Sanyo VMC-8415FP User manual

VMC-8415FP
FILE NO.
REFERENCE No.SM5310543
L8MAF/XE,UK,AU
NOTE: 1. Parts order must contain model number, part number, and description.
2. Substitute parts may be supplied as the service parts.
3. N.S.P. : Not available as service parts.
Design and specifications are subject to change without notice.
SERVICE MANUAL
Colour Video Monitor
CONTENTS
SPECIFICATIONS .................................................................... 2
1. OPERATING PARTS NAMES .............................................. 3
2. DISASSEMBLY ..................................................................... 4
3. SERVICE ADJUSTMENTS ................................................... 4
4. PARTS LIST ......................................................................... 7
CIRCUIT DIAGRAMS & PRINTED WIRING BOARDS...........C1
(Product Code : 114 952 06)
(Europe)
VMC-8415FP
(Product Code : 114 952 07)
(U.K.)
The components designated by a symbol ( ) in this schematic diagram designates components whose value are of
special significance to product safety. Should any component designated by a symbol need to be replaced, use only the
part designated in the Parts List. Do not deviate from the resistance, wattage, and voltage ratings shown.
PRODUCT SAFETY NOTICE
VMC-8415FP
(Product Code : 114 952 08)
(Australia)
All manuals and user guides at all-guides.com
all-guides.com

– 2 –
SPECIFICATIONS
Type Colour video monitor
Picture tube 15" 90° colour
Colour system PAL
Resolution 800 TV lines
Normal scan 6 % over scan of picture tube
effective screen area
Input terminals •Video in BNC connector (x1), 1.0 V
(p-p) composite video signal, 75 Ω
•Audio in RCA jack (x1), 400 mVrms
•Y/C-separated: 1 line, mini-DIN
4-pin connector (x1)
Y: 1.0 V (p-p), 75 Ω/C: 0.3 V (p-p), 75 Ω
Output terminals •Video out BNC connector (x1),
loop-through, automatic
termination setting
•Y/C-separated OUT, mini-DIN
4-pin connector (x1), loop-through,
automatic termination setting
•Audio out RCA jack (x1),
loop-through
Audio power output 1 W
Built-in speaker x1, impedance of 8 Ω
Power source AC 100 to 240 V 50/60 Hz
Power consumption 95 W
Operation temperature –10°C to 50°C (14°F to 122°F)
Storage temperature –20°C to 65°C (–4°F to 149°F)
Relative humidity 15 % to 90 %
Dimensions (W x H x D) 368 x 361 x 376 mm
Weight 15 kg
Accessary AC power cord x1
•Diagrams are shown for explanatory purposes only, and have
been exaggerated, abbreviated or created as required, and
so may differ from the actual product.
•Features and specifications are subject to change without
prior notice or obligations.
Dimensions
W
H
D
Fig. 1
All manuals and user guides at all-guides.com

– 3 –
1. OPERATING PARTS NAMES
Front Panel 1SPEAKER
2VOLUME control («)
For adjustment of audio volume.
3CONTRAST control (»)
For adjustment of picture contrast.
4BRIGHT control (ã)
For adjustment of picture brightness.
5COLOUR control (õ)
For adjustment of colour enhancement.
6Power button (ÑPOWER)
Press this button to turn the power on and off.
7Power indicator
Lights when the power is on.
COLOURBRIGHTCONTRASTVOLUME
1
POWER
COLOURBRIGHTCONTRASTVOLUME
62 3 4 5
7
POWER
Rear Panel 1AC INPUT socket
Connect the AC power cord (supplied) securely to this
socket and to a wall outlet.
2VIDEO OUT terminal (BNC-type)
Loop-throgh of the video in terminal.
Connect to the video input terminal for VCR or another
monitor.
3VIDEO IN terminal (BNC-type)
Connect to the video output terminal of video
equipment, such as a VCR or a colour video camera.
4AUDIO OUT terminal (RCA jack)
Loop-throgh output of the audio in terminal.
Connect to the audio input terminal of a VCR or
another monitor.
5AUDIO IN terminal (RCA jack)
Connect to the audio output terminal of a VCR or other
equipment.
6Y/C IN terminal (4-pin mini-DIN)
Connect to the Y/C separate output terminal of a video
camera, VCR or other video equipment.
7Y/C OUT terminal (4-pin mini-DIN)
Loop-through output of Y/C in terminal. Connect to the
Y/C separate input terminal of a VCR or another
monitor.
8Y/C or VIDEO signal input/output switch
Select the input/output signal either VIDEO (BNC) or
Y/C (4-pin mini-DIN jack).
OUT
IN
IN
OUT
AUDIO
IN
OUT
VIDEO
Y/C
Y/C
AC INPUT
OUT
IN
IN
OUT
AUDIO
IN
OUT
VIDEO
Y/C
Y/C
AC INPUT
VIDEO
VIDEO
1 23 764 5 8
Y/C (4-pin mini-DIN) terminal specification
Pin No. Signal
1GND (Y)
2GND (C)
3Y
4C
OUT
IN
4
2
3
1
4
2
3
1
Fig. 2
Fig. 3
Fig. 4
All manuals and user guides at all-guides.com

– 4 –
Fig. 5
Fig. 6
MAIN BOARD
(Foil side)
VIDEO BOARD
(Foil side)
(1)
(1)
(1)
(1)
(1)
(1)
(2)
(1)
(2)
(1)
METAL TOP COVER
3. SERVICE ADJUSTMENTS
3-1. LOCATION OF ADJUSTMENT POINTS
2. DISASSEMBLY
REMOVAL OF TOP COVER
VR501
T502
10
9
8
7
6
5
4
3
21
11 13
VR302
V-SIZE
VR303
VR401
VR503
IC202
1
T902
HD
H-PHASE
V-CENT
ABL
V-LIN
B+
VR301
D910
ZD501
VR203
VR901
VR204
VR202
S-CON
S-BRI
COLOR
PIN5
PIN3
PIN4
12
T902
H-SIZE
VR306
VR305
PIN
VR804
VR805
VR801
VR803
VR802
KR
G2
KG
G1
H
H
KB
NC
GND
B-GAIN
B-BAIS
R-BAIS
R-GAIN
G-BAIS
All manuals and user guides at all-guides.com

–5 –
1. Supply power to the set and measuring instruments and allow to warm up for at least 30 minutes.
NOTE
Be sure to use a non-metallic driver for adjusting there VRs. A metallic driver can cause damage by shorting.
Adjustment tool
1. Digital multi meter
2. Pattern generator
3. Colour analyzer
Adjustment mode
Over scan mode
ADJUSTMENT
ITEM
TIMING
PATTERN SETTING VR LOCA- TION ADJUSTMENT PROCEDURE
CHECK B+ VOLTAGE
HOLD DOWN VOLT-
AGE SETTING
PATTERN GEN-
ERATOR FULL
WHITE
PATTERN GEN-
ERATOR
MONOSCOPE
PATTERN
PATTERN GEN-
ERATOR
MONOSCOPE
PATTERN
PATTERN GEN-
ERATOR
MONOSCOPE
PATTERN
PATTERN GEN-
ERATOR
MONOSCOPE
PATTERN
PATTERN GEN-
ERATOR
MONOSCOPE
PATTERN
PATTERN GEN-
ERATOR
MONOSCOPE
PATTERN
PATTERN GEN-
ERATOR
MONOSCOPE
PATTERN
TEST POINT : D910(-)
DIGITAL VOLT METER
VALUE 47.5 ±0.5 VDC.
TEST POINT : ZD501(-)
DIGITAL VOLT METER
VALUE 8.5 ±0.2 VDC.
Pin4 voltage is 3.0 ±0.2 VDC.
Pin3 voltage is 4.0 ±0.2 VDC.
Pin5 voltage is 1.5 V or above.
Adjusting FBT FOCUS VR to make focus
resolution of reach over 800 TV lines,
Four corners must be also clear.
Adjusting VR401 horizontal phase to
make screen right and left symmetrize.
Adjusting H-size control VR306 to make
signal side of picture of scale is "2"
position.
Adjusting vertical linear control VR302,
make top square and bottom square to be
equal.
Adjusting VR303 to make screen up &
down symmetrize.
VR901
VR503
VR204
VR202
VR203
FBT
FOCUS
VR
VR401
VR306
VR302
VR303
BRIGHT VR and
CONTRAST VR
TO MAX.
BRIGHT VR and
CONTRAST VR
TO MAX.
All extemal VR
TO MAX.
BRIGHT VR and
CONTRAST VR
TO MAX.
BRIGHT VR and
CONTRAST VR
TO MAX.
BRIGHT VR and
CONTRAST VR
TO MAX.
BRIGHT VR and
CONTRAST VR
TO MAX.
BRIGHT VR and
CONTRAST VR
TO MAX.
VR TO MAX.
INTERNAL
VOLTAGE
ADJUST-
MENT
COLOUR
ADJUST-
MENT
LUMI-
NANCE
ADJUST-
MENT
CON-
TRAST
ADJUSEMENT
FOCUS
ADJUSTMENT
HORIZONTAL
PHASE
ADJUSTMENT
HORIZONTAL
SIZE ADJUSTMENT
VERTICAL LINEARY
ADJUSTMENT
VERTICAL CENTER
ADJUSTMENT
3-2. ADJUSTMENT CONTENTS
All manuals and user guides at all-guides.com

–6 –
ADJUSTMENT
ITEM
TIMING
PATTERN SETTING VR
LOCATION ADJUSTMENT PROCEDURE
VERTICAL SIZE
ADJUSTMENT
TILT ADJUSTMENT
PINCUSHION
ADJUSTMENT
WHITE BALANCE
ADJUSTMENT
LUMINANCE
ADJUSTMENT
PATTERN GENERA-
TOR MONOSCOPE
PATTERN
PATTERN GENERA-
TOR MONOSCOPE
PATTERN
PATTERN GENERA-
TOR MONOSCOPE
PATTERN
PATTERN GENERA-
TOR NO SIGNAL
PATTERN GENERA-
TOR FULL WHITE
PATTERN GENERA-
TOR NO SIGNAL
PATTERN GENERA-
TOR FULL WHITE
PATTERN GENERA-
TOR WINDOWS
PATTERN
BRIGHT VR and
CONTRAST VR
TO MAX.
BRIGHT VR and
CONTRAST VR
TO MAX.
BRIGHT VR and
CONTRAST VR
TO MAX.
BRIGHT VR and
CONTRAST VR
TO MAX.
BRIGHT VR and
CONTRAST VR
TO MAX.
BRIGHT VR and
CONTRAST VR
TO MAX.
BRIGHT VR and
CONTRAST VR
TO MAX.
BRIGHT VR and
CONTRAST VR
TO MAX.
VR301
VR305
VR801,VR803,
FBT FOCUS
VR
VR804,VR802,
VR501
FBT SCREEN
VR
VR501
VR203
Adjusting VR301 to make single side of
picture of scale is "1.5" position.
If screen slant and adjust DY to be not
slant.
Adjust VR305 to optimize the vertical lines
ot the picture.
(A)
Adjust FBT screen VR make luminance
without video to 1.5 ±0.3 FL..
Adjust VR801 and VR803 to make X value
is 0.313 ±0.015, Y value is 0.329 ±0.015.
(B)
Adjust VR501 make luminance with video
signal to 45 - 50 FL.
Adjust VR802 and VR804 to make X value
is 0.313 ±0.015,Y value is 0.329 ±0.015.
Repeat (A) and (B), make sure x, y value
of Raster and Full-White signals that both
are into spec.
Adjust FBT screen VR make luminance
without video signal is 1.5 ±0.3 FL..
Adjust VR501 make luminance is 45 - 50
FL.
Adjust VR203 make luminance is 100 ±3
FL.
Then make sure Full White luminance
whether it is 45 - 50 FL.
The way of adjusting it which a color analyzer is not used for.
ADJUSTMENT
ITEM
TIMING
PATTERN SETTING VR
LOCATION ADJUSTMENT PROCEDURE
WHITE BAL-
ANCE AD-
JUSTMENT
and
LUMINANCE
ADJUSTMENT
PATTERN GENERA-
TOR NO SIGNAL
PATTERN GENERA-
TOR FULL WHITE
BRIGHT VR ,
CONTRAST VR
and SHARPNESS
VR TO MAX.
BRIGHT VR ,
CONTRAST VR
and SHARPNESS
VR TO MAX.
VR801,VR802,
VR803,VR804,
VR805,
FBT SCREEN
VR
VR804,VR802,
VR501
VR801,VR802,VR803,VR804 and VR805
is center position.
Adjust the VR801, VR805 and FBT
SCREEN VR to dark gray with screen.
Adjust the VR802 and VR804 to white
gray with screen.
Adjust the VR501 it makes the screen of
the monitor proper brightness.
All manuals and user guides at all-guides.com
all-guides.com

7
4. PARTS LIST
N.S.P.: Not available as service parts.
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
ACCESSORIES & PACKING MATERIALS
645 034 3971 POWER CORD 10-1 VDE (Euope Only)
645 040 9257 POWER CORD NS8-5180N (Australia Only)
645 040 9264 POWER CORD NS8-5181N (U.K. Only)
645 065 0833 USER MANUAL VMC-8415FP
645 065 0796 CARTON 15
645 035 6254 PE BAG 15 INCH 16X16X32
645 065 1007 POLYFORM CH-15VNA
CABINET & CHASSIS PARTS
1 645 065 0840 FRONT PANEL 15 AA-51
2 645 065 0857 SPEAKER PANEL 15 AA-51
3 645 048 3516 CONTROL PANEL 14 AA-51
4 645 065 0864 VR KNOB 15 AA-51
5 645 065 1175 VR ASS’Y VMC-8415FP
6 645 048 3493 SW KNOB 19 AA-51
7 645 046 6441 SPEAKER S9711-22NQ4171C 8OHM/1W
8 645 034 3919 HANDLE COVER CM-14 PA-765A
9 645 034 4299 PCB GUIDE RAIL MM-12A
10 645 065 0987 BRAID WIRE CH-15DNA
11 645 065 1069 DEGAUSSING COIL CH-15DNA
12 645 065 1137 BASE CH-15VNA
13 645 065 1144 METAL TOP COVER CH-15VNA AA-51
14 645 065 1151 JACK PLATE CH-14VXA
15 645 065 1083 BRACKET RIGHT CH-15VNA
16 645 065 1090 BRACKET LEFT CH-15VNA
17 645 065 0741 PH SCREW 3X6MM
18 645 034 3582 PH W/W SCR. 4X8MM
19 645 034 3612 SCREW+WASHER 3X6MM
20 645 034 3599 PH W/W SCR. 4X18MM
21 645 046 4850 PH W/W SCR. 3X6MM
22 645 046 4829 PH SCREW 3X8MM
23 645 034 3605 RH W/W SCR. 3X8MM
24 645 065 0758 PH SCREW 3X14MM
25 645 046 4836 PH SCREW 4X12MM
26 645 035 6216 BH SCREW 4X6MM
27 645 035 6223 WASHER OUT TEETH 4.5X8.5X0.5MM
28 645 034 3650 RUBBER WASHER 6X20X2.5MM
29 645 046 4959 FIBER WASHER 8DIAX4.5DIA.X0.5T
30 645 034 4268 F.B.T CLIP HV-1
31 645 046 5772 PURST LOCK A-11
32 645 065 1113 FBT FASTEN METAL CH-15VNA
33 645 065 1106 REPAIR BOTTOM CH-15VNA
34 645 034 3841 ID LABEL 83X51MM (N.S.P.)
35 645 050 3320 VR LABEL 14" AA-51
36 645 038 5605 NYLON CABLE TIE 2.5X120MM
37 645 046 5710 NYLON CABLE TIE 2.5X200MM
38 645 046 5796 SPACER SUPPORTS FCB-15
39 645 034 4763 FOOT PAD ASS’Y GL-24H-B
40 645 065 1120 PCB FASTEN METAL CH-15VNA
41 645 065 1274 SIGNAL BOARD CH-15VNA
42 645 046 6281 JACK BRACKET CM-21DXA
43 645 046 6373 GND PLTE DX SERIES 20X13X0.5MM
44 645 046 6380 SHIELDING PLATE DXA SERIES
45 645 046 6533 AC SOCKET ASS’Y MM-20A
46 645 065 1250 MAIN BOARD VMC-8415FP
47 645 065 1236 VIDEO BOARD CH-15VNA
48 645 065 1014 CRT M36AES13X01 CPT
49 645 040 9226 X RADIATION 110X50MM
50 645 065 3438 1 PCS SW ASS’Y
51 645 034 3940 CORDS EDGE PROTECTOR AMB-1C
52 645 065 0819 SLOT COVER 15" AA-51
53 645 050 3474 LED ASS’Y CH/CM-14VA-P
41
44
12
23 22
4
3
35 6
2
27
45
42
14 2118
26
18
1
48
10 11
20
47
28
16
13
34
8
43
717
24
522
37
15
33
9
30
19
31
46
21 25
32
18
25
29
36
20
49
21
40
19
39
18
38
50
51
52
53
All manuals and user guides at all-guides.com

8
ELECTRICAL PARTS
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
Note:
1. Materials of Capacitors and Resistors are abbreviated as follows ;
Resistors Capacitors
CF RES Carbon Film Resistor MEF CAP Metallized Polyester Film Capacitor
MF RES Metal Film Resistor (Non-inductive)
MOF RES Metallized Oxide Film Resistor MEMB CAP Mini Box Metallized Polyester Capacitor
(Non-inductive)
PEI CAP Polyester Film Capacitor (Inductive)
PPN CAP Polypropylene Film Capacitor (Non-inductive)
PPS CAP Polypropylene and Metallized Polypropylene
Film Capacitor (Non-inductive)
MPP CAP Metallized Polypropylene Capacitor
(Non-inductive)
X CAP(MKP) Metallized Polypropylene Film Capacitor
(Non-inductive)
CC CAP Ceramic Capacitor
EC CAP Electrolytic Capacitor
2. N.S.P. : Not available as service parts.
1 PCS SW ASS’Y
645 065 3438
(SWITCH)
SW901 645 046 5086 PCS POWER SWITCH
(MISCELLANEOUS)
645 066 3130 PCS L/W HOUSING
VR ASS’Y VMC-8415FP
645 065 1175
(RESISTORS)
R707 645 034 1854 CF RES 1 KOHM 1/6W +/-5%
R536 645 034 1960 CF RES 1.5 KOHM 1/6W +/-5%
R341 645 046 2337 CF RES 1.6 KOHM 1/6W +/-5%
(VARIABLE RESISTORS)
VR601 645 034 3438 VR 10 KOHM 9DIA ND F 15
VR602 645 034 3438 VR 10 KOHM 9DIA ND F 15
VR603 645 034 3438 VR 10 KOHM 9DIA ND F 15
VR604 645 034 3438 VR 10 KOHM 9DIA ND F 15
(MISCELLANEOUS)
W601 645 065 0963 FLT CBL 9/13P 1007 24AWG 270MM (N.S.P.)
LED ASS’Y CH/CM-14VA-P
645 050 3474
(RESISTOR)
R601 645 034 2363 CF RES 820OHM 1/4W +/-5%
(MISCELLANEOUS)
B601 645 065 0925 L/W HOUSING 1007 24AWG L=250MM
LED601 645 046 0296 LED 5DIA
VIDEO BOARD CH-15VNA
645 065 1236
(CAPACITORS)
C801 645 055 0119 EC CAP 100UF 25V 105C
C802 645 065 0581 EC CAP .47UF 250 V
C803 645 065 0598 CC CAP 331PF 50V +/-5%
C804 645 065 0598 CC CAP 331PF 50V +/-5%
C805 645 065 0604 CC CAP 471PF 50V +/-5%
C806 645 043 3139 CC CAP 103PF 1.5KV Z5U
C807 645 065 0574 EC CAP 4.7UF 250 V
(DIODE)
D803 645 034 3377 RECTIFIER DIODE 1N4003
(SEMICONDUCTORS)
Q801 645 034 3216 TR 2SC1815GR
Q802 645 040 9110 TR 2SC2688L
Q803 645 034 3216 TR 2SC1815GR
Q804 645 040 9110 TR 2SC2688L
Q805 645 034 3216 TR 2SC1815GR
Q806 645 040 9110 TR 2SC2688L
(RESISTORS)
R801 645 065 0406 MOF RES 6.2 KOHM 3W +/-5%
R803 645 034 2141 CF RES 3.3 KOHM 1/4W +/-5%
R804 645 065 0345 CF RES 82OHM 1/4W +/-5%
R805 645 034 2141 CF RES 3.3 KOHM 1/4W +/-5%
R808 645 034 2141 CF RES 3.3 KOHM 1/4W +/-5%
R809 645 065 0345 CF RES 82OHM 1/4W +/-5%
R810 645 034 2141 CF RES 3.3 KOHM 1/4W +/-5%
R813 645 034 2141 CF RES 3.3 KOHM 1/4W +/-5%
R814 645 046 2382 CF RES 180OHM 1/4W +/-5%
R815 645 034 2141 CF RES 3.3 KOHM 1/4W +/-5%
R816 645 046 3235 MOF RES 220 KOHM 1/2W +/-5%
R817 645 065 0406 MOF RES 6.2 KOHM 3W +/-5%
R819 645 034 2417 MF RES 2.2 KOHM 1/2W +/-1%
R821 645 046 2382 CF RES 180OHM 1/4W +/-5%
R822 645 046 2382 CF RES 180OHM 1/4W +/-5%
R823 645 045 9597 CF RES 150OHM 1/4W +/-5%
R824 645 034 2417 MF RES 2.2 KOHM 1/2W +/-1%
R825 645 065 0406 MOF RES 6.2 KOHM 3W +/-5%
R826 645 034 2417 MF RES 2.2 KOHM 1/2W +/-1%
(VARIABLE RESISTORS)
VR801 645 046 4805 POT VR METEL 5 KOHM 6DIA
VR802 645 048 3370 POT VR METAL 200OHM 6DIA
VR803 645 046 4805 POT VR METEL 5 KOHM 6DIA
VR804 645 048 3370 POT VR METAL 200OHM 6DIA
VR805 645 046 4805 POT VR METEL 5 KOHM 6DIA
(CONNECTORS)
G2 645 034 3667 CONNECTOR BASE P235142 (N.S.P.)
GND1 645 034 3698 CONNECTOR BASE M11352 (N.S.P.)
W801 645 034 3773 CONNECTOR BASE M241855 (N.S.P.)
W802 645 034 3759 CONNECTOR BASE M241854-X (N.S.P.)
(MISCELLANEOUS)
SK801 645 040 9240 CRT SOCKET ISHM35S (N.S.P.)
SGP801 645 065 0871 SPARK GAP 300V +/-20%
SGP802 645 065 0871 SPARK GAP 300V +/-20%
SGP803 645 065 0871 SPARK GAP 300V +/-20%
MAIN BOARD VMC-8415FP
645 065 1250
(CAPACITORS)
C122 645 046 0098 MEMB CAP .1UF 100V +/-5%
C123 645 046 0098 MEMB CAP .1UF 100V +/-5%
C124 645 046 0098 MEMB CAP .1UF 100V +/-5%
C135 645 065 0475 EC CAP 220UF 16V 105C
C218 645 046 0098 MEMB CAP .1UF 100V +/-5%
C219 645 046 4003 PEI CAP .022UF 100V +/-5%
C221 645 046 0098 MEMB CAP .1UF 100V +/-5%
All manuals and user guides at all-guides.com

9
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
C222 645 055 0171 EC CAP 2.2UF 50V 105C
C223 645 055 0218 EC CAP 47UF 25V 105C
C224 645 034 3049 MEMB CAP .47UF 63V +/-5%
C225 645 055 0157 EC CAP 1UF 50V 105C
C226 645 055 0171 EC CAP 2.2UF 50V 105C
C227 645 055 0171 EC CAP 2.2UF 50V 105C
C229 645 055 0218 EC CAP 47UF 25V 105C
C230 645 034 2837 CC CAP 104PF 50V Y5V
C231 645 065 0611 PEI CAP .0018UF 100V +/-5%
C232 645 065 0611 PEI CAP .0018UF 100V +/-5%
C233 645 046 3952 PEI CAP .001UF 100V +/-5%
C234 645 046 3952 PEI CAP .001UF 100V +/-5%
C235 645 055 0256 PEI CAP .0047UF 100V +/-5%
C236 645 046 0098 MEMB CAP .1UF 100V +/-5%
C237 645 046 3914 CC CAP 15PF 50V +/-5%
C238 645 046 3921 CC CAP 20PF 50V +/-5%
C239 645 046 4003 PEI CAP .022UF 100V +/-5%
C240 645 055 0171 EC CAP 2.2UF 50V 105C
C260 645 065 0536 EC CAP 470UF 16V 105C
C301 645 065 0635 PEI CAP .0033UF 100V +/-5%
C302 645 046 0098 MEMB CAP .1UF 100V +/-5%
C303 645 055 0157 EC CAP 1UF 50V 105C
C304 645 065 0550 EC CAP 4700UF 25V 105C
C307 645 046 3952 PEI CAP .001UF 100V +/-5%
C308 645 046 4034 PEI CAP .0056UF 100V +/-5%
C309 645 065 0642 PEI CAP .0068UF 100V +/-5%
C310 645 065 0628 PEI CAP .0022UF 100V +/-5%
C311 645 046 4317 MEMB CAP .68UF 63V +/-5%
C312 645 052 1263 EC CAP 100UF 35V 105C
C313 645 065 0451 EC CAP 1000UF 35V +/-20%105C
C315 645 065 0673 EC CAP 1UF 100V +/-20%105C
C316 645 055 0225 EC CAP 47UF 50V 105C
C322 645 065 0529 EC CAP 3.3UF 50V 105C
C334 645 055 0096 EC CAP 10UF 50V 105C
C401 645 046 4003 PEI CAP .022UF 100V +/-5%
C402 645 055 0218 EC CAP 47UF 25V 105C
C403 645 048 3349 CC CAP 102PF 1KV Y5P
C409 645 065 0482 EC CAP 220UF 100V +/-20%105C
C410 645 046 0098 MEMB CAP .1UF 100V +/-5%
C411 645 046 4256 PL CAP .0027UF 100V +/-2%
C412 645 055 0256 PEI CAP .0047UF 100V +/-5%
C413 645 055 0157 EC CAP 1UF 50V 105C
C422 645 065 0666 PPN CAP .039UF 800V +/-5%
C423 645 046 4195 PPN CAP .1UF 250V +/-5%
C424 645 065 0697 MPP CAP 2.7UF 100V +/-5%
C425 645 046 4096 MEF CAP 10UF 100V+/-10% 27.5MM
C501 645 046 4126 MEF CAP .22UF 100V +/-5%
C502 645 055 0171 EC CAP 2.2UF 50V 105C
C504 645 046 0098 MEMB CAP .1UF 100V +/-5%
C505 645 055 0171 EC CAP 2.2UF 50V 105C
C506 645 055 0171 EC CAP 2.2UF 50V 105C
C507 645 065 0659 PEI CAP .068UF 100V +/-5%
C508 645 055 0171 EC CAP 2.2UF 50V 105C
C521 645 055 0157 EC CAP 1UF 50V 105C
C522 645 065 0567 EC CAP 4.7UF 50V 105C
C706 645 034 3049 MEMB CAP .47UF 63V +/-5%
C708 645 065 0512 EC CAP 3300UF 16V 105C 13DIA
C901 645 034 3070 X CAP .1UF 250V +/-10%
C902 645 034 3070 X CAP .1UF 250V +/-10%
C903 645 034 3087 Y CAP 472PF 400V +/-20%
C904 645 034 3087 Y CAP 472PF 400V +/-20%
C905 645 046 3693 EC CAP 220UF 400V 25*40MM
C906 645 034 2974 MEF CAP .1UF 630V +/-5%
C907 645 052 1263 EC CAP 100UF 35V 105C
C908 645 046 4034 PEI CAP .0056UF 100V +/-5%
C909 645 038 5407 CC CAP 561PF 50V Y5P
C910 645 046 4270 MEMB CAP .01UF 100V +/-5%
C911 645 055 0263 MEMB CAP .0056UF 100V +/-5%
C912 645 046 0098 MEMB CAP .1UF 100V +/-5%
C913 645 055 0102 EC CAP 100UF 16V 105C
C914 645 065 0659 PEI CAP .068UF 100V +/-5%
C915 645 034 3087 Y CAP 472PF 400V +/-20%
C916 645 046 3808 CC CAP 102PF 2KV Z5U
C917 645 040 8946 EC CAP 470UF 100V 105C
C918 645 040 8946 EC CAP 470UF 100V 105C
C919 645 046 3846 CC CAP 222PF 2KV Z5U 7.5MM
C920 645 065 0451 EC CAP 1000UF 35V +/-20%105C
C921 645 065 0451 EC CAP 1000UF 35V +/-20%105C
C922 645 046 3617 EC CAP 1000UF 16V 105C
C923 645 046 3617 EC CAP 1000UF 16V 105C
C924 645 055 0133 EC CAP <=13DIA 1000UF 25V 105C
C925 645 055 0133 EC CAP <=13DIA 1000UF 25V 105C
C926 645 034 3025 MEMB CAP .22UF 63V +/-5%
C927 645 046 0098 MEMB CAP .1UF 100V +/-5%
C930 645 046 3617 EC CAP 1000UF 16V 105C
C931 645 046 3761 EC CAP 470UF 25V 105C
C932 645 034 2837 CC CAP 104PF 50V Y5V
C933 645 046 3600 EC CAP 1000UF 10V 105C
C936 645 046 3679 EC CAP 22UF 250V 105C
C937 645 055 0263 MEMB CAP .0056UF 100V +/-5%
(DIODES)
D209 645 034 3315 DIODE 1N4148
D210 645 034 3315 DIODE 1N4148
D211 645 034 3315 DIODE 1N4148
D301 645 034 3377 RECTIFIER DIODE 1N4003
D403 645 046 0272 RECTIFIER DIODE BYT56J
D404 645 046 0272 RECTIFIER DIODE BYT56J
D502 645 034 3315 DIODE 1N4148
D503 645 034 3315 DIODE 1N4148
D504 645 040 9141 RECTIFIER DIODE PG102R
D505 645 040 9141 RECTIFIER DIODE PG102R
D511 645 046 0234 RECTIFIER DIODE PG106R
D901 645 065 0710 RECTIFIER DIODE PG5407
D902 645 065 0710 RECTIFIER DIODE PG5407
D903 645 065 0710 RECTIFIER DIODE PG5407
D904 645 065 0710 RECTIFIER DIODE PG5407
D905 645 034 3346 RECTIFIER DIODE BYT52M T52MM
D906 645 040 9141 RECTIFIER DIODE PG102R
D907 645 046 0234 RECTIFIER DIODE PG106R
D908 645 034 3315 DIODE 1N4148
D909 645 034 3315 DIODE 1N4148
D910 645 048 3363 RECTIFIER DIODE UF5402G 52MM
D911 645 040 9165 RECTIFIER DIODE 31DF4
D912 645 046 0272 RECTIFIER DIODE BYT56J
D913 645 040 9165 RECTIFIER DIODE 31DF4
D914 645 034 3346 RECTIFIER DIODE BYT52M T52MM
D915 645 048 3363 RECTIFIER DIODE UF5402G 52MM
D916 645 046 0272 RECTIFIER DIODE BYT56J
ZD201 645 046 4614 ZENER DIODE HZ5C1
ZD501 645 046 4621 ZENER DIODE HZ9C1
ZD901 645 034 3339 ZENER DIODE HZ22-2
(FUSES)
F901 645 038 5650 FUSE 3.15A/250V SLOWBLOW 5*20
FR901 645 055 0072 FUSE RES 1OHM 1/4W +/-5%
FR902 645 055 0089 FUSE RES 1OHM 1/2W +/-5%
(INTEGRATED CIRCUITS)
IC202 645 046 4430 LINEAR IC TDA8361
IC203 645 046 4447 LINEAR IC TDA4665
IC301 645 034 3148 LINEAR IC TDA3653B
IC701 645 034 3124 LINEAR IC TDA7056B
IC901 645 034 3094 LINEAR IC UC3842AN
IC902 645 034 3179 REGULATOR IC KA431Z
IC903 645 046 4379 LINEAR IC TLP721F
IC904 645 046 4492 REGULATOR IC LM317T
(COILS)
L402 645 065 1076 LINEARITY COIL 7.5 UH +/-20%
L405 645 046 6106 DIODE MODULA COIL 90 UH +/-20%
L901 645 046 0876 CHOKE COIL 20 UH +/-20%
L902 645 046 0876 CHOKE COIL 20 UH +/-20%
L903 645 046 0876 CHOKE COIL 20 UH +/-20%
L904 645 046 0876 CHOKE COIL 20 UH +/-20%
L905 645 046 0876 CHOKE COIL 20 UH +/-20%
(SEMICONDUCTORS)
Q210 645 034 3216 TR 2SC1815GR
Q303 645 046 0203 TR 2SD667C
Q304 645 046 4515 TR 2SB647
Q310 645 034 3216 TR 2SC1815GR
Q311 645 046 4515 TR 2SB647
Q312 645 046 4553 TR 2SD1163A
Q312 645 046 4546 TR 2SC4106M
Q401 645 046 4560 TR 2SD1348T
Q402 645 046 4539 TR 2SC5411
Q501 645 034 3216 TR 2SC1815GR
Q502 645 034 3209 TR 2SA733P
All manuals and user guides at all-guides.com

10
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
Q503 645 034 3209 TR 2SA733P
Q901 645 058 8280 FET SSS7N60B
Q902 645 034 3209 TR 2SA733P
Q903 645 034 3216 TR 2SC1815GR
(RESISTORS)
R231 645 046 2481 CF RES 22 KOHM 1/6W +/-5%
R232 645 046 2320 CF RES 15 KOHM 1/6W +/-5%
R233 645 034 1854 CF RES 1 KOHM 1/6W +/-5%
R234 645 046 2900 CF RES 5.6 KOHM 1/6W +/-5%
R235 645 046 2191 CF RES 10 KOHM 1/6W +/-5%
R236 645 034 1885 CF RES 100 KOHM 1/6W +/-5%
R239 645 046 2177 CF RES 100OHM 1/6W +/-5%
R240 645 046 2177 CF RES 100OHM 1/6W +/-5%
R241 645 046 2177 CF RES 100OHM 1/6W +/-5%
R242 645 034 1854 CF RES 1 KOHM 1/6W +/-5%
R244 645 034 1885 CF RES 100 KOHM 1/6W +/-5%
R252 645 046 2306 CF RES 150OHM 1/6W +/-5%
R253 645 034 1885 CF RES 100 KOHM 1/6W +/-5%
R254 645 046 2580 CF RES 3 KOHM 1/6W +/-5%
R261 645 046 2795 CF RES 47 KOHM 1/6W +/-5%
R290 645 046 3068 CF RES 82 KOHM 1/6W +/-5%
R291 645 065 0321 CF RES 680OHM 1/6W +/-5%
R292 645 046 3044 CF RES 8.2 KOHM 1/6W +/-5%
R293 645 046 2900 CF RES 5.6 KOHM 1/6W +/-5%
R294 645 046 2993 CF RES 6.8 KOHM 1/6W +/-5%
R296 645 046 2269 CF RES 120OHM 1/6W +/-5%
R297 645 034 1854 CF RES 1 KOHM 1/6W +/-5%
R301 645 046 2481 CF RES 22 KOHM 1/6W +/-5%
R302 645 046 2931 CF RES 62 KOHM 1/6W +/-5%
R303 645 046 2863 CF RES 56OHM 1/6W +/-5%
R304 645 046 2566 CF RES 27 KOHM 1/6W +/-5%
R305 645 034 2455 MOF RES 1OHM 2W +/-5%
R307 645 046 2733 CF RES 4.3 KOHM 1/6W +/-5%
R308 645 046 2733 CF RES 4.3 KOHM 1/6W +/-5%
R309 645 065 0383 MOF RES 51OHM 2W +/-5%
R311 645 046 2771 CF RES 470OHM 1/6W +/-5%
R312 645 046 3150 MOF RES 100OHM 1W +/-5%
R314 645 034 2097 CF RES 270OHM 1/2W +/-5%
R315 645 034 2097 CF RES 270OHM 1/2W +/-5%
R322 645 048 3240 CF RES 200 KOHM 1/6W +/-5%
R323 645 048 3264 CF RES 910 KOHM 1/6W +/-5%
R328 645 065 0444 CEMENT W-W 3.9OHM 5W +/-5%
R329 645 046 3099 CF RES 910OHM 1/6W +/-5%
R337 645 046 2795 CF RES 47 KOHM 1/6W +/-5%
R338 645 046 2924 CF RES 6.2 KOHM 1/6W +/-5%
R339 645 046 2580 CF RES 3 KOHM 1/6W +/-5%
R341 645 034 1885 CF RES 100 KOHM 1/6W +/-5%
R348 645 065 0352 CF RES 820OHM 1/6W +/-5%
R349 645 046 2252 CF RES 1.1 KOHM 1/6W +/-5%
R401 645 046 3075 CF RES 820 KOHM 1/6W +/-5%
R402 645 046 2320 CF RES 15 KOHM 1/6W +/-5%
R405 645 046 3037 CF RES 82OHM 1/2W +/-5%
R406 645 065 0376 MOF RES 39OHM 3W +/-5%
R410 645 048 3271 MOF RES 470OHM 1W +/-5%
R414 645 046 2825 CF RES 4.7OHM 1/6W +/-5%
R421 645 046 2269 CF RES 120OHM 1/6W +/-5%
R422 645 046 2849 CF RES 5.1 KOHM 1/6W +/-5%
R501 645 034 1861 CF RES 1 KOHM 1/4W +/-5%
R502 645 034 1878 CF RES 10 KOHM 1/4W +/-5%
R503 645 046 2283 CF RES 12 KOHM 1/6W +/-5%
R506 645 046 2788 CF RES 4.7 KOHM 1/6W +/-5%
R507 645 046 2566 CF RES 27 KOHM 1/6W +/-5%
R508 645 046 2566 CF RES 27 KOHM 1/6W +/-5%
R509 645 046 2634 CF RES 33 KOHM 1/6W +/-5%
R510 645 046 2283 CF RES 12 KOHM 1/6W +/-5%
R511 645 034 1885 CF RES 100 KOHM 1/6W +/-5%
R512 645 046 2474 CF RES 2.2 KOHM 1/6W +/-5%
R520 645 046 2337 CF RES 1.6 KOHM 1/6W +/-5%
R521 645 034 1960 CF RES 1.5 KOHM 1/6W +/-5%
R527 645 034 1854 CF RES 1 KOHM 1/6W +/-5%
R528 645 046 2894 CF RES 560OHM 1/6W +/-5%
R711 645 046 2689 CF RES 390OHM 1/6W +/-5%
R712 645 046 2993 CF RES 6.8 KOHM 1/6W +/-5%
R901 645 065 0253 CF RES 1 MOHM 1/2W +/-5%
R902 645 065 0437 FUSE RES 0.68OHM 1W +/-5%
R904 645 034 2516 MOF RES 47 KOHM 3W +/-5%
R905 645 034 2516 MOF RES 47 KOHM 3W +/-5%
R906 645 034 2547 CEMENT RES 10 KOHM 5W +/-5%
R907 645 046 3082 CF RES 91OHM 1/6W +/-5%
R908 645 046 2191 CF RES 10 KOHM 1/6W +/-5%
R909 645 046 2849 CF RES 5.1 KOHM 1/6W +/-5%
R910 645 046 3105 CF RES 9.1 KOHM 1/6W +/-5%
R911 645 046 2429 CF RES 2 KOHM 1/6W +/-5%
R912 645 046 2344 CF RES 16 KOHM 1/6W +/-5%
R913 645 046 2467 CF RES 220OHM 1/6W +/-5%
R914 645 046 2191 CF RES 10 KOHM 1/6W +/-5%
R915 645 046 2757 CF RES 47OHM 1/6W +/-5%
R916 645 046 2894 CF RES 560OHM 1/6W +/-5%
R917 645 046 2757 CF RES 47OHM 1/6W +/-5%
R918 645 046 2467 CF RES 220OHM 1/6W +/-5%
R919 645 046 2757 CF RES 47OHM 1/6W +/-5%
R920 645 046 2306 CF RES 150OHM 1/6W +/-5%
R921 645 046 2191 CF RES 10 KOHM 1/6W +/-5%
R922 645 046 3259 MOF RES 0.22OHM 2W +/-5%
R923 645 046 3495 CEMENT RES 220OHM 5W +/-5%
R924 645 044 3688 CF RES 24 KOHM 1/6W +/-5%
R925 645 046 2559 CF RES 2.7 KOHM 1/6W +/-5%
R928 645 046 2467 CF RES 220OHM 1/6W +/-5%
R929 645 046 2894 CF RES 560OHM 1/6W +/-5%
R930 645 034 1854 CF RES 1 KOHM 1/6W +/-5%
R931 645 034 1854 CF RES 1 KOHM 1/6W +/-5%
R932 645 065 0390 MOF RES 5.6OHM 2W +/-5%
R934 645 046 3365 MOF RES 470OHM 3W +/-5%
R935 645 048 3233 CF RES 1.5OHM 1/2W +/-5%
R936 645 065 0369 MOF RES 2.7OHM 3W +/-5%
R937 645 034 1939 CF RES 120 KOHM 1/4W +/-5%
R938 645 046 2511 CF RES 240OHM 1/6W +/-5%
R939 645 046 2290 CF RES 1.3 KOHM 1/6W +/-5%
R941 645 046 2894 CF RES 560OHM 1/6W +/-5%
R942 645 046 2566 CF RES 27 KOHM 1/6W +/-5%
(TRANSFORMERS)
T401 645 046 5956 DRIVE TRANS. VS-10S
T502 645 065 1052 FBT TRANS. CH-15DNA
T901 645 048 3615 LINE FILTER CH-19DXA 30MH
T902 645 065 1038 POWER TRANS. CH-15DNA NEW
(VARIABLE RESISTORS)
VR202 645 034 3483 POT VR METAL 100 KOHM 6DIA
VR203 645 034 3476 POT VR METAL 10 KOHM 6DIA
VR204 645 034 3483 POT VR METAL 100 KOHM 6DIA
VR205 645 034 3483 POT VR METAL 100 KOHM 6DIA
VR301 645 046 4775 POT VR METAL 300OHM 6DIA
VR302 645 034 3476 POT VR METAL 10 KOHM 6DIA
VR303 645 034 3476 POT VR METAL 10 KOHM 6DIA
VR305 645 034 3476 POT VR METAL 10 KOHM 6DIA
VR306 645 034 3476 POT VR METAL 10 KOHM 6DIA
VR401 645 034 3476 POT VR METAL 10 KOHM 6DIA
VR501 645 034 3520 POT VR METAL 50 KOHM 6DIA
VR503 645 034 3520 POT VR METAL 50 KOHM 6DIA
VR901 645 065 0734 POT VR METAL 200OHM 6DIA
(OSCILLATORS)
X201 645 046 3525 OSCILLATOR 3.579545 MHZ
X202 645 046 3532 OSCILLATOR 4.433619 MHZ
(CONNECTOR BASES)
B290 645 065 0772 CONNECTOR BASE M2418513
B701 645 034 3674 CONNECTOR BASE M241852
B901 645 046 4997 CONNECTOR BASE M241835-X
B902 645 034 3735 CONNECTOR BASE M241833-X
B903 645 034 3698 CONNECTOR BASE M11352
B905 645 034 3674 CONNECTOR BASE M241852
GND3 645 034 3667 CONNECTOR BASE P235142
PIN1 645 046 0371 CONNECTOR BASE 1038H
PIN2 645 046 0371 CONNECTOR BASE 1038H
PIN3 645 046 0371 CONNECTOR BASE 1038H
PIN4 645 046 0371 CONNECTOR BASE 1038H
PIN5 645 046 0371 CONNECTOR BASE 1038H
(MISCELLANEOUS)
B201 645 051 1066 CABLE CH-19DXA AWM2464 #24*4C
B904 645 048 3547 L/W HOUSING 1007 24AWG L=300MM
NTC901 645 034 2561 NTCR RES 10OHM +/-20% 5A
P201 645 065 0949 HOUSING L=320MMND 2835 24AWG
P401 645 046 4980 CONNECTOR BASE M11354
PTC901 645 034 2554 PTCR RES 14OHM +/-30%
All manuals and user guides at all-guides.com

11
LOCATION PARTS NO. DESCRIPTION
SIGNAL BOARD CH-15VNA
645 065 1274
(CAPACITORS)
C201 645 046 3549 EC CAP 10UF 25V +/-20%
C206 645 034 3025 MEMB CAP .22UF 63V +/-5%
C207 645 034 3025 MEMB CAP .22UF 63V +/-5%
C208 645 046 3549 EC CAP 10UF 25V +/-20%
C261 645 034 2837 CC CAP 104PF 50V Y5V
C262 645 046 3563 EC CAP 100UF 16V +/-20%105C
C263 645 034 3025 MEMB CAP .22UF 63V +/-5%
C705 645 046 3549 EC CAP 10UF 25V +/-20%
(DIODES)
D201 645 034 3315 DIODE 1N4148
D201 645 034 3308 DIODE 1N4148
D202 645 034 3315 DIODE 1N4148
D202 645 034 3308 DIODE 1N4148
D203 645 034 3315 DIODE 1N4148
D203 645 034 3308 DIODE 1N4148
D204 645 034 3315 DIODE 1N4148
D204 645 034 3308 DIODE 1N4148
D205 645 034 3315 DIODE 1N4148
D205 645 034 3308 DIODE 1N4148
D206 645 034 3315 DIODE 1N4148
D206 645 034 3308 DIODE 1N4148
D701 645 034 3315 DIODE 1N4148
D701 645 034 3308 DIODE 1N4148
D702 645 034 3315 DIODE 1N4148
D702 645 034 3308 DIODE 1N4148
(CONNECTOR BASE)
P201 645 065 0765 CONNECTOR BASE M241856R
(SEMICONDUCTOR)
Q202 645 034 3216 TR 2SC1815GR
(RESISTORS)
R201 645 034 2349 CF RES 75OHM 1/6W +/-5%
R202 645 046 2467 CF RES 220OHM 1/6W +/-5%
R209 645 046 2788 CF RES 4.7 KOHM 1/6W +/-5%
R210 645 034 2349 CF RES 75OHM 1/6W +/-5%
R211 645 046 2191 CF RES 10 KOHM 1/6W +/-5%
R212 645 046 2191 CF RES 10 KOHM 1/6W +/-5%
R213 645 046 2559 CF RES 2.7 KOHM 1/6W +/-5%
R214 645 034 2349 CF RES 75OHM 1/6W +/-5%
R215 645 046 2467 CF RES 220OHM 1/6W +/-5%
R259 645 065 0284 CF RES 180 KOHM 1/6W +/-5%
R260 645 046 2733 CF RES 4.3 KOHM 1/6W +/-5%
R708 645 046 3044 CF RES 8.2 KOHM 1/6W +/-5%
R709 645 046 2467 CF RES 220OHM 1/6W +/-5%
(JACK)
RCA701 645 046 5079 RCA JACK JPJ1151-01-230
(SWITCH)
SW201 645 065 0789 SLIDE SWITCH SS-22F-17-G92P2T
(MISCELLANEOUS)
YC201 645 046 5314 VERTICAL SOCKT TCS7940-01-2011
YC202 645 046 5307 VERTICAL SOCKET TCS7945-14-201
BNC201 645 046 5062 BNC CONNECTOR HXC0312-01-210
BNC202 645 046 5055 BNC CONNECTOR HXC0336-01-010
All manuals and user guides at all-guides.com
all-guides.com

Nov./’03
SANYO Electric Co., Ltd.
Osaka, Japan
All manuals and user guides at all-guides.com
