Sanyo LCD-47S10-HD User manual
M
odel No. L
C
D-47
S
1
0
-HD
S
ervice Re
f
.No.L
C
D-47
S
10-HD-0
0
S
ERVI
C
E MAN
U
AL L
C
D Televisio
n
S
a
f
ety Notice...............................................2
6
SHFL
¿
FDWLRQV
C
hassis Block Diagrams.............................4
C
PU Block Diagram
s
.................................5
O
n-screen
S
ervice Menu
S
yste
m
...............6
S
ervice Adjustment
s
...................................7
M
ec
h
an
i
ca
l
Di
sassem
bly
..........................8-9
C
hassis Electrical Parts Lis
t
3
&
%$VVHPEOH
P
r
i
nte
d
Wi
r
i
ng
B
oar
d
S
chematic Diagra
m
.
.............................40-42
3URGXFW
&
RGH
6
+'
O
riginal Versio
n
&
KDVVLV
6
HULHV8+
%
N
6
PW
C
ontents
FILE N
O
.
G
ive complete "
S
ERVI
C
E REF. N
O
."
f
o
r
parts or
d
er or serv
i
c
i
n
g
.
I
t
i
s s
h
own on t
h
e
ratin
g
lable at the cabinet back o
f
the unit.
r
Thi
s
T
.
V
. rece
i
ver w
ill
not wor
k
proper
ly
in
f
orei
g
n countries where the television
transm
i
ss
i
on s
y
stem an
d
power source
GL
II
HU
I
URPWKHGHVLJQVSHFL
¿
FDWLRQV5H
I
H
U
WRWKHVSHFL
¿
FDWLRQWDEOH
U
2
Safety Notice
Safety Precautions
The following precautions must be observed.
1:Comply with all caution and safety-related notes provided on the cabinet back, cabinet bottom, inside the
cabinet or on the chassis.
2:When replacing a chassis in the cabinet, always be certain that all the protective devices are installed
properly, such as, control knobs, adjustment covers or shields, barriers, etc..
DO NOT OPERATE THIS TELEVISION WITHOUT THE PROTECTIVE SHIELD IN POSITION AND
PROPERLY SECURED
%HIRUHUHSODFLQJWKHFDELQHWFRYHUWKRURXJKO\LQVSHFWWKHLQVLGHRIWKHFDELQHWWRVHHWKDWQRVWUD\SDUWVRU
tools have been left inside.
Before returning any televison to the customer, the service personnel must be sure that it is completely safe
to operate without danger of electrical shock.
Product Safety Notice
Product safety should be considered when a component replacement is made in any area of a receiver.
Components indicated by mark in the parts list and the schematic diagram designate components in
ZKLFKVDIHW\FDQEHRIVSHFLDOVLJQL¿FDQFH
It is particularly recommended that only parts designated on the parts list In this manual be used for
component replacement designated by mark .
No deviations from resistance Wattage or voltage ratings may be made for replacement items designated
by mark .
6SHFL¿FDWLRQV
Model LCD-47S10-HD
Maximum Visible Range 119cm (Screen Diagonal Size)
Picture Resolution 1920(H) x 1080(V)
Viewable Angle(L。
L/R:+/- 89D, U/D:+/- 89D
Brightness 500cd/m²
Contrast
Definition 5)$QDORJ6LJQDOV+RUL]RQWDO9HUWLFDO
Degree of Colour Coverage
Mobile Trailer Time 5ms
Voltage AC110-242V 50/60Hz
Power Consumption 255W
Power Management VESA DPMS
Colour System 3$/176&176&6(&$0
Sound System D/K, I, M, B/G
Channel Coverage9+)((55..--$$
8+)$$--
- CATV: S1-S41, X, Y, Z, Z+1, Z+2
Aerial input impedance
Speaker Size Mains: FP[FP[SFV Woofer: 8cm x 8cm x 1pcs
Alt: 7.5cm x 5cm x 2pcs
Sound speciality Maximum Output Power is 12.5W+12.5W+10W
7RWDO+DUPRQLF'LVWRUWLRQ7+'
Input terminals VGA Terminal : RGB X 1 HDMI terminal: x2
Audio: Mini stereo jack x 1 (Audio input of VGA)
Video: Composite video terminals x1 (9SS)
S-VIDEO input: x 1 (DIN 4-pin, Y/C separate signal input)
DVD input: Component video input Y, CB/PB, CR/PRinput x 1
Audio input: (R/L) x 4 (400mVrms)
USB input : Different value input D+, D-
MINI USB input : Different value input D+, D-
Output terminals Video Monitor Output: [9SS
Audio Monitor Output: R/L x 1P9UPV.
Headphone Jack : Mini stereo jack x1
Dimensions
(Width x Height x Depth)PP[PP[PP (Including Stand)
Net Weight
(Including Stand) 29.5 KG
Operating Environment
Operating Temperature 0ºC~40ºC（)a)）
2SHUDWLQJ+XPLGLW\a
Storage Temperature -10ºC~50ºC（14ºF~122ºF）
6WRUDJH+XPLGLW\a
4
Chassis Block Diagrams
5
MST6E89DL
CPU Block Diagrams
6
On-screen Service Menu System
1) How to enter the Service Menu
1. Press MENU button on SIDE controls, MENU will display.
2. Press and hold MENU button on SIDE controls and press “1” button on remote controls. SERVICE
MENU will display.
G
enera
l
This set has an
O
n-screen Menu system included in the
C
PU that allows remote operation
f
or most o
f
the
service adjustments.
"
1
"
bu
tt
on
Re
m
o
t
e
co
ntr
ols
Me
n
u
bu
tt
on
S
IDE
C
ontrol
s
2) How to select the service section and service item and change data value:
7RVHOHFWVHUYLFHVHFWLRQ3UHVVWKH&XUVRUŸRUźEXWWRQRQWKHUHPRWHFRQWUROKDQGVHWDQGSUHVVWKH
&XUVRUŻRUŹEXWWRQWRHQWHUWKH68%PHQX
7RFKDQJHGDWDYDOXH6HOHFWVHUYLFHLWHPE\SUHVVLQJWKH&XUVRUŸRUźEXWWRQDQGFKDQJHGDWDYDOXHE\
SUHVVLQJWKH&XUVRUŻRUŹEXWWRQ
([LWIURPWKHVHUYLFHPHQX
Press the MENU button repeatedly or turn off the TV set by pressing the POWER ON/OFF button.
7
How to adjust White Balance Adjustment
,QSXWDZKLWHSDWWHUQWRWKHFRPSRVLWHLQSXWWHUPLQDO
2. Set the television to following conditions:
Picture mode: standard
Colour temperature: normal
Pre-heading time: more than 10 minutes
(QWHUWKHVHUYLFHPHQXDQGVHOHFW:+,7(%$/$1&(ZLWKŸRUźNH\
3UHVVŻŹWRHQWHUWKH:KLWH%DODQFH$GMXVWPHQWSUHVVFRUUHVSRQGLQJQXPEHUNH\WRDGMXVW5*%
$IWHUDGMXVWPHQWFRQ¿UPZKLWHEDODQFHDJDLQE\QRUPDOSLFWXUH
Service Adjustments
Important Notice:
Do not attempt to adjust service adjustments not listed below otherwise it may cause loss of performance
and for correct operation.
White Balance Adjustment
Red "+" Green "+" Blue "+"
Red "-" Green "-" Blue "-"
8
Mechanical Disassembly
(ϔ) Cabinet Back Removal
1. Remove screws AB.
2. Take the Cabinet Back off.
(A:16pcsB:4pcs)
A
A
A
A
A
A
AAAA
AA
AA
A
A
B
POWER BOARD
LCD SCREEN
KEY&LED
BOARDS
MAIN
BOARD
USB
BOARD
9
Mechanical Disassembly
（二）Chassis and Terminal Board Removal
1. Remove screws CRemove screws CD and G, take the terminal board off.
2. Remove Screw ERemove Screw EScrew EF take Power BoardMain BoardUsb Board and WOOFER off.
C: 2pcsD: 2pcsE19pcsF: 4pcsG: 2pcs)
G
D
C
)
)
(
(
(
10
Chassis Electrical Parts List
Note: Parts order must contain Service Ref. No., Part No., and descriptions.
Key No. Part No. Description Key No. Part No. Description
MISCELLANEOUS
652 002 3222 SOCKET,HOUSING 2P
*03* 652 002 3222 SOCKET,HOUSING 2P
*03* 952 001 6324 SOCKET,HOUSING 3P
*03* 952 001 6348 SOCKET,HOUSING 4P
*03* 952 001 6348 SOCKET,HOUSING 4P
*03* 952 001 6348 SOCKET,HOUSING 4P
*03* 952 001 6300 SOCKET,HOUSING 5P
*03* 652 002 4830 SOCKET,HOUSING 6P
*03* 952 001 6355 SOCKET,HOUSING 10P
*03* 952 001 6355 SOCKET,HOUSING 10P
*03* 952 001 6461 SOCKET,HOUSING 12P
*03* 652 002 1501 SOCKET,HOUSING 14P
*03* 952 001 8212 SOCKET,HOUSING 2P
*03* 952 001 6263 SOCKET,HOUSING 4P
*03* 952 001 6164 TERMINAL,SOCKET
*03* 952 001 6164 TERMINAL,SOCKET
*03* 952 001 6164 TERMINAL,SOCKET
*03* 952 001 6164 TERMINAL,SOCKET
*03* 952 001 6164 TERMINAL,SOCKET
*03* 952 001 6164 TERMINAL,SOCKET
*03* 952 001 6164 TERMINAL,SOCKET
*03* 952 001 6164 TERMINAL,SOCKET
*03* 952 001 6171 TERMINAL,SOCKET
*03* 952 001 6171 TERMINAL,SOCKET
EL901 645 097 5899 LCD(LC470WUN-SAA1)
S P 9 0 1 6 5 2 0 0 2 5 8 4 4 S P E A K E R , 8
SP902 652 002 5844 SPEAKER,8
SP903 652 002 5318 SPEAKER,8
S P 9 0 4 6 5 2 0 0 2 6 6 4 3 S P E A K E R , 8
S P 9 0 5 6 5 2 0 0 2 6 6 4 3 S P E A K E R , 8
W662-001 652 002 6421 NONSTANDARD WIRE ASSY
W662A 952 001 9042 CORE,CLAMP
W671-101 652 002 6568 NONSTANDARD WIRE ASSY
W681-704 652 002 6414 NONSTANDARD WIRE ASSY
W7300 MechanicalDummyParts
W 8 0 0 2 A 9 5 2 0 0 1 5 4 7 1 C O R E , P I P E
W901 652 002 6131 CORD,POWER-2750MK
WCN1-663 652 002 6575 NONSTANDARD WIRE ASSY
WCN2-661 652 002 6551 NONSTANDARD WIRE ASSY
WSP9C 652 002 5998 NONSTANDARD WIRE ASSY
WSP9L 652 002 6506 NONSTANDARD WIRE ASSY
WSP9R 652 002 6544 NONSTANDARD WIRE ASSY
610 341 9695 ASSY,PWB, MAIN, N6PW
TRANSISTOR
Q001 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
406 021 4407 TR MMBTSC3928R
Q002 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
406 021 4407 TR MMBTSC3928R
Q003 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
406 021 4407 TR MMBTSC3928R
Q013 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
406 021 4407 TR MMBTSC3928R
Q014 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
406 021 4407 TR MMBTSC3928R
Q1000 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
406 021 4407 TR MMBTSC3928R
Q1001 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
406 021 4407 TR MMBTSC3928R
Q101 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
405 220 3115 TR ISA1235AC1E
405 220 3016 TR ISA1235AC1F
406 021 4308 TR MMBTSA1235F
Q3000 305 045 8728 TR 2SK536-TB
Q3001 305 045 8728 TR 2SK536-TB
Q3014 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
406 021 4407 TR MMBTSC3928R
Q700 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
11
Chassis Electrical Parts List
Key No. Part No. Description Key No. Part No. Description
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
406 021 4407 TR MMBTSC3928R
Q701 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
406 021 4407 TR MMBTSC3928R
Q7200 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
406 021 4407 TR MMBTSC3928R
Q7201 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
405 220 3115 TR ISA1235AC1E
405 220 3016 TR ISA1235AC1F
406 021 4308 TR MMBTSA1235F
Q7202 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
406 021 4407 TR MMBTSC3928R
Q7204 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
405 220 3115 TR ISA1235AC1E
405 220 3016 TR ISA1235AC1F
406 021 4308 TR MMBTSA1235F
Q7206 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
406 021 4407 TR MMBTSC3928R
Q7207 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
405 220 3115 TR ISA1235AC1E
405 220 3016 TR ISA1235AC1F
406 021 4308 TR MMBTSA1235F
Q7208 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
406 021 4407 TR MMBTSC3928R
Q7500 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
406 021 4407 TR MMBTSC3928R
Q7501 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
406 021 4407 TR MMBTSC3928R
Q 7 5 0 2 3 0 5 2 0 2 7 7 1 4 T R T P C 8 1 0 9
Q8000 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
406 021 4407 TR MMBTSC3928R
Q8001 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
406 021 4407 TR MMBTSC3928R
Q8002 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
406 021 4407 TR MMBTSC3928R
INTEGRATED CIRCUIT
IC001 409 691 0413 IC TPA3123D2PWPR
IC002 409 691 0413 IC TPA3123D2PWPR
IC003 409 691 0314 IC TPA6110A2DGNR
IC1501 309 462 0327 IC 24LC21AT/SN
IC3000 409 690 7710 IC AP8302-LQ-L
IC3100 309 039 7817 IC NJM4558M-TE2
IC3101 309 039 7817 IC NJM4558M-TE2
IC700 409 690 7819 IC CM2021-02TR
IC701 309 558 7213 IC 24C02CT-I/SNG
IC702 409 690 7819 IC CM2021-02TR
IC703 309 558 7213 IC 24C02CT-I/SNG
IC7200 410 662 0209 IC MST6E89DL-LF
IC7400 410 650 6909 IC HY5DU281622FTP-4-C
IC7501 309 559 9018 IC AMS1117-3.3
409 683 6515 IC LM1117S-3.3
12
Chassis Electrical Parts List
Key No. Part No. Description Key No. Part No. Description
IC7503 309 559 9018 IC AMS1117-3.3
409 683 6515 IC LM1117S-3.3
IC7504 309 655 2418 IC AMS1085CM
409 689 4416 IC LM1085R-ADJ
IC7505 309 559 8912 IC AMS1117-2.5
IC8001 410 648 9905 IC 24LC64T-I/SNG-N5CV
CAPACITOR
C001 304 108 4206 ELECT 470U M 35V
C002 304 108 4206 ELECT 470U M 35V
C003 303 256 9319 CERAMIC .47U Z 50V
C004 303 207 0310 CERAMIC 1U Z 16V
C005 303 207 0310 CERAMIC 1U Z 16V
C006 303 207 0310 CERAMIC 1U Z 16V
C007 303 256 9319 CERAMIC 0.47U Z 50V
C008 303 207 0310 CERAMIC 1U Z 16V
C009 304 109 7305 ELECT 470U M 50V
C010 303 450 2215 CERAMIC 0.22U K 25V
C011 303 402 8319 ELECT 10U M 50V
304 098 5900 ELECT 10U M 50V
C012 303 367 0410 CERAMIC 0.1U K 50V
304 104 4903 CERAMIC 0.1U K 50V
304 091 2609 CERAMIC 0.1U K 50V
C013 303 256 9319 CERAMIC 0.47U Z 50V
C014 303 256 9319 CERAMIC 0.47U Z 50V
C015 303 450 2215 CERAMIC 0.22U K 25V
C016 304 109 7305 ELECT 470U M 50V
C017 304 108 4206 ELECT 470U M 35V
C018 304 108 4206 ELECT 470U M 35V
C019 303 207 0310 CERAMIC 1U Z 16V
C020 303 207 0310 CERAMIC 1U Z 16V
C021 303 207 0310 CERAMIC 1U Z 16V
C022 303 256 9319 CERAMIC 0.47U Z 50V
C024 303 367 0410 CERAMIC 0.1U K 50V
304 104 4903 CERAMIC 0.1U K 50V
304 091 2609 CERAMIC 0.1U K 50V
C025 303 402 8319 ELECT 10U M 50V
304 098 5900 ELECT 10U M 50V
C026 303 450 2215 CERAMIC 0.22U K 25V
C027 303 256 9319 CERAMIC 0.47U Z 50V
C028 304 109 5509 ELECT 1000U M 35V
304 098 0509 ELECT 1000U M 35V
C029 304 095 4203 CERAMIC 0.01U Z 50V
C030 303 281 2415 CERAMIC 0.22U K 16V
304 103 6601 CERAMIC 0.22U K 16V
C031 303 207 0310 CERAMIC 1U Z 16V
C032 303 384 1414 ELECT 47U M 16V
C033 303 403 1012 ELECT 100U M 25V
C034 303 403 1012 ELECT 100U M 25V
C035 303 207 0310 CERAMIC 1U Z 16V
C037 303 367 0410 CERAMIC 0.1U K 50V
304 104 4903 CERAMIC 0.1U K 50V
304 091 2609 CERAMIC 0.1U K 50V
C038 303 256 9319 CERAMIC 0.47U Z 50V
C055 303 398 7518 ELECT 100U M 35V
C056 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C057 303 398 7518 ELECT 100U M 35V
C058 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C1002 303 403 0718 ELECT 220U M 16V
C1005 303 383 1316 ELECT 10U M 16V
304 094 0107 ELECT 10U M 16V
C1008 303 383 1316 ELECT 10U M 16V
304 094 0107 ELECT 10U M 16V
C1009 303 323 8818 CERAMIC 2.2U Z 16V
C101 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C1010 303 383 1316 ELECT 10U M 16V
304 094 0107 ELECT 10U M 16V
C1011 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C1012 303 323 8818 CERAMIC 2.2U Z 16V
C1013 303 383 1316 ELECT 10U M 16V
304 094 0107 ELECT 10U M 16V
C1014 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C102 303 386 0910 ELECT 100U M 16V
C1021 304 103 8209 CERAMIC 10P J 50V
304 094 6307 CERAMIC 10P J 50V
C1024 304 103 8209 CERAMIC 10P J 50V
304 094 6307 CERAMIC 10P J 50V
C1027 301 150 6014 MT-GLAZE 0.000ZA 1/10W
C103 303 157 3317 CERAMIC 68P J 50V
304 104 4606 CERAMIC 68P J 50V
304 094 9001 CERAMIC 68P J 50V
C1033 301 150 6014 MT-GLAZE 0.000ZA 1/10W
C104 303 157 3317 CERAMIC 68P J 50V
304 104 4606 CERAMIC 68P J 50V
304 094 9001 CERAMIC 68P J 50V
C105 303 403 3610 NP-ELECT 22U M 16V
303 397 8714 NP-ELECT 22U M 16V
C111 303 383 1316 ELECT 10U M 16V
304 094 0107 ELECT 10U M 16V
C112 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C120 303 386 0910 ELECT 100U M 16V
C121 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C122 303 386 0910 ELECT 100U M 16V
C123 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C124 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C1500 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C1501 304 104 0202 CERAMIC 100P J 50V
304 094 6406 CERAMIC 100P J 50V
C1502 304 104 0202 CERAMIC 100P J 50V
304 094 6406 CERAMIC 100P J 50V
C1520TM 304 108 4107 ELECT 100U M 16V
C1725 304 103 8209 CERAMIC 10P J 50V
304 094 6307 CERAMIC 10P J 50V
C1727 304 103 8209 CERAMIC 10P J 50V
304 094 6307 CERAMIC 10P J 50V
Chassis Electrical Parts List
Key No Part No. Description Key No. Part No. Description
C1729 304 103 8209 CERAMIC 10P J 50V
304 094 6307 CERAMIC 10P J 50V
C1731 304 103 8209 CERAMIC 10P J 50V
304 094 6307 CERAMIC 10P J 50V
C1732 304 103 8209 CERAMIC 10P J 50V
304 094 6307 CERAMIC 10P J 50V
C3000 303 336 3510 CERAMIC 0.47U K 16V
304 103 6700 CERAMIC 0.47U K 16V
304 110 9800 CERAMIC 0.47U K 16V
C3001 303 336 3510 CERAMIC 0.47U K 16V
304 103 6700 CERAMIC 0.47U K 16V
304 110 9800 CERAMIC 0.47U K 16V
C3002 303 367 0410 CERAMIC 0.1U K 50V
304 104 4903 CERAMIC 0.1U K 50V
304 091 2609 CERAMIC 0.1U K 50V
C3003 303 215 2214 CERAMIC 0.01U K 50V
304 103 2900 CERAMIC 0.01U K 50V
304 090 1207 CERAMIC 0.01U K 50V
C3004 303 367 0410 CERAMIC 0.1U K 50V
304 104 4903 CERAMIC 0.1U K 50V
304 091 2609 CERAMIC 0.1U K 50V
C3005 303 215 2214 CERAMIC 0.01U K 50V
304 103 2900 CERAMIC 0.01U K 50V
304 090 1207 CERAMIC 0.01U K 50V
C3006 303 367 0410 CERAMIC 0.1U K 50V
304 104 4903 CERAMIC 0.1U K 50V
304 091 2609 CERAMIC 0.1U K 50V
C3007 303 215 2214 CERAMIC 0.01U K 50V
304 103 2900 CERAMIC 0.01U K 50V
304 090 1207 CERAMIC 0.01U K 50V
C3008 303 367 0410 CERAMIC 0.1U K 50V
304 104 4903 CERAMIC 0.1U K 50V
304 091 2609 CERAMIC 0.1U K 50V
C3009 303 215 2214 CERAMIC 0.01U K 50V
304 103 2900 CERAMIC 0.01U K 50V
304 090 1207 CERAMIC 0.01U K 50V
C3010 303 383 1316 ELECT 10U M 16V
304 094 0107 ELECT 10U M 16V
C3011 303 367 0410 CERAMIC 0.1U K 50V
304 104 4903 CERAMIC 0.1U K 50V
304 091 2609 CERAMIC 0.1U K 50V
C3012 303 215 2214 CERAMIC 0.01U K 50V
304 103 2900 CERAMIC 0.01U K 50V
304 090 1207 CERAMIC 0.01U K 50V
C3013 303 367 0410 CERAMIC 0.1U K 50V
304 104 4903 CERAMIC 0.1U K 50V
304 091 2609 CERAMIC 0.1U K 50V
C3014 303 215 2214 CERAMIC 0.01U K 50V
304 103 2900 CERAMIC 0.01U K 50V
304 090 1207 CERAMIC 0.01U K 50V
C3015 303 383 1316 ELECT 10U M 16V
304 094 0107 ELECT 10U M 16V
C3016 303 383 1316 ELECT 10U M 16V
304 094 0107 ELECT 10U M 16V
C3017 303 215 2412 CERAMIC 0.015U K 50V
304 104 5306 CERAMIC 0.015U K 50V
304 091 2906 CERAMIC 0.015U K 50V
C3018 303 272 5814 CERAMIC 0.018U K 50V
304 104 5504 CERAMIC 0.018U K 50V
304 091 3101 CERAMIC 0.018U K 50V
C3019 303 215 2214 CERAMIC 0.01U K 50V
304 103 2900 CERAMIC 0.01U K 50V
304 090 1207 CERAMIC 0.01U K 50V
C3020 303 272 5814 CERAMIC 0.018U K 50V
304 104 5504 CERAMIC 0.018U K 50V
304 091 3101 CERAMIC 0.018U K 50V
C3021 303 215 2214 CERAMIC 0.01U K 50V
304 103 2900 CERAMIC 0.01U K 50V
304 090 1207 CERAMIC 0.01U K 50V
C3022 303 215 2412 CERAMIC 0.015U K 50V
304 104 5306 CERAMIC 0.015U K 50V
304 091 2906 CERAMIC 0.015U K 50V
C3023 303 383 1316 ELECT 10U M 16V
304 094 0107 ELECT 10U M 16V
C3024 303 336 3510 CERAMIC 0.47U K 16V
304 103 6700 CERAMIC 0.47U K 16V
304 110 9800 CERAMIC 0.47U K 16V
C3025 303 336 3510 CERAMIC 0.47U K 16V
304 103 6700 CERAMIC 0.47U K 16V
304 110 9800 CERAMIC 0.47U K 16V
C3026 303 383 1316 ELECT 10U M 16V
304 094 0107 ELECT 10U M 16V
C3027 303 367 0410 CERAMIC 0.1U K 50V
304 104 4903 CERAMIC 0.1U K 50V
304 091 2609 CERAMIC 0.1U K 50V
C3028 303 383 1316 ELECT 10U M 16V
304 094 0107 ELECT 10U M 16V
C3029 303 383 1316 ELECT 10U M 16V
304 094 0107 ELECT 10U M 16V
C3030 303 383 1316 ELECT 10U M 16V
304 094 0107 ELECT 10U M 16V
C3031 303 113 4112 CERAMIC 2200P K 50V
304 104 5702 CERAMIC 2200P K 50V
304 091 3309 CERAMIC 2200P K 50V
C3032 303 215 2214 CERAMIC 0.01U K 50V
304 103 2900 CERAMIC 0.01U K 50V
304 090 1207 CERAMIC 0.01U K 50V
C3033 303 383 1316 ELECT 10U M 16V
304 094 0107 ELECT 10U M 16V
C3034 303 383 1316 ELECT 10U M 16V
304 094 0107 ELECT 10U M 16V
C3035 303 336 3510 CERAMIC 0.47U K 16V
304 103 6700 CERAMIC 0.47U K 16V
C3036 303 155 2213 CERAMIC 3300P K 50V
304 104 6105 CERAMIC 3300P K 50V
304 091 3903 CERAMIC 3300P K 50V
C3037 303 113 4112 CERAMIC 2200P K 50V
304 104 5702 CERAMIC 2200P K 50V
304 091 3309 CERAMIC 2200P K 50V
C3038 303 281 2415 CERAMIC 0.22U K 16V
304 103 6601 CERAMIC 0.22U K 16V
C3039 303 401 5715 CERAMIC 0.33U K 16V
304 103 6304 CERAMIC 0.33U K 16V
C3041 303 383 1316 ELECT 10U M 16V
304 094 0107 ELECT 10U M 16V
C3042 303 383 1316 ELECT 10U M 16V
304 094 0107 ELECT 10U M 16V
C3100 304 104 0202 CERAMIC 100P J 50V
304 094 6406 CERAMIC 100P J 50V
C3101 304 103 2405 CERAMIC 1000P K 50V
304 090 1108 CERAMIC 1000P K 50V
C3102 303 323 8818 CERAMIC 2.2U Z 16V
C3103 304 103 2405 CERAMIC 1000P K 50V
304 090 1108 CERAMIC 1000P K 50V
14
Chassis Electrical Parts List
Key No. Part No. Description Key No. Part No. Description
C3104 304 104 0202 CERAMIC 100P J 50V
304 094 6406 CERAMIC 100P J 50V
C3105 303 323 8818 CERAMIC 2.2U Z 16V
C3106 303 386 0910 ELECT 100U M 16V
C3107 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C3108 303 386 0910 ELECT 100U M 16V
C3109 304 104 0202 CERAMIC 100P J 50V
304 094 6406 CERAMIC 100P J 50V
C3110 303 323 8818 CERAMIC 2.2U Z 16V
C3111 304 103 2405 CERAMIC 1000P K 50V
304 090 1108 CERAMIC 1000P K 50V
C3112 303 113 4112 CERAMIC 2200P K 50V
304 104 5702 CERAMIC 2200P K 50V
304 091 3309 CERAMIC 2200P K 50V
C3113 303 113 4112 CERAMIC 2200P K 50V
304 104 5702 CERAMIC 2200P K 50V
304 091 3309 CERAMIC 2200P K 50V
C3114 303 113 4112 CERAMIC 2200P K 50V
304 104 5702 CERAMIC 2200P K 50V
304 091 3309 CERAMIC 2200P K 50V
C3115 303 207 0310 CERAMIC 1U Z 16V
C3116 303 113 4112 CERAMIC 2200P K 50V
304 104 5702 CERAMIC 2200P K 50V
304 091 3309 CERAMIC 2200P K 50V
C400 303 386 0910 ELECT 100U M 16V
C402 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C403 303 386 0910 ELECT 100U M 16V
C405 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C700 303 383 1316 ELECT 10U M 16V
304 094 0107 ELECT 10U M 16V
C701 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C705 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7200 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7201 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7202 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7204 303 265 3216 CERAMIC 1000P J 50V
304 104 0301 CERAMIC 1000P J 50V
304 094 6505 CERAMIC 1000P J 50V
C7205 304 104 6709 CERAMIC 0.047U K 50V
304 091 4504 CERAMIC 0.047U K 50V
C7206 304 104 6709 CERAMIC 0.047U K 50V
304 091 4504 CERAMIC 0.047U K 50V
C7207 304 104 6709 CERAMIC 0.047U K 50V
304 091 4504 CERAMIC 0.047U K 50V
C7208 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7209 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7210 303 265 3216 CERAMIC 1000P J 50V
304 104 0301 CERAMIC 1000P J 50V
304 094 6505 CERAMIC 1000P J 50V
C7211 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7212 303 265 3216 CERAMIC 1000P J 50V
304 104 0301 CERAMIC 1000P J 50V
304 094 6505 CERAMIC 1000P J 50V
C7213 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7214 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7215 304 104 6709 CERAMIC 0.047U K 50V
304 091 4504 CERAMIC 0.047U K 50V
C7216 304 104 6709 CERAMIC 0.047U K 50V
304 091 4504 CERAMIC 0.047U K 50V
C7217 304 104 6709 CERAMIC 0.047U K 50V
304 091 4504 CERAMIC 0.047U K 50V
C7218 304 104 6709 CERAMIC 0.047U K 50V
304 091 4504 CERAMIC 0.047U K 50V
C7219 304 104 6709 CERAMIC 0.047U K 50V
304 091 4504 CERAMIC 0.047U K 50V
C7220 304 104 6709 CERAMIC 0.047U K 50V
304 091 4504 CERAMIC 0.047U K 50V
C7221 304 104 6709 CERAMIC 0.047U K 50V
304 091 4504 CERAMIC 0.047U K 50V
C7222 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7223 303 383 1316 ELECT 10U M 16V
304 094 0107 ELECT 10U M 16V
C7224 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7225 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7226 303 391 5511 ELECT 10U M 16V
304 094 0107 ELECT 10U M 16V
C7227 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7228 303 403 2712 ELECT 4.7U M 35V
C7229 304 094 9704 CERAMIC 1U Z 10V
C7232 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7233 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C725 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7255 303 367 0410 CERAMIC 0.1U K 50V
304 104 4903 CERAMIC 0.1U K 50V
15
Chassis Electrical Parts List
Key No. Part No. Description Key No. Part No. Description
304 095 0502 CERAMIC 0.1U K 16V
C7226 303 391 5511 ELECT 10U M 16V
304 094 0107 ELECT 10U M 16V
C7227 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7228 303 403 2712 ELECT 4.7U M 35V
C7229 304 094 9704 CERAMIC 1U Z 10V
C7232 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7233 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C725 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7255 303 367 0410 CERAMIC 0.1U K 50V
304 104 4903 CERAMIC 0.1U K 50V
304 091 2609 CERAMIC 0.1U K 50V
C7330 303 323 8818 CERAMIC 2.2U Z 16V
C7331 303 323 8818 CERAMIC 2.2U Z 16V
C7332 303 323 8818 CERAMIC 2.2U Z 16V
C7333 303 323 8818 CERAMIC 2.2U Z 16V
C7334 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7335 303 323 8818 CERAMIC 2.2U Z 16V
C7336 303 323 8818 CERAMIC 2.2U Z 16V
C7337 304 094 4303 CERAMIC 2200P Z 50V
C7338 304 094 4303 CERAMIC 2200P Z 50V
C7339 304 094 4303 CERAMIC 2200P Z 50V
C7340 304 094 4303 CERAMIC 2200P Z 50V
C7341 304 104 0202 CERAMIC 100P J 50V
304 094 6406 CERAMIC 100P J 50V
C7342 304 104 0202 CERAMIC 100P J 50V
304 094 6406 CERAMIC 100P J 50V
C7343 304 104 0202 CERAMIC 100P J 50V
304 094 6406 CERAMIC 100P J 50V
C7344 303 336 3510 CERAMIC 0.47U K 16V
304 103 6700 CERAMIC 0.47U K 16V
304 110 9800 CERAMIC 0.47U K 16V
C7345 304 103 8209 CERAMIC 10P J 50V
304 094 6307 CERAMIC 10P J 50V
C7346 304 103 8209 CERAMIC 10P J 50V
304 094 6307 CERAMIC 10P J 50V
C7347 303 265 3216 CERAMIC 1000P J 50V
304 104 0301 CERAMIC 1000P J 50V
304 094 6505 CERAMIC 1000P J 50V
C7348 303 384 1414 ELECT 47U M 16V
C7349 303 383 1316 ELECT 10U M 16V
304 094 0107 ELECT 10U M 16V
C7351 304 104 5702 CERAMIC 2200P K 50V
304 091 3309 CERAMIC 2200P K 50V
C7352 303 323 8818 CERAMIC 2.2U Z 16V
C7353 303 323 8818 CERAMIC 2.2U Z 16V
C741 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C742 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7500 303 386 0910 ELECT 100U M 16V
C7501 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7502 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7503 303 386 0910 ELECT 100U M 16V
C7504 303 378 1611 ELECT 470U M 16V
303 371 2318 ELECT 470U M 16V
C7505 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7506 303 386 0910 ELECT 100U M 16V
C7507 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7508 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7509 303 384 1414 ELECT 47U M 16V
C7510 303 386 0910 ELECT 100U M 16V
C7511 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7514 303 403 0312 ELECT 220U M 10V
C7515 303 315 6815 CERAMIC 4.7U Z 16V
C7516 303 394 0919 ELECT 22U M 6.3V
C7517 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7518 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7519 303 384 1414 ELECT 47U M 16V
C752 303 383 1316 ELECT 10U M 16V
304 094 0107 ELECT 10U M 16V
C7520 303 383 1316 ELECT 10U M 16V
304 094 0107 ELECT 10U M 16V
C7521 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7522 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7524 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C753 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7533 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7534 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7535 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7536 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
16
Chassis Electrical Parts List
Key No. Part No. Description Key No. Part No. Description
304 095 0502 CERAMIC 0.1U K 16V
C7537 303 215 2214 CERAMIC 0.01U K 50V
304 103 2900 CERAMIC 0.01U K 50V
304 090 1207 CERAMIC 0.01U K 50V
C7538 303 215 2214 CERAMIC 0.01U K 50V
304 103 2900 CERAMIC 0.01U K 50V
304 090 1207 CERAMIC 0.01U K 50V
C7539 303 215 2214 CERAMIC 0.01U K 50V
304 103 2900 CERAMIC 0.01U K 50V
304 090 1207 CERAMIC 0.01U K 50V
C7540 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7541 303 265 3216 CERAMIC 1000P J 50V
304 104 0301 CERAMIC 1000P J 50V
304 094 6505 CERAMIC 1000P J 50V
C7542 303 265 3216 CERAMIC 1000P J 50V
304 104 0301 CERAMIC 1000P J 50V
304 094 6505 CERAMIC 1000P J 50V
C7543 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7544 303 383 1316 ELECT 10U M 16V
304 094 0107 ELECT 10U M 16V
C7545 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7546 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7547 303 383 1316 ELECT 10U M 16V
304 094 0107 ELECT 10U M 16V
C7548 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7549 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7550 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7551 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7552 303 383 1316 ELECT 10U M 16V
304 094 0107 ELECT 10U M 16V
C7553 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7554 303 298 9612 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7555 303 298 9612 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7556 303 298 9612 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7557 303 298 9612 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7558 303 383 1316 ELECT 10U M 16V
304 094 0107 ELECT 10U M 16V
C7559 303 298 9612 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7560 303 383 1316 ELECT 10U M 16V
304 094 0107 ELECT 10U M 16V
C7561 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7562 303 383 1316 ELECT 10U M 16V
304 094 0107 ELECT 10U M 16V
C7563 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7564 303 383 1316 ELECT 10U M 16V
304 094 0107 ELECT 10U M 16V
C7565 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7566 303 215 2214 CERAMIC 0.01U K 50V
304 103 2900 CERAMIC 0.01U K 50V
304 090 1207 CERAMIC 0.01U K 50V
C7567 303 383 1316 ELECT 10U M 16V
304 094 0107 ELECT 10U M 16V
C7568 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7569 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7570 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7571 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7572 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7573 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7574 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7575 303 383 1316 ELECT 10U M 16V
304 094 0107 ELECT 10U M 16V
C7576 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7577 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7578 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7579 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7580 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C7802 303 383 1316 ELECT 10U M 16V
304 094 0107 ELECT 10U M 16V
C7803 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
17
Chassis Electrical Parts List
Key No. Part No. Description Key No. Part No. Description
C8000 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C8001 303 383 1316 ELECT 10U M 16V
304 094 0107 ELECT 10U M 16V
C8002 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C8003 303 298 9612 CERAMIC 0.1U K 16V
304 103 4508 CERAMIC 0.1U K 16V
304 095 0502 CERAMIC 0.1U K 16V
C8004 303 383 1316 ELECT 10U M 16V
304 094 0107 ELECT 10U M 16V
C8005 303 157 3614 CERAMIC 100P J 50V
304 104 0202 CERAMIC 100P J 50V
304 094 6406 CERAMIC 100P J 50V
C8006 303 157 3614 CERAMIC 100P J 50V
304 104 0202 CERAMIC 100P J 50V
304 094 6406 CERAMIC 100P J 50V
C8007 303 157 3614 CERAMIC 100P J 50V
304 104 0202 CERAMIC 100P J 50V
304 094 6406 CERAMIC 100P J 50V
C8008 303 383 1316 ELECT 10U M 16V
304 094 0107 ELECT 10U M 16V
RESISTOR
R003 301 256 6314 MT-GLAZE 47K JA 1/10W
R004 301 150 5918 MT-GLAZE 10K JA 1/10W
R005 301 255 6513 MT-GLAZE 100 JA 1/10W
R007 301 150 6014 MT-GLAZE0.000 ZA 1/10W
R008 301 150 6014 MT-GLAZE0.000 ZA 1/10W
R009 301 150 5918 MT-GLAZE 10K JA 1/10W
R010 301 150 5918 MT-GLAZE 10K JA 1/10W
R011 301 276 4710 MT-GLAZE0.000 ZA 1/3W
R012 301 276 4710 MT-GLAZE0.000 ZA 1/3W
R014 301 255 6513 MT-GLAZE 100 JA 1/10W
R015 301 150 5918 MT-GLAZE 10K JA 1/10W
R017 301 150 6014 MT-GLAZE0.000 ZA 1/10W
R018 301 276 4710 MT-GLAZE0.000 ZA 1/3W
R019 301 276 4710 MT-GLAZE0.000 ZA 1/3W
R020 301 150 6014 MT-GLAZE0.000 ZA 1/10W
R021 301 150 5918 MT-GLAZE 10K JA 1/10W
R025 301 150 5918 MT-GLAZE 10K JA 1/10W
R026 301 256 6314 MT-GLAZE 47K JA 1/10W
R027 301 150 6014 MT-GLAZE0.000 ZA 1/10W
R028 301 150 5918 MT-GLAZE 10K JA 1/10W
R029 301 162 4114 MT-GLAZE 5.6K JA 1/10W
R030 301 276 4710 MT-GLAZE0.000 ZA 1/3W
R031 301 276 4710 MT-GLAZE0.000 ZA 1/3W
R032 301 150 6212 MT-GLAZE 1K JA 1/10W
R033 301 150 6212 MT-GLAZE 1K JA 1/10W
R034 301 150 5918 MT-GLAZE 10K JA 1/10W
R035 301 162 4114 MT-GLAZE 5.6K JA 1/10W
R036 301 150 5918 MT-GLAZE 10K JA 1/10W
R037 301 255 6513 MT-GLAZE 100 JA 1/10W
R039 301 150 6014 MT-GLAZE0.000 ZA 1/10W
R041 301 162 2417 MT-GLAZE 1.2K JA 1/10W
R042 301 162 2417 MT-GLAZE 1.2K JA 1/10W
R043 301 150 5918 MT-GLAZE 10K JA 1/10W
R045 301 150 6014 MT-GLAZE0.000 ZA 1/10W
R046 301 150 6014 MT-GLAZE0.000 ZA 1/10W
R048 301 150 6014 MT-GLAZE0.000 ZA 1/10W
R049 301 150 6014 MT-GLAZE0.000 ZA 1/10W
R050 301 150 6014 MT-GLAZE0.000 ZA 1/10W
R051 301 150 6014 MT-GLAZE0.000 ZA 1/10W
R057 301 162 3711 MT-GLAZE 4.7K JA 1/10W
R058 301 162 3711 MT-GLAZE 4.7K JA 1/10W
R059 301 162 3711 MT-GLAZE 4.7K JA 1/10W
R1000 301 256 2712 MT-GLAZE 75 JA 1/10W
R1001 301 256 5614 MT-GLAZE 47 JA 1/10W
R1002 301 150 5819 MT-GLAZE 100K JA 1/10W
R1003 301 150 5918 MT-GLAZE 10K JA 1/10W
R1004 301 256 0411 MT-GLAZE 12K JA 1/10W
R1005 301 150 5819 MT-GLAZE 100K JA 1/10W
R1006 301 150 5918 MT-GLAZE 10K JA 1/10W
R1007 301 256 0411 MT-GLAZE 12K JA 1/10W
R1008 301 150 5819 MT-GLAZE 100K JA 1/10W
R1009 301 150 5918 MT-GLAZE 10K JA 1/10W
R101 301 255 6513 MT-GLAZE 100 JA 1/10W
R1010 301 256 6314 MT-GLAZE 47K JA 1/10W
R1011 301 256 0114 MT-GLAZE 8.2K JA 1/10W
R1012 301 162 3711 MT-GLAZE 4.7K JA 1/10W
R1013 301 256 5614 MT-GLAZE 47 JA 1/10W
R1014 301 256 5614 MT-GLAZE 47 JA 1/10W
R1015 301 150 5918 MT-GLAZE 10K JA 1/10W
R1016 301 256 6314 MT-GLAZE 47K JA 1/10W
R1017 301 256 0114 MT-GLAZE 8.2K JA 1/10W
R1018 301 162 3711 MT-GLAZE 4.7K JA 1/10W
R1019 301 256 5614 MT-GLAZE 47 JA 1/10W
R102 301 255 6513 MT-GLAZE 100 JA 1/10W
R1020 301 256 5614 MT-GLAZE 47 JA 1/10W
R1021 301 256 2712 MT-GLAZE 75 JA 1/10W
R1022 301 256 2712 MT-GLAZE 75 JA 1/10W
R1023 301 150 6014 MT-GLAZE0.000 ZA 1/10W
R1024 301 162 3810 MT-GLAZE 470K JA 1/10W
R1025 301 162 3810 MT-GLAZE 470K JA 1/10W
R1026 301 256 2712 MT-GLAZE 75 JA 1/10W
R1027 301 256 5614 MT-GLAZE 47 JA 1/10W
R1028 301 162 3612 MT-GLAZE 70 JA 1/10W
R1029 301 256 2712 MT-GLAZE 75 JA 1/10W
R103 301 256 7311 MT-GLAZE 6.8K JA 1/10W
R1030 301 150 6014 MT-GLAZE0.000 ZA 1/10W
R1031 301 150 5918 MT-GLAZE 10K JA 1/10W
R1032 301 256 0411 MT-GLAZE 12K JA 1/10W
R1034 301 256 2712 MT-GLAZE 75 JA 1/10W
R1035 301 150 6014 MT-GLAZE0.000 ZA 1/10W
R1036 301 150 5918 MT-GLAZE 10K JA 1/10W
R1037 301 256 0411 MT-GLAZE 12K JA 1/10W
R104 301 256 3610 MT-GLAZE 15K JA 1/10W
R105 301 162 3018 MT-GLAZE 22K JA 1/10W
R106 301 150 6014 MT-GLAZE0.000 ZA 1/10W
R107 301 256 2712 MT-GLAZE 75 JA 1/10W
R108 301 150 5918 MT-GLAZE 10K JA 1/10W
R109 301 150 5918 MT-GLAZE 10K JA 1/10W
R110 301 162 3612 MT-GLAZE 470 JA 1/10W
R111 301 256 6512 MT-GLAZE 68 JA 1/10W
R118 301 276 4710 MT-GLAZE0.000 ZA 1/3W
R119 301 276 4710 MT-GLAZE0.000 ZA 1/3W
R120 301 256 5614 MT-GLAZE 47 JA 1/10W
R122 301 256 6314 MT-GLAZE 47K JA 1/10W
R125 301 150 6014 MT-GLAZE0.000 ZA 1/10W
R1500 301 162 3711 MT-GLAZE 4.7K JA 1/10W
R1502 301 150 6014 MT-GLAZE0.000 ZA 1/10W
R1503 301 162 3711 MT-GLAZE 4.7K JA 1/10W
R1506 301 150 6014 MT-GLAZE0.000 ZA 1/10W
18
Chassis Electrical Parts List
Key No. Part No. Description Key No. Part No. Description
R1507 301 150 6014 MT-GLAZE0.000 ZA 1/10W
R1508 301 162 3711 MT-GLAZE 4.7K JA 1/10W
R1509 301 162 3711 MT-GLAZE 4.7K JA 1/10W
R1510 301 256 2712 MT-GLAZE 75 JA 1/10W
R1511 301 256 2712 MT-GLAZE 75 JA 1/10W
R1512 301 256 2712 MT-GLAZE 75 JA 1/10W
R1513 301 256 5614 MT-GLAZE 47 JA 1/10W
R1514 301 256 5614 MT-GLAZE 47 JA 1/10W
R1515 301 256 5614 MT-GLAZE 47 JA 1/10W
R1516 301 255 6513 MT-GLAZE 100 JA 1/10W
R1517 301 255 6513 MT-GLAZE 100 JA 1/10W
R1518 301 162 3612 MT-GLAZE 470 JA 1/10W
R1519 301 256 0411 MT-GLAZE 12K JA 1/10W
R1520 301 256 0411 MT-GLAZE 12K JA 1/10W
R1521 301 150 5918 MT-GLAZE 10K JA 1/10W
R1522 301 150 5918 MT-GLAZE 10K JA 1/10W
R1524 301 150 5918 MT-GLAZE 10K JA 1/10W
R1526 301 150 6014 MT-GLAZE0.000 ZA 1/10W
R1528 301 150 6014 MT-GLAZE0.000 ZA 1/10W
R1772 301 256 2712 MT-GLAZE 75 JA 1/10W
R1773 301 256 2712 MT-GLAZE 75 JA 1/10W
R1774 301 256 2712 MT-GLAZE 75 JA 1/10W
R1775 301 150 5918 MT-GLAZE 10K JA 1/10W
R1777 301 150 5918 MT-GLAZE 10K JA 1/10W
R3000 301 264 2919 MT-GLAZE 12K FA 1/10W
R3001 301 264 2919 MT-GLAZE 12K FA 1/10W
R3002 301 276 4710 MT-GLAZE0.000 ZA 1/3W
R3003 301 276 4710 MT-GLAZE0.000 ZA 1/3W
R3004 301 150 5819 MT-GLAZE 100K JA 1/10W
R3006 301 150 6311 MT-GLAZE 200K JA 1/10W
R3007 301 150 6014 MT-GLAZE0.000 ZA 1/10W
R3010 301 150 6014 MT-GLAZE0.000 ZA 1/10W
R3011 301 150 6014 MT-GLAZE0.000 ZA 1/10W
R3012 301 162 3711 MT-GLAZE 4.7K JA 1/10W
R3013 301 162 3711 MT-GLAZE 4.7K JA 1/10W
R3014 301 150 6014 MT-GLAZE0.000 ZA 1/10W
R3015 301 150 6014 MT-GLAZE0.000 ZA 1/10W
R3016 301 150 6014 MT-GLAZE0.000 ZA 1/10W
R3022 301 150 6014 MT-GLAZE0.000 ZA 1/10W
R3023 301 255 6513 MT-GLAZE 100 JA 1/10W
R3025 301 256 7014 MT-GLAZE 180K JA 1/10W
R3026 301 256 7014 MT-GLAZE 180K JA 1/10W
R3100 301 162 3414 MT-GLAZE 39K JA 1/10W
R3101 301 162 4015 MT-GLAZE 560 JA 1/10W
R3102 301 256 6314 MT-GLAZE 47K JA 1/10W
R3103 301 150 5918 MT-GLAZE 10K JA 1/10W
R3104 301 150 5918 MT-GLAZE 10K JA 1/10W
R3105 301 162 3414 MT-GLAZE 39K JA 1/10W
R3106 301 162 4015 MT-GLAZE 560 JA 1/10W
R3107 301 256 6314 MT-GLAZE 47K JA 1/10W
R3108 301 256 1715 MT-GLAZE 33K JA 1/10W
R3109 301 256 1715 MT-GLAZE 33K JA 1/10W
R3110 301 255 6513 MT-GLAZE 100 JA 1/10W
R3114 301 150 6014 MT-GLAZE0.000 ZA 1/10W
R3115 301 150 6014 MT-GLAZE0.000 ZA 1/10W
R3123 301 162 3414 MT-GLAZE 39K JA 1/10W
R3124 301 162 3018 MT-GLAZE 22K JA 1/10W
R3125 301 256 6314 MT-GLAZE 47K JA 1/10W
R3127 301 150 5918 MT-GLAZE 10K JA 1/10W
R3128 301 150 6014 MT-GLAZE0.000 ZA 1/10W
R405 301 256 0114 MT-GLAZE 8.2K JA 1/10W
R700 301 255 6018 MT-GLAZE 1M JA 1/10W
R701 301 150 6212 MT-GLAZE 1K JA 1/10W
R702 301 150 6212 MT-GLAZE 1K JA 1/10W
R703 301 150 5918 MT-GLAZE 10K JA 1/10W
R704 301 255 6513 MT-GLAZE 100 JA 1/10W
R705 301 255 6513 MT-GLAZE 100 JA 1/10W
R706 301 162 3711 MT-GLAZE 4.7K JA 1/10W
R707 301 162 2219 MT-GLAZE 10 JA 1/10W
R708 301 162 2219 MT-GLAZE 10 JA 1/10W
R709 301 162 2219 MT-GLAZE 10 JA 1/10W
R710 301 162 2219 MT-GLAZE 10 JA 1/10W
R711 301 162 2219 MT-GLAZE 10 JA 1/10W
R712 301 162 2219 MT-GLAZE 10 JA 1/10W
R713 301 162 2219 MT-GLAZE 10 JA 1/10W
R714 301 162 2219 MT-GLAZE 10 JA 1/10W
R715 301 256 0718 MT-GLAZE 33 JA 1/10W
R716 301 256 0718 MT-GLAZE 33 JA 1/10W
R717 301 255 6018 MT-GLAZE 1M JA 1/10W
R718 301 150 6212 MT-GLAZE 1K JA 1/10W
R719 301 150 5918 MT-GLAZE 10K JA 1/10W
R720 301 150 6212 MT-GLAZE 1K JA 1/10W
R7200 301 265 0211 MT-GLAZE 390 FA 1/10W
R7201 301 256 5614 MT-GLAZE 47 JA 1/10W
R7202 301 256 5614 MT-GLAZE 47 JA 1/10W
R7203 301 255 8715 MT-GLAZE 22 JA 1/10W
R7204 301 255 8715 MT-GLAZE 22 JA 1/10W
R7205 301 255 8715 MT-GLAZE 22 JA 1/10W
R7206 301 256 5614 MT-GLAZE 47 JA 1/10W
R7207 301 256 5614 MT-GLAZE 47 JA 1/10W
R7208 301 256 3610 MT-GLAZE 15K JA 1/10W
R7209 301 162 3711 MT-GLAZE 4.7K JA 1/10W
R721 301 255 6513 MT-GLAZE 100 JA 1/10W
R7210 301 152 3219 MT-GLAZE 330 JA 1/10W
R7211 301 255 5912 MT-GLAZE 200 JA 1/10W
R7212 301 256 6512 MT-GLAZE 68 JA 1/10W
R7213 301 255 6513 MT-GLAZE 100 JA 1/10W
R7214 301 256 4112 MT-GLAZE 56 JA 1/10W
R7216 301 150 6014 MT-GLAZE0.000 ZA 1/10W
R7217 301 162 3018 MT-GLAZE 22K JA 1/10W
R7218 301 162 3018 MT-GLAZE 22K JA 1/10W
R7219 301 162 3018 MT-GLAZE 22K JA 1/10W
R722 301 255 6513 MT-GLAZE 100 JA 1/10W
R7220 301 162 3018 MT-GLAZE 22K JA 1/10W
R7221 301 150 6014 MT-GLAZE0.000 ZA 1/10W
R7222 301 162 3711 MT-GLAZE 4.7K JA 1/10W
R7223 301 162 3711 MT-GLAZE 4.7K JA 1/10W
R7224 301 162 3711 MT-GLAZE 4.7K JA 1/10W
R7225 301 162 3711 MT-GLAZE 4.7K JA 1/10W
R7226 301 162 3711 MT-GLAZE 4.7K JA 1/10W
R7227 301 162 3711 MT-GLAZE 4.7K JA 1/10W
R723 301 162 3711 MT-GLAZE 4.7K JA 1/10W
R7232 301 162 3612 MT-GLAZE 470 JA 1/10W
R7233 301 255 8715 MT-GLAZE 22 JA 1/10W
R7234 301 255 8715 MT-GLAZE 22 JA 1/10W
R7235 301 255 8715 MT-GLAZE 22 JA 1/10W
R7236 301 162 3018 MT-GLAZE 22K JA 1/10W
R7238 301 162 3018 MT-GLAZE 22K JA 1/10W
R724 301 162 2219 MT-GLAZE 10 JA 1/10W
R725 301 162 2219 MT-GLAZE 10 JA 1/10W
R726 301 162 2219 MT-GLAZE 10 JA 1/10W
R727 301 162 2219 MT-GLAZE 10 JA 1/10W
R728 301 162 2219 MT-GLAZE 10 JA 1/10W
R729 301 162 2219 MT-GLAZE 10 JA 1/10W
19
Chassis Electrical Parts List
Key No. Part No. Description Key No. Part No. Description
R730 301 162 2219 MT-GLAZE 10 JA 1/10W
R731 301 162 2219 MT-GLAZE 10 JA 1/10W
R732 301 256 0718 MT-GLAZE 33 JA 1/10W
R733 301 256 0718 MT-GLAZE 33 JA 1/10W
R7339 301 255 6513 MT-GLAZE 100 JA 1/10W
R734 301 162 3711 MT-GLAZE 4.7K JA 1/10W
R7342 301 255 8715 MT-GLAZE 22 JA 1/10W
R7343 301 255 8715 MT-GLAZE 22 JA 1/10W
R7344 301 255 8715 MT-GLAZE 22 JA 1/10W
R7345 301 255 6513 MT-GLAZE 100 JA 1/10W
R7347 301 255 6513 MT-GLAZE 100 JA 1/10W
R7349 301 255 6513 MT-GLAZE 100 JA 1/10W
R7350 301 255 6513 MT-GLAZE 100 JA 1/10W
R7351 301 255 6513 MT-GLAZE 100 JA 1/10W
R7352 301 150 5918 MT-GLAZE 10K JA 1/10W
R7355 301 150 5918 MT-GLAZE 10K JA 1/10W
R7357 301 150 5918 MT-GLAZE 10K JA 1/10W
R7358 301 150 5918 MT-GLAZE 10K JA 1/10W
R736 301 162 3711 MT-GLAZE 4.7K JA 1/10W
R7360 301 150 5918 MT-GLAZE 10K JA 1/10W
R7361 301 256 0411 MT-GLAZE 12K JA 1/10W
R7362 301 256 7311 MT-GLAZE 6.8K JA 1/10W
R7363 301 256 6314 MT-GLAZE 47K JA 1/10W
R7364 301 255 6513 MT-GLAZE 100 JA 1/10W
R7365 301 255 6513 MT-GLAZE 100 JA 1/10W
R7366 301 255 6513 MT-GLAZE 100 JA 1/10W
R7367 301 255 6018 MT-GLAZE 1M JA 1/10W
R7368 301 150 5918 MT-GLAZE 10K JA 1/10W
R7369 301 150 6212 MT-GLAZE 1K JA 1/10W
R7370 301 150 5918 MT-GLAZE 10K JA 1/10W
R7371 301 150 6212 MT-GLAZE 1K JA 1/10W
R7373 301 150 5918 MT-GLAZE 10K JA 1/10W
R7374 301 150 6014 MT-GLAZE0.000 ZA 1/10W
R7375 301 150 5918 MT-GLAZE 10K JA 1/10W
R7376 301 150 6212 MT-GLAZE 1K JA 1/10W
R7377 301 150 5918 MT-GLAZE 10K JA 1/10W
R7378 301 255 6513 MT-GLAZE 100 JA 1/10W
R738 301 276 4710 MT-GLAZE0.000 ZA 1/3W
R7380 301 256 5911 MT-GLAZE 2.7K JA 1/10W
R7381 301 150 6113 MT-GLAZE 2.2K JA 1/10W
R7382 301 162 3711 MT-GLAZE 4.7K JA 1/10W
R7383 301 256 6314 MT-GLAZE 47K JA 1/10W
R7384 301 256 6314 MT-GLAZE 47K JA 1/10W
R7385 301 150 5918 MT-GLAZE 10K JA 1/10W
R7386 301 276 4710 MT-GLAZE0.000 ZA 1/3W
R7387 301 276 4710 MT-GLAZE0.000 ZA 1/3W
R7388 301 256 7014 MT-GLAZE 180K JA 1/10W
R7389 301 276 4710 MT-GLAZE0.000 ZA 1/3W
R739 301 162 3711 MT-GLAZE 4.7K JA 1/10W
R7390 301 276 4710 MT-GLAZE0.000 ZA 1/3W
R7391 301 276 4710 MT-GLAZE0.000 ZA 1/3W
R7392 301 276 4710 MT-GLAZE0.000 ZA 1/3W
R7393 301 276 4710 MT-GLAZE0.000 ZA 1/3W
R7394 301 276 4710 MT-GLAZE0.000 ZA 1/3W
R7395 301 276 4710 MT-GLAZE0.000 ZA 1/3W
R7396 301 276 4710 MT-GLAZE0.000 ZA 1/3W
R7397 301 276 4710 MT-GLAZE0.000 ZA 1/3W
R7398 301 276 4710 MT-GLAZE0.000 ZA 1/3W
R7399 301 276 4710 MT-GLAZE0.000 ZA 1/3W
R740 301 162 3711 MT-GLAZE 4.7K JA 1/10W
R7400 301 276 4710 MT-GLAZE0.000 ZA 1/3W
R7401 301 276 4710 MT-GLAZE0.000 ZA 1/3W
R7402 301 276 4710 MT-GLAZE0.000 ZA 1/3W
R7403 301 276 4710 MT-GLAZE0.000 ZA 1/3W
R7404 301 276 4710 MT-GLAZE0.000 ZA 1/3W
R7405 301 276 4710 MT-GLAZE0.000 ZA 1/3W
R7406 301 276 4710 MT-GLAZE0.000 ZA 1/3W
R7407 301 276 4710 MT-GLAZE0.000 ZA 1/3W
R7408 301 258 2611 MT-GLAZE 150 FA 1/10W
R7500 301 162 3711 MT-GLAZE 4.7K JA 1/10W
R7501 301 162 3711 MT-GLAZE 4.7K JA 1/10W
R7502 301 150 5918 MT-GLAZE 10K JA 1/10W
R7503 301 162 3711 MT-GLAZE 4.7K JA 1/10W
R7504 301 150 5918 MT-GLAZE 10K JA 1/10W
R7505 301 234 7616 MT-GLAZE 3.9 JA 1W
R7506 301 234 7616 MT-GLAZE 3.9 JA 1W
R7507 301 159 0617 MT-GLAZE 8.2 JA 1/16W
R7508 301 256 0312 MT-GLAZE 820 JA 1/10W
R7509 301 150 5918 MT-GLAZE 10K JA 1/10W
R7510 301 150 5918 MT-GLAZE 10K JA 1/10W
R7511 301 150 5918 MT-GLAZE 10K JA 1/10W
R7512 301 150 5918 MT-GLAZE 10K JA 1/10W
R7513 301 276 4710 MT-GLAZE0.000 ZA 1/3W
R7514 301 276 4710 MT-GLAZE0.000 ZA 1/3W
R752 301 256 6017 MT-GLAZE 27K JA 1/10W
R7801 301 190 1710 MT-GLAZE0.000 ZA 1W
R7808 301 150 6014 MT-GLAZE0.000 ZA 1/10W
R7809 301 150 6014 MT-GLAZE0.000 ZA 1/10W
R7810 301 150 6014 MT-GLAZE0.000 ZA 1/10W
R8000 301 256 1715 MT-GLAZE 33K JA 1/10W
R8002 301 255 6513 MT-GLAZE 100 JA 1/10W
R8003 301 255 6513 MT-GLAZE 100 JA 1/10W
R8004 301 162 3711 MT-GLAZE 4.7K JA 1/10W
R8005 301 162 3711 MT-GLAZE 4.7K JA 1/10W
R8006 301 162 3711 MT-GLAZE 4.7K JA 1/10W
R8007 301 162 3711 MT-GLAZE 4.7K JA 1/10W
R8009 301 162 3711 MT-GLAZE 4.7K JA 1/10W
R8010 301 162 3711 MT-GLAZE 4.7K JA 1/10W
R8011 301 255 6513 MT-GLAZE 100 JA 1/10W
R8012 301 255 6513 MT-GLAZE 100 JA 1/10W
R8013 301 150 6212 MT-GLAZE 1K JA 1/10W
R8014 301 150 6212 MT-GLAZE 1K JA 1/10W
R8015 301 255 6018 MT-GLAZE 1M JA 1/10W
R8016 301 255 6018 MT-GLAZE 1M JA 1/10W
R8017 301 162 3711 MT-GLAZE 4.7K JA 1/10W
R8018 301 256 6314 MT-GLAZE 47K JA 1/10W
R8019 301 255 6513 MT-GLAZE 100 JA 1/10W
R8020 301 150 6212 MT-GLAZE 1K JA 1/10W
R8021 301 150 6212 MT-GLAZE 1K JA 1/10W
R8022 301 150 6014 MT-GLAZE0.000 ZA 1/10W
R8023 301 162 3612 MT-GLAZE 470 JA 1/10W
R8025 301 150 6014 MT-GLAZE0.000 ZA 1/10W
R8026 301 162 3612 MT-GLAZE 470 JA 1/10W
RB7200 945 021 0359 R-NETWORK 100X4 0.063W
952 001 9707 R-NETWORK 100X4 0.063W
952 001 9974 R-NETWORK 100X4 0.063W
RB7201 945 021 0359 R-NETWORK 100X4 0.063W
952 001 9707 R-NETWORK 100X4 0.063W
952 001 9974 R-NETWORK 100X4 0.063W
RB7202 945 021 0359 R-NETWORK 100X4 0.063W
952 001 9707 R-NETWORK 100X4 0.063W
952 001 9974 R-NETWORK 100X4 0.063W
RB7203 945 021 0359 R-NETWORK 100X4 0.063W
952 001 9707 R-NETWORK 100X4 0.063W
20
Chassis Electrical Parts List
Key No. Part No. Description Key No. Part No. Description
952 001 9974 R-NETWORK 100X4 0.063W
RB7204 945 021 0359 R-NETWORK 100X4 0.063W
952 001 9707 R-NETWORK 100X4 0.063W
952 001 9974 R-NETWORK 100X4 0.063W
RB7205 945 021 0359 R-NETWORK 100X4 0.063W
952 001 9707 R-NETWORK 100X4 0.063W
952 001 9974 R-NETWORK 100X4 0.063W
RB7206 945 058 8847 R-NETWORK 33X4 0.063W
952 001 9813 R-NETWORK 33X4 0.063W
952 002 0031 R-NETWORK 33X4 0.063W
RB7207 945 021 0359 R-NETWORK 100X4 0.063W
952 001 9707 R-NETWORK 100X4 0.063W
952 001 9974 R-NETWORK 100X4 0.063W
RB7208 945 021 0359 R-NETWORK 100X4 0.063W
952 001 9707 R-NETWORK 100X4 0.063W
952 001 9974 R-NETWORK 100X4 0.063W
RB7209 945 021 0359 R-NETWORK 100X4 0.063W
952 001 9707 R-NETWORK 100X4 0.063W
952 001 9974 R-NETWORK 100X4 0.063W
RB7210 945 021 0359 R-NETWORK 100X4 0.063W
952 001 9707 R-NETWORK 100X4 0.063W
952 001 9974 R-NETWORK 100X4 0.063W
RB7211 945 021 0359 R-NETWORK 100X4 0.063W
952 001 9707 R-NETWORK 100X4 0.063W
952 001 9974 R-NETWORK 100X4 0.063W
RB7212 945 021 0427 R-NETWORK 4.7KX4 0.063W
952 001 9721 R-NETWORK 4.7KX4 0.063W
952 001 9912 R-NETWORK 4.7KX4 0.063W
RB7213 945 021 0427 R-NETWORK 4.7KX4 0.063W
952 001 9721 R-NETWORK 4.7KX4 0.063W
952 001 9912 R-NETWORK 4.7KX4 0.063W
RB7214 945 021 0359 R-NETWORK 100X4 0.063W
952 001 9707 R-NETWORK 100X4 0.063W
952 001 9974 R-NETWORK 100X4 0.063W
RB7215 945 021 0359 R-NETWORK 100X4 0.063W
952 001 9707 R-NETWORK 100X4 0.063W
952 001 9974 R-NETWORK 100X4 0.063W
COIL
L001 945 086 1681 INDUCTOR,47U M
L002 945 086 1681 INDUCTOR,47U M
L003 945 086 1681 INDUCTOR,47U M
L004 945 080 6828 INDUCTOR,3.3U M
L1000 945 036 3895 INDUCTOR,220 OHM
952 001 6980 INDUCTOR , 220 OHM
L1001 945 036 3895 INDUCTOR,220 OHM
952 001 6980 INDUCTOR , 220 OHM
L102 945 080 6828 INDUCTOR,3.3U M
L103 945 080 6828 INDUCTOR,3.3U M
L1500 301 150 6014 MT-GLAZE0.000 ZA 1/10W
L1501 301 150 6014 MT-GLAZE0.000 ZA 1/10W
L3001 945 080 6828 INDUCTOR,3.3U M
L3002 945 080 6828 INDUCTOR,3.3U M
L7500 945 036 3895 INDUCTOR,220 OHM
952 001 6980 INDUCTOR , 220 OHM
L7501 945 036 3895 INDUCTOR,220 OHM
952 001 6980 INDUCTOR , 220 OHM
L7502 945 036 3895 INDUCTOR,220 OHM
952 001 6980 INDUCTOR , 220 OHM
L7503 945 036 3895 INDUCTOR,220 OHM
952 001 6980 INDUCTOR , 220 OHM
L7504 945 036 3895 INDUCTOR,220 OHM
952 001 6980 INDUCTOR , 220 OHM
L7505 945 036 3895 INDUCTOR,220 OHM
952 001 6980 INDUCTOR , 220 OHM
L7506 945 036 3895 INDUCTOR,220 OHM
952 001 6980 INDUCTOR , 220 OHM
L7507 945 036 3895 INDUCTOR,220 OHM
952 001 6980 INDUCTOR , 220 OHM
L7508 945 036 3895 INDUCTOR,220 OHM
952 001 6980 INDUCTOR , 220 OHM
L7509 945 036 3895 INDUCTOR,220 OHM
952 001 6980 INDUCTOR , 220 OHM
L7510 945 036 3895 INDUCTOR,220 OHM
952 001 6980 INDUCTOR , 220 OHM
L7511 945 036 3895 INDUCTOR,220 OHM
952 001 6980 INDUCTOR , 220 OHM
L8000 945 036 3895 INDUCTOR,220 OHM
952 001 6980 INDUCTOR , 220 OHM
L8001 301 150 6014 MT-GLAZE0.000 ZA 1/10W
L8002 301 150 6014 MT-GLAZE0.000 ZA 1/10W
L8003 301 150 6014 MT-GLAZE0.000 ZA 1/10W
L8004 301 150 6014 MT-GLAZE0.000 ZA 1/10W
L8005 301 150 6014 MT-GLAZE0.000 ZA 1/10W
L8006 301 150 6014 MT-GLAZE0.000 ZA 1/10W
DIODE
D008 307 218 7719 ZENER DIODE UDZS20B-TE-17
408 064 1900 ZENER DIODE MM3Z 20B
D009 307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D010 307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D1500 307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D1501 307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D1502 307 208 9716 ZD UDZS-TE-175.6B
408 062 9700 ZENER DIODE MM3Z5V6B
D1503 307 208 9716 ZD UDZS-TE-175.6B
408 062 9700 ZENER DIODE MM3Z5V6B
D3000 307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D3001 307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D3100 307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D3101 307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D400 307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D401 307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D700 307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D701 307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D702 307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D703 307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D704 307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D7200 307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D7201 307 149 0810 DIODE 1SS355-TE-17
