Sandpiper HDF2-A User manual

hdf2dl5sm-REV0208 Model HDF2-A Page 1 Rev B
PLEASE NOTE!
The photos shown in this manual are for general instruction only.YOUR SPECIFIC
MODEL MAY NOT BE SHOWN. Always refer to the parts list and exploded view
drawing for your specific model when installing, disassembling or servicing your pump.
PRINCIPLE OF PUMP OPERATION
This flap swing check valve pump is powered by compressed air and is a 1:1
pressure ratio design. It alternately pressurizes the inner side of one diaphragm
chamber, while simultaneously exhausting the other inner chamber. This causes the
diaphragms, which are connected by a common rod, to move endwise. Air pressure
is applied over the entire surface of the diaphragm, while liquid is discharged from
the opposite side. The diaphragm operates under a balanced condition during the
discharge stroke, which allows the unit to be operated at discharge heads over 200
feet (61 meters) of water head.
Since the diaphragms are connected by a common rod, secured by plates to the
center of the diaphragms, one diaphragm performs the discharge stroke, while the
other is pulled to perform the suction stroke in the opposite chamber.
For maximum diaphragm life, keep the pump as close to the liquid being pumped
as possible. Positive suction head in excess of 10 feet of liquid (3.048 meters) may
require a back pressure regulating device. This will maximize diaphragm life.
Alternate pressuring and exhausting of the diaphragm chamber is performed by
means of an externally mounted, pilot operated, four-way spool type air distribution
valve. When the spool shifts to one end of the valve body, inlet air pressure is applied
to one diaphragm chamber and the other diaphragm chamber exhausts. When the
spool shifts to the opposite end of the valve body, the porting of chambers is reversed.
The air distribution valve spool is moved by an internal pilot valve which alternately
pressurizes one side of the air distribution valve spool, while exhausting the other
side. The pilot valve is shifted at each end of the diaphragm stroke by the diaphragm
plate coming in contact with the end of the pilot spool. This pushes it into position for
shifting of the air distribution valve.
The chambers are manifolded together with a suction and discharge flap-type
check valve for each chamber, maintaining flow in one direction through the pump.
INSTALLATION & START-UP
Locate the pump as close to the product being pumped as possible, keeping suc-
tion line length and number of fittings to a minimum. Do not reduce line size.
For installations of rigid piping, short flexible sections of hose should be installed
between pump and piping. This reduces vibration and strain to the piping system. A
surge suppressor is recommended to further reduce pulsation in flow.
This pump was tested at the factory prior to shipment and is ready for operation.
It is completely self-priming from a dry start for suction lifts of 20 feet (6.096 meters)
or less. For suction lifts exceeding 20 feet of liquid, fill the chambers with liquid prior
to priming.
AIR SUPPLY
Air supply pressures cannot exceed 125 psi (8.61 bar). Connect the pump air inlet
to an air supply of sufficient capacity and pressure required for desired performance.
When the air line is solid piping, use a short length of flexible hose [not less than
3/4" (19mm) in diameter] between pump and piping to eliminate strain to pipes.
WARREN RUPP, INC. A Unit of IDEX Corporation P.O. Box 1568 Mansfield, Ohio 44901-1568 USA [phone] Fax [phone]
SERVICE AND OPERATING MANUAL
Model HDF2-A
Type 5
I M2 c T5
II 2GD T5
CE
I n t h e e v e n t o f
diaphragm rupture,
pumped material may
enter the air end of
the pu mp, and be
discharged into the atmosphere. The air
exhaust must be piped to an appropriate
area for safe disposition.
WARNING
Before maintenance
or repair, shut off the
com-pressed air line,
bleed the pressure,
and disconnect the
air line from the pump.
The discharge line may be pressurized
and must be bled of its pressure.
WARNING
Before pump
operation, inspect all
gasketed fasteners
for looseness caused
by gasket creep. Re-
torque loose fasteners to prevent leakage.
Follow recommended torques stated in
this manual.
CAUTION
Read these safety
warnings and
instructions in this
manual completely,
before installation and start-up of the pump.
It is the responsibility of the purchaser to
retain this manual for reference. Failure to
comply with the recommendations stated
in this manual will damage the pump, and
void factory warranty.
Take action to prevent
static sparking. Fire
or explosion can
result, especially
when handling
flammable liquids.
The pump, piping, valves,
containers or other miscellaneous
equipment must be grounded.
WARNING
IMPORTANT

Model HDF2-A Page 2 hdf2dl5sm-REV0208
AIR INLET & PRIMING
For start-up, open an air valve approximately 1/2" to 3/4" turn. After the unit primes,
an air valve can be opened to increase flow as desired. If opening the valve increases
cycling rate, but does not increase flow rate, cavitation has occurred, and the valve
should be closed slightly.
For the most efficient use of compressed air and the longest diaphragm life, throttle
the air inlet to the lowest cycling rate that does not reduce flow.
A NOTE ABOUT AIR VALVE LUBRICATION
The SANDPIPER pump’s pilot valve and main air valve assemblies are designed
to operate WITHOUT lubrication. This is the preferred mode of operation. There may
be instances of personal preference, or poor quality air supplies when lubrication
of the compressed air supply is required. The pump air system will operate with
properly lubricated compressed air supplies. Proper lubrication of the compressed air
supply would entail the use of an air line lubricator (available from Warren Rupp) set
to deliver one drop of 10 wt., non-detergent oil for every 20 SCFM of air the pump
consumed at its point of operation.Consult the pump’s published Performance Curve to
determine this.
It is important to remember to inspect the sleeve and spool set routinely. It should
move back and forth freely. This is most important when the air supply is lubricated.
If a lubricator is used, oil accumulation will, over time, collect any debris from the
compressed air. This can prevent the pump from operating properly.
Water in the compressed air supply can create problems such as icing or
freezing of the exhaust air causing the pump to cycle erratically, or stop operating.This
can be addressed by using a point of use air dryer to supplement a plant’s air drying
equipment.This device will remove excess water from the compressed air supply and
alleviate the icing or freezing problem.
ESADS: EXTERNALLY SERVICEABLE AIR
DISTRIBUTION SYSTEM
Please refer to the exploded view drawing and parts list in the Service Manual
supplied with your pump. If you need replacement or additional copies, contact your
local Warren Rupp Distributor, or the Warren Rupp factory Literature Department at
the number shown below.To receive the correct manual, you must specify the MODEL
and TYPE information found on the name plate of the pump.
MODELS WITH 1" SUCTION/DISCHARGE OR LARGER,
AND METAL CENTER SECTIONS:
The main air valve sleeve and spool set is located in the valve body mounted on
the pump with four hex head capscrews. The valve body assembly is removed from
the pump by removing these four hex head capscrews.
With the valve body assembly off the pump, access to the sleeve and spool set
is made by removing four hex head capscrews (each end) on the end caps of the
valve body assembly. With the end caps removed, slide the spool back and forth in
the sleeve. The spool is closely sized to the sleeve and must move freely to allow for
proper pump operation. An accumulation of oil, dirt or other contaminants from the
pump’s air supply, or from a failed diaphragm, may prevent the spool from moving freely.
This can cause the spool to stick in a position that prevents the pump from operating.
If this is the case, the sleeve and spool set should be removed from the valve body
for cleaning and further inspection.
Remove the spool from the sleeve. Using an arbor press or bench vise (with an
improvised mandrel), press the sleeve from the valve body. Take care not to damage
the sleeve. At this point, inspect the o-rings on the sleeve for nicks, tears or abrasions.
Damage of this sort could happen during assembly or servicing. A sheared or cut
o-ring can allow the pump’s compressed air supply to leak or bypass within the air
valve assembly, causing the pump to leak compressed air from the pump air exhaust
or not cycle properly. This is most noticeable at pump dead head or high discharge
pressure conditions. Replace any of these o-rings as required or set up a routine,
preventive maintenance schedule to do so on a regular basis. This practice should
include cleaning the spool and sleeve components with a safety solvent or equivalent,
inspecting for signs of wear or damage, and replacing worn components.
Do not smoke near
t h e p u m p o r u s e
the pump near an
open flame. Fire or
explosion could result.
WARNING
This pump must not be
used for fluid transfer
into aircraft.
WARNING
This pump is
pressurized internally
with air pressure
during operation.
Always make certain
that all bolting is in good condition and
that all of the correct bolting is reinstalled
during assembly.
WARNING
When used for toxic or
aggressive fluids, the
pump should always
be flushed clean prior
to disassembly.
WARNING
Before doing any
main-tenance on the
pump, be certain all
pressure is completely
vented from the
pump, suction, discharge, piping, and
all other openings and connections. Be
certain the air supply is locked out or
made non-operational, so that it cannot
be started while work is being done on
the pump. Be certain that approved eye
protection and protective clothing are
worn all times in the vicinity of the pump.
Failure to follow these recommendations
may result in serious injury or death.
WARNING
Airborne particles and
loud noise hazards.
Wear ear and eye
protection.
WARNING

hdf2dl5sm-REV0208 Model HDF2-A Page 3 Rev B
To re-install the sleeve and spool set, lightly lubricate the o-rings on the sleeve
with an o-ring assembly lubricant or lightweight oil (such as 10 wt. air line lubricant).
Re-install one end cap, gasket and bumper on the valve body. Using the arbor press
or bench vise that was used in disassembly, carefully press the sleeve back into the
valve body, without shearing the o-rings. You may have to clean the surfaces of the
valve body where the end caps mount. Material may remain from the old gasket. Old
material not cleaned from this area may cause air leakage after reassembly.Take care
that the bumper stays in place allowing the sleeve to press in all the way. Reinstall the
spool, opposite end cap, gasket and bumper on the valve body. After inspecting and
cleaning the gasket surfaces on the valve body and intermediate, reinstall the valve
body on the pump using new gaskets. Tighten the four hex head capscrews evenly
and in an alternating cross pattern.
AIR EXHAUST
If a diaphragm fails, the pumped liquid or fumes can enter the air end of the pump,
and be exhausted into the atmosphere. When pumping hazardous or toxic materials,
pipe the exhaust to an appropriate area for safe disposition.
This pump can be submerged if materials of construction are compatible with the
liquid. The air exhaust must be piped above the liquid level. Piping used for the air
exhaust must not be smaller than 1" (2.54 cm). Reducing the pipe size will restrict
air flow and reduce pump performance .When the product source is at a higher level
than the pump (flooded suction), pipe the exhaust higher than the product source to
prevent siphoning spills.
Freezing or icing-up of the air exhaust can occur under certain temperature and
humidity conditions. Use of an air dryer unit should eliminate most icing problems.
BETWEEN USES
When used for materials that tend to settle out or transform to solid form, the pump
should be completely flushed after each use, to prevent damage. Product remaining
in the pump between uses could dry out or settle out. This could cause problems with
valves and diaphragms at re-start. In freezing temperatures, the pump must be drained
between uses in all cases.
CHECK VALVE SERVICING
Valve inspection requires removal of (4) 3/8" hex nuts. On the suction side the
flange, when removed, carries the valve and seat as an assembly. On the discharge
side, the valve and seat will stay with the diaphragm housing. Visual inspection and
cleaning is possible.If parts are to be replaced, remove the self locking nuts and all parts
are accessible.
DIAPHRAGM SERVICING
Diaphragms can be inspected or the diaphragm assembly removed
without removing the suction and discharge flanges. Remove (8) nuts around the
chamber flange, and the housing assembly will pull off. Check valves can be inspected
for proper seating at this point as well as the diaphragm. Use care to keep foreign
matter from behind the diaphragm. The opposite diaphragm may be inspected by the
same procedure. If either diaphragm has to be replaced, follow closely these steps:
Pull the outer diameter of one diaphragm off the (8) capscrews. NOTE: One
side only! On the free diaphragm assembly, use a 3/8" allen wrench to turn the
assembly (diaphragm, plates and screw) loose from the shaft. Once the
assembly has turned, it will turn out by hand by use of the diaphragm. Now the opposite
diaphragm assembly and the drive shaft will pull free from the capscrews and pump
intermediate assembly. The interior components consisting of sleeve bearings, rod
seals, and pilot valve actuator bushings are now accessible for service if required.
Hold the shaft in a clamping device making sure to protect surface of shaft so as not to
scratch or mar it in any way. The diaphragm assembly will turn loose. To disassemble
the components, turn a 1/4"-20 capscrew by hand into the tapped hole in the inner
plate. This keeps the plate from turning while the socket head capscrew is removed.
To do this, place assembly in a vise so the two protruding ends of screws are loose in
the vise jaws (about 3/4" apart). Turn the center screw loose from the back plate and
the assembly will come apart.

Model HDF2-A Page 4 hdf2dl5sm-REV0208
REASSEMBLY
All procedures for reassembling the pump are the reverse of the previous
instructions with further instructions as shown:
1. The diaphragm assemblies are to be installed with the natural bulge outward
or toward the head of the center screw. Make sure both plates are installed with
outer radii against the diaphragm. After all components are in position in a vise and
hand tight, set a torque wrench for 480 inch pounds (40 ft. pounds) (54.23 Newton
meters) using a (3/8") allen head socket. After each diaphragm sub assembly has been
completed, thread one assembly into the shaft (held near the middle in a vise having
soft jaws to protect the finish) making sure the stainless steel washer is in place on
the capscrew.
Make sure 1/4"-20 mounting screw has been removed and that the bumper (Item
#19 on drawing) is in place in the shaft.
Install this sub assembly into the pump and secure by placing the outer chamber
housing and capscrews on the end with the diaphragm. This will hold the assembly
in place while the opposite side is installed. Make sure the last diaphragm assembly
is torqued to 30 ft. lbs. (40.67 Newton meters) before placing the outer diaphragm
over the capscrews. If the holes in the diaphragm flange do not line up with the holes
in the chamber flange, turn the diaphragm assembly in the direction of tightening
to align the holes so that the capscrews can be inserted. This final torquing of the
last diaphragm assembly will lock the two diaphragm assemblies together. Place
remaining outer chamber on the open end and tighten down the securing nuts
gradually and evenly on both sides.
Caution should be used while reassembling check valves.The valves are designed
for some preload over the retainer hinge pad.This is done to insure proper face contact
with the seat. After all parts are in place, tighten the lock nuts down on the assembly
to the point where visual inspection shows that seat and valve face mate without gap.
This is important for dry prime. However, after priming action has started, valves will
function due to differential pressure without concern or trouble.
PILOT VALVE
The pilot valve assembly is accessed by removing the main air distribution valve
body from the pump and lifting the pilot valve body out of the intermediate housing.
Most problems with the pilot valve can be corrected by replacing the o-rings.
Always grease the spool prior to inserting it into the sleeve. If the sleeve is removed
from the body, reinsertion must be at the chamfered side. Grease the o-rings to slide
the sleeve into the valve body. Securely insert the retaining ring around the sleeve.
When reinserting the pilot valve, push both plungers (located inside the intermediate
bracket) out of the path of the pilot valve spool ends to avoid damage.
PILOT VALVE ACTUATOR
Bushings for the pilot valve actuators are threaded into the intermediate bracket
from the outside. The plunger may be removed for inspection or replacement. First
remove the air distribution valve body and the pilot valve body from the pump. The
plungers can be located by looking into the intermediate. It may be necessary to
use a fine piece of wire to pull them out. The bushing can be turned out through the
inner chamber by removing the outer chamber assembly. Replace the bushings if pins
have bent.

hdf2dl5sm-REV0208 Model HDF2-A Page 5 Rev B
TROUBLESHOOTING
PROBLEM: Pump cycles but will not pump. (Note: higher suction lifts require faster
cycling speed for priming.)
POSSIBLE CAUSES:
A. Air leak in suction line.
B. Excessive suction lift.
C. Check valve not seating properly.
D. Leakage at joint of suction manifold or elbow flange.
E. Suction line or strainer plugged.
F. Diaphragm ruptured.
PROBLEM: Pump will not cycle. (Note: Always disconnect air supply to relieve air
pressure before disassembling any portion of pump.)
POSSIBLE CAUSES:
A. Discharge hose or line plugged, or discharge head requirement greater than air
supply pressure. (Disconnect discharge line to check.)
B. Spool in air distribution valve not shifting. (Remove end cap and check spool —
must slide freely.)
C. Diaphragm ruptured. (Air will escape out discharge line in this case.)
D. Blockage in diaphragm chamber preventing movement. (Shut off air supply and
reopen after pressure is relieved.)
PROBLEM: Uneven discharge flow. (Indicates one chamber not operating properly.)
POSSIBLE CAUSES:
A. Check valve not sealing properly in one chamber.
B. Diaphragm failure in one chamber.
C. Air leak at suction manifold joint or elbow flange one side.
For additional information, see the Warren Rupp Troubleshooting Guide.
WARRANTY:
This unit is guaranteed for a period of five years against defective material and
workmanship.
©2006 Warren Rupp, Inc. All rights reserved.
®Warren Rupp, SANDPIPER and Tranquilizer are registered tradenames of Warren Rupp, Inc.
Printed in U.S.A.
RECOMMENDED WARREN RUPP ACCESSORIES
TO MAXIMIZE PUMP PERFORMANCE:
 ®
 
 
 
 
For more detailed information on these accessories,
contact your local Warren Rupp Factory-Authorized Distributor,
or Warren Rupp corporate headquarters.

Model HDF2-A Page 6 hdf2dl5sm-REV0208

Take action to prevent static spark-
ing. Fire or explosion can result,
especially when handling flammable
liquids. The pump, piping, valves,
containers or other miscellaneous
equipment must be grounded.
WARNING


To reduce the risk of static electrical sparking, this pump must be
grounded. Check the local electrical code for detailed grounding
instruction and the type of equipment required, or in the absence of local
codes, an industry or nationally recognized code having juristiction over
specific installations.
THIS 8 FOOT LONG (244 CENTIME-
TERS) GROUND STRAP, PART NUMBER
920-025-000 CAN BE ORDERED AS A
SERVICE ITEM.

hdf2dl5sm-REV0208 Model HDF2-A Page 7 Rev B
1 070.006.170. Bearing, Sleeve 2
2 114.002.156. Bracket, Intermediate 1
114.002.010. Bracket, Intermediate 1
    
  
    
  11
6-A 095.070.551. Pilot Valve Body 1
6-B 755.025.000. Sleeve (w/O-Ring) 1
6-C 560.033.360. O-Ring (Sleeve) 4
6-D 775.026.000. Spool (w/O-Ring) 1
6-E 560.023.360. O-Ring (Spool) 2
6-F 675.037.080. Retaining Ring 1
    
      
9 095.043.156. Body, Valve 1
095.043.010. Body, Valve 1
    
11 165.011.157. Cap, End 2
165.011.010. Cap, End 2
    
13 360.010.425. Gasket, End Cap 2
14 560.020.360. O-Ring 6
     
16 170.032.330. Capscrew, Hex Head 8
17 170.045.330. Capscrew, Hex Head 4
18 115.062.080. Mounting Foot, Left Hand 2
    
20 196.001.157. Chamber, Inner 2
196.001.010. Chamber, Inner 2
21 196.002.157. Chamber, Outer 2
196.002.110. Chamber, Outer 2
196.002.010. Chamber, Outer 2
    
286.007.354. Diaphragm 2
286.007.356. Diaphragm 2
286.007.363. Diaphragm 2
286.007.360. Diaphragm 2
286.007.366. Diaphragm 2
286-007-364 Diaphragm 2
    
24 612.008.330. Plate, Diaphragm (Outer) 2
612.096.110. Plate, Diaphragm (Outer) (SS Units Only) 2
    
26 170.023.330. Capscrew, Hex Head 8
AL only -- 16
27 170.024.330. Capscrew, Hex Head 8
28 618.003.330. Plug, Pipe 4
618.003.110. Plug, Pipe (SS Pump Only) 2
29 115.063.080. Mounting Foot, Right Hand 2
    
171.002.110. Capscrew, Socket Head 2
Repair Parts shown in 
type are more likely to need replacement
after extended periods of normal use.
They are readily available from most Warren
Ruppdistributors.Thepumpowner may prefer
to maintain a limited inventory of these parts
in his own stock to reduce repair downtime
to a minimum.
IMPORTANT: When ordering repair parts
always furnish pump model number, serial
number and type number.
MATERIAL CODES

000... Assembly, sub-assembly; and some
purchased items
010... Cast Iron
015... Ductile Iron
025... Music Wire
080... Carbon Steel, AISI B-1112
110... Alloy Type 316 Stainless Steel
112... Alloy “C”
114... 303 Stainless Steel
115... 301/302/304 Stainless Steel
120... 416 Stainless Steel (Wrought Martensitic)
148... Hardcoat Anodized Aluminum
150... 6061-T6 Aluminum
151... 6063-T6 Aluminum
154... Almag 35 Aluminum
155 or 156...356-T6 Aluminum
157... Die Cast Aluminum Alloy #380
159... Anodized Aluminum
162... Brass, Yellow, Screw Machine Stock
170... Bronze, Bearing Type, Oil Impregnated
180... Copper Alloy
330... Plated Steel
331... Chrome Plated Steel
332... Electroless Nickel Plated
335... Galvanized Steel
354... Injection Molded #203-40 Santoprene —
Duro 40D +/-5; Color: RED
356... Hytrel
357... Rupplon (Urethane Rubber)
360... Buna-N Rubber. Color coded: RED
363... Viton (Fluorel). Color coded:YELLOW
364... E.P.D.M. Rubber. Color coded: BLUE
365... Neoprene Rubber. Color coded: GREEN
366... Food Grade Nitrile. Color coded: WHITE
Delrin, PTFE, Hytrel, and Viton are
registered tradenames of E.I. DuPont.
Gylon is a registered tradename of Garlock, Inc.
Rupplon and SANDPIPER are registered
tradenames of Warren Rupp, Inc.
Ryton is a registered tradename of Phillips
Chemical Company.
Loctite is a registered tradename of Loctite Corporation.
1Available in kit form. Order P/N 031.055.000. which also includes items 4,5,6,7,8 & 12.
ITEM TOTAL
   
SERVICE AND OPERATING MANUAL
Model HDF2-A
Type 5
I M2 c T5
II 2GD T5
CE

Model HDF2-A Page 8 hdf2dl5sm-REV0208
Repair Parts shown in 
type are more likely to need replacement
after extended periods of normal use.
They are readily available from most Warren
Ruppdistributors.Thepumpowner may prefer
to maintain a limited inventory of these parts
in his own stock to reduce repair downtime
to a minimum.
IMPORTANT: When ordering repair parts
always furnish pump model number, serial
number and type number.
ITEM TOTAL
   
31 545.007.330. Nut, Hex 16
(AL Units use 8)
32 807.008.330. Stud 16
33 900.006.330. Washer, Lock 8
(AL Units use 12)
34 612.047.330. Plate, Diaphragm 2
35 312.012.156. Elbow, Suction 2
312.012.110. Elbow, Suction 2
312.012.010. Elbow, Suction 2
334.014.156. Flange, Suction (Dual Ported Only) 2
334.014.010. Flange, Suction (Dual Ported Only) 2
36 312.013.156. Elbow, Discharge 2
312.013.110. Elbow, Discharge 2
312.013.010. Elbow, Discharge 2
334.015.010. Flange, Discharge (Dual Ported Only) 2
334.015.156. Flange, Discharge (Dual Ported Only) 2
    
338.005.365. Flap Valve 4
338.005.360. Flap Valve 4
338.005.366. Flap Valve 4
338.005.363. Flap Valve 4
338.005.364. Flap Valve 4
338.010.356. Flap Valve 4
338.010.354. Flap Valve 4
    
360.011.366. Gasket, Seat 4
    
    
360.012.366. Gasket, Flange 4
360.012.608. Gasket, Flange (Viton, EPDM, Santoprene) 4
40 518.001.157. Manifold, Discharge, Suction 2
518.001.010. Manifold, Discharge, Suction 2
518.001.110. Manifold, Discharge, Suction 2
    
570.001.366. Pad, Hinge — Flap Valve 4
570.001.360. Pad, Hinge — Flap Valve 4
570.001.363. Pad, Hinge — Flap Valve 4
570.001.364. Pad, Hinge — Flap Valve 4
    
     
675.013.360. Ring, Sealing 4
675.013.363. Ring, Sealing 4
675.013.366. Ring, Sealing 4
675.013.364. Ring, Sealing 4
    
722.070.364.* Seat, Flap Valve 4
722.070.360.* Seat, Flap Valve 4
722.070.363.* Seat, Flap Valve 4
46 770.005.330. Spacer 2
47 807.018.110. Stud 8
48 170.052.330. Capscrew, Hex Head 2
49 170.026.330. Capscrew, Hex Head 2
50 545.005.330. Nut, Hex 20
51 900.005.330. Washer, Lock 24
    
     
54 530.036.000. Muffler, Exhaust 1
    
     
57 612.007.150. Plate, Base 1
612.007.080. Plate, Base 1
59 170.018.330. Capscrew, Hex Head 4
62 031.019.156. Main Air Valve Assembly 1
031.019.010. (Inc. Items 9, 10, 11, 13, 14, 15, 16)
64 570.009.360. Pad, Wear 2
570.009.363. Pad, Wear 2
570.009.364. Pad, Wear 2
570.009.365. Pad, Wear 2
65 170.035.330. Capscrew, Hex Head (AL Units only) 8
316SS seats with seals (non-replaceable) eliminate need for items 38 & 39.
MATERIAL CODES

Continued from previous page
375…Fluorinated Nitrile
378…High density Polypropylene
379…Conductive Nitrile
384…Conductive Neoprene
405…Cellulose Fibre
408…Cork and Neoprene
425…Compressed Fibre
426…Blue Gard
440…Vegetable Fibre
465…Fibre
500…Delrin 500
501…Delrin 570
505…Acrylic Resin Plastic
520…Injection Molded PVDF Natural Color
540…Nylon
541…Nylon
542…Nylon
544…Nylon Injection Molded
550…Polyethylene
551…Polypropylene
552…Unfilled Polypropylene
553…Unfilled Polypropylene
555…Polyvinyl Chloride
558…Conductive HDPE
570…Rulon II
580…Ryton
590…Valox
591…Nylatron G-S
592…Nylatron NSB
600…PTFE (virgin material) Tetrafluoroethylene (TFE)
601…PTFE (Bronze and moly filled)
602…Filled PTFE
603…Blue Gylon
604…PTFE
606…PTFE
608…Conductive PTFE
610…PTFE Encapsulated Silicon
611…PTFE Encapsulated Viton
Delrin, Viton and Hytrel are registered tradenames of E.I.
DuPont.
Gylon is a registered tradename of Garlock. Inc.
Nylatron is a registered tradename of Polymer Corp.
Rulon II is a registered tradename of Dixion Industries
Corporation.
Hastelloy-C is a registered tradename of Cabot Corp.
Ryton is a registered tradename of Phillips Chemical
Company.
Valox is a registered tradename of General Electric
Company.
Rupplon, SANDPIPER, PortaPump, Tranquilizer, and
SludgeMaster are registered tradenames of Warren
Rupp Inc.

hdf2dl5sm-REV0208 Model HDF2-A Page 9 Rev B
©2006 Warren Rupp, Inc. All rights reserved.
® Warren Rupp, SANDPIPER is a registered tradename of Warren Rupp, Inc.
Printed in U.S.A.


A= Available as Kit # 475-102-000
B= Available as Kit # 475-101-000 (SA2 Only)
(Parts Included on TSA2)
