Saniwise F8 User manual

Tips
Bidet Seat F8 User Manual
Please read the user manual and check all the accessories before installation.
During the warranty period, free repair service will be provided for any product
issues or failures occurred under the instructions described in the User Manual.
Please contact with us on Saniwise’s Facebook page if you have any questions.
Saniwise

Thank you for purchasing Saniwise Bidet Seat. Please read through this manual
carefully to ensure the safe use of your product.
Keep this manual in a safe place for your future reference.
Contents
1
1
2
3
3
3
4
5
7
7
7
7
8
9
10
11
12
Parts and What’s in the Box
Parts
What’s in the Box
Self-diagnosis and Troubleshooting
Cleaning and Dismantling
Maintenance
Warranty Record
Saniwise Warranty
6
Extra Installation Tips
Installation
Caution
Preparation
Installation Procedures
Connecting Water Inlet Hose
Functions
WASH (REAR WASH)
BIDET (FRONT WASH)
STOP

Water inlet on the left
Parts
Bowl
Water inlet hose
Shutoff valve
T-shaped adapter
Lever
Water tank
Water supply hose
Seat cover
Seat
Wash nozzle
Bidet nozzle
Dismantle button
Parts and What’s in the Box
1

1. Bidet seat and lid 2. Installation template
Connecting bolts x2
Sliding plates x2
4. T-shaped connector 5. Water inlet hose 6. User Manual
User Manual
3. Fixing components
Expansion nuts x2
Filter
Note
There are two methods to install the Saniwise Bidet Seat. It is recommended that you use expansion
nuts. You can also use butterfly nuts. Please choose the appropriate installation method according
to your specific installation needs.
Nuts x2
Adapter plate x1
2
What’s in the Box

1
1. The water pressure limit ranges from 10 to 110 PSI. Please use as instructed.
2. The water shutoff valve should be near where the product can be installed and dismantled.
Please read the following instructions carefully and install your Saniwise Bidet Seat
properly.
Preparation
1. Insert the connecting bolts into the sliding plates.
Insert the connecting bolts into the holes of the sliding plates, as shown in the figure below.
2. Insert the connecting bolts with the sliding plates into the adapter plate.
Insert the connecting bolts with the sliding plates into the holes of the adapter
plate, as shown in the figure below.
Caution

2Installation Procedures
Installation Method One (Recommended)
1. Dismantle the old bidet seat and lid.
Loosen the hinge and remove the old bidet seat and lid.
Keep this side with FRONT up
Installation
template *Butterfly nuts are only used for
the optional installation method two.
Installation template
Installation template
Installation Method Two
1. Dismantle the old bidet seat and lid, and place the installation template on the ceramic, as described in step 1 and step 3 of the
installation method one.
2. Put the adapter plate over the toilet seat’s mounting holes in the ceramic of the connecting bolts with adjusting pieces. Screw the nuts
from underneath the toilet. Then tighten them to secure the adapter plate. Refer to the step 4 of the installation method one.
3. Complete the following installation procedures, as described in step 5 and step 6 of the installation method one.
2. Install the expansion nuts.
Insert the expansion nuts into the holes of the ceramic. Be
sure to firmly press down so the top of the expansion nut is
flush with the ceramic toilet surface.
3. Install the installation template. 4. Fix the adaptable panel.
Attach the adapter plate. Attach the adapter plate in the toilet
seat holes. Adjust the connecting bolts’ and adjusting pieces’
position to line up the connecting bolts to the expansion nuts.
Then tighten them to secure the adapter plate.
5. Remove the installation template. 6. Mount the Saniwise Bidet Seat.
Keep the fixing slots under the Saniwise Bidet Seat aiming
at the slots on the adaptable panel. Push the Saniwise Bidet
Seat to the end. Now, the Saniwise Bidet Seat is installed
successfully.
Fixing slots under the
Saniwise Bidet Seat
Bidet seat and lid
Place the installation template on the ceramic.

1. Turn off the water supply valve. 2. Unscrew the water supply hose from the water
tank. Place a towel below the tank to catch any
dripping water.
3. Using finger nut, attach the T-shaped connector
to the water tank where you removed the water
supply hose.
4. Attach the water supply hose to the bottom of
the T-shaped connector.
5. If they have become loose during shipping,
press the filter screen and rubber washer into
the connectors at the ends of the white water
inlet hose. Connect the white water inlet hose to
the bidet seat and the other end to the T-shaped
connector and tighten snugly. Do not over
tighten.
6. Slowly turn on the water valve to check if
there is any water leakage.
Unscrew to remove
Finger nut
Washer
Filter
Connecting Water Inlet Hose

6
13
2
Please remove the regulator cover and regulator O-ring under the following conditions:
Caution: Must use the regulator cover and regulator O-ring when the water pressure
is greater than 15 PSI.
How to do:
1. Take out the regulator with pliers and other tools.
2. Remove the regulator cover and regulator O-ring except the sealing O-ring.
3. Insert the regulator component into the inlet pipe.
a. When the water pressure is lower than 10 PSI.
b. When the nozzle cannot work normally and water pressure is low.
Regulator
Regulator
cover
Regulator
O-ring
Sealing
O-ring
7. Wipe the hoses and connectors thoroughly with a towel and carefully observe for any leaks for at least
10 minutes. Tighten any connectors gently until leakage stops. If any leaks continue, turn off the water
supply and check older hoses for damaged rubber O-rings and replace them if necessary.
*Optional, only do the following if water pressure is too low.
Warning
1. Do not lift the product with the seat cover and seat open.
This may damage the bidet seat.
2. Do not use with hot water where temperature is higher
than 40 /104 .
1. This will not apply to most customers, however, if you happen to have a rigid water
supply line to your toilet tank you will need to replace that with a flexible steel braided
water supply hose which can be found at any hardware store, Home Depot, Lowe's etc.
The addition of the "T" connector will make an existing "rigid" hose too long. We
recommend you purchase the same length flexible hose as your rigid line +/- an inch.
It does not need to be exact because it's flexible, but too long may look unattractive.
2. There is a white rubber hose that is sealed in a plastic bag. Occasionally the rubber
gasket will fall out of the hose end during shipping. Just make sure you put it back in
place if yours fell out, or if you find it loose in the bag with the hose.
3. If you are not using the nuts, be sure to firmly push the two adapter plate anchors all
the way into the two holes on your toilet bowl to ensure the adapter plate fits tightly to
your toilet after tightening the stainless steel screws.
3Extra Installation Tips

7
4. In most cases everyone is happy with the pressure that the cleaning jets put out. If for
any reason you would like a stronger stream, please refer to page 6 in the instructions
and it will explain how to remove the pressure regulator and dramatically increase the
pressure.
If you still need help, feel free to send us an email at [email protected].
Functions
STOP
1) During WASH or BIDET status, rotate the lever to the vertical
position to stop the freshwater spray.
2) The nozzle moves back to the original position.
3) The water volume decreases while turning the lever towards the vertical
position. It will totally shut off when the lever is on the vertical position.
WASH (REAR WASH)
1) Turn the lever clockwise from the vertical position.
2) The nozzle for rear wash extends forward, and the freshwater spray
function starts.
3) The water volume decreases while turning the lever towards the vertical
position. It will totally shut off when the lever is on the vertical position.
1) Turn the lever counterclockwise from the vertical position.
2) The nozzle for feminine Bidet (front wash) moves forward and the
freshwater spray function starts.
3) The water volume decreases while turning the lever towards the vertical
position. It will totally shut off when the lever is on the vertical position.
Note that the front wash nozzle is slightly longer when fully extended and
directs spray more in the forward direction.
BIDET (FRONT WASH)

Cleaning and Dismantling
1. Clean the exterior of the bidet seat.
2. Clean the spray nozzles.
Pull out the nozzle softly and use smooth
cloth/sponge or toothbrush with liquid dish
soap to clean the nozzle.
Close the cover. Push the dismantle button
and pull the Saniwise Bidet Seat forward,
as shown in the figure below.
4. Dismantle the Saniwise Bidet Seat.
Use a smooth sponge/cloth with diluted
dish detergent to clean the product. Do not
use the following types: hydrogen chloride
detergent, paint thinner, benzene, abrasive
paper, polishing agent, bleach, or chlorine.
Insecticide
Abrasive paper
Paining thinner
Then pull the bidet seat
forward while pressing the
dismantle button.
Close the cover first
Filter
Braided hose
(If the water flow is less than usual)
1) Turn off the water supply, remove the
white water inlet hose, and clean the
filter screen.
2) Remove the regulator with a pair of
pliers, remove the regulator cover, and
clean the regulator O-ring.
Regulator
3. Clean the filter and regulator.
8
5

9
Maintenance
6
1) Remove the old lever as shown in figure A.
2) Insert the new lever rib into the
corresponding slot. When the new lever is
mounted properly, a click will be heard.
1) Pull out the tube and hold it, then remove
the old nozzle, as shown in figure A.
2) Mount the new nozzle to the corresponding
slot on the tube. Now, the nozzle is
replaced successfully.
If water leaks from either end of the water
hose, tighten the nuts gently until the water
inlet hose stops leaking.
1) Rotate the lever forward. Remove the
regulator from the water inlet with the
needle-nose pliers.
2) Press the new regulator into the water
inlet tube.
3) Rotate the lever to the vertical position.
Now, the regulator replacement is
completed.
Regulator
1. Lever Replacement 2. Nozzle Replacement
3. Regulator Replacement 4. Repairing a Leaking Water Hose
AB
Nozzle
ABC

10
0.35 - 1.8 L/min
0.35 - 1.8 L/min
Issue Cause Solution
The water pressure is low
when using WASH/BIDET.
The bidet seat’s water pressure is low.
The pressure of the water supply is low.
Turn the lever forward or backward to the highest setting during use.
If the pressure of the water supply is too low, please contact your
local water department.
No water comes out
when using WASH/BIDET.
The shutoff valve is turned off. Turn on the shutoff valve.
The T-shaped connector’s filter is stuck. Clean the T-shaped connector’s filter.
The water inlet hose’s filter is stuck. Clean the water inlet hose’s filter.
The nozzle head is stuck. Remove the nozzle head and clean it.
The pressure of the water supply is too low. Increase the pressure of the water supply.
The toilet bowl is leaking
during usage.
The maximum water pressure of the Saniwise Bidet Seat is 110 PSI.
If the pressure of the water supply is higher than that, please contact
your local water department.
The pressure of the water supply is too
high.
If the failure still occurs after the solutions above have been taken, please contact Saniwise by
sending an email to [email protected].
FB108
Model No.
Check valve and vacuum breaker
Water Supply Directly from water pipes
Water Pressure Range
Dimensions
Weight
Caution
Do not disassemble, repair, or remodel the Saniwise Bidet Seat.
Self-diagnosis and Troubleshooting
Water Flow (WASH)
Water Flow (BIDET)
Backflow Prevention
Specifications
2.09 kg
370x480x62 mm
10-110 PSI
7Self-diagnosis and Specifications

Dear customer,
Thank you for choosing Saniwise. If any failure or issue occurs, please
check your Saniwise Bidet Seat following the troubleshooting methods in
this manual first. If the failure or issue cannot be fixed, please follow the
return instructions on the next page.
Warranty Record
A. Related Information
B. Notes
1. Please make sure the above information is completed before
requesting the warranty service.
2. This Warranty Record and User Manual are important documents
for product maintenance. Please keep them in a safe place.
3. During the warranty period, if any product issue or failure occurs
under normal condition following the User Manual, free repair
will be provided. See the following page for complete warranty
details and return instructions.
4. Thank you for choosing Saniwise. We are pleased to share with
you that you can extend your bidet seat's warranty by one year
(which is equivalent of $35) for free after registering on
www.saniwise.com within 2 weeks of receiving the product.
Name:
Tel:
Address:
Model No.:
Date of Purchase:
Warranty Period:

Web: www.saniwise.com
Saniwise Warranty
Return Policy: A Saniwise Bidet Seat which has been installed or used is non-refundable due to
governmental regulations pertaining to personal hygiene products. Saniwise cannot accept
product returns if the installation hardware kit has been opened or if other signs of use are
detected.
How to obtain service:
To obtain repair service under this warranty, you must contact us to obtain an RMA
(Return Merchandise Authorization) number.
Proof of purchase in the form of a copy of your original receipt must accompany the returned
unit for the warranty to be valid.
To obtain your RMA number and to receive return instructions or to speak with a customer
service representative.
1. Loss of or damage to Saniwise Bidet Seat due to abuse, misuse, tampering, mishandling,
improper packaging by you, alteration, modification and not following operation instructions.
No implied warranty, including any implied warranty of merchantability or fitness for a particular
purpose applies to the Saniwise Bidet Seat after the applicable period of the expressed
warranty or guarantee stated above, and no other express warranty or guarantee, except as
mentioned above, given by any person or entity with respect to Saniwise Bidet Seat shall bind
Saniwise, (some states and provinces do not allow limitation on how long an implied warranty
applies, so the above limitations or exclusions may not apply to you if prohibited by law,)
Saniwise shall not be liable for revenues or profits, inconvenience, expense, for substitute
equipment or service, or any other special, incidental or consequential damages. In no event
shall any claim or recovery of any kind against Saniwise be greater in amount than the purchase
price of the product causing the alleged damage. Without limiting the foregoing, you assume all
risk and liability for loss, damage or injury to you and your property and to others and their
property arising out of use or misuse of, or inability to use, the Saniwise Bidet Seat not caused
directly by the negligence of Saniwise. This limited warranty shall not extend to anyone other
than the original purchaser of the Saniwise Bidet Seat.
This limited warranty given by Saniwise covers all defects encountered in normal use of
Saniwise Bidet Seat and does not apply in the following situations.
Your Saniwise Bidet Seat is warranted against defects in materials or workmanship for one (1)
year from the date of original purchase. A defective product or defective parts returned to
Saniwise will be repaired or exchanged for a Refurbished Saniwise Bidet Seat as determined
by Saniwise in their sole discretion. Saniwise will not charge for labor or parts in connection
with warranty repairs or replacements. Saniwise is not responsible for the cost of removal,
return and/or re-installation of products.
2. Use of unauthorized or incorrect parts or supplies sourced from anywhere other than
Saniwise authorized dealers or parts that cause damage to the Saniwise Bidet Seat.
3. Replacement of discolored or stained parts caused by use of chlorine, bleach, ammonia,
and other chemicals, or abrasive cleaning supplies, oxidation or normal wear and tear.
4. Damage to or malfunction of the Saniwise Bidet Seat as a result of improper and negligent
installation.
5. Damage or loss resulting from sediments or foreign matter contained in a water system.
6. Any and all damages to plumbing, walls, floors, ceiling, and personal properties resulting
from water leaks or breakage. The product must be used at the user’s own risk. Therefore,
the owner hereby releases the manufacturer and distributor from any and all claims for
damages where the above conditions exist.
