Sanipex BAGNODESIGN BDM-ZEP-410 Series User manual

BDM-ZEP-410-XX
ZEPHYR CONCEALED SHOWER MIXER
www.sanipexgroup.com

IMPORT ANT PLEASE READ


            

         

         

 
           

   




         










 of 

Concealed Shower Mixer
Install the mixer housing at a depth so that the finished surface is no further than
the maximum distance marking shown in the diagram.
Connect the Hot and Cold water supplies to the mixer, then install the mixed
water supply, cap off and pressure test to prevent any future leakages

Cleaning All surface should be cleaned using a clean damp cloth. No abrasive
cleaning agents or materials should be used.
Once the surrounding finishes have been applied (Tiles/Marble etc.) remove the
protection covers. Fit the face plate onto the mixer body, it is advised to use a
small amount of lubricant on the rubber seals. Slide the handle onto the cartridge
pin and secure with the grub screw, then push on the cover cap.
Open the water supplies and re-test for leaks.
• Before making any inlet pipe connections, all supply pipes MUST be thoroughly
flushed to remove debris. Failure to do this could result in damage to the
cartridge and components or low flow from the mixer'
