Sanuvox S1000 User manual

S1000 VOC FOR SMOKING ROOM
INSTALLER INSTRUCTIONS
These instructions are for a smoking room of a maximum of 9600 cu ft
Box contains:
• Une (1) S1000 VOC unit that includes:
o One (1) "J" lamp UVC/UVV with yellow tips (part LMPHGXJ160-8 6" exposed)
o One (1) "J" lamp all UV-V with blue tips (part LMPHXJ160)
o Two (2) Multi voltage ballasts (part BST120/277SHS) and two lamp-holding brackets.
o One (1) Relay (part MSCELC16) connected to the all UVV lamp
o Twenty (20) feet of wire that can be inserted in BX shield.
o One (1) VOC controller (part MSC1A) factory’s pre-set
• Four (4) replacement pre-filters (part MSCFTR2)
LAMP INSTALLATION (this step can be done later)
1. Open the front door on the S1000 unit.
2. Open the door access to the aluminum box by removing the two
wing nuts. (see picture aside)
3. Remove the BLUE END CAP (LMPHXJ160) lamp from packaging:
Use the gloves provided.
4. Identify the ballast showing LMPHXJ160, follow the wire and insert
it in the appropriate clamp, using the foam tape supplied.
5. Holding the cap with one hand, plug the white connector tightly
on the lamp
6. Repeat the operation with the second lamp (LMPHGXJ160-8).
7. Put the cover back on with the 2 wingnuts.
Controller
Casing
Wiring 20’
Relay

SUGGESTED INSTALLATION
Unit could be
• Suspended from ceiling with suspension
rods or chains (not included).
• Hung on the wall with angle iron
Install collar plates on the unit. Note that both are
distinct.
Attach ducts (metal or flex) to the return side of
the unit above the area where smoke
accumulates to remove smoke as fast as possible.
Attach ducts (metal or flex) to the supply side of
the unit to discharge clean air in the room or over
a door to prevent odors from escaping the room. It is through recirculation that the odors will be
removed. You may use multiple inlets to pull the smoke to the unit.
The VOC controller should be installed on the ceiling where the smoke tends to accumulate. The
S1000 unit comes with 20ft of wire (Fig3) to link the controller box to the unit. If 20 ft not long
enough, you can replace it with BX wiring with 3 wires.
Note that when powering up, it will take 3 minutes until the VOC monitor will be ready to act: LED
green and red lights will tell you it works.
IMPORTANT: you may have to calibrate the VOC Monitor: refer to the monitor instructions or call
Sanuvox.
WORKING INSTRUCTION
The VOC controller analyzes the air every 90 seconds. A 20-foot power cord connects it via a relay to
the device to activate the second oxidizing lamp on demand.
The S1000 VOC unit runs continuously, so its regular lamp purifies the air constantly. This dual zone
lamp (UVC / UVV) is sufficient when there are only one or two smokers.
However, when the cigarette smoke increases in the room, the VOC controller that samples the air
at regular intervals, then triggers the 2nd UVV lamp for periods of 90 seconds. This cycle is repeated
if the controller detects smoke in the room: it then turns off the 2nd lamp, leaving the 1st lamp to
continue the cleaning cycle.
SIMPLIFIED PROCESS:
• Ashes in the “white” smoke will be trapped onto the filter
• Nicotine molecules will be dried by the UVC rays than trapped in the filters without the tar like
material that coats everything.
• VOC will be oxidised by the UVV, reducing substantially their olfactory perception.
air returned into the room
Collecting pipe with openings to grab smoke
S-1000
unit
air returned into the room

VOC CONTROLLER
Remove the cover.
Connect the 3 wires from the controller to the same color
wiring coming from the unit. Use the wire connectors
included.
The detector is factory set a t 3.0 V DC; If you wish to set up a
higher sensitivity, please proceed as follow.
SETTING (if necessary)
You will need a voltmeter with alligator probes.
Place the probes one on the positive terminal, the other on the neutral terminal.
Use a small screwdriver to turn the adjustment screw to increase the sensitivity of the controller.
The default setting is 3.0 v dc. The more you increase the voltage, the faster the controller will react to
VOC or smoke.
CHECKING IF IT WORKS
1. Start the unit: inside the polycarbonate box, the GREEN LED flashes. It will take some time, so
the electronic board initializes itself.
2. After 5 minutes, the GREEN LED will turn solid. Blow some cigarette smoke into the controller. If
the other RED LED lights up, the relay triggers on the oxidizing lamp (all UVV). This sequence
reproduce itself every minute or so. When there is no more smoke (VOC), the RED LED is turned
off at the same time as the lamp.
MAINTENANCE INSTRUCTIONS
• MONTHLY: Change the pre-filters that protects the motor (part # MSCFTR2) to ensure the
optimal performance of the unit. Check the lamps: if there is a cloudy residue please clean then
off with denatured alcohol.
• YEARLY: Change lamps (parts -see below) to maintain performance: make sure to put the same
lamp in the same clamp. Do not interchange the lamps as the blue end cap lamp works only with
the VOC controller.
o LMPHGXJ160-8 lamp UVC/UVV 6’’ exposed (yellow end cap)
o LMPHXJ160 lamp all UVV (blue end cap)
• 3-5 years: Change VOC controller board
setting screw:
triggers at
3.4 V DC
Positive
Neutral
Sensor

S1000 VOC FOR SMOKING ROOM
USER INSTRUCTIONS
MAINTENANCE
• MONTLY:
o Check pre-filter: if filters are dirty, change them (part # MSCFTR2). This will help lower
air restrictions so to keep up the performance of the unit.
o Check if the lamps are covered with dust; in that case, clean them with denatured
alcohol and a clean cloth.
• ANNUALLY:
o Change lamps (parts -see below) to maintain performance: make sure to put the same
lamp in the same clamp. Do not interchange lamps as the blue end cap lamp works only
with the VOC controller.
§ LMPHGXJ160-8 lamp UVC/UVV 6’’ exposed (yellow end cap)
§ LMPHXJ160 lamp all UVV (blue end cap)
• 3-5 years: Change VOC controller board
WORKING INSTRUCTIONS
• The VOC controller analyzes the air every 90 seconds. A 20-foot power cord connects it via a
relay to the device to activate the second oxidizing lamp on demand.
• The S1000 VOC unit runs continuously, so its regular lamp purifies the air constantly. This
dual zone lamp (UVC / UVV) is enough when there are only one or two smokers.
• However, if there is much smoke in the room, the VOC controller, that samples the air on a
regular basis, will then trigger the second all UVV lamp for a period of 90 seconds. This cycle
will repeat itself until there is no more smoke in the room: the second lamp will then shut
off, leaving the first lamp on doing the work
SIMPLIFIED PROCESS:
• Ashes in the “white” smoke will be trapped onto the filter
• Nicotine molecules will be dried by the UVC rays than trapped in the filters without the tar like
material that coats everything.
• VOC will be oxidised by the UVV, reducing substantially their olfactory perception.
It is very important that the fan processes the air rapidly.
Changing the filters regularly is a must.
