Sanyo PDP-42H1EV User manual

Multimedia Plasma Monitor
SERVICE MANUAL
FILE NO.
Model No. PDP-42H1EV
(EUROPE)
PDP-42H1A
(U.S.A., ASIA)
ORIGINAL VERSION
PRODUCT CODE
1 114 019 00 PDP-42H1EV, J3BL
1 114 034 00 PDP-42H1A, J3BJB
REFERENCE NO. SM5110311-00
Chassis No. PDP-42H1E-00
(PDP-42H1EV)
NOTE: Match the Chassis No. on the
unit’s back cover with the Chassis
No. in the Service Manual.
If the Original Version Service
Manual Chassis No. does not
match the unit’s, additional
Service Literature is required. You
must refer to “Notices” to the
Original Service Manual prior to
servicing the unit.
CONTENTS
Pages
SAFETY INSTRUCTIONS --------------------------------------------------------------------- 2
TECHNICAL SPECIFICATIONS ------------------------------------------------------------- 3
DIMENSIONS AND OPTIONS---------------------------------------------------------------- 4
TERMINALS FOR PC----------------------------------------------------------------------- 5 - 6
MECHANICAL DISASSEMBLIES------------------------------------------------------ 7 - 14
ADJUSTMENT ---------------------------------------------------------------------------- 17 - 19
CIRCUIT BLOCK DIAGRAM----------------------------------------------------------- 20 - 21
POWER SUPPLY LINES --------------------------------------------------------------------- 22
POWER FAIL CIRCUIT ----------------------------------------------------------------- 23 - 24
TROUBLESHOOTING ------------------------------------------------------------------ 25 - 26
CONTROL PORT FUNCTIONS ------------------------------------------------------ 27 - 28
IC BLOCK DIAGRAMS------------------------------------------------------------------ 29 - 36
PIN DESCRIPTION OF DIODE, TRANSISTOR AND IC----------------------------- 37
PARTS LIST ------------------------------------------------------------------------------- 38 - 60
PARTS DESCRIPTION AND READING IN SCHEMATIC DIAGRAM ------------ 61
SCHEMATIC DIAGRAMS---------------------------------------------------------- A-1 - A-12
PRINTED WIRING BOARD DIAGRAMS ------------------------------------- A-13 - A-18
Chassis No. J3B-42H1A00
(PDP-42H1A)

-2-
CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-
SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
THIS SYMBOL INDICATES THAT DANGEROUS
VOLTAGE CONSTITUTING A RISK OF ELECTRIC
SHOCK IS PRESENT WITHIN THIS UNIT.
THIS SYMBOL INDICATES THAT THERE ARE IMPORTANT
OPERATING AND MAINTENANCE INSTRUCTIONS IN THE
OWNER'S MANUAL WITH THIS UNIT.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
SAFETY PRECAUTIONS
WARNING : TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO
RAIN OR MOISTURE.
●This Plasma Monitor should be set in the way indicated. If not, it may result in a fire hazard.
●Take appropriate space on the top, sides and rear of the Plasma Monitor cabinet for allowing air circulation and
cooling the Plasma Monitor. Minimum distance should be taken. If the Plasma Monitor is to be built into a
compartment or similarly enclosed, the minimum distances must
be maintained. Do not cover the ventilation slot on the Plasma
Monitor. Heat build-up can reduce the life of your Plasma
Monitor, and can also be dangerous.
●If the Plasma Monitor is not to be used for an extended time,
unplug the Plasma Monitor from the power outlet.
READ AND KEEP THIS OWNER'S MANUAL FOR LATER USE.
SIDE and TOP REAR
CAUTION IN INSTALLING
●Handle the Plasma Monitor carefully when installing it and do not drop.
●Locate set away from heat, excessive dust, and direct sunlight.
●For correct installation and mounting it is strongly recommended to use a trained, authorized dealer. Failure to
follow correct mounting procedures could result in damage to the equipment or injury to the installer.
10 cm
10 cm
10 cm
6 cm
NOTE :
When Plasma Monitor is not used for a long period of time, unlighting dots may be observed. This is caused by
characteristic of the Plasma Monitor. If this occurs, turn the Plasma Monitor on and leave it on about 1 hour. These
dots will gradually disappear.
■Safety Instructions
Product safety should be considered when a component replacement is made in any area of the monitor.
Components indicated by mark in the parts list and the schematic diagram designate components in
which safety can be of special significance. It is, therefore, particularly recommended that the replacement of
there parts must be made by exactly the same parts.
PRODUCT SAFETY NOTICE

-3-
■Technical Specifications
Screen Diagonal 42V
Product name Multimedia Plasma Monitor
Panel type Plasma Display Panel (16 x 9)
Display area 922 mm (W) x 522 mm (H)
Resolution / Color 1024 x 1024 pixels / 16,770,000 colors
Viewing Angle 160˚ (Vertical / Horizontal)
Color System PAL / SECAM / NTSC / NTSC4.43 / PAL-M / PAL-N
PC Interface D-SUB, RGB
Capability Up to XGA
Plug & Play VESA DDC2B
Power Management VESA DPMS
Audio Amp 10W + 10W (8 Ω)
Terminals
VIDEO1-3 IN ✽VIDEO (RCA type / BNC type), S-VIDEO (Mini DIN 4pin type)
AUDIO R and L (MONO) (RCA type)
COMPONENT/RGB IN ✽Y, Pb/Cb, Pr/Cr / R, G, B, VD, HD (BNC type)
AUDIO R and L (RCA type)
THROUGH OUT ✽Y, Pb/Cb, Pr/Cr / R, G, B, VD, HD (BNC type)
(COMPONENT/RGB) AUDIO R and L (RCA type)
MONITOR OUT ✽VIDEO (RCA type / BNC type)
AUDIO R and L (RCA type)
PC IN RGB (D-SUB 15pin)
AUDIO R / L (Stereo Mini jack)
RS232C IN RS232C (D-SUB 9pin)
WIRED RC IN Mini Jack
HEADPHONE OUT Stereo Mini Jack
EXT. SP OUT R and L, 10W (8 Ω), Push type
AC IN 3PIN
POWER SUPPLY AC 220 - 240V 50 Hz (PDP-42H1EV)
AC 100 - 120V 50/60 Hz, AC 200 - 240V 50/60 Hz (PDP-42H1A)
DIMENSION (W x H x D) 1036 x 641 x 100 mm (41.4" x 25.2" x 4" ) (Plasma Monitor only)
WEIGHT (NET) 36 kg (79.3 lbs ) (Plasma Monitor only)
Regulations FCC CLASS-B, UL (PDP-42H1A), CE (PDP-42H1EV, PDP-42H1E)
Environmental Considerations
Operating Temperature 0˚C ~ 40˚C (32˚F ~ 104˚F )
Humidity 20 ~ 80%
Altitude 0 ~ 2,000 m (0 ~ 6,560 ft)
Storage Temperature -10˚C ~ 50˚C (14˚F ~ 122˚F)
Humidity 20 ~ 80 %
Altitude 0 ~ 3,000 m (0 ~ 9,840 ft)
Accessories Owner’s Manual
AC Power Cord
Wired/Wireless Remote Control Transmitter and Batteries
Remote Control Cable
BNC / RCA Adapter ( x3)
Ferrite cores
✽ Those terminals are not provided on model PDP-42H1E.
●Specifications are subject to change without notice.

-4-
1036
(41.4)
1036
(41.1)
641
(25.2)
100
(4.0)
■Dimensions and Options
MEASUREMENT
OPTIONS
Size in mm (inch)
The products listed below are optionally supplied.
When ordering these products, give name and Type No. to sales dealer.
Speaker unit KA-SX-42H (R and L)
Table top stand KA-TD-H10S
Side rack KA-TD-R100
Tilt mount unit KA-TI-H10
Wall mount unit KA-WA-H10WV
Ceiling mount unit KA-CH-H10
Floor Stand KA-TD-42HW

-5-
RS232C TERMINAL
Terminal : HDB9-PIN
Connect the serial port of computer to this terminal with Serial Cross Cable (not supplied).
3
5
4
2
1
7
9
8
6
No Connect
Ground
R x D
DTR (5V)
T x D
1
5
2
4
3
DSR
No Connect
No Connect
No Connect
6
7
9
8
Pin Configuration
CONFIGURATIONS OF RS232C TERMINALS
RS232C COMMAND
(ASCII)
C09
C03
C01
C00
C0A
C0B
C22
C23
C0F
C24
C10
C25
C26
C27
C28
C29
C5F
C30
C47
C46
C60
OPERATION
VOLUME UP
POWER ON-OFF
POWER OFF
POWER ON
VOLUME DOWN
MUTE
INPUT (Input signal select)
INPUT "VIDEO" (VIDEO1 / VIDEO2)
Wide mode "Normal"
INPUT "COMPONENT" (COMPONENT)
WIDE (Wide mode select)
INPUT "PC / RGB" (PC / RGB)
Wide mode "Natural wide"
Wide mode "Zoom"
Wide mode "Zoom (Caption-IN)"
Wide mode "Full"
Screen Saver "White pattern-On"
Screen Saver "Rotation-Off"
Screen Saver "Rotation-On"
Screen Saver "White pattern-Off"
COMMAND
HEX
ASCII
43h 30h 30h 0Dh 0Ah
'C' '0' '0' [CR] [LF]
EXAMPLE : POWER ON (C00) FUNCTION CODE / END CODE
INTERFACE Protocol
Stop bit
Boadrate
Parity
Data length
Flow control
RS-232C
2 bits
9600 bps
-
8 bits
-
■Terminals for PC

-6-
CONFIGURATIONS OF PC TERMINALS
PC IN (D-SUB) TERMINAL
Terminal : HDB15-PIN
Connect the display output terminal of computer to this terminal with VGA Cable (supplied). When connecting the Macintosh
computer, the MAC Adapter (not supplied) is required.
51
2
34
10
9 678
15 14 13 11
12
Red Input
Ground (Horiz.sync.)
Green Input
Sense 2
Blue Input
Ground (Red)
Ground (Green)
Ground (Blue)
1
5
2
4
3
6
7
8
No Connect
Horiz. sync.
Ground (Vert.sync.)
Sense 1
Sense 0
Vert. sync.
Reserved
9
13
10
12
11
14
15
Pin Configuration
MAC ADAPTER (NOT SUPPLIED)
Set Slide Switches as shown in the table below depending on RESOLUTION MODE that you want to use before
you turn-on Plasma Monitor and computer.
ON
1
DIP
ON
OFF
2 3 4 5 6
13” MODE (640 x 480)
16” MODE (832 x 624)
19” MODE (1024 x 768)
21” MODE (1152 x 870)
ON
OFF
OFF
ON
ON
ON
ON
ON
OFF
OFF
ON
ON
OFF
ON
OFF
ON
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
1 2 3 4 5 6
Slide Switches (1 ~ 6)
Terminals for PC

A
B
A
B
B
B
AA
A
A
A
AA A AAAA
AAAA
AA
A
A
A
A
A
A
A
A
A
A
A
A
AA
A
A
-7-
■Mechanical Disassemblies
■Optional Stand Removal
1.Put the PDP Monitor Display with the screen face down
on the flat desk.
CAUTION : When placing the display with the face down,
lay the soft cloth under the screen to protect
the screen surface. And make sure there is
nothing to damage the screen surface like a
screw or small part near by before placing the
display.
2.Remove 6 Screws (A). (Fig. 1)
■Optional Speaker Removal
Fig. 2
Fig. 1
A
1.Remove speaker lead wires (R & L).
2.Remove 16 Screws (B) and 4 plates. (Fig. 2)
B
1. Cabinet Back Removal (Fig. 3)
Remove screws (A,B) and remove Cabinet Back as Fig. 3.
A (36pcs: 4X8), B (4pcs: 5X16)
Fig. 3

-8-
Location of Circuit Board
Mechanical Disassemblies
Sensor
Unit (A)
Jack
Unit (D)
Main
Unit
(PANEL)
Power
Unit
Sub CPU Unit
Sub Power Unit
+
Shield Plate
RC/RS2324
Unit
Front
Unit
Jack
Unit (C)
Contact Unit
+
Jack Unit (A)
Fig. 4
Sensor
Unit (B)

-9-
2. Panel Module and Chassis Removal (Fig. 5)
1) Remove 21 screws (C: 4X8). (Fig. 5)
2) Remove Flat Cable from Front Unit (R/C AMP. or Power SW ...etc.) to Sub CPU Unit (K8H).
Note: This cable is fixed with another cables by ferrite core. After servicing, it is necessary to be fixed to previous
position.
3) Remove chassis with Panel Module to have Panel Holders and lift up.
4) Place chassis with the face down to the desk with soft cloth.
[ATTENTION]
This PDP monitor is used the different kind of screw. Using correct screwis needed to avoid the damage.
Mechanical Disassemblies
C
C
CC
CFig. 5
Panel
Holder

-10-
3. Chassis Removal (Fig. 6)
To remove chassis from Panel Module.
1) Remove screws D (8pcs: 5X40).
2) Lift up the chassis to have Panel Holders and remove one side of the wire between Main Unit (K7S) and Panel
Module. (Recommended to remove the connector of Panel Module Side.)
3) Remove the connector of 2 black wires between screw (AA) and Panel Module. (Recommended to remove the
terminal of Panel Module Side.)
4) Remove the screw (A) and Yellow - Green wire.
5) Loose the screw (B) and remove the grounding terminal of type “U”.
6) Remove the connectors of (C), (D), (E) and (F) of Panel Power Unit.
7) Lift up Panel Holders and remove the chassis from Panel Module with Panel Power Unit.
8) Remove screws and wires of Panel Power Unit and remove Panel Power Unit from Panel Module.
Note: If the cable is fixed by ferrite core or CV band (fixer), remove it as the need arises. After servicing, it is neces-
sary to be fixed again to previous position.
Mechanical Disassemblies
DD
D
D
Panel Power Unit Main
Unit
K7S
(C), (D), (E), (F)
(A) (B)
(AA)
Fig. 6
[NOTE]
Can not clean Panel surface or Optical Filter after assembling Panel Module, if caught the dust to them.

-11-
4. Optical Filter Removal
Cabinet Front includes Optical Filter to protect the damage of Panel, improve picture quality, or prevent exposure of
interference. For removal of Optical Filter, remove screws of Fig.7-1 and Fig.7-2.
[NOTE]
The Optical Filter is easy to be damaged. Do not touch directly by hand. If there is the dust, remove it by watery
neutral detergent.
5. Servicing of Unit
Remove screws which fixed PWB for servicing unit.
For Sub Power Unit, remove the shield plate at first.
For Jack Unit, remove terminal plate together.
Note: If the cable is fixed by ferrite core or CV band (fixer), remove it as the need arises. After servicing, it is neces-
sary to be fixed again to previous position.
6. Servicing of Panel Power Unit
Panel Power Unit is not included in Panel Module. Can be ordered. (Refer to parts list.)
The inside parts of Panel Power Unit are not supplied for servicing.
Fig. 7-2
■ PDP Panel Replacement
For change of PDP Panel (Module), proceed 1to 3.
Mechanical Disassemblies
Fig. 7-1

-12-
■Flat Cable Removal
This set is used 3 kinds of connector for flat cable. For removal of cable, refer as below not to damage.
■For Gasket
The gasket is provided to prevent exposure of interference for other radio and television receptions.
The gasket should be replaced on previous positions after servicing.
For removal of flat cable, slide hook of
both sides.
For insert and fixing, slide hook to pre-
vious position after inserting the flat
cable.
Type A Type B Type C
For removal of flat cable, lift up hook of
both sides.
For insert and fixing, hold down hook
after inserting the flat cable.
For removal of flat cable, pull off only.
For fixing , insert into socket.
Cable Cable Cable
Mechanical Disassemblies

-13-
■ Notice for service of Unit
In below Unit, can be repaired inside parts or unit itself. Order service parts for repair.
Mechanical Disassemblies
Sensor
Unit (A)
Jack
Unit (D)
Main
Unit
(PANEL)
Power
Unit
Sub CPU Unit
Sub Power Unit
+
Shield Plate
RC/RS2324
Unit
Front
Unit
Jack
Unit (C)
Contact Unit
+
Jack Unit (A)
Sensor
Unit (B)

-14-
Mechanical Disassemblies
Do not remove these units.
For changing Panel, it is necessary to change
these all units too.
Refer to parts list.
Attention
Below 3 Units are included with Panel for PDP Module. Do not remove from Panel.
For changing Panel, it is necessary to change these all units together.
!
Panel Power Unit
This is not included in Panel Module.
For changing Panel Module, remove and use it.

-15-
■Adjustment
Before Adjustment
This adjustment is done to enter Service Mode by Remote
Control Unit.
■ To enter Service Mode
Quick operation is needed to enter Service Mode.
(1) Turn the monitor on.
(2) Press and hold the MENU button on the monitor.
(3) Keep item (2) and press the STATUS button and
release the both buttons.
(4) Within 2 seconds after item (3), press the MUTE
button to appear the Service Mode Display.
■ Service Mode Display
■ To return to the Normal Mode
Once turn the Monitor off by pressing “POWER” button on the monitor or remote control unit and turn it on again.
MENU
OK
INPUT VOLUME
MENU Button
MUTE
WIDE
INPUT
ON-OFF
VOLUME
PC/RGB
F
COMPONENT
OFF TIMER
STATUS
MOVE UP
MOVE DOWN
VIDEO
OK
OFF
ON
POWER
MENU
(←) / (→)
To select :
Adjustment Item
or Data Setting
To enter
Service Mode
STATUS
MUTE
(↑)
●Adjustment :
UP
●Data Setting
(+)
(↓)
●Adjustment :
DOWN
●Data Setting
(–)
Av-Dynamic
Cont063 (3F)
Main
Sub
42H1
103
040
CAUTION
The each circuit has been made by the fine adjustment at factory. Do not attempt to adjust
the following adjustments except requiring the readjustments in servicing otherwise it may
cause loss of performance and product safety.

-16-
■ To adjust
The next 2 pages show Data for adjustment.
To select adjustment item, press (↑) button on the remote control unit.
To adjust data, press (→) button ( The characters of data become yellow.) and press (↑) or (↓) button to change
data.
The all data adjusted in service mode memorizes into non-volatile memory IC.
Note: In the explanation all buttons are indicated for remote control unit without any notice.
Service Mode Display
Av-Dynamic
1) Select adjustment item by (↑) but-
ton.
Adjustment item displays in order. To reverse
adjustment item, press (↓) button.
3) Adjust the data by (↑) (↓) button.
To adjust another item, press (←) button to
change color of characters of adjustment item
and repeat 1) to 3).
Select by (↑) Button
and
Press (→) Button ( )
Hex decimal data
Adjust by (↑) or
(↓) Button.
4) To exit the Service Mode.
To exit the service mode, press POWER ON-
OFF button on the monitor or remote control
unit.
2) Press (→) button to change color
of characters (of data).
The character of data become yellow by pressing
(→) button.
0Cont 63 (3F)
Adjustment Item Data
Number
Av-Dynamic
Cont063 (3F)
Main
Sub
42H1
103
040
Adjustment

-17-
0 AV-Dynamic Contrast 63 0 63 Picture Menu (Dynamic)
1 Brightness 31 0 63
2 Color 42 0 63
3 Tint 0 -31 32
4 Sharpness 15 0 30
5 AV Standard Contrast 50 0 63 Picture Menu (Natural)
6 Brightness 31 0 63
7 Color 31 0 63
8 Tint 0 -31 32
9 Sharpness 15 0 30
10 AV Cinema Contrast 37 0 63 Picture Menu (Cinema)
11 Brightness 32 0 63
12 Color 22 0 63
13 Tint 0 -31 32
14 Sharpness 13 0 30
15 PC Graphic Contrast 63 0 63 Picture Menu (Graphic)
16 Brightness 31 0 63
17 Color 45 0 63
18 Tint 0 -31 32
19 --------------- -- -- --
20 PC Standard Contrast 40 0 63 Picture Menu (Standard)
21 Brightness 31 0 63
22 Color 31 0 63
23 Tint 0 -31 32
24 --------------- -- -- --
25 PC-Text Contrast 31 0 63 Picture Menu (Text)
26 Brightness 31 0 63
27 Color 26 0 63
28 Tint 0 -31 32
29 --------------- -- -- --
30 Sub Menu AV Contrast 6Bh 00h FFh Composite, S-Video
31 Brightness 33h 00h FFh
32 Color-S 78h 00h FFh S-Video
33 --------------- -- -- --
34 Tint FFh 80h 7Fh
35 Sharpness 0Fh 00h 1Fh 0Fh=9415add.5Dh:78h
36 Sub Menu PC Contrast 61h 00h FFh
37 Brightness 32h 00h FFh
38 Color 80h 00h FFh
39 Tint 00h 80h 7Fh
40 Sharpness 40h 00h FFh
41 Sub Menu AV-D2-D4 Contrast 5Bh 00h FFh D2–4 Input
42 Brightness 32h 00h FFh
43 Color 80h 00h FFh
44 Tint FAh 80h 7Fh
45 Sharpness 40h 00h FFh
46 Sub Menu AV-D1 Contrast 6Dh 00h FFh D1 Input (480i)
47 Brightness 33h 00h FFh
48 Color C0h 00h FFh
49 Tint 00h 80h 7Fh
50 Sharpness 0Ch 00h 1Fh 0Fh=9415add.5Dh:78h
51 Color Temp H-AV Red DCh 00h FFh AV Color Temperature (High)
52 Green F0h 00h FFh
53 Blue FFh 00h FFh
54 Color Temp M-AV Red FFh 00h FFh AV Color Temperature (STD)
55 Green FFh 00h FFh
■ Service Adjustment Data Table
Adjustment
• All data except in gray box area is fixed. Do not change for correct operating.
• Data in gray box area is initial. Can be set according to adjustment information.
No. NoteAdjustment Name
Data Area
Adjustment Item Initial
Data Min Max

-18-
Adjustment
No. NoteAdjustment Name
Data Area
Adjustment Item Initial
Data Min Max
56 Blue FFh 00h FFh
57 Color Temp L-AV Red FFh 00h FFh AV Color Temperature (Low)
58 Green EBh 00h FFh
59 Blue CDh 00h FFh
60 Color Temp H-PC Red DCh 00h FFh PC Color Temperature (High)
61 Green F0h 00h FFh
62 Blue FFh 00h FFh
63 Color Temp M-PC Red FFh 00h FFh PC Color Temperature (STD)
64 Green FFh 00h FFh
65 Blue FFh 00h FFh
66 Color Temp L-PC Red FFh 00h FFh PC Color Temperature (Low)
67 Green EBh 00h FFh
68 Blue CDh 00h FFh
69 Cont AV Red FFh 00h FFh White Balance Adjustment
70 Green FFh 00h FFh
71 Blue FFh 00h FFh
72 Bright AV Red 80h 00h FFh Black Balance Adjustment
73 Green 80h 00h FFh
74 Blue 80h 00h FFh
75 Cont PC Red 00h 00h FFh W/B (Differential Data to AV)
76 Green 00h 00h FFh
77 Blue 00h 00h FFh
78 Bright PC Red 00h 00h FFh B/B (Differential Data to AV)
79 Green 00h 00h FFh
80 Blue 00h 00h FFh
81 Cont PC Red 00h 00h FFh W/B (Differential Data to AV)
82 Green 00h 00h FFh
83 Blue 00h 00h FFh
84 Bright PC Red 00h 00h FFh B/B (Differential Data to AV)
85 Green 00h 00h FFh
86 Blue 00h 00h FFh
87 Cont-AV-D1 Red FEh 00h FFh W/B (Differential Data to AV)
88 Green 00h 00h FFh
89 Blue 00h 00h FFh
90 Bright-AV-D1 Red 00h 00h FFh B/B (Differential Data to AV)
91 Green 00h 00h FFh
92 Blue 00h 00h FFh
93 Sharpness-AV50 Sharpness 10 0 – Filter
94 Sharpness-AV60 Sharpness 6 0 – Filter
95 Sharpness-PC Sharpness 0 0 – Filter
96 Sharpness-HD Sharpness 10 0 – Filter
97 Snd-Sep Snd Sep 3Fh 0 3Fh Sound Separation
98 AFC Tuning-TV ABh 21Ch 000h FFFh
99 ACh 218h 000h FFFh
100 AFC Tuning-Video50 ABh 21Ch 000h FFFh
101 ACh 21Ch 000h FFFh
102 AFC Tuning-Video60 ABh 21Ch 000h FFFh
103 ACh 21Ch 000h FFFh
104 AFC Tuning-Video BEh 06h 00h FFh
105 AFC Tuning-D1 ABh 298h 000h FFFh
106 ACh 5D1h 000h FFFh
107 AFC Tuning-525i ABh 298h 000h FFFh
108 ACh 5D1h 000h FFFh
109 Color System Auto Auto/NTSC only
110 Wide Squeeze Off Off/On
111 Display Language English English/Japanese
112 PDP COLOR8 PDP Internal Pattern Display (∆Key)
113 PDP WHITE PDP Internal Pattern Display (∆Key)

-19-
■Setting the fixed data
(1) Receive the good quality signal.
(2) Enter the Service Mode
(3) Confirm fixed data to be same as data table. If it is different, change to
correct data.
(4) Return to the Normal Mode
This adjustment is controlled by the CPU (IC801) thorough the IIC Data Bus Line in the chassis, and those
adjustment data are memorized into the memory IC (IC808). Therefore, SUB CPU Board or the memory
IC (IC808) is replaced, data of those will be disappeared. Readjustment should be made. Initial data is
provided in the CPU ROM ,when memory IC (IC808) is replaced with new one, CPU ROM data is loaded
into the memory. (Data list will be shown in previous 2 pages.) Initial data is provided to operating the
monitor basically. For operating the monitor quality performance, further adjustment required following
chassis electrical adjustment.
Adjustment
■Y-Level Adjustment
Pattern : Color Bar Pattern
Equipment : Oscilloscope
Connection: TPY – Ground (Main Unit)
Adjustment: To be 1±0.1Vp-p by VR7001 in Main Unit.
0.83±0.01Vp–p
White100%
(H)
■Circuit Adjustment
■White Balance Adjustment
Pattern : White Pattern
Condition : Screen Size : FULL, Picture Image Level : NATURAL
Adjustment : Enter the service mode, select item No. 69 [ Red ], 70 [ Green ] or 71 [ Blue ] (Cont AV), and
adjust a proper white balance.
Note : After adjustment, confirm white balance again by normal picture.
●Input Signal : 1.0Vp-p / 75Ωterminated

-20-
D-SUB
Main
M/O CVBS
IC1001
AV Switch
IC1123
RGB,
Component
SW
IC1124
RGB,
Component
SW
CVBS
Y/C
RGB
Y/Cb/Cr
IC401
Digital
Decoder
CVBS
IC7101
3D Y/C Sep.
For NTSC
Y/C
IC501
Interlace/
Progressive
Converter
IC207
A/D Converter
IC601
RGB Matrix
IC301
Main Scaler
IC751
LVDS
Interface
PDP
Panel
Module
RGB
Y/Cb/Cr
RGB
Y/Pb/Pr
Y/Cb/Cr
RGB
Y/Pb/Pr
RGB
RGB
CVBS3
Y/C3
13
15(Y)
17(C)
CVBS2
Y/C2
7
9(Y)
11(C)
49(Y)
51(C)
CVBS1
Y/C1
1
3(Y)
5(C)
84(Y),83(C)
88
73(Y)
71(C)
75
6(R/Cr)
5(G/Y)
4(B/Cb)
1(R/Pr/Cr)
3(G/Y)
5(B/Pb/Cb)7(R/Pr)
15(G/Y)
22(B/Pb)
Sub CPU
PC Analog Input
Jack C
53
56(Y)
58(C)
RGB
Y/Pb/Pr
R/Pr/Cr4
G/Y4
B/Pb/Cb4
R
G
B
7
9
11
1
3
5
21
19
15
R/Pr/Cr
G/Y4
B/Pb/Cb
21
19
15
R/Pr/Cr
G/Y4
B/Pb/Cb
AV4
R/Pr/Cr4
G/Y4
B/Pb/Cb4
AV3 CVBS3
Y/C3
Jack D
AV2 CVBS2
Y/C2
AV1 CVBS1
Y/C1
Jack A
Monitor
Out
M/O
CVBS
Through
Out
■ Circuit Block Diagram
■ Video
Signal Flow
(1) CVBS, Y/C
CVBS (Composite Video) or Y/C signal from AV1, AV2 or AV3 terminal is input to AV SW IC (IC1001) and
selected signal.
CVBS signal selected by IC1001 is input to 3 Dimension Y/C Separation IC (IC7101) and input to IC1001 again.
(In case of NTSC Signal) On the other hand it is input to Digital Decoder IC (IC401) and output for Monitor Out
signal (CVBS only).
(2) RGB, Component
RGB or Component signal from AV4 terminal is output for “Through Out” terminal and input to RGB /
Component SW IC (IC1123) and selected to D-SUB RGB signal. Selected signal by IC1123 is input to IC1124.
(3) Decoder, I/P Conversion
CVBS or Y/C signal from IC1001 or Component signal (480i) from IC1124 is input to Digital Decoder IC
(IC401). Component signal from IC401 is input to I/P (interlace / Progressive) Conversion IC (IC501).
(4) A/D Conversion
RGB ( or Progressive Component) signal from IC1124 is input A/D Conversion IC (IC207) and converted.
(5) Panel Drive
Signal from IC501 or IC207 is input to RGB Matrix IC (IC601) and proceeded for picture control.
Signal from IC601 is input to Main Scaler IC (IC301) and LVDS Interface IC (IC751) and input to PDP Panel
Module.
