Sangean MMR-77 User manual

B
L
MMR-77
User Manual

Controls
AM/FMband switch
Emergency buzzer
Dynamopower
AM/FMband indicator
Tuning LEDindicator
Charging LEDindicator
Illumination button
Dialscale
Dialpointer
Illumination lamp
Rotarytuning
Powerand volumecontrol
Hand strap holder
Earphone socket
DC jack forACpoweradaptor
Battery/Dynamoswitch
Batterycompartment
Telescopicantenna
1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18

PowerSupply
1.Batteryoperation
a.Open the batterycompartmentbypressing the marking
and opening the lid.
b.Takeoutthe used batteriesbypulling the firstone with
yourindexfinger.Then takeoutthe second battery.
c.When inserting the newbatteries(2x1.5V,type UM-3,
AA orLR6),observethe correctpolarity.
Note:
Takeoutthe batterieswhen you knowthatthe devicewon’t
be used foralong period oftime.The manufactureraccepts
no liabilityfordamage fromused batteries.
Environmentalnote:
Batteries,including thosewhichcontainno heavy metal,
maynotbe disposed ofwithhouseholdwaste.
Pleasedisposeofused batteriesinaenvironmentally
sound manner.Find outaboutthe legalregulationswhich
applyinyourarea.
2.Mainsoperation (with3V/200mAmainspoweradaptor,
centralpositiveinpolarity)
a.plug the mainspoweradaptor(notsupplied)intothe
DC jack socket(2.5mm indiameter) on the left of
the device.
b.The batteriesinthe compartmentareswitched off.
Note:
you can’tcharge the standardbatteryorrechargeablebattery
viaMainsoperation.2
GB

3.Dynamopower
Note:
You can charge the radioviaDynamopowereitherthe battery
switchinbatteryordynamoposition.The Dynamocharging
istothe built-indynamobatterynotthe batteryinthe battery
compartment.
a.takeoutDynamopowerhandlefromitrestposition.
b.rotarytheDynamohandlearound 120 circlesper
minutespeed,eitherclock oranti-clock wiseuntil
the charging LEDindicatorison indicating charging
condition.
c.Undernormallistening condition,one minutecharging
can listen tothe radioforaround 30 minutes.
(AMband and using speaker).
d.Makesurethe handleinitsrestposition aftercharging
completed.
e.You can dynamocharge the radioeitherradioinitson
oroff position.
f. Makesurethe telescopicantenna tobe inrestposition
beforerotarythe dynamohandle.
Note:
When plugged inACpoweradaptorintoDC jack,the dynamo
charging won’tbe effective.
3

Note:
The built-inrechargeablebatteryforDynamopowerwill last
for300-500 timesofcharging,thereforeit’s suggested to
powerthe radiobystandardbatteryorACpoweradaptor
(notsupplied).
Radiooperation
1.Selectthe powertobe Battery(makesurethe batteries
areinand powerful)orDynamoposition byswitching
battery/dynamoswitch.
2.Switchon the radiobyturning the power/volumecontrol.
3.Selectrequired radioband (AMorFM).
4.ForFMreception ,pull outthe telescopicantenna and
rotaryituntil you receivethe bestsignal.ForAM,align the
antenna byturning the radioforbestreception and avoid
interferencefromcomputer,electronics devicesetc.
5.Adjustthe volumebyrotaryvolumecontrol.
Listening withearphones
Insertthe earphonesplug (3.5mm,stereo)intothe
earphonessocketon the left side ofthe device.
Thiswill automaticallyswitchesoff the loudspeakers.
4
GB

Conditionalwaterresistant
Thisradioisawaterresistantdevicenotawaterproofdevice,
thereforemakesurethe rubbercoveron earphonessocket
andDC jack areproperlysealed afterusage.
Illumination lamp
The radioequipswithaillumination lamp,itcan either
illuminatethe dialwindoworilluminateforshortdistance
wheneverisnecessary.Simplypress illumination button
toswitchon /off the illumination lampeitherradiopoweris
on oroff.
Emergency buzzer
Press the Emergency Buzzerbutton will sound the
emergency buzzertoletthe peopleknowthatit’s in
emergencystatusorsomething like“Iamhereand need
help“.Press the button againtoswitchoff the buzzer.
Note:
The Emergency buzzercan executeeitherradioisinon or
off position.
5

TechnicalData
PowerSupply:
Batteryoperation
Mainsoperation
Dynamooperation
Output
FrequencyCoverage
FM(VHF)87.50 -108 MHz
AM(MW)526.5-1710 kHz
Antenna
Telescopicantenna FM(VHF)
Ferriterod antennaAM(MW)
Socket
DC socket
2.5mm indiameter,3V200 mA,centerpinPositive.
Earphone jack
3.5mm indiameter,stereo,32 ohmImpedance
Dimensionsand weight
167mm x89mm x52mm (WxHxD)
250g
2x1.5V(type Mignon LR6/UM3/AA)
3V300mA,mainspoweradaptor,
centerPinPositiveinpolarity
built-in2AAA sizex1.2Vrechargeable
Battery
100mW
6
GB

7
If atanytimeinthe futureyou shouldneed todisposeof
thisproductpleasenotethat: Wasteelectricalproducts
shouldnotbe disposed ofwithhouseholdwaste.
Pleaserecyclewherefacilitiesexist. Check withyour
LocalAuthorityorretailerforrecycling advice.
(WasteElectricaland ElectronicEquipmentDirective)

8
Commandes
Sélecteurde bandeAM/FM
Sonneried’urgence
Alimentation Dynamo
Indicateurde bande AM/FM
Indicateurlumineuxde syntonisation
Indicateurlumineuxde charge
Bouton d’éclairage
Cadran gradué
Pointeurde syntonisation
Éclairage
Bouton rotatifde syntonisation
Commande de marche/arrêtetcontrôledu volume
Fixation pourdragonne
Priseécouteurs
PriseCC pouradaptateursecteur
SélecteurPiles/Dynamo
Compartimentàpiles
Antenne télescopique
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
F

Alimentation
1.Fonctionnementsurpiles
a.Ouvrezlecompartimentàpilesen appuyantsur
l’indication correspondanteeten tirantlecouvercle.
b.Enlevezlespilesusagéesen tirantlapremièreavec
votreindex.Retirezensuitelaseconde pile.
c.Pourleplacementde pilesneuves(2x1,5 V,type
UM-3,AA ou LR6),veillezàrespecterlespolarités.
Remarque:
Retirezlespilessivousne comptezpasutiliserl’appareil
pendantune longue période.Le fabricantdécline toute
responsabilitéen casde dégâtscausés pardespiles
usagées.
Remarqueconcernantl’environnement :
Lespiles,ycompriscellesquine contiennentpasde métaux
lourds,ne peuventpasêtremisesau rebutaveclesdéchets
ménagers.Veuillezvousdébarrasserdespilesusagéesd’une
manièrerespectueusepourl’environnement. Renseignez-vous
surlalégislation en vigueurdansvotrerégion.
9
