Sanipex BAGNO DESIGN BDA-MLI-V002 Series User manual

BDA-MLI-V002-XX
M-LINE VERTICAL HEATED TOWEL RAIL
www.sanipexgroup.com

IMPORTANT PLEASE READ
 B 
 

 






 L  C 



 x 
           
          
 








 









The following manual has been elaborated in order to supply all the useful
information for a correct installation together with the precautions to adopt both
from installer and users. Manufacturer declines every responsibility in case of
different uses from these instructions.
The heated towel rails is connected to the mains with a z type connection, and
consequently it cannot be substituted in any case of damage. Such an action would
make the item dangerous and free the producer from every responsibility.
ATTENTION :This item can be only used as holder for towels and similar garments.
This item, in normal use, cannot be loaded with more than 5 Kg. weight.
Please, only use provided screws and dowels or replace them with other ones
equivalent or greater in mechanical characteristics.
PROTECTION DEGREE: Squirts resistant IPX4.
PACKING CONTENTS : (see image 1)
(2) Confection screw with dowel for flanges
(3) Sliding cups
(1) Confection screw with dowel for flange per BOX
(1) Flange for switch BOX
(1) Screw for flange fixing BOX M6 X 6
(1) Instruction & Operation Manual
Raw material : Brass, Operation: Electrical
INSTALLATION: (see design 2)
Take out the heated towel rail and its components from the package.
To mount the heated towel rails, insert the sliding caps in the wall brackets to slide,
then rotate the switch box and let it coincide with the mains output from the wall;
Consequently to mark their position and make the holes in correspondence of the
flanges.
Fix the two flanges and the flange for switch box bracket to the wall by the proper
screws.
Fix the wall brackets and the wall holder at the opposite side of the wall switch
box. Rotate the item and approach it to the wall to connect the electrical whirls
coming out from the wall to the cables exiting from the switch box and then fix
the other two wall brackets. Only after finishing this action, you can turn the
power on and verify the heated towel rails works correctly.
Our Company refuses any responsibility in the case the assembly doesn’t respect
the above mentioned instruction.
WARNING:
Whether a leakage of antifreeze liquid occurs from our electrical towel heaters,
take care not to permit any contact with eyes and skin and avoid inhalation or
ingestion

WARNING: DO NOT get rid of this item as urban waste,
but swallow it separately or by properly equipped institutes.
IMPORTANT:
THE ELECTRICAL CONNECTION BETWEEN ITEM AND MAINS MUST BE
EXECUTED BY QUALIFIED STAFF AND AFTER TURNING OFF ELECTRICITY AT
THE MAIN PANEL.
616/B/L
1)
616/B/S 516
2)

Standard CEI / Zone of Installation
Only if shielded by a safety switch I△N < mA
ZONE
1
2
3
4
NON
NON
YES
YES
NON
NON
NON
YES
Socket

Note:

INA-MLI-V002-XX-11-23
www.sanipexgroup.com
