Sanyo XS1271 User manual

XS1271
XS1872
COOL/DRY Model
© SANYO 2008
Pub. OI-85264181108000
INSTRUCTION MANUAL
Inverter-Controlled Split System Air Conditioner
MODE D’EMPLOI
Climatiseur de type séparé contrôlé par inverseur
This air conditioner uses
the new refrigerant R410A.
Save These Instructions!
Conserver ce mode d’emploi
00_XS1872_Cover.fm Page 1 Friday, August 15, 2008 6:33 PM

2
FEATURES
This air conditioner is an inverter type unit that automatically adjusts capability as appropriate. Details on these functions are provided below;
refer to these descriptions when using the air conditioner.
• Microprocessor Controlled Operation
The interior compartment of the remote control unit
contains several features to facilitate automatic operation,
easy logically displayed for easy use.
• Simple One-touch Wireless Remote Control
The remote control unit has several features to facilitate
automatic operation.
• 24-Hour ON or OFF Timer
This timer can be set to automatically turn the unit on or off
at any time within a 24 hour period.
• 1-Hour OFF Timer
This timer can be set to automatically turn off the unit at
any time after one hour.
•NightSetback
This function saves energy by controlling operation to
provide a quieter operating sound than normal.
• Automatic and 3-step Fan Speed
Auto/High/Medium/Low
• Air Sweep Control
This function moves a flap up and down in the air outlet,
directing air in a sweeping motion around the room and
providing comfort in every corner.
• Auto. Flap Control
This automatically sets the flap to the optimum position
during cooling and drying operation.
• Automatic Restart Function for Power Failure
Even when power failure occurs, preset programmed
operation can be reactivated once power resumes.
• High Power Operation
The unit operates at maximum output for 30 minutes,
regardless of the desired temperature.
The fan speed is 1 step above “High”.
CONTENTS
Page
FEATURES ......................................................................................................................................... 2
PRODUCT INFORMATION ................................................................................................................ 3
ALERT SYMBOLS.............................................................................................................................. 3
INSTALLATION LOCATION ................................................................................................................ 3
ELECTRICAL REQUIREMENTS........................................................................................................3
SAFETY INSTRUCTIONS.................................................................................................................. 3
NAMES OF PARTS............................................................................................................................. 4
USING THE REMOTE CONTROL UNIT ............................................................................................ 8
OPERATION WITH THE REMOTE CONTROL UNIT ........................................................................9
1. Operation............................................................................................................................. 9
2. Adjusting the Fan Speed .....................................................................................................9
3. Fan Only .............................................................................................................................. 9
4. Night Setback Mode ..........................................................................................................10
5. HIGH POWER Mode......................................................................................................... 10
SPECIAL REMARKS........................................................................................................................ 10
SETTING THE TIMER...................................................................................................................... 10
USING THE 1-HOUR OFF TIMER...................................................................................................12
TIPS FOR ENERGY SAVING........................................................................................................... 12
ADJUSTING THE AIRFLOW DIRECTION .......................................................................................12
OPERATION WITHOUT THE REMOTE CONTROL UNIT...............................................................13
CARE AND CLEANING.................................................................................................................... 13
TROUBLESHOOTING...................................................................................................................... 15
OPERATING RANGE ....................................................................................................................... 15
WIRED REMOTE CONTROLLER .................................................................................................... 15
OI-108-2-EG
01_XS1872_EN.fm Page 2 Thursday, September 25, 2008 8:31 PM

3
PRODUCT INFORMATION
If you have problems or questions concerning your Air
Conditioner, you will need the following information. Model
and serial numbers are on the nameplate on the bottom of
the cabinet.
Model No. __________________________________
Serial No. ___________________________________
Date of purchase _____________________________
Dealer’s address _____________________________
Phone number ________________
ALERT SYMBOLS
The following symbols used in this manual, alert you
to potentially dangerous conditions to users, service
personnel or the appliance:
INSTALLATION LOCATION
• We recommend that this air conditioner be installed
properly by qualified installation technicians in
accordance with the Installation Instructions
provided with the unit.
• Before installation, check that the voltage of the electric
supply in your home or office is the same as the voltage
shown on the nameplate.
Avoid:
To protect the air conditioner from heavy corrosion, avoid installing
the outdoor unit where salty sea water can splash directly onto it or
in sulphurous air near a spa.
ELECTRICAL
REQUIREMENTS
1. All wiring must conform to the local electrical codes.
Consult your dealer or a qualified electrician for details.
2. Each unit must be properly grounded with a ground (or
earth) wire or through the supply wiring.
3. Wiring must be done by a qualified electrician.
SAFETY INSTRUCTIONS
• Read this Instruction Manual carefully before using
this air conditioner. If you still have any difficulties
or problems, consult your dealer for help.
• This air conditioner is designed to give you
comfortable room conditions. Use this only for its
intended purpose as described in this Instruction
Manual.
This symbol refers to a hazard or unsafe
practice which can result in severe
personal injury or death.
This symbol refers to a hazard or unsafe
practice which can result in personal
injury or product or property damage.
• Do not install this air conditioner
where there are fumes or flammable
gases, or in an extremely humid space
such as a greenhouse.
• Do not install the air conditioner where
excessively high heat-generating
objects are placed.
CAUTION
• Never use or store gasoline or other
flammable vapor or liquid near the air
conditioner — it is very dangerous.
• This air conditioner has no ventilator
for intaking fresh air from outdoors.
You must open doors or windows
frequently when you use gas or oil
heating appliances in the same room,
which consume a lot of oxygen from
the air. Otherwise there is a risk of
suffocation in an extreme case.
• Do not turn the air conditioner on and
off from the power mains switch. Use
the ON/OFF operation button.
• Do not stick anything into the air outlet
of the outdoor unit. This is dangerous
because the fan is rotating at high
speed.
• Do not let children play with the air
conditioner.
• Do not cool the room too much if
babies or invalids are present.
CAUTION
OI-108-3-EG
01_XS1872_EN.fm Page 3 Thursday, September 25, 2008 8:31 PM

4
NAMES OF PARTS
This illustration is based on the external view of a standard model.
Consequently, the shape may differ from that of the air conditioner
which you have selected.
This air conditioner consists of an indoor unit and an outdoor unit.
You can control the air conditioner with the remote control unit.
UNIT DISPLAY AND OPERATION
BUTTON
Avoid using radio equipment such as mobile phone near (within
4 ft. (1.2 m)) the remote control receiver. Some radio equipment
may cause malfunction of the unit.
If the trouble happens, disconnect power and restart the air
conditioner after a few minutes.
The unit’s display lamps are dimmed during operation in the NIGHT
SETBACK mode.
Air Intake Air from the room is drawn into this section and
passes through air filters which remove dust.
Air Outlet Conditioned air is blown out of the air
conditioner through the air outlet.
Remote
Control Unit
The wireless remote control unit controls power
ON/OFF, operation mode selection,
temperature, fan speed, timer setting, and air
sweeping.
Refrigerant
Tubes
The indoor and outdoor units are connected by
copper tubes through which refrigerant gas
flows.
Drain Hose Moisture in the room condenses and drains off
through this hose.
Outdoor
(Condensing)
Unit
The outdoor unit contains the compressor, fan
motor, heat exchanger coil, and other electrical
components.
INDOOR UNIT
Air intakes
Remote control unit
Refrigerant tubes
Drain hose
OUTDOOR UNIT
Air outlet
Air outlet
(4 locations)
NOTE
REMOTE
CONTROL
receiver
This section picks up infrared signals from the
remote control unit (transmitter).
OPERATION
button
When the remote control cannot be used,
pressing this button enables cooling operation.
Each time this button is pressed, the operation
mode changes cyclically.
OPERATION
lamp
This lamp lights when the system is in the
continuous DRY (orange), COOL (green) and
FAN (green) mode.
TIMER lamp This lamp lights when the system is being
controlled by the timer.
HIGH POWER
lamp
This lamp lights during operation in the HIGH
POWER mode.
REMOTE CONTROL receiver
OPERATION lamp
TIMER lamp
OPERATION button
HIGH POWER lamp
INDOOR UNIT
IMPORTANT
Cooling operation Stop
NOTE
OI-108-4-EG
01_XS1872_EN.fm Page 4 Thursday, September 25, 2008 8:31 PM

5
REMOTE CONTROL UNIT (DISPLAY)
(1) Operation mode
MILD DRY ..............................
COOL.....................................
FAN ........................................
(2) Fan speed
Automatic operation ...............
HIGH .....................................
MEDIUM.................................
LOW .......................................
(3) Temperature setting
60–86°F
When set to 80 °F
temperature indication............
(4) Timer
24-hour clock with ON/OFF
program Timer .......................
ON Timer. ..............................
OFF Timer. ............................
1-hour OFF Timer. .................
(5) NIGHT SETBACK..................
(6) Confirmation
of transmission.......................
(7) Auto. flap indication................
Flap angle indication..............
Sweep indication....................
(8) High power operation.............
Displayed when setting timer
Displayed when transmitting data
Displayed when indoor unit sensor is
in use
Displayed when setting temperature
Displayed when temperature is shown
Displayed when the time
display is set to 12-hour
time.
Symbols
OI-108-5-EG
