Sanyo CE27LC4-C User manual

Part No. SKSM0801 N2WL JUNE 2005
Colour Television
Service Manual
Model CE27LC4-C
Service Ref. No. CE27LC4-C-00
PRODUCT CODE: 111376210
ORIGINAL VERSION: Chassis No. UK2A
Note
This TV receiver will not work properly in foreign
countries where the television transmission
system and power source differ from the design
specifications. Refer to the specifications for the
design specifications
CE27LC4-C
Contents
Safety precautions/Specifications ..................................................................................................................2
Block diagrams ..............................................................................................................................................3
Cabinet Disassembly......................................................................................................................................4
Adjustment and Repair Procedures............................................................................................................5~9
CPU Port Functions......................................................................................................................................10
IC Block Diagrams ..................................................................................................................................11~13
Pin description of semiconductors................................................................................................................14
Part Description and reading of schematic diagram ....................................................................................15
Cabinet Parts List ........................................................................................................................................16
Electric Parts List....................................................................................................................................17~26
Please use Schematic Diagram SKP20535 with
this Service Manual.
Give complete "SERVICE REF. NO." for parts
order or servicing, it is shown on the rating sheet
on the cabinet back of the TV set.

-2-
N2WL
SAFETY PRECAUTION
PRODUCT SAFETY NOTICE
SPECIFICATIONS
1: An isolation transformer should be connected in the
power line between the receiver and the AC line
when a service is performed on the primary of the
converter transformer of the set.
2: Comply with all caution and safety-related notes
provided on the cabinet back, inside the cabinet, on
the chassis or the LCD display .
3: When replacing a chassis in the cabinet, always be
certain that all the protective devices are installed
properly, such as, control knobs, adjustment covers
or shields, barriers, isolation resistor-capacitor networks
etc. Before returning any television to the customer,
the service technician must be sure that it is completely
safe to operate without danger of electrical shock.
Power source AC 220~240V, 50Hz
Television system System I
Colour system PAL/NTSC4.43 (PAL/NTSC4.43/NTSC3.58 IN AV MODE)
Receiving channel UHF: 21~69
VHF: A-J, E2-E12
CATV: X, Y, Z, S1-S41
Aerial input impedance 75ohm
Rear AV terminal
AV1: CENELEC standard
INPUT: Composite video, RGB and Audio L/R
OUTPUT: TV-output with composite video and audio L/R
AV2: CENELEC standard
INPUT: Composite video, RGB, S-VHS and Audio L/R
OUTPUT: Monitor output with composite video and Audio L/R
AV3: INPUT: Composite video and Audio L/R
OUTPUT: No output
Front AV terminal
AV4: RCA jacks
INPUT: Composite video and Audio L/R
Headphone socket Mini Jack
Sound output(Music) 10W x 2
Dimensions (WxHxD) 800 x 470 x 239mm
Weight 14.1 Kg
Product safety should be considered when a component replacement is made in any area of a receiver.
Components indicated by mark in the parts list and the schematic diagram designate components in which safe-
ty can be of special signifigance. It is particularly recommended that only parts designated on the parts list in this
manual be used for component replacement designated by mark . No deviations from resistance wattage or volt-
age ratings may be made for replacement items designated by mark .
!
!
!
Important recycling information.
Your SANYO product is designed and manufactured with high quality
materials and components which can be recycled and reused.
This symbol means that electrical and electronic equipment, at their
end-of-life, should be disposed of separately from your household
waste.
Please dispose of this equipment at your local community waste collec-
tion / recycling centre.
In the European Union there are separate collection systems for used electrical and electronic
products.
Please help us to conserve the environment we live in!
Note: This symbol mark and recycle system are applied only to EU countries and are not applied
to other countries of the world.

-3- N2WL
BLOCK DIAGRAM
This is a diagram for all models and therefore differs slightly from the actual block diagram.
LCD PANEL
THC63
LVDM83R
LVDS
IC1CCI
ADE3800XLM
SCALER IC
LVDS CABLE 10 PAIRS
Y/PR/PB OR RGB 3 LINES
IC1801 SUB CPU M16C/26
I2C BUS
LCD - TV BLOCK DIAGRAM
This is a diagram for all models and therefore differs slightly model by  model
DIGITAL MODULE CONTROL BUS
IC001 LA4919 AUDIO AMP
SPEAKERS 10WX2
IC8O1 STV3600 & VIDEO PROCESSOR
IC3501 NJM2155M SOUND ENHANCEMENT AUDIO PROCESSOR 
IC1221 BA7609F DM OUT SWITCH
DIGITAL  MODULE
V - OUT A - OUT

A - IN
V - IN A - IN
IC 1221 TC4052 AV AUDIO IN SWITCH
IC3451 STV8216 AUDIO PROCESSOR
IC1251 BA7603F Y/U/V SWITCH
IC1205 BA7603F RGB SWITCH
IC1224 BA7626F TV VIDEO SWITCH
IC805 M29W160E FLASH 16KB
IC802 M24C64 NVM (EEPROM) 64KB
IC803 SD RAM 128MB
IC804 SD RAM 128MB
IC2001 STV2310 VIDEO PROCESSOR

A101 TUNER
IC101
IDA9886 IF DETECTOR
X121
VIF SAWF 
X121
SIF SAWF
V - IN A - IN
RGB V-I/O A-I/O RC-IN AV-LINK
RGB V-I/O A-I/O RC-IN AV-LINK
9PIN DIN SERVICE SOCKET
12C BUS NVM
12C BUS
DATA DATA DATA
ADD- RESS
ADD- RESS
ADD- RESS
12C BUS
12C BUS
SCART1-AV1
SCART2-AV2
SCART3-AV3
ANALOG
VIDEO
AV RGB IN
TV OUT1
TV OUT2
AV1 VIDEO IN
AV2 VIDEO IN
AV4 VIDEO IN
AV2 RGB IN
AV3 VIDEO IN
AV1 AUDIO IN
AV2 AUDIO IN
AV1 AUDIO OUT

DIGITAL Y/U/V IN
AV4 AUDIO IN
AUDIO IN
AV OR DIGITAL AUDIO IN
DIGITAL AUDIO
AV4
AUDIO OUT
AV2 AUDIO OUT
AV2 VIDEO OUT
VIDEO OUT
ANALOG VIDEO
ANALOG AUDIO
DIGITAL VIDEO
Y/U/V  DIGITAL VIDEO
DIGITAL MODULE CONTROL BUS
L & R DIGITAL AUDIO
L & R  AUDIO
L & R AUDIO FOR HEADPHONES
Y/CR/CB 8 LINES
12C BUS
12C BUS
L & R  AUDIO
BUS0 (BBE) BUS1 (MACH-3)
ADDRESS/DATA/CLOCK 3 LINES
AV RGB OR DIGITALY/U/V IN
AV3 AUDIO IN




-4-
N2WL
CABINET DISASSEMBLY
CABINET BACK DISASSEMBLY
1. Remove 11 screws marked A for 27”
2. Pull out the cabinet back.
AA
A
A
A
AAA A
A
A

-5- N2WL
OPTION SETTING
[After replacing the Memory IC (IC802)]
The memory IC, IC802, stores the option data of the TV set and service adjustments data for each circuit, therefore,
when the memory IC is replaced, it should be set up following these settings and “SERVICE ADJUSTMENTS” on
the next page.
To enter to the Option Mode
+ Press and hold the F/OK button on the remote control and P▼button on the front panel of the TV. The option
window will appear on the screen.
To set the option mode
+ Highlight the desired option item by using the P▲or P▼ button .
+ To switch the option mode, use the Volume - (LEFT) or Volume + (RIGHT) button.
+ The data which is set in the option mode is stored into the memory IC automatically.
Following table shows the available option items and default setting mode.
Exit from the Service Mode
+ Press the MENU button.
Option Mode Mode Description & Note
ON-TIMER ON or OFF On-timer available, default “OFF”
PLUG AND PLAY ON or OFF Plug and Play mode, default “ON”
WELCOME TEXT ON or OFF Display message when first set up, default “ON”
BBE ON or OFF BBE sound mode, default “ON”
AUTO VOLUME OFF or ON Default “OFF”
HEADPHONE ON or OFF Headphone control , default “OFF”
CRT 16:9 MODE ON or OFF Default “ON”
NOISE REDUCTION ON or OFF Default “ON”
COUNTRY UK, IRE, UK/IRE, EU TV system, default “EU”
RASTER ROTATION ON or OFF Default “OFF”
SESA ON or OFF Default “OFF”
DIGITAL RC ON or OFF Digital option, default “ON”
LIGHT MONITORING ON or OFF Ambient light control of LCD brightness,default “OFF”
VIDEO MUTE ON or OFF Default “OFF”
ON-TIMER OFF
PLUG AND PLAY ON
WELCOME TEXT ON
BBE ON
AUTO VOLUME OFF
HEADPHONE OFF
16:9 MODE ON
NOISE REDUCTION ON
COUNTRY EU
RASTER ROTATION OFF
SESA OFF
DIGITAL RC ON
LIGHT MONITORING OFF
VIDEO MUTE OFF
OPTION MODE FOR CE27LC4-C-00

-6-
N2WL
SERVICE ADJUSTMENTS
INITIALISATION OF MEMORY IC
To initialise the memory IC (IC802), enter the service mode as below, navigate to “EEPROM Reset” and press OK
on the remote control. Turn the mains power off and on - the initialisation is now complete.
When initialised the memory IC and all of the setting data (option data and service adjustment data) stored in the IC
are reset to the default value. It is necessary to set the option settings, readjust the service adjustments and to
re-tune all the channels.
The available adjustment items are as follows;
TDA9885 : This can be adjusted for AGC.
Video : This can be adjusted for the service adjustment.
Others : ONLY use for greyscale adjustment
DO NOT ADJUST OTHER SETTINGS
[After replacing the Memory IC (IC803)]
The memory IC, IC802, stores the service adjustments data for each circuit, therefore, when the memory IC is
replaced, it should be programmed by using “OPTION SETTING” on previous page and the following adjustments.
While pressing the green button on the remote control press the P▼ on the cabinet front.
The service menu appears.
Use the 6or 5 to highlight the service menu you require and press the F/OK button to enter.
Press the Menu button to navigate backwards through the service menus until menus disappear.
Note: Some items of the service adjustments for this chassis are controlled by the CPU, IC801, and the
adjustments are carried out by using the RC handset.
TO ENTER SERVICE ADJUSTMENTS
TO EXIT SERVICE ADJUSTMENTS
Service
SV Vers 042
Sound
Video
Other
STV8206
TDA9885
STV2310
ADE3800
WSS
EEPROM Reset
IMPORTANT NOTICE
Do not attempt to adjust service adjustments not listed on the above otherwise it may cause
loss of performance and product safety.

-7- N2WL
Service menu: Video
Enter the service adjustment menu as described on the previous page and select “Video” using
the P▼or P▲buttons and then press the F/OK button to enter.
Use the P▼ or P▲ buttons to select the option, then press
the F/OK button on the remote control to enter.
Service menu: Sound
Enter the service adjustment menu as described on the previous page and select “Sound” using
the P▼ or P▲ buttons and then press the F/OK button to enter.
Use the P▼or P▲buttons to select the option, then
press the F/OK button on the remote control to enter.
Service menu: TDA9885
Enter the service adjustment menu as described on the previous page and select “TDA9885”
using the P▼ or P▲ buttons and then press the F/OK button to enter
Use the P▼ or P▲ buttons to select the option,
then press the F/OK button on the remote
control to enter.
VIDEO
G2 Alignment Config.
White Point R 41
White Point G 32
White Point B 36
Peak White Limiter 0
Black Level offset R 8
Black Level offset G 8
Gain pre-scale RGB 0
Fast blanking delay 0
Luma/Chroma delay 0
Restore default
Audio Menu
¥VL’ AGC Ads
Prescl Scart
Prescl FM
Prescl Nicam
Reserve sound
0
3
10
10
13
TDA9885
Write 1 70

-8-
N2WL
ADJUSTMENTS
IMPORTANT NOTICE
Do not attempt to adjust the following service adjustments except when adjustments are required in servicing
otherwise it may cause loss of performance and product safety.
1. Select the clearest VHF station
2. Connect a digital voltmeter to test point TP-A and GND
3. Enter service menu : TDA9885
4. With the P▼ or P▲ buttons select “Write 1”
5. Adjust using the or buttons until the read-
out from the voltmeter is 3.2 Vdc.
SCREEN ADJUSTMENT
1. Make sure the set is warm (20 mins)
2. Receive Black and White picture/pattern
3. Enter service menu “Others”
4. Use the +P and -P keys to navigate to item no 51
(white bal R) or no. 52 (white bal G)
5. Using the or buttons adjust to make the
white, white.
GREY SCALE ADJUSTMENT
AGC ADJUSTMENT

-9- N2WL
CPU PORT FUNCTIONS
STV3600BM
IC801
2
PORTC6/SDA
3
PORTC5/SCL_NVM
4
PORTC4/SDA_NVM
5
PORTD0/AV_CTL_A
6
PORTD1/LCD_ON
7
PORTD2/50/60HZ
8
PORTD3/AV_CTL_B
9
PORTD6/POWER_FAIL2
10
PORTA2/PLL_LOCK
11
PORTA3/LCD_BR
12
VSS_IO
13
VDD33_IO
14
VSS
15
VDD12_CORE
16
SDRAM_D7
17
SDRAM_D6
18
SDRAM_D5
19
SDRAM_D4
20
SDRAM_D3
21
SDRAM_D2
22
SDRAM_D1
23
SDRAM_D0
24
VSS_IO
25
VDD33_IO
26
SDRAM_D15
27
SDRAM_D14
28
SDRAM_D13
29
SDRAM_D12
30
SDRAM_D11
31
SDRAM_D10
32
SDRAM_D9
33
SDRAM_D8
34
VDD33_IO
35
VSS_IO
36
ADDR_13
37
NOT_BE1
38
ADDR_12
39
ADDR_11
40
ADDR_9
41
ADDR_8
42
ADDR_7
43
ADDR_6
44
ADDR_5
45
ADDR_4
46
CKOUT_SDRAM
47
VDD33_IO
48
VSS_IO
49
CKIN_SDRAM
50
ADDR_3
51
ADDR_2
52
ADDR_1
53
ADDR_0
54
ADDR_10
55
ADDR_16
56
ADDR_15
57
NOT_CS_SDRAM
58
NOT_RAS
59
NOT_CAS
60
RD_NOTWR
61
NOT_BE0
62
VDD12_CORE
63
VSS
64
VDD33_IO
65
VSS_IO
66
NOT_CS_FLASH
67
ADDR_17
68
ADDR_18
69
ADDR_19
70
ADDR_14
71
VDD12_CORE
72
VSS
73
FLASH_D15
74
FLASH_D7
75
FLASH_D14
76
FLASH_D6
77
FLASH_D13
78
FLASH_D5
79
FLASH_D12
80
FLASH_D4
81
VSS_IO
82
VDD33_IO
83
FLASH_D11
84
FLASH_D3
85
FLASH_D10
86
FLASH_D2
87
FLASH_D9
88
FLASH_D1
89
FLASH_D8
90
FLASH_D0
91
VSS
92
VDD12_CORE
93
TMS
94
TCK
95
TDO
96
TDI
97
TRST
98
NRESET
99
VSS
100
VDD12_CORE
101
VCC12_PLL2
102
GND_PLL2
103
VCC12_PLL3
104
GND_PLL3
105
XTALIN
106
XTALOUT
107
VCC12_IO
108
GND_IO
109
CLKXTM
110
CLKXTP
111
VSS_PLL
112
VDD12_PLL
113
SHIELD_PLL
114
VSYNC
115
HSYNC
116
CLK_DATA
117
YCRCB0
118
YCRCB1
119
YCRCB2
120
YCRCB3
121
YCRCB4
122
YCRCB5
123
YCRCB6
124
YCRCB7
125
VDD12_CORE
126
VSS
127
PORTC3/POWER3
128
PORTC2/AV_CTL_C
129
PORTC1/SCL_ADE3800
130
PORTC0/SDA_ADE3800
131
PORTA0/NRESET_OUT
132
PORTD4/RC_IN
133
PORTA1/POWER_FAIL1
134
PORTD7/POWER_INFO
135
PORTA4/LED/FLASH_TXD
136
PORTA5/MUTE/FLASH_RXD
137
PORTA6/SEL
138
PORTA7/STATUS/FAN_CTL
139
VDD33_IO
140
VSS_IO
141
PORTB5/AGC
142
PORTB4/SC3_8
143
PORTB3/SC2_8
144
PORTB2/SC1_8
145
PORTB1/KEYBOARD
146
PORTB0/POWER_SW
147
PORTD5/POWER1
148
VCC33_ADC
149
GND_ADC
150
SHIELD_ADCDAC
151
REXT
152
GND_REXT
153
PB_B
154
PR_R
155
Y_G
156
GND_DAC
157
VCC33_DAC
158
V100
159
H100
160
CLK_DFL/PIP_CLK
1
PORTC7/SCL
IC801

-10-
N2WL
IC801
IC BLOCK DIAGRAMS
Build-Up
YSI/CTI
Video
ST20 Core
H100
PR_R
Y_G
PB_B
SDRAM
SDIN
TNR
HV Filter
8
YCRCB[7:0]
CLK_DATA
Saturation
HSYNC
VSYNC
16/32
TV Peripherals
30
I/Os
Flash
Counter
NRESET
CLKXTM
Triple
Clock
Generator
2D
Block Move
OSD
Pipeline
Pipeline
Block
Time Base
Generator
TV Chassis Control
CSA
Comp.
Cursor
BG
Plane
Fast Blanking
EMI4
CLKXTP
Compositor
DAC
V100
CLK_DFL
27 MHz
Crystal
PIPIN
H/V Filter
8
YCRCB[7:0]

-11- N2WL
IC001 LA4919NE <Audio Output>













 

Multi-Standard
Demodulator
Diital
udio
Matri

 
  
 
oudeaer udio roein
         
eadone udio roein
  
   
  
 
 
 
 

 
   
  
   


  


  
 
 
 
 
 





 
 
 
   
 
udio Matriin
udio roein
Demodulation

oer Sul Manaement
   
   
nut S
Sound 
utut Sart
eadone
Suooer
oudeaer
 
Mono n


S
Diital Stereo

  


IC BLOCK DIAGRAMS
IC3451 STV8216T <NICAM & Stereo Sound Decoder>

-12-
N2WL
BLOCK DIAGRAMS
IC2001

-13- N2WL
PIN DESCRIPTION OF SEMICONDUCTORS
A
K
C
BE
C2
C1
B1 B2
E
C
CBE
KA
C
B
E
B2
B1
C1 C2
E
E
B
C
B2
B1
C1 C2
E
B2
B1 C1
C2
E1
E2
K
AA
A
KK
K
A
K
A
C
BECBEC
B
E
1
2
3
4
5
6
Index
12N
Index Index
12N
2
13
(IN) (OUT)
(GND)
21 4
2
1
3
Index
1
N
Index 1
N
Index 1
N
Index 1
N
Index 1
N
Index
1N
2
131
232
1
3
RESET GND
Vdd
5
3
D
GSD
G
S
K: Cathode
A: Anode
C: Collector
B: Base
E: Emitter
D: Drain
G: Gate
S: Source
●Diode
●Transistor/FET
●IC
E1
C2
E2 C1
B2
B1
Index
●Diode
●Transistor/FET
●IC
FET

-14-
9
N2WL
PARTS DESCRIPTION AND READING IN SCHEMATIC DIAGRAM
1. The parts specification of resistors, capacitors and
coils are expressed in designated code. Please
check the parts description by the following code
table.
2. Some of transistors and diodes are indicated in
mark for the substitution of parts name. Please
check the parts name by the following code table.
3. Voltages and waveforms were taken with a video
colour bar signal(1Vp-p at 75 ohms terminated) and
controls to normal.
4. Voltages were taken with a high-impedance digital
voltmetre.
Example 2000 K K 1000 BG
Characteristic
Example 160 E M 10
Capacitance value
Tolerance
Type
Rated voltage
Excepting electric capacitors, all
capacitance values of less than 1
are expressed in µF and more
than 1 are in pF.
Example L2 C1 4R7 K N
Tolerance
Inductance value
Manufacture code
Unique code
Mark Material
E Electrolytic
P Electrolytic (non-Polarised)
C Ceramic (temperature compensation)
K Ceramic
F Polyester
N Polypropylene
M Metalised polypropylene
H Metalised polypromylar
B Ceramic (semiconductor)
G Metalised polyester
Y Composite film
S Styrol
T Tantalum oxide solid electrolytic
U Organic semiconductive electrolyte
D Electric double layer electrolytic
Mark Tolerance
A not specified
B ±0.1
C ±0.25
D ±0.5
F±1
G±2
E ±2.5
H±3
J±5
K±0
M±20
N±30
P +100 -0
Q +30 -10
T +50 -10
U +75 -10
V +20 -10
W +100 -10
X +40 -20
Y +150 -10
Z +80 -20
Mark Tolerance (nH) Mark Tolerance (%)
C ±0.25 G ±2
D ±0.5 J ±5
S ±0.3 K ±10
A ±0.2 L ±15
M±20
Coil Reading
Capacitor Reading
Example 1/2 D J 10K B
Example 6 W K 8.2
Example 1/2 C K 1M
Resistor Reading
Characteristic
Z (Carbon fuse)
B (Non-burnable)
Resistance value
Tolerance (see below table)
Material (see below table)
Rated wattage (W)
K indicates in KΩ
M indicate in MΩ
Note: Resistor which is indicated with resistance value only are
1/6W carbon resistor. Resistor which is indicated with materi-
al, tolerance and value are 1/4W rated wattage.
Mark Material
D Carbon
N Metal film
S Oxide metal film
C Solid
G Metal glaze
W Wire wounding or cement
H Ceramic
F Fusible
Mark Tolerance
A ±0.05
B ±0.1
C ±0.25
D ±0.5
F±1
G±2
J±5
K±10
M±20
P +5 -15
Z used in 0 ohm
●Material table ●Tolerance table
●Material table ●Tolerance table
Mark Type number
-- 1S1555,1S2473,1S2076,1SS133,DS442,1SS176
K 1S1555,1S2473,1S2076,DS442
L 1S1555,1S2076A,1S2471
M 1SS133,1SS176,GMA01
N 1S1555,1S2473,1S2076,1SS133,DS442,1SS176,1N4148
P 1S1555,1S2076A,1S2471,1N4148
R 1S1555,1S2076,1S2473,DS442,1N4148
AA 1S1555,1S2076,1S2473,1SS133,DS442,1SS176,1N4148,GMA01
●Diode
Mark Type number
-- 2SC536 2SC945A 2SC1815 2SC1740 2SC1740S KSC945C
A E, F, G P, Q, R O, Y, G Q, R, S Q, R, S
B E, F, G P, Q, R O, Y, G Q, R, S
D F, G P, Q Y, G Q, R, S
F F, G P G R, S
H F, G P, Q Y, G Q, R, S Y, G
I E, F, G P, Q, R O, Y, G Q, R, S Y, G
G F, G P G R, S G
AD F, G Q, R Y, GR Q, R, S
AE E, F, G Q, R O, Y, GR Q, R, S
●Transistor (NPN type)
Mark Type number
-- 2SA608 2SA564A 2SA1015 2SA933 2SA933S KSA733C
Y E, F Q, R O, Y, G Q, R
WF R Y,GR
V E, F Q, R O, Y, G Q, R Y, G
U F R Y, G R G
Z E, F Q, R O, Y, G Q, R Q, R
AB F R Y Q, R
AE E, F Q, R O, Y R
●Transistor (PNP type)
Diode/Transistor Type Reading

-15- N2WL
CABINET PARTS LIST FOR MODEL CE27LC4-C-00
CABINET PARTS
1 610 319 4578 CABINET BACK-N2WJ
2 610 319 4554 CABINET FRONT-N2WJ
3 645 076 4936 BADGE,SANYO*53.5X12L53.5
4 610 320 2600 ASSY,STAND BASE-N2WJ
5 610 319 4547 BUTTON UNITED-N2W
6 610 319 4639 DEC IND-N2WJ
7 610 319 4622 DOOR-N2WJ
8 610 319 6572 MOUNTING BRKT-N2WJ
9 610 319 4769 STAND BASE-N2WJ
10 610 319 4776 STAND COVER-N2WJ
11 610 319 4806 TERMINAL BASE-N2WJ
12 645 079 9488 PAD (BLACK) RICHCO RBS-24
ACCESSORIES
13 645 075 1394 ASSY,REMOCON JXPTA
1AV4D11B06800 BATT ENERGIZER R03SHP2VP
665 000 4016 INST MANUAL - N2WL (1)
665 000 4023 INST MANUAL - N2WL (2)
665 000 4030 INST MANUAL - N2WL (3)
Item Part No. Description Item Part No. Description
Note: Parts order must contain Service Ref. No., Part No., and descriptions.
1
13
11
DS
1
2
65
3
4
8
12 x 4
9
10

N2WL -16-
CHASSIS ELECTRICAL PARTS LIST
Product safety should be considered when a component replacement is made in any area of a receiver.
Components indicated by a mark in this parts list and the circuit diagram show components whose value have
special significance to product safety. It is particularly recommended that only parts specified on the following
parts list be used for components replacement pointed out by the mark .
!
!
013N2WJ ELECTRICAL PARTS
LIQUID CRYSTAL DISPLAY
EL901 645 067 6215 LCD(V270W1-L04)
ELECTRICAL
FN902 645 068 3763 MOTOR,FAN DC
KLP1-PN 610 322 8631 CORD,30P 1.25MM(LVDS)
KSPL-A 645 033 2227 CORE, FERRITE
KSPR-A 645 033 2227 CORE, FERRITE
K8D-KD 645 078 3920 FLEXIBLE FLAT CABLE
SP901 652 001 4473 SPEAKER,8
SP902 652 001 4473 SPEAKER,8
W900 645 012 7632 EURO PLUG +2P HOUSE @ 2.1
W900-A 645 020 3640 FERRITE RING
Z801 610 322 9201 SHIELD CASE SCALER-N2WJ
1AA0B10N137BA ASSY,PWB,SIGNAL,N2WL
CAPACITOR
C001 403 314 5915 GRM21BR71C474KA01L PT297
C002 403 314 5915 GRM21BR71C474KA01L PT297
C003 403 387 6918 ELECT 100U M 25V
C004 403 387 7212 ELECT 47U M 25V
C005 403 184 8313 ELECT 22U M 25V
403 398 4712 25CE22BS 22U M 25V
C006 403 314 5915 GRM21BR71C474KA01L PT297
C007 403 184 8511 ELECT 2.2U M 50V
403 398 6518 50CE2R2BS 2.2U M 50V
C008 403 314 5915 GRM21BR71C474KA01L PT297
C009 403 155 2319 GRM188R71H472KA01D PT115
C010 403 155 2319 GRM188R71H472KA01D PT115
C013 403 113 3815 GRM188R71H102KA01D PT115
C014 403 042 4875 ELECT 1000U M 16V
C015 403 372 7517 CERAMIC 2.2U K 6.3V
C019 403 207 0317 GRM21BF51C105ZA01L PT297
C020 403 207 0317 GRM21BF51C105ZA01L PT297
C021 403 281 5215 GRM188F51C224ZA01D PT115
C022 403 281 5215 GRM188F51C224ZA01D PT115
C023 403 281 5215 GRM188F51C224ZA01D PT115
C024 403 281 5215 GRM188F51C224ZA01D PT115
C025 403 336 3517 CERAMIC 0.47U K 16V
C026 403 336 3517 CERAMIC 0.47U K 16V
C027 403 387 6918 ELECT 100U M 25V
C028 403 387 6918 ELECT 100U M 25V
C031 403 215 2211 GRM188R71H103KA01D PT115
C032 403 215 2211 GRM188R71H103KA01D PT115
C033 403 215 2211 GRM188R71H103KA01D PT115
C034 403 215 2211 GRM188R71H103KA01D PT115
C041 403 281 5215 GRM188F51C224ZA01D PT115
C042 403 281 5215 GRM188F51C224ZA01D PT115
C043 403 281 5215 GRM188F51C224ZA01D PT115
C044 403 281 5215 GRM188F51C224ZA01D PT115
Ref. No. Part No. Description
Chassis construction
CE27LC4-C-00
013N2WL ELECTRICAL PARTS (PAGE 16)
1AA0B10N137BA ASSY,PWB,SIGNAL,N2WL (PAGE 16 -22)
1AA0B10N1370B ASSY,PWB,CONTROL,N2WJ (PAGE 22)
1AA0B10N13900 ASSY,PWB,POWER,N2WJ (PAGE 22-25)
1AA0B10N13800 ASSY,PWB,SCAL,N2WJ (PAGE 25-29)
Read description in the Capacitor and Resistor as follows:
CAPACITOR
CERAMIC 100P K 50V
Tolerance Symbols:
Less than 10PF
A: Not specified B: ±0.1PF C: ±0.25PF
D: ±0.5PF F: ±1PF G:±2PF
R: ±0.25-0PF S: ±0-0.25PF E: +0-1PF
More than 10PF
A: Not specified B: ±0.1% C: ±0.25%
D: ±0.5% F: ±1% G:±2%
H: ±3% J: ±5% K: ±10%
L: ±15% M: ±20% N: ±30%
P: +100-0% Q: +30-10% T: +50-10%
U: +75-10% V: +20-10% W:+100-10%
X: +40-20% Y: +150-10% Z: +80-20%
Material:
CERAMIC............Ceramic
MT-PAPER ..........Metallized Paper
POLYESTER ......Polyester
MT-POLYEST......Metallized Polyester
POLYPRO............Polypropylene
MT-POLYPRO ....Metallized Polypropylene
COMPO FILM......Composite film
MT-COMPO ........Metallized Composite
STYRENE............Styrene
TA-SOLID ............Tantalum Solid
AL-SOLID............Aluminium Solid
ELECT ................Electrolytic
NP-ELECT ..........Non-polarised Electrolytic
OS-SOLID ..........Aluminium Solid with Organic Semiconductive Electrolytic
DL-ELECT ..........Double Layered Electrolytic
RESISTOR
CARBON 4.7K J A 1/4W Rated Wattage
Performance Symbols:
A: General B: Non flammable Z: Low noise
Other: Temperature coefficient
Tolerance Symbols:
A: ±0.05% B: ±0.1% C:±0.25% D: ±0.5%
F: ±1% G:±2% J: ±5% K: ±10%
M:±20% P: +5-15%
Rated value, ohms:
K: 1,000, M: 1,000,000
Material:
CARBON ............Carbon
MT-FILM ..............Metal Film
OXIDE-MT ..........Oxide Metal Film
SOLID..................Composition
MT-GLAZE ..........Metal Glaze
WIRE WOUND ....Wire Wound
CERAMIC RES....Ceramic
FUSIBLE RES ....Fusible
Rated Voltage
Rated value: P=pico farad, U=Micro farad
Note: Parts order must contain Service Ref. No., Part No., and descriptions.

-17- N2WL
Part No.
Ref. No. Part No.
Description Ref. No. Description
C049 403 155 2319 GRM188R71H472KA01D PT115
C050 403 155 2319 GRM188R71H472KA01D PT115
C1003 403 157 3611 GRM1885C1H101JZ01D PT115
C1005 403 157 3611 GRM1885C1H101JZ01D PT115
C1006 403 157 3611 GRM1885C1H101JZ01D PT115
C1007 403 157 3611 GRM1885C1H101JZ01D PT115
C1008 403 157 3611 GRM1885C1H101JZ01D PT115
C1009 403 157 3611 GRM1885C1H101JZ01D PT115
C101 403 184 8412 ELECT 4.7U M 25V
403 391 5716 25CE4R7BS 4.7U M 25V
C1010 403 215 2211 GRM188R71H103KA01D PT115
C1011 403 174 6213 ELECT 47U M 10V
403 398 3210 10CE47BS 47U M 10V
C1012 403 157 3611 GRM1885C1H101JZ01D PT115
C1013 403 323 8815 GRM21BF51C225ZA01K PT115
C1014 403 323 8815 GRM21BF51C225ZA01K PT115
C1015 403 157 3611 GRM1885C1H101JZ01D PT115
C1016 403 157 3611 GRM1885C1H101JZ01D PT115
C1017 403 157 3611 GRM1885C1H101JZ01D PT115
C1018 403 157 3611 GRM1885C1H101JZ01D PT115
C1019 403 157 3611 GRM1885C1H101JZ01D PT115
C102 403 215 2211 GRM188R71H103KA01D PT115
C1025 403 157 3611 GRM1885C1H101JZ01D PT115
C1026 403 157 3611 GRM1885C1H101JZ01D PT115
C1027 403 157 3611 GRM1885C1H101JZ01D PT115
C1028 403 157 3611 GRM1885C1H101JZ01D PT115
C103 403 224 3414 ELECT 220U M 6.3V
C1031 403 157 3611 GRM1885C1H101JZ01D PT115
C1032 403 323 8815 GRM21BF51C225ZA01K PT115
C1033 403 323 8815 GRM21BF51C225ZA01K PT115
C1034 403 157 3611 GRM1885C1H101JZ01D PT115
C1036 403 323 8815 GRM21BF51C225ZA01K PT115
C1037 403 323 8815 GRM21BF51C225ZA01K PT115
C1038 403 323 8815 GRM21BF51C225ZA01K PT115
C1039 403 323 8815 GRM21BF51C225ZA01K PT115
C104 403 215 2211 GRM188R71H103KA01D PT115
C1041 403 157 3611 GRM1885C1H101JZ01D PT115
C1042 403 157 3611 GRM1885C1H101JZ01D PT115
C1043 403 157 3611 GRM1885C1H101JZ01D PT115
C1044 403 157 3611 GRM1885C1H101JZ01D PT115
C1045 403 207 0317 GRM21BF51C105ZA01L PT297
C1046 403 207 0317 GRM21BF51C105ZA01L PT297
C1047 403 207 0317 GRM21BF51C105ZA01L PT297
C1050 403 215 2211 GRM188R71H103KA01D PT115
C106 403 073 1210 CERAMIC 0.033U K 50V
C107 403 073 1210 CERAMIC 0.033U K 50V
C108 403 215 2211 GRM188R71H103KA01D PT115
C111 403 215 2211 GRM188R71H103KA01D PT115
C1116 403 207 0317 GRM21BF51C105ZA01L PT297
C1117 403 207 0317 GRM21BF51C105ZA01L PT297
C1118 403 207 0317 GRM21BF51C105ZA01L PT297
C112 403 368 7316 CERAMIC 10U M 6.3V
403 370 7618 CERAMIC 10U M 603V
C113 403 155 2319 GRM188R71H472KA01D PT115
C114 403 155 2319 GRM188R71H472KA01D PT115
C115 403 155 2319 GRM188R71H472KA01D PT115
C116 403 172 6116 GRM1885C1H271JD01D PT115
C117 403 073 1210 CERAMIC 0.033U K 50V
C120 403 215 2211 GRM188R71H103KA01D PT115
C1200 403 323 8815 GRM21BF51C225ZA01K PT115
C1202 403 175 4218 ELECT 47U M 10V
403 398 3210 10CE47BS 47U M 10V
C1204 403 207 0317 GRM21BF51C105ZA01L PT297
C1205 403 323 8815 GRM21BF51C225ZA01K PT115
C1208 403 207 0317 GRM21BF51C105ZA01L PT297
C121 403 157 6513 CERAMIC 390P K 50V
C1211 403 153 9310 GRM1885C1H820JZ01D PT115
C1212 403 153 9310 GRM1885C1H820JZ01D PT115
C1213 403 323 8815 GRM21BF51C225ZA01K PT115
C1214 403 153 9310 GRM1885C1H820JZ01D PT115
C1215 403 323 8815 GRM21BF51C225ZA01K PT115
C1218 403 153 9310 GRM1885C1H820JZ01D PT115
C122 403 149 9218 GRM188F51H103ZA01D PT115
C123 403 314 5915 GRM21BR71C474KA01L PT297
C1230 403 164 0214 GRM188F51E104ZA01D PT115
C125 403 139 7118 GRM1885C1H120JZ01
C1254 403 153 9310 GRM1885C1H820JZ01D PT115
C1255 403 323 8815 GRM21BF51C225ZA01K PT115
C126 403 215 2211 GRM188R71H103KA01D PT115
C127 403 215 2211 GRM188R71H103KA01D PT115
C131 403 215 2211 GRM188R71H103KA01D PT115
C132 403 215 2211 GRM188R71H103KA01D PT115
C133 403 184 8214 UWX1E100MCL1GB
403 398 4415 25CE10BS
C134 403 149 9218 GRM188F51H103ZA01D PT115
C137 403 256 5011 CERAMIC 560P J 50V
C138 403 256 5011 CERAMIC 560P J 50V
C141 403 314 5915 GRM21BR71C474KA01L PT297
C142 403 269 5916 GRM219R71C224KC01D PT115
C143 403 155 2111 GRM188R71H152KD01D PT115
C144 403 155 2418 GRM188R71H562KA01D PT115
C146 403 113 3815 GRM188R71H102KA01D PT115
C147 403 113 3815 GRM188R71H102KA01D PT115
C148 403 157 7114 GRM188R71H272KA01D PT115
C1841 403 184 8313 ELECT 22U M 25V
403 398 4712 25CE22BS 22U M 25V
C1851 403 184 8313 ELECT 22U M 25V
403 398 4712 25CE22BS 22U M 25V
C1858 403 149 9218 GRM188F51H103ZA01D PT115
C1861 403 149 9218 GRM188F51H103ZA01D PT115
C1862 403 184 8313 ELECT 22U M 25V
403 398 4712 25CE22BS 22U M 25V
C1863 403 164 0214 GRM188F51E104ZA01D PT115
C3406 403 164 0214 GRM188F51E104ZA01D PT115
C3408 401 105 7919 MT-GLAZE 0.000 ZA 1/16W
C3431 403 157 3611 GRM1885C1H101JZ01D PT115
C3433 403 157 3611 GRM1885C1H101JZ01D PT115
C3441 403 157 3611 GRM1885C1H101JZ01D PT115
C3442 403 279 4312 GRM21BR71C334KA01L PT297
C3443 403 157 3611 GRM1885C1H101JZ01D PT115
C3444 403 279 4312 GRM21BR71C334KA01L PT297
C3445 403 157 3611 GRM1885C1H101JZ01D PT115
C3446 403 279 4312 GRM21BR71C334KA01L PT297
C3447 403 157 3611 GRM1885C1H101JZ01D PT115
C3448 403 279 4312 GRM21BR71C334KA01L PT297
C3449 403 164 0214 GRM188F51E104ZA01D PT115
C3450 403 184 8214 UWX1E100MCL1GB
403 398 4415 25CE10BS
C3451 403 269 5916 GRM219R71C224KC01D PT115
C3452 403 164 0214 GRM188F51E104ZA01D PT115
C3454 403 157 3611 GRM1885C1H101JZ01D PT115
C3455 403 164 0214 GRM188F51E104ZA01D PT115
C3456 403 207 0317 GRM21BF51C105ZA01L PT297
C3457 403 368 7316 CERAMIC 10U M 6.3V
C3458 403 368 7316 CERAMIC 10U M 6.3V
C3461 403 164 0214 GRM188F51E104ZA01D PT115
C3462 403 184 8214 UWX1E100MCL1GB
403 398 4415 25CE10BS
C3463 403 164 0214 GRM188F51E104ZA01D PT115
C3464 403 184 8214 UWX1E100MCL1GB
403 398 4415 25CE10BS
C3465 403 164 0214 GRM188F51E104ZA01D PT115
C3466 403 184 8214 UWX1E100MCL1GB
403 398 4415 25CE10BS
C3467 403 164 0214 GRM188F51E104ZA01D PT115
C3468 403 184 8214 UWX1E100MCL1GB
403 398 4415 25CE10BS
C3469 403 164 0214 GRM188F51E104ZA01D PT115
C3470 403 184 8214 UWX1E100MCL1GB
C3477 403 184 8214 UWX1E100MCL1GB

-18-
N2WL
Ref. No. Part No. Description Ref. No. Part No. Description
403 398 4415 25CE10BS
C3478 403 164 0214 GRM188F51E104ZA01D PT115
C3481 403 155 4214 GRM1885C1H150JD01D PT115
C3482 403 139 7316 GRM1882C1H180JA01D PT115
C3483 403 164 0214 GRM188F51E104ZA01D PT115
C3484 403 164 0214 GRM188F51E104ZA01D PT115
C3486 403 164 0214 GRM188F51E104ZA01D PT115
C3487 403 178 6318 ELECT 100U M 6.3V
403 391 5815 6.3CE100BS 100U M 6.3V
C3501 403 387 6918 ELECT 100U M 25V
C3502 403 325 6314 CERAMIC 0.22U K 10V
C3503 403 325 6314 CERAMIC 0.22U K 10V
C3504 403 164 0214 GRM188F51E104ZA01D PT115
C3505 403 272 5613 CERAMIC 0.033U K 16V
C3506 403 155 2210 GRM188R71H332KA01D PT115
C3507 403 184 8214 UWX1E100MCL1GB
C3508 403 184 8214 UWX1E100MCL1GB
C3509 403 155 2210 GRM188R71H332KA01D PT115
C3510 403 272 5613 CERAMIC 0.033U K 16V
C3511 403 207 0317 GRM21BF51C105ZA01L PT297
C3512 403 184 8214 UWX1E100MCL1GB
403 398 4415 25CE10BS
C3513 403 368 7316 CERAMIC 10U M 6.3V
403 370 7618 CERAMIC 10U M 603V
C3514 403 207 0317 GRM21BF51C105ZA01L PT297
C3515 403 368 7316 CERAMIC 10U M 6.3V
403 370 7618 CERAMIC 10U M 603V
C6602 403 149 9218 GRM188F51H103ZA01D PT115
C6604 403 397 6014 ELECT 1000U M 10V
C6618 403 397 6717 ELECT 470U M 25V
C6624 403 164 0214 GRM188F51E104ZA01D PT115
C6626 403 387 6918 ELECT 100U M 25V
C6628 403 397 6014 ELECT 1000U M 10V
C6630 403 178 6318 ELECT 100U M 6.3V
403 391 5815 6.3CE100BS 100U M 6.3V
C6632 403 279 4312 GRM21BR71C334KA01L PT297
C6633 403 178 6318 ELECT 100U M 6.3V
403 391 5815 6.3CE100BS 100U M 6.3V
C6634 403 279 4312 GRM21BR71C334KA01L PT297
C6635 403 178 6318 ELECT 100U M 6.3V
403 391 5815 6.3CE100BS 100U M 6.3V
C6636 403 279 4312 GRM21BR71C334KA01L PT297
C6637 403 178 6318 ELECT 100U M 6.3V
403 391 5815 6.3CE100BS 100U M 6.3V
DIODE
D001 407 149 6324 DIODE SFPB-54V
D1001 407 206 5618 ZENER D. UDZS-TE-1710B
D1002 407 206 5618 ZENER D. UDZS-TE-1710B
D1003 407 206 5618 ZENER D. UDZS-TE-1710B
D1004 407 206 5618 ZENER D. UDZS-TE-1710B
D1005 407 206 5618 ZENER D. UDZS-TE-1710B
D1006 407 206 5618 ZENER D. UDZS-TE-1710B
D1007 407 206 5618 ZENER D. UDZS-TE-1710B
D1008 407 206 5618 ZENER D. UDZS-TE-1710B
D1009 407 206 5618 ZENER D. UDZS-TE-1710B
D101 407 149 0817 DIODE 1SS355-TE-17
D1012 407 206 5618 ZENER D. UDZS-TE-1710B
D1013 407 206 5618 ZENER D. UDZS-TE-1710B
D1014 407 206 5618 ZENER D. UDZS-TE-1710B
D1017 407 206 5618 ZENER D. UDZS-TE-1710B
D1018 407 206 5618 ZENER D. UDZS-TE-1710B
D1019 407 206 5618 ZENER D. UDZS-TE-1710B
D102 407 149 0817 DIODE 1SS355-TE-17
D103 407 149 0817 DIODE 1SS355-TE-17
D104 407 228 4910 ZENER DIODE UDZS33B-TE-17
D1058 407 206 5618 ZENER D. UDZS-TE-1710B
D1201 407 149 0817 DIODE 1SS355-TE-17
D1202 407 206 5618 ZENER D. UDZS-TE-1710B
D1203 407 206 5618 ZENER D. UDZS-TE-1710B
D1204 407 149 0817 DIODE 1SS355-TE-17
D1205 407 206 5618 ZENER D. UDZS-TE-1710B
D1206 407 206 5618 ZENER D. UDZS-TE-1710B
D121 407 166 1118 DIODE 1SS356-TW11
D1841 407 149 0817 DIODE 1SS355-TE-17
D1842 407 149 0817 DIODE 1SS355-TE-17
D1856 407 201 2721 DIODE RB051L-40-TE25
D202 407 206 5618 ZENER D. UDZS-TE-1710B
D3443 407 206 5618 ZENER D. UDZS-TE-1710B
D3444 407 206 5618 ZENER D. UDZS-TE-1710B
D3501 407 210 5413 DIODE RB551V-30-TE-17
D6601 407 149 0817 DIODE 1SS355-TE-17
D6608 407 149 0817 DIODE 1SS355-TE-17
D6611 407 149 0817 DIODE 1SS355-TE-17
D6613 407 149 0817 DIODE 1SS355-TE-17
D6618 407 149 0817 DIODE 1SS355-TE-17
INTEGRATED CIRCUIT
IC001 409 591 8707 IC LA4919N-E
IC001A 610 315 3452 HEAT SINK
IC101 409 549 8219 IC TDA9886TS/V4
IC1205 409 311 4121 IC BA7603F
IC1222 409 051 2722 IC TC4052BF(EL)
IC1224 409 631 2217 IC BA7626F
IC1841 409 039 6322 IC NJM2903M-T2
409 644 2013 IC BA2903F
IC1851 409 039 6629 IC NJM2904-T2
409 644 1917 IC BA2904F
IC3451 409 550 6815 IC STV8216T
IC3501 409 501 0411 IC NJM2155M
IC6604 409 493 2912 IC SI-3012LU-TL
IC6606 409 503 8019 IC BA05SFP
IC6608 409 578 0314 IC BA18BC0FP
IC6642 409 588 6313 IC BA33BC0FP
COIL
L001 645 066 2416 INDUCTOR,180U M
L002 645 036 3894 BLM21PG221SN1D E258
L003 645 004 0351 INDUCTOR 12U K
L004 645 004 0351 INDUCTOR 12U K
L1001 645 036 3894 BLM21PG221SN1D E258
L1001A 645 036 3894 BLM21PG221SN1D E258
L1002 645 036 3894 BLM21PG221SN1D E258
L1002A 645 036 3894 BLM21PG221SN1D E258
L1003 645 036 3894 BLM21PG221SN1D E258
L101 645 049 6875 IMPEDANCE,1000 OHM P
L102 645 075 7419 INDUCTOR,390U J
L103 645 059 2782 INDUCTOR,47U M
L1201 645 037 1615 SMDCOIL LEM2520T4R7J
L1202 645 037 1615 SMDCOIL LEM2520T4R7J
L1203 645 037 1615 SMDCOIL LEM2520T4R7J
L1204 645 037 1615 SMDCOIL LEM2520T4R7J
L1205 645 037 1615 SMDCOIL LEM2520T4R7J
L1851 645 033 7918 INDUCTOR,10U M
L1852 645 036 3894 BLM21PG221SN1D E258
L1853 645 036 3894 BLM21PG221SN1D E258
L3452 645 036 3894 BLM21PG221SN1D E258
L3453 645 036 3894 BLM21PG221SN1D E258
TRANSISTOR
Q001 406 017 2400 TR BC847B,215
405 014 4618 TR 2SC2412KT146/S
405 015 8724 TR 2SC2812TR 2SC2812-L6-T
405 015 8922 TR 2SC2812-L7-TA
405 163 1612 TR 2SC2812TR 2SC2812-L6-T
405 1631 711 TR 2SC2812-L7-TA
405 173 9813 TR 2SC3928A1R
405 173 9912 TR 2SC3928A1S
Q002 405 118 5729 TR 2SD2198-R-DL
Q003 406 017 2400 TR BC847B,215
405 014 4618 TR 2SC2412KT146/S

-19- N2WL
Ref. No. Part No. Part No.Description Ref. No. Description
405 015 8724 TR 2SC2812TR 2SC2812-L6-T
405 015 8922 TR 2SC2812-L7-TA
405 163 1612 TR 2SC2812TR 2SC2812-L6-T
405 163 1711 TR 2SC2812-L7-TA
405 173 9813 TR 2SC3928A1R
405 173 9912 TR 2SC3928A1S
Q004 406 017 2400 TR BC847B,215
405 014 4618 TR 2SC2412KT146/S
405 015 8724 TR 2SC2812TR 2SC2812-L6-T
405 015 8922 TR 2SC2812-L7-TA
405 163 1612 TR 2SC2812TR 2SC2812-L6-T
405 163 1711 TR 2SC2812-L7-TA
405 173 9813 TR 2SC3928A1R
405 173 9912 TR 2SC3928A1S
Q1003 406 017 2103 TR BC857B,215 3000/REEL
405 147 2215 TR 2SA1037AK-S-14
405 002 0318 TR 2SA1037K-T96-R
405 002 0417 TR 2SA1037K-T146 S
405 002 6726 TR 2SA1179-M6-TB
405 002 6924 TR 2SA1179-M7-TB
405 163 1513 TR 2SA1179N-M6-TB
405 163 2718 TR 2SA1179N-M7-TB
405 173 9615 TR 2SA1235A1E-P
405 173 9714 TR 2SA1235A1E-F
Q1004 406 017 2400 TR BC847B,215
405 014 4618 TR 2SC2412KT146/S
405 015 8724 TR 2SC2812TR 2SC2812-L6-T
405 015 8922 TR 2SC2812-L7-TA
405 163 1612 TR 2SC2812TR 2SC2812-L6-T
405 163 1711 TR 2SC2812-L7-TA
405 173 9813 TR 2SC3928A1R
405 173 9912 TR 2SC3928A1S
Q1005 406 017 2400 TR BC847B,215
Q111 406 017 2400 TR BC847B,215
405 014 4618 TR 2SC2412KT146/S
405 015 8724 TR 2SC2812TR 2SC2812-L6-T
405 015 8922 TR 2SC2812-L7-TA
405 163 1612 TR 2SC2812TR 2SC2812-L6-T
405 163 1711 TR 2SC2812-L7-TA
405 173 9813 TR 2SC3928A1R
405 173 9912 TR 2SC3928A1S
Q112 405 015 9721 TR 2SC2814-F4-TB
405 015 9929 TR 2SC2814-F5-TB
Q113 405 015 9721 TR 2SC2814-F4-TB
405 015 9929 TR 2SC2814-F5-TB
Q114 405 210 9912 TR 2SC5730-R
Q1201 406 017 2400 TR BC847B,215
405 014 4618 TR 2SC2412KT146/S
405 015 8724 TR 2SC2812TR 2SC2812-L6-T
405 015 8922 TR 2SC2812-L7-TA
405 163 1612 TR 2SC2812TR 2SC2812-L6-T
405 163 1711 TR 2SC2812-L7-TA
405 173 9813 TR 2SC3928A1R
405 173 9912 TR 2SC3928A1S
Q1202 406 017 2103 TR BC857B,215 3000/REEL
405 147 2215 TR 2SA1037AK-S-14
405 002 0318 TR 2SA1037K-T96-R
405 002 0417 TR 2SA1037K-T146 S
405 002 6726 TR 2SA1179-M6-TB
405 002 6924 TR 2SA1179-M7-TB
405 163 1513 TR 2SA1179N-M6-TB
405 163 2718 TR 2SA1179N-M7-TB
405 173 9615 TR 2SA1235A1E-P
405 173 9714 TR 2SA1235A1E-F
Q1204 406 017 2400 TR BC847B,215
405 014 4618 TR 2SC2412KT146/S
405 015 8724 TR 2SC2812TR 2SC2812-L6-T
405 015 8922 TR 2SC2812-L7-TA
405 163 1612 TR 2SC2812TR 2SC2812-L6-T
405 163 1711 TR 2SC2812-L7-TA
405 173 9813 TR 2SC3928A1R
405 173 9912 TR 2SC3928A1S
Q1205 406 017 2103 TR BC857B,215 3000/REEL
405 147 2215 TR 2SA1037AK-S-14
405 002 0318 TR 2SA1037K-T96-R
405 002 0417 TR 2SA1037K-T146 S
405 002 6726 TR 2SA1179-M6-TB
405 002 6924 TR 2SA1179-M7-TB
405 163 1513 TR 2SA1179N-M6-TB
405 163 2718 TR 2SA1179N-M7-TB
405 173 9615 TR 2SA1235A1E-P
405 173 9714 TR 2SA1235A1E-F
Q1262 406 017 2400 TR BC847B,215
405 014 4618 TR 2SC2412KT146/S
405 015 8724 TR 2SC2812TR 2SC2812-L6-T
405 015 8922 TR 2SC2812-L7-TA
405 163 1612 TR 2SC2812TR 2SC2812-L6-T
405 163 1711 TR 2SC2812-L7-TA
405 173 9813 TR 2SC3928A1R
405 173 9912 TR 2SC3928A1S
Q131 406 017 2400 TR BC847B,215
405 014 4618 TR 2SC2412KT146/S
405 015 8724 TR 2SC2812TR 2SC2812-L6-T
405 015 8922 TR 2SC2812-L7-TA
405 163 1612 TR 2SC2812TR 2SC2812-L6-T
405 163 1711 TR 2SC2812-L7-TA
405 173 9813 TR 2SC3928A1R
405 173 9912 TR 2SC3928A1S
Q133 406 017 2400 TR BC847B,215
405 014 4618 TR 2SC2412KT146/S
405 015 8724 TR 2SC2812TR 2SC2812-L6-T
405 015 8922 TR 2SC2812-L7-TA
405 163 1612 TR 2SC2812TR 2SC2812-L6-T
405 163 1711 TR 2SC2812-L7-TA
405 173 9813 TR 2SC3928A1R
405 173 9912 TR 2SC3928A1S
Q134 406 017 2103 TR BC857B,215 3000/REEL
405 147 2215 TR 2SA1037AK-S-14
405 002 0318 TR 2SA1037K-T96-R
405 002 0417 TR 2SA1037K-T146 S
405 002 6726 TR 2SA1179-M6-TB
405 002 6924 TR 2SA1179-M7-TB
405 163 1513 TR 2SA1179N-M6-TB
405 163 2718 TR 2SA1179N-M7-TB
405 173 9615 TR 2SA1235A1E-P
405 173 9714 TR 2SA1235A1E-F
Q1851 405 148 2917 TR 2SC5103 TL P
Q1854 406 017 2400 TR BC847B,215
405 014 4618 TR 2SC2412KT146/S
405 015 8724 TR 2SC2812TR 2SC2812-L6-T
405 015 8922 TR 2SC2812-L7-TA
405 163 1612 TR 2SC2812TR 2SC2812-L6-T
405 163 1711 TR 2SC2812-L7-TA
405 173 9813 TR 2SC3928A1R
405 173 9912 TR 2SC3928A1S
Q1855 406 017 2400 TR BC847B,215
405 014 4618 TR 2SC2412KT146/S
405 015 8724 TR 2SC2812TR 2SC2812-L6-T
405 015 8922 TR 2SC2812-L7-TA
405 163 1612 TR 2SC2812TR 2SC2812-L6-T
405 163 1711 TR 2SC2812-L7-TA
405 173 9813 TR 2SC3928A1R
405 173 9912 TR 2SC3928A1S
Q1856 406 017 2400 TR BC847B,215
Q6606 406 017 2400 TR BC847B,215
405 014 4618 TR 2SC2412KT146/S
405 015 8724 TR 2SC2812TR 2SC2812-L6-T
405 015 8922 TR 2SC2812-L7-TA
405 163 1612 TR 2SC2812TR 2SC2812-L6-T
405 163 1711 TR 2SC2812-L7-TA

-20-
N2WL
Part No.
Ref. No. Description Ref. No. Part No. Description
405 173 9813 TR 2SC3928A1R
405 173 9912 TR 2SC3928A1S
Q6607 406 017 2400 TR BC847B,215
405 014 4618 TR 2SC2412KT146/S
405 015 8724 TR 2SC2812TR 2SC2812-L6-T
405 015 8922 TR 2SC2812-L7-TA
405 163 1612 TR 2SC2812TR 2SC2812-L6-T
405 163 1711 TR 2SC2812-L7-TA
405 173 9813 TR 2SC3928A1R
405 173 9912 TR 2SC3928A1S
RESISTOR
R001 401 105 7919 MT-GLAZE 0.000 ZA 1/16W
R002 401 105 7919 MT-GLAZE 0.000 ZA 1/16W
R003 401 105 2013 MT-GLAZE 1.8K JA 1/16W
R004 401 105 4215 T-GLAZE 33K JA 1/16W
R005 401 105 2013 MT-GLAZ 1.8K JA 1/16W
R006 401 105 4215 MT-GLAZE 33K JA 1/16W
R008 401 105 4215 MT-GLAZE 33K JA 1/16W
R009 401 105 2914 MT-GLAZE 22K JA 1/16W
R010 401 10 50613 MT-GLAZE 10K JA 1/16W
R011 401 276 4717 MT-GLAZE 0.000 ZA 1/3W
R012 401 276 4717 MT-GLAZE 0.000 ZA 1/3W
R013 401 037 5014 MT-GLAZE 0.000 ZA 1/10W
R021 401 259 1511 MT-GLAZE 2.2 JA 1/3W
R022 401 259 1511 MT-GLAZE 2.2 JA 1/3W
R023 401 259 1511 MT-GLAZE 2.2 JA 1/3W
R024 401 259 1511 MT-GLAZE 2.2 JA 1/3W
R026 401 105 0316 MT-GLAZE 10 JA 1/16W
R027 401 105 0316 MT-GLAZE 10 JA 1/16W
R028 401 105 6516 MT-GLAZE 680 JA 1/16W
R029 401 105 6516 MT-GLAZE 680 JA 1/16W
R041 401 105 0613 MT-GLAZE 10K JA 1/16W
R042 401 105 0613 MT-GLAZE 10K JA 1/16W
R043 401 105 1511 MT-GLAZE 1.5K JA 1/16W
R045 401 105 1511 MT-GLAZE 1.5K JA 1/16W
R049 401 105 2914 MT-GLAZE 22K JA 1/16W
R051 401 105 4215 MT-GLAZE 33K JA 1/16W
R052 401 276 4717 MT-GLAZE 0.000 ZA 1/3W
R1001 401 105 1412 MT-GLAZE 150 JA 1/16W
R1002 401 105 1412 MT-GLAZE 150 JA 1/16W
R1003 401 037 2815 MT-GLAZE 75 JA 1/8W
R1005 401 105 2815 MT-GLAZE 2.2K JA 1/16W
R1006 401 105 2716 MT-GLAZE 220 JA 1/16W
R1007 401 105 2815 MT-GLAZE 2.2K JA 1/16W
R1008 401 105 2716 MT-GLAZE 220 JA 1/16W
R1009 401 105 2815 MT-GLAZE 2.2K JA 1/16W
R101 401 105 0415 MT-GLAZE 100 JA 1/16W
R1011 401 105 0613 MT-GLAZE 10K JA 1/16W
R1012 401 105 4116 MT-GLAZE 3.3K JA 1/16W
R1013 401 105 2716 MT-GLAZE 220 JA 1/16W
R1014 401 105 2815 MT-GLAZE 2.2K JA 1/16W
R1015 401 105 2815 MT-GLAZE 2.2K JA 1/16W
R1016 401 105 2815 MT-GLAZE 2.2K JA 1/16W
R1017 401 105 2716 MT-GLAZE 220 JA 1/16W
R1018 401 105 2716 MT-GLAZE 220 JA 1/16W
R1019 401 105 2716 MT-GLAZE 220 JA 1/16W
R102 401 105 0415 MT-GLAZE 100 JA 1/16W
R1020 401 105 0415 MT-GLAZE 100 JA 1/16W
R1021 401 105 1412 MT-GLAZE 150 JA 1/16W
R1022 401 105 1412 MT-GLAZE 150 JA 1/16W
R1023 401 037 2815 MT-GLAZE 75 JA 1/8W
R1024 401 105 0514 MT-GLAZE 1K JA 1/16W
R1026 401 105 0514 MT-GLAZE 1K JA 1/16W
R1027 401 260 8417 MT-GLAZE 22 JA 1/3W
R1028 401 105 2815 MT-GLAZE 2.2K JA 1/16W
R1029 401 105 2815 MT-GLAZE 2.2K JA 1/16W
R103 401 105 0613 MT-GLAZE 10K JA 1/16W
R1030 401 105 2716 MT-GLAZE 220 JA 1/16W
R1031 401 105 0613 MT-GLAZE 10K JA 1/16W
R1032 401 105 4116 MT-GLAZE 3.3K JA 1/16W
R1033 401 105 2716 MT-GLAZE 220 JA 1/16W
R1034 401 105 2716 MT-GLAZE 220 JA 1/16W
R1035 401 105 2716 MT-GLAZE 220 JA 1/16W
R1036 401 113 4412 MT-GLAZE 75 JA 1/16W
R1037 401 113 4412 MT-GLAZE 75 JA 1/16W
R1038 401 113 4412 MT-GLAZE 75 JA 1/16W
R1039 401 113 4412 MT-GLAZE 75 JA 1/16W
R104 401 105 0613 MT-GLAZE 10K JA 1/16W
R1040 401 113 4412 MT-GLAZE 75 JA 1/16W
R1041 401 105 0415 MT-GLAZE 100 JA 1/16W
R1042 401 105 0415 MT-GLAZE 100 JA 1/16W
R1043 401 105 0415 MT-GLAZE 100 JA 1/16W
R1044 401 105 0415 MT-GLAZE 100 JA 1/16W
R1046 401 113 4412 MT-GLAZE 75 JA 1/16W
R1047 401 113 4412 MT-GLAZE 75 JA 1/16W
R1049 401 113 4412 MT-GLAZE 75 JA 1/16W
R1051 401 105 0415 MT-GLAZE 100 JA 1/16W
R1052 401 105 0415 MT-GLAZE 100 JA 1/16W
R1054 401 105 2815 MT-GLAZE 2.2K JA 1/16W
R1055 401 105 2815 MT-GLAZE 2.2K JA 1/16W
R1056 401 105 1412 MT-GLAZE 150 JA 1/16W
R1057 401 105 1412 MT-GLAZE 150 JA 1/16W
R1058 401 105 0613 MT-GLAZE 10K JA 1/16W
R1059 401 105 4116 MT-GLAZE 3.3K JA 1/16W
R106 401 105 2815 MT-GLAZE 2.2K JA 1/16W
R107 401 105 7919 MT-GLAZE 0.000 ZA 1/16W
R1071 401 105 1412 MT-GLAZE 150 JA 1/16W
R1072 401 105 1412 MT-GLAZE 150 JA 1/16W
R1073 401 105 2815 MT-GLAZE 2.2K JA 1/16W
R1074 401 105 2815 MT-GLAZE 2.2K JA 1/16W
R1078 401 105 8213 MT-GLAZE ERJ 3GEYJ683V
R1079 401 105 8213 MT-GLAZE ERJ 3GEYJ683V
R1080 401 105 7919 MT-GLAZE 0.000 ZA 1/16W
R1081 401 105 5915 MT-GLAZE 560 JA 1/16W
R109 401 105 2617 MT-GLAZE ERJ-3GEYJ220V
R110 401 105 4116 MT-GLAZE 3.3K JA 1/16W
R111 401 105 5113 MT-GLAZE 47 JA 1/16W
R1112 401 105 7919 MT-GLAZE 0.000 ZA 1/16W
R1117 401 105 7919 MT-GLAZE 0.000 ZA 1/16W
R1118 401 105 7919 MT-GLAZE 0.000 ZA 1/16W
R112 401 105 4017 MT-GLAZE 330 JA 1/16W
R1128 401 105 7919 MT-GLAZE 0.000 ZA 1/16W
R1129 401 105 7919 MT-GLAZE 0.000 ZA 1/16W
R113 401 105 0613 MT-GLAZE 10K JA 1/16W
R1130 401 105 7919 MT-GLAZE 0.000 ZA 1/16W
R116 401 105 0415 MT-GLAZE 100 JA 1/16W
R118 401 105 0613 MT-GLAZE 10K JA 1/16W
R120 401 105 6011 MT-GLAZE 5.6K JA 1/16W
R1200 401 105 0613 MT-GLAZE 10K JA 1/16W
R1201 401 105 3218 MT-GLAZE 270 JA 1/16W
R1202 401 105 0415 MT-GLAZE 100 JA 1/16W
R1203 401 105 5311 MT-GLAZE 4.7K JA 1/16W
R1204 401 105 0613 MT-GLAZE 10K JA 1/16W
R1205 401 105 0613 MT-GLAZE 10K JA 1/16W
R1206 401 105 3218 MT-GLAZE 270 JA 1/16W
R1207 401 105 0415 MT-GLAZE 100 JA 1/16W
R1208 401 105 5311 MT-GLAZE 4.7K JA 1/16W
R121 401 105 0415 MT-GLAZE 100 JA 1/16W
R1210 401 105 0415 MT-GLAZE 100 JA 1/16W
R1211 401 105 0415 MT-GLAZE 100 JA 1/16W
R1212 401 105 0415 MT-GLAZE 100 JA 1/16W
R1213 401 105 0415 MT-GLAZE 100 JA 1/16W
R1214 401 105 0415 MT-GLAZE 100 JA 1/16W
R1215 401 105 0415 MT-GLAZE 100 JA 1/16W
R1216 401 105 0415 MT-GLAZE 100 JA 1/16W
R1217 401 105 0415 MT-GLAZE 100 JA 1/16W
R122 401 105 0415 MT-GLAZE 100 JA 1/16W
R123 401 105 3317 MT-GLAZE 2.7K JA 1/16W
R1230 401 105 3218 MT-GLAZE 270 JA 1/16W
