Sansui LCDVD200 User manual

20” TFT LCD TV WITH DVD PLAYER
LCDVD200
OWNER’S MANUAL
Before operating the unit, please read this manual thoroughly.
TV/CATV MODE SELECTION
When shipped from the factory, the TV/CATV menu option is set to the "CATV" (Cable Television) mode.
If not using CATV, set this menu option to the "TV" position.
ORION WEBSITE
FOR INFORMATION ON OUR OTHER PRODUCTS,
PLEASE VISIT OUR WEBSITE AT
www.orionsalesinc.com
R
5M80201A E Cover 1/11/05, 9:35 AM1

2
CAUTION:
THIS DIGITAL VIDEO PLAYER EMPLOYS ALASER SYSTEM.
TO ENSURE PROPER USE OF THIS PRODUCT, PLEASE
READ THIS OWNER'S MANUAL CAREFULLY AND RETAIN
FOR FUTURE REFERENCE. SHOULD THE UNIT REQUIRE
MAINTENANCE, CONTACT AN AUTHORIZED SERVICE LO-
CATION-SEE SERVICE PROCEDURE.
USE OF CONTROLS, ADJUSTMENTS OR THE PERFORM-
ANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED
HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPO-
SURE.
TOPREVENTDIRECTEXPOSURETOLASERBEAM, DO NOT
TRY TO OPEN THE ENCLOSURE. VISIBLE LASER RADIA-
TIONMAYBEPRESENTWHENTHEENCLOSUREIS OPENED.
DO NOT STARE INTO BEAM.
Location of the required Marking
The rating sheet and the safety caution
are on the rear of the unit.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
The lightning flash with arrowhead
symbol, within an equilateral triangle is
intended to alert the user to the
presence of uninsulated dangerous
voltage within the product's
enclosure that may be of sufficient mag-
nitudeto constituteariskof electricshock.
The exclamation point within an
equilateral triangle is intended to alert
the user to the presence of important
operating and maintenance (servicing)
instructions in the literature accompa-
nying the appliance.
CAUTION:TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICINGTO
QUALIFIEDSERVICE PERSONNEL.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THISAPPLIANCE TO RAIN
ORMOISTURE.
WARNING: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
CAUTION: Changes or modifications not expressly approved by the partly responsible for compliance with
the FCC Rules could void the user's authority to operate this equipment.
CERTIFICATION: COMPLIES WITH FDA
RADIATION PERFORMANCE STANDARDS,
21 CFR SUBCHAPTER J.
5M80201A E P02-05 1/11/05, 9:35 AM2

3
IMPORTANT SAFEGUARDS
1. READ INSTRUCTIONS
All the safety and operating instructions should be read before the unit is operated.
2. RETAIN INSTRUCTIONS
The safety and operating instructions should be retained for future reference.
3. HEED WARNINGS
All warnings on the unit and in the operating instructions should be adhered to.
4. FOLLOW INSTRUCTIONS
All operating and use instructions should be followed.
5. CLEANING
Unplug this unit from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners.
Use a damp cloth for cleaning the exterior cabinet only.
6. ATTACHMENTS
The manufacturer of this unit does not make any recommendations for attachments, as they may cause
hazards.
7. WATER AND MOISTURE
Do not use this unit near water. For example, near a bathtub, washbowl, kitchen sink, laundry tub, in a wet
basement, or near a swimming pool.
8. ACCESSORIES
Do not place this unit on an unstable cart, stand, tripod, bracket, or table.
The unit may fall, causing serious injury, and serious damage to the unit.
8A. An appliance and cart combination should be moved with care. Quick stops,
excessive force, and uneven surfaces may cause the appliance and cart
combination to overturn.
9. VENTILATION
Slots and openings in the cabinet back or bottom are provided for ventilation,
and to ensure reliable operation of the unit, and to protect it from overheating.
These openings must not be blocked or covered. The openings should never be blocked by placing the unit
on a bed, sofa, rug, or other similar surface. This unit should never be placed near or over a radiator or heat
source. This unit should not be placed in a built-in installations such as a bookcase or rack unless proper
ventilation is provided or the manufacturer’s instructions have been adhered to.
10. POWER SOURCES
This unit should be operated only from the type of power source indicated on the rating plate. If you are not
sure of the type of power supply to your home, consult your appliance dealer or local power company. For
units intended to operate from battery power, or other sources, refer to the operating instructions.
11. GROUNDING OR POLARIZATION
This unit is equipped with a polarized alternating-current line plug (a plug having one blade wider than the
other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert
the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to
replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug, if your unit is equipped
with a 3-wire grounding-type plug, a plug having a third (grounding) pin. This plug will only fit into a ground-
ing-type power outlet. This too, is a safety feature. If you are unable to insert the plug into the outlet, contact
your electrician to replace your obsolete outlet.
Do not defeat the safety purpose of the grounding-type plug.
S3126A
PORTABLE CART WARNING
(symbol provided by RETAC)
5M80201A E P02-05 1/11/05, 9:35 AM3

4
IMPORTANT SAFEGUARDS (Continued)
12. POWER-CORD PROTECTION
Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed
upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point
where they exit from the appliance.
13. LIGHTNING
To protect your unit from a lightning storm, or when it is left unattended and unused for long periods of time,
unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the
unit due to lightning and power line surges.
14. POWER LINES
An outside antenna system should not be located in the vicinity of overhead power lines or other electric
light or power circuits, or where it can fall into such power lines or circuits. When installing an outside
antenna system, extreme care should be taken to keep from touching such power lines or circuits, as
contact with them might be fatal.
15. OVERLOADING
Do not overload wall outlets and extension cords, as this can result in a risk of fire or electric shock.
16. OBJECT AND LIQUID ENTRY
Do not push objects through any openings in this unit, as they may touch dangerous voltage points or short
out parts that could result in fire or electric shock. Never spill or spray any type of liquid into the unit.
17. OUTDOOR ANTENNA GROUNDING
If an outside antenna or cable system is connected to the unit, be sure the antenna or cable system is
grounded to provide some protection against voltage surges and built-up static charges, Section 810 of the
National Electrical Code, ANSI/NFPA 70, provides information with respect to proper grounding of the mast
and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding
conductors, location of antenna discharge unit, connection to grounding electrodes, and requirements for
the grounding electrode.
18. SERVICING
Do not attempt to service this unit yourself as opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified service personnel.
19. DAMAGE REQUIRING SERVICE
Unplug this unit from the wall outlet and refer servicing to qualified service personnel under the following
conditions:
a. When the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the unit.
c . If the unit has been exposed to rain or water.
d. If the unit does not operate normally by following the operating instructions. Adjust only those
controls that are covered by the operating instructions, as an improper adjustment of other controls
may result in damage and will often require extensive work by a qualified technician to restore the
unit to its normal operation.
e. If the unit has been dropped or the cabinet has been damaged.
f. When the unit exhibits a distinct change in performance, this indicates a need for service.
20. REPLACEMENT PARTS
When replacement parts are required, be sure the service technician uses replacement parts specified by
the manufacturer or those that have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock or other hazards.
21. SAFETY CHECK
Upon completion of any service or repairs to this unit, ask the service technician to perform safety checks to
determine that the unit is in proper operating condition.
22. HEAT
The product should be situated away from heat sources such as radiators, heat registers, stoves, or other
products (including amplifiers) that produce heat.
23. DISC TRAY
Keep your fingers clear of the disc tray as it is closing. It may cause injury.
24. CONNECTING
When you connect the product to other equipment, turn off the power and unplug all of the equipment from
the wall outlet. Failure to do so may cause an electric shock and serious personal injury. Read the owner's
manual of the other equipment carefully and follow the instructions when making any connections.
25. SOUND VOLUME
Reduce the volume to the minimum level before you turn on the product. Otherwise, sudden high volume
sound may cause hearing or speaker damage.
5M80201A E P02-05 1/11/05, 9:35 AM4

5
EXAMPLE OF ANTENNA GROUNDING AS PER THE
NATIONAL ELECTRICAL CODE
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
ANTENNA LEAD
IN WIRE
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
GROUND
CLAMP
ELECTRIC SERVICE
EQUIPMENT
NEC-NATIONAL ELECTRICAL CODE
S2898A
26. SOUND DISTORTION
Do not allow the product to output distorted sound for an extended period of time. It may cause speaker
overheating and fire.
27. HEADPHONES
When you use the headphones, keep the volume at a moderate level. If you use the headphones continu-
ously with high volume sound, it may cause hearing damage.
28. LASER BEAM
Do not look into the opening of the disc tray or ventilation opening of the product to see the source of the
laser beam. It may cause eye damage.
29. DISC
Do not use a cracked, deformed, or repaired disc. These discs are easily broken and may cause serious
personal injury and product malfunction.
30. NOTE TO CATV SYSTEM INSTALLER
This reminder is provided to call the CATV system installer’s attention toArticle 820-40 of the NEC that
provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be con-
nected to the grounding system of the building, as close to the point of cable entry as practical.
HOW TO HANDLE THE LCD PANEL
•Do not press hard or jolt the LCD panel. It may cause the LCD panel glass to break and injury may occur.
• If the LCD panel is broken, make absolutely sure that you do not touch the liquid in the panel. This may
cause skin inflammation.
If the liquid gets in your mouth, immediately gargle and consult with your doctor. Also, if the liquid gets in
your eyes or touches your skin, consult with your doctor after rinsing for at least 15 minutes or longer in clean
water.
CONDENSATION
Moisture will form in the operating section of the player if the player is brought from cool surroundings into a
warm room or if the temperature of the room rises suddenly. When this happens, player's performance will
be impaired.
To prevent this, let the player stand in its new surroundings for about an hour before switching it on, or
make sure that the room temperature rises gradually.
Condensation may also form during the summer if the player is exposed to the breeze from an air condi-
tioner. In such cases, change the location of the player.
5M80201A E P02-05 1/11/05, 9:35 AM5

6
Features
LCD color TV With DVD/CD player
Unique space saving design combines a 20” LCD color TV and a DVD/CD player.
The DVD disc has much more capacity, but is the same size as the audio CD disc. Picture/Audio quality of the
DVD exceeds other software. Picture quality is higher than Super VHS.Audio quality is higher than audio CD. The
DVD also has special options; audio language selection, subtitle language selection or multi-angle, etc.
The DVD PLAYER can play back audio CDs and MP3 CDs.
Compatible with a wide range of DVD audio outputs
Digital Audio Jack (Coaxial)
• When a component with a built-in Dolby Digital decoder is connected, Dolby Digital sound can produce the effect
of being in a movie theatre or a concert hall.
• Surround standard different from Dolby Digital.This format is already in use in many theatres. By connecting this
unit to a DTS decoder or anAV amplifier with a built-in DTS decoder, the DTS audio of DVD discs recorded in this
format can be enjoyed. However, audio will not be output from the analog audio output jacks.
• By connecting this unit to anAV amplifier with a built-in MPEG decoder, the MPEG audio of DVD discs recorded
in this format can be enjoyed.
• The Linear PCM sound of a 48 kHz/24 bit through 96 kHz/24 bit exceeds audio CD sound.
Convenience Features
Direct selection of your desired scenes using Title/Chapter/Time/Track - You can play back from the desired
scene.
Recalling Up to 3 Scenes (DVD only) -You can program up to 3 scenes in memory and recall the marked scenes.
Frame Advance -The PAUSE/STILL moves one frame at a time.
Slow Motion -The SLOW moves you back and forth through the program by 4 steps of 1/8-1/2 times.
Repeat Playback -You can repeat chapter, track, title, sides or material between two selected points.
Program Playback (Audio CD/MP3 CD) -You can play back tracks in programmed sequences.
Zoom (DVD only) -You can zoom in the selected subject on the screen during playback.
Note: Make sure that discs are suitable for the following functions.
Multi-Language -Maximum 32 language subtitles and maximum 8 language soundtracks can be played back for
movies or programes.
Multi-Angle -Pictures of Sports or a Live Concert are recorded with many cameras. When you play such a disc,
you can change the angles during playback.
Parental Control - You can limit the play back of scenes or sounds of adult DVD discs which have parental level.
Video Aspect Ratio - You can change the aspect ratio of the screen for your monitor.
TV Features
181 Channel Tuner - Receives standard VHF and UHF broadcast channels and up to 113 cable channels. The
actual number of channels received depends upon channel reception in your area or your cable system.
Closed Caption Decoder With Full Text Mode - Displays text captions or full screen text on the screen for
hearing impaired viewers.
Picture Adjustments Using The Remote Control - The On-Screen display allows precise remote control adjust-
ment of BRIGHTNESS, CONTRAST, COLOR, TINT and SHARPNESS.
Programmable TV Sleep Timer - Operable from the remote control, the TV can be programmed up to 120
minutes to turn off automatically.
On-Screen 3 Language Display - You can select one of 3 languages, English, Spanish or French for on-
screen programming.
V-Chip - The V-Chip function can read the rating of a TV program or movie content if the program is encoded
with this information. V-chip will allow you to set a restriction level.
This product incorporates copyright protection technology that is protected by method claims of certain U.S.
patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use
of this copyright protection technology must be authorized by Macrovision Corporation and is intended for
home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse
engineering or disassembly is prohibited.
5M80201A E P06-13 1/11/05, 9:35 AM6

7
Contents
IMPORTANT SAFEGUARDS .............................................. 3
Features ............................................................................... 6
Contents............................................................................... 7
Disc ...................................................................................... 8
Location of controls .............................................................. 9
Remote control................................................................... 11
To bundle the connected cable .......................................... 12
Power source ..................................................................... 13
Antenna connections.......................................................... 14
Cable TV connections ........................................................ 15
Before using your unit
Preparation/Status display of disc...................................... 28
Playback procedure ........................................................... 29
Special playback ................................................................ 30
MP3 playback..................................................................... 31
Playback operation
Advanced Function
Additional Information
Setting the on screen display language ............................. 16
TV operation....................................................................... 17
Closed caption ................................................................... 19
To memorize channels ....................................................... 20
Setting the V-Chip .............................................................. 22
Picture control adjustment..................................................25
Stereo and second audio program (SAP) .......................... 26
Sound control adjustment .................................................. 27
TV operation
Zooming/Locating desired scene ....................................... 32
Repeat/Random/Program playback and Repeat A-B......... 33
Marking desired scenes ......................... ........................... 34
Changing soundtrack language/Subtitles .......................... 35
Changing angles/Title selection/DVD menu....................... 36
Picture and sound control adjustment in the DVD mode ... 37
Setting language ................................................................ 38
Setting the aspect ratio of TV screen/
Setting on screen display ................................................... 39
Dynamic Range Control .....................................................40
Parental control setting ..................................................... 41
To change the parental level .............................................. 42
Temporary disabling of rating level by DVD disc................ 43
Language code list ............................................................. 44
Connections to other equipment ........................................ 45
Reception disturbances...................................................... 47
Problems and troubleshooting ............................................. 48
Specifications ..................................................................... 50
Warranty............................................................................. 51
5M80201A E P06-13 1/11/05, 9:35 AM7

8
Playable discs
CAUTION:
•Only the above types of discs can be played on this unit.
DVD-ROM, CD-ROM, SVCD, CVD, VCD, etc. cannot be
played.
•When you play an 8cm disc, please assemble it with an
off-the-shelf disc adapter before you insert it into the unit.
•This unit is to be used exclusively with the NTSC color
system. PAL and SECAM system discs cannot be used
with this unit.
•Some CD-R/RWs can not be played back depending on
the recording conditions.
You cannot play discs like the following:
•Irregularshapeddiscssuch ascardshaped,heartshaped
•Stickered or papered discs
• Discs with scotch tape, glue or other remains of labels
Region Number
Region number (Regional restriction code) is built-in to the unit and DVD video discs.
Region number “1” or “ALL” of DVD video discs can be used on this unit.
Title/Chapter/Track
Title
When two or more movies are recorded on a disc,
the disc is divided into two or more sections.
Each section is called a “TITLE”.
Chapter
The titles can be subdivided into many sections.
Each section is called a “CHAPTER”.
Track
An Audio CD can contain several items.
These are assigned to the tracks.
Removing Disc from Case
Be sure to hold the edge of disc. Do not touch the surface of the disc.
Pick up the disc gently from the case.
• Do not scratch the disc.
• Do not get dirt on the surface of the disc.
• Do not stick a label or adhesive tape on the disc.
• Do not drop or bend the disc.
Storing Disc
• Store the disc in the case to avoid risk of scratches, dirt or damage.
• Do not leave disc exposed to direct sunlight or in hot or humid places.
Cleaning Disc
Wipe the disc with a clean, dry cloth from center to edge.
• Do not wipe the disc in a circular motion.
• Do not use liquid or aerosol cleaners.
Disc
TRACK 1 TRACK 2 TRACK 3 TRACK 4 TRACK 5
CD
CHAPTER 1
TITLE1 TITLE2
DVD DISC
CHAPTER 2 CHAPTER 2 CHAPTER 3CHAPTER 1
1
ALL
DVD Video
CD-DA
content
Audio
+
Video
(moving
pictures)
Audio
Disc type and logo mark
CD-R/
CD-RW Audio/
MP3 file
Recordable
ReWritable
5M80201A E P06-13 1/11/05, 9:35 AM8

9
Location of controls
Headphones jack
AUDIO (L/R)/VIDEO IN
(LINE 2 IN) jacks
PLAY button
STOP button
5(EJECT) button
SKIP buttons
Left Side Right Side
DISC slot
POWER indicator
Remote sensor
Front
POWER button
VOLUME UP/DOWN buttons
CHANNEL UP/DOWN buttons
Top
5M80201A E P06-13 1/11/05, 9:35 AM9

10
Location of controls (continued)
Rear
Cable holder
Approx. 15˚ Approx. 5˚0˚
Variable TV-screen angle
You can adjust the angle of
the TV-screen for 5˚ forward
or for 15˚ backward from
vertical angle.
AUDIO (L/R)/VIDEO
IN (LINE 1 IN) jacks
COAXIAL
DIGITALAUDIO
OUT jack RF IN jack
S-VIDEO IN jack
5M80201A E P06-13 1/11/05, 9:35 AM10

11
Remote control
Page
POWER Power On/Off 16,17,28,29,31
DISPLAY/CALL Call TV information 18
Call DVD information 28
TV/DVD Switch between TV/AV and DVD 28,29,37~42
5(EJECT) Eject a disc 29,31,43
0-9 Direct channel selection of TV 17,21
Input setting 31~33
Enter a password 22,24,41~43
VOL +/– Adjust volume of TV 17,18
MUTE Switch off the sound 18
SLEEP Sleep timer 18
SETUP/TV MENU
TV mode - Display menu of TV 16,20~25,27
DVD mode - Call up initial setup mode 37~42
DVD MENU Display DVD menu 36
CH / Select channel of TV 18,21
Cursor buttons 16,20~25,27,29,31,32,34,
36~42
SELECT/ENTER Enter information in the menu 16,22,24,29,31~34,
36,38~43
CANCEL Reset information in the menu 22,24,25,27,
32~34,41
TOP MENU Select title 36
SEARCH Fast Forward/Review playback 30
PLAY Playback 29~31,33,36
SKIP Skip chapter to forward or reverse 30
direction
SUB TITLE Set subtitle 35
STOP Stop 29,31,33
SLOW Forward/Reverse- slow motion 30
PAUSE/STILL Pause CD sound 30
Still picture of DVD
PLAY MODE Select playback mode 33
RETURN Remove DVD setup menu 38~43
REPEATA-B Repeat playback between A and B 33
ANGLE Change playback angle 36
AUDIO Switch the sound of TV 26
Change sound track language 35
MARKER Index 34
JUMP Locating desired scene 32
TV/CAP/TEXT Switch between TV/Caption/Text in Closed
Caption mode 19
QUICK VIEW/ZOOM Switch between present/last channel 18
Zoom 32
FREEZE Make a freeze framed picture 18
INPUT SELECT Switch between TV/AV 46
5M80201A E P06-13 1/11/05, 9:35 AM11

12
Inserting Batteries
12 3
Operation
•Aim the remote control at the remote sensor and
press control buttons to operate.
•Operate the remote control within 30°angle on
either side of the remote sensor, up to a dis-
tance ofApprox. 5 meters.
Do not leave the remote control unit exposed to direct sunlight or in hot or humid places.
The remote control unit uses infrared beams to transmit signals, so sunlight or fluorescent light on the remote
sensor may shorten operating distance.
Incorrect use of batteries may cause them to leak or burst. Read the battery warnings and use the batteries
properly.
Do not mix old and new batteries.
Remove batteries if the remote control will not be operated for an extended period of time.
Approx. 5 meters
Remote control (continued)
NOTES:
•
•
•
•
•
To bundle the connected cable
Replace the compartment
cover.
Install two "AAA" batteries
(supplied), paying attention to
the polarity diagram in the
battery compartment.
Open the battery compartment
cover in the direction of the
arrow.
You can bundle the connected cables as follows.
1While pressing on both sides of
the clip, remove it from the unit
while pulling with an upward
motion.
2Gather up the cables
between the holes of the
cable holder. 3Replace the holder.
5M80201A E P06-13 1/11/05, 9:35 AM12

13
Power source
Use the AC polarized line cord provided for operation on AC. Insert theAC cord plug into a standard 120V 60Hz
polarized AC outlet.
NOTES: • Never connect the AC line cord plug to anything other than the specified voltage (120V 60Hz). Use
the attached power cord only.
•If the polarized AC cord does not fit into a nonpolarized AC outlet, do not attempt to file or cut the
blade. It is the user's responsibility to have an electrician replace the obsolete outlet.
•If you cause a static discharge when touching the unit, and the unit fails to function, simply unplug the
unit from the wall outlet, wait 10 minutes and plug it back in. The unit should return to normal operation.
Wider Hole
and Blade
Polarized AC Cord Plug
(One blade is wider than the other.)
AC Outlet
5M80201A E P06-13 1/11/05, 9:35 AM13

14
Ifyouareusinganindoororoutdoorantenna,followtheinstructionsbelowthatcorrespondtoyourantenna
system. If you are using a cable TV service (CATV), see page 15 for Cable TV connections.
Combination VHF/UHF Antenna (Separate VHF and UHF 300 ohm twin-lead wires)
Combination VHF/UHF Antenna (Single 75 ohm cable or 300 ohm twin-lead wire)
Antenna connections
75 ohm
Coaxial
Cable 300-75 ohm
Matching
Transformer
VHF 75 ohm
Separate VHF/UHF Antennas (75 ohm VHF cable and 300 ohm UHF twin-lead wires)
Antenna
Jack
Connect the 75 ohm cable from the combination
VHF/UHF antenna to the antenna jack.
If your combination VHF/UHF antenna has a 300
ohm twin-lead wire, the use of the 300-75 ohm
matching transformer may be necessary.
Connect the UHF 300 ohm twin-lead wire to the
Combiner (not supplied). Connect the VHF 300
ohm twin-lead wire to the 300-75 ohm Matching
Transformer. Attach the Transformer to the Com-
biner, then attach the Combiner to the Antenna
Jack.
Connectthe VHF75ohm cableand UHF300 ohm
twin-lead wire to the Combiner (not supplied).
Attach the Combiner to the Antenna Jack.
Antenna
Jack
300-75 ohm Matching Transformer
UHF 300 ohm VHF 300 ohm
Antenna
Jack
Combiner
Antenna
Jack
Combiner
UHF 300 ohm
5M80201A E P14-19 1/11/05, 9:35 AM14

15
FOR SUBSCRIBERS TO BASIC CABLE TV SERVICE
For basic cable service not requiring a Converter/Descrambler
box, connect the 75 ohm Coaxial Cable directly to the Antenna
Jack on the back of the TV/DVD.
Cable TV connections
FOR SUBSCRIBERS TO SCRAMBLED CABLE TV SERVICE
75 ohm
Coaxial Cable
If you subscribe to a cable TV service in which basic channels are unscrambled and premium channels require the
use of a Converter/Descrambler box, you may wish to use a signal Splitter and an A/B Switch box (available from
the Cable company or an electronics supply store). Follow the connections shown below. With the switch in the “B”
position,youcandirectlytuneanynonscrambledchannelsonyourTV/DVD.Withtheswitchinthe“A”position,tune
your TV/DVD to the output of the Converter/Descrambler box (usually channel 3 or 4) and use the Converter/
Descrambler box to tune scrambled channels.
FOR SUBSCRIBERS TO UNSCRAMBLED BASIC CABLE TV SERVICE WITH
SCRAMBLED PREMIUM CHANNELS
Splitter B
A
Incoming
75 ohm
CATV Cable A/B Switch
75 ohm Cable
to TV/DVD
Incoming
75 ohm
CATV Cable 75 ohm Cable to
TV/DVD
Converter/
Descrambler
Antenna
Jack
Antenna
Jack
Antenna
Jack
Converter/
Descrambler
This TV/DVD has an extended tuning range and can tune most cable channels without using a Cable
TV Converter box. Some cable companies offer “premium pay channels” where the signal is
scrambled. Descrambling these signals for normal viewing requires the use of a descrambler device
which is generally provided by the cable company.
If you subscribe to a cable TV service which requires the use of a Converter/Descrambler box, connect the
incoming 75 ohm Coaxial Cable to the Converter/Descrambler box. Using another 75 ohm Coaxial Cable,
connect the output jack of the Converter/Descrambler box to the Antenna Jack on the TV/DVD. Follow the
connections shown below. Set the TV/DVD to the output channel of the Converter/Descrambler box (usually
channel 3 or 4) and use the Converter/Descrambler box to select channels.
5M80201A E P14-19 1/11/05, 9:35 AM15

16
NOTES:
•
•
< / / / /MENU >
V-CHIP SET
LANGUAGE/IDIOMA/LANGUE
< / / / /MENU >
V-CHIP SET
LANGUAGE/IDIOMA/LANGUE
4
Setting the on screen display language
You can choose from three different languages (English, French and Spanish) for the on-screen displays.
Adjustment menus and messages will appear in the language of your choice.
On-screen language selection (step 5) will automatically appear on the screen when you press the TV MENU
button initially. Select the language you prefer first, then proceed with the other menu options.
Press TV MENU in the TV mode.
The TV menu screen will appear.
Press TV MENU until the MENU screen is cleared.
Press or to select the
“LANGUAGE” option, then press
or .
1
2
3Press or until the OPTION
menu appears.
To turn on the TV/DVD, press POWER. The Power indicator
will light.
If the unit does not operate properly
(by the buttons on the unit and/or the
remote control) disconnect the AC
cord, wait a few minutes and plug it
back in. Static electricity, etc., may have
affected the player's operation.
TheTVsection andthe DVDsection each
have their own menu.
6
Press or to select the
desired language: English
(ENGLISH), Spanish
(ESPAÑOL) or French
(FRANCAIS), then press
ENTER.
< / /ENTER/MENU >
LANGUAGE/IDIOMA/LANGUE
ENGLISH
ESPAÑOL
FRANCAIS
5
5M80201A E P14-19 1/11/05, 9:35 AM16

17
CATV
VHF
2-13
STD/HRC/IRC
14-36
(A) (W)
37-59
(AA) (WW)
60-85
(AAA) (ZZZ)
86-94
(86) (94)
95-99
(A-5) (A-1)
100-125
(100) (125)
01
(5A)
TV
VHF
2-13
UHF
14-69
TV operation
If a channel with no broadcast is
selected, the sound will automati-
cally be muted.
If a station being viewed stops
broadcasting, the TV will automati-
cally shut itself off after 15 minutes.
To turn on the TV/DVD, press
POWER.
Set the TV/CATV menu
option to the appropriate
position. (See page 20.) TV - VHF/UHF channels
CATV - CABLE TV channels
VOLUME 32
CH 012
Adjust the volume level by
pressing VOL + or – . The
volume level will be indicated on
the screen by green bars. As the
volume level increases, so do
the number of bars. If the volume
decreases, the number of green
bars also decreases.
CATV Mode Direct Channel Selection
When the TV/CATV menu option is in the CATV position, channels
can be selected as follows:
TO SELECT CATV CHANNELS:
1-9: Press “0” twice, then 1-9 as needed. Example, to select
channel 2, press "002".
10-12: Press “0”, then the remaining 2 digits. Example, to
select channel 12, press "012".
13-99: Press the 2 digits in order. Example, to select channel
36, press "36".
100-125: Press the 3 digits in order. Example, to select channel
120, press "120".
NOTE FOR CHANNELS 1-12:
If only 1 or 2 buttons are pressed, the corresponding channel
will be selected in 2 seconds.
1
2
3
4Press the Direct Channel selection
buttons to select the channel.
TVModeDirectChannelSelection
When the TV/CATV menu option is
in the TV position, all channels can
be instantly selected by using two
buttons. (for example, to select
channel 2, press “0”, then “2”. If
you press only “2”, channel
selection will be delayed for a few
seconds.) For channels 10 and
above, press the 2 digits in order.
NOTES:
•
•
5M80201A E P14-19 1/11/05, 9:35 AM17

18
CALL
Press DISPLAY/CALL to display the
current information on the screen.
Press DISPLAY/CALL again to clear
the call display.
CHANNEL /
Press and release CH or . The
channel automatically stops at the
next channel set into memory.
For proper operation, before select-
ing channels, they should be set into
the memory. See pages 20 and 21
“To memorize channels”
QUICK VIEW
This button allows you to go back to
the last channel selected by press-
ing QUICK VIEW. Press QUICK
VIEW again to return to the last
channel you were watching.
SLEEP
To set the TV/DVD to turn off after a
preset amount of time, press SLEEP
on the remote control. The clock will
countdown 10 minutesfor eachpress
ofSLEEP (120, 110,...10, 0).After the
sleeptime is programmed,the display
will appear briefly every ten minutes
to remind you that the sleep timer is
operating. To confirm the sleep timer setting, press SLEEP and the
remaining time will be displayed for a few seconds. To cancel the
sleep timer, press SLEEP repeatedly until the display turns to 0.
FREEZE
This function allows you to make a freeze frame of a picture on
the TV-screen. If you find a favorite picture during TV-reception,
DVD mode or connected VCR- or CAMCORDER-playback, press
FREEZE. To cancel freeze, press FREEZE again.
SLEEP
120
STEREO SAP CH 012
SEL. MONO+SAP
•Channel number or VIDEO mode
•Stereo or SAP (second audio
program) audio status
•Audio output status
MUTE
Press MUTE to switch off the sound.
The TV/DVD’s sound will be silenced
and “MUTE” will briefly appear on the
screen. The sound can be switched
back on by pressing this button
again or one of the VOL + or –
buttons.
MUTE
TV operation (continued)
NOTE:
The unit is capable of holding a still video
imageorOn screendisplay imageonyour
television screen indefinitely. If you leave
the still video image or On screen display
image displayed on your TV for an ex-
tendedperiod oftime, youriskpermanent
damage to your television screen.
5M80201A E P14-19 1/11/05, 9:35 AM18

19
NOTES:
Captions: This Closed Caption Mode will display text on the
screen in English or another language (depending on the set-
ting of the Closed Captions CH 1/2).
Generally, Closed Captions in English are transmitted on Cap-
tions Channel 1 and Closed Captions in other languages are
transmitted on Captions Channel 2.
The Captions will appear in places on the screen where they will
leastinterferewith thepicture,usually onthebottomofthescreen.
News programs will usually show three-line Closed Captions
which scroll onto the screen.
Most other shows provide two or three lined Captions placed
near the character who is speaking so the viewer can follow the
dialogue. Words in italics or underlined describe titles, words in
foreign languages or words requiring emphasis. Words that are
sung usually appear enclosed by musical notes.
Text: The Text Closed Caption Mode will usually fill the screen
with a programming schedule or other information.
Afterselecting a Closed Caption Mode,it will stay ineffect until it
is changed, even if the channel is changed.
If the Captions signal is lost due to a commercial or a break in
thesignal, the Captionswill reappearwhen the signalis received
again. If the channels are changed, the Captions will be delayed
approximately 10 seconds.
Fortelevision programsbroadcasting with ClosedCaptions, look
in your TV guide for the Closed Captions symbol (CC).
•When selecting Closed Captions, the captioning will be delayed for approximately 10 seconds.
•If no caption signal is received, no captions will appear, but the television will remain in the Caption Mode.
•Misspellings or unusual characters may occasionally appear during Closed Captioning. This is normal with
Closed Captioning, especially with live programs. This is because during live programs, captions are also
entered live. These transmissions do not allow time for editing.
•When Captions are being displayed, on-screen displays, such as volume and mute may not be seen or may
interfere with Closed Captions.
•Some cable systems and copy protection systems may interfere with the Closed Captioned signal.
•If using an indoor antenna or if TV reception is very poor, the Closed Caption Decoder may not appear or
may appear with strange characters or misspelled words. In this case, adjust the antenna for better reception
or use an outdoor antenna.
Closed caption
WHAT IS CLOSED CAPTIONING?
This television has the capability to decode and display Closed Captioned television programs. Closed Captioning
will display text on the screen for hearing impaired viewers or it will translate and display text in another language.
TO VIEW CLOSED CAPTIONS
Press TV/CAP/TEXT to switch
between normal TV and the two
closed caption modes (captions
and full screen text). Closed
captioning will display text on the
screen for hearing impaired
viewers.
5M80201A E P14-19 1/11/05, 9:35 AM19

20
< / / / /MENU >
TV/CATV
ADD/DELETE CATV ADD
AUTO CH MEMORY
< / / / /MENU >
TV/CATV
ADD/DELETE CATV ADD
AUTO CH MEMORY
To memorize channels
Press TV MENU in the TV mode.
The TV menu screen will appear.
Press or until the SET UP
menu appears.
This TV/DVD is equipped with a channel memory feature which allows channels to skip up or down to the next
channel set into memory, skipping over unwanted channels. Before selecting channels, they must be programmed
into the TV/DVD’s memory. In addition to normal VHF and UHF channels, this TV/DVD can receive up to 113
Cable TV channels. To use this TV/DVD with an antenna, set the TV/CATV menu option to the TV mode. When
shipped from the factory, this menu option is in the CATV mode.
TV/CATV SELECTION
Press or to select the TV
or CATV mode.
Press TV MENU until the MENU
screen is cleared.
Press or to select the
“TV/CATV” option.
TV - VHF/UHF channels
CATV - CABLE TV channels
1
2
3
4
5
CATV CHART
The chart below is typical of many cable system channel allocations.
< / / / /MENU >
TV/CATV TV
ADD/DELETE ADD
AUTO CH MEMORY
5M80201A E P20-27 1/11/05, 9:35 AM20
