INSTRUCTION MANUAL VCC-9624
COLOR CCD CAMERA
About this manual
•Before installing and using the camera, please read this manual
carefully. Be sure to keep it handy for later reference.
L53D4/US GB 1998, 3, 10
SANYO INDUSTRIAL VIDEO
COLOR VIDEO CAMERA LIMITED WARRANTY
OBLIGATIONS
In order to obtain warranty service, the product must be delivered to and picked up from an Authorized Sanyo Service Center at the user’s expense, unless specifically stated otherwise in this warranty. The names and
addresses of Authorized Sanyo Service Centers may be obtained by writing to SFS Corporation, SFC’s warranty administrator, at any of the addresses listed below, or by calling (toll-free) 1-800-421-5013.
New Jersey Office
210 Riser Road
Little Ferry, NJ 07643
201-641-3000
California Office
1200 W. Artesia Blvd.
Compton, CA 90220
310-537-5830
Illinois Office
900 N. Arlington Heights Rd.
Itasca, IL 60143
708-775-1414
THIS WARRANTY IS VALID ONLY ON SANYO PRODUCTS PURCHASED OR RENTED IN THE UNITED STATES OF AMERICA, EXCLUDING HAWAII AND ALL U.S. TERRITORIES AND PROTECTORATES. THIS
WARRANTY APPLIES ONLY TO THE ORIGINAL RETAIL USER. THE ORIGINAL DATED BILL OF SALE, SALES SLIP OR RENTAL AGREEMENT MUST BE SUBMITTED TO THE AUTHORIZED SANYO SERVICE CENTER
AT THE TIME WARRANTY SERVICE IS REQUESTED.
Subject to the OBLIGATIONS above and EXCLUSIONS below, SANYO FISHER (USA) CORPORATION warrants this SANYO product against defects in materials and workmanship for the periods specified below. SFC
will repair or replace (at its option) the product and any of its parts which fail to conform to this warranty. The warranty period commences on the date the product was first purchased or rented at retail.
LABOR PARTS IMAGE DEVICE
2 YEARS 2 YEARS 2 YEARS
EXCLUSIONS
This warranty does not cover (A) the adjustment of customer-operated controls as explained in the appropriate model’s instruction manual, or (B) the repair of any product whose serial number has been altered,defaced
or removed.
This warranty shall not apply to the cabinet or cosmetic parts, antenna, knobs, batteries or image burns to projection or picture tubes caused by electronic devices or games.
This warranty does not apply to uncrating, setup, installation, removal of the product for repair or reinstallation of the product after repair.
This warranty does not apply to repairs or replacements necessitated by any cause beyond the control of SFC including, but not limited to, any malfunction, defect or failure caused by or resulting from unauthorized
service or parts, improper maintenance, operation contrary to furnished instructions, shipping or transit accidents, modification or repair by the user, abuse, misuse, neglect, accident, incorrect power line voltage, fire,
flood or other Acts of God, or normal wear and tear.
The foregoing is in lieu of all other expressed warranties and SFC does not assume or authorize any party to assume for it any other obligation or liability.
THE DURATION OF ANY WARRANTIES WHICH MAY BE IMPLIED BY LAW (INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS) IS LIMITED TO THE TERM OF THIS WARRANTY. IN NO EVENT
SHALL SFC BE LIABLE FOR SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING FROM OWNERSHIP OR USE OF THIS PRODUCT, OR FOR ANY DELAY IN THE PERFORMANCE OF ITS OBLIGATIONS
UNDER THIS WARRANTY DUE TO CAUSES BEYOND ITS CONTROL.
SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS AND/OR DO NOT ALLOW THE EXCLUSION OR LIMITATION OF CONSEQUENTIAL DAMAGES, SO THE ABOVE
LIMITATIONS AND EXCLUSIONS MAY NOT APPLY TO YOU.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY HAVE OTHER RIGHTS, WHICH VARY FROM STATE TO STATE.
ATTENTION
For your protection in the event of theft or loss of this product, please fill in the information below for you own personal records.
Model No._____________________________________________________________________ Serial No. _____________________________________________________________________
(Located on back or bottom side of unit.)
Date of Purchase _______________________________________________________________ Purchase Price _________________________________________________________________
Where Purchased _________________________________________________________________________________________________________________________________________________
L53D4/US GB 1998, 3, 10
18 English
Safety Guard
THIS SYMBOL INDICATES THAT THERE ARE
IMPORTANT OPERATING AND MAINTENANCE
INSTRUCTIONS IN THE LITERATURE ACCOMPANYING
THIS UNIT.
ARNING:
TO PREVENT THE RISK OF FIRE OR ELECTRIC SHOCK , DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
This installation should be made by a qualified service person and
should conform to all local codes.
INFORMATION TO USER
For the customers in Canada
This Class B digital apparatus complies with Canadian ICE -003.
Pour la clientèle canadienne
Cet appareil numerique de la Classe B est conforme a la norme
NMB-003 du Canada.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may
cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of
the following measures:
–Reorient or relocate the receiving antenna.
–Increase the separation between the equipment and receiver.
–Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
–Consult the dealer or an experienced radio/TV technician for
help.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved by Sanyo may
void the user’s authority to operate this camera.
L53D4/U GB 1998, 3, 10
English 1
CONTENTS
PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
PARTS NAMES AND FUNCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
PREPARATIONS AND CONNECTIONS . . . . . . . . . . . . . . . . . . . . . . . . . 7
CONNECTIONS AND INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . 8
SETTINGS AND ADJUSTMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Accessories
crews for base installation
(4 x 35 tapping screws)
The rated value label is located on the back of the camera.
FEATURES
•Built-in interline transfer method 1/3" CCD, approx. 410,000
picture elements
•Low smear, anti-blooming, low lag, no burning and no geometric
distortion using the CCD solid state image device
•Built-in Vari Focal type auto iris lens, F=2.0 - 2.7, f=2,6 - 5.6 mm
•100% solid state components giving excellent immunity to shock
and vibration
•Not subject to interference from magnetic or electrostatic fields
•High sensitivity mininum required illumination is approx. 6 lux at
F2.0
•TTL auto-white balance, auto-tracking system
•With manual PAN/TILT/ROUND mechanism
•Horizontal resolution, more than 470 TV lines
•Power supply: 24 V AC operation
L53D4/U GB 1998, 3, 10
2 English
PRECAUTIONS
In case of problem
Do not use the camera if smoke or a strange odour comes from the
unit, or if it seems not to function correctly. Disconnect the power
cord immediately, and consult your dealer (or a anyo Authorized
ervice Centre).
Do not open or modify
Do not open the cabinet, as it may be dangerous and cause damage
to the unit. For internal settings and repairs, consult your dealer (or a
anyo Authorized ervice Centre).
Do not put objects inside the unit
Make sure that no metal objects or flammable substance get inside
the camera. If used with a foreign object inside, it could cause a fire,
short-circuits or damages.
If water or a liquid gets inside the camera, disconnect the power cord
immediately, and consult your dealer (or a anyo Authorized ervice
Centre). Be careful to protect the camera from rain, sea water, etc.
Be careful when handling the unit
To prevent damages, do not drop the camera or subject it to strong
shock or vibration.
Install away from electric or magnetic fields
If installed close to a TV, radio transmitter, magnet, electric motor,
transformer, audio speakers the magnetic field they generate will
distort the image.
Protect from humidity and dust
To prevent damages to the camera, do not install it where there is
greasy smoke or steam, where the dampness may get too high, or
where there is a lot of dust.
Protect from high temperatures
Do not install close to stoves, or other heat generating devices, such
as spotlights, etc., or where it could be subject to direct sunlight, as
that could cause deformation, discoloration or other damages.
Be careful when installing close to the ceiling, in a kitchen or boiler
room, as the temperature may raise to high levels.
Install where the temperature range will stay between –10˚C and
50˚C. (no condensation)
Cleaning
•Dirt can be removed from the cabinet by wiping it with a soft
cloth. To remove stains, wipe with a soft cloth moistened with a
soft detergent solution and wrung dry, then wipe dry with dry soft
cloth.
•Do not use benzine, thinner or other chemical product on the
cabinet, as that may cause deformation and paint peeling. Before
using a chemical cloth, make sure to read all accompanying
instructions. Make sure that no plastic or rubber material comes in
contact with the cabinet for a long period of time, as that may
cause damage or paint peeling.
L53D4/U GB 1998, 3, 10
English 3
PARTS NAMES AND FUNCTIONS
MONITOR
GND
M
A
1
0
BLCWB SYC
LEVEL
B
R
1
5
1
4
3
22
F
G
9
7
A
HIO
L
JKMN
6
L-PHASE
8
C
B
A
1
1
Manual pan, tilt and rotation
The angle of the lens can be adjusted
manually in ranges indicated below.
A: Horizontally ± 45˚
B: Vertically ± 60˚
C: Rotation of the camera unit ± 35˚
L53D4/U GB 1998, 3, 10
4 English
PARTS NAMES AND FUNCTIONS
1Camera unit fixing screws (4)
These screws are used to attach the camera unit to the base.
Tighten the four screws evenly when attaching the camera unit.
2Screw openings for base installation
These openings are to attach the base to the ceiling or a wall
using the four supplied tapping screws.
3CAMERA (VIDEO) OUT terminal screw
Video signal output terminal. Insert the center wire of the coaxial
cable into the CAMERA OUT terminal, then tighten the screw to
secure it.
4GND (ground) terminal screw
Video signal ground terminal. Insert the shielding mesh of the
coaxial cable under the GND terminal plate, then tighten the
screw to secure it.
5Cabling tab
When the cables cannot be run behind the ceiling, etc., remove
this tab to allow the coaxial cable to go through.
624 V AC input terminal
(24 V AC, GND)
With this camera use only the 24 V AC
power adaptor model No. VPT-115
available from anyo.
Power supply connections
Use a 3 wire grounded cable (22 AWG
or more), and connect as shown by the
illustration.
CAUTION:
• To prevent camera and/or AC
adaptor failure, pay close attention
polarity when making the connections.
• To prevent fire hazard any UL listed
wire rated VW-1, should be used for
the 24 V AC cable input terminal.
7Lens cover
This cover will protect the lens from dust and damage. Turn the
cover in the direction of the arrow, shown on the illustration, to
remove it. To install the cover, align the tabs (A) with the
openings, then turn it in the opposite direction.
GND
AC AC
L53D4/U GB 1998, 3, 10
English 5
PARTS NAMES AND FUNCTIONS
8Secondary lens cover
9Lens
FFocus ring
To set the focus, loosen the focus ring knob, then turn the ring
towards ∞ (infinity) or N (near) as necessary. When the focus is
set as desired, tighten the focus ring knob.
GZoom ring
To adjust the viewing range (zoom), loosen the zoom ring knob,
then turn the ring towards T (the range will be smaller and the
subject larger) or W (the range will be wider and the subject
smaller) as necessary. When the zoom is set as desired, tighten
the zoom ring knob.
HGND (ground) pin
For monitor use. ( ee I)
IMONITOR output pin
When setting up the camera, connect a monitor to this video
output pin and to the GND pin using alligator clip cables, then
using the image displayed on the monitor, set the surveillance
angle and range, the lens focus, etc.
JColor adjustment (B: blue gain, R: red gain) volume
controls
KB (white balance) switch
A: Automatic white balance
M: Manual white balance
To set the white balance manually, set the WB switch to M, then
adjust the color by turning the B and R volume controls.
LBLC (backlight compensation) switch
0: Backlight compensation off
1: Backlight compensation on
For backlight compensation, set the BLC switch to 1, then, if
necessary, adjust the LEVEL volume control.
MSYC (synchronization) switch
0: Internal sync
1: L-L (line lock) sync
NLEVEL volume control
Used when the BLC switch is set to 1. Under normal conditions, it
should be turned all the way to the left. When adjusting the
backlight compensation, turn it to the right until the desired
correction level is obtained.
OL-PHASE (line phase) volume control
Used when the YC switch is set to 1. Turn it to adjust the line
phase between two or more cameras.
L53D4/U GB 1998, 3, 10
6 English
PREPARATIONS AND CONNECTIONS
Concerning the coaxial cable
To connect the camera to peripheral devices, use a coaxial cable with BNC plug.
•Cable type RG-6U (5C-2V), 500 m maximum.
•Cable type RG-11U (7C-2V), 600 m maximum.
If the type of peripheral devices connected, the type of cable used and/or the cable length
are not as specified, the image and synchronization signals may not be transmitted
correctly.
CAUTION:
Use CCTV/Video grade coaxial cable. Due to its construction, an RG-59U cable will not
transmit the signal properly when installed through conduits or through the air, and
therefore cannot be used.
Installing the BNC plug (sold separately)
1Cut the extremity of the coaxial cable (sold separately), as illustrated.
2Insert the cable through the adaptor, then turn the shielding mesh over.
3Loosen the center wire securing screw of the plug, then install the cable in the BNC
plug, so that the center wire is threaded through the plug center opening.
Before tightening the center wire securing screw, make sure the center wire comes out
through the plug center opening.
4Screw the adaptor onto the plug.
7mm 8mm
3 4
1 2
L53D4/U GB 1998, 3, 10
English 7
CONNECTIONS AND INSTALLATION
Basic connections for monitoring or recording
The peripheral devices (VCR, monitor, etc.) and cables are sold separately.
1Make the video signal connection between the camera and the monitor or time lapse
VCR.
2Plug the AC adaptor to a wall outlet.
Adjust the picture on the monitor using the Brightness and Contrast controls.
Multiple cameras connection
You can use multiple cameras by connecting them a camera switcher or a quad unit (sold
separately), then conducting the surveillance from one location by splitting the monitor screen
to view the image from each camera, or by switching the image from each camera on the
monitor screen. For detailed information, please refer to the installed devices instruction
manuals.
(Example of connection to a monitor)
NOTE: (Fig. 1)
•Make sure the AC adaptor is not
connected to the wall outlet before
connecting it to the 12 V DC input
terminals.
•When making the connections be careful
to respect the polarity and not to
shortcut the terminals.
VIDEO IN Time lapse VCR VIDEO OUT VIDEO IN
Monitor
(sold separately)
(sold separately)
Fig. 1
VIDEO IN
: VIDEO IN
: VIDEO OUT
L53D4/U GB 1998, 3, 10
8 English
