-
PT1SD1 AC26-00001D TRANS-SWITCHING;-,100V-240V,DEMCO,EE2821
PT1SD1 AC26-00001E TRANS-SWITCHING;-,230V,DEMCO,EE2821,1.3M SVR-2301 ONLY
Q1SR01 0502-001050 TR-POWER;2SC4517A,NPN,30W,TO-220,ST,10- SVR-2301 ONLY
Q1SR02 0501-000442 TR-SMALL SIGNAL;KTC3203-Y,NPN,400MW,T0-9 SVR-2301 ONLY
R1SD11 2001-000305 R-CARBON;110KOHM,5%,1/8W,AA,TP,1.8X3.2MM SVR-2301 ONLY
R1SD12 2001-000869 R-CARBON;56OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SD12 2001-000003 R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2mm SVR-2301 ONLY
R1SD13 2001-000076 R-CARBON;47KOHM,5%,1/4W,AA,TP,2.4X6.4MM
R1SD13 2001-000305 R-CARBON;110KOHM,5%,1/8W,AA,TP,1.8X3.2MM SVR-2301 ONLY
R1SD14 2001-000076 R-CARBON;47KOHM,5%,1/4W,AA,TP,2.4X6.4MM
R1SD14 2001-000305 R-CARBON;110KOHM,5%,1/8W,AA,TP,1.8X3.2MM SVR-2301 ONLY
R1SD15 2001-000076 R-CARBON;47KOHM,5%,1/4W,AA,TP,2.4X6.4MM
R1SD15 2001-000305 R-CARBON;110KOHM,5%,1/8W,AA,TP,1.8X3.2MM SVR-2301 ONLY
R1SD16 2003-000994 R-METAL OXIDE(S);33Kohm,5%,2W,AF,TP,3.9x
R1SD16 2006-000273 R-CEMENT;27Kohm,5%,2W,CA,BK,6.4x27x6.4m SVR-2301 ONLY
R1SD31 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SD31 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM SVR-2301 ONLY
R1SD32 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SD32 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2M SVR-2301 ONLY
R1SF11 2001-000076 R-CARBON;47KOHM,5%,1/4W,AA,TP,2.4X6.4MM SVR-2301 NOT USER
R1SF15 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,1.8X3.2M SVR-2301 NOT USER
R1SF19 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM SVR-2301 NOT USER
R1SF20 2003-000105 R-METAL OXIDE;0.33ohm,5%,2W,AD,TP,6x16mm SVR-2301 NOT USER
R1SF21 2001-000096 R-CARBON(S);1MOHM,5%,1/2W,AA,TP,2.4X6.4M SVR-2301 NOT USER
R1SR11 2003-000119 R-METAL OXIDE;0.68ohm,5%,2W,AE,TP,6x16mm SVR-2301 ONLY
R1SR12 2003-000264 R-METAL OXIDE;300ohm,5%,1W,AD,TP,4.3x12m SVR-2301 ONLY
R1SR14 2001-000003 R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2mm SVR-2301 ONLY
R1SS10 2006-000262 R-CEMENT;2.7ohm,10%,2W,CB,TP,7.5x11x20.
R1SS11 2003-000994 R-METAL OXIDE(S);33Kohm,5%,2W,AF,TP,3.9x SVR-2301 NOT USER
R1SS13 2003-000148 R-METAL OXIDE;100OHM,5%,2W,AE,TP,6X16MM
R1SS32 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SS33 2004-000869 R-METAL;3Kohm,1%,1/8W,AA,TP,1.8x3.2mm
R1SS34 2004-000459 R-METAL;2.2Kohm,1%,1/8W,AA,TP,1.8x3.2m
VA1SS1 1405-001026 VARISTOR;470V,600A,9x7mm,TP
ZD1SS1 0403-000571 DIODE-ZENER;UZP43B,43V,40-46V,1W,DO-41,T SVR-2301 ONLY
POWER DRIVE PARTS
C1P102 2401-001507 C-AL;47uF,20%,16V,GP,TP,6.3x5,5
C1P103 2401-001915 C-AL;1uF,20%,50V,GP,TP,3x5,5
C1P104 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
C1P105 2401-001507 C-AL;47uF,20%,16V,GP,TP,6.3x5,5
C1P106 2401-001915 C-AL;1uF,20%,50V,GP,TP,3x5,5
C1P107 2401-001507 C-AL;47uF,20%,16V,GP,TP,6.3x5,5
C1P108 2401-001507 C-AL;47uF,20%,16V,GP,TP,6.3x5,5
C1P115 2401-001915 C-AL;1uF,20%,50V,GP,TP,3x5,5 SVR-2301 ONLY
D1P101 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
D1P103 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
D1P104 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
D1P106 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
D1P108 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
D1P109 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP SVR-131 NOT USER
D1P117 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
D1P120 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
D1P121 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
Q1P101 0501-000616 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1W,TO-92L
Q1P103 0501-000616 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1W,TO-92L
Q1P106 0504-000142 TR-DIGITAL;KSR2001,PNP,300MW,4.7K/4.7K,T
Q1P107 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
Q1P108 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
Q1P114 0501-000616 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1W,TO-92L
R1P101 2001-000855 R-CARBON;560OHM,5%,1/4W,AA,TP,2.4X6.4MM
R1P102 2001-000855 R-CARBON;560OHM,5%,1/4W,AA,TP,2.4X6.4MM
R1P103 2001-000034 R-CARBON;220OHM,5%,1/4W,AA,TP,2.4X6.4MM
R1P108 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
R1P115 2001-000362 R-CARBON;150OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1P116 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
R1P117 2001-000554 R-CARBON;270OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1P118 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
ZD1P01 0403-001211 DIODE-ZENER;MTZJ12B,11.44-12.03V,500MW,D
ZD1P02 0403-000717 DIODE-ZENER;MTZJ5.1B,5.1V,4.94-5.2V,500m
ZD1P03 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500
4. Electrical Parts List
Loc.No Part No Description ; Specification RemarkLoc.No Part No Description ; Specification Remark

Loc.No Part No Description ; Specification RemarkLoc.No Part No Description ; Specification Remark
4-2 Samsung Electronics
Electrical Parts List
SYSTEM CONTROL/SERVO PARTS
C601 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C602 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C603 2401-001545 C-AL;47uF,20%,25V,GP,TP,6.3x7mm,2.5
C604 2202-000797 C-CERAMIC,MLC-AXIAL;10NF,30%,16V,Y5S,TP,
C605 2202-000797 C-CERAMIC,MLC-AXIAL;10NF,30%,16V,Y5S,TP,
C607 2401-000118 C-AL;1000uF,20%,10V,GP,TP,10x12.5,5 SVR-131 NOT USER
C609 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C610 2202-000797 C-CERAMIC,MLC-AXIAL;10NF,30%,16V,Y5S,TP,
C611 2301-000392 C-FILM,PEF;15nF,5%,50V,TP,6.5x8.5x3.2mm,
C614 2401-001507 C-AL;47uF,20%,16V,GP,TP,6.3x5,5
C615 2401-001507 C-AL;47uF,20%,16V,GP,TP,6.3x5,5
C618 2401-001545 C-AL;47uF,20%,25V,GP,TP,6.3x7mm,2.5
C619 2202-000797 C-CERAMIC,MLC-AXIAL;10NF,30%,16V,Y5S,TP,
C620 2202-000797 C-CERAMIC,MLC-AXIAL;10NF,30%,16V,Y5S,TP,
C621 2401-001545 C-AL;47uF,20%,25V,GP,TP,6.3x7mm,2.5
C622 2301-001006 C-FILM,PEF;68nF,5%,50V,TP,8x4x8.5mm,5mm
C623 2202-000807 C-CERAMIC,MLC-AXIAL;22nF,+80-20%,25V,Y5V
C624 2202-000205 C-CERAMIC,MLC-AXIAL;22pF,5%,50V,SL,TP,1. SVR-131 NOT USER
C625 2202-000205 C-CERAMIC,MLC-AXIAL;22pF,5%,50V,SL,TP,1. SVR-131 NOT USER
C626 2202-000205 C-CERAMIC,MLC-AXIAL;22pF,5%,50V,SL,TP,1.
C627 2202-000205 C-CERAMIC,MLC-AXIAL;22pF,5%,50V,SL,TP,1.
C633 2202-000797 C-CERAMIC,MLC-AXIAL;10NF,30%,16V,Y5S,TP,
C634 2202-000797 C-CERAMIC,MLC-AXIAL;10NF,30%,16V,Y5S,TP,
C635 2202-000183 C-CERAMIC,MLC-AXIAL;2.2NF,20%,16V,Y5R,TP
C636 2202-000183 C-CERAMIC,MLC-AXIAL;2.2NF,20%,16V,Y5R,TP
C637 2202-000263 C-CERAMIC,MLC-AXIAL;470pF,10%,50V,Y5P,TP
C638 2401-000922 C-AL;22uF,20%,16V,GP,TP,5x5,5
C639 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
C640 2401-001507 C-AL;47uF,20%,16V,GP,TP,6.3x5,5
C641 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
C644 2202-000806 C-CERAMIC,MLC-AXIAL;220pF,10%,50V,Y5P,TP
C646 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C679 2202-000807 C-CERAMIC,MLC-AXIAL;22nF,+80-20%,25V,Y5V
C689 2202-000791 C-CERAMIC,MLC-AXIAL;150pF,10%,50V,Y5P,TP
C690 2301-001006 C-FILM,PEF;68nF,5%,50V,TP,8x4x8.5mm,5mm
C691 2202-000797 C-CERAMIC,MLC-AXIAL;10NF,30%,16V,Y5S,TP,
C693 2401-000118 C-AL;1000uF,20%,10V,GP,TP,10x12.5,5
CN601 AC39-20817S LEAD CONNECTOR-ASSY;DP,SMH200-02,YBH200-
CN602 3708-001163 CONNECTOR-FPC/FC/PIC;5P,1.25mm,STRAIGHT,
CN604 3711-003749 CONNECTOR-HEADER;BOX,8P,2R,2mm,STRAIGHT,
D601 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
D603 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
D604 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
D606 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
D610 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
D612 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
IC601 AC09-00089A IC-MICOM;uPD784927GF-159-3BA,784927GF-1
IC601 AC09-00102A IC-MICOM;uPD784927GF-153-3BA,784927GF-1 SVR-131 ONLY
IC602 1003-001162 IC-MOTOR DRIVER;KA3082,SIP,10PIN,25MIL,D
IC604 AC14-12006C IC;KA7533,DIP,-
IC605 1103-001148 IC-EEPROM;24C021,2KBIT,DIP,8P,300MIL,10M
IC608 1203-000515 IC-VOL. DETECTOR;7042,TO-92,3P,177MIL,PL SVR-131 NOT USER
L601 2701-000002 INDUCTOR-AXIAL;100uH,10%,4.2x9.8mm
L602 2701-000002 INDUCTOR-AXIAL;100uH,10%,4.2x9.8mm
L603 2701-000002 INDUCTOR-AXIAL;100uH,10%,4.2x9.8mm
L604 2701-000002 INDUCTOR-AXIAL;100uH,10%,4.2x9.8mm
LD601 0601-000517 LED-IR;RECTANGULA,4x6.0mm,75mW,6V,950
PT601 0604-001122 PHOTO-INTERRUPTER;TR,0.065%,150mW,DIP-4,
PT602 0604-001122 PHOTO-INTERRUPTER;TR,0.065%,150mW,DIP-4,
Q602 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
R608 2001-000864 R-CARBON;56KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R609 2001-000864 R-CARBON;56KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R613 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM SVR-131 NOT USER
R614 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R641 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
R642 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
R644 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R650 2003-000259 R-METAL OXIDE;3.9OHM,5%,2W,AE,TP,6X16MM
R651 2001-000010 R-CARBON;68KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R654 2001-000812 R-CARBON;5.6KOHM,5%,1/8W,AA,TP,1.8X3.2M
R655 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R656 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2M
R657 2001-000010 R-CARBON;68KOHM,5%,1/8W,AA,TP,1.8X3.2MM SVR-131 NOT USER
R660 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R661 2001-000660 R-CARBON;33KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R666 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R667 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R668 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
R669 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
R670 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
R671 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
R672 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
R674 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R675 2001-000032 R-CARBON;180OHM,5%,1/4W,AA,TP,2.4X6.4MM
R676 2001-000633 R-CARBON;30KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R677 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R678 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R679 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
R682 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R685 2001-000660 R-CARBON;33KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R686 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R687 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R688 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R690 2001-000864 R-CARBON;56KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R691 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
R692 2001-000568 R-CARBON;27OHM,5%,1/8W,AA,TP,1.8X3.2MM SVR-131 NOT USER
R693 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
R696 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
RS601 AC34-20100B SWITCH-REC;-,-,X-9,-
S601 0603-001011 PHOTO-TR;NPN,35V,6V,50mA,75mW,BK
S602 0603-001011 PHOTO-TR;NPN,35V,6V,50mA,75mW,BK
SW601 AC34-20100A SWITCH-MODE;-,-,X-9,-
W117 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
W128 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
W173 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
W174 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
W250 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
W300 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
XT601 2801-003318 CRYSTAL-UNIT;32.768KHz,20ppm,28-AAP,12.5 SVR-131 NOT USER
XT602 2801-003139 CRYSTAL-UNIT;8MHz,50ppm,28-AAA,22pF,80oh
AUDIO/VIDEO PARTS
C301 2401-001919 C-AL;2.2uF,20%,50V,-,TP,4x7mm,5
C302 2301-000283 C-FILM,PEF;47nF,5%,100V,TP,7.3X7X3.2X5,5
C303 2401-001915 C-AL;1uF,20%,50V,GP,TP,3x5,5
C304 2202-000216 C-CERAMIC,MLC-AXIAL;.027NF,5%,50V,SL,TP,
C305 2202-000164 C-CERAMIC,MLC-AXIAL;.18NF,10%,50V,Y5P,TP
C306 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
C307 2202-000162 C-CERAMIC,MLC-AXIAL;.015NF,5%,50V,SL,TP,
C308 2202-000797 C-CERAMIC,MLC-AXIAL;10NF,30%,16V,Y5S,TP,
C309 2401-001915 C-AL;1uF,20%,50V,GP,TP,3x5,5
C310 2401-000407 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
C311 2401-000922 C-AL;22uF,20%,16V,GP,TP,5x5,5
C313 2202-000173 C-CERAMIC,MLC-AXIAL;1nF,10%,50V,Y5P,TP,1
C314 2401-001775 C-AL;470nF,20%,50V,GP,TP,4x7,5
C315 2401-000407 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
C316 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C318 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C320 2401-001915 C-AL;1uF,20%,50V,GP,TP,3x5,5
C321 2401-000407 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
ULP : ULTRA LONG PLAY
