Saniclass SW 492793 User manual

[3]L shape screw 3pcs
1
3
4. 0mm
6m m
2
[1] Hanging mirror 1pc [2] Wall plugs 3pcs
Tools required
Mirror diagram
Please read this instruction carefully,in order to familiar with the
required tools,materials and installation procedures. Please comply
with the applicable sections to install product, to avoid unnecessary
loss, in addition to relevant correct installation method, please also
read all operating and safety instructions.
All informations provided by the guidelines are based on the latest
situation of product,we reserves the right to change the product c
haracteristics,packaging or supply situation, without prior notice.
The guidelines are including mentenance,clean informations.
WARNING:There may be hidden danger to people or product during
installing.Please wear protective equipment when installation.
WARNING:Do not use any acidic or alkaline cleanser,alcohol on it.
Please clean with wet soft cloth.
IMPORTANCE:This product is a one-way hanging mirror Pl ease
make sure that there is not obstacles(just like electrical cable/
water pipe) inside the wall before installation.
Please read these instructions carefully before installation.
Installation should be carried out by a qualified electrician.
ENSURE THAT CONNECTIONS ARE TURNED OFF AT THE CONSUMER
UNIT OR FUSE BOARD BEFORE INSTALLING OR CARRYING OUT ANY
MAINTENANCE.
THIS PRODUCT IS FOR IN DOOR USE ONLY.
WARNING: Risk of electrical shock ，pleae replace wires.
Process reference Parts listing
1
400*50mm
SW
492799
SW
492793
600*50mm
SW
SW
492801
492802
SW
492794
800*50mm
SW
SW
492803
492804
SW
209334
1000*50mm
SW
SW
492805
492806
SW
209335
SW
492800

2
STEP1
STEP2
Installation Steps
L
L/2
L
L/2
12m m
Specific height depends on site conditions
400:290 600:440 800:640 1000:640
