Samwontech SDR100E Series User manual


http://www.samwontech.com
Being the controller market leader in the 21st century with the best technology
Instruction manual (Digital recorder)
It is a digital recorder without paper. It supports the high screen quality TFT_LCD touch screen and
SD card. It is a product with rapid graph searching function.
SAMWONTECHNOLOGY CO.,LTD.
(420-733) 202-703 Bucheon Techno-Park, #192Yakdae-Dong,
Wonmi-Gu, Bucheon-City, Gyeonggi-Do, Korea
T+82-32-326-9120 F+82-32-326-9119 [e-mail]
1st Edition of SDR100E IM : May. 04. 2022

Copyright
Copyright© 2022 SAMWONTECHNOLOGY CO.,LTD.
This instruction manual is a work protected by
the copyright law.
A part or entire of this manual shall not be
copied, air sent, distributed, translated or
changed into the form to be read by electronic
media or machine without prior written consent
of SAMWONTECHNOLOGY CO.,LTD.
Please inform the SDR model name, failure condition and
contact point for queries of after sales service.
Queries related with after sales service for SDR 100E series
Quotation request / Product request
Specication request / Data request/ Other request
Customer contact for SDR 100E series
T : 82-32-326-9120
F : 82-32-326-9119
■Internet
■E-mail
www.samwontech.com
management : [e-mail]
sales : [e-mail]
MSIP-REM-
S31-SDRSERIES

1
1st Edition of SDR100E IM : May. 04. 2022
This manual is commonly used for SDR102E, SDR104E,
SDR106E and SDR112E and SDR100E is written inside.
Contents
01. Cautions (Instructions) for safety  4
1 - 1 . Checking the product ‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥ 4
1 - 2 . Exterior and how to install ‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥ 6
1 - 3 . Wiring ‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥ 9
02. Operation and setting 13
2 - 1 . Function and name of the display ‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥ 1 3
2 - 2 . Menu flow chart ‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥ 1 4
2 - 3 . Basic operation flow chart ‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥ 1 6
2 - 4 . Setting button operation ‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥ 1 8
2 - 5 . Warning message display ‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥ 1 9
2 - 6 . Parameter setting method ‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥ 2 0
03. Main screen22
04. Graph recording24
4 - 1 . Graph recording screen ‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥ 2 4
05. Graph searching35
5 - 1 . Graph view ‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥ 35
5
- 2 . Data searching ‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥ 3 6
06. Function setting 39
07. Graph option 46
7 - 1 . Graph display option ( Graph recording screen ) ‥‥‥‥‥‥‥‥‥‥ 4 6
7 - 2 . Graph display option ( Graph searching screen ) ‥‥‥‥‥‥‥‥‥‥ 4 7
08. Setting canned message 50
09. Setting reserve operation53
10. Setting screen display 56
1 0 - 1 . Setting screen display ‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥ 5 6
1 0 - 2 . Touch screen calibration Seting ‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥ 5 9
1 0 - 3 . Internal memory management ‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥ 6 1
11. Error history display 64
12. Setting system parameter 67
13. Screen for setting the sensor input 69
1 3 - 1 . Sensor input screen ‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥ 69
14. Alarm signal  80
1 4 - 1 . Alarm signal setting screen 1 ‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥ 8 0
1 4 - 2 . Alarm signal setting screen 2 ‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥ 8 1
1
4 - 3 . Alarm signal motion ‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥ 8 5
15. User screen 89
1 5 - 1 . User screen setting ‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥ 8 9
1 5 - 2 . Setting user screen upload ‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥ 9 0
1 5 - 3 . Operation of user screen ‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥ 9 1
16. DI function and operation 94
17. Communication environment setting 96
1 7 - 1 . RS 2 3 2 C / 4 8 5 Communication setting ‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥ 96
1 7 - 2 . Ethernet communication environment setting screen ‥‥‥‥‥‥‥‥ 9 7
1 7 - 3 . Serial communication environment setting ‥‥‥‥‥‥‥‥‥‥‥‥ 9 8
18. System initial setting  101

2
01. Cautions (Instructions) for safety
Symbol marks for safety
(A) It means the “Handle with
care” or “Cautions.” In case of
violation of this point, it may cause
the death, severe injury or the
extreme damage on the product.
■
Product : It is marked on the
points to be acknowledged
certainly to protect the human
body and device.
■
Instruction manual : It describes
the cautions to prevent the cases
of endangered situation on the life
and body of the user due to the
electric shock and so on.
(B) It means “Ground terminal”.
■
Make the earth with the ground
in case of product installation and
controlling the product.
(C) It means the “supplementary ”
explanation.
■
It describes the points to
supplement the explanation.
(D) It describes the“references”.
■
It describes the information and
pages of reference to be referred.
Cautions in this instruction manual
■ Please deliver for the end user to possess always and keep it in the place accessible at any time.
■ Use the product after full understanding of this manual.
■ This manual does not warrant any other things because it is a description of the details for the function.
■ A part or whole of this manual shall not be edited or copied randomly.
■ The descriptions in this manual may be changed randomly without pre notice or warning.
■ Even though this manual was made with elaboration, it will be appreciate if you inform to the purchasing point
(Dealer shop and etc) in case of deficiency, mistake or omission in the contents.
Cautions for the safety and modification (Change) of the product
■ Please use this product after full understanding on the safety cautions in this manual for the protection and safety for this
product and the system connected to this system.
■ Our company is not responsible to the damages occurred by the use or handle not relying on this instruction manual and not
attended use.
■ Please install at the outside of this product when the additional protection and safety circuit is installed separately for the
protection and safety for this product and the system connected to this system.
■ The internal modification (Change) and addition to this product are prohibited.
■ Do not disassemble, repair and modify of this product because it becomes the electric shock, fire and malfunction.
■ In case of changing the part or the consumables of this product, please contact to the sales part of our company.
■ Do not contact to the moisture with this product. It may cause the failure on this product.
■ Do not apply the strong impact on this product. It may cause the failure on this product.
With regard to the exemption of this product
■ We are not responsible for any warranty on this product besides the defined cases in the quality assurance condition
of our company.
■ We are not responsible for the direct or indirect damages on the user of any third party due to the not expectable defect or the
natural disaster in use of this product.
With regard to the quality assurance condition of this product
■ The warranty period shall be one year from the purchasing of this product. Free of charge repair is available only for the cases
of out of order occurred from normal use conditions.
■ The repair due to the out of order occurred after the warranty period shall be repaired according to the defined condition
by our company.
■ The out of order occurred within the warranty period shall be repaired with payment for the following cases in spite of with
in the warranty period.
(1) Out of order due to the mistake or fault of the user (Ex: Initialization by losing the password and etc) (2) Out of order due to the
natural disaster (Ex: Fire and flood and etc) (3) Out of order due to the movement of product after installation. (4) Out of order due to
the random disassemble, change or damage on the product. (5) Out of order due to the electric power instability (6) Others
■ Please contact to the purchasing points or sales part of our company in case of necessity for after sales service due
to the failure on the product.
Thank you for your choice of out digital recorder (SDR100E). This manual describes the method of installation and use of the product.

1 - 1 . Checking the product ‥‥‥‥‥‥‥‥‥‥‥‥‥ 4
1 - 2 . Exterior and how to install ‥‥‥‥‥‥‥‥‥‥‥ 6
1 - 3 . Wiring ‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥ 9
Cautions (Instructions) for safety
Part
01

4
01. Cautions (Instructions) for safety
1-1. Checking the product
● When the product is purchased, please check the damaged on the product by checking the exterior of the product.
(1) Checking the specification of the ordered product
● Check whether the purchased product is identical with the ordered specification.
● How to check : Check the model name specification code marked on the right of the packing box and on the left label of product case.
SDR 1 **E - N **/ *
① ② ③ ④
①Number of channel
02 : 2channels | 04 : 4channels | 06 : 6channels | 12 : 12channels
③Remote input
N : None | R1 : 2points
②Alarm output
N : None | A1 : 6points | A2 : 12points
④Others
M1 : Arithmetic function | P1 : Portable type

5
6'56(5,(6
8VHU0DQXDO
(3) How to treat the damaged parts
● In case of product damage after checking the exterior of the product as shown in the above or the accessories are missed, please contact
to the purchasing point or the sales part of our company.
● Please check the corresponding replacing period as shown below and replace prior to the expiration if it is necessary.
● Only parts that meet the following specifications should be used.
- FUSE 2A/250VAC Equivalent : Semi permanent
- RELAY ALD105(5V) Equivalent : Under 300,000 times of ON/OFF
- BATTERY CR2030 3V Equivalent : Under 200,000
● The exchange of the product with expiration date, please contact to the purchasing point (Dealer shop) or the sales part of our company.
Period of exchange for the part of expiration date
(2) Check the parts inside the package
● Please check whether the following parts are included.
01. Cautions (Instructions) for safety
SDR100E Series main body SD card Instruction manualMount for fixing (Left : 2, Right : 2)

6
1-2. Exterior and how to install
(1) Installation location and environment
Cautions for the installation location and environment Installation Precautions
●This product is an industrial product.
●Please manipulate in electricity on state at the installation of this product
on the panel because of the electric shock risk. (Caution for electric shock)
●Do not install the product in the following location or environment.
- A place for contacting the terminal by the human without recognition
- A place directly exposed for mechanical vibration or impact
- A place exposed for the corrosive gas or ammable gas
- A place of temperature uctuation
- A place of extremely high (Over 50℃) and low (Under 10℃) temperature
- A place exposed to the direct sunlight
- A place inuenced with electromagnetic wave
- A place of moisture (A place with more than 85% of humidity)
- A place where there are the ammable stus at the surrounding
- A place of dusty and salty
- A place of receiving the ultra violet light
●Do not use sharp thing or excessive pressure to manipulate the touch
screen.
●Please pay attention to the handling of the product because the product is
weak to the organic solvent (Chemical substances) as the exterior of the
product is made of plastic. (Do not contact the front side of the product to
the organic solvent especially.)
●
Even though the case of this product is made of non ammable material
such as ABS/PC, but do not install in the place where there are the stus of
easy ammability.
●Don’t put the device or the wiring which cause the noise near to this
product.
●Use the product in 10~50℃, in 20~90% RH (It shall not be dewing.) Don’t
put the heat radiant device closely.
●Don’t install the product in declined position.
●Keep the product in -5~70℃(It shall not be dewing.). Especially, use after
full warming up (Switch on) when you use the product under 10 ℃.
●The wiring work shall be made after switching o electric power on the
machine.
●
This product operates in 24V DC, 22V max without special manipulation.
There is a risk of the electric shock or re when the electric power other than
the specication
.
●Don’t work with wet hands. It has the risk of electric shock.
●Follow up the basic cautions to reduce risk of re, electric shock and injury
during using.
●The installation and the use shall be made according to the specied
methods in instruction manual.
●
Refer to the installation procedure regarding to the description for ground.
However, do not make the ground on the water supply pipe, gas pipe, phone
line and lightening rod.
There is a risk of explosion and re.
●Do not switch on before nishing the connection of the devices. It may
cause the failure.
●Do not close the heat radiating hole on this product. It may cause the
failure.
● This product can be used under the following environmental conditions.
- Indoor
- Altitude up to 2000m
- Pollution degree II
- The level of excessive voltage protection category II

7
(2) External dimension (Unit:mm)
(3) Panel cutting dimension (Unit:mm)
137+2
0
137+2
0
180(Minimum)
180(Minimum)
01. Cautions (Instructions) for safety


_౸֑فԋ





2 ~ 7 (Panel thickness)

8
(4) How to attach on the panel mount
*How to install the product
Display Panel
(Refer to the panel cutting dimension)
Direction
of insertion
Fixing mount right
Fixing mount right
Fixing mount left
Fixing mount left
Fixing mount
Phillips screwdriver
Panel thickness : 2 ~ 7mm
Display Panel
(Refer to the panel cutting dimension)
Direction
of insertion
Fixing mount right
Fixing mount right
Fixing mount left
Fixing mount left
Fixing mount
Phillips screwdriver
Panel thickness : 2 ~ 7mm
References
▶ Cut the panel to be installed. Refer to the
[1-2(3) Panel cutting dimension]
▶ Insert into the hole from the rear side of the
product as shown in the above figure.
▶ Fix this product using in fixing mount at the
upper/lower part of the product ( As shown
in the figure) Apply 0.2Nm~0.4Nm of torque
in case of assembling the fixing mount
(Use the Phillips driver)
The clamping screw is too tightened, the panel
surface is deformed. It can cause touch not working
normally, or likely to decrease waterproof.
Cautions

9
● Recommended specification for electric cable: Vinyl insulated electric cable KSC3304 0.9~2.0mm2
● Recommended specification for terminal: Use the pressed terminal with insulation sleeve which is proper to the M3 screw as shown in [Fig. 1].
● Source of noise
(A) Relay and contact point
(B) Solenoid coil and solenoid valve
(C) Electric power line
(D) Induced load
(E) Inverter
(F) Commutator in motor
(G) SCR for controlling the phase angle
(H) Wireless communication device
(I) Welding machine
(J) High pressure ignition device and etc
● Solution for noise
(A) Make the wiring with caution for the following points from the noise creation source.
(B) Make the wiring for the input circuit with placing the gap from the power circuit and ground circuit.
(C) Use the shield line for the noise from the electrostatic induction.
(D) Connect the shield line to the ground terminal according to the necessity not to make the 2 point ground.
(E) Make the wiring in tight twisting for the noise from the electric induction.
1-3. Wiring
● Make the wiring after checking whether the wiring cable is applied for current with tester by switching off the main electric power in every
supplied instrument.
● Never contact to the terminal because of the risk of electric shock during application of the current (Electric power on).
● Make the wiring after switching off the main electric power certainly.
Cautions
(1) How to make the wiring
Φ5.8mm Under
5.8mm Under
Φ3mm Over 3mm Over
Fig.1
01. Cautions (Instructions) for safety

10
(2) Terminal layout
57;
7;'
6*
57;
5;'
359
59%
4(
359
39%
a
9$&
)*
/
1
E
$
%
E
$
%
&+
&+






E
$
%
E
$
%
&+
&+






E
$
%
E
$
%
&+
&+






E
$
%
E
$
%
&+
&+






E
$
%
E
$
%
&+
&+






E
$
%
E
$
%
&+
&+






&20
&20
&20
5/<
5/<
5/<






&20
&20
&20
5/<
5/<
5/<






5/<
5/<
5/<
&20
&20
&20






&20
&20
&20






5/<
5/<
5/<
5(027(
5(027(
&20



/
1
Channel input (Channel 7~12) Remote (DI/Option)
Electric power
Switch
Ethernet
RS485/232C
Channel input (Channel 1~6)
Relay output (Option)

11
▶ Resistance Temperature
Detector(RTD) Input
▶ DC Voltage input ▶ DC Current input
(3) Electric power circuit
(4) Measurement (Sensor) input circuit
● Use the cable with equivalent or above the vinyl insulated cable (KSC3340) or
electric cable for electric power circuit.
● Make the circuit for ground with the electric cable over 2mm and above the
third class ground (Unver100Ω of ground resistance)
● Make 1 point ground from the ground terminal and the wiring cross the ground
terminal shall not be made.
● Switch off the electric power to SDR100E main body and external power supply when the measurement (Sensor) input circuit
is made because of the electric shock risk.
● Use the cable with shield for the input circuit. In addition, make 1 point ground for the shield.
● Make the circuit off from the electric power circuit or ground circuit for the signal line for measuring input.
● Use the electric cable with small cable resistance and no difference in resistance among 3 cables.
'(
_7"$
The 3rd
class ground
SHIELD
RTD
R
+
-
+
-
1
2
3
A
b+
B- The 3rd
class ground
SHIELD
1
2
3
A
b+
B-
V
The 3rd
class ground
SHIELD
1
2
3
A
b+
B-
mA
01. Cautions (Instructions) for safety

2 - 1 . Function and name of the display ‥‥‥‥‥‥‥ 1 3
2 - 2 . Menu flow chart ‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥ 1 4
2 - 3 . Basic operation flow chart ‥‥‥‥‥‥‥‥‥‥‥ 1 6
2 - 4 . Setting button operation ‥‥‥‥‥‥‥‥‥‥‥‥ 1 8
2 - 5 . Warning message display ‥‥‥‥‥‥‥‥‥‥‥ 1 9
2 - 6 . Parameter setting method ‥‥‥‥‥‥‥‥‥‥‥ 2 0
Operation and setting
Part
02

13
02. Operation and setting
02. Operation and setting
2-1. Function and name of the display
● This product is a digital recorder designed in dialogue type touch screen for easy use.
2
3
5
1
6
4Cover (There are electric power switch, SD card insertion part,
Mini USB when the cover is opened.)
SDR100E electric switch
SD card insertion part
Lamp (The yellow lamp is on when the electric power is ON firstly.)
Screen display
Mini USB (For after sales service: User cannot use it.)
①
②
③
④
⑤
⑥

14
2-2. Menu flow chart
Main
button
Pass-
word
input
Operation screen
Electric power ON
Initial screen
Graph recording
Main screen Graph searching
Function setting 1. Recording cycle 2. Restrict of main(User password) 3. Record media(MEM/SD)
4. Power stop mode 5. Basic screen 6. Pen using Unuse/Use
7. Graph scale High/Low 7. Pen thickess 8. PV display method
View the stored graph (Time/Range axis, reduction&enlargement) and capture function
1. Trend screen 2. Bar graph 3. Digital screen 4. Message input 5. (Graph record) Save
6. Internal memory, SD card, alarm status display 7. Search bar button 8. Capture button
9. Channel change button 10. Measured value for each channel 11. Button to move to the beginning/end
12. Button to move by one page 13. Button to move search bar 14. Zoom button 15. All/Area button
16. Memo button
Option for graph display
Setting reserve operation
Setting screen display
Error history display
1. Graph direction (Y-axis/X-axis) 2. Background color
3. Scale display 4. Drawing pen type 5. Reference line 1/2
1. Buzzer sound 2. Backlight power saving 3. LCD brightness 4. Internal memory 5. SD card memory
6. Graph rotation 7. Digital graph display method 8. Folder list 9. Files list
Setting the graph display message
1. Current time 2. Start time 3. End time
1. Save format 2. Error history 3. Event history
Setting canned message

15
02. Operation and setting
System setup Setting the sensor input 1. Sensor type 2. Unit of display 3. Tag name 4. Dot position
5. Sensor range 6. PV when S.OPN 7. Measurement method
Alarm signal
Setting the user screen
System initial setting
DI function and operation (Option)
Communication environment
setting
1. Ethernet communication
● Communication protocol, communication port setting, network setting, communication setting lock
● IP, Subnet mask, Gateway setting
2. Serial communication
● Communication protocol, communication speed, parity, stop bit, data length, other parameters
Setting the user screen display
1. Language set 2. Display method 3. Internal memory 4. System password 5. Paramerer password
1. Buzzer time setting 2. DI detection delay time 3. DI operation method 4. Relay output in DI detection
1. Alarm Operation 2. 4 for each channel
● Type : PV upper limit, PV lower limit, within PV range, Out of PV range, Over PV ascending
change ratio, under PV descending change ratio, within the deviation between
channels, out of the deviation error between channels, sensor circuit short
● Setting the delay time

16
ԙ The logo displaying screen and the initial screen are displayed sequentially when the electric power is switched ON after installation of the product and
it converts to the graph recording screen automatically.
ԙ It takes about 20 seconds in screen loading
ԙ When button is pressed at the top of the graph recording screen, the sub menu bar is displayed and when is pressed, it converts to the main screen.
2-3. Basic operation flow chart
Loading screen
System parameter setting screen Password input screen Main screen
Initial screen Graph recording screen

17
02. Operation and setting
Password input screen
Screen without DI option Screen with DI option

18
2-4. Setting button operation
[Table 2-1]
Button type Button operation
It is used for inputting the general numbers and name.
It is used for selection for one out of many types.
It is used for selection for one out of more than 2 parameter setting. (ON / OFF state)
It is used for selection of Y/N for the corresponding parameter. (ON / OFF state)
It is used for screen conversion of different function.
It is used for increasing or decreasing of the page within the screen of same function.
