Sansui HDLCD3200B User manual

32" WIDE TFT LCD TELEVISION
WITH DIGITAL TUNER
HDLCD3200B
OWNER’S MANUAL
Before operating the unit, please read this manual thoroughly.
ATTENTION
If you purchase a universal remote control from your local retailer, please contact the remote manufac-
turer for the required programming code.
IF CONTACT WITH CUSTOMER SERVICE IS REQUIRED
PLEASE HAVE THE MODEL NUMBER READY PRIOR TO THE CALL
CUSTOMER SERVICE – 1-800-289-0980
ORION WEBSITE
FOR INFORMATION ON OUR OTHER PRODUCTS, PLEASE VISIT OUR WEBSITE AT
www.orionsalesinc.com
Air/Cable MODE SELECTION
When shipped from the factory, the Tuning Band menu option is set to the “Cable” (Cable Television)
mode. If not using Cable TV, set this menu option to the “Air” position.
34K0101A_eng.indd 134K0101A_eng.indd 1 8/31/2007 4:20:56 PM8/31/2007 4:20:56 PM

2
Location of the required Marking
The rating sheet and the safety caution are
on the rear of the unit.
The lightning flash with arrowhead
symbol, within an equilateral triangle
is intended to alert the user to the
presence of uninsulated dangerous
voltage within the product's enclosure
that may be of sufficient magnitude to
constitute a risk of electric shock.
The exclamation point within an
equilateral triangle is intended to
alert the user to the presence of
important operating and maintenance
(servicing) instructions in the literature
accompanying the appliance.
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
WARNING: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules.These limits are designed to provide reasonable protection
against harmful interference in a residential installation.This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
CAUTION: Changes or modifications not expressly approved by the party responsible for compliance with the
FCC Rules could void the user's authority to operate this equipment.
WARNING:TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN
OR MOISTURE.
CAUTION: TO PREVENT ELECTRIC SHOCK DO NOT USE THIS POLARIZED PLUG WITH AN
EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE
FULLY INSERTED TO PREVENT BLADE EXPOSURE.
The lamp(s) within this product contain mercury.
Disposal should be in compliance with local, state or
federal laws.
34K0101A_eng.indd 234K0101A_eng.indd 2 8/31/2007 4:20:57 PM8/31/2007 4:20:57 PM

3
IMPORTANT SAFETY INSTRUCTIONS
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with a clean dry cloth.
7) Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has two blades and a third grounding prong.The
wide blade and the third prong are provided for your safety. If the provided plug does not fit into your outlet,
consult an electrician to replace the obsolete receptacle.
10) Protect the power cord from being walked on or pinched particularly at plug, and the point where it exits
from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the
apparatus.When a cart is used, use caution when moving the cart/apparatus combination to avoid injury
from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long periods of
time.
14) Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug
damage, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or
has been dropped.
15) Apparatus should not be exposed to dripping or splashing, and objects filled with liquids, such a vases,
should not be placed on the apparatus.
16) An outside antenna system should not be located in the vicinity of overhead power lines or other electric
light or power circuits, or where it can fall into such power lines or circuits.When installing an outside
antenna system, extreme care should be taken to keep from touching such power lines or circuits, as
contact with them might be fatal.
17) Do not overload wall outlets and extension cords, as this can result in a risk of fire or electric shock.
18) Do not push objects through any openings in this unit, as they may touch dangerous voltage points or short
out parts that could result in fire or electric shock. Never spill or spray any type of liquid into the unit.
S3126A
PORTABLE CART WARNING
(symbol provided by RETAC)
34K0101A_eng.indd 334K0101A_eng.indd 3 8/31/2007 4:20:57 PM8/31/2007 4:20:57 PM

4
IMPORTANT SAFETY INSTRUCTIONS
19) If an outside antenna or cable system is connected to the unit, be sure the antenna or cable system is
grounded to provide some protection against voltage surges and built-up static charges, Section 810 of
the National Electrical Code, ANSI/NFPA 70, provides information with respect to proper grounding of the
mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding
conductors, location of antenna discharge unit, connection to grounding electrodes, and requirements for
the grounding electrode.
EXAMPLE OF ANTENNA GROUNDING AS PER THE
NATIONAL ELECTRICAL CODE
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
ANTENNA LEAD
IN WIRE
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
GROUND
CLAMP
ELECTRIC SERVICE
EQUIPMENT
NEC-NATIONAL ELECTRICAL CODE
S2898A
20) When replacement parts are required, be sure the service technician uses replacement parts specified by
the manufacturer or those that have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock or other hazards.
21) Upon completion of any service or repairs to this unit, ask the service technician to perform safety checks to
determine that the unit is in proper operating condition.
22) When you connect the product to other equipment, turn off the power and unplug all of the equipment from
the wall outlet. Failure to do so may cause an electric shock and serious personal injury. Read the owner's
manual of the other equipment carefully and follow the instructions when making any connections.
23) Reduce the volume to the minimum level before you turn on the product. Otherwise, sudden high volume
sound may cause hearing or speaker damage.
24) Do not allow the product to output distorted sound for an extended period of time. It may cause speaker
overheating and fire.
25) This reminder is provided to call the cable TV system installer’s attention to Article 820-40 of the NEC
that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be
connected to the grounding system of the building, as close to the point of cable entry as practical.
34K0101A_eng.indd 434K0101A_eng.indd 4 8/31/2007 4:20:57 PM8/31/2007 4:20:57 PM

5
10cm
IMPORTANT SAFETY INSTRUCTIONS
CONDENSATION
Moisture will form in the operating section of the player if the player is brought from cool surroundings into a
warm room or if the temperature of the room rises suddenly. When this happens, player's performance will be
impaired.To prevent this, let the player stand in its new surroundings for about an hour before switching it on, or
make sure that the room temperature rises gradually.
Condensation may also form during the summer if the player is exposed to the breeze from an air conditioner. In
such cases, change the location of the player.
HOW TO HANDLE THE LCD PANEL
Do not press hard or jolt the LCD panel. It may cause the LCD panel glass to break and injury may occur.
If the LCD panel is broken, make absolutely sure that you do not touch the liquid in the panel.This may cause
skin inflammation.
If the liquid gets in your mouth, immediately gargle and consult with your doctor. Also, if the liquid gets in your
eyes or touches your skin, consult with your doctor after rinsing for at least 15 minutes or longer in clean water.
Possible Adverse Effects on LCD Panel: If a fixed (non-moving) pattern remains on the LCD Panel for
long periods of time, the image can become permanently engrained in the LCD Panel and cause subtle but
permanent ghost images.This type of damage is NOT COVERED BYYOUR WARRANTY. Never leave your
LCD Panel on for long periods of time while it is displaying the following formats or images:
Fixed Images, such as stock tickers, video game patterns, TV station logos, and websites.
Special Formats that do not use the entire screen. For example, viewing letterbox style (16:9) media on
a normal (4:3) display (black bars at top and bottom of screen); or viewing normal style (4:3) media on a
widescreen (16:9) display (black bars on left and right sides of screen).
The following symptoms are not signs of malfunction but technical limitation. Therefore we disclaim any
responsibility for these symptoms.
LCD Panels are manufactured using an extremely high level of precision technology, however sometimes
parts of the screen may be missing picture elements or have luminous spots.
This is not a sign of a malfunction.
Do not install the LCD Panel near electronic equipment that is susceptible to electromagnetic waves. Some
equipment placed too near this unit may cause interference.
Effect on infrared devices – There may be interference while using infrared devices such as infrared cordless
headphones.
•
•
•
•
•
•
•
SAFETY PRECAUTIONS
The unit emits heat when in operation. Do not place any covers or blankets on the unit, this may cause
overheating.
Do not block ventilation holes, or set up near radiators. Do not place in direct sunshine. When placing on a shelf
leave 10 cm (4 inches) free space around the entire unit.
Notes when mounting the LCD TV on a wall
When installing the unit on a wall, allow at least 6 cm (2 1/2
inches) clearance between the rear of the LCD TV and the wall.
Clearance of less than 6 cm (2 1/2 inches) will obstruct the vents
and may cause the interior of the unit to overheat, resulting in
damage to the unit.
If the unit is to be mounted on the wall, contact the retailer where
you purchased the LCD TV for advice, and have the equipment
professionally installed. Incomplete or improper installation may
cause injury to you, and/or damage to the LCD TV.
Bracket holes: To attach a wall mounting bracket (not supplied)
remove the screws and attached where indicated in the drawing
below.
•
•
•
Bracket holes
34K0101A_eng.indd 534K0101A_eng.indd 5 8/31/2007 4:20:57 PM8/31/2007 4:20:57 PM

6
Contents
PREPARATIONS
IMPORTANT SAFETY INSTRUCTIONS........................................ 3
SAFETY PRECAUTIONS .............................................................. 5
Contents ........................................................................................ 6
Features......................................................................................... 7
Power source................................................................................. 7
Parts and functions ........................................................................ 8
Remote control .............................................................................. 9
Antenna connections ................................................................... 10
Cable TV connections.................................................................. 11
Connections to other equipment.................................................. 12
Setting the language.................................................................... 17
OPERATION
Memorizing channels................................................................... 17
TV operation ................................................................................ 18
Labeling channels........................................................................ 19
Setting the V-Chip ........................................................................ 20
Closed Caption............................................................................ 21
CC advanced............................................................................... 22
Setting the picture size................................................................. 22
Adjusting the picture preference .................................................. 23
Picture control adjustment ........................................................... 23
DNR............................................................................................. 24
Selecting the color temperature................................................... 24
Setting the 3D Y/C........................................................................ 24
Selecting Stereo/Second Audio Program (SAP) .......................... 24
Sound control adjustment............................................................ 25
Selecting the audio language....................................................... 25
Selecting the digital output........................................................... 25
Checking the Digital-signal strength ............................................ 25
Resetting your settings ................................................................ 25
Picture control adjustment in the Component and PC mode........ 26
Reception disturbances ............................................................... 27
OTHERS
Troubleshooting ........................................................................... 28
Specifications .............................................................................. 29
LIMITED WARRANTY ................................................................. 30
34K0101A_eng.indd 634K0101A_eng.indd 6 8/31/2007 4:20:58 PM8/31/2007 4:20:58 PM

7
Features
Integrated Digital Tuner -You can view digital broadcasts without using a Digital TV Set-Top Box.
Closed Caption Decoder With Full Text Mode -Displays text captions or full screen text on the screen for
hearing impaired viewers.
Picture Adjustments Using The Remote Control -The On-Screen display allows precise remote control
adjustment of BRIGHTNESS, CONTRAST, COLOR, TINT and SHARPNESS.
Programmable TV Sleep Timer -Operable from the remote control, the LCD TV can be programmed for up
to 240 minutes to turn off automatically.
V-Chip -The V-Chip function can read the rating of a broadcast program or movie content if the program is
encoded with this information.V-chip will allow you to set a restriction level.
Digital Audio Jack (Coaxial) -When a component with a built-in Dolby Digital decoder is connected, Dolby
Digital sound can produce the effect of being in a movie theater or a concert hall.
S-Video/Component Video Jacks -A VCR, DVD player, satellite receiver or other audio/video component
can be connected to this unit.
Video Input Jacks -This unit is equipped with 3 types of video input jacks.The component video in jacks and
S-video in jack enable you to watch the DVD player or the video devices with high quality picture.
On-Screen 3 Language Display -You can select one of 3 languages, English, Spanish or French for on-
screen programming.
•
•
•
•
•
•
•
•
•
NOTE:
Please make sure to insert the cord securely at both the LCD TV and the wall outlet.
The AC cord has a grounding-type AC line plug. If the supplied AC cord does not match your AC outlet,
contact a qualified electrician, do not defeat the purpose of a grounding plug.
WARNING:
DO NOT CONNECT THIS UNIT TO THE POWER USING ANY DEVICE OTHER THAN THE SUPPLIED AC
CORD. THIS COULD CAUSE FIRE, ELECTRICAL SHOCK, OR DAMAGE.
DO NOT USE WITH A VOLTAGE OTHER THAN THE POWER VOLTAGE DISPLAYED. THIS COULD CAUSE
FIRE, ELECTRICAL SHOCK, OR DAMAGE.
CAUTION:
WHEN THIS UNIT IS NOT USED FOR A LONG TIME, (E.G., AWAY ON A TRIP) IN THE INTEREST OF
SAFETY, BE SURE TO UNPLUG IT FROM THE AC OUTLET.
DO NOT PLUG/UNPLUG THE PLUG WHEN YOUR HANDS ARE WET.THIS MAY CAUSE ELECTRICAL
SHOCK.
IF YOU NEED TO REPLACE THE SUPPLIED AC ADAPTER OR AC CORD, THE SPECIFIED ONE IS
RECOMMENDED. CONTACT CUSTOMER SERVICE AT 1-800-289-0980.
•
•
•
•
•
•
•
Power source
TO USE AC POWER
Connect the AC cord plug into this unit’s AC INPUT jack.
Connect the AC cord into an AC outlet.
1.
2.
* Manufactured under license from Dolby Laboratories.“Dolby” and the double-D symbol are trademarks of
Dolby Laboratories.
AC cord (supplied)
AC 120V, 60Hz
Wider Hole
and Blade
AC Outlet
34K0101A_eng.indd 734K0101A_eng.indd 7 8/31/2007 4:20:58 PM8/31/2007 4:20:58 PM

8
Parts and functions
To display the menu screen.
Press MENU button to display the menu
screen.
CHANNEL ▲/▼buttons and VOLUME
+/– buttons can be used to select the desired
setting during the menu screen operations.
POWER button
INPUT button
VOLUME +/– buttons
CHANNEL ▲/▼buttons MENU button
Remote sensor
RF (ANT)IN jacks
COAXIAL DIGITAL
AUDIO OUT jack
AV1 IN jacks
(VIDEO/S-VIDEO/AUDIO (L/R))
PC/HDMI AUDIO IN jack
PC IN jack
HDMI 1 IN jack
AUDIO (L/R)jacks
(for COMPONENT IN and AV2 VIDEO IN)
COMPONENT IN jacks
To p
Rear
Left side
Front
Bundle
cables with
the cable
clip
•
HDMI 2 IN jack
POWER indicator
Red: Standby
Green: On
(It alternately blinks to red and green while starting.)
AV2 VIDEO IN jack
34K0101A_eng.indd 834K0101A_eng.indd 8 8/31/2007 4:20:58 PM8/31/2007 4:20:58 PM

9
Remote control
2
3
11
6
9
13
1
7
15
14
12
8
10
5
16
4
HOW TO INSTALL BATTERIES
1. Open the battery compartment cover.
2. Install two “AA” batteries (supplied).
3. Replace the battery compartment cover.
Before using the remote control, batteries must first be installed.
Use two “AA” size batteries.The batteries may last
approximately one year depending on how much the
remote control is used. For best performance, it is
recommended that batteries should be replaced on a
yearly basis, or when the remote operation becomes
erratic. Do not mix old and new batteries or different
types.
BATTERY PRECAUTIONS
These precautions should be followed when using
batteries in this device:
Use only the size and type of batteries specified.
Be sure to follow the correct polarity when
installing the batteries as indicated in the battery
compartment. Reversed batteries may cause
damage to the device.
Do not mix different types of batteries together (e.g.
Alkaline and Carbon-zinc) or old batteries with fresh
ones.
If the device is not to be used for a long period of
time, remove the batteries to prevent damage or
injury from possible battery leakage.
Do not try to recharge batteries not intended to be
recharged; they can overheat and rupture. (Follow
battery manufacturer’s directions.)
•
•
•
•
•
1.POWER Button -Used to turn the power on/off to
the LCD TV.
2.SLEEP Button -To set the LCD TV to turn off
after a preset amount of time, use the SLEEP
button on the remote control.
3.Direct Channel Selection Buttons (0-9) -Allows
direct access to any channel of the LCD TV.
4.–Button -This button is the “–” button used
when selecting digital channels. Also can display
the current channel number when viewing the
program.
5.RESET Button -Press to reset the On-Screen
picture adjustments to their factory preset positions.
To use this function, select “Setup” in the menu
screen, then press this button.
6.CH (CHANNEL) + / –/ CURSOR ▲/ ▼Buttons
-Used to operate the menu functions of the LCD
TV, and to change the channels of the LCD TV.
7.MENU Button -Use to display the On-Screen
menu function.
8.MUTE Button -To turn off the sound, press this
button once.The LCD TV will be silenced and
the symbol “Mute” will appear on the screen.The
muting feature can be released by pressing the
MUTE button again or one of the VOL (VOLUME)
+ or – buttons.
9.DISPLAY Button -When you press this button,
the current information will be displayed on a
screen.To remove the display from the screen,
press this button again.
10.PICTURE SIZE Button -Used to change the
picture size.
11.INPUT SELECT Button -Use to change the
external input.
12.RECALL Button -This button allows you to go
back to the previous channel selected by just
pressing the RECALL button. Press this button
again to return to the channel you were watching.
13.CCD Button -Used to set the closed caption “CC
On”, “CC On Mute” or “CC Off”.
14.ENTER Button -Use to enter or select
information for On-Screen operations. Also can
display the current channel number when viewing
the program.
15.VOL (VOLUME) + / –/ CURSOR ◀/ ▶Buttons -
Used to operate the menu functions of the ◀LCD
TV. Press the ▶button to increase, or the button
to decrease the sound level.
16.EXIT Button -Press to remove setup menu.
34K0101A_eng.indd 934K0101A_eng.indd 9 8/31/2007 4:20:58 PM8/31/2007 4:20:58 PM

10
ANT
ANT
If you are using an indoor or outdoor antenna, follow the instructions below that correspond to your
antenna system. If you are using a Cable TV service, see page 11 for Cable TV connections.
Combination VHF/UHF Antenna (Single 75 ohm cable or 300 ohm twin-lead wire)
Combination VHF/UHF Antenna (Separate VHF and UHF 300 ohm twin-lead wires)
Antenna connections
Separate VHF/UHF Antennas (75 ohm VHF cable and 300 ohm UHF twin-lead wires)
Connect the 75 ohm cable from the combination
VHF/UHF antenna to the antenna jack.
If your combination VHF/UHF antenna has a 300
ohm twin-lead wire, the use of the 300-75 ohm
matching transformer may be necessary.
Connect the UHF 300 ohm twin-lead wire to
the Combiner (not supplied). Connect the VHF
300 ohm twin-lead wire to the 300-75 ohm
Matching Transformer. Attach the Transformer to
the Combiner, then attach the Combiner to the
Antenna Jack.
Connect the VHF 75 ohm cable and UHF 300 ohm
twin-leadwiretotheCombiner(notsupplied).Attach
the Combiner to the Antenna Jack.
ANT
75 ohm
Coaxial
Cable
300-75 ohm
Matching
Transformer
VHF 75 ohm
Antenna
Jack
Antenna
Jack
300-75 ohm Matching Transformer
UHF 300 ohm
Antenna
Jack
Combiner
Antenna
Jack
Combiner
UHF 300 ohm
VHF 300 ohm
ANT
34K0101A_eng.indd 1034K0101A_eng.indd 10 8/31/2007 4:20:59 PM8/31/2007 4:20:59 PM

11
For basic Cable TV service not requiring a Converter/
Descrambler box, connect the 75 ohm Coaxial Cable directly
to the Antenna Jack on the back of the TV.
Cable TV connections
FOR SUBSCRIBERS TO SCRAMBLED CABLE TV SERVICE
If you subscribe to a Cable TV service which requires the use of a Converter/Descrambler box, connect
the incoming 75 ohm Coaxial Cable to the Converter/Descrambler box. Using another 75 ohm Coaxial
Cable, connect the output jack of the Converter/Descrambler box to the Antenna Jack on the TV. Follow the
connections shown below. Set the TV to the output channel of the Converter/Descrambler box (usually channel
3 or 4) and use the Converter/Descrambler box to select channels.
FOR SUBSCRIBERS TO UNSCRAMBLED BASIC CABLE TV SERVICE WITH
SCRAMBLED PREMIUM CHANNELS
If you subscribe to a Cable TV service in which basic channels are unscrambled and premium channels require
the use of a Converter/Descrambler box, you may wish to use a signal Splitter and an A/B Switch box (available
from the Cable TV company or an electronics supply store). Follow the connections shown below.With the
switch in the “B” position, you can directly tune any nonscrambled channels on your TV. With the switch in the
“A” position, tune your TV to the output of the Converter/Descrambler box (usually channel 3 or 4) and use the
Converter/Descrambler box to tune scrambled channels.
Splitter B
A
Incoming
75 ohm
Cable TV
Cable A/B Switch 75 ohm Cable to TV
Incoming
75 ohm
Cable TV
Cable 75 ohm Cable to TV
Converter/
Descrambler
Antenna
Jack
Antenna
Jack
Converter/
Descrambler
This TV has an extended tuning range and can tune most cable channels without using a Cable TV
Converter box. Some cable companies offer “premium pay channels” where the signal is scrambled.
Descrambling these signals for normal viewing requires the use of a descrambler device which is
generally provided by the Cable TV company.
FOR SUBSCRIBERS TO BASIC CABLE TV SERVICE
75 ohm
Coaxial Cable
Antenna
Jack
ANT
34K0101A_eng.indd 1134K0101A_eng.indd 11 8/31/2007 4:20:59 PM8/31/2007 4:20:59 PM

12
Connections to other equipment
The exact arrangement you use to interconnect various video and audio components to the LCD TV is
dependent on the model and features of each component. Check the Owner’s Manual provided with each
component for the location of video and audio inputs and outputs.
The connection diagrams below are offered as suggestions.You may need to modify them to accommodate
your particular assortment of components.The diagrams are intended to show component video and audio
interconnections only.
To connect the LCD TV to a VCR
To connect the LCD TV to a VCR with an S-Video cord
If you connect a VCR with a S-VIDEO cord to the S-VIDEO IN jack on the rear of the LCD TV , you must also
connect
the audio cords to the AV1 AUDIO(L/R) IN jacks on the rear of the LCD TV. The S-VIDEO cord only
carries the video signal.The audio signal is separate.
NOTE:
When the S-video cord and the video cord are connected to each jack at the same time, the S-video cord
takes precedence over the video cord.
•
Left side of the LCD TV
To Audio/Video OUT
Audio/Video cord
(not supplied)
Rear of the LCD TV
To S-Video OUT
To Audio OUT
Audio cord (not supplied)
S-Video cord (not supplied)
To S-VIDEO IN
To AV1 AUDIO (L/R)IN
or
To AV1 VIDEO/AUDIO (L/R) IN
To AV2 VIDEO/AUDIO (L/R) IN
Rear of the LCD TV
34K0101A_eng.indd 1234K0101A_eng.indd 12 8/31/2007 4:20:59 PM8/31/2007 4:20:59 PM

13
Y
PB
PR
To connect the LCD TV to a DVD player/Satellite receiver
If your DVD player or Satellite receiver has a S-Video out jack, connect cords as shown.
To connect the LCD TV to a DVD player with component video
If your DVD player has component video out jacks, connect your LCD TV to a DVD player using a component
video cord. It can greatly enhance picture quality and performance.
NOTE:
Component Video inputs of the unit are for use with a device which outputs 480i/1080i interlaced signals and
480p/720p progressive signals.
•
Connections to other equipment
Rear of the LCD TV
To S-Video OUT
To Audio OUT
Audio cord (not supplied)
S-Video cord (not supplied)
To S-VIDEO IN
To AV1 AUDIO (L/R)IN
To Component OUT
To Audio OUT
Audio cord (not supplied)
Video cord (not supplied)
Left side of the LCD TV
To COMPONENT IN
To AV2 AUDIO (L/R) IN
34K0101A_eng.indd 1334K0101A_eng.indd 13 8/31/2007 4:20:59 PM8/31/2007 4:20:59 PM

14
Connections to other equipment
To connect the LCD TV to a DTV receiver/set-top box
If you connect a DTV receiver/set-top box, connect your LCD TV to a DTV receiver/set-top box using a
component video cord.
Y
PB
PR
To Component OUT
To Audio OUT
Audio cord (not supplied)
Video cord (not supplied)
Left side of the LCD TV
To COMPONENT IN
To AV2 AUDIO (L/R) IN
To connect the LCD TV to an HDMI or a DVI device
The HDMI input receives digital audio and uncompressed video from an HDMI device or uncompressed digital
video from a DVI device.
When you connect to a DVI device with an HDMI-to-DVI adapter cable, it transfers only the video signal.
Separate analog audio cords are required.
NOTE:
If you connect an external component (cable box, satellite receiver, etc.) to this LCD TV using an HDMI cable
or a DVI to HDMI cable, the image will not display if the output resolution of the component is set to 480i.To
receive the picture you must change the output resolution on the external component.
Should you require further instruction, please contact the manufacturer of the external component.
When you connect a DVI device, you must connect only with HDMI 1.
•
•
HDMI - to - DVI adapter cable
(HDMI type A connector)
(not supplied)
Audio cord (not supplied)
HDMI cable (type A connector)
(not supplied)
To DVI output
To HDMI out
or
Left side of the LCD TV
or
HDMI device
DVI device
To HDMI 1
To HDMI 2 (or1)
To PC/HDMI AUDIO IN
34K0101A_eng.indd 1434K0101A_eng.indd 14 8/31/2007 4:21:00 PM8/31/2007 4:21:00 PM

15
TV GAME
Connections to other equipment
Using an AV Amplifier with built-in digital surround
If you are using an Amplifier with built-in digital surround sound, you can enjoy various audio systems including
Dolby Digital Surround audio that sounds just like the movie.
Connect an AV amplifier with built-in Dolby Digital decoder, or etc. as shown below.
NOTE:
Coaxial digital audio output is active only when receiving digital broadcasting, not when receiving analog
broadcasting.
Coaxial digital audio output doesn’t output the sound of external inputs.
•
•
To connect the LCD TV to a Game or a Camcorder
The LCD TV can also be used as a TV device for many video games or camcorders. However, due to the wide
variety of signals generated by these devices and subsequent hook-up variations required, they have not all
been included in the suggested connection diagrams.You’ll need to consult each component’s Owner’s Manual
for additional information.
Left side of the LCD TV
Audio/Video cord (not supplied)
To Audio/
Video OUT
or
Audio/Video cord
(not supplied)
To AV1 VIDEO/AUDIO (L/R) IN
To AV2 VIDEO/AUDIO (L/R) IN
Coaxial digital cable
(not supplied)
Coaxial Digital Audio Output
Rear of the LCD TV
Front
Speaker
(Left)
Front
Speaker
(Right)
Subwoofer
TV
AV Amplifier with built-in digital
surround decoder as listed above
Center Speaker
To Coaxial Digital Audio Input
Surround
Speaker (Left) Surround
Speaker
(Right)
Rear of the LCD TV or
34K0101A_eng.indd 1534K0101A_eng.indd 15 8/31/2007 4:21:00 PM8/31/2007 4:21:00 PM

16
Connections to other equipment
To connect the LCD TV to a PC (Personal Computer)
Before you connect this LCD TV to your PC, change the adjustment of your PC’s Resolution and Refresh rate
(60 Hz).
Connect one end of a (male to male) VGA cable to the video card of the computer and the other end to the VGA
connector PC MONITOR on the back of the
LCD TV . Attach the connectors firmly with the screws on the plug. In
case of a Multimedia computer, connect the audio cord to the audio output of your Multimedia computer and to
the AUDIO connector of the PC/HDMI AUDIO IN jack of the LCD TV.
Press INPUT SELECT on the remote control to select PC mode.
Switch on the computer.The LCD TV can operate as the computer monitor.
Monitor Display modes
MODE Resolution Refresh rate
VGA 640x480 60Hz
VGA 720x400 70Hz
SVGA 800x600 60Hz
XGA 1024x768 60Hz
WXGA 1280x768 60Hz
WXGA 1280x720 60Hz
WXGA 1360x768 60Hz
To return to normal mode
Press INPUT SELECT again.
NOTE:
The on-screen displays will have a different appearance in PC mode than in TV mode.
If there is no video signal from the PC when the unit is in PC mode, “No signal” will appear on the TV-screen.
•
•
VGA cable (not supplied)
Left side of the LCD TV
To PC/
HDMI
AUDIO
IN jack
To PC IN
Audio cord (not supplied)
34K0101A_eng.indd 1634K0101A_eng.indd 16 8/31/2007 4:21:00 PM8/31/2007 4:21:00 PM

17
Setting the language
You can choose from three different languages
(English, French and Spanish) for the on-screen
displays.
Select the language you prefer first, then
proceed with the other menu options.
1To turn on the TV, press POWER.
(POWER indicator on the front of the unit blinks
while starting. It may take approx. 15 seconds for
a picture to appear on screen.)
2Press MENU.The menu screen will appear.
3Press ▲or ▼to select “Setup” menu, then press
▶.
4Press ▲or ▼to select “Menu Language”.
Setup
Audio
Feature
Tuning Band
DTV Signal
Auto Ch Search
Add On Ch Search
Manual Ch Set
Channel Labels
Menu Language
Reset
Cable
English
To M o v e To S e l e c t To E x i t
Enter Menu
5Press ▶or ENTER to select the desired
language: English (ENGLISH), French
(FRANÇAIS) or Spanish (ESPAÑOL).
6Press MENU to return to the normal screen.
NOTE:
If no buttons are pressed for more than about 30
seconds, the MENU screen will return to normal
operation automatically.
On this TV, there are setting menus for each
external input.You can change the settings to fit
your needs.
(Some settings are commoditized.
I.e., Audio settings, Parental control, NTSC CC,
ATSC CC and Digital Closed Caption settings are
applied to all external inputs.)
Memorizing channels
This TV is equipped with a channel memory
feature which allows channels to skip up or down
to the next channel set into memory, skipping
over unwanted channels. Before selecting
channels, they must be programmed into the
TV’s memory. To use this TV with an antenna, set
the Tuning Band menu option to the Air mode.
When shipped from the factory, this menu option
is in the Cable mode.
Air/Cable selection
1Press MENU. The menu screen will appear.
2Press ▲or ▼to select “Setup” menu, then press
▶.
3Press ▲or ▼to select “Tuning Band”.
•
•
4Press ▶or ENTER to select “Air” or “Cable”.
Air - VHF/UHF channels
Cable - CABLE TV channels
Setup
Audio
Feature
Tuning Band
DTV Signal
Auto Ch Search
Add On Ch Search
Manual Ch Set
Channel Labels
Menu Language
Reset
Air
English
To Move To S e l e c t To E x i t
Enter Menu
5Press MENU to return to the normal screen.
CABLE CHART
The chart below is typical of many cable system
channel allocations.
NOTE:
It may take a few seconds for a digital channel
picture to appear on screen after being selected.
Automatic channel search
1Press MENU. The menu screen will appear.
2Press ▲or ▼to select “Setup” menu, then press
▶.
Press ▲or ▼to select “Auto Ch Search”.
Setup
Audio
Feature
Tuning Band
DTV Signal
Auto Ch Search
Add On Ch Search
Manual Ch Set
Channel Labels
Menu Language
Reset
Cable
English
To M o v e To Select To E x i t
Enter Menu
3Press ▶or ENTER.The TV will begin memorizing
all the channels available in your area.
It may take from 15 minutes to 30 minutes to
complete memorizing digital cable channels.
Depending on the reception condition, a BAR
display may not advance for several minutes,
please be patient.
•
Add on channel search
This feature searches only blank, unregistered
channels.
1Press MENU.The menu screen will appear.
2Press ▲or ▼to select “Setup” menu, then press
▶.
Press ▲or ▼to select “Add On Ch Search”.
•
34K0101A_eng.indd 1734K0101A_eng.indd 17 8/31/2007 4:21:00 PM8/31/2007 4:21:00 PM

18
Setup
Audio
Feature
Tuning Band
DTV Signal
Auto Ch Search
Add On Ch Search
Manual Ch Set
Channel Labels
Menu Language
Reset
Cable
English
To M o v e To S e l e c t To E x i t
Enter Menu
3Press ▶or ENTER.The TV will begin searching
only blank, unregistered channels.
It may take from 15 minutes to 30 minutes to
complete memorizing digital cable channels.
Depending on the reception condition, a BAR
display may not advance for several minutes,
please be patient.
•
NOTE:
Memorizing channels is best accomplished during
evening “PRIMETIME” hours, as more stations are
broadcasting digital signals. Memorizing channels
can only be accomplished while a station is
broadcasting a digital signal to set that channel into
memory.
If you are unsure of the digital channels available
in your area, you may visit www.antennaweb.org to
receive a list based on your address or zip code.
Should you require further assistance you may call
our toll-free customer service line at 1-800-289-
0980.
New digital channels may be added to your area
periodically, it is recommended to perform the “Add
On Ch Search” procedure regularly.
Manual Ch Set
You can select the channel that you want to skip.
1Press MENU.The menu screen will appear.
2Press ▲or ▼to select “Setup” menu, then press
▶.
Press ▲or ▼to select “Manual Ch Set”, then
press ▶or ENTER.
Manual Ch Set menu will appear.
3Press ▲or ▼to select the channel that you want
to skip, then press ENTER.
Manual Channel Set Menu
Ch 7-0 Viewable
Ch 7-0 Viewable
Ch 11-0 Viewable
Ch 12-0 Viewable
Ch 22-0 Viewable
Ch 23-0 Viewable
Ch 23-1 CH-1 Viewable
Ch 23-2 CH-2 Viewable
Ch 23-3 CH-3 Viewable
Ch 23-4 CH-4 Viewable
Ch 23-77 CH-77 Viewable
Ch 23-999 CH-999 Viewable
To M o v e To S e l e c t To Exit
Enter Menu
4Press MENU to return to the normal screen.
TV operation
1To turn on the TV, press POWER.
(POWER indicator on the front of the unit blinks
while starting. It may take approx. 15 seconds for
a picture to appear on screen.)
•
•
•
2Adjust the volume level by pressing VOL + or –.
The volume level will be indicated on the screen
by white bars. As the volume level increases, so
do the number of bars. If the volume decreases,
the number of white bars also decreases.
3Set the Tuning Band menu option to the
appropriate position (see “Air/Cable selection” on
page 17).
4Press the Direct Channel Selection (0-9, –)
buttons to select the channel, then press ENTER.
(If you press only channel number, channel
selection will be delayed for a few seconds.)
TO SELECT ANALOG CHANNELS
1-9: Press 1-9 as needed. Example, to
select channel 2, press 2.
10-99: Press the 2 digits in order. Example, to
select channel 12, press 1, 2.
100-135: Press the 3 digits in order. Example, to
select channel 120, press 1, 2, 0.
TO SELECT DIGITAL CHANNELS
Press the first 3 digits, then press the –button,
followed by the remaining number.
Example, to select channel 015-001, press 0,1,
5,–,1.
If a channel is selected with only audio content,
“Audio only” will be displayed on the screen.
If a channel is selected with a weak digital
signal, “Digital channel signal strength is low”
will be displayed on the screen.
If the digital channel has the same analog
channel, you way be able to watch the same
channel with analog.
If a channel is selected to which you have not
subscribed,
“Digital channel is encrypted” will
be displayed on the screen.
•
•
•
VHF/UHF/CABLE CHANNELS
Air Cable
VHF
2-13 VHF 2-13
UHF
14-69 STD/HRC/IRC 14-36 (A) (W)
37-59 (AA) (WW)
60-85 (AAA) (ZZZ)
86-94 (86) (94)
95-99 (A-5) (A-1)
100-135 (100) (135)
01 (5A)
NOTE:
If a channel with no broadcast is selected, the
sound will automatically be muted.
It may take a few seconds for a digital channel
picture to appear on screen after being selected.
To select the video input source
Press INPUT SELECT to view a signal from another
device connected to your LCD TV, such as a VCR
or DVD player.You can select ANT, Composite1,
Composite2, S-Video, Component, HDMI1, HDMI2
or PC depending on which input jacks you used to
connect your devices.
•
•
34K0101A_eng.indd 1834K0101A_eng.indd 18 8/31/2007 4:21:01 PM8/31/2007 4:21:01 PM

19
CH +/–
Press and release CH+/–.The channel automatically
stops at the next channel set into memory.
For proper operation, before selecting channels, they
should be set into the memory. See “Memorizing
channels” on pages 17 and 18.
DISPLAY
Press DISPLAY to display the current information on
the screen.
When the TV receives a digital signal, the digital
information will appear.
Ch 15
Monscope_480i_1
720x480 I 30Hz TV-G
Monscope_480i_1_ABCDEFGHLIJKLMNOPQRST....
ABCDEFGHLIJKLMNOPQRSTUVWXYZabcdefghi....
Channel number
Broadcast program name
Station name
Program guide
V-CHIP RATING
When the TV receives a analog signal, the analog
information will appear.
•
•
•
•
•
Ch 12 ABCDEFG
No Program Information is Available
720x480 I 30Hz TV-14VSLD SAP
Channel number or VIDEO mode selected
Channel label (if preset)
Stereo or SAP (second audio program) audio status
Content rating
Press DISPLAY again to clear the call display.
•
•
•
•
NOTE:
When the TV receives an analog signal, DISPLAY
shows only analog information.
After 4 seconds, DISPLAY screen will return to
normal TV-operation automatically.
RECALL
This button allows you to go back to the last channel
selected by pressing RECALL. Press RECALL again
to return to the last channel you were watching.
MUTE
Press MUTE to switch off the sound.The TV’s sound
will be silenced and “Mute” will briefly appear on
the screen.The sound can be switched back on by
pressing this button again or the VOL + or –.
•
•
SLEEP
The sleep timer allows you to set a time when the
LCD TV automatically switches to standby.
1Press MENU.The menu screen will appear.
2Press ▲or ▼to select “Feature” menu, then
press ▶.
3Press ▲or ▼to select “Sleep Timer”.
4Press ▶or ENTER repeatedly to select the
desired sleep time (Off, 15 min, 30 min, 45 min,
60 min, 90 min, 120 min, 180 min or 240 min).
Setup
Audio
Feature
Sleep Timer 240 min
Advanced Video Menu
Password Set
Parental Control
NTSC CC Off
ATSC CC Off
Digital Closed Caption
To M o v e To S e l e c t To E x i t
Enter Menu
5Press MENU to return to the normal screen.
NOTE:
You can also set the sleep timer by pressing SLEEP
on the remote control.
After the sleep time is programmed, the display
will appear briefly 10 minutes and 5 minutes, 1
minute before to remind you that the sleep timer is
operating.
To confirm the sleep timer setting, press SLEEP
and the remaining time will be displayed for a few
seconds.
To cancel the sleep timer, press ▶or ENTER
repeatedly to select “Off” in step 4.
Labeling channels
Channel labels appear over the channel number
display each time you turn on the TV, select a
channel, or press DISPLAY.
You can choose any seven characters to identify
a channel.
To create channel labels
1Press MENU, then press ▲or ▼to select “Setup”
menu, then press ▶.
2Press ▲or ▼to select “Channel Labels”, then
press ▶or ENTER.
The “Channel Labels” menu will appear.
3Press ▲or ▼to select a channel you want to
label.
Channel Labels Menu
Ch 23-0 -------
To M o v e To C h a n g e To E x i t
Enter Menu
4Press ◀or ▶to enter a character in the first
space. Press ▲or ▼repeatedly until the
character you want appears on the screen.
•
•
•
•
34K0101A_eng.indd 1934K0101A_eng.indd 19 8/31/2007 4:21:01 PM8/31/2007 4:21:01 PM

20
Channel Labels Menu
Ch 23-0 -------
To M o v e To C h a n g e To E x i t
Enter Menu
The characters rotation as follows:
SPACE
-
*
?
If the character which you desire appears, press
▶.
Repeat this step to enter the rest of the
characters.
If you would like a blank space in the label name,
you must choose the empty space from the list of
characters.
5When you finish inputting the label name, press
MENU to return to the normal screen.
6Repeat steps 1-5 for other channel.You can
assign a label to each channel.
NOTE:
The channel labels will be reset after “Auto Ch
Search” on page 17.
Setting the V-Chip
An age limitation can be set to restrict children
from viewing or hearing violent scenes or
pictures that you may choose to exclude. The
restriction applies to “TV RATING” and “MPAA”
if this data is transmitted. You may set this
restriction separately. To use the V-Chip function,
you must register a password.
To register a password
1Press MENU.The menu screen will appear.
Press ▲or ▼to select “Feature” menu, then
press ▶.
2Press ▲or ▼to select “Password Set”, then press
▶or ENTER.
3Use Number buttons (0-9) to enter your
password (The factory default password is
“0000”).
Enter Old Password
“ ” appears instead of the number.
4Select and enter a password (4 digits) using
Number buttons (0-9).
5Enter the same password again to confirm.
The password is now registered.
NOTE:
If you forget the password, contact Customer
Service at 1-800-289-0980 for assistance.
Your original remote control will be required.
To avoid forgetting the password, write it down and
keep in a safe place.
•
•
•
To set the V-Chip
1Press MENU.
Press ▲or ▼to select “Feature” menu, then
press ▶.
2Press ▲or ▼to select “Parental Control”, then
press ▶or ENTER.
Use Number buttons (0-9) to enter your
password.The Parental Control Menu appears.
3Press ▲or ▼to select “US Ratings”, then press ▶
or ENTER.
Parental Control Menu
US Ratings
Advanced Rating Off
To M o v e To S e l e c t To Exit
Enter Menu
4Press ▲/▼/◀/▶to select the desired rating, then
press ENTER.
Parental Control Menu
MPAA
ALL FV L S V D
NONE
G
PG
PG-13
R
NC-17
X
NONE
TV-Y
TV-Y7
TV-G
TV-PG
TV-14
TV-MA
TV Rating
To M o v e To S e l e c t To E x i t
Enter Menu
MPAA (Motion Picture Association of America)
NONE : MPAA is not set.
G: all ages
PG : parental guidance
PG-13 : parental guidance less than 13 years old
R: under 17 years old parental guidance
suggested
NC-17 : 17 years old and above
X: adult only
TV Rating
NONE : TV Rating is not set
TV-Y: All children
TV-Y7 : 7 years old and above
TV-G: General audience
TV-PG : Parental guidance
TV-14 : 14 years old and above
TV-MA : 17 years old and above
ALL (All)
FV (Fantasy Violence)
L(Language)
S(Sex)
V(Violence)
D(Dialogue)
5Press MENU to return to the normal screen.
To use the TV after the TV is protected.
When a program is received that is blocked by the
V-Chip, press DISPLAY or MENU.
The protection will be temporarily overridden. If the TV
is turned off, the V-Chip restriction will be reactivated.
NOTE:
The V-Chip function is activated only on programs
and input sources that include a rating signal.
•
34K0101A_eng.indd 2034K0101A_eng.indd 20 8/31/2007 4:21:01 PM8/31/2007 4:21:01 PM
