Sangean DDR-22 User manual

Please read this manual before use
AWORLDOF LISTENING
GB
Operating instruction
WARNING:
TO PREVENT FIRE OR ELECTRIC SHOCK HAZARD,DO
NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
THE LIGHTNING FLASH AND
ARROW- HEAD WITHIN THE
TRIANGLE IS AWARNING SIGN
ALERTING YOU OF
“DANGEROUS VOLTAGE”
INSIDE THE RADIO.
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
THE BACK, NO USER SERVICEABLE
PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
THE EXCLAMATION POINT
WITHIN THE TRIANGLE IS A
WARNING SIGN ALERTING
YOU OF IMPORTANT
INSTRUCTIONS ACCOMPANYING
THIS RADIO.
!
CAUTION
RISK OF ELECTRIC
SHOCK DO NOT OPEN
DDR-22
DAB+FM/RDS+MW
DIGITAL STEREO RECEIVER
DDR-22_381P101_GB.p65 2006/4/14, ¤U¤È 04:421

IMPORTANT SAFETY INSTRUCTIONS ........................... 2
Controls .......................................................................... 3-4
Remote control .................................................................. 5
Remote handset battery replacement .............................. 6
Mains operation ................................................................. 6
Time setting ...................................................................... 7
Alarm time setting ............................................................. 8
Alarm off time setting ....................................................... 9
Alarm Source .................................................................... 9
Alarm Volume.................................................................. 10
Alarm on and off .............................................................. 10
Sleep setting ................................................................... 11
Operation radio ................................................................ 12
Operating your radio – DAB ............................................ 12
Selecting a station – DAB .............................................. 13
Auto tuning ...................................................................... 14
Secondary services ......................................................... 14
Normal display mode....................................................... 15
Advanced display mode .................................................. 16
Station order – Service list order .................................... 17
Manual Tuning ................................................................. 18
DRC Value Control .......................................................... 19
Contents
Factory RESET ............................................................... 20
SW version ...................................................................... 20
Operating the radio – FM band ....................................... 21
Display modes – FM RDS .............................................. 22
Search RDS program type .............................................. 23
Operating the radio – MW band ..................................... 24
Presetting stations .......................................................... 24
DAB band Preset station................................................ 25
Recalling DAB preset station ......................................... 26
FM/MW waveband preset station ................................... 27
Recalling FM/MW waveband preset station ................... 27
Preset EQ........................................................................ 28
Operating the radio – Aux In ........................................... 29
Operating the radio – Line Out ....................................... 29
Headphone use ............................................................... 30
Flat/3D sound effect ....................................................... 30
Mute ................................................................................. 30
Specifications.................................................................. 31
1
DDR-22_381P101_GB.p65 2006/3/23, ¤W¤È 09:492

2
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with
the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including amplifiers)
that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades with one
wider than the other. A grounding type plug has two blades and a
third grounding prong. The wide blade or the third prong are
provided for your safety. If the provided plug does not fit into your
outlet. consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by
the manufacturer, or sold with the apparatus. When a cart is
used, use caution when moving the cart/apparatus combination
to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for
long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged. liquid has been
spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate
normally, or has been dropped.
15. To Reduce the Risk of Fire or Electric Shock, Do not Expose
This Appliance To Rain or Moisture.
16. The Shock Hazard Marking and Associated Graphical Symbol is
provided on the bottom panel of unit.
17. Apparatus shall not be exposed to dripping or splashing and no
objects filled with liquids, shall not be placed on the apparatus.
GB
DDR-22_381P101_GB.p65 2006/3/23, ¤W¤È 09:493

3
Controls
1. Infra red sensor
2. Standby indicator
3. Volume Control/Standby button
(Front)
1 2 3
DDR-22_381P101_GB.p65 2006/3/23, ¤W¤È 09:494

4
4. Telescopic aerial
5. AUX IN socket
6. LINE OUT socket
7. Headphone socket
8. 3D sound switch
9. Mains input socket
GB
4
5 6 7 8 9
Controls
(Rear)
DDR-22_381P101_GB.p65 2006/3/23, ¤W¤È 09:495

5
1. Standby button
2. Sleep button
3. Mode Selection
4. Audio Mute
5. Volume Control
6. Not applicable for non-CD version
7. Audio Equalizer (EQ)
8. Not applicable for non-CD version
9. Not applicable for non-CD version
10. Information /Preset Down button
11. Set Up button /Preset Up button
12. Auto Tune button /RDS Pty search
13. OK button/RDS Mode selection
14. Not applicable for non-CD version
15. Not applicable for non-CD version
16. Not applicable for non-CD version
17. Number keys
18. Preset Button
19. AM/FM band /Aux In Selection
20. DAB band button
21. Alarm button
22. Not applicable for non-CD version
Remote control
Note:
Remote control unit is designed to suit for CD and also non-CD version of radio. Some buttons will be useless for non-CD version.
MP3
DDR-22_381P101_GB.p65 2006/3/23, ¤W¤È 09:496

6
GB
Remote handset battery replacement
1. Release battery holder locker by pressing the holder up.
2. Pull out the battery holder.
3. Replace supplied battery (CR2025 or equivalent) ensuring that
positive side of battery faces you with holder positioned.
4. Replace the battery holder and make sure the holder locker is in
right position.
Mains operation
1. Place your radio on a flat surface.
2. Plug the mains lead into the socket located on the rear of your
radio, ensuring that the plug is pushed fully into the socket.
3. Plug the other end of the mains lead into a wall socket and switch
on the wall socket.
DDR-22_381P101_GB.p65 2006/3/23, ¤W¤È 09:497

7
Time setting
1. Turn on the radio by pressing standby button.
2. Press and release MODE button, display will flash 0:00.
3. Press and release Time Set button , display hour digit
will flash.
4. Press Tuning +/- button to select required hour then press Time Set
button again to confirm hour setting. Display minute digit will flash.
5. Press Tuning +/- button to select required minute then press
Time Set button again to finalize time setting.
Note:
The time can be auto adjusted by FM-RDS Auto clock set (CT)
but can’t be auto adjusted by DAB signal.
DDR-22_381P101_GB.p65 2006/3/23, ¤W¤È 09:498

8
GB
Alarm time setting
1. Press Mode button will cycle through Normal display, clock display,
alarm on display , Alarm off display, Alarm source, Alarm volume,
Sleep and normal display again.
2. During Alarm on display status, press Time Set button ,
display hour digit will flash.
3. Press Tuning +/- button to select required hour then press Time Set
button again to confirm hour setting. Display minute digit will flash.
4. Press Tuning +/- button to select required minute then press
Time Set button again to finalize alarm time setting.
5. The alarm will last for one hour until you switch it off by pressing
Standby button.
DDR-22_381P101_GB.p65 2006/3/23, ¤W¤È 09:499

9
Alarm off time setting
Follow above alarm on time setting to set alarm off time.
Alarm Source
1. Pressing Mode button to select Alarm Source mode.
2. Press Adj. button, display will flash last alarm source set.
3. Press Tuning + /- button to select required alarm source.
DDR-22_381P101_GB.p65 2006/3/23, ¤W¤È 09:4910

10
GB
Alarm Volume
1. Pressing Mode button to select Alarm Volume mode.
2. Press Adj. Button, display will flash last alarm volume set.
3. Press Tuning +/- button to select required alarm volume.
Alarm on and off
1. Press ALARM button will toggle the alarm timer enable or disable.
2. Display will show when alarm timer is set after radio is
switched off.
DDR-22_381P101_GB.p65 2006/3/23, ¤W¤È 09:4911

11
Sleep setting
1. Press and release Sleep button to select required radio auto
off time.
2. Release Sleep button when required sleep time is reached.
3.To check remaining Sleep timer time. Press and release Mode
button to select Sleep mode.
DDR-22_381P101_GB.p65 2006/3/23, ¤W¤È 09:4912

12
GB
Operation radio
Note:
other than the volume control and standby on/off. All the operation of
this receiver is via supplied remote control unit.
Operating your radio – DAB
1. Fully extend the telescopic aerial.
2. Press the Standby button to switch on your radio then press DAB.
Display will show “Welcome to Digital Radio“ for a few seconds.
3. If this is the first time the radio is used, a quick scan of DAB
channels will be carried out. The display will show “scanning“.
If the radio has been used before, the last used station will
be selected.
4. During the scanning, as each group of stations is detected,
the bottom line of the display will show the stations count.
The top line of the display shows a bar graph indicating progress
of the Scanning .
5. When the Scanning is completed, the first station will be selected.
6. If the station list is still empty after Scanning, your radio will display
“Station not available“.
7. If no signals are found, it may be necessary to relocate your radio
to the position giving better reception.
DDR-22_381P101_GB.p65 2006/3/23, ¤W¤È 09:4913

13
Selecting a station – DAB
1. The top line of the display shows the name of the station
currently selected.
2. Press the Tuning + or Tuning – button to scroll through the list of
available stations. Stop pressing the Tuning buttons when you find
the station you wish to hear.
3. Press OK to select the station. The display may show
“Now tuning ….” While your radio finds the new station.
4. Adjust the Volume control and 3D sound switch to the
required setting.
Note:
If after selecting a station, the display continues to show
“Station not available“, it may be necessary to relocate your radio
to a position giving better reception.
DDR-22_381P101_GB.p65 2006/3/23, ¤W¤È 09:4914

14
GB
Auto tuning
As time passes, new station may become available.
To find new stations, proceed as follows:
a. Press and release Auto Tune button, display will show “Scanning“.
Your radio will perform a scan of the DAB channels. As new
stations are found, the station counter on the right-hand side of the
display will increase and stations will be added to the list.
b. To carry out a full scan of the entire DAB band, press and hold
down the Auto Tune button for more than 2 seconds until display
shows “Scanning“. As new stations are found, the station counter
on the right-hand side of the display will increase and stations will
be added to the list.
Secondary services
Certain radio stations have one or more secondary services
associated with them. If a station has a secondary services
associated with it, the display will show “ “ next to the station
name on the station list. The secondary service will then appear
immediately after the primary service as press and release Tuning +/-.
DDR-22_381P101_GB.p65 2006/3/23, ¤W¤È 09:4915

15
Normal display mode
Your radio have several display modes. Press the INFO button to
cycle through the various modes.
a. Scrolling text
b. Program type
c. Multiplex name
d. Time and date
e. channel frequency
f . Audio type and bit rate
g. Signal strength
Displays scrolling text messages,
such as artist/track name,
phone in number, etc.
Displays type of station being listened to
e.g. Pop, Classic, News etc.
Displays names of multiplex to which
current station belongs.
Display signal strength for station being
listened to.
DDR-22_381P101_GB.p65 2006/3/23, ¤W¤È 09:4916

16
GB
Advanced display mode
a. Press and release SETUP button to view technical information
on the currently selected services and select lower level menu
options to configure the DAB receiver.
b. Press Tune +/- button to scroll through the options:
Station order Manual tune DRC value Factory reset
Sw version Station order ……. .
c. Press OK to confirm the option.
DDR-22_381P101_GB.p65 2006/3/23, ¤W¤È 09:4917

17
Station order – Service list order
1. In Station order mode, the user will be presented with a menu.
The top line will contain currently selected service list order.
The bottom line will contain the selected service mode with
scrolling indicators.
2. During Station Order mode, press OK button and press Tuning +/-
buttons to scroll through the options:
Favorite Station Alphanumeric Active station
Prune Stations Favorite Station………
3. Press OK button, will see a list of stations. Press OK button to
select required stations.
DDR-22_381P101_GB.p65 2006/3/23, ¤W¤È 09:4918

18
GB
Manual Tuning
1. In the Manual Tuning mode, press OK then tuning +/- button to
scroll through the band III options:
5A 174.92 MHz 5B 176.64 MHz 13E 237.48 MHz
13F 239.20 MHz 5A 174.92 MHz.
2. Press OK button to select the stations.
3. The first line to indicate signal strength.
DDR-22_381P101_GB.p65 2006/3/23, ¤W¤È 09:4919

19
DRC Value Control
1. In DRC value mode, the user will be presented with a menu.
The top line will contain the currently selected DRC value.
The bottom line will contain the first value in the list,
with scrolling indicators.
2. Press OK then Tuning +/- buttons to scroll through the option
DRC 0 DRC 1/2 DRC1 DRC 0 …….
3. Press OK to confirm the selection.
Note:
DRC ( Dynamic Range Control ) can make quieter sounds easier to
hear when your radio is used in a noisy environment.
DRC 0 DRC is switched off, Broadcast DRC will be ignored.
DRC 1/2 DRC level is set to 1/2 that sent by broadcaster.
DRC 1 DRC is set as sent by broadcaster.
DDR-22_381P101_GB.p65 2006/3/23, ¤W¤È 09:4920
