Sanyo PLC-EF60A Installation guide

■Brightness: 5,800 (PLC-EF60A), 6,500 (PLC-XF60A) ANSI lumens
■Resolution: 1,400 x 1,050 (PLC-EF60A), 1,024 x 768 (PLC-XF60A)
■Contrast ratio 1,300 : 1
■Horizontal and vertical lens shift function
■Two lamp system
■Network integration optional
■13 optional interchangeable lenses
■Mechanical shutter
www.sanyo.de
PLC-EF60A | PLC-XF60A
Brilliant Ideas for Great Images.

Technical specifications subject to change without notice. Status 03/2007
PLC-EF60A | PLC-XF60A
Brilliant Ideas for Great Images.
TECHNICAL DETAILS
Category
Panel
Lamp
Brightness in ANSI lumens
Lamp Service Life
Fan noise
Lens
Throw Distance Ratio
Throw Distance
Contrast Ratio
Resolution in pixels
Horizontal Resolution
Uniformity
Bandwith/Frequency
Colour Systems
Connections
Keystone Correction
Lens-Shift
HDTV Signals
Computer Compatibility
Zoom/Focus
Power Consumption
Warranty
Dimensions (W x H x D)
Weight
Standard Accessories
Optional Accessories
Lenses
PLC-EF60A PLC-XF60A
Professional
3 x 1.4" TFT p-Si (4 : 3), microlens
2 x 300 W UHP (LMP-80)
5,800 6,500
3,000 h (Eco mode) / 1,500 h (Normal mode)
39 dB (Eco mode) / 42 dB (Normal mode)
Delivery without lens
Depending on lens
Depending on lens
1,300 : 1
1.400 x 1.050 (S-XGA+) 1.024 x 768 (XGA)
1,100 TV lines
90 %
230 MHz, horizontal 15 –120 kHz, vertical 50 –120 Hz
PAL, SECAM, NTSC, NTSC4.43, PAL-M/N
Input 1: DVI-D (digital/HDCP), D-Sub15 (RGB)
Input 2: 5 BNC (RGBHV/Video/Y-Pb/Cb-Pr/Cr)
Input 3: 3 x RCA (Video/Y-Pb/Cb-Pr/Cr), Mini-DIN 4-pin (S-Video)
Input 4: freely configurable with optional interface boards
Input 5: freely configurable with optional interface boards
Monitor Output: D-Sub15
Control Input 1: D-Sub9 (RS232)
Control Input 2: USB Type B (mouse control)
Control Input 3: 3.5 mm Stereo Jack (IR remote control)
Control Output: D-Sub9 (RS232)
Others: USB Type A (USB-Key)
vertical +/–40°, horizontal +/–30°
2.5 : 1 to 1 : 2.5 vertical (for LNS-W05)
1 : 1 vertical (for LNS-W03/W07)
10 : 0 to 0 : 10 vertical (for all other lenses)
1 : 1 horizontal (for LNS-W03/W05/W07)
2 : 3 to 3 : 2 horizontal (for all other lenses)
720p, 1,035i, 1,080i
U-XGA/S-XGA+/S-XGA/W-XGA/XGA/S-VGA/VGA
Depending on lens
900 W (Normal mode)
3 years
518 x 252 x 606 mm
24 kg
Wireless remote control, batteries, D-Sub15 cable, power cable, operating manual (CD-ROM),
2 Lens-Adapters, Software for Real Colour Manager Pro
7 optional adapter boards: DVI-I-Board (POA-MD18DVI), 5 BNC-Board (POA-MD16VD1), D-Sub15-Board
(POA-MD04VGA), Progressive Video-Board (POA-MD09VD3), Network-Board (POA-MD19NET), HD-SD-SDI-Board
(POA-MD17SDI), WARP & Blending-Board (POA-MD21WARP)
13 interchangeable lenses
Optional wide angle lenses: LNS-WO1Z, LNS-WO2Z, LNS-WO3, LNS-WO4, LNS-WO5, LNS-W06, LNS-W07
Optional standard lenses: LNS-SO2Z, LNS-SO3
Optional tele zoom lenses: LNS-MO1Z, LNS-TO1Z, LNS-TO2, LNS-TO3
