-2 -
WARNING
Do not use solder containing lead.
This product has been manufactured using lead-free
solder in order to help preserve the environment.
Because of this, be sure to use lead-free solder when
carrying out repair work, and never use solder
containing lead.
Lead-free solder has a melting point that is 30 - 40°C (86 -
104°F) higher than solder containing lead, and moreover it
does not contain lead which attaches easily to other metals.
As a result, it does not melt as easily as solder containing
lead, and soldering will be more difficult even if the
temperature of the soldering iron is increased.
The extra difficulty in soldering means that soldering time
will increase and damage to the components or the circuit
board may easily occur.
Because of this, you should use a soldering iron and
solder that satisfy the following conditions when carrying out
repair work.
Soldering iron
Use a soldering iron which is 70 W or equivalent, and
which lets you adjust the tip temperature up to 450°C
(842°F). It should also have as good temperature recovery
characteristics as possible.
Set the temperature to 350°C (662°F) or less for chip
components, to 380°C (716°F) for lead wires and similar,
and to 420°C (788°F) when installing and removing shield
plates.
The tip of the soldering iron should have a C-cut shape or
a driver shape so that it can contact the circuit board as flat
or in a line as much as possible.
Solder
Use solder with the metal content and composition ratio by
weight given in the table below. Do not use solders which
do not meet these conditions.
Lead-free solder is available for purchase as a service tool.
Use the following part number when ordering:
Part name: Lead-free solder with resin (0.5 mm dia., 500 g)
Part number: VJ8-0270
Metal content Tin (Sn) Silver (Ag) Copper (Cu)
Composition
ratio by weight 96.5% 3.0% 0.5%
Note:
If replacing existing solder containing lead with lead-free
solder in the soldered parts of products that have been
manufactured up until now, remove all of the existing solder
at those parts before applying the lead-free solder.

-3 -
Image sensor : 1/4-inch
Effective pixels : [VCC-MC600P :752 (Horizontal) x 582 (Vertical)] [VCC-MC600 :768 (Horizontal) x 494 (Vertical)]
Horizontal resolution : Over 520 TV lines
Lens : x30 zoom lens, f=3.5 - 105 mm (F1.4 - 3.7)
Electronic zoom and gearing. Zoom speed setting possible
Electronic zoom : 16 power (combined with optic zoom gives 480 power max)
Max zoom magnification setting possible
Vertical resolution ON/OFF setting
Auto focus : AUT/ONE-PUSH/MANUAL. AF area setting possible (3 step)
Iris control : AUTO/MANUAL
Synchronization method : Internal synchronization/Line lock
V phase adjustment possible
Lowest image illumination : 0.8 lx (F 1.4, AGC gain at maximum, COLOR mode) , 0.04 lx (F 1.4, B/W mode)
0.025 lx (F 1.4, x32 electronic sensitivity increased, COLOR mode) ,
0.00125 lx (F 1.4, x32 SENSE UP, B/W mode)
S/N : Over 50 dB
Backlight compensation : Centerweighted average metering/Multi-spot evaluative metering/Multi-spot metering
Day/Night : AUTO / COLOR / B/W settings available
Electronic shutter :
Fast shutter speed (SHORT) mode : 1/50, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000 (VCC-M600P)
Fast shutter speed (SHORT) mode : 1/60, 1/100, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000 (VCC-M600)
Slow shutter speed (LONG) mode : x1, x2, x4, x8, x16, x32
Electronic sensitivity boosting : AUTO/OFF, works with auto iris
Up to x32 max setting possible
White balance : ATW/AWC/MWB/3200/5600/FLUO (Fluorescent lighting).
AGC gain : Low/Normal/Middle/High/Off (When “OFF” is selected, manual gain adjusement is available.)
Motion detector : ON/OFF, individual settings possible
Aperture : H/V setting possible
Privacy masking : ON/OFF, max of 24 masked locations (Wide view screen; 1 screen max 4 masks)
The mask can be set regardless of the camera’s direction
Alarm input/output : External input x 8, External output x 2, NO/NC switch
Motion detector with external alarm AND/OR output options
Screen titles : ON/OFF, 16 characters
Preset functions : 8 settings
Auto mode : Sequential pan/auto pan/tour (4 patterns each)
Rotation range : Horizontal: 360 ° endless, Vertical : -5 ° - 185 °
Rotation speed : Horizontal- Preset: 435 °/second. Manual : 0.1 ° - 120 °/second
Vertical- Preset: 400 °/second. Manual : 0.1 ° - 120 °/second
Preset positions : 128 positions
Communications : Coaxial control, RS-485
Operational temperature/humidity : -10 °C - + 50 °C/below 90 % RH
Power source : DC 24 V
Weight : Approx. 1560 g (58.3 oz)
Dimensions [ mm (inch)] : W170.5(67.2) x H155.5(61.3) x D156.5(61.7) , Dome 170.5(67.2)
Power supply : AC 24 V ± 10 %, 50/60 Hz
Power consumption : 16 W
Weight : Approx. (480 g 17oz)
Dimensions [ mm (inch)] : W186(73.3) x H54(21.3) x D166(65.4) , Dome 186(73.3)
SPECIFICATIONS
VCC-MC600P, VCC-MC600
VA-84S

-4 -
The following parts can deteriorate and become worn as a
result of repeated pan and tilt operations, and this can result
in problems occurring such as vibration while pan/tilt
operations are carried out, position errors during sequencing
operation, and failure to operate. These parts should be
replaced periodically after roughly either 1.2 million operations
or 2 years.
MOTOR,FAN should be replaced periodically after roughly 3.5
years.
1.MAINTENANCE
1.Maintenance Table
When replacing parts, check the PAN COUNT and TILT
COUNT values in MTR-COUNT, and at the same time be sure
to clear the counter values.
1.Use the system controller to display the camera menu on
the monitor.
2.Use the SELECT button to move the cursor to “OPTION”.
Move the SELECT button to [Right] -> [Right] -> [Left] ->
[Left] in that order and then press the SET button to
display the SERVICE MENU screen.
The number of pan motor and tilt motor operations will be
displayed in MTR-COUNT, so check the counter values.
3.When replacing parts, clear the counter values.
Use the SELECT button to move the cursor to the PAN
counter value in “MTR-COUNT”, and then operate the
SELECT button in the order [Right] -> [Right] -> [Left] ->
[Left] and press the SET button to clear the PAN/TILT
counter values.
SERVICE MENU
CAMERA VER
MAIN VER
SSP VER
MTR-COUNT PAN
TILT
0 0
0 0
INITIAL OFF
MENU END
BACKUP SAVE
MTR-COUNT is used as a guide for checking the number of
pan/tilt motor operations.
One starting and stopping of the motor as a result of a pan or
tilt operation is counted as one operation, and each time 100
such operations occur, the value in the 100 column is
incremented by one. (The numbers in the 0 and 10 column
are fixed at “0”.)
2. Checking and clearing the counter values for PAN
COUNT and TILT COUNT
PARTS NO.
645 091 0104
645 090 3861
645 090 3878
645 088 7093
DESCRIPTION
ASSY,TERMINAL,SLIP RING
ASSY,MOTOR STEPPING PAN
ASSY,MOTOR STEPPING TIL
LENS(ASSY),X30
PARTS NO.
645 091 5192
DESCRIPTION
MOTOR,FAN DC 0.55W

-5 -
E
23
24
25
25
26
27
27
33
29
28
30
31
32
(R) 32 31
2. DISASSEMBLY
2-1. REMOVAL OF CABINET, COVER, SY-1 BOARD AND CAMERA MODULE PART
1. DEC cover
2. Four screws 2.6 x 4
3. Cover inner pan
4. Assy wire - CN492
5. Four screws 4 x 8
6. Cabinet main
7. Screw 2 x 4
8. Two screws 2 x 3
9. Cover inner tilt
10. Screw 2 x 4
11. Two screws 2 x 3
12. Cover inner tilt
13. Five screws 3 x 6
14. Five fixers
15. Assy wire - CN403 4pin
16. Assy wire - CN407 7pin
17. Assy wire - CN404 4pin
18. FPC - CN401
19. Four screws 2 x 6
20. SY-1 board
21. Two screws 2 x 6
22. Holder FPC B
23. Assy wire - CN302
24. Motor fan
25. Four screws 2 x 4
26. FPC - CN204
27. Three screws 2 x 4
28. Two screws 2 x 4
29. Two screws 2 x 6
30. Holder FPC A
31. Holder magnet
32. Magnet
A red line is the lower side (R)
33. Compl, Camera module unit
1
2
4
3
7
10
2
5
5
68
9
12 11
15
17
16
18
20
19
19
21
22
14
13
13
14
14
13
5
21

-6 -
31
35
36
36
40
40
37
38
38
38
38
32
33
34
31
32
33
34
35
39
41
42
BB
23
24
25
26
26
27
25
26
27
27
28
29
30
22
21
18
20
19
20
B
B
C
A
A
C
1
2
2
6
3
3
4
5
7
8
9
9
9
10
11
12
13
13 14
15
16
17
2-2. REMOVAL OF CA-3 BOARD, CA-2 BOARD, CA-1 BOARD, TB-1 BOARD AND BOARD LOCATION
1. Two screws 2 x 3
2. Two screws 2 x 3
3. Two screws 2 x 3
4. Holder lens R
5. CA-3 board
6. FPC - CN205
7. Two screws 2 x 3
8. CA-2 board
9. Three screws 2 x 5
10. Holder lens L
11. Screw 2 x 3
12. CA-1 board
13. Two screws 2 x 5
14. Assy, unit, CCD
15. Spacer CCD
16. Optical filter
The direction of the arrow is
long. It installs it in the direction
of figure.
17. Lens 18. Screw 3 x 6
19. Screw 2 x 6
20. Three screws 2 x 4
21. Cover safety wire
22. Mounting safety wire
23. Two screws 2 x 4
24. TB-1 board
25. Four screws 2 x 12
26. Four washers
27. Four pipes
28. Motor fan
29. Assy wire - CN494
30. Eight spacer fan
31. Two screws 3 x 8
32. Two washers
SY-1 board
CA-1 board
CA-3 board
CA-2 board
TB-1 board
33. Two pipes
34. Lever lock
35. Two screws 2 x 4
36. Spring lever
37. Spacer dome
38. Spacer
39. Cover dust
40. Spacer lever
41. Fixer clamp
42. Cabinet main

-7 -
3
1
21
4
3
4
5
6
7
8
9
9
10
13
11
11
13
12
16
14
15
18
16
17
19
20
21
23
27
30
28
29
23
31
24
24
25
26
22 22
7
8
(R)
2-3. REMOVAL OF STEPPING MOTOR AND GEAR
1. Three screws 2.6 x 4
2. Holder SY-1
3. Three screws 3 x 6
4. Three screws 3 x 6
5. Spacer slip ring
6. Turn of assy, terminal, slip ring
7. Magnet
A red line is the left side (R)
8. Spacer magnet
9. Three screws 3 x 10
10. Assy, terminal, slip ring
11. Three screws 2 x 4
(tightening torque:0.15-0.20N m)
(New screws should be used)
12. Holder
13. Three springs
14. Gear
15. Gear
16. Two screws 3 x 6
17. Two screws 3 x 6
18. Assy, motor stepping tilt
19. Two screws 3 x 6
20. Assy, motor stepping pan
21. Chassis
22. Damper fan motor
23. Three screws 2 x 4
(tightening torque:0.15-0.20N m)
(New screws should be used)
24. Three springs
25. Gear
26. Gear
27. Two screws 3 x 4
28. Mounting, bearing
(It installs it while pushing)
29. Two bearinngs
30. Housing, bearing
31. Assy,holder cam unit

-8 -
A
A
1
23
4
5
6
8
7
78
10
9
11
12
13 14
14
14
15
16
18
16 17
19
20
2-4. REMOVAL OF POWER BOARD UNIT
1. Assy wire CN612
2. TB-3 board
3. Spacer TB3
4. Two screws 1.7 x 5
5. TB-2 board
6. Assy wire CN761
7. Two screws 2 x 6
8. Two screws 2 x 6
9. PW-1 board
10. Assy wire CN603
11. Screw 2 x 6
12. Three screws 2 x 6
13. CP-1 board
14. Five screws 2 x 6
15. Holder PWB
16. Shaft lock
17. Spacer shaft
18. Earth lock
19. Cover bottom
20. Fixer clamp

-9 -
3-3-1. Computer screen during adjustment
3-3-2. Adjustment parts
3. ADJUSTMENT
3-1. ADJUSTMENT CONDITION
1. Use the 5,100K viewer for the subject. (color temperature
: 5500 ± 100 k, luminosity : 1000 ± 100 cd/m )
2. Set the trigger signal of oscilloscope to VIDEO OUT, and
apply H sync unless specified.
3. In adjustments without direction to display charts, shield
light with a lens cap to provide dark condition.
4. Connect the video output to a video monitor with an input
impedance of 75 ohms.
3-2. PREPARATION
1. Install the adjustment software (VHJ-0179) in a computer
running the Windows operating system.
2. Use the adjustment tool (VHJ-0127) to connect the
camera to be adjusted to the serial port (COM1) of the
computer with RS-232C cross cable (
Inter link cross cable,
VHJ-0149), and then turn on the power for the computer .
3-3. TABLE FOR SERVICING TOOLS
Ref. No. Name Part code
J-2
J-3
J-4 VHJ-0126
VHJ-0149
Commander cable (spare)
Adjustment jig
Inter link cross cable VHJ-0127
J-1 VJ8-0007
Color viewer
J-5
VHJ-0179
Calibration software
J-7
VJ8-0009
Gray scale chart
Color bar chart VJ8-0010
J-6
Collimator
J-8
VJ8-0260
2
CA-2 BOARD
SIDE B
BUST
F LOCK
Y GAIN
R GAIN
R HUE
B HUE
VHJ-0179
0
0
0
0
0
START END
CLOSE
AUTO
LENS X
LENS Y
0
0
TELE
TRIG
TELE
0
SYNC
STATUS
IRIS
0
AUTO
LENS T
B GAIN
F LOCK
R
B
LOCK
LOCK
AUTO
WDD
CN204
TP203
TP201
TP200
CT202
CT252
TP202
CT201

-10 -
3-4. Iris Adjustment
Adjustment location: Computer screen
Measuring location: Computer screen
Adjusting method:
1. Click the adjustment software installed from the personal
computer, and the adjustment window will be displayed.
2. Click the START button.
3. In IRIS adjustment mode, Click the AUTO button of IRIS.
4. When “AUTOADJ. NG” display, carry out the adjustment
again.
3-5. Lens Tracking Adjustment
Adjustment location: Computer screen
Measuring location: Computer screen,
CN204 pin6 (VIDEO OUT)
Measuring equipment: Collimator, Monitor
Subject: Siemens star chart
Adjusting method:
1. Set the camera unit lens 10 ± 5 mm from the collimator.
(Do not enter any light.)
2. Use the “ ” button to be LENS T in the adjustment window.
3. Display the siemens star chart at centered picture angle.
4. Click the AUTO button of LENS T.
5. When “AUTOADJ. NG” display, carry out the adjustment
again.
3-6. Privacy Masking Compensation
Adjustment location: Computer screen
Measuring location: Computer screen,
CN204 pin6 (VIDEO OUT)
Measuring equipment: Collimator, Monitor
Subject: Siemens star chart
Adjusting method:
1. Set the camera unit lens 10 ± 5 mm from the collimator.
(Do not enter any light.)
2. Use the “ ” button to select TELE below LENS T in order
to display the masking correction screen.
3.Carefully align the center of the Siemens star chart with
the “+” mark in the center of the screen.
4. Operate “LENS X” with the mouse to adjust the masking
area that is displayed so that it is at an even distance at
left and right from the center of the Siemens star chart.
5. Operate “LENS Y” with the mouse to adjust the masking
area that is displayed so that it is at an even distance
above and below the center of the Siemens star chart.
10 ± 5 mm Siemens star chart
Collimator
Camera module unit
10 ± 5 mm
Collimator
Camera module unit
Siemens star chart
6. Use the “ ” button to select TELE below LENS Y, and
check that there is an even amount of space between the
masking area on the TELE screen and the top, bottom,
left and right edges of the monitor screen.
If there is a large amount of difference in the spaces, re-adjust.

-11 -
3-10. Y-Gain Adjustment
Adjustment location: Computer screen
Measuring location: CN204 pin6 (VIDEO OUT)
Measuring equipment: Oscilloscope
Subject: Gray scale chart
Adjusting method:
1. Display the gray scale chart at designated picture angle.
2. Use the “ ” button to be F LOCK in the adjustment
window.
3. Click the LOCK button.
4. Use the “ ” button to be YGAIN in the adjustment
window.
5. Shield light with a lens cap to provide dark condition.
6. Use the computer’s mouse to adjust the YGAIN in the
adjustment window so that the video out terminal is 700 ±
10 mVp-p.
3-11. Hue and Chroma Adjustment
Adjustment location: Computer screen
Measuring location: CN204 pin6 (VIDEO OUT)
Measuring equipment: Oscilloscope, vectorscope
Subject: Color bar chart
1. Use the “ ” button to be R GAIN in the adjustment window.
2. Display the color bar chart at designated picture angle.
3. Shield light with a lens cap to provide dark condition.
4. Select the R GAIN and B GAIN by using the “ ” and “ ”
button in the adjustment window.Adjust by operating level
scroll bar so that the red and yellow luminescent spots are
the size and position which are designated in the vectorscope.
5. Select the R HUE and B HUE by using the “ ” and “ ”
button in the adjustment window. Adjust by operating level
scroll bar so that the red and yellow luminescent spots are
the size and position which are designated in the vectorscope.
3-7. Frequency Adjustment (INT)
Adjustment location: CT252, CT202 (CA-2)
Measuring location: TP203, TP202 (CA-2)
Measuring equipment: Frequency counter, Digital voltmeter
Subject: No designation
Adjusting method:
1. Adjust with CT252 so that the frequency of TP203 is
17734475 Hz ± 50 Hz (VCC-MC600P) or 14318180 Hz ±
50 Hz (VCC-MC600).
2. Adjust with CT202 so that the voltage of TP202 is 7.0 V ±
0.5 V (VCC-MC600P only).
3-8. Frequency Adjustment (L-L)
Adjustment location: CT201 (CA-2)
Measuring location: TP201 (CA-2)
Measuring equipment: Digital voltmeter
Subject: No designation
Adjusting method:
1. Use the “ ” button to select the TRIG in the frequency
adjustment window.
2. Input a pulse signal to the pin 8 of CN204.
3. Adjust with CT201 so that the voltage of TP201 is 7.0 V ±
0.5 V.
3-9. SYNC and BURST Level Adjustment
Adjustment location: Computer screen
Measuring location: CN204 pin6 (VIDEO OUT)
Measuring equipment: Oscilloscope
Subject:
Adjusting method:
1. Shield light with a lens cap to provide dark condition.
2. Use the “ ” button to be SYNC in the adjustment window.
3. Use the computer’s mouse to adjust the SYNC in the
adjustment window so that the video out terminal is 300 ± 5
mVp-p (VCC-MC600P) or 286 ± 5 mVp-p (VCC-MC600).
4. Use the “ ” button to be BURST in the adjustment
window.
5. Use the computer’s mouse to adjust the BURST in the
adjustment window so that the video out terminal is 300 ±
5 mVp-p (VCC-MC600P) or 286 ± 5 mVp-p (VCC-MC600).
50Hz ± 0.25Hz (VCC-MC600P)
60Hz ± 0.25Hz (VCC-MC600)
5V
PULSE SIGNAL
VIDEO OUT
300 mV ± 5 mV
or
286 mV ± 5 mV
sync
burst
300 mV ± 5 mV
or
286 mV ± 5 mV
VIDEO OUTPUT
700 mV ± 10 mV
35 µsec

-12 -
3-12. CCD White Point Defect Detect Adjustment
Measuring location: CN204 pin6 (VIDEO OUT)
Measuring equipment: Monitor display
Adjustment method:
1. Shield light with a lens cap to provide dark condition.
2. Use the “ ” button to be WDD in the adjustment window.
3. Click the AUTO button.
4. After completing the CCD White Defect Detect adjustment,
it comfirms that white point can not be seen on the monitor
display.
5. Click the END button.
6. Click the Close button.
45 µsec
R
YL
MG
CY
G
B
Q
100%
75%
YL R
W
R
YL
MG
Cy
G
B
75%
100%
cy
g
yl
mg
b
U
v
YL R
W
VCC-MC600P
VCC-MC600

13
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
ELECTRICAL PARTS
Note:
1. Materials of Capacitors and Resistors are abbreviated as follows ;
Resistors Capacitors
MT-FILM Metallized Film Resistor MT-POLYEST Metallized Polyester Capacitor
MT-GLAZE Metallized Glaze Resistor MT-COMPO Metallized Composite Capacitor
OXIDE-MT Oxide Metallized Film Resistor TA-SOLID Tantalum Solid Capacitor
AL-SOLID Aluminum Solid Capacitor
NP-ELECT Non-Polarized Electrolytic Capacitor
OS-SOLID Aluminum Solid Capacitors with Organic
Semiconductive Electrolytic Capacitor
DL-ELECT Double Layered Electrolytic Capacitor
POS-SOLID Polymerized Organic Semiconductor Capacitor
2. Tolerance of Capacitor (10pF over) and Resistor are noted with follow symboles.
F ............1% G ............2% J ............5% K ............10%
M ..........20% N ..........30% Z ..........+80% ~ -20%
3. Capacitors
U : µF P : pF
4. Inductors
UH : µH MH : mH
5. N.S.P. : Not available as service parts.
4. PARTS LIST (R)
COMPL PWB,CA-1
613 211 2932
(SEMICONDUCTOR)
Q1102 305 153 6702 TR 2SC3931-D
(INTEGRATED CIRCUIT)
IC102 309 446 8701 IC CXD3400N
IC103 310 607 4302 IC AD9948AKCPZW
IC105 309 534 2703 IC XC6201P332M
(DIODE)
D1101 307 210 1903 DIODE 1SS400
(INDUCTOR)
L1301 945 066 4725 IMPEDANCE,600 OHM P
(CAPACITORS)
C1102 303 338 0309 CERAMIC 0.1U K 10V
C1103 303 338 0309 CERAMIC 0.1U K 10V
C1106 303 342 3303 CERAMIC 0.1U K 25V
C1108 303 420 7209 CERAMIC 10U K 10V
C1109 303 338 0309 CERAMIC 0.1U K 10V
C1110 303 420 7902 CERAMIC 10U K 16V
C1111 303 420 7902 CERAMIC 10U K 16V
C1112 303 397 7608 CERAMIC 1U K 25V
C1113 303 342 3303 CERAMIC 0.1U K 25V
C1114 303 420 7902 CERAMIC 10U K 16V
C1115 303 155 1800 CERAMIC 0.01U K 25V
C1116 303 283 5701 CERAMIC 2200P K 50V
C1117 303 155 1800 CERAMIC 0.01U K 25V
C1118 303 420 7902 CERAMIC 10U K 16V
C1121 303 420 7209 CERAMIC 10U K 10V
C1122 303 420 7902 CERAMIC 10U K 16V
C1123 303 420 7902 CERAMIC 10U K 16V
C1135 303 323 6309 CERAMIC 0.1U K 16V
C1137 303 342 3303 CERAMIC 0.1U K 25V
C1138 303 323 6309 CERAMIC 0.1U K 16V
C1139 303 323 6309 CERAMIC 0.1U K 16V
C1301 303 338 0309 CERAMIC 0.1U K 10V
C1302 303 384 6508 CERAMIC 10U K 6.3V
C1304 303 384 6508 CERAMIC 10U K 6.3V
C1305 303 338 0309 CERAMIC 0.1U K 10V
C1307 303 338 0309 CERAMIC 0.1U K 10V
C1308 303 384 6508 CERAMIC 10U K 6.3V
C1309 303 338 0309 CERAMIC 0.1U K 10V
C1310 303 312 6808 CERAMIC 0.1U Z 16V
C1314 303 338 0309 CERAMIC 0.1U K 10V
C1316 303 384 6508 CERAMIC 10U K 6.3V
C1319 303 338 0309 CERAMIC 0.1U K 10V
C1321 303 378 5302 CERAMIC 1U K 10V
C1323 303 378 5302 CERAMIC 1U K 10V
C1324 303 381 8109 CERAMIC 1U K 6.3V
CB101 303 392 5500 CERAMIC 1U K 6.3V
VCC-MC600P/MC600
(RESISTOR PACKS)
RB101 945 049 0690 R-NETWORK 33X4 1/16W
RB102 945 049 0690 R-NETWORK 33X4 1/16W
RB103 945 049 0690 R-NETWORK 33X4 1/16W
(RESISTORS)
R1101 301 225 0906 MT-GLAZE 82K JA 1/16W
R1102 301 224 8903 MT-GLAZE 100K JA 1/16W
R1103 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R1104 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R1105 301 235 1405 MT-GALZE 1.2K JA 1/16W
R1106 301 224 9405 MT-GLAZE 1.0M JA 1/16W
R1109 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R1121 301 224 9009 MT-GLAZE 10K JA 1/16W
R1122 301 224 9009 MT-GLAZE 10K JA 1/16W
R1141 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R1304 301 225 8100 MT-GLAZE 10 JA 1/16W
R1305 301 225 8100 MT-GLAZE 10 JA 1/16W
R1306 301 225 8100 MT-GLAZE 10 JA 1/16W
R1307 301 148 6009 MT-GLAZE 2.2 JA 1/16W
R1311 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
(CONNECTOR)
CN102 645 075 5378 PLUG,PWB-PWB 50P (N.S.P)
COMPL PWB,CA-2 F/W
613 211 3113 VCC-MC600P ONLY
613 211 3120 VCC-MC600 ONLY
(SEMICONDUCTORS)
Q2001 305 167 0307 TR EMD3
Q2004 305 167 0307 TR EMD3,VCC-MC600P ONLY
Q2088 305 165 1108 TR EMH11
Q2101 305 168 4502 TR 2SA2029-R
Q2102 305 172 8800 TR 2SC5658-R
Q2103 305 168 4502 TR 2SA2029-R
Q2104 305 172 8800 TR 2SC5658-R
Q2450 305 165 1108 TR EMH11
(INTEGRATED CIRCUITS)
IC201 310 558 7001 IC SCC0030A A
IC202 309 320 9107 IC TC7SU04FU
IC203 309 323 9005 IC TC7S04FU
IC205 309 320 9107 IC TC7SU04FU,VCC-MC600P ONLY
IC206 309 323 9005 IC TC7S04FU,VCC-MC600P ONLY
IC208 409 678 8309 IC UPC358GR-9LG-A
IC214 309 478 2203 IC NJM2274R
IC231 410 623 2808 IC UPD70F3716GC-8EA-A (N.S.P.)
IC232 410 626 3901 IC AT24C128-10TU-2.7
IC233 309 541 4806 IC BD4829G
IC234 410 635 0106 IC UPD6467GR-580-A
OR 410 635 0205 IC UPD6467GR-001-A

14
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTIONLOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
IC236 309 673 7300 IC W9816G6CH-7
IC251 309 320 9107 IC TC7SU04FU
IC252 309 323 9005 IC TC7S04FU
IC261 309 610 7707 IC UPD168117K9-9B4-A
IC262 309 646 8709 IC AK7331
IC273 309 400 9102 IC TC7SET08FU
IC274 309 330 2501 IC TC7SH04FU
IC281 309 577 8304 IC LB1906CL-E
(DIODES)
D2001 307 215 9201 DIODE MA365(E)
D2002 307 215 9201 DIODE MA365(E),VCC-MC600P ONLY
D2140 307 210 1903 DIODE 1SS400
D2751 307 248 2408 ZENER DIODE EDZ7.5B
D2752 307 248 2408 ZENER DIODE EDZ7.5B
D2753 307 248 2408 ZENER DIODE EDZ7.5B
D2754 307 248 2408 ZENER DIODE EDZ7.5B
D2755 307 248 2408 ZENER DIODE EDZ7.5B
D2756 307 248 2408 ZENER DIODE EDZ7.5B
D2757 307 248 2408 ZENER DIODE EDZ7.5B
D2758 307 248 2408 ZENER DIODE EDZ7.5B
D2759 307 229 6807 DIODE RSX101M-30
(OSCILLATORS)
X2001 645 055 5299 OSC,CRYSTAL 14.1875MHZ,VCC-MC600P ONLY
X2140 945 053 3878 OSC,CERAMIC 5.00MHZ
X2501 645 049 0590 OSC,CRYSTAL 14.31818MHZ,VCC-MC600 ONLY
X2501 645 055 5282 OSC,CRYSTAL 17.734475MHZ,
VCC-MC600P ONLY
(TRIMMERS)
CT201 645 069 5131 TRIMMER,30PF
CT202 645 069 5131 TRIMMER,30PF,VCC-MC600P ONLY
CT252 645 069 5131 TRIMMER,30PF
(INDUCTORS)
L2001 945 043 5882 INDUCTOR,10U J
L2002 945 007 6863 INDUCTOR,5.6U J
L2003 945 043 5899 INDUCTOR,47U J
L2040 945 043 5882 INDUCTOR,10U J
L2101 945 043 5882 INDUCTOR,10U J
L2121 945 055 3135 INDUCTOR,68U J
L2131 945 043 7381 INDUCTOR,33U J
L2141 945 043 5882 INDUCTOR,10U J
L2142 945 043 5882 INDUCTOR,10U J
L2301 945 043 5882 INDUCTOR,10U J
L2302 945 043 5882 INDUCTOR,10U J
L2303 945 043 5882 INDUCTOR,10U J
L2304 945 043 5882 INDUCTOR,10U J
L2305 945 043 5882 INDUCTOR,10U J
L2306 945 043 5882 INDUCTOR,10U J
L2603 645 018 3553 INDUCTOR,1000 OHM
L2604 645 018 3553 INDUCTOR,1000 OHM
L2605 645 018 3553 INDUCTOR,1000 OHM
L2606 645 018 3553 INDUCTOR,1000 OHM
(CAPACITORS)
C2001 303 418 0007 CERAMIC 4.7U K 25V
C2002 303 397 7608 CERAMIC 1U K 25V
C2004 303 164 0207 CERAMIC 0.1U Z 25V
C2006 303 276 1000 CERAMIC 0.01U K 16V,
VCC-MC600P ONLY
C2007 303 276 1000 CERAMIC 0.01U K 16V,
VCC-MC600P ONLY
C2008 303 338 0309 CERAMIC 0.1U K 10V,VCC-MC600P ONLY
C2011 303 420 7209 CERAMIC 10U K 10V
C2012 303 338 0309 CERAMIC 0.1U K 10V
C2013 303 338 0309 CERAMIC 0.1U K 10V
C2014 303 276 1000 CERAMIC 0.01U K 16V
C2015 303 276 1901 CERAMIC 22P J 50V
C2016 303 276 1307 CERAMIC 1000P K 50V
C2018 303 418 0007 CERAMIC 4.7U K 25V
C2019 303 420 7209 CERAMIC 10U K 10V
C2020 303 338 0309 CERAMIC 0.1U K 10V,VCC-MC600P ONLY
C2021 303 420 7209 CERAMIC 10U K 10V,VCC-MC600P ONLY
C2022 303 276 1307 CERAMIC 1000P K 50V,
VCC-MC600P ONLY
C2023 303 276 1307 CERAMIC 1000P K 50V,
VCC-MC600P ONLY
C2026 303 420 7209 CERAMIC 10U K 10V
C2027 303 338 0309 CERAMIC 0.1U K 10V
C2028 303 338 0309 CERAMIC 0.1U K 10V
C2030 303 309 8204 CERAMIC 6P D 50V
C2031 303 418 0007 CERAMIC 4.7U K 25V
C2033 303 418 0007 CERAMIC 4.7U K 25V,VCC-MC600P ONLY
C2040 303 420 7209 CERAMIC 10U K 10V
C2080 303 338 0309 CERAMIC 0.1U K 10V
C2109 303 378 3605 POS-SOLID 33U M 10V
C2111 303 276 2809 CERAMIC 18P J 50V,VCC-MC600P ONLY
C2111 303 309 2509 CERAMIC 27P J 50V,VCC-MC600 ONLY
C2115 303 349 1401 CERAMIC 0.01U K 25V
C2123 303 338 0309 CERAMIC 0.1U K 10V
C2132 303 305 8505 CERAMIC 15P J 50V
C2133 303 305 8505 CERAMIC 15P J 50V
C2140 303 338 0309 CERAMIC 0.1U K 10V
C2142 303 338 0309 CERAMIC 0.1U K 10V
C2143 303 338 0309 CERAMIC 0.1U K 10V
C2144 303 393 2607 CERAMIC 22U M 6.3V
C2145 303 381 4804 ELECT 100U M 6.3V
C2146 303 378 5302 CERAMIC 1U K 10V
C2149 303 338 0309 CERAMIC 0.1U K 10V
C2150 303 420 7209 CERAMIC 10U K 10V
C2151 303 338 0309 CERAMIC 0.1U K 10V
C2160 303 393 2607 CERAMIC 22U M 6.3V
C2161 303 338 0309 CERAMIC 0.1U K 10V
C2162 303 338 0309 CERAMIC 0.1U K 10V
C2163 303 387 3009 CERAMIC 4.7U K 10V
C2164 303 338 0309 CERAMIC 0.1U K 10V
C2165 303 338 0309 CERAMIC 0.1U K 10V
C2166 303 420 7209 CERAMIC 10U K 10V
C2301 303 420 7209 CERAMIC 10U K 10V
C2302 303 338 0309 CERAMIC 0.1U K 10V
C2303 303 338 0309 CERAMIC 0.1U K 10V
C2304 303 338 0309 CERAMIC 0.1U K 10V
C2305 303 338 0309 CERAMIC 0.1U K 10V
C2306 303 338 0309 CERAMIC 0.1U K 10V
C2307 303 338 0309 CERAMIC 0.1U K 10V
C2308 303 338 0309 CERAMIC 0.1U K 10V
C2309 303 338 0309 CERAMIC 0.1U K 10V
C2310 303 338 0309 CERAMIC 0.1U K 10V
C2311 303 420 7209 CERAMIC 10U K 10V
C2312 303 338 0309 CERAMIC 0.1U K 10V
C2313 303 420 7209 CERAMIC 10U K 10V
C2314 303 338 0309 CERAMIC 0.1U K 10V
C2315 303 338 0309 CERAMIC 0.1U K 10V
C2316 303 338 0309 CERAMIC 0.1U K 10V
C2317 303 338 0309 CERAMIC 0.1U K 10V
C2318 303 420 7209 CERAMIC 10U K 10V
C2319 303 338 0309 CERAMIC 0.1U K 10V
C2320 303 393 2607 CERAMIC 22U M 6.3V
C2321 303 393 2607 CERAMIC 22U M 6.3V
C2322 303 338 0309 CERAMIC 0.1U K 10V
C2324 303 338 0309 CERAMIC 0.1U K 10V
C2325 303 338 0309 CERAMIC 0.1U K 10V
C2330 303 420 7209 CERAMIC 10U K 10V
C2331 303 338 0309 CERAMIC 0.1U K 10V
C2333 303 338 0309 CERAMIC 0.1U K 10V
C2450 303 338 0309 CERAMIC 0.1U K 10V
C2501 303 338 0309 CERAMIC 0.1U K 10V
C2502 303 276 1901 CERAMIC 22P J 50V,VCC-MC600P ONLY
C2502 303 276 2908 CERAMIC 12P J 50V,VCC-MC600 ONLY
C2601 303 382 7804 CERAMIC 2.2U K 10V
C2603 303 276 1307 CERAMIC 1000P K 50V
C2604 303 276 1307 CERAMIC 1000P K 50V
C2605 303 276 1307 CERAMIC 1000P K 50V
C2606 303 276 1307 CERAMIC 1000P K 50V
C2608 303 420 7209 CERAMIC 10U K 10V
C2610 303 294 6100 CERAMIC 100P J 50V
C2611 303 338 0309 CERAMIC 0.1U K 10V
C2613 303 338 0309 CERAMIC 0.1U K 10V
C2615 303 382 7804 CERAMIC 2.2U K 10V
C2616 303 382 7804 CERAMIC 2.2U K 10V
C2651 303 338 0309 CERAMIC 0.1U K 10V
C2652 303 317 1709 CERAMIC 6800P K 25V
C2653 303 294 6100 CERAMIC 100P J 50V
C2654 303 338 0309 CERAMIC 0.1U K 10V
C2655 303 378 5302 CERAMIC 1U K 10V
C2656 303 381 8109 CERAMIC 1U K 6.3V
C2659 303 338 0309 CERAMIC 0.1U K 10V
C2660 303 276 1000 CERAMIC 0.01U K 16V
C2661 303 317 1709 CERAMIC 6800P K 25V
C2662 303 282 5108 CERAMIC 470P K 50V
C2663 303 338 0309 CERAMIC 0.1U K 10V

15
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTIONLOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
C2664 303 276 1307 CERAMIC 1000P K 50V
C2665 303 338 0309 CERAMIC 0.1U K 10V
C2703 303 338 0309 CERAMIC 0.1U K 10V
C2706 303 397 7608 CERAMIC 1U K 25V
C2711 303 164 0207 CERAMIC 0.1U Z 25V
C2801 303 378 5302 CERAMIC 1U K 10V
(RESISTOR PACKS)
RB201 945 037 0817 R-NETWORK 0X4 1/16W
RB202 945 037 0817 R-NETWORK 0X4 1/16W
RB203 945 049 0690 R-NETWORK 33X4 1/16W
RB204 945 049 0690 R-NETWORK 33X4 1/16W
RB205 645 078 5023 R-NETWORK 5.6KX2 0.063W
RB231 645 078 5719 R-NETWORK 10KX2 0.063W
RB232 645 078 5719 R-NETWORK 10KX2 0.063W
RB233 945 049 0690 R-NETWORK 33X4 1/16W
RB234 945 049 0690 R-NETWORK 33X4 1/16W
RB236 945 028 0710 R-NETWORK 10KX4 1/16W
RB237 645 078 4941 R-NETWORK 4.7KX2 0.063W
RB243 645 078 4941 R-NETWORK 4.7KX2 0.063W
RB261 645 078 4835 R-NETWORK 33KX2 0.063W
(RESISTORS)
R2001 301 225 8704 MT-GLAZE 120K JA 1/16W
R2002 301 224 9009 MT-GLAZE 10K JA 1/16W
R2003 301 225 1705 MT-GLAZE 39K JA 1/16W
R2004 301 224 9405 MT-GLAZE 1.0M JA 1/16W
R2005 301 227 5602 MT-GLAZE 8.2K JA 1/16W
R2006 301 224 8903 MT-GLAZE 100K JA 1/16W
R2009 301 225 8704 MT-GLAZE 120K JA 1/16W
R2010 301 224 9801 MT-GLAZE 220K JA 1/16W,VCC-MC600P ONLY
R2010 301 226 1506 MT-GLAZE 0.000 ZA 1/16W,VCC-MC600 ONLY
R2011 301 225 1200 MT-GLAZE 4.7K JA 1/16W,VCC-MC600P ONLY
R2012 301 225 1200 MT-GLAZE 4.7K JA 1/16W,VCC-MC600P ONLY
R2013 301 229 3903 MT-GLAZE 180 JA 1/16W,
VCC-MC600P ONLY
R2014 301 225 1200 MT-GLAZE 4.7K JA 1/16W,VCC-MC600P ONLY
R2015 301 224 8903 MT-GLAZE 100K JA 1/16W,VCC-MC600P ONLY
R2016 301 224 9009 MT-GLAZE 10K JA 1/16W,
VCC-MC600P ONLY
R2017 301 226 1506 MT-GLAZE 0.000 ZA 1/16W,VCC-MC600 ONLY
R2019 301 225 1408 MT-GLAZE 47K JA 1/16W
R2020 301 224 9405 MT-GLAZE 1.0M JA 1/16W
R2021 301 224 8903 MT-GLAZE 100K JA 1/16W
R2022 301 225 0500 MT-GLAZE 33K JA 1/16W
R2023 301 158 4002 MT-GLAZE 3.3 JA 1/16W,
VCC-MC600P ONLY
R2024 301 224 9009 MT-GLAZE 10K JA 1/16W,
VCC-MC600P ONLY
R2026 301 224 9009 MT-GLAZE 10K JA 1/16W,
VCC-MC600P ONLY
R2028 301 224 8903 MT-GLAZE 100K JA 1/16W,VCC-MC600P ONLY
R2029 301 224 9405 MT-GLAZE 1.0M JA 1/16W,VCC-MC600P ONLY
R2031 301 224 8804 MT-GLAZE 100 JA 1/16W
R2032 301 224 8804 MT-GLAZE 100 JA 1/16W,
VCC-MC600P ONLY
R2041 301 224 8804 MT-GLAZE 100 JA 1/16W,VCC-MC600 ONLY
R2045 301 224 8804 MT-GLAZE 100 JA 1/16W
R2046 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2049 301 234 4803 MT-GLAZE 3.3 JA 1/16W
R2052 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2121 301 224 9306 MT-GLAZE 1K JA 1/16W
R2122 301 224 9306 MT-GLAZE 1K JA 1/16W
R2123 301 224 9306 MT-GLAZE 1K JA 1/16W
R2124 301 225 1408 MT-GLAZE 47K JA 1/16W
R2125 301 225 1408 MT-GLAZE 47K JA 1/16W
R2126 301 224 9306 MT-GLAZE 1K JA 1/16W
R2131 301 224 9306 MT-GLAZE 1K JA 1/16W
R2132 301 224 9306 MT-GLAZE 1K JA 1/16W
R2133 301 224 9504 MT-GLAZE 2.2K JA 1/16W
R2134 301 224 9306 MT-GLAZE 1K JA 1/16W
R2142 301 166 5305 MT-FILM 68 DC 1/16W
R2162 301 225 1408 MT-GLAZE 47K JA 1/16W
R2164 301 224 9009 MT-GLAZE 10K JA 1/16W
R2165 301 225 1200 MT-GLAZE 4.7K JA 1/16W
R2166 301 224 8903 MT-GLAZE 100K JA 1/16W
R2177 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2204 301 224 9009 MT-GLAZE 10K JA 1/16W
R2205 301 224 9306 MT-GLAZE 1K JA 1/16W
R2207 301 224 9405 MT-GLAZE 1.0M JA 1/16W
R2216 301 226 1506 MT-GLAZE 0.000 ZA 1/16W,VCC-MC600P ONLY
R2217 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2218 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2219 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2220 301 226 1506 MT-GLAZE 0.000 ZA 1/16W,VCC-MC600 ONLY
R2225 301 224 9009 MT-GLAZE 10K JA 1/16W
R2235 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2337 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2343 301 225 0302 MT-GLAZE 33 JA 1/16W
R2344 301 225 0302 MT-GLAZE 33 JA 1/16W
R2345 301 225 0302 MT-GLAZE 33 JA 1/16W
R2349 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2351 301 225 0302 MT-GLAZE 33 JA 1/16W
R2352 301 225 0302 MT-GLAZE 33 JA 1/16W
R2360 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2370 301 225 0302 MT-GLAZE 33 JA 1/16W
R2379 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2390 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2391 301 224 9009 MT-GLAZE 10K JA 1/16W
R2392 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2451 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2453 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2457 301 105 4505 MT-GLAZE 390 JA 1/16W
R2462 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2467 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2468 301 105 4505 MT-GLAZE 390 JA 1/16W
R2469 301 224 9009 MT-GLAZE 10K JA 1/16W
R2501 301 224 9405 MT-GLAZE 1.0M JA 1/16W
R2502 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2607 301 224 9009 MT-GLAZE 10K JA 1/16W
R2608 301 224 9009 MT-GLAZE 10K JA 1/16W
R2609 301 224 9009 MT-GLAZE 10K JA 1/16W
R2610 301 224 9009 MT-GLAZE 10K JA 1/16W
R2611 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2612 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2613 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2614 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2615 301 226 5405 MT-GLAZE 56 JA 1/16W
R2616 301 226 5405 MT-GLAZE 56 JA 1/16W
R2617 301 226 5405 MT-GLAZE 56 JA 1/16W
R2618 301 226 5405 MT-GLAZE 56 JA 1/16W
R2626 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2629 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2651 301 166 8801 MT-FILM 2.2K DU 1/16W
R2652 301 166 9907 MT-FILM 6.8K DU 1/16W
R2653 301 166 8108 MT-FILM 1K DU 1/16W
R2654 301 224 9504 MT-GLAZE 2.2K JA 1/16W
R2655 301 225 8100 MT-GLAZE 10 JA 1/16W
R2656 301 262 1003 MT-GLAZE 33K DC 1/16W
R2658 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2659 301 261 7501 MT-FILM 100K DD 1/16W
R2660 301 261 7501 MT-FILM 100K DD 1/16W
R2661 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2664 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2668 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2669 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2670 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2675 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2677 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2685 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2703 301 225 0302 MT-GLAZE 33 JA 1/16W
R2706 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2709 301 224 9306 MT-GLAZE 1K JA 1/16W
R2712 301 224 9405 MT-GLAZE 1.0M JA 1/16W
R2715 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2716 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2717 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2718 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2751 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2811 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2812 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2813 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2814 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2815 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2816 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2818 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
(FUSE)
F2751 323 031 5203 FUSE 125V 2A
(CONNECTORS)
CN201 645 075 5507 SOCKET,PWB-PWB 50(N.S.P)

16
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
CN202 645 077 0319 PLUG,PWB 7P (N.S.P)
CN203 645 088 3293 PLUG,PWB-PWB 16P (N.S.P)
CN204 645 084 8476 SOCKET,FPC 9P (N.S.P)
CN205 645 073 9620 SOCKET,FPC 29P (N.S.P)
COMPL PWB,CA-3
613 210 6306
(SEMICONDUCTORS)
Q3101 305 195 7200 TR MCH3333-TL-E
Q3102 305 169 7601 TR CPH5809-E
Q3501 305 195 7200 TR MCH3333-TL-E
Q3601 305 169 7601 TR CPH5809-E
Q3801 305 115 5200 TR 2SC4617 R
OR 305 158 2501 TR 2SC4617-S
(INTEGRATED CIRCUIT)
IC301 309 604 7409 IC BD9739KN
(DIODES)
D3002 307 251 2204 DIODE RF001M2S
OR 307 239 5005 DIODE RF071M2S PMDU
D3003 307 206 6301 ZENER DIODE UDZS5.1B-TE17
D3201 307 229 6807 DIODE RSX101M-30
D3301 307 229 6807 DIODE RSX101M-30
D3501 307 229 6807 DIODE RSX101M-30
D3902 307 251 2204 DIODE RF001M2S
OR 307 239 5005 DIODE RF071M2S PMDU
(INDUCTORS)
L3101 945 056 6418 INDUCTOR,10U M
L3201 945 056 6418 INDUCTOR,10U M
L3301 945 056 6418 INDUCTOR,10U M
L3501 945 056 6418 INDUCTOR,10U M
L3601 945 056 6418 INDUCTOR,10U M
(CAPACITORS)
C3001 303 343 3104 CERAMIC 1U K 6.3V
C3002 303 155 1503 CERAMIC 180P J 50V
C3003 303 215 2907 CERAMIC 0.022U K 25V
C3004 303 343 3104 CERAMIC 1U K 6.3V
C3005 303 408 5500 CERAMIC 2.2U K 16V
C3006 303 408 5500 CERAMIC 2.2U K 16V
C3007 303 408 5500 CERAMIC 2.2U K 16V
C3009 303 420 7902 CERAMIC 10U K 16V
C3010 303 420 7902 CERAMIC 10U K 16V
C3011 303 387 8707 CERAMIC 10U K 10V
C3013 303 358 8309 CERAMIC 1U K 10V
C3014 303 343 3104 CERAMIC 1U K 6.3V
C3015 303 358 8309 CERAMIC 1U K 10V
C3016 303 420 7902 CERAMIC 10U K 16V
C3017 303 343 3104 CERAMIC 1U K 6.3V
C3019 303 420 7902 CERAMIC 10U K 16V
C3022 303 420 7902 CERAMIC 10U K 16V
C3027 303 420 7902 CERAMIC 10U K 16V
C3028 303 420 7902 CERAMIC 10U K 16V
C3029 303 387 8707 CERAMIC 10U K 10V
C3030 303 420 7902 CERAMIC 10U K 16V
C3101 303 378 3605 POS-SOLID 33U M 10V
C3102 303 420 7902 CERAMIC 10U K 16V
C3103 303 157 7305 CERAMIC 6800P K 50V
C3104 303 215 1108 CERAMIC 390P J 50V
C3105 303 215 2204 CERAMIC 0.01U K 50V
C3106 303 420 7902 CERAMIC 10U K 16V
C3107 303 298 9602 CERAMIC 0.1U K 16V
C3201 303 378 3605 POS-SOLID 33U M 10V
C3202 303 420 7902 CERAMIC 10U K 16V
C3203 303 157 7107 CERAMIC 2700P K 50V
C3204 303 157 6100 CERAMIC 330P J 50V
C3205 303 275 3005 CERAMIC 0.047U K 16V
C3206 303 420 7902 CERAMIC 10U K 16V
C3207 303 420 7902 CERAMIC 10U K 16V
C3208 303 298 9602 CERAMIC 0.1U K 16V
C3301 303 379 0207 POS-SOLID 68U M 6.3V
C3302 303 420 7902 CERAMIC 10U K 16V
C3303 303 155 2401 CERAMIC 5600P K 50V
C3304 303 215 1108 CERAMIC 390P J 50V
C3306 303 420 7902 CERAMIC 10U K 16V
C3307 303 420 7902 CERAMIC 10U K 16V
C3501 303 387 8707 CERAMIC 10U K 10V
C3502 303 420 7902 CERAMIC 10U K 16V
C3503 303 157 7305 CERAMIC 6800P K 50V
C3504 303 157 6100 CERAMIC 330P J 50V
C3505 303 343 3104 CERAMIC 1U K 6.3V
C3506 303 420 7902 CERAMIC 10U K 16V
C3601 303 420 0606 CERAMIC 10U K 25V
C3602 303 420 7902 CERAMIC 10U K 16V
C3603 303 157 7008 CERAMIC 1800P K 50V
C3604 303 113 0500 CERAMIC 220P J 50V
C3605 303 358 5506 CERAMIC 0.1U K 25V
C3606 303 420 7902 CERAMIC 10U K 16V
C3801 303 343 3104 CERAMIC 1U K 6.3V
C3902 303 420 7902 CERAMIC 10U K 16V
C3903 303 420 7902 CERAMIC 10U K 16V
C3904 303 420 7902 CERAMIC 10U K 16V
C3910 303 420 7902 CERAMIC 10U K 16V
(RESISTORS)
R3001 301 167 0309 MT-FILM 10K DU 1/16W
R3101 301 166 3103 MT-FILM 22K DU 1/16W
R3102 301 166 7309 MT-FILM 470 DU 1/16W
R3103 301 166 9709 MT-FILM 5.6K DU 1/16W
R3104 301 105 0606 MT-GLAZE 10K JA 1/16W
R3105 301 113 6508 MT-GLAZE 6.2K JA 1/16W
R3106 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R3107 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R3108 301 105 0507 MT-GLAZE 1K JA 1/16W
R3201 301 166 3103 MT-FILM 22K DU 1/16W
R3202 301 166 7309 MT-FILM 470 DU 1/16W
R3203 301 166 9709 MT-FILM 5.6K DU 1/16W
R3204 301 105 0606 MT-GLAZE 10K JA 1/16W
R3205 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R3208 301 105 0507 MT-GLAZE 1K JA 1/16W
R3301 301 167 0507 MT-FILM 12K DU 1/16W
R3302 301 166 8108 MT-FILM 1K DU 1/16W
R3303 301 166 9709 MT-FILM 5.6K DU 1/16W
R3304 301 105 2907 MT-GLAZE 22K JA 1/16W
R3305 301 113 6508 MT-GLAZE 6.2K JA 1/16W
R3501 301 167 1405 MT-FILM 33K DU 1/16W
R3502 301 166 9808 MT-FILM 6.2K DU 1/16W
R3503 301 166 9709 MT-FILM 5.6K DU 1/16W
R3504 301 113 6805 MT-GLAZE 11K JA 1/16W
R3505 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R3506 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R3507 301 105 2907 MT-GLAZE 22K JA 1/16W
R3601 301 263 0807 MT-FILM 68K DU 1/16W
R3602 301 167 0408 MT-FILM 11K DU 1/16W
R3603 301 166 9709 MT-FILM 5.6K DU 1/16W
R3604 301 113 6201 MT-GLAZE 3.6K JA 1/16W
R3605 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R3606 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R3607 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R3707 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R3801 301 105 0507 MT-GLAZE 1K JA 1/16W
R3901 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R3902 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R3910 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R3917 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
(CONNECTORS)
CN301 645 088 3286 SOCKET,PWB-PWB 16(N.S.P)
CN302 645 074 0190 PLUG,SIDE-ZR-SM4 (N.S.P)
COMPL PWB,TB-1
613 210 9048
(CAPACITOR)
C4901 303 382 2908 ELECT 10U M 16V
(RESISTOR)
R4901 301 037 5007 MT-GLAZE 0.000 ZA 1/10W
(CONNECTORS)
CN491 645 089 4466 PLUG,PWB-PWB 13P (N.S.P)
CN492 645 076 9757 PLUG,SIDE-ZR-SM4 (N.S.P)
CN494 645 074 0190 PLUG,SIDE-ZR-SM4 (N.S.P)
COMPL PWB,SY-1 F/W
613 211 3175
(SEMICONDUCTORS)
Q4001 305 129 2301 TR UMZ1N
Q4201 305 129 2301 TR UMZ1N

17
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
Q4320 305 131 0203 TR DTC144EUA
Q4321 305 131 0203 TR DTC144EUA
Q4350 305 092 4104 TR 2SC4081-R
(INTEGRATED CIRCUITS)
IC401 309 669 1909 IC TB62209FG
IC402 309 669 1909 IC TB62209FG
IC403 309 336 1201 IC TC4W66FU(BRA,F)
IC404 309 336 1201 IC TC4W66FU(BRA,F)
IC411 410 623 2907 IC UPD70F3728GC-8BT-A (N.S.P.)
IC412 309 537 6104 IC BD4846G
IC413 410 626 3901 IC AT24C128-10TU-2.7
IC421 309 670 6405 IC EW-650B
IC422 309 670 6405 IC EW-650B
IC423 409 678 9900 IC EW-750B
IC424 409 678 9900 IC EW-750B
IC431 309 415 7704 IC TC74VHC14FT
IC432 309 534 2703 IC XC6201P332M
IC433 309 400 9102 IC TC7SET08FU
IC435 309 167 7205 IC NJM2406F
IC451 309 601 0502 IC BD9703FP-E2
IC452 309 601 0502 IC BD9703FP-E2
(DIODES)
D4320 307 198 4200 LED SML-010LT
D4321 307 198 4200 LED SML-010LT
D4401 307 210 1903 DIODE 1SS400
D4501 307 229 6807 DIODE RSX101M-30
D4521 307 229 6807 DIODE RSX101M-30
(OSCILLATOR)
X4001 645 053 8483 OSC,CERAMIC 10.000MHZ
(INDUCTORS)
L4001 645 068 9000 INDUCTOR,10U K
L4201 645 068 9000 INDUCTOR,10U K
L4301 645 068 9000 INDUCTOR,10U K
L4401 645 068 9000 INDUCTOR,10U K
L4501 645 058 0918 INDUCTOR,10U M
L4521 645 058 0918 INDUCTOR,10U M
L4801 645 058 0918 INDUCTOR,10U M
(CAPACITORS)
C4001 303 387 8707 CERAMIC 10U K 10V
C4002 303 155 1800 CERAMIC 0.01U K 25V
C4003 303 387 8707 CERAMIC 10U K 10V
C4004 303 155 1800 CERAMIC 0.01U K 25V
C4005 403 458 1405 ELECT 220U M 35V
C4006 303 155 1800 CERAMIC 0.01U K 25V
C4007 303 281 5208 CERAMIC 0.22U Z 16V
C4008 303 215 2907 CERAMIC 0.022U K 25V
C4009 303 157 6704 CERAMIC 560P K 50V
C4021 303 155 1800 CERAMIC 0.01U K 25V
C4201 303 387 8707 CERAMIC 10U K 10V
C4202 303 155 1800 CERAMIC 0.01U K 25V
C4203 303 387 8707 CERAMIC 10U K 10V
C4204 303 155 1800 CERAMIC 0.01U K 25V
C4205 403 458 1405 ELECT 220U M 35V
C4206 303 155 1800 CERAMIC 0.01U K 25V
C4207 303 281 5208 CERAMIC 0.22U Z 16V
C4208 303 215 2907 CERAMIC 0.022U K 25V
C4209 303 157 6704 CERAMIC 560P K 50V
C4221 303 155 1800 CERAMIC 0.01U K 25V
C4301 303 155 1800 CERAMIC 0.01U K 25V
C4302 303 387 8707 CERAMIC 10U K 10V
C4303 303 392 5005 CERAMIC 22U M 6.3V
C4304 303 164 0207 CERAMIC 0.1U Z 25V
C4305 303 164 0207 CERAMIC 0.1U Z 25V
C4350 303 215 2204 CERAMIC 0.01U K 50V
C4351 303 298 9602 CERAMIC 0.1U K 16V
C4353 303 298 9602 CERAMIC 0.1U K 16V
C4354 303 298 9602 CERAMIC 0.1U K 16V
C4355 303 381 4804 ELECT 100U M 6.3V
C4401 303 387 8707 CERAMIC 10U K 10V
C4402 303 155 1800 CERAMIC 0.01U K 25V
C4403 303 387 8707 CERAMIC 10U K 10V
C4404 303 155 1800 CERAMIC 0.01U K 25V
C4405 303 387 8707 CERAMIC 10U K 10V
C4410 303 155 1800 CERAMIC 0.01U K 25V
C4411 303 387 8707 CERAMIC 10U K 10V
C4420 303 387 8707 CERAMIC 10U K 10V
C4421 303 155 1800 CERAMIC 0.01U K 25V
C4430 303 387 8707 CERAMIC 10U K 10V
C4431 303 155 1800 CERAMIC 0.01U K 25V
C4440 303 387 8707 CERAMIC 10U K 10V
C4441 303 155 1800 CERAMIC 0.01U K 25V
C4450 303 387 8707 CERAMIC 10U K 10V
C4451 303 155 1800 CERAMIC 0.01U K 25V
C4501 303 452 7901 CERAMIC 2.2U K 100V
C4502 303 452 7901 CERAMIC 2.2U K 100V
C4503 303 378 3605 POS-SOLID 33U M 10V
C4504 303 372 7500 CERAMIC 2.2U K 6.3V
C4505 303 358 5506 CERAMIC 0.1U K 25V
C4506 303 420 7902 CERAMIC 10U K 16V
C4521 303 452 7901 CERAMIC 2.2U K 100V
C4522 303 452 7901 CERAMIC 2.2U K 100V
C4523 303 365 2604 OS-SOLID 22U M 16V
C4524 303 372 7500 CERAMIC 2.2U K 6.3V
C4525 303 358 5506 CERAMIC 0.1U K 25V
C4526 303 358 5506 CERAMIC 0.1U K 25V
C4527 303 365 2604 OS-SOLID 22U M 16V
C4601 303 164 0207 CERAMIC 0.1U Z 25V
C4801 303 358 5506 CERAMIC 0.1U K 25V
(RESISTORS)
R4001 301 167 0309 MT-FILM 10K DU 1/16W
R4002 301 241 3806 MT-GLAZE 24K DC 1/16W
R4003 301 036 7200 MT-GLAZE 4.7 JA 1/8W
R4004 301 036 7200 MT-GLAZE 4.7 JA 1/8W
R4005 301 036 7200 MT-GLAZE 4.7 JA 1/8W
R4006 301 036 7200 MT-GLAZE 4.7 JA 1/8W
R4007 301 036 7200 MT-GLAZE 4.7 JA 1/8W
R4008 301 036 7200 MT-GLAZE 4.7 JA 1/8W
R4017 301 113 6201 MT-GLAZE 3.6K JA 1/16W
R4021 301 241 2809 MT-GLAZE 3.3K DC 1/16W
R4023 301 241 5701 MT-GLAZE 18K DC 1/16W
R4024 301 167 0309 MT-FILM 10K DU 1/16W
R4025 301 166 9600 MT-FILM 5.1K DU 1/16W
R4201 301 241 5800 MT-GLAZE 22K DC 1/16W
R4202 301 167 2006 MT-FILM 62K DD 1/16W
R4203 301 036 8900 MT-GLAZE 5.6 JA 1/8W
R4204 301 036 8900 MT-GLAZE 5.6 JA 1/8W
R4205 301 036 8900 MT-GLAZE 5.6 JA 1/8W
R4206 301 036 8900 MT-GLAZE 5.6 JA 1/8W
R4207 301 036 8900 MT-GLAZE 5.6 JA 1/8W
R4208 301 036 8900 MT-GLAZE 5.6 JA 1/8W
R4217 301 113 6201 MT-GLAZE 3.6K JA 1/16W
R4221 301 241 5305 MT-GLAZE 10K DC 1/16W
R4223 301 241 4001 MT-GLAZE 27K DC 1/16W
R4224 301 167 0309 MT-FILM 10K DU 1/16W
R4225 301 166 9600 MT-FILM 5.1K DU 1/16W
R4301 301 105 4208 MT-GLAZE 33K JA 1/16W
R4303 301 105 4208 MT-GLAZE 33K JA 1/16W
R4305 301 105 4208 MT-GLAZE 33K JA 1/16W
R4307 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R4309 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R4320 301 105 4505 MT-GLAZE 390 JA 1/16W
R4321 301 105 4505 MT-GLAZE 390 JA 1/16W
R4350 301 105 0705 MT-GLAZE 100K JA 1/16W
R4351 301 105 0705 MT-GLAZE 100K JA 1/16W
R4352 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R4353 301 105 0507 MT-GLAZE 1K JA 1/16W
R4354 301 105 6004 MT-GLAZE 5.6K JA 1/16W
R4355 301 105 0507 MT-GLAZE 1K JA 1/16W
R4356 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R4357 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R4358 301 105 4208 MT-GLAZE 33K JA 1/16W
R4359 301 105 0606 MT-GLAZE 10K JA 1/16W
R4361 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R4401 301 105 0507 MT-GLAZE 1K JA 1/16W
R4402 301 105 0606 MT-GLAZE 10K JA 1/16W
R4403 301 105 5304 MT-GLAZE 4.7K JA 1/16W
R4405 301 105 0507 MT-GLAZE 1K JA 1/16W
R4410 301 105 5304 MT-GLAZE 4.7K JA 1/16W
R4411 301 105 5304 MT-GLAZE 4.7K JA 1/16W
R4412 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R4420 301 105 0606 MT-GLAZE 10K JA 1/16W
R4430 301 105 0606 MT-GLAZE 10K JA 1/16W
R4440 301 105 0606 MT-GLAZE 10K JA 1/16W
R4450 301 105 0606 MT-GLAZE 10K JA 1/16W
R4451 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R4452 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R4453 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R4458 301 105 0606 MT-GLAZE 10K JA 1/16W

18
R4501 301 166 9709 MT-FILM 5.6K DU 1/16W
R4502 301 105 3508 MT-GLAZE 270K JA 1/16W
R4503 301 105 0705 MT-GLAZE 100K JA 1/16W
R4504 301 166 7309 MT-FILM 470 DU 1/16W
R4505 301 166 3103 MT-FILM 22K DU 1/16W
R4506 301 105 4703 MT-GLAZE 39K JA 1/16W
R4521 301 166 9709 MT-FILM 5.6K DU 1/16W
R4522 301 105 3508 MT-GLAZE 270K JA 1/16W
R4523 301 105 0705 MT-GLAZE 100K JA 1/16W
R4524 301 166 2908 MT-FILM 1.5K DU 1/16W
R4525 301 167 1603 MT-FILM 43K DD 1/16W
R4526 301 105 4703 MT-GLAZE 39K JA 1/16W
R4601 301 105 0606 MT-GLAZE 10K JA 1/16W
R4701 301 105 0606 MT-GLAZE 10K JA 1/16W
R4801 301 105 0408 MT-GLAZE 100 JA 1/16W
R4802 301 105 0408 MT-GLAZE 100 JA 1/16W
R4803 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R4804 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R4805 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R4813 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R4814 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R4815 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R4816 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R4817 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R4818 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R4819 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R4820 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R4821 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R4822 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R4823 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R4824 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R4825 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R4826 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R4827 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R4828 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
(THERMISTOR)
TH461 308 051 1008 TH NCP18XH103J03RB
(CONNECTORS)
CN401 645 089 6132 SOCKET,FFC 9P (N.S.P)
CN402 645 077 0319 PLUG,PWB 7P (N.S.P)
CN403 645 074 0299 PLUG,SIDE-ZR-SM4 (N.S.P)
CN404 645 074 0299 PLUG,SIDE-ZR-SM4 (N.S.P)
CN407 645 076 9757 PLUG,SIDE-ZR-SM4 (N.S.P)
ACCESSORIES & PACKING MATERIALS
9110 613 211 8958 INST MANUAL,A4,English,French,Spanish,
VCC-MC600 ONLY
9110 613 211 4417 INSTRUCTION MANUAL,
English,French,German,Chinese (Simplified),
VCC-MC600P ONLY
9111 613 212 1941 INST MANUAL,SETUP A4,English,French,
Spanish,German,Chinese (Simplified)
9119 645 091 5345 DISC,MANUAL,CD,12 ,Italian
9201 613 203 0465 BAG POLY AIR-0150X0120*NC
9205 645 052 1980 CORE,FERRITE FOR VIDEO CABLE
9206 645 052 1997 CORE,FERRITE FOR PW CODE/ALARM&RS485
7001 613 211 3908 CARTON CASE INNER
7002 645 009 3432 POLY SHEET-0600X0300*NC
7003 613 211 7357 CUSHION SHEET
7004 613 211 3960 REINFORCEMENT,PAD-A
7005 613 211 3977 REINFORCEMENT,PAD-B
7006 613 211 7340 CUSHION,TOP
CABINET & CHASSIS PARTS 1
5001 613 210 9833 DEC COVER
5002 613 210 9840 CABINET MAIN
5003 613 210 9857 LEVER LOCK
5004 613 210 9864 SPRING LEVER
5005 613 211 4615 COVER DUST
5006 613 212 5079 SPACER-L5BU2/XE
5007 613 211 3663 SPACER LEVER
5008 613 211 3656 MOUNTING SAFETY WIRE
5009 613 211 3649 COVER SAFETY WIRE
5010 613 211 7692 SPACER FAN
5016 613 211 6930 LABEL ARROW-RED
5017 613 211 6954 LABEL ARROW-BLUE
5018 613 212 3549 PIPE,FAN
5019 645 041 0314 FIXER,14.2X19.6
5021 613 212 4409 SPACER DOME
M2001 645 091 5192 MOTOR,FAN DC 0.55W
TB-1 613 210 9048 COMPL PWB,TB-1
NJ510 411 191 9107 SCR BIN 3X8
NJ520 411 214 8902 SCR PAN+W 2X4
NJ530 411 197 3307 SCR BIN 2X12
NJ531 411 203 9309 WASHER V 2X6X0.4
NJ540 411 030 5406 SCR BIN 2X4
NJ550 411 087 7705 WASHER V 3X8X0.5
NJ560 613 201 0016 PIPE
NJ570 411 030 7004 SCR BIN 2X6
NJ580 411 030 5406 SCR BIN 2X4
NJ595 411 031 8604 SCR BIN 3X6
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION

19
5007
NJ520
NJ510
NJ550
NJ560
5006
5006
5004
5003
5016
5004
M2001
NJ520
5003
NJ560
NJ550
5002
5006
5006 5019
5001
5005
5017
5007
NJ510 5010
5010
5010
5018
NJ531
NJ530
5018
NJ531
NJ530
5018
NJ531
NJ530
5018
NJ531
NJ530
NJ540
NJ540
TB-1
5010
5010
5010
5008
5009
NJ595
NJ580
NJ580 NJ580
NJ570
5021
5021
EXPLODED VIEW OF THE VCC-MC600P/MC600
CABINET & CHASSIS PARTS 1

20
CABINET & CHASSIS PARTS 2
5011 613 211 7975 COVER INNER TILT
5012 613 211 7982 COVER INNER PAN
6005 613 211 0549 SPACER CCD
6015 613 210 6634 HOLDER LENS L
6020 613 210 6641 HOLDER LENS R
6025 613 211 0556 SPACER SHEET
6040 613 212 2658 SPACER CA-3
8000 613 211 4400 HOLDER-L5BU2
8100 645 091 0104 ASSY,TERMINAL,SLIP RING
8120 613 211 7333 SPACER,SLIP RING
8200 613 212 3532 GEAR-L5BU2
8210 613 212 5444 SPRING-L5BU2
8300 613 211 4387 CHASSIS-L5BU2
8500 613 211 4394 HOLDER,SY1-L5BU2
8600 613 211 4295 ASSY,HOLDER CAM UNIT-L5BU
8605 613 212 2672 DAMPER,FAN MOTOR
8610 613 212 3532 GEAR-L5BU2
8620 613 212 5444 SPRING-L5BU2
8630 613 211 4356 HOUSING,BEARING-L5BU2
8640 613 211 4462 BEARING-L5BU2
8650 613 211 4479 MOUNTING,BEARING-L5BU2
8700 613 211 4486 HOLDER,MAGNET-L5BU2
8710 645 067 6673 MAGNET
8715 613 212 3556 SPACER,MAGNET-L5BU2
8720 613 211 6077 HOLDER,FPC A-L5BU2
8730 613 211 6084 HOLDER,FPC B-L5BU2
8740 613 211 8453 FIXER L5BU2
8800 645 090 3861 ASSY,MOTOR STEPPING PAN
8810 645 090 3878 ASSY,MOTOR STEPPING TIL
9000 645 088 7093 LENS(ASSY),X30
9001 645 090 2758 OPTICAL FILTER
9002 613 211 3205 ASSY,UNIT,CCD PAL,VCC-MC600P ONLY
9002 613 211 5186 ASSY,UNIT,CCD NTSC,VCC-MC600 ONLY
M1001 645 091 5192 MOTOR,FAN DC 0.55W
W1001 613 211 8941 FLEXIBLE PWB,9P
Y1001 636 102 9315 SHIELD TAPE HOLDER LENS R,
VCC-MC600P ONLY
Y1002 636 079 7741 SHIELD TAPE PW2,VCC-MC600P ONLY
CA-1 613 211 2932 COMPL PWB,CA-1
CA-2 613 211 3113 COMPL PWB,CA-2 F/W,VCC-MC600P ONLY
CA-2 613 211 3120 COMPL PWB,CA-2 F/W,VCC-MC600 ONLY
CA-3 613 210 6306 COMPL PWB,CA-3
SY-1 613 211 3175 COMPL PWB,SY-1 F/W
NJ500 411 212 7006 SCR BIN+SW 4X8
NJ600 411 191 1309 SCR S-TPG PAN PCS 2X5
NJ610 411 192 1407 SCR BIN 2X3
NJ630 411 191 1309 SCR S-TPG PAN PCS 2X5
NJ830 411 192 1407 SCR BIN 2X3
NJ840 411 214 8902 SCR PAN+W 2X4
NJ842 411 214 8902 SCR PAN+W 2X4
NJ844 411 214 2207 SCR BIN 2X4
NJ846 411 214 2207 SCR BIN 2X4
NJ847 411 214 5109 SCR PAN 2.6X4
NJ848 411 214 8308 SCR S-TPG BIN 2X4
NJ850 411 191 1804 SCR S-TPG BIN 2X6
NJ860 411 030 7004 SCR BIN 2X6
NJ862 411 197 3000 SCR PAN 2.6X4
NJ864 411 206 9801 SCR BIN 2X6
NJ870 411 006 1906 SCR SET HEX-SCT 3X4
NJ880 411 191 9404 SCR PAN 3X6
NJ882 411 191 9404 SCR PAN 3X6
NJ884 411 031 8604 SCR BIN 3X6
NJ886 411 191 9404 SCR PAN 3X6
NJ888 411 031 8604 SCR BIN 3X6
NJ890 411 192 5702 SCR PAN+SW+W 3X10
LOCATION PARTS NO. DESCRIPTION

21
9000
NJ610
NJ610
Y1001
NJ610
6015
NJ600
6040
9001
6005
9002
CA-2
6025
NJ630
NJ630
NJ600
NJ600
NJ610
CA-1
CA-3
6020
NJ610
NJ610
NJ610 NJ610
NJ610
8640
8600
8300 8810
NJ882
NJ88
2
NJ864
NJ864
W1001
8630
8610
8200
8640
8650
NJ870
8605
8605
8605
NJ840
NJ840
8210
NJ840
8210
NJ844
NJ844
M1001
5011
NJ830
NJ848
NJ844
NJ844
NJ830
NJ848
8800
NJ888
NJ8888740 8740
SY-1 8730
NJ882
NJ882 NJ888
NJ880
NJ880
8720
8700
8710
NJ886
NJ886
NJ850
NJ850
NJ860
N
J860
NJ860
NJ862
NJ862
8500
8200
NJ842
NJ842
NJ842
8620 8620
NJ888
8740 8740
NJ88
8
5011
8610
NJ500 NJ500
8000
NJ862
8100
NJ890
NJ890
8715
8710
8120
NJ890
NJ884
NJ884
NJ884
NJ846
NJ844 NJ844
5012
NJ847
NJ847
NJ847
NJ847
Y1002
Y1002
EXPLODED VIEW OF THE VCC-MC600P/MC600
CABINET & CHASSIS PARTS 2
