Sansui HDLCDVD260A User manual

26” TFT LCD DIGITAL TV WITH DVD PLAYER
HDLCDVD260A
OWNER’S MANUAL
Before operating the unit, please read this manual thoroughly.
IF CONTACT WITH CUSTOMER SERVICE IS REQUIRED
PLEASE HAVE THE MODEL NUMBER READY PRIOR TO THE CALL
CUSTOMER SERVICE – 1-800-289-0980
ORION WEBSITE
FOR INFORMATION ON OUR OTHER PRODUCTS, PLEASE VISIT OUR WEBSITE AT
www.orionsalesinc.com
TV/CABLE MODE SELECTION
When shipped from the factory, the Tuning Band option is set to the “Cable” (Cable Television) mode.
If not using CABLE, set this option to the “Air” position.
ATTENTION
If you purchase a universal remote control from your local retailer, please contact the remote
manufacturer for the required programming code.
50H0201A.indd 150H0201A.indd 1 07.8.29 3:25:06 PM07.8.29 3:25:06 PM

2
CAUTION:
THIS DIGITAL VIDEO PLAYER EMPLOYS A LASER SYSTEM.
TO ENSURE PROPER USE OF THIS PRODUCT, PLEASE
READ THIS OWNER'S MANUAL CAREFULLY AND RETAIN
FOR FUTURE REFERENCE. SHOULD THE UNIT REQUIRE
MAINTENANCE, CONTACT AN AUTHORIZED SERVICE
LOCATION-SEE SERVICE PROCEDURE.
USE OF CONTROLS, ADJUSTMENTS OR THE
PERFORMANCE OF PROCEDURES OTHER THAN THOSE
SPECIFIED HEREIN MAY RESULT IN HAZARDOUS
RADIATION EXPOSURE.
TO PREVENT DIRECT EXPOSURE TO THE LASER BEAM,
DO NOT TRY TO OPEN THE ENCLOSURE. RADIATION
MANY BE PRESENT WHEN THE ENCLOSURE IS OPENED.
DO NOT STARE INTO THE BEAM.
Location of the required Marking
The rating sheet and the safety caution are
on the rear of the unit.
The lightning flash with arrowhead
symbol, within an equilateral triangle
is intended to alert the user to the
presence of uninsulated dangerous
voltage within the product's enclosure
that may be of sufficient magnitude to
constitute a risk of electric shock.
The exclamation point within an
equilateral triangle is intended to
alert the user to the presence of
important operating and maintenance
(servicing) instructions in the literature
accompanying the appliance.
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN
OR MOISTURE.
CAUTION: TO PREVENT ELECTRIC SHOCK DO NOT USE THIS POLARIZED PLUG WITH AN EX-
TENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE
FULLY INSERTED TO PREVENT BLADE EXPOSURE.
WARNING: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules.These limits are designed to provide reasonable protection
against harmful interference in a residential installation.This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be deter-
mined by turning the equipment off and on, the user is encouraged to try to correct the interfer-
ence by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
CAUTION: Changes or modifications not expressly approved by the party responsible for compliance with
the FCC Rules could void the user's authority to operate this equipment.
CERTIFICATION: COMPLIES WITH FDA
RADIATION PERFORMANCE STANDARDS,
21 CFR SUBCHAPTER J.
The lamp(s) within this product contain mercury.
Disposal should be in compliance with local, state or federal laws.
50H0201A.indd 250H0201A.indd 2 07.8.29 3:25:09 PM07.8.29 3:25:09 PM

3
IMPORTANT SAFETY INSTRUCTIONS
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with a clean dry cloth.
7) Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has two blades and a third grounding prong.The
wide blade and the third prong are provided for your safety. If the provided plug does not fit into your outlet,
consult an electrician to replace the obsolete receptacle.
10) Protect the power cord from being walked on or pinched particularly at plug, and the point where it exits
from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus.When a cart is used, use caution
when moving the cart/apparatus combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long periods
of time.
14) Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug
damage, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or
has been dropped.
15) Apparatus should not be exposed to dripping or splashing, and objects filled with liquids, such a vases,
should not be placed on the apparatus.
16) An outside antenna system should not be located in the vicinity of overhead power lines or other electric
light or power circuits, or where it can fall into such power lines or circuits.When installing an outside
antenna system, extreme care should be taken to keep from touching such power lines or circuits, as
contact with them might be fatal.
17) Do not overload wall outlets and extension cords, as this can result in a risk of fire or electric shock.
18) Do not push objects through any openings in this unit, as they may touch dangerous voltage points or short
out parts that could result in fire or electric shock. Never spill or spray any type of liquid into the unit.
19) If an outside antenna or cable system is connected to the unit, be sure the antenna or cable system is
grounded to provide some protection against voltage surges and built-up static charges, Section 810 of
the National Electrical Code, ANSI/NFPA 70, provides information with respect to proper grounding of the
mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding
conductors, location of antenna discharge unit, connection to grounding electrodes, and requirements for
the grounding electrode.
S3126A
PORTABLE CART WARNING
(symbol provided by RETAC)
50H0201A.indd 350H0201A.indd 3 07.8.29 3:25:09 PM07.8.29 3:25:09 PM

IMPORTANT SAFETY INSTRUCTIONS (continued)
20) When replacement parts are required, be sure the service technician uses replacement parts specified by
the manufacturer or those that have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock or other hazards.
21) Upon completion of any service or repairs to this unit, ask the service technician to perform safety checks to
determine that the unit is in proper operating condition.
22) Keep your fingers clear of the disc slot as it is closing. It may cause injury.
23) When you connect the product to other equipment, turn off the power and unplug all of the equipment from
the wall outlet. Failure to do so may cause an electric shock and serious personal injury. Read the owner's
manual of the other equipment carefully and follow the instructions when making any connections.
24) Reduce the volume to the minimum level before you turn on the product. Otherwise, sudden high volume
sound may cause hearing or speaker damage.
25) Do not allow the product to output distorted sound for an extended period of time. It may cause speaker
overheating and fire.
26) When you use the headphones, keep the volume at a moderate level. If you use the headphones
continuously with high volume sound, it may cause hearing damage.
27) Do not look into the opening of the disc slot or ventilation opening of the product to see the source of the
laser beam. It may cause eye damage.
28) Do not use a cracked, deformed, or repaired disc.These discs are easily broken and may cause serious
personal injury and product malfunction.
29) This reminder is provided to call the cable TV system installer’s attention to Article 820-40 of the NEC
that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be
connected to the grounding system of the building, as close to the point of cable entry as practical.
CONDENSATION
Moisture will form in the operating section of the player if the player is brought from cool surroundings into a warm
room or if the temperature of the room rises suddenly. When this happens, player's performance will be impaired.
To prevent this, let the player stand in its new surroundings for about an hour before switching it on, or make sure
that the room temperature rises gradually.
Condensation may also form during the summer if the player is exposed to the breeze from an air conditioner. In
such cases, change the location of the player.
HOW TO HANDLE THE LCD PANEL
Do not press hard or jolt the LCD panel. It may cause the LCD panel glass to break and injury may occur.
If the LCD panel is broken, make absolutely sure that you do not touch the liquid in the panel. This may cause
skin inflammation.
If the liquid gets in your mouth, immediately gargle and consult with your doctor. Also, if the liquid gets in your
eyes or touches your skin, consult with your doctor after rinsing for at least 15 minutes or longer in clean water.
•
•
4
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
ANTENNA LEAD
IN WIRE
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
GROUND
CLAMP
ELECTRIC SERVICE
EQUIPMENT
NEC-NATIONAL ELECTRICAL CODE
S2898A
EXAMPLE OF ANTENNA GROUNDING AS PER THE
NATIONAL ELECTRICAL CODE
50H0201A.indd 450H0201A.indd 4 07.8.29 3:25:10 PM07.8.29 3:25:10 PM

5
The unit emits heat when in operation. Do not place any covers or blankets on the unit, this may cause
overheating. Do not block ventilation holes, or set up near radiators. Do not place in direct sunshine. When
placing on a shelf leave 10 cm (4 inches) free space around the entire unit.
10cm
Notes when mounting the LCD TV/DVD on a wall
• When installing the unit on a wall, allow at least 6 cm (2 1/2 inches) clearance between the rear of the LCD
TV/DVD and the wall. Clearance of less than 6 cm (2 1/2 inches) will obstruct the vents and may cause the
interior of the unit to overheat, resulting in damage to the unit.
• If the unit is to be mounted on the wall, contact the retailer where you purchased the LCD TV/DVD for advice,
and have the equipment professionally installed. Incomplete or improper installation may cause injury to you,
and/or damage to the LCD TV/DVD.
IMPORTANT NOTICE
Possible Adverse Effects on LCD Panel: If a fixed (non-moving) pattern remains on the LCD Panel for
long periods of time, the image can become permanently engrained in the LCD Panel and cause subtle but
permanent ghost images.This type of damage is NOT COVERED BYYOUR WARRANTY. Never leave your
LCD Panel on for long periods of time while it is displaying the following formats or images:
Fixed Images, such as stock tickers, video game patterns, TV station logos, and websites.
Special Formats that do not use the entire screen. For example, viewing letterbox style (16:9) media on
a normal (4:3) display (black bars at top and bottom of screen); or viewing normal style (4:3) media on a
widescreen (16:9) display (black bars on left and right sides of screen).
The following symptoms are not signs of malfunction but technical limitation. Therefore we disclaim
any responsibility for these symptoms.
LCD Panels are manufactured using an extremely high level of precision technology, however sometimes
parts of the screen may be missing picture elements or have luminous spots.
This is not a sign of a malfunction.
Do not install the LCD Panel near electronic equipment that is susceptible to electromagnetic waves. Some
equipment placed too near this unit may cause interference.
Effect on infrared devices – There may be interference while using infrared devices such as infrared cordless
headphones.
•
•
•
•
•
SAFETY PRECAUTIONS
50H0201A.indd 550H0201A.indd 5 07.8.29 3:25:10 PM07.8.29 3:25:10 PM

6
*This product incorporates copyright protection technology that is protected by U.S. patents and other
intellectual property rights. Use of this copyright protection technology must be authorized by Macrovision,
and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision.
Reverse engineering or disassembly is prohibited.
* is a trademark of DVD Format/Logo Licensing Corporation.
*Manufactured under license from Dolby Laboratories.“Dolby” and the double-D symbol are trademarks of
Dolby Laboratories.
* “DTS” and “DTS Digital Out” are registered trademarks of DTS, Inc.
Features
LCD color TV With DVD/CD player
Unique space saving design combines a 26” LCD color TV and a DVD/CD player.
A DVD disc has much more capacity, but is the same size as an audio CD disc.The Picture/Audio quality of a
DVD exceeds other software.The picture quality is higher than Super VHS video cassettes.The audio quality
is higher than an audio CD.The DVD also has special options; audio language selection, subtitle language
selection, or multi-angle, etc.
The DVD PLAYER can play back both audio CDs and MP3/WMA/JPEG CDs.
Compatible with a wide range of DVD audio outputs
Digital Audio Jack (Coaxial)
When a component with a built-in Dolby Digital decoder is connected, Dolby Digital sound can produce the
effect of being in a movie theater or a concert hall.
Surround standard is different from Dolby Digital.This format is already in use in many theaters. By connecting
this unit to a DTS decoder or an AV amplifier with a built-in DTS decoder, the DTS audio of DVD discs
recorded in this format can be enjoyed. However, audio will not be output from the analog audio output jacks.
By connecting this unit to an AV amplifier with a built-in MPEG decoder, the MPEG audio of DVD discs
recorded in this format can be enjoyed.
The Linear PCM sound of a 48 kHz/24 bit through 96 kHz/24 bit exceeds audio CD sound.
Convenience Features
Direct selection of your desired scenes using Title/Chapter/Time/Track -You can play back from the
desired scene.
Recalling Up to 3 Scenes (DVD only) -You can program up to 3 scenes in memory and recall the marked
scenes.
Frame Advance -The PAUSE/STILL moves one frame at a time.
Slow Motion -The SLOW moves you back and forth through the program by 4 steps of 1/7-1/2 times.
Repeat Playback -You can repeat chapter, track, title, sides or material between two selected points.
Program Playback (Audio CD/MP3/WMA CD) -You can play back tracks in programmed sequences.
Zoom (DVD only) -You can zoom in the selected subject on the screen during playback.
Note: Make sure that discs are suitable for the following functions.
Multi-Language -Maximum 32 language subtitles and maximum 8 language soundtracks can be played back
for movies or programs.
Multi-Angle -Pictures of Sports or a Live Concert are recorded with many cameras.When you play such a disc,
you can change the angles during playback.
Parental Control -You can limit the play back of scenes or sounds of DVD discs that have a rating level
encoded on the disc.
Video Aspect Ratio -You can change the aspect ratio of the screen for your monitor.
TV Features
Integrated Digital Tuner -You can view digital broadcasts without using a Digital TV Set-Top Box.
Closed Caption Decoder With Full Text Mode -Displays text captions or full screen text on the screen for
hearing impaired viewers.
Picture Adjustments Using The Remote Control -The On-Screen display allows precise remote control
adjustment of BRIGHTNESS, CONTRAST, COLOR, TINT and SHARPNESS.
Programmable TV Sleep Timer -Operable from the remote control, the TV can be programmed for up to 120
minutes to turn off automatically.
On-Screen 3 Language Display -You can select one of 3 languages, English, Spanish or French for on-
screen programming.
V-Chip -The V-Chip function can read the rating of a TV program or movie content if the program is encoded
with this information.V-chip will allow you to set a restriction level.
•
•
•
•
50H0201A.indd 650H0201A.indd 6 07.8.29 3:25:11 PM07.8.29 3:25:11 PM

7
Contents
Before using your unit
IMPORTANT SAFETY INSTRUCTIONS...........3
SAFETY PRECAUTIONS .................................5
IMPORTANT NOTICE.......................................5
Features............................................................6
Contents ...........................................................7
Disc...................................................................8
Location of controls...........................................9
Remote control ...............................................11
Power source ..................................................12
Antenna connections ......................................13
Cable TV connections.....................................14
TV operation
Setting the language.......................................15
Memorizing channels......................................16
TV operation ...................................................19
Labeling channels...........................................22
Setting the V-Chip ...........................................23
Closed Caption...............................................27
CC advanced..................................................28
Setting the picture size....................................29
Adjusting the picture preference .....................31
Picture control adjustment ..............................31
DNR................................................................32
Selecting the color temperature......................32
Setting the 3D Y/C...........................................33
Selecting Stereo/Second Audio Program
(SAP) ..............................................................34
Sound control adjustment...............................34
Selecting the audio language..........................35
Selecting the digital output..............................35
Checking the Digital-signal strength ...............36
Resetting your settings ...................................36
Picture control adjustment in the Component
and PC mode..................................................37
Playback operation
Preparation .....................................................38
Status display of disc ......................................38
Playback procedure........................................39
Special playback.............................................40
MP3/WMA/JPEG and Audio CD playback......41
Setting the JPEG interval................................43
Advanced function
Program playback (CD)..................................44
Repeat playback (CD).....................................45
Random playback (CD)..................................45
Zooming..........................................................46
Locating desired scene...................................46
Repeat playback.............................................47
Marking desired scenes..................................48
Changing soundtrack language ......................49
Subtitles..........................................................49
Changing angles.............................................50
Title selection..................................................50
DVD menu ......................................................50
Additional information
Setting the language.......................................51
Setting the aspect ratio of TV screen ..............52
Setting on screen display................................52
Setting the picture mode.................................53
Night Mode .....................................................54
Digital Out.......................................................54
Parental control setting ...................................55
Setting the new password...............................56
Temporary disabling of rating level by
DVD disc.........................................................57
Language code list..........................................58
Connections to other equipment.....................59
Reception disturbances ..................................62
Problems and troubleshooting ........................63
Specifications .................................................65
limited WARRANTY ........................................66
50H0201A.indd 750H0201A.indd 7 07.8.29 3:25:11 PM07.8.29 3:25:11 PM

8
Playable discs
Disc type and logo mark content
DVD Video
Audio
+
Video
(moving
pictures)
CD-DA Audio
The following discs are also available.
DVD-R/RW discs of DVD video format.
CD-R/RW discs of MP3/WMA/JPEG.
•
•
Disc
CAUTION:
Only the left types of discs can be played on this
unit. DVD-ROM, CD-ROM, SVCD, CVD, VCD, etc.
cannot be played.
8cm discs can be played directly. If an 8cm disc
adapter is used it will cause errors.
If you insert an irregular shaped disc, it may get
stuck and cause a malfunction.
The use of a ring protector or other disc
accessories will cause errors.
This unit is to be used exclusively with the NTSC
color system. PAL and SECAM system discs cannot
be used with this unit.
Some CD-R/RWs and DVD-R/RW can not be
played back depending on the recording conditions.
•
•
•
•
•
•
Region Number
Region number (Regional restriction code) is built-in to the unit and DVD video discs.
Region number “1” or “ALL” of DVD video discs can be used on this unit.
Title
When two or more movies are recorded on a disc, the disc
is divided into two or more sections. Each section is called
a “TITLE”.
Chapter
The titles can be subdivided into many sections.
Each section is called a “CHAPTER”.
Track
An Audio CD can contain several items.
These are assigned to the tracks.
Removing Disc from Case
Be sure to hold the edge of disc. Do not touch the surface of the disc.
Pick up the disc gently from the case.
Do not scratch the disc.
Do not get dirt on the surface of the disc.
Do not stick a label or adhesive tape on the disc.
Do not drop or bend the disc.
Storing Disc
Store the disc in the case to avoid risk of scratches, dirt or damage.
Do not leave disc exposed to direct sunlight or in hot or humid places.
Cleaning Disc
Wipe the disc with a clean, dry cloth from center to edge.
Do not wipe the disc in a circular motion.
Do not use liquid or aerosol cleaners.
•
•
•
•
•
•
•
•
1ALL
CHAPTER 1
TITLE 1 TITLE 2
DVD DISC
CHAPTER 2 CHAPTER 2 CHAPTER 3CHAPTER 1
TRACK 1 TRACK 2 TRACK 3 TRACK 4 TRACK 5
Audio - CD
50H0201A.indd 850H0201A.indd 8 07.8.29 3:25:12 PM07.8.29 3:25:12 PM

9
Location of controls
To p
Front
To display the menu screen.
Press MENU button to display the menu screen.
CHANNEL ▲/▼buttons and VOLUME +/– buttons can be used to select the desired setting during the menu
screen operations.
POWER button
INPUT button
VOLUME +/– buttons
CHANNEL ▲/▼buttons
MENU button
Remote sensor
POWER indicator
STOP button
SKIP button
EJECT button
PLAY button
50H0201A.indd 950H0201A.indd 9 07.8.29 3:25:13 PM07.8.29 3:25:13 PM

10
Location of controls (continued)
Left side
Right side
DISC slot
COAXIAL DIGITAL
AUDIO OUT jack
AV1 IN jacks
AV2 IN jacks
COMPONENT IN jacks
PC IN jack
PC/HDMI AUDIO IN jack
HDMI IN jack
RF (ANT)IN jack
50H0201A.indd 1050H0201A.indd 10 07.8.29 3:25:13 PM07.8.29 3:25:13 PM

11
Remote control
Page
POWER Power On/Off 15, 19, 38, 39
DISPLAY/– Call TV information 20, 22, 34
Call DVD information 38
Input “–” for digital channels 19
TV/DVD Switch between TV/AV and DVD 15, 19, 38, 39
(EJECT) Eject a disc 39
0-9 Direct channel selection of TV 19
Input setting 46
Enter a password 23~26, 55~57
VOL +/– Adjust volume of TV 19, 20
MUTE Switch off the sound 20
SLEEP Sleep timer 21
SETUP
TV MENU TV mode - Display menu of TV 15~18, 21~29, 31~37
DVD mode - Call up initial setup mode 43, 51~56
DVD MENU Display DVD menu 50
CH /Select channel of TV 20
▲▼◀▶ Cursor buttons
15~18, 21~29, 31~37, 39, 41~46, 48, 50~56
ENTER Enter information in the menu
15~19, 21~29, 31~37, 39, 41~48, 50~57
EXIT
CANCEL Exit from On-Screen menu Reset information in the menu 46, 48, 55, 56
TOP MENU Select title 50
SEARCH Fast Forward/Review playback 40
PLAY Playback 39~42, 44, 45, 47, 50
SKIP Skip chapter to forward or reverse direction 40, 45
SUBTITLE Set subtitle 49
STOP Stop 39, 41, 42
SLOW Forward/Reverse- slow motion 40
PAUSE/STILL Pause CD sound
Still picture of DVD 40
PLAY MODE Select playback mode 47
AUDIO Change sound track language 49
RETURN Remove DVD setup menu 43, 51~55, 57
REPEAT A-B Repeat playback between A and B 47
ANGLE Change playback angle 50
SCREEN SIZE Display PICTURE SIZE menu 29
MARKER Index 48
JUMP Locating desired scene 46
QUICK VIEW Switch between present/last channel 20
ZOOM Zoom 46
INPUT SELECT Display source selection menu 20, 37, 61
50H0201A.indd 1150H0201A.indd 11 07.8.29 3:25:13 PM07.8.29 3:25:13 PM

12
Approximately 15 feet
Inserting Batteries
1Open the battery compartment
cover in the direction of the arrow. 2Install two “AAA” batteries,
paying attention to the
polarity diagram in the battery
compartment.
3Replace the compartment cover.
Operation
Aim the remote control at the remote sensor and press control
buttons to operate.
Operate the remote control within a 30° angle on either side of
the remote sensor, up to a distance of approximately 15 feet.
•
•
Remote control (continued)
NOTE:
Do not leave the remote control unit exposed to direct sunlight or in hot or humid places.
The remote control unit uses infrared beams to transmit signals, so sunlight or fluorescent light on the remote
sensor may shorten operating distance.
Incorrect use of batteries may cause them to leak or burst. Read the battery warnings and use the batteries
properly.
Do not mix old and new batteries.
Remove batteries if the remote control will not be operated for an extended period of time.
•
•
•
•
•
Power source
TO USE AC POWER
Connect the AC cord plug into this unit’s AC IN jack.
Connect the AC cord into an AC outlet.
1.
2.
NOTE:
Please make sure to insert the cord securely at both the LCD TV/DVD and the wall outlet.
The AC Cord has a grounding-type AC line plug. If the supplied AC cord does not match your AC outlet,
contact a qualified electrician, do not defeat the purpose of a grounding plug.
WARNING:
DO NOT CONNECT THIS UNIT TO THE POWER USING ANY DEVICE OTHER THAN THE SUPPLIED AC
CORD.THIS COULD CAUSE FIRE, ELECTRICAL SHOCK, OR DAMAGE.
DO NOT USE WITH A VOLTAGE OTHER THAN THE POWER VOLTAGE DISPLAYED. THIS COULD CAUSE
FIRE, ELECTRICAL SHOCK, OR DAMAGE.
CAUTION:
WHEN THIS UNIT IS NOT USED FOR A LONG TIME, (E.G., AWAY ON A TRIP) IN THE INTEREST OF
SAFETY, BE SURE TO UNPLUG IT FROM THE AC OUTLET.
DO NOT PLUG/UNPLUG THE PLUG WHEN YOUR HANDS ARE WET.THIS MAY CAUSE ELECTRICAL
SHOCK.
IF YOU NEED TO REPLACE THE SUPPLIED AC ADAPTER OR AC CORD, THE SPECIFIED ONE IS
RECOMMENDED. CONTACT CUSTOMER SERVICE AT 1-800-289-0980.
•
•
•
•
•
•
•
AC cord (supplied)
AC 120V, 60Hz
Wider Hole
and Blade
AC Outlet
50H0201A.indd 1250H0201A.indd 12 07.8.29 3:25:14 PM07.8.29 3:25:14 PM

13
If you are using an indoor or outdoor antenna, follow the instructions below that correspond to your
antenna system. If you are using a Cable TV service, see page 15 for Cable TV connections.
Combination VHF/UHF Antenna (Separate VHF and UHF 300 ohm twin-lead wires)
Combination VHF/UHF Antenna (Single 75 ohm cable or 300 ohm twin-lead wire)
Antenna connections
Separate VHF/UHF Antennas (75 ohm VHF cable and 300 ohm UHF twin-lead wires)
Connect the 75 ohm cable from the combination
VHF/UHF antenna to the antenna jack.
If your combination VHF/UHF antenna has a 300
ohm twin-lead wire, the use of the 300-75 ohm
matching transformer may be necessary.
Connect the UHF 300 ohm twin-lead wire to
the Combiner (not supplied). Connect the VHF
300 ohm twin-lead wire to the 300-75 ohm
Matching Transformer. Attach the Transformer to
the Combiner, then attach the Combiner to the
Antenna Jack.
Connect the VHF 75 ohm cable and UHF
300 ohm twin-lead wire to the Combiner (not
supplied). Attach the Combiner to the Antenna
Jack.
75 ohms
coaxial
cable
300-75 ohms
matching
transformer
Antenna
jack Antenna
jack
300-75 ohms
matching
transformer
UHF 300 ohms
VHF 300 ohms
Antenna
jack
Combiner
UHF 300 ohms
VHF 75 ohms
Antenna
jack
Combiner
50H0201A.indd 1350H0201A.indd 13 07.8.29 3:25:15 PM07.8.29 3:25:15 PM

14
For basic Cable TV service not requiring a Converter/
Descrambler box, connect the 75 ohm Coaxial Cable directly
to the Antenna Jack on the back of the TV/DVD.
Cable TV connections
FOR SUBSCRIBERS TO SCRAMBLED CABLE TV SERVICE
If you subscribe to a Cable TV service which requires the use of a Converter/Descrambler box, connect the
incoming 75 ohm Coaxial Cable to the Converter/Descrambler box. Using another 75 ohm Coaxial Cable,
connect the output jack of the Converter/Descrambler box to the Antenna Jack on the TV/DVD. Follow the
connections shown below. Set the TV/DVD to the output channel of the Converter/Descrambler box (usually
channel 3 or 4) and use the Converter/Descrambler box to select channels.
FOR SUBSCRIBERS TO UNSCRAMBLED BASIC CABLE TV SERVICE WITH
SCRAMBLED PREMIUM CHANNELS
If you subscribe to a Cable TV service in which basic channels are unscrambled and premium channels require
the use of a Converter/Descrambler box, you may wish to use a signal Splitter and an A/B Switch box (available
from the Cable TV company or an electronics supply store). Follow the connections shown below. With the
switch in the “B” position, you can directly tune any nonscrambled channels on your TV/DVD. With the switch in
the “A” position, tune your TV/DVD to the output of the Converter/Descrambler box (usually channel 3 or 4) and
use the Converter/Descrambler box to tune scrambled channels.
Splitter B
A
Incoming
75 ohm
Cable TV
Cable A/B Switch
75 ohm Cable
to TV/DVD
Incoming
75 ohm
Cable TV
Cable
75 ohm Cable
to TV/DVD
Converter/
Descrambler
Antenna
Jack
Antenna
Jack
Converter/
Descrambler
This TV/DVD has an extended tuning range and can tune most cable channels without using a
Cable TV Converter box. Some cable companies offer “premium pay channels” where the signal is
scrambled. Descrambling these signals for normal viewing requires the use of a descrambler device
which is generally provided by the Cable TV company.
FOR SUBSCRIBERS TO BASIC CABLE TV SERVICE
75 ohms
coaxial cable
Antenna
jack
50H0201A.indd 1450H0201A.indd 14 07.8.29 3:25:15 PM07.8.29 3:25:15 PM

15
Setting the language
You can choose from three different
languages (English, French and
Spanish) for the on-screen displays.
Select the language you prefer first,
then proceed with the other menu
options.
NOTE:
If no buttons are pressed for more
than about 30 seconds, the MENU
screen will return to normal operation
automatically.
On this TV, there are setting menus for
each external input.You can change
the settings to fit your needs.
(Some settings are commoditized.
I.e., Audio settings, Parental control,
NTSC CC, ATSC CC and Digital
Closed Caption settings are applied
to all external inputs.)
•
•
1To turn on the TV, press POWER.
(POWER indicator on the front of the unit blinks while starting.
It may take approx. 15 seconds for a picture to appear on
screen.)
2Press TV/DVD to select TV mode.
3Press SETUP/TV MENU.The menu screen will appear.
4Press ▲or ▼to select
“Setup” menu, then press
▶.
Setup
Audio
Feature
Tuning Band
DTV Signal
Auto Ch Search
Add On Ch Search
Manual Ch Set
Channel Labels
Menu Language
Reset
Cable
English
To M o v e To Select To E x i t
Enter Menu
5Press ▲or ▼to select
“Menu Language”.
Setup
Audio
Feature
Tuning Band
DTV Signal
Auto Ch Search
Add On Ch Search
Manual Ch Set
Channel Labels
Menu Language
Reset
Cable
English
To M o v e To S e l e c t To E x i t
Enter Menu
6Press ▶or ENTER to select the desired language: English
(ENGLISH), French (FRANÇAIS) or Spanish (ESPAÑOL).
7Press SETUP/TV MENU to return to the normal screen.
50H0201A.indd 1550H0201A.indd 15 07.8.29 3:25:16 PM07.8.29 3:25:16 PM

16
This TV is equipped with a channel memory feature which allows channels to skip up or down to the
next channel set into memory, skipping over unwanted channels. Before selecting channels, they
must be programmed into the TV’s memory. To use this TV with an antenna, set the Tuning Band menu
option to the Air mode. When shipped from the factory, this menu option is in the Cable mode.
Air/Cable selection
1Press SETUP/TV MENU in the TV mode.The menu screen will
appear.
2Press ▲or ▼to select
“Setup” menu, then press
▶.
Setup
Audio
Feature
Tuning Band
DTV Signal
Auto Ch Search
Add On Ch Search
Manual Ch Set
Channel Labels
Menu Language
Reset
Cable
English
To M o v e To S e l e c t To E x i t
Enter Menu
3Press ▲or ▼to select
“Tuning Band”.
Setup
Audio
Feature
Tuning Band
DTV Signal
Auto Ch Search
Add On Ch Search
Manual Ch Set
Channel Labels
Menu Language
Reset
Cable
English
To M o v e To S e l e c t To E x i t
Enter Menu
4Press ▶or ENTER to
select “Air” or “Cable”.
Air - VHF/UHF channels
Cable - CABLE TV channels
Setup
Audio
Feature
Tuning Band
DTV Signal
Auto Ch Search
Add On Ch Search
Manual Ch Set
Channel Labels
Menu Language
Reset
Air
English
To M o v e To S e l e c t To E x i t
Enter Menu
5Press SETUP/TV MENU to return to the normal screen.
CABLE CHART
The chart below is typical of many cable system channel
allocations.
Memorizing channels
NOTE:
It may take a few seconds for a digital
channel picture to appear on screen
after being selected.
•
50H0201A.indd 1650H0201A.indd 16 07.8.29 3:25:17 PM07.8.29 3:25:17 PM

17
Automatic channel search
1Press SETUP/TV MENU in the TV mode.The menu screen will
appear.
2Press ▲or ▼to select
“Setup” menu, then press
▶.
Press ▲or ▼to select
“Auto Ch Search”.
Setup
Audio
Feature
Tuning Band
DTV Signal
Auto Ch Search
Add On Ch Search
Manual Ch Set
Channel Labels
Menu Language
Reset
Cable
English
To M o v e To S e l e c t To E x i t
Enter Menu
3Press ▶or ENTER.The
TV will begin memorizing
all the channels available
in your area.
Cable Channel 55 Scanning
Analog Channels Found 12
Digital Channels Found 0
Progress (%) 39
Autoprogram Menu
To M o v e To S e l e c t To E x i t
Enter Menu
It may take from 15 minutes to 30 minutes to complete
memorizing digital cable channels.
Depending on the reception condition, a BAR display may
not advance for several minutes, please be patient.
•
•
Add on channel search
This feature searches only blank, unregistered channels.
1Press SETUP/TV MENU in the TV mode.The menu screen will
appear.
2Press ▲or ▼to select
“Setup” menu, then press
▶.
Press ▲or ▼to select
“Add On Ch Search”.
Setup
Audio
Feature
Tuning Band
DTV Signal
Auto Ch Search
Add On Ch Search
Manual Ch Set
Channel Labels
Menu Language
Reset
Cable
English
To M o v e To S e l e c t To E x i t
Enter Menu
3Press ▶or ENTER.The
TV will begin searching
only blank, unregistered
channels.
Cable Channel 44 Scanning
Analog Channels Found 1
Digital Channels Found 0
Progress (%) 16
Add On Autoprogram Menu
To M o v e To S e l e c t To E x i t
Enter Menu
It may take from 15 minutes to 30 minutes to complete
memorizing digital cable channels.
Depending on the reception condition, a BAR display may
not advance for several minutes, please be patient.
•
•
Memorizing channels
NOTE:
Memorizing channels is best
accomplished during evening
“PRIMETIME” hours, as more stations
are broadcasting digital signals.
Memorizing channels can only be
accomplished while a station is
broadcasting a digital signal to set
that channel into memory.
If you are unsure of the digital
channels available in your area, you
may visit www.antennaweb.org to
receive a list based on your address
or zip code. Should you require further
assistance you may call our toll-free
customer service line at 1-800-289-
0980.
New digital channels may be
added to your area periodically, it is
recommended to perform the “Add On
Ch Search” procedure regularly.
•
•
•
50H0201A.indd 1750H0201A.indd 17 07.8.29 3:25:18 PM07.8.29 3:25:18 PM

18
Memorizing channels
Manual Ch Set
You can select the channel that you want to skip.
1Press SETUP/TV MENU in the TV mode.The menu screen will
appear.
2Press ▲or ▼to select
“Setup” menu, then press
▶.
Press ▲or ▼to select
“Manual Ch Set”, then
press ▶or ENTER.
Manual Ch Set menu will
appear.
Setup
Audio
Feature
Tuning Band
DTV Signal
Auto Ch Search
Add On Ch Search
Manual Ch Set
Channel Labels
Menu Language
Reset
Cable
English
To M o v e To S e l e c t To E x i t
Enter Menu
3Press ▲or ▼to select
the channel that you
want to skip, then press
ENTER.
Manual Channel Set Menu
Ch 7-0 Viewable
Ch 7-0 Viewable
Ch 11-0 Viewable
Ch 12-0 Viewable
Ch 22-0 Viewable
Ch 23-0 Viewable
Ch 23-1 CH-1 Viewable
Ch 23-2 CH-2 Viewable
Ch 23-3 CH-3 Viewable
Ch 23-4 CH-4 Viewable
Ch 23-77 CH-77 Viewable
Ch 23-999 CH-999 Viewable
To M o v e To S e l e c t To E x i t
Enter Menu
4Press SETUP/TV MENU to return to the normal screen.
50H0201A.indd 1850H0201A.indd 18 07.8.29 3:25:19 PM07.8.29 3:25:19 PM

19
TV operation
NOTE:
If a channel with no broadcast is
selected, the sound will automatically
be muted.
It may take a few seconds for a digital
channel picture to appear on screen
after being selected.
•
•
1To turn on the TV, press POWER.
(POWER indicator on the front of the unit blinks while starting.
It
may take approx. 15 seconds for a picture to appear on screen.)
Press TV/DVD to select TV mode.
2Adjust the volume level
by pressing VOL + or –.
The volume level will be
indicated on the screen
by white bars. As the
volume level increases,
so do the number of bars.
If the volume decreases,
the number of white
bars also decreases.
Volum e 14
3Set the Tuning Band
option to the appropriate
position (see page 16).
Air -VHF/UHF channels
Cable -CABLE TV channels
4Press the Direct
Channel Selection
(0-9, –)buttons to select
the channel, then press
ENTER. (If you press
only channel number,
channel selection will
be delayed for a few
seconds.)
Ch 9
TO SELECT ANALOG CHANNELS
1-9: Press 1-9 as needed. Example, to select channel 2,
press 2.
10-99: Press the 2 digits in order. Example, to select
channel 12, press 1,2.
100-135: Press the 3 digits in order. Example, to select
channel 120, press 1,2,0.
TO SELECT DIGITAL CHANNELS
Press the first 3 digits, then press the –button, followed by the
remaining number.
Example, to select channel 015-001, press 0,1,5,–,1.
If a channel is selected with only audio content, “Audio only”
will be displayed on the screen.
If a channel is selected with a weak digital signal, “Digital
channel signal strength is low” will be displayed on the screen.
If the digital channel has the same analog channel, you way
be able to watch the same channel with analog.
If a channel is selected to which you have not subscribed,
“Digital channel is encrypted” will be displayed on the screen.
•
•
•
VHF/UHF/CABLE CHANNELS
Air Cable
VHF
2-13 VHF 2-13
UHF
14-69 STD/HRC/IRC
14-36 (A) (W)
37-59 (AA) (WW)
60-85 (AAA) (ZZZ)
86-94 (86) (94)
95-99 (A-5) (A-1)
100-135 (100) (135)
01 (5A)
50H0201A.indd 1950H0201A.indd 19 07.8.29 3:25:20 PM07.8.29 3:25:20 PM

20
NOTE:
The TV is capable of holding a still
video image or On screen display
image on your TV screen indefinitely.
If you leave the still video image or
On screen display image displayed
on your TV for an extended period of
time, you risk permanent damage to
your TV screen.
When the TV receives an analog
signal, DISPLAY shows only analog
information.
After 4 seconds, DISPLAY screen
will return to normal TV-operation
automatically.
•
•
•
TV operation
To select the video input source
Press INPUT SELECT to view a signal from another device
connected to your LCD TV, such as a VCR or DVD player.You can
select ANT, Composite 1, Composite 2, S-Video, Component,
HDMI-DVI or PC depending on which input jacks you used to
connect your devices.
CH /
Press and release CH /.The
channel automatically stops at the
next channel set into memory.
For proper operation, before
selecting channels, they should be
set into the memory. See pages 16
and 17 “Memorizing channels”.
Ch 9
DISPLAY
Press DISPLAY to display the current information on the screen.
When the TV receives a digital
signal, the digital information will
appear.
Channel number
Broadcast program name
Station name
Program guide
V-CHIP RATING
•
•
•
•
•
Ch 15
Monscope_480i_1
720x480 I 30Hz TV-G
Monscope_480i_1_ABCDEFGHLIJKLMNOPQRST....
ABCDEFGHLIJKLMNOPQRSTUVWXYZabcdefghi....
When the TV receives a analog
signal, the analog information will
appear.
Channel number or VIDEO mode
selected
Channel label (if preset)
Stereo or SAP (second audio
program) audio status
Content rating
•
•
•
•
Ch 12 ABCDEFG
No Program Information is Available
720x480 I 30Hz TV-14VSLD SAP
Press DISPLAY again to clear the call display.
QUICK VIEW
This button allows you to go back
to the last channel selected by
pressing QUICK VIEW. Press
QUICK VIEW again to return to the
last channel you were watching.
Ch 8
MUTE
Press MUTE to switch off the sound.
The TV’s sound will be silenced
and “Mute” will briefly appear on the
screen.The sound can be switched
back on by pressing this button
again or the VOL + or –.
Mute
50H0201A.indd 2050H0201A.indd 20 07.8.29 3:25:20 PM07.8.29 3:25:20 PM
