SUBMITTAL SHEET
SYSTEM INDOOR/OUTDOOR
30KS32AKS3032/C3032A
WALL MOUNTED AIR CONDITIONER
GENERAL DATA(AT 230V)
POWER V/PH/HZ 230/208/1/60
Circuit Ampacity, Min. (A) 30
Fuse size, Max. (A) 30
COMPRESSOR Rotary-Hermetic
No. used 1
R.L. Amps - L.R. Amps (A) 10.6 ñ 77.0
Crankcase Heater -
OUTDOOR FAN - TYPE Propeller
Dia. (in.) - No. used 18-3/32 - 2
Type Drive - No. speeds Direct ñ 2 (AUTO)
No. Poles - RPM (High) 6 - 879
No. Motors ñ HP 2 - 110
CFM (High) 3,670
F.L. Amps. (A) 1.8
OUTDOOR COIL - TYPE Aluminum Fin & Copper Pipe
Fin Type - Pipe Type Slit Plate - Inner Bared
Rows - F.P.I. 2 - 12.7
Face Area (sq.ft.) 11.63
Tube Size (in.) 3/8
INDOOR FAN - TYPE Cross - Flow
Dia. & Length (in.) - No. used 4 -13/18 & 46-1
No. speeds 3 & Auto
No. Poles -RPM (High) 4 -1,260
No. Motors - WATTS 1 - 40
CFM (HI/MED/LOW) 840/740/620
F.L. Amps (A) 0.6
INDOOR COIL - TYPE Aluminum Fin & Copper Pipe
Fin Type - Pipe type Slit Plate - Inner Riffled
Rows - F.P.I. 2-12.7
Face Area (sq. ft.) 3.33
Tube Size (in.) 3/8
Drain Connection Size (in.) 1 - 1/4
REFRIGERANT R22
Lbs. - R22 (O.D. Unit) 8.6
Control Capillary Tube
Connection Flare
Line Length, Max (ft.) 165
Lift difference, Max (ft.) 100
Line Size - in. O.D. Discharge 3/8
Line Size - in. O.D. Suction 3/4
DIMENSIONS (in.) H x W x D
Indoor Unit -Uncrated 4- 9/16 x 59- 1/16 x 9- 7/16
-Crated 18- 3/16x 62- 9/16 x 11-5/8
Outdoor Unit -Uncrated 48- 5/8 x 37 x 13-3/8
-Crated 52- 7/32 x 40 x 16- 3/8
WEIGHT INDOOR OUTDOOR
Net (lbs.) 64.0 198.0
Shipping(lbs.) 82.0 223.0
Shipping Volume (cu.ft.) 7.7 19.8
SS30KS32-2
PERFORMANCE DATA @ ARI STANDARD CONDITIONS (230/208V)
COOLING
Total Capacity (BTU/H) 30,000/29,000
Sensible Capacity (BTU/H) 18,800/18,200
Latent Capacity (BTU/H) 11,200/10,800
SEER 10.4/10.7
Dehumidification (Pints/H) 10.0/10.9
Amps (A) 13.0/13.6
Power Inputs (W) 2,880/2,770
Outdoor Sound Rating(bels) 7.9
FEATURE
Controls Microprocessor
Remote Controller LCD Wireless type
Temperature Control IC Thermostat
Timer ON/OFF, 24 hours
Night Setback Built-In
Air Louver (Horizontal) Manual
(Vertical) Automatic
Power Failure Automatic Restart Built-In
Self Diagnosis N/A
OPTION
Refrigerant Line Set AP3210BH (30 ft)
AP3215BH (50 ft)
Low Ambient Control Available
Fresh Air Intake N/A
Central Remote ON-OFF Control Available
Airduct Extension N/A
Indoor Frame Extension N/A
Condensate Drain Pump Available
Non-Removable Remo-con Bracket RCS5PS4B
Wire Remote Controller RCS-102WD/RDS-302WD
OPERATING RANGE
Cooling Indoor Air Outdoor Air
Intake Temp. Intake Temp.
Maximum 95 F DB/71 F WB 115 F DB
Minimum 67 F DB/57 F WB 67 F DB
CERTIFICATION
30KS32A
AIRCONDITIONING PRODUCTS

SUBMITTAL SHEET
SUBMITTAL SHEETSUBMITTAL SHEET
SUBMITTAL SHEET
SYSTEM INDOOR/OUTDOOR
30K
30K30K
30KL
LL
LS
SS
S3
33
32A
2
2KS3
KS3KS3
KS303
0303
032/C
2/C2/C
2/CL
LL
L3
33
303
0303
032
222A
WALL MOUNTED LOW AMBIENT AIR CONDITIONER
GENERAL DATA (AT 230V)
POWER V/PH/HZ 230/208/1/60
Circuit Ampacity, Min. (A) 30
Fuse size, Max. (A) 30
COMPRESSOR Rotary-Hermetic
No. used 1
R.L. Amps - L.R. Amps (A) 10.6 ñ 77.0
Crankcase Heater 30W
OUTDOOR FAN - TYPE Propeller
Dia. (in.) - No. used 18-3/32 - 2
Type Drive - No. speeds Direct ñ 3 (AUTO)
No. Poles - RPM (High) 6 - 879
No. Motors - HP 2 - 110
CFM (High) 3,670
F.L. Amps. (A) 1.8
OUTDOOR COIL - TYPE Aluminum Fin & Copper Pipe
Fin Type - Pipe Type Slit Plate - Inner Bared
Rows - F.P.I. 2 - 12.7
Face Area (sq.ft.) 11.63
Tube Size (in.) 3/8
INDOOR FAN - TYPE Cross - Flow
Dia. & Length (in.) - No. used 4-13/18 & 46-1
No. speeds 3 & Auto
No. Poles -RPM (High) 4-1,260
No. Motors - WATTS 1 - 40
CFM (HI/MED/LOW) 840/710/620
F.L. Amps (A) 0.6
INDOOR COIL - TYPE Aluminum Fin & Copper Pipe
Fin Type - Pipe type Slit Plate - Inner Riffled
Rows - F.P.I. 2-12.7
Face Area (sq. ft.) 3.33
Tube Size (in.) 3/8
Drain Connection Size (in.) 1 - 1/4
REFRIGERANT R22
Lbs. - R22 (O.D. Unit) 8.6
Control Capillary Tube
Connection Flare
Line Length, Max (ft.) 165
Lift difference, Max (ft.) 100
Line Size - in. O.D. Discharge 3/8
Line Size - in. O.D. Suction 3/4
DIMENSIONS (in.) H x W x D
Indoor Unit -Uncrated 14- 9/16 x 59- 1/16 x 9- 7/16
-Crated 18- 3/16 x 62- 9/16 x 11-5/8
Outdoor unit -Uncrated 48- 5/8 x 37 x 13-3/8
-Crated 52- 7/32 x 40 x 16- 3/8
WEIGHT INDOOR OUTDOOR
Net (lbs.) 64.0 198.0
Shipping (lbs.) 82.0 223.0
Shipping Volume (cu.ft.) 7.7 19.8
SS30KLS32-1
PERFORMANCE DATA @ ARI STANDARD CONDITIONS (230/208V)
COOLING
Total Capacity (BTU/H) 30,000/29,000
Sensible Capacity (BTU/H) 18,800/18,820
Latent Capacity (BTU/H) 11,200/10,800
SEER 10.4/10.7
Dehumidification (Pints/H) 10.0/9.9
Amps (A) 13.0/13.6
Power Inputs (W) 2,880/2,770
Outdoor Sound Rating(bels) 7.9
FEATURE
Controls Microprocessor
Remote Controller LCD Wireless type
Temperature Control IC Thermostat
Timer ON/OFF, 24 hours
Night Setback Built-In
Air Louver (Horizontal) Manual
(Vertical) Automatic
Power Failure Automatic Restart Built-In
Self Diagnosis N/A
OPTION
Refrigerant Line Set AP3210BH (30 ft)
AP3215BH (50 ft)
Low Ambient Control Equipped
Fresh Air Intake N/A
Central Remote ON-OFF Control Available
Airduct Extension N/A
Indoor Frame Extension N/A
Condensate Drain Pump Available
Non-Removable Remo-con Bracket RCS5PS4B
Wire Remote Controller RCS-102WD/RDS-302WD
OPERATING RANGE
Cooling Indoor Air Outdoor Air
Intake Temp. Intake Temp.
Maximum 95 F DB/71 F WB 115 F DB
Minimum67 F DB/57 F WB0 F DB
CERTIFICATION
30KLS32A
