Sanus ELM806 User manual
Total Solution Connector Kit
ELM806
Power Extension Cable Management
Tools for Installa
Not Included
Stud Finder Flat-Blade
Drywall Saw
THIS PRODUCT IS NOT TO BE INSTALLED, DIRECT WIRED, OR BRANCHED TO THE BUILDING ELECTRICAL CIRCUIT/WIRING SYSTEM !
DO NOT MODIFY OR ALTER ANY PORTION OF THE COMPONENTS OF THE FACTORY ASSEMBLED APPLIANCE
Do not install this product near water, example, near a sink, tub, shower, swimming pool or laundry area.
Manufacturer is not liable for damages due to improper installation methods not followed herein.
This product does not have built-in electronic circuitry for surge protection or A/C filtering.
It is recommended that this product be connected to a quality surge-protector/power conditioner for equipment protection.
Disclaimer. Milestone AV Technologies, it's agents, suppliers, and affiliates, shall not be liable for any damages, not limited to; misuse, acts of nature,
verbal and written expression and improper installation. Improper installation is determined such to include, not limited to, non-code compliant installation, product
modifications, alterations, adjustments, and substitutions of components or materials.
Limited 2-year Warranty from Manufactures Defects: The ELM806 has a Limited Two Year product warranty against manufacturer's defects.
If you have any questions or experience any problems with this product, please contact Customer Service. .
Step 1 Loca all Cutout
PowerOUT - Determine TV wall mount bracket loca
Align between wall framing studs.
Use stud finder to determine in-wall obs tween
framing both VERTICALLY and HORIZONTALLY.
Install in any dir t/le ontal or v al below,
above, next to TV wall bracket.
PowerIN - Align with upper PowerOUT within same stud-bay
no more than 60” apart.
Install within 60” from an exis er outlet or power-surge device.
Use supplied template sheet to mark area to cut out from drywall.
Use a level to maintain proper alignment.
Carefully use drywall saw to cut along outside of line.
Horizontal
or V al
Do not exceed more
than 60” apart
Do not exceed more
than 60” apart from
exis t or
surge-prot
PowerOUT
PowerIN
Milestone AV Technologies intent is to make this manual accurate and complete. However, Milestone makes no claim that the information contained herein covers all details, conditions, or
variations. Nor does it provide for every possible contingency in connection with the installation or use of this product. The information contained in this document is subject to change
without notice or obligation of any kind. Milestone makes no representation of warranty, expressed or implied, regarding the information contained herein.
ETL LISTED
CONFORMS TO
UL STD 514C
CERTIFIED TO
CAN/CSA STD C22.2 NO.42.1
3183743
Part No. 115-2
MODEL #TSCK
Patent Pending
|
Kit Includes:
Slimline 3D Design In-Wall Power Cable Panels
72” Powerwire Prewired PowerOutlet | 12” Powerwire Prewired PowerInlet
Pre-wired PowerConnectors | 72” PowerConnect Supply Cord
ELM806 can only be installed
within standard cons alls.
Only attempt installa
2x4 or 2x6 wood/metal stud
framed wall.
!
!
CABLE
Ultra Low Profile In-Wall System
POWER
3
D
PowerOUT Panel PowerIN Panel
If insula xists, remove or push
completely away from the openings
to allow flush moun operly.
LEVEL
!
Level
SANUS • 6436 City West Parkway • Eden Prairie, MN 55344 USA
Customer Service: 800-359-5520 • 952-225-6013 • [email protected] • sanus.com
©2012 Milestone AV Technologies, a Duchossois Group Company. All rights reserved. Sanus is a division of Milestone.
All other brand names or marks are used for identification purposes and are trademarks of their respective owners.
Step 2 Wall Installaon
A) Begin at the upper PowerOUT locaon.
Drop or wall-fish audio video cables FIRST, to the PowerIN
locaon below.
REPEAT for PowerConnect cable with connector.
Step 3 Plug it in
Plug TV power supply cord in to PowerOUT and connect AV cables to TV.
Follow wall mount manufacture instrucons, install TV on wall bracket.
Surge Protector
Plug supplied 6’ PowerConnect cord into PowerIN.
Plug other end into exisng grounded outlet or surge protector.
Do not use another extension cord to extend the supplied cord.
To disconnect PowerConnectors, push-in end of Locking Latch on the clear side of both connectors.
Press with finger ps at the same me pulling apart connectors to disconnect from Locking Tabs.
!Locking Tab
Locking Latch
Plug in TV
Plug in Flat Angle Plug in the far right receptacle
Drop or wall-fish audio/video
cables within wall
BEFORE PowerConnect cable
!
B) Slide audio video cables through backside of CableGate.
Oponal:
Cable zip-e straps can be used to secure cables through CableHoops.
Allow for enough cable length out to connect to TV and AV equipment.
C) Slide PowerOUT panel into wall opening.
Use Flat-Blade screw driver to secure panel to wall.
Careful to not over-ghten.
D) At PowerIN locaon, connect both PowerConnect Cable
connectors together.
You should hear a click sound locking both connectors together.
Repeat step B with audio video cables.
E) Slide PowerIN panel into wall opening.
Use Flat-Blade screw driver to secure panel to wall.
Careful to not over-ghten.
The ELM806 In-Wall Extension is now energized.
