IMPORTANT SAFETY INSTRUCTIONS – SAVE THESE INSTRUCTIONS – PLEASE READ ENTIRE MANUAL BEFORE USING
THIS PRODUCT
The HTSAT stands are designed to support satellite speakers.
Specications:
Speaker maximum weight - DO NOT EXCEED: 1.6 kg (3.5 lbs)
CAUTION: Avoid potential personal injuries and property damage!
Do not use this product for any purpose not explicitly specied by manufacturer.
If you do not understand these instructions, or have doubts about the safety of the installation, assembly or use of this
product, contact manufacturer Customer Service or call a qualied contractor.
Manufacturer is not responsible for damage or injury caused by incorrect assembly or use.
CAUTION:
Supplied Parts and Hardware.
Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer
Service. Never use damaged parts!
NOTE: Not all hardware included will be used.
M5 x 12mm
M5 x 12mm
[01] x 2 [02] x 2
[03] x 2
[04] x 2
[06] x 2 [08] x 2[07] x 2
[11] x 4[10] x 2[09] x 2
[12] x 4 [13] x 20
[05] x 2
1/4-20 x 12mm
1/4-20
[14] x 2
OPT
WARNING: This product contains small
items that could be a choking hazard.
M5 x 15mm

6904-002019 <00>
4
1
1
2 3
2x
[13]
[01] [02]
[01]
[03]
[03]
Fit upper poles [02] into lower poles [01] and twist the
connecting ring of the upper poles [01] until secure. Be
sure to orient the upper poles [02] to
the base [03] correctly.
2x 2x
Assemble lower poles [01] into bases [03]
and twist until poles [01] are secure.
Base Assembly
Apply felt pads [13] to
bottom of both bases [03]
where indicated.

6904-002019 <00> 5
2
1
2
1.1 1.2
[04]
Mounting Options
[09]
[07]
[09]
[06] [10]
[05]
[08]
[08]
[11] [12]
OPT
OPT
OPT
OPT
[11] [12]
OPT

6904-002019 <00>
6
Milestone AV Technologies and its aliated corporations and subsidiaries (collectively, “Milestone”), intend to make this manual accurate and complete.
However, Milestone makes no claim that the information contained herein covers all details, conditions, or variations. Nor does it provide for every possible
contingency in connection with the installation or use of this product. The information contained in this document is subject to change without notice or
obligation of any kind. Milestone makes no representation of warranty, expressed or implied, regarding the information contained herein. Milestone assumes
no responsibility for accuracy, completeness or suciency of the information contained in this document.
3Wire Routing
CAUTION:
CAUTION: Disconnect the speaker wire from the receiver
or amplier when routing the wire through the upper and
lower pillar and out through the base to avoid damage to the
speakers, amplier, or receiver.
