S&C IntelliCom®Mesh Radio
Installation
Table of Contents
Section Page Section Page
Safety
Understanding Safety-Alert Messages ..............2
Following Safety Instructions .....................2
Replacement Instructions ........................2
Power Line Safety ..............................3
Safety Procedures for Working at Heights ...........3
Setup and Installation
Radio Kit Contents .............................4
Setup and Configuration ........................4
Radio Upgrades ...............................4
Preparing for Installation .........................5
Installation Overview for IntelliCom DA Mesh Radio....5
Installation Overview for IntelliCom WAN Mesh Radio ..5
Tools Needed .................................6
Preparing Earth Ground .........................6
Antenna Placement ............................6
Mounting Outdoor Antennas ......................6
Mounting IntelliCom WAN Mesh Radio..............7
Pole Mounting.................................8
Mounting Straps ...............................8
Mounting Antennas .............................8
Connecting Cables .............................8
Power Connection..............................9
Powering Other Ethernet Devices..................9
Connecting Antennas ...........................9
Specifications ................................10
Regulatory Information........................12
Connector Wiring—IntelliCom WAN Mesh Radio
AC Power Connection..........................16
DC Power Connection .........................16
Custom DC Cable.............................16

2S&C Instruction Sheet 1069-500
Safety
There are several types of safety-alert messages which may appear throughout this
instruction sheet and on labels attached to the radio. Familiarize yourself with these
types of messages as explained below.
ÇDANGER
“DANGER” identifies the most serious and immediate hazards which will likely result
in serious personal injury or death if instructions, including recommended precautions,
are not followed.
ÇWARNING
“WARNING” identifies hazards or unsafe practices which can result in serious personal
injury or death if instructions, including recommended precautions, are not followed.
ÇCAUTION
“CAUTION” identifies hazards or unsafe practices which can result in minor personal
injury or product or property damage if instructions, including recommended precautions,
are not followed.
NOTICE
“NOTICE” identifies important procedures or requirements that can result in product or
property damage if instructions are not followed.
If you do not understand any portion of this instruction sheet and need assistance,
contact your nearest S&C Sales Office or S&C Authorized Distributor. Their
telephone numbers are listed on S&C’s website sandc.com Or call S&C Headquarters
at [phone]; in Canada, call S&C Electric Canada Ltd. at [phone].
ÇCAUTION
Do not remove cover
• Dangerous voltages inside.
• No serviceable parts inside.
• Refer to qualified service personnel.
• Unit must be disconnected from power before servicing.
Following Safety
Instructions
If you need additional copies of this instruction sheet, contact your nearest S&C Sales
Office, S&C Authorized Distributor, S&C Headquarters, or S&C Electric Canada Ltd.
Understanding
Safety-Alert
Messages
Replacement
Instructions

S&C Instruction Sheet 1069-500 3
Safety
When working near power lines, follow ALL safety procedures appropriate for the type
of power line and voltage.
• Select equipment locations that allow safe and simple installation.
• Don’t work alone. A co-worker can save your life if an accident happens.
• Don’t attempt repair work when you are fatigued.
• Use approved non-conducting ladders, shoes, and other safety equipment. Make sure
all equipment is in good condition.
• If a tower or pole begins falling, don’t attempt to catch it. Stand back and let it fall.
ÇCAUTION
If a wire or pole does come into contact with a power line, never touch it or attempt to
move it. To prevent electrocution, call the electric utility company immediately.
• Do not attempt to erect antennas or towers on a windy day.
ÇWARNING
Make sure all towers and poles are securely grounded, and electrical cables
connected to antennas have lightning arrestors. This will help prevent fire damage
or human injury in case of lightning, static build-up, or short circuit within equipment
connected to the antenna.
• The IntelliCom WAN Mesh Radio has built-in lightning protection, but antennas still
need their own lightning protection. Be sure that any other equipment connected to
the IntelliCom Radio has the same level of protection.
• The base of the antenna pole or tower must be connected directly to the building
protective ground or to one or more approved grounding rods, using 10AWG ground
wire and corrosion-resistant connectors.
• Refer to the National Electrical Code for grounding details.
ÇDANGER
If a co-worker comes in contact with a power line, don’t touch that person.You
may be electrocuted.
• Immediately call for medical help.
• Use a non-conductive dry board, stick, or rope to push or pull that person so that
person is no longer in contact with electrical power.
• Once that person is no longer contacting electrical power, administer CPR if you
are certified.
Power Line Safety
Safety Procedures for
Working at Heights

4S&C Instruction Sheet 1069-500
Setup and Installation
The IntelliCom DA Mesh and WAN Mesh Radio kits contain the items shown in Table 1.
Table 1—IntelliCom DA Mesh and WAN Mesh Radio Kit Contents
Item
DA
Radio
Qty.
WAN
Radio
Qty.
Warranty and registration card 1 1
CD with Software; Reference Guide; Hardware Installation Guide; EULA 1 1
2.4-/5-GHz dual-band omnidirectional antennas, detachable 2 6
IntelliCom WAN Mesh Radio, NEMA-4X enclosure 1
N to reverse-polarity SMA adapter 2
Mounting bracket for pole and wall mounting. Designed to fit 37- to 50-mm
(1.5- to 2.0-inch) poles 1
Mounting Kit, including U-bolts, M61.0-80 mm, with flat washers, split
washers, and nuts. Claw-tooth pole grippers. M61.0-40 mm hex bolt.
M61.0-20 mm hex bolt. Hex-head socket wrench
1
AC power cord with NEMA 5-15 (US) plug. Other IEC cords are available
separately 1
External power module with NEMA 5-15 (US) to IEC-320 cord. Other IEC
cords are available separately 1
This instruction sheet describes how to safely install the IntelliCom WAN Mesh Radio.
It is intended to be installed by trained professionals. Be sure to read and understand all
installation and safety instructions before proceeding with the installation.
You should set up and test your radios indoors, on a bench or table, before installing
them. This will allow you to pre-congure the radios so that they are all on the same
radio frequency (RF) channel. You will use IntelliCom®View Pro Network Management
Software to congure the radios and create a small mesh network. Test the network
settings you plan to use.
IntelliCom DA Mesh and WAN Mesh Radios can be congured to support one- or two-radio
operation, and the WAN Mesh Radio can optionally support 802.11n (MIMO) operation.
The IntelliCom DAM Mesh Radio does not support 802.11n (MIMO) operation.
For IntelliCom DA Mesh and WAN Mesh Radios, the second radio, if needed, must be
enabled via a license and IntelliCom View Pro software. Likewise, the MIMO capability
must be enabled for those radios which require it.
Radio Kit Contents
Setup and
Configuration
Radio Upgrades

S&C Instruction Sheet 1069-500 5
Setup and Installation
1. Verify that all radios (nodes) are visible in the IntelliCom View Pro software. If not,
troubleshoot per directions in the IntelliCom View Pro Reference Guide.
2. Set the country code for your country of operation.
3. Re-verify that all radios are visible.
4. Apply MIMO upgrade licenses to radios requiring them. For radios requiring dual-radio
operation, apply dual-radio upgrade licenses.
5. Verify that dual radios have both radios correctly meshed.
6. Verify that MIMO-enabled radios show 802.11n radio options.
7. Label each radio. Make the label large enough to be visible from the ground when the
unit is mounted. The label should include the last four digits of the radio serial number,
for easy identication in the eld. Many installers mark the unit with the number of the
active radio (1 or 2), MIMO status, and the type of antenna to be connected to each
radio.
NOTICE
The staging antennas provided with the radios are for temporary use only. They must be
replaced with outdoor-rated antennas as soon as the mesh is staged and operational.
The staging antennas are not waterproof and not moisture-resistant.If staging antennas
are used outdoors, the radio may be damaged.
Radio installation is straightforward. You must power up and congure all radios on
a table or bench before deployment. Apply power. The power LED should illuminate
immediately; after about 60-90 seconds, the status LED should switch to steady green.
Note the location of the reset hole in the lower right corner of the rear panel. To reset
the unit, apply power and wait until the unit has fully booted and the status light has come
on. Then use a paperclip to press and hold the reset button until the status LED blinks.
The supplied antennas are rated for use in dry, indoor environments. If an antenna is
exposed to weather, moisture, or high humidity, it may be damaged. Install an approved
outdoor-rated antenna instead of the supplied test antenna.
Preparing for
Installation
Installation Overview
for IntelliCom DA Mesh
Radios
1. Pre-assemble the antenna, radio, and other devices to a metal pole or other suitable
structure. Then, attach the assembly to the mast, tower, or other mounting system.
It is often easier to install all devices on one object, such as a pole, and then attach
the pole to the roof. In many cases, connecting the devices on a pole already attached
to the roof top can be difcult and dangerous.
2. A lightning surge suppressor must be used. Some antennas include one. If not, you
must install a lightning suppressor.
3. Install the antenna higher than the radio. Take care when locating the radio far away
from the antenna; a short antenna cable provides better performance than a longer
one. When possible, use antenna cables less than three meters long.
4. The radio and its antenna must both be grounded.
5. Use weatherproong kits that include non-vulcanized rubber to weather-proof
connectors and antennas. All Ethernet cables must be weatherproofed; standard
RJ-45 connectors are not suitable for outdoor application.
6. Power over Ethernet (PoE): Consider which devices require PoE and the required
input voltage. Ports2 and 3 on the radio can supply up to 13W each of PoE-compliant
power.
7. Connect peripheral devices to the radio.
8. Connect power to the radio and peripherals.
Installation Overview
for IntelliCom WAN
Mesh Radios

6S&C Instruction Sheet 1069-500
Setup and Installation
The IntelliCom WAN Mesh Radio must be properly connected to earth ground. Failure
to do so may result in equipment damage, injury, or death. The product warranty does
not cover damages resulting in part or in whole from improper grounding. Consult your
local building and electrical codes regarding antennas and follow them, or consult the
National Electrical Code (NEC) guide.
• If connecting to a tower or pole, connect the base of the tower pole directly to the
building’s ground or to one or more approved grounding rods using 10AWG ground
wire and corrosion-resistant connectors.
• Connect the grounding cable to rain gutters only if the rain gutter is connected to
earth ground.
• Ground rods should be copper-plated, 1.8–2.4 m (6–8 ft.) long.
• Install all grounding components in straight lines. If bends are unavoidable, do not
make sharp turns.
• Earth-to-ground resistance should not be more than 10 ohms.
• Understanding the soil is very important in order to create a proper earth ground. If
your soil is rocky or sandy, drive your ground rods and then pull them back out and
dump an approved ground enhancement material into the holes where the grounding
rods go. Then replace the grounding rods. Keep in mind that some salt compounds
can corrode copper.
S&C recommends the use of antennas specically designed for MIMO applications. While
it is possible to select and mount six individual antennas, determining correct placement
and spacing is difcult. Use an antenna engineered for best results with MIMO.
If you are not using three antennas on each radio, install antennas in order, from the
front of the unit toward the back. Do not skip antenna connections.
Once you determine which radio frequency band to use, you can obtain spectrum-specic
high-gain antennas.
Many installers prefer to mount the radio and its associated antennas to a short bar,
typically about 2 meters long. This entire bar assembly is then mounted horizontally to
the vertical mast of the main antenna structure.
These tools are necessary:
• #2 Phillips screwdriver.
• Small adjustable wrench.
• Wire cutters to cut tie wraps around cables.
• Weatherproong kit—this kit provides electrical tape and butyl mastic.
Depending on the installation location, you may need ladders, a lift truck, or other
means to access the installation locations.
Tools Needed
Preparing Earth Ground
Antenna Placement
Mounting Outdoor
Antennas

S&C Instruction Sheet 1069-500 7
Setup and Installation
Mounting the IntelliCom
WAN Mesh Radio
Your radio is supplied with a two-piece mounting bracket. To mount the radio, remove
the outer piece by loosening the thumb screws. The inner bracket can be left attached
to the radio, as shown in Figure 1.
You can mount the radio to a wall, a light pole, or an irregularly shaped pole. The universal
mounting bracket has been designed with multiple holes and slots to allow mounting with
U-bolts, straps, or other methods. Extra nuts and bolts are provided for this purpose;
don’t be concerned if you have leftover fasteners when installation is complete. See
Figure 2. Use four screws (not supplied) to attach the universal mounting bracket securely
to the wall using the four holes near the top and bottom of the bracket. Use appropriate
anchors when attaching to masonry or other materials.
Figure 1. IntelliCom WAN Mesh Radio universal mounting bracket.
Figure 2. Attaching the IntelliCom WAN Mesh Radio mounting bracket.

8S&C Instruction Sheet 1069-500
For poles having a diameter larger than 50 mm (2 inches) or irregularly shaped poles,
use mounting straps (not supplied) to mount the radio.
1. Position the universal mounting bracket against the pole.
2. Thread two mounting straps around the pole and through the slots located near the top
and bottom of the universal mounting bracket. Secure the mounting straps.
Setup and Installation
Mounting Straps
Pole Mounting 1. Insert the two U-bolts through the holes in the claw-toothed piece.
2. On each U-bolt, place a washer, a lock washer, and a nut. Smaller pole diameters
usually require a second nut as a spacer to hold the bracket away from the U-bolt
clamp. Finger-tighten the nuts. There should be about 12-15mm (1/2-5/8 inch) of the
U-bolt sticking out past the second nut.
3. Mount the second U-bolt. Use the mounting bracket as a guide to correctly space the
two U-bolts, then tighten the nuts. A horizontal pole-mount is also shown for reference.
Use lock washers and nuts to secure the bracket to the U-bolts. Installation on
a horizontal pole is the same; you just use different holes in the mounting plate.
See Figure 3.
Figure 3. Mounting examples, vertical, horizontal, and universal mounting bracket.
Now that you’ve attached the Universal Mounting Plate, you are ready to proceed to the
next steps. If you are using separately mounted antennas, mount them now. If you are
using the temporary staging antennas, slide the IntelliCom WAN Mesh Radio onto the
mounting plate; secure it with four screws.
Mounting Antennas
Connecting Cables After the radio is mounted, attach the antennas, the power cable, and any Ethernet cables
you need. In Figure 4 on page 9, note that all of the weatherproof caps have been removed
for illustrative purposes. Do not leave any unused connectors uncovered.
Note the location of the weatherproof cap that has the reset button under it, at the
bottom left in Figure 4. To reset the unit, apply power and wait until the unit has fully
booted and the status light has come on. Then use a paperclip to press and hold the reset
button until the status LED blinks. This takes about 12 to 15 seconds.

S&C Instruction Sheet 1069-500 9
Setup and Installation
Figure 4. IntelliCom WAN Mesh Radio power and Ethernet connectors.
Figure 5. IntelliCom WAN Mesh Radio antenna connectors.
Power Connection Connect the ac power cable to ac power and to the IntelliCom WAN Mesh Radio. Refer to
Figure 4, from left to right: ac power, dc power, Ethernet Port 3 (PoE), Ethernet Port 2
(PoE), Ethernet Port 1 (no PoE), USB (not used).
Bottom row, from left to right: Reset button (under threaded cap), Power LED, Status
LED, Radio 1 Mesh LED, Radio 2 Mesh LED, Ethernet.
Ports 2 and 3 can provide IEEE 802.3af PoE functionality to powered devices connected
to these ports. Port 1 cannot supply power.
Powering Other
Ethernet Devices
When connecting antennas, connect them in numerical order 1-2-3. If you are not using
three antennas per radio, do not skip antenna connectors. Refer to Figure 5, from left
to right: Antenna 1, antenna2, antenna 3. The antenna 1 connector is at the top of the
unit (farthest from the power and Ethernet connections) on both the left and right sides.
Connecting Antennas

10 S&C Instruction Sheet 1069-500
This table describes the technical limits of the radios. Some countries have restrictions
which may further limit available choices.
Table 2—IntelliCom DA and WAN Mesh Radio Wireless Interface
Mode Frequency (GHz) Restrictions
802.11a
802.11nn
5.15–5.25
5.25–5.35
5.725–5.825
50 mW; indoor (US)
250 mW, DFS (US)
none
4.9–5.090
4.94–4.990
Japan only
U.S. Public Safety
5.470–5.725 ETSI 301.893, U-NII
802.11b/g/nn2.412–2.484 400 mW
Modes Max TX Power
802.11a
802.11nn
5.725–5.825 UNII-3
5.470–5.735 UNII
5.25–5.36 M UNII-2
5.15–5.25 UNII-1
26 dBm
26 dBm
24 dBm
23 dBm
23 dBm
23 dBm
17 dBm
802.11b 2.412–2.484 24 dBm
802.11g
802.11nn
2.412–2.484 26 dBm
26 dBm
n802.11n is supported on the IntelliCom WAN Mesh Radio only.
Specications
Supported Data Rates and Standards
• 802.11a 6/9/12/18/24/36/48/54 Mbps
• 802.11a 1⁄4 and 1⁄2 rates for 4.940–4.990 GHz Public Safety Band
• 802.11b 1/2/5.5/11 Mbps
• 802.11g 6/9/12/18/24/36/48/54 Mbps
• 802.11n 6.5/13/19.5/26/65/130 (20 MHz LGB)
7.2/14.4/21.7/28.9/72.2/144 (20MHz SGB)
13.5/27/40.5/54/135/270 (40 MHz LGB)
15/30/45/60/150/300 (40MHz LGB)
• Network Standards: IEEE 802.11a/b/d/g/e/f/h/i/n
• Dynamic Frequency Selection (DFS) capable in conjunction with S&C software
application
Mesh Protocol
S&C AutoMesh Protocol
Mesh Management Software
S&C IntelliCom® View Pro Network Management Software
Security and Encryption
Security: WPA—64/128/256 w/TKIP, AES

S&C Instruction Sheet 1069-500 11
Specications
Network Ports
IntelliCom DA Mesh Radio: Four 10/100/1000 Mbps Ethernet ports with LEDs; PoE PD
on Port 1
IntelliCom WAN Mesh Radio: Three weatherproof 10/100/1000 Mbps Ethernet ports
with weatherproof connectors, and LED activity indicators
• IEEE 802.3, 802.3u compliant
• CSMA/CD 10/100/1000 autosense
• Ports 2, 3 PSE PoE per 802.3af
Enclosure
• IntelliCom DA Mesh Radio: Plenum-rated metal; 2 RP-SMA antenna connectors
• IntelliCom WAN Mesh Radio: Aluminum NEMA-4X/IP66; 6 N antenna connectors
• System LEDs (power, status, mesh (per radio), Ethernet)
• IntelliCom DA Mesh Radio Dimensions: 9.4 X6 X1.8 inches (238 X152 X48 mm)
3 lbs (1.4 Kg)
• IntelliCom WAN Mesh Radio Dimensions: 8.8 X11.2 X4 inches (220 X280 X100 mm);
12 lbs (5.5 Kg) with bracket
Power
• IntelliCom DA Mesh Radio: 12 Vdc ±15%, 1.8 A
• IntelliCom WAN Mesh Radio: 12 Vdc ±15%, 3 A; or 90-240 Vac 50-60 Hz, 0.9 A
PoE
• IntelliCom DA Mesh Radio: PoE PD on Port 1
• IntelliCom WAN Mesh Radio: Ports 2 and 3: IEEE 802.3af compliant PoE (PSE),
13.5 W max
Environmental Specifications
• Operating temperature: -40º C to +60ºC
• Storage temperature: -40º C to +85º C
• Humidity (non-condensing): 10% to 90%
• Storage humidity (non-condensing): 5% to 95%
• Maximum altitude 15,000 feet (4600 meters)
Included Accessories
• IntelliCom DA Mesh Radio: ac power adapter; two dual-band 2.4 GHz/4.9-5.8 GHz
omnidirectional staging antennas, for indoor use only
• IntelliCom WAN Mesh Radio: six dual-band 2.4 GHz/4.9-5.8 GHz omnidirectional stag-
ing antennas, for indoor use only

12 S&C Instruction Sheet 1069-500
Regulatory Information
FCC Class A Notice
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in an office installation. This
equipment generates, uses, and can radiate radio frequency energy, and if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/television technician for help.
FCC Part 15 Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
• This device may not cause harmful interference.
• This device must accept any interference received, including interference that may
cause undesired operation.
FCC Part 90 and Public Safety Statement
This equipment has been tested pursuant to FCC Part 90, DSRC-C mask certication, and
is approved for use in the U.S. on Public Safety bands by licensed Public Safety agencies.
Pursuant to Part 90.1215, use of antennas with gain greater than 9 dBi and up to 19 dBi
in the 4.940–4.990 GHz Public Safety band is permissible without reduction of TX output
power. The antenna shall have a directional gain pattern in order to meet the requirement
of point to point and point to multi-point operation.
Modification and Antenna Installation Statement
Any modications made to this device that are not approved by S&C Electric Company
may void the authority granted to the user by the FCC to operate this equipment.
Antenna(s) for this unit must be installed by a qualied professional. Operation of the
unit with non-approved antennas is a violation of U.S. FCC Rules, Part 15.203(c), Code
of Federal Regulations, Title 47.

S&C Instruction Sheet 1069-500 13
Regulatory Information
FCC Radiation Exposure Statement
To ensure compliance with the FCC’s radio frequency exposure limits, the antenna used
for this transmitter must be installed to provide a separation distance from all personnel.
The distance must be 76 cm.
The transmitter must not be co-located or operated in conjunction with any other
antenna or transmitter. Installers and end users must follow these installation instructions.
FCC Canadian Compliance Statement
This Class A digital apparatus meets all Canadian Interference-Causing Equipment
Regulations.
Cet appareil numerique de la classe A respecte les exigences du Reglement sur le
material broilleur du Canada.
This device complies with Class A Limits of Industry Canada. Operation is subject to
the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may
cause undesired operation.
S&C IntelliCom®Mesh Radios are certified to the requirements of RSS-210 for 2.4
and 5 GHz spread spectrum devices. The use of this device in a system operating either
partially or completely outdoors may require the user to obtain a license for the system
according to the Canadian regulations. For further information, contact your local
Industry Canada office.
Canadian units will not transmit in the 5600–5650 MHz band.
DFS Notice
IntelliCom WAN Mesh Radio devices are subject to Section 15.407 of FCC rules and are
required to implement radar detection and DFS functions. They are DFS-certied, and will
not transmit on channels which overlap the 5600–5650 MHz band (channels 120, 124, 128).
Devices intended for outdoor use are further restricted, as follows:
Any installation of a device within 35 km of a Terminal Doppler Weather Radar (TDWR)
location shall be separated by at least 30 MHz (center-to-center) from all TDWR operating
frequencies (as shown in Table 3 on page 14).
Procedures for the installers and the operators on how to register the devices in the
industry-sponsored database with the appropriate information regarding the location
and operation of the device and installer information is included.

14 S&C Instruction Sheet 1069-500
Regulatory Information
Table 3—U.S. Terminal Doppler Weather Radar Installations
ST City Longitude Latitude Frequency
AZ Phoenix W 112 09 46 N 33 25 14 5610 MHz
CO Denver W 104 31 35 N 39 43 39 5615 MHz
FL Ft Lauderdale W 080 20 39 N 26 08 36 5645 MHz
FL Miami W 080 29 28 N 25 45 27 5605 MHz
FL Orlando W 081 19 33 N 28 20 37 5640 MHz
FL Tampa W 082 31 04 N 27 51 35 5620 MHz
FL West Palm Beach W 080 16 23 N 26 41 17 5615 MHz
GA Atlanta W 084 15 44 N 33 38 48 5615 MHz
IL Crestwood W 087 43 47 N 41 39 05 5645 MHz
IL McCook W 087 51 31 N 41 47 50 5615 MHz
IN Indianapolis W 086 26 08 N 39 38 14 5605 MHz
KS Wichita W 097 26 13 N 37 30 26 5603 MHz
KY Covington W 084 34 48 N 38 53 53 5610 MHz
KY Louisville W 085 36 38 N 38 02 45 5646 MHz
LA New Orleans W 090 24 11 N 30 01 18 5645 MHz
MA Boston W 070 56 01 N 42 09 30 5610 MHz
MD Brandywine W 076 50 42 N 38 41 43 5635 MHz
MD Benfield W 076 37 48 N 39 05 23 5645 MHz
MD Clinton W 076 57 43 N 38 45 32 5615 MHz
MI Detroit W 083 30 54 N 42 06 40 5615 MHz
MN Minneapolis W 092 55 58 N 44 52 17 5610 MHz
MO Kansas City W 094 44 31 N 39 29 55 5605 MHz
MO Saint Louis W 090 29 21 N 38 48 20 5610 MHz
MS Desoto County W 089 59 33 N 34 53 45 5610 MHz
NC Charlotte W 080 53 06 N 35 20 14 5608 MHz
NC Raleigh Durham W 078 41 50 N 36 00 07 5647 MHz
NJ Woodbridge W 074 16 13 N 40 35 37 5620 MHz
NJ Pennsauken W 075 04 12 N 39 56 57 5610 MHz
NV Las Vegas W 115 00 26 N 36 08 37 5645 MHz
NY Floyd Bennett Field W 073 52 49 N 40 35 20 5647 MHz
OH Dayton W 084 07 23 N 40 01 19 5640 MHz
OH Cleveland W 082 00 28 N 41 17 23 5645 MHz

S&C Instruction Sheet 1069-500 15
Regulatory Information
Table 3—U.S. Terminal Doppler Weather Radar Installations—
continued
ST City Longitude Latitude Frequency
OH Columbus W 082 42 55 N 40 00 20 5605 MHz
OK Aero. Ctr TDWR #1 W 097 37 31 N 35 24 19 5610 MHz
OK Aero. Ctr TDWR #2 W 097 37 43 N 35 23 34 5620 MHz
OK Tulsa W 095 49 34 N 36 04 14 5605 MHz
OK Oklahoma City W 097 30 36 N 35 16 34 5603 MHz
PA Hanover W 080 29 10 N 40 30 05 5615 MHz
PR San Juan W 066 10 46 N 18 28 26 5610 MHz
TN Nashville W 086 39 42 N 35 58 47 5605 MHz
TX Houston W 095 34 01 N 30 03 54 5605 MHz
TX Pearland W 095 14 30 N 29 30 59 5645 MHz
TX Dallas Love Field W 096 N 32 55 33 5806 MHz
TX Lewisville Dfw W 096 N 33 03 53 5505 MHz
UT Salt Lake City W 111 N 40 58 02 5547 MHz
VA Leesburg W 077 31 46 N 39 05 02 5605 MHz
WI Milwaukee W 088 02 47 N 42 49 10 5603 MHz

16 S&C Instruction Sheet 1069-500
Connector Wiring—IntelliCom WAN Mesh Radio
Figure 6. IntelliCom WAN Mesh Radio ac connector.
Connector View Cable-End View
Figure 7. IntelliCom WAN Mesh Radio dc connector.
Connector View Cable-End View
Figure 6 shows the pin out of the ac power connector for an IntelliCom WAN Mesh Radio.
Views are shown for the connector on the unit, and the mating connector on the cable
itself. Pin 1 is neutral; pin 2 is line, and pin 3 is ground.
Figure 7 shows the pinout of the dc power connector for an IntelliCom WAN Mesh Radio.
Views are shown for the connector on the unit, and the mating connector on the cable
itself. Pin 4 is +12 Vdc, and pin 3 is ground.
Figure 8 shows the wiring diagram for the optional 6-pin power connector, Catalog
Number DC-1720. The connector is supplied without a cable. Standard power cable can
be used to make the required length.
NOTICE
For the IntelliCom WAN Mesh Radio to supply PoE-compliant 48 Vdc power to other
devices, it must be supplied 12 Vdc ±15%, at 3 amperes.
Figure 8. Wiring for catalog number DC-1720 dc connector.
Cable-End View
Printed in U.S.A.
AC Power Connection
DC Power Connection
Custom DC Cable
