SANCH S900 Series User manual

Manual Service
For S900 Series Inverters
All Rights Reserved. Subject to
change without notice.

Contents
Preface…………………………………………………………………..………………………..
1
1. Safety Instructions.……………………………………………..…………………...........
2
1.1 NOTES FOR OPERATION………………………………………..……………………....
2
1.2 NOTES FOR OPERATION ENVIRONMENT………...………..………………………..
4
2. DESCRIPTIONS FOR SANCH AND INSTALLATION………………..…….…………
5
2.1 OPERATION ENVIRONMENT…………………………………………………………...
5
2.2 MODEL DESCRIPTION……………………………………………………………………
6
2.3 PRODUCT SPECIFICATION……………………………………………………………...
7
2.4 LIST OF APPLICABLE NO FUSE BRAKER ……………………………………………
9
2.5 APPLICATION AND DESCRIPTION FOR AMBIENT EQUIPMENTS………………..
10
2.6 BASIC WIRING DIAGRAM…….…………….………………...…………………………
13
2.7 DIAGRAM FOR PRODUCT OUTLINE..…….………………………..………………….
15
3. DESCRIPTION OF OPERATORS……………………………………………………..….
16
3.1 DESCRIPTION OF BIT OPERATION………………………….………………………..
15
3.2 DESCRIPTION OF KEYBOARD OPERATION………………………………………...
18
3.3 PRELIMINARY OPERATION-NOT CONNECTING WITH MOTOR………………….
19
4. LIST OF DESCRIPTIONS FOR FUNCTIONAL PARAMETERS…………..…….…….
21
5. DESCRIPTION OF FUNCTIONAL PARAMETERS…………………………..…………
32
0: USER’S PARAMETERS…………………………………………………………………….
32
1: BASIC PARAMETERS……………………..……………………………………………….
34
2: OPERATION MODE PARAMETERS………………………………………………………
38
3: OUTPUT FUNCTION PARAMETERS…………………………………………………….
41
4: INPUT FUNCTION PARAMETERS………………………………………………………..
46
5: MULTI-STEP SPEED AND AUTO-PROGRAM OPERATION PARAMETERS………..
51
6: PROTECTION PARAMETERS…………………………………………………………….
53
7: SPECIAL PARAMETERS…………………………………………………………………..
56
8: HIGH FUNCTION PARAMETERS…………………………………………………………
57
9: COMMUNICATION PARAMETERS……………………………………………………….
61
A: WOBBLE FREQUENCY PARAMETERS………………………………………………...
71
6. TROUBLE SHOOTING……………………………………………………………….…....
73
6.1 FAULTAND CORRECTIVE MEASURES………………………………………………..
73
6.2 TROUBLESHOOTING FOR FAULTS IN GENERAL…………………………………...
75
7. MAINTENANCE AND AMBIENT ELEMENTS……………………….………………….
76

1
Preface
This instruction manual, which includes operation descriptions and notes for maintenance, shall be
delivered to the end-user.
For safety running and effective operation, this instruction manual shall be read thoroughly prior to use,
which shall also be preserved for later use.
Provided problems occur and solution is not provided in this instruction manual, contact your SANCH
ELECTRIC representative or contact with our company directly. Our professional technicians will serve
for you actively.And please continue to adopt products of SANCH, give valuable opinion and advice.
1. Reading Instructions
symbols of” DANGER” and” ATTENTION” in the manual indicates that, for safety running or
maintenance of inverters or other electrical products, attention shall be attached during delivering,
installation, operation and checks for the inverter. And these notes shall be applied for a better and safer
operation.
DANGER
indicates a potentially hazardous situation visiting. If not used correctly, personnel
damage even death may be caused.
CAUTION
indicates a potentially hazardous situation visiting. If not used correctly, serious
damage to inverter or machine may be resulted.
ATTENTION

Do not perform a withstand voltage test for components of inverter, it can cause
semi-conductor components to be damaged by high voltage.
Never connect the output terminals U/T1, V/T2, W/T3 to AC power supply.

IC of CMOS on control circuit of the inverter shall be damaged by electrostatic
influence. Do not touch main circuit board.
2. Products receiving
All products have been performed with strict test and inspection. After receiving the inverters, the
following checks shall be performed.
To check that SANCH inverter, an instruction manual.
To check whether model number correspond with model and capacity your purchase order.
To check whether there are damaged parts during transportation and delievering. If there are,
do not connect with power supply.
If any of the above checkpoints are not satisfactory, contact your SANCH ELECTRIC representative
for a quick resolution.
DANGER

Do not touch circuit board and other components after power supply off and
CHARGE indicators are still ON.

Never connect wires while power on. Do not check components or signal for
circuit board during operation.
Do not
dismantle or change inner wire, circuit or components unnecessarily.
Make sure grounding terminals are correctly grounded. 220V level: Grounding
Ⅲ;440V level:SpecialG rounding

2
CAUTION
1 SAFETY INSTRUCTIONS
1.1 NOTES FOR OPERATION
Before wiring
●Specification of app
lying power supply shall correspond to input voltage of the
inverter.
DANGER
●Main circuit terminals must be correct, L1/R, L2/ S and L3/ T is input terminals and it’s
forbidden to use mixing with U/T1, V/T2 and W/T3. Failure to observe this may cause
the inverter damaged.
CAUTION
●
When delivering the inverter, do not take the cover directly. Take the air fan seat to
prevent the cover got off. Inverters getting off which may cause damage to personal
or machine shall be avoided.
●Install the inverter on metal or other non-
inflammable materials. Do not fix it on
inflammable materials which may cause a fire hazard.
●
In case of several inverters are installed together in one control panel, a fan shall be
prepared to make sure temperature lower than 50℃, thus over-
heating or a fire
hazard shall be avoided.
●
Make sure applied power supply comply with label showed on the right of the
machine. Failure to observe this may cause action failure.
During operation DANGER
Never put in or take off the motor during operation, otherwise over-current even over
burning the main circuit of the inverter may happen.
When auto-restart function is set, do not approach the machine since motor can be
reset suddenly after being stopped.
The function set can make the stop key invalid, which is different from the emergency
stop key. Please pay attention to it.

3
CAUTION
●Never touch heatsink or discharging resistor since temperature may be very high.
●Since it is easy to change running speed from low to a high speed, verify safe working
range of motor and machine before running.
●Use brake according to the method described in wiring diagram.
●Do not check signals during running.
●
All parameters of the inverter have been preset at the factory according to line
frequency. Do not change the setting value at will.
During check and maintenance CAUTION
●Ambient temperature for operating the inverter shall be -10℃to + 50℃(+40℃
parallel installation) and 90%RH no condensation. However under this condition, the
ambient environment must be without drips of water or metal dust.
During rejection CAUTION
●Explosion may occur when burning the electrolytic capacitor of the main circuit and
printing plate. Toxic gas may be generated when burning control panel and other
plastic fittings. It shall be treated as Industrial waste.

4
1.2 NOTES FOR OPERATION ENVIRONMENT
Make sure the inverter is protected from the following during operation:
Direct Sunlight.
Corrosive gas
or
fluids Oil l
Salt or saline Rain, moisture Iron chips and dust
Large impelling
Extreme low
temperatures
Extreme high ambient
temperatures (Above 40℃)
Electromagnetic waves and
ultra high-
angle rays (For
example: locations of
welding machines and etc.)
Radioactive materials
Locations of inflammable
materials

5
2 DESCRIPTIONS FOR SANCH AND INSTALLATION
2.1 OPERATION ENVIRONMENT
Since operation environment can directly influence functions and operation life, to ensure proper
performance and long operation, follow the recommendations below when choosing allocation for
installing the inverter. Make sure it is protected from the following:
Extreme cold and heat.
Use only with the ambient temperature range: -10℃to +50℃(+40℃parallel installation)
Rain, moisture
Direct sunlight.(Avoid using outdoors)
Corrosion of oil sprays or salt
Corrosive fluid and methane
Dust or metallic particles in the air.
Radioactive materials and inflammable materials
Electromagnetic interference (Avoid using together with welding machine or dynamic machines.)
Vibration.
(If inverter must be used in this environment, an anti vibration pad is necessary).
Attention shall be attached to clearance of inverters allocated closely. A fan shall be installed to
make sure temperature is lower than 50℃
correct configuration
For cooling off, face shall be toward front and upper parts shall be upwards.
Clearance shall meet the following specifications:
AIR EXCHANGE FAN AIR EXCHANGE FAN
DIRECTION OF
INSTALLATION
VENTILATION
FRONT SIDE
INSIDE THE CABINET
INSIDE THE CABINET
INSIDE THE CABINET
INSIDE THE CABINET
correct configuration wrong configuration correct configuration wrong

6
2.2 MODEL DESCRIPTION
Model
Input power supply Specification
Output power supply Specification
Output frequency
PRODUCT
SERIES SINGLE PHASE
THREE PHSES
G: CONSTANT TORQUE
LOAD (FOR GENERAL USE)
P: Variable torque load

7
2.3 PRODUCT SPECIFICATION Individual Specification
■220V Signal phase Series
Model number S900-2s□□□G 0.2 0.4 0.75 1.5 2.2
Output
Max applicable motor output
power(kW)
0.2 0.4 0.75 1.5 2.2
Max applicable motor output
power(HP)
0.25 0.5 1 2 3
Output rated capacity(kVA) 0.6 1.0 1.9 2.5 4.2
Output rated current (A) 1.6 2.5 4.2 7.5 11
Output frequency range 0.1~400Hz
Over load capacity
150% of rated output current and run for 60sec.
Max output voltage
Correspond to input power supply
Input
Phase number. Voltage. Frequency
Single phase. 200 to 240V. 50/60Hz
Allowable variation range for Voltage.
Frequency
Voltage: ±10%, Frequency: ±5%
Input current (A) 4.9 6.5 10 17.5 27
Cooling System Natural air cooling Forced air cooling
■440V Three phase Series
Model number S900-4T
□□□
G
0.4
0.75
1.5
2.5
3.7
Output
Max applicable motor output
power(kW)
0.4 0.75 1.5 2.5 3.7
Max applicable motor output
power(HP)
0.5 1 2 3 5
Output rated capacity(kVA)
1.2
2.3
3.2
4.2
6.3
Output rated current (A)
1.5
2.5
4.2
5.5
8.2
Output frequency range
0.1~400Hz
Over load capacity
150% of rated output current and run for 60sec.
Max output voltage
Correspond to input power supply
Input
Phase number. Voltage. Frequency
Three phase. 380 to 460V. 50/60Hz
Allowable variation range for Voltage.
Frequency
Voltage: ±10%, Frequency: ±5%
Input current (A)
1.9
3.5
6.0
7.2
9.0
Cooling System
Natural air cooling
Forced air cooling

8
Individual Specification
■Standard Specification
Controlling Characteristics
Control mode
Adopting SVPWM or SPWM modulating techniques
Output frequency range
0.01~400.0Hz
Frequency setting analyzing
degree
0.1Hz
Output frequency analyzing
degree
0.1Hz
PWM load wave frequency
Available to modulate from 2 to 12kHz.
Torque increase
Auto torque-increase and auto slip compensation, at 5Hz the
starting torque can reach 150% of rated torque.
Jog frequency
3 points can be set from 0.1 to 400.0Hz
Acceleration/deceleration
time
0.1 to 600.0seconds. (2 steps of accel/decel time can be set
separately.)
Stall Prevention Level
According to the load characteristics of motor, it’s available to be
set as 50 to 200% of rated current of the drive
DC braking
Available to be operated from 0.1 to 60.0Hz from STOP, braking
current 0 to 100% of the rated current. Starting time 0 to 60.0
sec. Stopping time 0 to 60.0 sec.
V/F curve
V/F curve available to be set
Operation Characteristics
Frequency
setting signal
Digital
Operator
Set by UP and DOWN
External
information
Potentiometer 5K
Ω
, 0-10VDC, multi-function input choosing3-5
(7 velocities: jog-on, up/down command), serial communication
(RS-485)
Running
operating
signal
Digital
Operator
Available to be operated by RUN, STOP and JOG keys.
External
terminals
2 wire style (Fwd/Stop, Rev/Stop, Run/Stop and Fwd/Rev)/ 3 wire
operation, JOG running, Serial Communication Board(RS-485)
Intelligent Input Terminal
Switching of 7 step pre-set available speed; Switching of
First/Second acceleration/deceleration time; prohibiting
acceleration/deceleration and external interrupt input; Jog
running UP/DOWN frequency terminal setting; Count terminals
Intelligent Output Terminal
During running, frequency agreement output, non-zero count
agreement output, over torque output, external interrupt
reference, low voltage detection, operation mode reference, fault
output and external fault interruption.
Analog signal output
Corresponding to output current, output frequency 1( before slip
ratio compensation), output frequency 2( after slip ratio
compensation), output voltage, consumed power, DC bus voltage
Built-in Function
Setting max/min output frequency; momentary power off
restarting; fault restarting; setting of S curve
acceleration/deceleration time; auto-voltage stabilizing output
modulation; digital frequency output signal; fault records;
parameters locking; reset to factory setting; inhibiting reverse run;
over current stalling prevention, over voltage stalling prevention,
electrical thermal relay.
Protection Function
Over current; over voltage, low voltage;’external fault interruption
input; motor over load; over load of the drive and drive
overheating
Digital operator
Consisting of 6 functional keys, 7 step LED in 4 digits; 4 status
LED indicators. Available to set frequency, display actual output
frequency, output current, self-determined unit parameter
overview of users, modify settings and for parameter locking,
fault displaying. Available to perform running, stop, reset, fwd/rev
run and jog run.
environment
Operational Environment
temperature
-10
℃
to +50
℃
(+40
℃
parallel installation, no condensation, no
freezing)
Storing temperature
-20
℃
to +60
℃
Operational Environment
dampness
Below 90%RH without moister
Installation height
Lower than 1000m, without corrosive gas, fluid and dust.

9
SANCH ELECTRIC shall not be responsible for faults due to the following:
(1) Absence or inapplicable or over large non fuse breakers was put between the power supply and the
inverter, which results in the inverter fault.
(2) Magnetic contactors or advance capacitor or Surge Absorber were connected in series between the
inverter and motor.
Athree phase Squirrel-cage induction motor which corresponds with the capacity of the inverter
shall be adopted.
If more than one motors were driven simultaneously by one inverter, the current of these motors
when running shall below capacity of the inverter. And each motor shall be prepared with a
thermal relay in appropriate capacity.
Phase advance capacitors and other capacity elements such as LC or RC shall not be fixed
between the inverter and motor.
2.4 List of applicable no-fuse breaker
Type
S900-2S
single-phase
series
S
uitable power
of motor (kW)
Rated current
of breaker (A) Main return circuit Control circuit (mm²)
Input
wire
P
ositive and
negative bus
Output
wire
Grounding
wire
Control terminal
wire
S900-2S0.2G 0.2 10 1 1 1 2 1
S900-2S0.4G 0.4 15 1.5 1 1 2 1
S900-2S0.75G 0.75 20 2.5 1 1 2 1
S900-2S1.5G 1.5 40 4 1.5 2.5 2 1
S900-2S2.2G 2.2 50 5.5 1.5 2.5 2 1
Type
S900-4T
three-phase
series
S
uitable power
of
motor (kW)
R
ated current
of breaker (A)
Main return circuit Control circuit (mm
²)
Input wire P
ositive and
negative bus
Output
wire
G
rounding
wire
Control terminal wire
S900-4T0.4G 0.4 5 1 1 1 2 1
S900-4T0.75G 0.75 10 1 1 1 2 1
S900-4T1.5G 1.5 15 1.5 1 1.5 2 1
S900-4T2.2G 2.2 15 1.5 1.5 1.5 2 1
S900-4T3.7G 3.7 20 2.5 1.5 2.5 2 1

10
2.5 Application and description for ambient equipments
Power supply:
Power supply:
Make sure voltage class is correct, otherwise inverter may
be damaged.
A no fu
se breaker (air circuit breaker) shall be provided
between AC supply and inverter.
No fuse Breaker
No fuse Breaker:

Circuit breaker which complies with rated voltage and
current of inverter shall be applied as ON/OFF control for
inverter.And it shall also be protective to the inverter.

Never use circuit breaker as ON/OFF switch for inverter.
Magnetic Contactor
Leakage Breaker

A leakage breaker shall be installed to prevent
mal-
functioning and to ensure the safety of operators; To
prevent the mal fu
nctions, those of which the sensitivity
current above 200mA and action time above 0.1 sec shall
be applied.
Power Improving AC
Electric Reactor
Magnetic Contactor
Inverters can be used without a magnetic contactor (MC)
installed at the power supply side. However, when used
for external control or automatically restart after power off,
or when braking control is used, a magnetic contactor
shall be applied.
Do not use the magnetic contactor as RUN/STOP switch
for inverter.
Input side Noise Filter
Power ImprovingAC Electric Reactor

When the output capacity is greater than 500KVA or
enter-
wire electricity capacity acts, the instant jump of
voltage or current will be produced, resulting to damage
the internal circuit. So it is recommended that an AC
electric reactor is installed additionally to improve function
factors and decrease the power harmonic. The wiring
distance is within 10m.
S900 Inverter
Input side Noise Filter
The Input side Noise Filter must be applied if inverter has
electronic induction load around.
Zero Phase Noise
Filter
Inverter
Input Power supply terminals R/L1, S/L2 and T/L3 can be
connected without phase sequence.

Connect output terminals U/T1, V/T2 and W/T3 to U/T1,
V/T2 and W/T3.of motors, if the inverter is in forward run
re
ference, while motor reverse runs, change any two of
U/T1, V/T2 or W/T3

Never connect U, V, W to AC Power supply otherwise
inverter may be damaged.

Grounding terminals shall be grounded correctly.
Category Ⅲ G rounding: below 100Ω
Special grounding: below 10Ω.
Three Phase Squirrel
Cage Motor
Zero Phase Noise Filter

If specialized noise filters are fit at inverter output side,
radiation interference and induction noise shall be
decreased.

11
Wiring shall be checked whether correct or not. Peripheral wiring shall fulfill the following requirements.
(Do not use a buzzer of control circuit to check wiring)
(A) Wiring for control circuit Power supply must be isolated or far from other high voltage
wirings or high current power lines, thus electromagnetic interference can be avoided. See
diagrams below:
Individual power supply bridge for inverter

Good effect may not be received if general
use noise filters are applied

If inverter power supply circuit is used
commonly with other machines,
inverter-
specialized noise filter or isolating
transformer shall be added.
Interference during transmission can be prohibited by adding an inverter-specialized noise filter at
main circuit output side. For preventing electromagnetic radiation, a metal tube shall be installed,
and distance from signal wiring of other control machines shall be 30cm at least.
杂讯滤波器 Noise filter 信号线 Signal wire 控制机器 Control device
30cm 以上 30cm above
Power supply
Power supply
Power supply
Noise
filter
Isolated transformer
Machine
Machine
Power supply
Power supply
Noise
filter in
general
use
Noise
filter in
general
use
Machine
Machine
power supply Iron box
electromagnetic contactor
inverter
electromagnetic contactor
electromagnetic contactor
inverter
electromagnetic contactor
electromagnetic contactor
inverter
inverter
inverter
electromagnetic contactor
electromagnetic contactor
electromagnetic contactor
Power supply
Power supply
Isolated transformer
inverter

12
Voltage drop of wiring shall be considered providing that inverter and motor are with an excessive
distance. Voltage drop (V) =31/2× wiring resistance (Ω/km) × wire length (m) ×current(A) × 10-3, load
wave frequency shall be modified according to wiring prepared.
Distance between
inverter and motor
wiring Below 50M Below 100M Above 100M
Allowable load wave no. Below 12kHz Below 9kHz Below 6kHz
Set value for parameter
2-09 12 9 6
(B) Wiring for control circuit shall be isolated or far from main circuit wiring or other high
voltage/current power lines, thus electromagnetic interference shall be avoided.
For preventing electromagnetic interference and false sequence, shielding wiring shall be used for
control circuit. Shielding wiring shall connect grounding terminals.
Distance for wiring shall be 50m or less.
(C) Grounding terminal for inverters shall be grounded properly. Below 100Ω: Category
Ⅲ;
Below 10Ω: Special
AWG shall be taken as standard for ground wire. Ground wire shall be as short as possible.
Never ground simultaneously for Inverter ground wire with other large current load (such as welding
machine or large Power motors). They shall be grounded separately.
Ground circuit shall be avoided when several inverters are grounded simultaneously.
(a) CORRECT (b) CORRECT (c) FAULSE
(D) Cable line width for main circuit and control circuit shall be selected according to power line
standard.
(E) After completing of grounding and wiring, check for the following items: wiring is proper;
wire is not broken and screws are securely tightened.
Shielded Armor
To inverter shielded sheath
terminal 1
Insulate these parts
with insulation tape
Never connect

13
2.6 Basic Wiring Diagram
Wiring of AC motor drive can be divided into two parts, the main circuit and control circuit. Users must
connect terminals as diagram shows.
The following diagram is the standard wiring diagram of S900 series AC motor driver.
以上图片翻译为,中英文对照：
三相交流电源：three-phase AC power supply
接线用断路器：wiring with breaker
电磁接触器：electromagnetic connector
制动电阻（选购）： braking resistance （optional）
制动单元（选购）：braking Unit （optional）
单相交流电源：single-phase AC power supply
电机：motor
短路跳线位置：short circuit jumper position
出厂设定为 NPN：factory setting NPN
出厂设定： factory setting
正转/停止：Fwd run/Stop
反转/停止：Rev run / Stop
多段速指令 1：multi-velocity command 1
多段速指令 2：multi-velocity command 1
异常复位：abnormal reset
NPN 模式：NPN mode
多功能输入端子：multi-function input terminal
继电器接点输出：relay joint output
电感性负载：inductive load
出厂设定为故障指示：factory setting is fault indication
晶体管输出：transistor output
出厂设定为运转中指示; factory setting is indication in operation.
模拟电压输出端子：analog voltage output terminal
出厂设定为输出频率：factory setting is output frequency
出厂设定为 AVI：factory setting AVI
频率设定用电源：set frequency by power supply
模拟信号共同端：analog signal joint terminal
串行通信; serial communication
保留：reserved
主端子：main terminal
控制端子： control terminal
隔离线：shielding wire
Note: RS-485 may damage the terminal of connector side. So the terminal configuration has to be
confirmed before connection. The used signal wire can be cut if necessarily.

14
Description for S900 Series inverter terminals
Main circuit terminal descriptions
Terminal symbols Function
L1/R,L2/S,L3/T Main circuit AC power supply input(For single phase input, connect to L1/L
and L2/N)
U/T,V/T2,W/T3 Connect to motor
P/(+),N(-) Connecting to braking module
For grounding(High voltage wave impact and noise interference shall be
avoided.)
Terminal Symbol Description
Terminal symbols Function of Terminal Specification
RA-RC Multifunctional reference signal output
contactor See Description 3-
05 for RELAY
CONTACTOR OUTPUT
RB-RC Multifunctional reference signal output
contactor
MI1-DCM Rev run/ Stop
See Description 4-05-4-08
MI2-DCM Fwd run/ Stop
MI3-DCM Multifunctional input option 1
MI4-DCM Multifunctional input option 2
MI5-DCM Abnormal reset
MO1-MCM Multifunctional output terminal See description of 3-09 and 3-10 (Open
collector output)
+10V-ACM Power supply for speed setting Speed reference power supply (+10V)
AVI/ ACI -ACM Analog voltage frequency reference 0 to +10V/4~20ma Max output frequency
AFM-ACM Analog frequency/ current meter 0 to +10V/Max output frequency
RS-485 serial
communication Serial connected communication board RS-485 Serial connected communication connector
+24V-DCM Assisted control power supply DC 20V-26V (20Ma Max)
Pay attention to insulate the control signal wire with insulation tape.
Note: RS-485 may damage the terminal of connector side. So the terminal configuration has to be
confirmed before connection. The used signal wire can be cut if necessarily.

15
2.7 DIAGRAM FOR PRODUCT OUTLINE
Figure 7-1 Dimension and installation size of
S900-2S0.2G~0.75G/S900-4T0.4G -1.5G (unit: mm)
Figure 7-2 Dimension and installation size of
S900-2S1.5G~2.2G/S900-4T2.2G -3.7G (unit: mm)

16
3 DESCRIPTION OF OPERATORS
3.1 DESCRIPTION FOR DIGITAL OPERATOR
The digital operator has two spaces: display space and operating space. Parameters setting and
different operation states shall be displayed on the display space, while for the operating space, it is an
interface for communication of the operators and AC motor drive.
左侧依次为：
LED 指示灯 LED indicator light
频率设定电位器旋钮 potentiometer knob for frequency
setting
模式切换/异常复位键 mode switch / fault reset key
参数/数据修改确认键 confirm key for parameter/data
modify
增量键 increment key
右侧依次为：
数据显示区 data display space
(四位 LED 数码管)(LED four-digital tube)
运行键 Operation key
停止键 STOP key
减量键 decrease key
MODE/RESET
In normal operation mode,
various states information of the AC motor drive, such as
frequency reference and input current, shall be displayed by depressing this key; in various
operative modes of the parameter setting, the machine shall reset by depressing this key;
Press this key to reset the error when error occurs
ENTER
After selecting appropriate operation or program mode, i.e. parameters must be replaced
(This key shall be available regardless the AC motor drive is in operation or stop), program
mode shall be realized by depressing this key; as an ENTER key for parameter setting, if this
key is depressed in program mode, modified parameters shall be taken into memory by the
system.
RUN
To start operation (Pressing this key is invalid when set as external terminal control)
STOP
To stop operation
UP/DOWN
For modifying data or parameter programs
If depressing this key for long time, for a short time then released, all modified parameters
shall be alternated step by step;
If depressed it for a long time and not released
, all modified parameters shall alternate
quickly.

17
Description of indicator light
RUN operation indicator light: it will light on when the inverter is in operation state.
STOP stop indicator light:: it will light on when the inverter is in stop state.
FWD forward indicator light: it will light on when the rotating direction of inverter is forward.
REV reverse indicator light: it will light on when the rotating direction of inverter is reversal.
Note: In the following several states, indicator lights are combined to indicate the inverter state.
set the inverter to operate, RUN indicator light is on and STOP flickers when the output
frequency is 0.
set the inverter to stop, RUN indicator light flickers and STOP is on when the output
frequency hasn’t decreased to 0.
If it is necessary to set the inverter to do the reverse operation when it is in forward operation
state, stop the forward operation first, then start the reverse operation. The FWD indicator
light flickers and REV is on before the forward rotating stops.
If it is necessary to set the inverter to do the forward operation when it is in reverse operation
state, stop the reverse operation first, then start the forward operation. The FWD indicator
light is on and REV flickers before the reverse rotating stops.
Descriptions of Functional Displaying Project
Display Project Description
Showing the current set frequency of AC motor drive.
Displaying actual frequency output fromAC motor drive to motor
Displaying physical quantity(U) defined by users (U=H×0.05)
Displaying count value(C) of internal counter
Displaying output current of U/T1, V/T2 and W/T3 at output side of the AC motor drive
Displaying parameter project. Content of this parameter shall be displayed by
depressing ENTER .
Displaying parameter content value. Modified materials shall be stored by depressing.
ENTER
If END information (as diagram left shows) lasts for about 1 sec, it means that data
has been received and memorized automatically. If data needs modifying, it shall be
completed by acting directly with UP / DOWN and depress ENTER key again.
This interface will be displayed when setting parameters are not received.

18
3.2 DESCRIPTION OF KEYBOARD OPERATION
Scenes Selection
Configuration Setup
Data Modification
Steering Setup
or
or
