SUBMITTAL SHEET
SYSTEM INDOOR/OUTDOOR
36TS32ATS3632/C3632A
CEILING SUSPENDED AIR CONDITIONER
GENERAL DATA (AT 230V)
POWER V/PH/HZ 230/208/1/60
Circuit Ampacity, Min. (A) 35
Fuse size, Max. (A) 35
COMPRESSOR Rotary-Hermetic
No. used 1
R.L. Amps - L.R. Amps (A) 12.5 ñ 95.0
Crankcase Heater 30W
OUTDOOR FAN - TYPE Propeller
Dia. (in.) - No. used 18-3/32 - 2
Type Drive - No. speeds Direct ñ 3 (AUTO)
No. Poles - RPM (High) 6 - 879
No. Motors ñ HP 2 - 110
CFM (High) 3,670
F.L. Amps. (A) 1.8
OUTDOOR COIL - TYPE Aluminum Fin & Copper Pipe
Fin Type - Pipe Type Slit Plate - Inner Riffled
Rows - F.P.I. 2 - 12.7
Face Area (sq.ft.) 11.63
Tube Size (in.) 3/8
INDOOR FAN - TYPE Cross - Flow
Dia. (in.) - No. used 5-29/32 & 39-4
No. speeds 3 & Auto
No. Poles -RPM (High) 4 - 1,015
No. Motors ñ HP 1 - 100
CFM (HI/MED/LOW) 900/790/680
F.L. Amps (A) 0.7
INDOOR COIL ñ TYPE Aluminum Fin & Copper Pipe
Fin Type - Pipe type Slit Plate - Inner Riffled
Rows - F.P.I. 2 - 12.7
Face Area (sq. ft.) 3.51
Tube Size (in.) 5/16
Drain Connection Size (in.) 1-1/4
REFRIGERANT R22
Lbs. - R22 (O.D. Unit) 9.48
Control Capillary Tube
Connection Flare
Line Length, Max (ft.) 165
Lift difference, Max (ft.) 100
Line Size - in. O.D. Discharge 3/8
Line Size - in. O.D. Suction 3/4
DIMENSIONS (in.) H x W x D
Indoor Unit -Uncrated 9-7/16 x 62 x 26-3/8
-Crated 12 x 65-20/32 x 29-3/4
Outdoor Unit -Uncrated 48-5/8 x 37 x 13-3/8
-Crated 52ñ7/32 x 40 x 16-12/32
WEIGHT INDOOR OUTDOOR
Net (lbs.) 84.0 198.0
Shipping(lbs.) 97.0 223.0
Shipping Volume (cu.ft.)13.6 19.8
SS36TS32A-2
PERFORMANCE DATA @ ARI STANDARD CONDITIONS (230/208V)
COOLING
Total Capacity (BTU/H) 34,800/33,000
Sensible Capacity (BTU/H) 22,320/21,700
Latent Capacity (BTU/H) 11,680/11,300
SEER 10.6/10.9
Dehumidification (Pints/H) 10.6/10.8
Amps (A) 15.0/15.5
Power Inputs (W) 3,340/3,130
Outdoor Sound Rating (bels) 7.9
FEATURE
Controls Microprocessor
Remote Controller LCD Wireless type
Temperature Control IC Thermostat
Timer ON/OFF, 24 hours
Night-Setback Built-In
Air Louver (Horizontal) Manual
(Vertical) Automatic
Power Failure Automatic Restart Built-In
Self Diagnosis N/A
OPTION
Refrigerant Line Set AP3210BH (30 ft)
AP3215BH (50 ft)
Low Ambient Control Available
Fresh Air Intake Available
Central Remote ON-OFF Control Available
Airduct Extension N/A
Indoor Frame Extension N/A
Condensate Drain Pump Available
Non-Removable Remo-con Bracket Available
OPERATING RANGE
Cooling Indoor Air Outdoor Air
Intake Temp. Intake Temp.
Maximum 95 F DB/71 F WB 115 F DB
Minimum 67 F DB/57 F WB 67 F DB
CERTIFICATION
AIRCONDITIONING PRODUCTS

SUBMITTAL SHEET
SYSTEM INDOOR/OUTDOOR
36TLS32A TS3632/CL3632A
CEILING SUSPENDED LOW AMBIENT AIR CONDITIONER
GENERAL DATA (AT 230V)
POWER V/PH/HZ 230/208/1/60
Circuit Ampacity, Min. (A) 35
Fuse size, Max. (A) 35
COMPRESSOR Rotary-Hermetic
No. used 1
R.L. Amps - L.R. Amps (A) 12.5 ñ 95.0
Crankcase Heater 30W
OUTDOOR FAN - TYPE Propeller
Dia. (in.) - No. used 18-3/32 - 2
Type Drive - No. speeds Direct ñ 3 (AUTO)
No. Poles - RPM (High) 6 - 879
No. Motors ñ HP 2 - 110
CFM (High) 3,670
F.L. Amps. (A) 1.8
OUTDOOR COIL ñ TYPE Aluminum Fin & Copper Pipe
Fin Type - Pipe Type Slit Plate - Inner Riffled
Rows - F.P.I. 2 - 12.7
Face Area (sq.ft.) 11.63
Tube Size (in.) 3/8
INDOOR FAN ñ TYPE Cross - Flow
Dia. (in.) - No. used 5-29/32 & 39-4
No. speeds 3 & Auto
No. Poles -RPM (High) 4 - 1,015
No. Motors ñ HP 1 - 100
CFM (HI/MED/LOW) 900/790/680
F.L. Amps (A) 0.7
INDOOR COIL - TYPE Aluminum Fin & Copper Pipe
Fin Type - Pipe type Slit Plate - Inner Riffled
Rows - F.P.I. 2 - 12.7
Face Area (sq. ft.) 3.51
Tube Size (in.) 5/16
Drain Connection Size (in.) 1-1/4
REFRIGERANT R22
Lbs. - R22 (O.D. Unit) 9.48
Control Capillary Tube
Connection Flare
Line Length, Max (ft.) 165
Lift difference, Max (ft.) 100
Line Size - in. O.D. Discharge 3/8
Line Size - in. O.D. Suction 3/4
DIMENSIONS (in.) H x W x D
Indoor Unit -Uncrated 9-7/16 x 62 x 26-3/8
-Crated 12 x 65-20/32 x 29-3/4
Outdoor Unit -Uncrated 48-5/8 x 37 x 13-3/8
-Crated 52ñ7/32 x 40 x 16-12/32
WEIGHT INDOOR OUTDOOR
Net (lbs.) 84.0 198.0
Shipping(lbs.) 97.0 223.0
Shipping Volume (cu.ft.) 13.6 19.8
SS36TLS32A-2
PERFORMANCE DATA @ ARI STANDARD CONDITIONS (230/208V)
COOLING
Total Capacity (BTU/H) 34,800/33,000
Sensible Capacity (BTU/H) 22,320/21,700
Latent Capacity (BTU/H) 11,680/11,300
SEER 10.6/10.9
Dehumidification (Pints/H) 10.6/10.8
Amps (A) 15.0/15.5
Power Inputs (W) 3,340/3,130
Outdoor Sound Rating (bels) 7.9
FEATURE
Controls Microprocessor
Remote Controller LCD Wireless type
Temperature Control IC Thermostat
Timer ON/OFF, 24 hours
Night-Setback Built-In
Air Louver (Horizontal) Manual
(Vertical) Automatic
Power Failure Automatic Restart Built-In
Self Diagnosis N/A
OPTION
Refrigerant Line Set AP3210BH (30 ft)
AP3215BH (50 ft)
Low Ambient Control Equipped
Fresh Air Intake Available
Central Remote ON-OFF Control Available
Airduct Extension N/A
Indoor Frame Extension N/A
Condensate Drain Pump Available
Non-Removable Remo-con Bracket Available
OPERATING RANGE
Cooling Indoor Air Outdoor Air
Intake Temp. Intake Temp.
Maximum 95 F DB/71 F WB 115 F DB
Minimum67 F DB/57 F WB0 F DB
CERTIFICATION
36TLS32A
AIRCONDITIONING PRODUCTS
